44 (0)1480 445678
www.Meridian-audi o. c o M
C ontrol 10
17in Touch Panel Control, Playback & Music Importer
SLS0 00031 • 200 91007 • V2.0
The Control 10 is the first of a new generation
of Meridian Sooloos devices which provide
high-quality digital audio outputs as well as the
acclaimed vivid touch interface to interact with
your media library. It features a high-contrast 17inch LCD display, resistive touch panel, and CD
mechanism for importing music.
Technical Specifications:
Dimensions:
(
43cm
(
WHD
)
457 x 345 x 18 5mm / 18 x 13.6 x 7.3in
(
Weight: 10 .75kg
ti lt: Adjusts from 0º
netWork ConneCtions:
-
-
232
(
RJ
45
1 Ethernet
PoWer ConneCtions:
12 V DC input, external AC adapter 110-230V
Removable IEC 3-prong power cable
AuDio ConneCtions:
1 S/PDIF coaxial digital output, RCA type
Meridian SpeakerLink
Control ConneCtions:
Meridian Comms
RS
lCD Dis PlAy:
Screen Size: 17 inch diagonal
Resolution: 128 0 x 10 24 pixels
Brightness: 350 cdm2
Viewing Angle: 150 º
touCh PAn el:
Type: Analogue resistive 5-wire
Activation Force: < 50g
Structure: Film/Glass
Lifetime Durability: 35 million touches
reAr V ieW:
)
23.6lb
vertical) to 50º (tilted)
(
)
or Neutrik EtherCon
)
Integrated heatsinks in the Control 10’s machined
aluminium chassis eliminate fans – making it
completely silent – so it’s right at home in the
most discriminating listening environment. Like
all Meridian Sooloos components, the Control
10 connects to the system using standard TCP/
IP Ethernet, using either the supplied Neutrik
EtherCon connectors or any CAT5/5e/6 cable with
RJ-45 connectors.
Latham R oad, hun ting don, Cam bRid ge Pe 29 6Ye , un ited K ingd om
