SOFA
PARTS AND HARDWARE
Avoid using sharp objects such as a knife to open packing as you may accidentally damage the upholstery.
14mm
Spanner
1x
Leg
4x
M8 x 80mm
Threaded Rod
6x
Back Cushion
Backrest
1x
2x
M8
Nut
6x
M8 x 22mm
Washer
6x
M8
Spring Washer
6x
Pillow
2x
Arm
1 Pair
2 of 8
Seat Body
1x
7 of 8
ASSEMBLY INSTRUCTIONS
Place accent pillows as desired .
CAUTION: At least two adults are required to safely complete this task.
Individual attempts may result in back injury due to large and heavy part(s).
Carefully unpack parts/hardware from the storage located under the seat body
and place on a clean flat surface.
Storage
Screw in three threaded rods into the pre-drilled holes of the armrest by hand until
about half of the thread is exposed. Repeat steps for other armrest.
6 of 8
3 of 8
Locate the pre-drilled holes on the side of the body and match the orientation with the
correct armrest.
Now, carefully join armrest (with the three threaded rods exposed) with the body by
aligning and going through the three pre-drilled holes on the side of the body.
Open the compartment cover underneath the base and secure all three threaded rods
with flat washers, spring washers and nuts from inside with the spanner, making sure
there is no movement.
Repeat step for other armrest.
Insert the backrest metal plates to both arms as shown
below. Ensuring it is correctly in place.
s. Fasten both sides
when
Align all four legs into the pre-drilled holes and secure by
Secure both back cushions by locating the zipper end
and continue all the way to the end. Flip the pillow into position
finished.
hand. Please avoid over-tightening
4 of 8 5 of 8
