Mesa-Boogie Rectifier Stereo User Manual

M
ESA
Owner's Manual
OOGIE
B
Hello from the Tone Farm...
YOU, the smart player and all around intuitive human, have put your trust in us to be your amplifier company. This is something we do not take lightly. Our reward is that we've made a classic amplifier and by choosing this amplifier, you have become part of the MESA family...Welcome! Our goal is to never let you down. Your reward is that you are now the owner of our most popular selling power amp, the 2:100. Bred of fine all tube amp heritage...benefiting from the many patented pioneering MESA/Boogie circuits that led to the refinement of your new instrument. Feel confident, as we do, this product will inspire many hours of musical satisfaction and lasting enjoyment. It was built with you in mind, by players who know the value of a fine musical instrument and the commitment it takes to make great music. The same commitment to quality, value and support we make to you...our new friend.
TABLE OF CONTENTS
Precautions
OVERVIEW 1/2
FRONT PANEL CONTROLS & SWITCHES
LEVEL CONTROLS 2
PRESENCE 2
POWER ON 3
STANDBY 3
MODERN 3
REAR PANEL - SWITCHES & JACKS
INPUTS A / B 4
BIAS SWITCH 4
GROUND LIFT 5
SPEAKER JACKS 5
TUBE BAY 6
DRIVER TUBES 12AX7A 6/7
AC RECEPTACLE 7
LINE FUSE 7
TUBE MAINTENANCE
DIAGNOSING POWER TUBE FAILURE 8
DIAGNOSING PRE-AMP TUBE FAILURES & PROBLEMS 9
Feature Article by Randall Smith On Bias Adjustment 10/12
SPEAKER HOOK-UP GUIDE & IMPEDANCE MATCHING 13/14
POSSIBLE HOOK-UP SCHEMES - Amplifier to Speaker Cabinets 15/18
WIRING EXAMPLES USING THE SIMUL-CLASS 2:100 19/20
Feature Article By Randall Smith On How Tubes Work 21/23
PRECAUTIONS & WARNINGS
Your MESA/Boogie Amplifier is a professional instrument. Please treat it with respect and operate it properly.
USE COMMON SENSE AND ALWAYS OBSERVE THESE PRECAUTIONS:
WARNING: EU: permission from the Supply Authority is needed before connection.
WARNING: Vacuum tube amplifiers generate heat. To insure proper ventilation always make
certain there is at least four inches (100mm) of space behind the rear of the amplifier cabinet. Keep away from curtains or any flammable objects.
WARNING: Do not block any ventilation openings on the rear or top of the amplifier. Do not impede ventilation by placing objects on top of the amplifier which extend past the rear edge of its cabinet.
WARNING: Do not expose the amplifier to rain, moisture, dripping or splashing water. Do not place objects filled with liquids on or nearby the amplifier.
WARNING: Always make certain proper load is connected before operating the amplifier. Failure to do so could pose a shock hazard and may result in damage to the amplifier.
Do not expose amplifier to direct sunlight or extremely high temperatures.
Always insure that amplifier is properly grounded. Always unplug AC power cord before changing fuse or any tubes. When replacing fuse, use only same type and rating.
Avoid direct contact with heated tubes. Keep amplifier away from children.
Be sure to connect to an AC power supply that meets the power supply specifications listed on the rear of the unit. Remove the power plug from the AC mains socket if the unit is to be stored for an extended period of time. If there is any danger of lightning occurring nearby, remove the power plug from the wall socket in advance.
To avoid damaging your speakers and other playback equipment, turn off the power of all related equipment before making the connections.
Do not use excessive force in handling control buttons, switches and controls. Do not use solvents such as benzene or paint thinner to clean the unit. Wipe off the exterior with soft cloth.
Be sure to have the warranty card filled out by the store at which it was purchased and return to
Mesa/Boogie.
YOUR AMPLIFIER IS LOUD! EXPOSURE TO HIGH SOUND VOLUMES MAY CAUSE PERMANENT HEARING DAMAGE !
No user serviceable parts inside. Refer service to qualified personnel. Always unplug AC power before removing chassis.
EXPORT MODELS: Always insure that unit is wired for proper voltage. Make certain grounding conforms with local standards.
READ AND FOLLOW INSTRUCTIONS OF PROPER USAGE.
Operating Instructions
Overview:
MESA/Boogie
. Here the stunning performance of the
Head
when the
Dual
Congratulations on your choice of the
Family. This 2 rack space unit is born of legendary stock and traces its lineage to the mighty
Dual
RECTIFIER STEREO 2:100
as your power amplifier and welcome to the
Dual Rectifier Solo
is faithfully recreated in a stereo format that duplicates the power section exactly
is set to its Silicon Diode rectifier setting. Rectifier tubes were not included in this package, as their size did not permit inclusion along with an overall consensus among players asked, that those needing 200 watts of this type of aggressive power would require the tighter, faster response of the silicon diodes. The eight 6L6 power tubes (4 per side) are fan cooled and kick out 100 watts of all-tube power per channel. Three 12AX7s’ make up the driver section and these are housed inside the unit. Preamp tubes used in this manner rarely wear out as there is little or no exposure to excessive vibration and they are operating under minimal gain require­ments .
RECTIFIER STEREO 2:100
The to a trigger pulse sent by either of its companions, the
is a “smart” power amplifier as it contains the MODERN Switchable Voicing feature. It responds
Rectifier Recording Preamp
or the
TriAxis Programmable Preamp
.
When a cable is connected to the MODERN trigger port and this feature is switched via any tip-to-ground type logic, the negative
2:100
feedback in the power section of the
Triple Rectifier Solo Heads
FRONT VIEW
2:100
and has become the most recorded sound in heavy modern rock.
is reduced, unleashing a sound of true ferocity. This is a trademark sound in the
E N G I N E E R I N G
LEVEL A LEVEL B
MODERN
ONON
Dual
and
REAR VIEW:
WARNING
:
To reduce risk of fire or
electric shock, replace fuse with
same type and rating only. Do not
I N P U T S
RECTO INPUTS RECTO INPUTS
CHAN. B CHAN. A
SPEAKERS
expose this unit to rain or moisture.
BIAS
SWITCH
NORMAL
6L6
EL34
MUST MATCH TUBES SEE OWNERS BOOK
8
OHM
4
OHM
E N G I N E E R I N G
POWER FUSE
120 V~
60 Hz
6 A
MODERN
2:100
WARNING
:
To reduce risk of fire or electric shock, Do not remove cover. No user­serviceable parts inside. Refer servicing to qualified personnel.
GROUND
SWITCH
LIFT
6 A
SLO
BLO
GROUND
NORMAL
OHM
8
SPEAKERS
4
OHM
PRESENCE
I N P U T S
STANDBYPOWER
PRESENCE
S
E
U
F
F
U
E
S
PAGE 1
Overview: (Continued)
most commanding sounds in rack-mount history as
Without further delay, connect up your favorite preamp and get ready to experience one of the
Recto
power goes stereo for the first time in this amazing package.
NOTE: BEFORE YOU MOUNT THE
with one of the above mentioned you need, you may find one of the more forgiving
Class2:90
more suited to your style or application. Save the packing material and keep the amplifier in perfect condition and you
2:100
IN YOUR RACK! This is an extremely aggressive and powerful amplifier intended for use
MESA
preamplifiers in large venues. If after trying it you feel you may have chosen more amp than
MESA
strereo power amplifiers such as the
Stereo 2:50
or the
Stereo Simul-
should be able to return it to the place of purchase for full credit toward one of the less aggressive models that might perhaps better suit your needs. If this stunning, agressive power well suits your playing style and needs, congratulations and by all means rock on.
And now on to the controls and features of it will prove to be quite worth while in the end and will help you to enjoy
your
new
2:100
. Please take some time along the way and read this operating manual,
your
new amplifier to its full extent.
FRONT PANEL CONTROLS
LEVEL CONTROLS:
pre-amp, try a setting of 2 as a starting point. If the amp is being fed by lower-level signals such as those from (minus) -20db type effects units, etc..., you may need to raise the Levels as high as 2:00 or 3:00.
Each channel of the
2:100
has its own LEVEL Control. If the amplifier is being fed by signals from a typical
E N G I N E E R I N G
LEVEL A LEVEL B
MODERN
PRESENCE
PRESENCE CONTROLS:
ONON
STANDBYPOWER
Each channel on the
NOTE:
nected to a speaker or load resistor!
either channels’ LEVEL Control is dialed to anything other than zero.
to comply to this procedure can cause serious damage to your section.
PRESENCE
Remember to turn the LEVEL Control to zero on any channel not con-
A Load must be present at all times when
Failure
2:100’s
2:100
has its own “active” PRESENCE Control. These controls provide a boost
power
in the upper mid-range/lower Treble zone, which are the frequencies that tend to get obscurred in the energy of live performance; use
them when you need to cut through a “loud mix.”
Use these PRESENCE Controls with discretion as they can make for some ear
E N G I N E E R I N G
LEVEL A LEVEL B
MODERN
PRESENCE
ONON
STANDBYPOWER
PRESENCE
damaging, almost harsh sounds if set too high - especially if the TREBLE Control on your pre-amp is dialed up extremely high.
PAGE 2
FRONT PANEL CONTROLS: (Continued)
POWER SWITCH & POWER UP:
First remove the protective covers from the tubes (plastic webbing) before con-
necting the A.C. cord to a power receptacle.
Make all necessary connections including pre-amp, effects, speakers and instrument before
E N G I N E E R I N G
VEL A LEV
MODERN
ENCE
ON
POWER
ON
STANDBY
PRE
neglected by the user.) But ignoring this procedure everytime the amplifier is used will shorten the tubes toneful life.
Never remove any of the power cords terminals. All three terminals of the A.C. power cord must be connected and always check that the power receptacle has the proper voltage present. Also, make sure that the power cord is inserted all the way in when connecting to a power receptacle.
STANDBY SWITCH:
Perfect for set breaks...this toggle switch also serves an even more important purpose. In the standby
position the tubes are at idle so that during power up they may have a chance to warm up before being put to use.
E N G I N E E R I N G
VEL A LEV
ON
MODERN
ON
you flip the STANDBY switch to its ON position. AC power is turned on via the POWER switch and indicated by the pilot lamp. Before switching on the power, place the STANDBY switch into its Standby position and allow at least 30 seconds of warm-up time before switching the STANDBY switch to the ON position.
This start up procedure helps extend tube life by preventing a high voltage turn-on surge. (How­ever, all of our amplifiers are tested to withstand this extra stress, just in case this procedure is
Before the power is switched on, make sure the STANDBY switch is in the standby position. And as mention above, wait at least 30 seconds before changing to the ON position.
ENCE
POWER
MODERN:
STANDBY
This jack is the trigger port for the auto-tracking MODERN feature. This jack can receive a trigger pulse from the corresponding jack on the modifies the amount of negative feedback in the power section when the MODERN mode in Channel 2 of the
PRE
MESA Rectifier Recording Preamp
or
Triaxis Programmable Preamp
. This smart power amp auto-
Recto Preamp
is
selected or switched to via the Footswitch. The Front Panel LED indicates when the feature is active and negative feedback has been
reduced.
E N G I N E E R I N G
MODERN
If used with the
ONON
jacks and store under a user preset. This reshaping is crucial to the
Triaxis
- use one of the 4 programmable switch
sound of the MODERN mode and using this feature duplicates the
STANDBYPOWER
circuit and the performance of this punishing mode in the
Dual &
Triple Rectifier Solo Heads.
NOTE: Use unshielded cable of good quality when connecting the
MODERN
trigger port to your preamp or master switching unit.
I N P U T S
RECTO INPUTS RECTO INPUTS
CHAN. B CHAN. A
WARNING
:
To reduce risk of fire or
electric shock, replace fuse with
same type and rating only. Do not
expose this unit to rain or moisture.
BIAS
SWITCH
NORMAL NORMAL
POWER FUSE
6L6
120 V~
60 Hz
EL34
MUST MATCH TUBES SEE OWNERS BOOK
8 OHM
E N G I N E E R I N G
6 A
MODERN
6 A
SLO
BLO
WARNING
:
To reduce risk of fire or electric shock, Do not remove cover. No user­serviceable parts inside. Refer servicing to qualified personnel.
GROUND
SWITCH
LIFT
GROUND
8 OHM
I N P U T S
Shielded cable will also work ,but is unnecessary.
PAGE 3
REAR PANEL FEATURES:
REAR VIEW:
WARNING
:
To reduce risk of fire or
electric shock, replace fuse with
same type and rating only. Do not
I N P U T S
RECTO INPUTS RECTO INPUTS
CHAN. B CHAN. A
SPEAKERS
INPUTS:
inputs for pre-amps and/or effects, depending on how you have your system wired. You may drive the
expose this unit to rain or moisture.
BIAS
SWITCH
NORMAL
6L6
EL34
MUST MATCH TUBES SEE OWNERS BOOK
8
OHM
4
OHM
Located on the Rear Panel, these two 1/4” jacks are the Channel A and Channel B inputs for the
E N G I N E E R I N G
POWER FUSE
120 V~
60 Hz
6 A
MODERN
2:100
WARNING
:
To reduce risk of fire or electric shock, Do not remove cover. No user­serviceable parts inside. Refer servicing to qualified personnel.
GROUND
SWITCH
LIFT
6 A
SLO
BLO
GROUND
I
N
NORMAL
P U T S
OHM
8
SPEAKERS
4
OHM
2:100.
2:100
These are the
with your pre-amp
S
E
U
F
F
U
E
S
directly or choose to come from the last effect in a chain and drive the power amp this way. Either way is fine and up to your
preference. The amplifier is stereo, offering two separate channels of
WARNING
:
To reduce risk of fire or
electric shock, replace fuse with
same type and rating only. Do not
expose this unit to rain or moisture.
I
N
P
U
NORMAL
BIAS
SWITCH
6L6
T S
RECTO INPUTS RECTO INPUTS
EL34
MUST MATCH TUBES SEE OWNERS MANUAL
E N G I N E E R I N G
POWER FUSE
120 V~
60 Hz
6 A
6 A SLO BLO
WARNING
:
To reduce risk of fire or electric shock, Do not remove cover. No user­serviceable parts inside. Refer servicing to qualified personnel.
GROUND
SWITCH
LIFT
GROUND
NORMAL
amplification. If you wish to use only one of its channels, it is neces­sary to: 1 ) Make sure a speaker (or load resistor) remains con-
I
nected to a speaker jack on both channels, including the unused
N P
one; or 2 ) Turn the LEVEL Control of the unused channel to zero.
U
(This is necessary because an amplifier channel receiving any amount
T S
of signal at its input will require a “load” at its output - or damage will most likely result.)
MODERN
the signal path between preamp and power section as it occurs in the a driver tube responsible for the effects return stage and all related circuitry in the
The RECTO INPUTS are wired such that when the companion
tifier Recording Preamp
Dual
and
Triple Rectifier Heads
is used, the circuit remains exactly true to
. To achieve this duplication,
2:100
must be removed and this includes the
Rec-
LEVEL Conbtrols as they are part of this circuitry. As a result, when using the RECTO INPUTS, you will use the Recto Pre LIVE OUTPUT Control as your overall final master level control.
TUBE BIAS:
2:100
of the
Your
2:100
was designed with versatility in mind. The BIAS SWITCH allows you to adapt the power output section
in order to use the other classic pentode power tubes, the British style EL 34. These tubes are largely responsible for the
signature sound of many immediately identifiable and wonderful sounding amps created in Great Britain
WARNING
:
I
N
NORMAL
P U T S
RECTO INPUT
To reduce risk of fire or
electric shock, replace fuse with
same type and rating only. Do not
expose this unit to rain or moisture.
BIAS
SWITCH
6L6
EL34
MUST MATCH TUBES
E N G I N E
POWER
120 V~
60 Hz
6 A
and used on some of the best recordings to date. The nature of their sound is usually brighter in the extremely high frequencies...some players find this almost thin at first. However, aficionados of the EL34 sound know that nothing has the lushness of harmonics or spread like a power amp using EL34’s. In truth EL34’s do focus in on a region of upper harmonics that 6L6’s reproduce, but not really enhance, in the same way the EL34’s do.
This characteristic is sometimes preferred for sounds that range from a soft clip that would be used for chording or soloing, to an all out high gain crunch or lead sound. Players that use mostly these types of sounds may prefer the EL34 clip to the 6L6’s that come standard in the you will likely prefer the stock compliment of 6L6’s that the
2:100
. If you need a variety of sounds and rely on a clean chording sound much of the time,
2:100
comes fitted with. We feel the 6L6 is a more balanced sounding tube that produces plenty of harmonic lushness, while at the same time delivering the rich lows that are crucial to both a warm clean sound and huge, tight high gain crunch sound.
PAGE 4
REAR PANEL
(Continued)
TUBE BIAS: (Continued)
We recommend the 6L6 for reliability: In our many tests and continued use of the currently
available EL34 type power tubes on the market today, we regret to say that they do not appear to be as rugged in construction as the
2:100
available 6L6. This is another reason why your
was shipped with 6L6 power tubes. If you plan to use the EL34’s we suggest that you keep a full set of tubes and extra fuses with you during all performances in the event of a tube failure occurring when using the currently available EL34’s.
GROUND LIFT:
This mini-toggle switch is extremely useful in reducing the hum and buzz caused by ground loops which occur in
rack installations. Ground loops occur when there is more than one path for grounds between electronic units. There are three main
type of ground loops; each one contributes its own trademark component of buzz or hum. The three types of ground loops are:
I
N
1 ) Grounds being connected via the ground lugs of the power cords on the units. The rule-of-thumb here
P
is that one and only one unit in a rack should have a connection to the AC power ground; all the other
U T
units in the rack should have their grounds lifted by using 3 to 2 adaptors on their AC plugs. We suggest
S
grounding the Power amp (no adapter).
E R I N G
FUSE
6 A SLO BLO
WARNING
:
To reduce risk of fire or electric shock, Do not remove cover. No user­serviceable parts inside. Refer servicing to qualified personnel.
GROUND
SWITCH
LIFT
GROUND
NORMAL
2 ) Ground loops occuring because of two or more audio cables connecting two components. The most common solution is to diconnect the shield from the sleeve connection at one end of some of the inter-connecting cables, so that only one cable between each device has an intact ground shield. Some experimentation is required to find which cable is best for conducting the ground, and which cables are best suited to have the special “clipped ground.” We recommend trying the intact-ground cables for the signal path which flows, say, from an Effects Send jack to an effects unit; and trying the clipped-ground method on the cable which connects the effects output back into an Effect Return.
3 ) Ground loops created by the physical contact between the metal chassis of the components and the steel rack rails. It is for this third type of ground loop that the GROUND ISOLATION Switch was provided. This switch effectively lifts the electronic circuit ground from the metal chassis ground (which otherwise must be done manually by disconnecting a wire inside of the amp.) Here again, the rule is that one device in your system - and usually only one - needs its circuit ground connected to its metal chassis ground; all others should be lifted (in other words, disconnected) for quietest operation. (Some effects units provide similar switches; some are con­structed such that the input ground and the output ground are permanently separated; in other cases, the method used to isolate the grounds is unclear.) Again, some experimentation is vital to discovering which combination of “lifted” and “grounded” works best in your rack...and our GROUND ISOLATION Switch makes this process much easier.
NOTE: If the
2:100
is operated outside of a rack installation, the switch should generally be set to the Normal position, or squealing,
buzzing and oscillation may occur. Always check this switch before thinking that something has gone wrong with your amp!
SPEAKER OUTPUTS:
The
2:100
provides one 8 Ohm and two 4 Ohm speaker outputs for each channel. When using a single
8 Ohm speaker or 8 Ohm cabinet on a channel, connect the speaker or cabinet to the 8 Ohm jack. If using two 8 Ohm speakers (assuming they are wired in parallel) or cabinets on a channel, plug them both into the 4 Ohm jacks. ( The logic here is that two 8 Ohm
loads connected in parallel add up to a 4 Ohm total load.) Mismatching of speaker
CHAN. B CHAN. A
SPEAKERS
8 OHM
4 OHM
8 OHM
4 OHM
SPEAKERS
impedance will not cause damage or severe loss of power. (Extreme mis-matches will decrease tube life, however.)
MESA/Boogie
4x12 and 4x10 cabinets come
standard wired to 8 Ohms and are wired in series-parallel.
Some Non-
MESA
4x12 cabinets are wired 16 Ohms using four 16 Ohm speakers.
By wiring all four speakers in parallel, you can reduce the cabinet to an impedance load of 4 Ohms (assuming the speakers are 16 Ohms each.) Further back in this manual we have included a number of possible wiring schemes - amps to cabinets, that may be of some use to you when considering how to configure your rig.
PAGE 5
Loading...
+ 20 hidden pages
