FCC and IC Compliance Statement
Xi5 ASM‑FT PEDAL, INC, WRLS FCC ID ‑ MVU09291
Xi5 ASM‑KEY FOB, TROLLING MOTR FCC ID ‑ MVU09305
ACMA: N2523
IC: 6094A‑09291, 6094A‑09305
This device complies with part 15 of the FCC Rules. Operation is subject
to the following two conditions:
1. This device may not cause harmful interference.
2. This device must accept any interference received including
interference that may cause undesired operation.
This device complies with FCC Rules. Changes or modifications not
expressly approved by MotorGuide could void the user's authority to
operate the equipment.
The MotorGuide Xi5 trolling motor complies with Industry Canada
RSS‑210 standard. See RSS‑GEN 7.1.5. The term "IC:" before the
certification/registration number only signifies that registration was
performed based on a Declaration of Conformity indicating that Industry
Canada technical specifications were met. The term "IC:" before the
certification/registration number does not imply that Industry Canada
approved the equipment.
EU Compliance Statement
Attwood Corporation hereby declares that the Motorguide Xi5 trolling
motor is in compliance with the essential requirements and other relevant
provisions of the 99/5/EC R&TTE directive.
A copy of the original CE Declaration of Conformity is on our website at
http://www.motorguide.com/support/certifications.
Environmental Compliance Statement
All MotorGuide products that are subject to the 2002/96/EC WEEE
directive are compliant with the WEEE marking requirement. Such
products are marked with the "crossed‑out wheelie bin" WEEE symbol
(shown, below) in accordance with European Standard EN50419.
54539
eng i
© 2014 Mercury Marine
Xi5 Wireless Edition 90-8M0088277 1213
The symbol on the product or its packaging indicates that this product must not
be disposed of with your other household waste. Instead, it is your
responsibility to dispose of your waste equipment by handing it over to a
designated collection point for the recycling of waste electrical and electronic
equipment. The separate collection and recycling of your waste equipment at
the time of disposal will help conserve natural resources and ensure that it is
recycled in a manner that protects human health and the environment. For
more information about where you can drop off your waste for recycling, please
contact your local authority, or where you purchased your product.
Thank You
Thank you for purchasing a MotorGuide Xi5 Wireless Trolling Motor.
The Xi5 is designed and engineered to deliver the performance that anglers
expect: quiet operation, reliability, and precise control. We’re confident that the
Xi5 will enhance your fishing experience and we appreciate that you chose
MotorGuide.
Please take a moment to register your new Xi5 at motorguide.com—or
complete and mail the enclosed Warranty Registration Card.
Warranty Message
The product you have purchased comes with a Limited Warranty from
MotorGuide. The terms of the policy are set forth in the Warranty Information
section of this manual. The policy statement contains a description of the
duration of coverage, important disclaimers and limitations of damages,
and other related information. Please review this important information.
The description and specifications contained herein were in effect at the time
this manual was approved for printing. MotorGuide, whose policy is one of
continued improvement, reserves the right to discontinue models at any time, to
change specifications, designs, methods, or procedures without notice and
without incurring obligation.
MotorGuide, Lowell, Michigan U.S.A.
Mercury Marine
Cradle Lock is a trademark of Brunswick Corporation.
Eagle and Lowrance are registered trademarks of Navico Inc. Garmin is a
registered trademark of Garmin Ltd. Humminbird is a registered trademark of
Johnson Outdoors Marine Electronics, Inc. Vexilar is a registered trademark of
Vexilar, Inc.
Copyright and Trademark Information
© MERCURY MARINE. All rights reserved. Reproduction in whole or in
part without permission is prohibited.
ii eng
Alpha, Axius, Bravo One, Bravo Two, Bravo Three, Circle M with Waves Logo,
K‑planes, Mariner, MerCathode, MerCruiser, Mercury, Mercury with Waves
Logo, Mercury Marine, Mercury Precision Parts, Mercury Propellers, Mercury
Racing, MotorGuide, OptiMax, Quicksilver, SeaCore, Skyhook, SmartCraft,
Sport‑Jet, Verado, VesselView, Zero Effort, Zeus, #1 On the Water and We're
Driven to win are registered trademarks of Brunswick Corporation. Pro XS is a
trademark of Brunswick Corporation. Mercury Product Protection is a registered
service mark of Brunswick Corporation.
eng iii
eng iv
Warranty Information
MotorGuide Two Year Limited Warranty............................................................ 1
General Information and Component Identification
Component Identification.................................................................................... 4
Recording the Serial Number............................................................................. 5
Product Registration........................................................................................... 5
Boater's Responsibilities..................................................................................... 6
Protecting People in the Water........................................................................... 6
Passenger Safety Message................................................................................ 6
Safe Boating Suggestions.................................................................................. 6
Product Installation, Wiring, and Battery Information
Installing the Trolling Motor.................................................................................8
Recommended Practice and Procedures......................................................... 12
Battery Recommendations............................................................................... 12
Battery Precautions.......................................................................................... 13
Establishing a Common Ground....................................................................... 13
Wire Color Code Abbreviations........................................................................ 14
Battery Connection........................................................................................... 14
Activating the Wireless Foot Pedal................................................................... 18
Activating the Handheld Remote...................................................................... 18
Connecting the Sonar Display to the Trolling Motor......................................... 19
Trolling Motor Operation
Status Indicator Light Identification................................................................... 21
Stowing and Deploying the Trolling Motor........................................................ 21
Adjusting the Motor Depth................................................................................ 25
Foot Pedal Operation........................................................................................26
Handheld Remote Operation............................................................................ 30
eng v
Maintenance and Storage
Trolling Motor Care........................................................................................... 32
Inspection and Maintenance Schedule............................................................. 32
Storage Preparation..........................................................................................34
Battery Inspection............................................................................................. 35
Propeller Replacement..................................................................................... 35
Owner Service Assistance
Troubleshooting................................................................................................ 38
Troubleshooting the Foot Pedal and Handheld Remote...................................42
Service Assistance........................................................................................... 46
Mercury Marine Service Offices........................................................................ 46
vi eng
MotorGuide Two Year Limited Warranty
KEEP YOUR ORIGINAL PURCHASE RECEIPT OR BILL OF SALE.
1. For recreational use customers, MotorGuide electric trolling motors are
warranted to the original retail purchaser to be free from defects in
material or workmanship for a period of two years from the date of
purchase.
2. To obtain warranty service, the purchaser should deliver or return the unit
(postage prepaid and insured) to any MotorGuide authorized service
dealer. DO NOT RETURN TO PLACE OF PURCHASE unless they are
an authorized service center. Products returned by mail should be
carefully packaged and include a note describing the nature of the
problem and/or service requested, customer address, and phone number.
A copy of the receipt, bill of sale, registration verification or other proof of
purchase is required with the return of the product for warranty
consideration. Warranty claims will not be accepted without presentation
of purchase receipt for the trolling motor, other verification of registration,
or bill of sale for a boat package.
3. MotorGuide, at its discretion, will repair or replace items covered under
the terms of this warranty. Neither MotorGuide nor MotorGuide service
dealers are responsible for damages to MotorGuide products due to
repairs performed by anyone other than an authorized MotorGuide
service dealer. Neither MotorGuide nor Attwood is responsible for failure
or damage caused by improper installation, set‑up, preparation, or
previous service or repair errors.
4. For commercial use and government use customers, MotorGuide electric
trolling motors are warranted to the original retail purchaser to be free
from defects in material or workmanship for one (1) year. Commercial use
is defined as any work or employment‑related use of the product, or any
use of the product which generates income, for any part of the warranty
period, even if the product is only occasionally used for such purpose
such as rental fleets, guides, fish camps or similar operations. Warranty is
not transferable to any subsequent purchaser. The Mercury Product
Protection plan is not available to commercial use or government use
customers.
5. MotorGuide Composite Shaft Limited Lifetime Warranty. MotorGuide
composite shafts are warranted to the original retail purchaser to be free
of defects in material or workmanship for the lifetime of the original
purchaser. MotorGuide will provide a new composite shaft at no cost for
any composite shaft which contains a defect in material or workmanship.
The installation costs are the sole responsibility of the purchaser.
WARRANTY INFORMATION
eng 1
6. Warranty coverage is available to customers that purchase from an
authorized dealer or retailer that is authorized by MotorGuide Marine to
distribute the product in the country in which the sale occurred. Warranty
coverage and duration varies by the country in which the owner resides.
This Limited Warranty begins on the date the product is first sold to a
purchaser or the date on which the product is first put into service,
whichever occurs first. MotorGuide accessories are covered by this
Limited Warranty for a coverage period of one (1) year from the date of
retail sale. The repair or replacement of parts, or the performance of
service under this warranty, does not extend the life of this warranty
beyond its original expiration date. Promotional warranties are not
included in this statement and coverage may vary by promotion. Product
either sold or put into service more than six years from date of
manufacture is excluded from warranty coverage.
7. This warranty does not apply to normal worn parts, for example, worn
cables, adjustments, or product damage due to: 1) neglect, lack of
maintenance, accident, abnormal operation or improper installation or
service; 2) abuse, such as, bent metal columns, bent armature shafts,
broken control cables, etc., accidents, modifications, misuse, excessive
wear or damage caused by an owner’s failure to provide reasonable and
necessary installation or care; 3) use of an accessory or part not
manufactured by MotorGuide or Attwood; 4) alteration or removal of parts;
5) opening the lower unit (motor) by anyone other than an authorized
MotorGuide service center will void this warranty.
8. We reserve the right to improve the design of any trolling motor without
assuming any obligation to modify any trolling motor previously
manufactured.
9. All serialized "Service‑Repair" trolling motors receive a (1) one year
warranty. Non‑serialized "Service‑Repair" electric trolling motors are NOT
warranted. "Service‑Repair" motor denotes a trolling motor sold by
MotorGuide that may be used, but has been inspected and may have had
minor repairs. Original retail purchaser of a "Service‑Repair" motor is the
first purchaser of the motor after it is denoted as "Service‑Repair."
"Service‑Repair" motors have a blue sticker on the battery cable and box
denoting "Manufacturer Certified Service‑Repair Motor."
10. This warranty will not apply to: 1) haul‑out, launch, towing and storage,
transportation charges and/or travel time, telephone or rental charges of
any type, inconvenience, or loss of time or income, or other consequential
damages; or 2) removal or replacement of boat partitions or material
because of boat design for necessary access to the Product; or 3)
disconnection and reconnection of hard‑wired trolling motors.
11. TERMINATION OF COVERAGE: Warranty coverage may be terminated
for repossessed product, or product purchased at auction, from a salvage
yard, from a liquidator, from an insurance company, from unauthorized
marine dealers or boatbuilders, or other third party entities.
WARRANTY INFORMATION
2 eng
12. ALL INCIDENTAL OR CONSEQUENTIAL DAMAGES ARE EXCLUDED
FROM THIS WARRANTY, WARRANTIES OF MERCHANTABILITY AND
FITNESS ARE EXCLUDED FROM THIS WARRANTY, IMPLIED
WARRANTIES ARE LIMITED TO THE LIFE OF THIS WARRANTY.
SOME STATES DO NOT ALLOW LIMITATIONS ON HOW LONG AN
IMPLIED WARRANTY LASTS OR THE EXCLUSION OR LIMITATION
OF INCIDENTAL OR CONSEQUENTIAL DAMAGES, SO THE ABOVE
LIMITATIONS OR EXCLUSIONS MAY NOT APPLY TO YOU. THIS
WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS, AND YOU MAY
ALSO HAVE OTHER LEGAL RIGHTS WHICH MAY VARY FROM
STATE TO STATE.
For Your Records:
Model Number _______________________________
Serial Number _______________________________
WARRANTY INFORMATION
eng 3
Component Identification
a - Head
b - Curly cable
c - Stow/deploy release lever
d - Battery cables (hidden)
e - Wireless foot pedal
f - Handheld wireless remote
g - Deck mount
h - Propeller
i - Skeg
j - Lower unit (motor)
k - Depth collar
l - Depth collar knob
m - Composite column
n - Steering transmission
53443
b
h
i
j
k
m
g
e
d
a
n
c
f
l
GENERAL INFORMATION AND COMPONENT
IDENTIFICATION
4 eng
Recording the Serial Number
It is important to record the serial number and model number for future
reference. The serial number tags are located on the trolling motor as shown.
Record the serial number and the model number in the space provided in the
Warranty Information section of this manual.
a - Model identification number
b - Serial number
Product Registration
For warranty purposes, please register your MotorGuide trolling motor by
completing the enclosed warranty card or by visiting www.motorguide.com.
b
a
53462
GENERAL INFORMATION AND COMPONENT
IDENTIFICATION
eng 5
Boater's Responsibilities
The operator (driver) is responsible for the correct and safe operation of the
boat and safety of its occupants and general public. It is strongly recommended
that each operator (driver) read and understand this entire manual before
operating the trolling motor.
Be sure at least one additional person on board is instructed in the basic
operation of the trolling motor in case the driver is unable to operate the boat.
Protecting People in the Water
WHILE YOU ARE TROLLING
It is difficult for a person in the water to take quick action to avoid a boat
heading in their direction, even at slow speeds.
21604
Always slow down and exercise extreme caution any time you are boating in an
area where there might be people in the water.
WHILE THE BOAT IS STATIONARY
!
WARNING
A spinning propeller, a moving boat, or any solid device attached to the boat
can cause serious injury or death to swimmers. Stop the trolling motor
immediately whenever anyone in the water is near your boat.
Shut off the trolling motor before allowing people to swim or be in the water
near your boat.
Passenger Safety Message
Whenever the boat is in motion, observe the location of all passengers. A
sudden reduction in boat speed, such as a sharp change of boat direction,
could throw them off the boat.
Safe Boating Suggestions
In order to safely enjoy the waterways, familiarize yourself with local and other
governmental boating regulations and restrictions, and consider the following
suggestions.
Use flotation devices. It is the law to have an approved personal flotation
device of suitable size for each person aboard and have it readily accessible.
GENERAL INFORMATION AND COMPONENT
IDENTIFICATION
6 eng
Do not overload your boat. Most boats are rated and certified for maximum
load (weight) capacities, refer to your boat capacity plate. If in doubt, contact
your dealer or the boat's manufacturer.
Perform safety checks and required maintenance. Follow a regular
schedule and ensure all repairs are made properly.
Never be under the influence of alcohol or drugs while boating (it is the
law). Alcohol or drug use impairs your judgment and greatly reduces your
ability to react quickly.
Passenger boarding. Stop the trolling motor whenever passengers are
boarding or unloading.
Be alert. The operator of the boat is responsible by law to maintain a proper
lookout by sight and hearing. The operator must have an unobstructed view
particularly to the front. No passengers, load, or fishing seats should block the
operators view when operating the boat.
Underwater hazards. Reduce speed and proceed with caution whenever
navigating in shallow water.
Tripping hazards. To avoid a trip hazard, route all cables and wiring neatly
and out of the way.
Report accidents. Boat operators are required by law to file a Boating
Accident Report with their state boating law enforcement agency when their
boat is involved in certain boating accidents. A boating accident must be
reported if 1) there is loss of life or probable loss of life, 2) there is personal
injury requiring medical treatment beyond first aid, 3) there is damage to boats
or other property where the damage value exceeds $500.00 or 4) there is
complete loss of the boat. Seek further assistance from local law enforcement.
GENERAL INFORMATION AND COMPONENT
IDENTIFICATION
eng 7
Installing the Trolling Motor
1. Remove the two side panel screws from each side of the deck mount.
Gently pull the side panels away from the deck mount, taking care not to
damage the locating tabs, and remove the side panels from both sides of
the trolling motor.
a - Side panel screws
b - Locating tab
2. If you are replacing an existing MotorGuide or competitive brand trolling
motor on your current boat, check if the existing mounting holes align with
the new deck mount before drilling new holes. Ensure that the mounting
location meets the requirements listed in Step 4.
3. If new holes are not required to mount the trolling motor, skip ahead to
Step 7.
4. Carefully select an appropriate area on the deck of the boat close to the
centerline to install the trolling motor. Ensure that the forward mounting
bolts will not penetrate the hull. Have an assistant hold the trolling motor
in position while the mounting location is being selected.
IMPORTANT: The mounting position must be tested in the stowed and
deployed positions before drilling the mounting holes.
IMPORTANT: Choose an area on the deck with 10.2 cm (4.0 in.) of clearance
between the bow of the boat and the deck mount to prevent interference
between the trolling motor and the bow roller when loading or unloading on a
steep ramp.
IMPORTANT: Ensure that the head does not protrude beyond the beam of the
boat when in the stowed position.
a
a
53446
b
PRODUCT INSTALLATION, WIRING, AND BATTERY
INFORMATION
8 eng
IMPORTANT: A minimum clearance of 13 mm (0.5 in.) is required between
the motor column and the rub rail on the boat when the trolling motor is
deployed.
53447
Mounting position with 10.2 cm (4.0 in.) clearance from the bow
5. Place the trolling motor onto the deck of the boat at the selected location
in the stowed position. Use the deck mounting bracket as a template and
mark the location of the mounting holes.
IMPORTANT: Four mounting holes (two on each side) are required to securely
mount the trolling motor. There are seven mounting hole positions to choose
from on each side of the deck mounting bracket. Choose two hole positions on
each side that work the best with your boat configuration.
IMPORTANT: Select mounting hole locations as far apart as practical on each
side of the deck mounting bracket for the most secure mounting.
53448
Mounting hole locations—same on both sides
6. Drill the mounting holes with a 8 mm (5/16 in.) drill bit. Remove any
debris.
IMPORTANT: To help prevent cracking on fiberglass decks, use a countersink
bit or a larger drill bit to countersink the mounting holes.
7. Align the deck mounting bracket to the holes in the deck. On fiberglass
boats with no carpet where the motor is being installed, install the rubber
isolators between the boat deck and the deck mounting bracket. Install
three stainless steel mounting bolts through the mounting holes on one
side of the deck mounting bracket. Install a washer and a nylock nut onto
each bolt, but do not tighten them at this time.
PRODUCT INSTALLATION, WIRING, AND BATTERY
INFORMATION
eng 9
NOTE: If the trolling motor is being mounted to a carpeted boat deck, the
rubber isolators are not required.
a - Deck mounting bracket
b - Mounting bolt
c - Rubber isolator
d - Deck
e - Washer
f - Nylock nut
g - Carpet
a
b
c
d
e
f
a
b
d
e
f
g
52406
PRODUCT INSTALLATION, WIRING, AND BATTERY
INFORMATION
10 eng
8. Grab onto the motor column and raise the unbolted side of the deck
mounting bracket. Install the bolts through the deck mounting holes while
holding the deck mounting bracket at an angle. Holding the deck
mounting bracket at an angle allows the bolts to be installed with less
interference from the foot release mechanism. Install a washer and a
nylock nut onto each bolt.
53451
9. Align the trolling motor with the mounting holes in the deck. Hold the
mounting bolts securely with a 7/16 in. wrench while using a wrench or
socket to tighten the nylock nuts on both sides of the deck mounting
bracket from under the deck.
10. Install the side panels onto the trolling motor, taking care not to damage
the locating tabs. Install the side panel screws.
a - Side panel screws
b - Locating tab
a
a
53446
b
PRODUCT INSTALLATION, WIRING, AND BATTERY
INFORMATION
eng 11
Recommended Practice and Procedures
IMPORTANT: Unplug the trolling motor after each use and when charging the
battery.
• Do not use the main engine battery to power the trolling motor.
• Ensure that the batteries are enclosed within a battery box to prevent
accidental shorting of the battery terminals.
• Route the trolling motor wires on the opposite side of the boat from other
boat wiring.
• Connect boat accessories directly to the main engine battery.
• Do not charge the trolling motor batteries while the trolling motor is in the
deployed (down) position.
Battery Recommendations
• Use 12‑volt, deep cycle marine batteries. The number of batteries
required varies according to the model of your trolling motor. Refer to
Battery Connection.
• As a general rule, deep cycle batteries with a higher amp‑hour rating or
reserve capacity rating will provide longer run times and better
performance.
• Install a manual reset circuit breaker in line with the trolling motor positive
leads within 180 cm (72 in.) of the batteries. These can be purchased
from your local MotorGuide retailer or from www.motorguide.com.
• Do not extend the included 10‑gauge battery cables more than 1.8 m (6 ft)
for a total of 3 m (10 ft). If longer battery cables are required, MotorGuide
offers accessory 13 mm² (6‑gauge) battery cables.
• Use nylock nuts to secure the battery cables to their terminals. Using wing
nuts to secure the battery cables can cause loose connections.
• Any depth sounders or fish finders must be powered from the engine
starting battery. Connecting electronic equipment to the trolling motor
batteries can cause electrical interference and possible electrolysis.
Recommended MotorGuide Accessory Description
Part Number
6‑gauge battery cable and terminals with 50‑amp
manual reset circuit breaker
MM309922T
50‑amp manual reset circuit breaker MM5870
60‑amp manual reset circuit breaker 8M0064076
PRODUCT INSTALLATION, WIRING, AND BATTERY
INFORMATION
12 eng
Battery Precautions
!
WARNING
An operating or charging battery produces gas that can ignite and explode,
spraying out sulfuric acid, which can cause severe burns. Ventilate the area
around the battery and wear protective equipment when handling or servicing
batteries.
When charging batteries, an explosive gas mixture forms in each cell. Part of
this gas escapes through holes in the vent plugs and may form an explosive
atmosphere around the battery if ventilation is poor. This explosive gas may
remain in or around the battery for several hours after it has been charged.
Sparks or flames can ignite this gas and cause an internal explosion, which
may shatter the battery.
The following precautions should be observed to prevent an explosion:
1. Do not smoke near batteries being charged or which have been charged
recently.
2. Do not break live circuits at the battery terminals, because a spark usually
occurs at the point where a live circuit is broken. Always be careful when
connecting or disconnecting cable clamps on chargers. Poor connections
are a common cause of electrical arcs, which cause explosions.
3. Do not reverse the polarity of battery terminal to cable connections.
Establishing a Common Ground
A common ground (–) connection increases sonar sensitivity, improves sonar
display, avoids the ground circuit as a possible source of corrosion or
electrolysis, and reduces interference with other electronic equipment. For
12‑volt trolling motor applications, connect the negative (–) terminal on the
trolling motor battery to the negative (–) terminal on the engine starting battery
with a common ground cable to establish a common ground.
For 24‑volt and 36‑volt trolling motors, a common ground (–) connection cannot
be established with the 12‑volt electrical system in the boat due to the different
circuit voltages. As a general rule to reduce interference with other electronics
on your boat, route all battery wiring away from other boat wiring (opposite side
of the boat if possible), keep the battery cable length as short as possible, and
always use battery cables of the appropriate size (gauge).
ELECTROLYSIS
Using the main engine battery as a power source for the trolling motor may
cause electrolysis on metallic parts. If the motor and battery wiring are installed
correctly and electrolysis issues continue, separate the trolling motor from any
other boat electronics. Using the main engine battery as a power source for the
trolling motor is not recommended. Refer to Battery Connection for correct
installation.
PRODUCT INSTALLATION, WIRING, AND BATTERY
INFORMATION
eng 13
Wire Color Code Abbreviations
Wire Color Abbreviations
BLK Black
BLU Blue
BRN Brown GRY Gray
GRN Green ORN or ORG Orange
PNK Pink PPL or PUR Purple
RED Red TAN Tan
WHT White YEL Yellow
LT or LIT Light DK or DRK Dark
Battery Connection
!
WARNING
Before working around electrical system components, disconnect the battery
cables from the battery to prevent injury or damage to the electrical system
due to an accidental short circuit.
!
CAUTION
Disconnecting or connecting the battery cables in the incorrect order can
cause injury from electrical shock or can damage the electrical system.
Always disconnect the negative (‑) battery cable first and connect it last.
NOTICE
Failure to operate the trolling motor within the recommended voltage
specifications can cause product damage. Do not exceed the maximum
supply voltage.
IMPORTANT: Refer to the decal on the head of the trolling motor to determine
the voltage requirements of your trolling motor.
12-VOLT BATTERY CONNECTION
1. Starting with the negative (–) lead, disconnect the battery cables from the
engine starting battery.
2. Install a 50‑amp (good) or 60‑amp (best) manual reset circuit breaker in
line with the trolling motor power cable positive (+) lead and the trolling
motor battery positive (+) terminal.
3. Connect the positive (+) trolling motor lead to the positive (+) trolling
motor battery terminal.
4. Connect the negative (–) trolling motor lead to the negative (–) trolling
motor battery terminal.
PRODUCT INSTALLATION, WIRING, AND BATTERY
INFORMATION
14 eng
5. Connect a jumper cable (common ground bond) from the trolling motor
battery negative (–) terminal to the engine battery negative (–) terminal.
NOTE: Vessels using 12‑volt trolling motors with multiple batteries must have
a common ground bonding circuit. Not establishing a common ground
between the vessel batteries may cause severe corrosion, electrolysis, or
electrical shock.
NOTE: The common ground bond cable should be no more than one wire size
(gauge) smaller than the battery cables, nor smaller than 16‑gauge (AWG).
The common ground bond cable must be insulated, and secured to the
negative (–) battery terminals with ring‑style connectors.
6. Starting with the positive (+) lead, reconnect the battery cables to the
engine starting battery.
12-volt battery connection with common ground bond
a - Power cables to trolling motor
b - Manual reset circuit breaker
c - Trolling motor battery
d - Engine starting battery
e - Power cables to engine
f - Common ground (–) bond cable
24-VOLT BATTERY CONNECTION
1. Starting with the negative (–) lead, disconnect the battery cables from the
engine starting battery.
2. Install a 50‑amp (good) or 60‑amp (best) manual reset circuit breaker in
line with the trolling motor power cable positive (+) lead and the trolling
motor battery B positive (+) terminal.
3. Connect the positive (+) trolling motor lead to the positive (+) terminal on
trolling motor battery B.
RED
BLK
BLK
REDRED
abcde
44291
f
PRODUCT INSTALLATION, WIRING, AND BATTERY
INFORMATION
eng 15
4. Connect a jumper wire (reference gray) between the negative (–) terminal
on battery B to the positive (+) terminal on battery A.
IMPORTANT: The jumper wire should be the same wire gauge as the
negative (–) and positive (+) power cables.
5. Connect the trolling motor negative (–) lead to the negative (–) terminal on
battery A.
6. Starting with the positive (+) lead, reconnect the battery cables to the
engine starting battery.
24-volt battery connection
a - Power cables to trolling motor
b - Manual reset circuit breaker
c - Jumper wire (not supplied)
d - Negative (–) battery terminal
IMPORTANT: Do not connect a common ground bond cable between 24‑volt
and 12‑volt electrical circuits.
36-VOLT BATTERY CONNECTION
1. Starting with the negative (–) lead, disconnect the battery cables from the
engine starting battery.
2. Install a 50‑amp (good) or 60‑amp (best) manual reset circuit breaker in
line with the trolling motor power cable positive (+) lead and the trolling
motor battery C positive (+) terminal.
3. Connect the positive (+) trolling motor lead to the positive (+) terminal on
trolling motor battery C.
RED
BLK
a
b
c
d
37824
GRY
c
Battery A
Battery B
PRODUCT INSTALLATION, WIRING, AND BATTERY
INFORMATION
16 eng
4. Connect a jumper wire (reference gray) between the negative (–) terminal
on battery C to the positive (+) terminal on battery B.
IMPORTANT: The jumper wire should be the same wire gauge as the
negative (–) and positive (+) power cables.
5. Connect a jumper wire (reference gray) between the negative (–) terminal
on battery B to the positive (+) terminal on battery A.
6. Connect the trolling motor negative (–) lead to the negative (–) terminal on
battery A.
7. Starting with the positive (+) lead, reconnect the battery cables to the
engine starting battery.
36-volt battery connection
a - Power cables to trolling motor
b - Manual reset circuit breaker
c - Jumper wire (not supplied)
d - Negative (–) battery terminal
IMPORTANT: Do not connect a common ground bond cable between 36‑volt
and 12‑volt electrical circuits.
RED
BLK
37825
GRY
c
Battery B
Battery C
Battery A
GRY
c
a
b
c
d
PRODUCT INSTALLATION, WIRING, AND BATTERY
INFORMATION
eng 17
Activating the Wireless Foot Pedal
Each wireless foot pedal and wireless handheld remote has a unique serial
number, and each wireless controller must be synced individually to the trolling
motor receiver. The trolling motor receiver can sync up to 40 wireless
controllers. This ensures that the trolling motor will respond to commands only
from designated controllers. Follow the instructions below to activate a wireless
controller with your trolling motor. For erasing and reprogramming information,
refer to Troubleshooting the Foot Pedal and Handheld Remote in the
Owner Service Assistance section.
IMPORTANT: To activate multiple foot pedals or remotes, the motor must be
unplugged from the power source and then plugged back into the power source
between activating each control device.
1. Connect the battery cables to the battery, or plug in the battery cable to a
power source. Within ten seconds of connecting the battery cables to their
terminals, press and hold the propeller and anchor buttons on the
wireless foot pedal simultaneously.
2. Listen for a multitone beep, indicating that the receiver has synced the
electronic serial number.
a -
Anchor button (foot
pedal on/off)
b -
Propeller button
(propeller on/off)
3.
To turn the pedal on or off, press and hold the anchor button. One beep
from the foot pedal indicates that the foot pedal is turned on, two beeps
indicate that the foot pedal is turned off.
Activating the Handheld Remote
1. If the trolling motor battery cables are connected, disconnect the battery
cables from the trolling motor battery, starting with the negative (–) lead.
2. Connect the battery cables to the battery or plug in the battery cable to a
power source. Within ten seconds of connecting the battery cables to their
terminals, press and hold the left arrow button and right arrow button on
the handheld remote simultaneously.
a
b
51767
PRODUCT INSTALLATION, WIRING, AND BATTERY
INFORMATION
18 eng
3. Listen for a multitone beep, which indicates that the receiver has stored
the electronic serial number.
a -
+ button—increase
speed
b -
Propeller button—
propeller on/off
c -
Right arrow button
d -
– button—decrease
speed
e -
Left arrow button
Connecting the Sonar Display to the Trolling Motor
NOTE: This procedure applies only to models equipped with integrated sonar.
This sonar display connection procedure applies to trolling motor models with
internal sonar that offer built‑in 200/83 kHz sonar transducers compatible with
Eagle, Garmin, Humminbird, Lowrance, and Vexilar brand sonar displays. For
compatibility with other sonar units, refer to www.motorguide.com.
51842
b
a
c
d
e
PRODUCT INSTALLATION, WIRING, AND BATTERY
INFORMATION
eng 19
The trolling motor is equipped with a Lowrance 6‑pin plug. Adapters are
available to connect other brands of sonar displays to the trolling motor. Match
the cable connector to the sonar port on the back of the sonar display. Power
up the unit to ensure that the sonar cable is connected securely.
a - Harness—to nose
cone sonar
b - 6‑pin Lowrance plug
—to sonar display
Transducer adapter cables available from MotorGuide Part Number
Lowrance 6‑to‑7‑pin adapter 8M4000386
Garmin 6‑pin adapter 8M4001961
Vexilar 3‑pin 8M4001960
Humminbird 7‑pin 8M4001962
53441
a
b
PRODUCT INSTALLATION, WIRING, AND BATTERY
INFORMATION
20 eng
Status Indicator Light Identification
This trolling motor is equipped with a multifunction status indicator light panel. It
can display the status of the motor, propeller, battery charge, and GPS status
for quick and easy reference during operation.
a - Power on/off indicator light
b - Propeller on/off indicator light
c - GPS navigation indicator
light
d - Battery status light
Stowing and Deploying the Trolling Motor
!
WARNING
Rotating propellers can cause serious injury or death. Never start or operate
the motor out of water.
!
CAUTION
Moving parts, such as hinges and pivot points, can cause serious injury.
Keep away from moving parts when stowing, deploying, or tilting the motor.
a
b
c
d
51836
TROLLING MOTOR OPERATION
eng 21
STOWING THE TROLLING MOTOR
1. Press down on the stow/deploy release lever with one hand or one foot.
Firmly grasp the column with one hand and tilt the trolling motor towards
the mount.
53452
TROLLING MOTOR OPERATION
22 eng
2. Raise the motor out of the water and rotate the column so the lower unit is
aligned with the mount cradle. Orient the lower unit so the cable does not
wrap around the trolling motor column. Slide the lower unit into the mount
cradle and release the stow/deploy release lever. The mount will lock the
trolling motor in the stowed position.
a - Lower unit (motor)
b - Depth collar
c - Column
d - Curly cable
e - Stow/deploy release lever
f - Mount cradle
3. Slide the depth collar tightly against the steering transmission. Rotate the
depth collar until it engages the steering transmission, then tighten the
depth collar knob.
a - Steering transmission
b - Depth collar
c - Depth collar knob
NOTE: Optional mounts are available for supporting the trolling motor in
extremely rough boating conditions.
a
b
d
e
f
53458
c
a
c
51780
b
TROLLING MOTOR OPERATION
eng 23
Recommended MotorGuide Accessory Description Part Number
Standard Ram® mount stabilizer
8M4000977
Long Ram® mount stabilizer
8M4000978
DEPLOYING THE TROLLING MOTOR
1. Loosen the depth collar knob, then slide the depth collar away from the
steering transmission. Tighten the depth collar knob.
2. Press down on the stow/deploy release lever with one hand or one foot.
Firmly grasp the column and slide the lower unit away from the mount
cradle.
a - Lower unit (motor)
b - Depth collar
c - Column
d - Curly cable
e - Stow/deploy release lever
f - Mount cradle
a
b
d
e
f
53459
c
TROLLING MOTOR OPERATION
24 eng
3. Tilt the motor out of the stowed position and lower the trolling motor until
the depth collar rests on top of the steering housing collar. Rotate the
trolling motor so the depth collar locks into position on the steering
housing collar and release the stow/deploy release lever. The motor will
lock into the deployed position. Pull back on the motor to ensure that it is
securely locked into the deployed position.
a - Depth collar knob
Adjusting the Motor Depth
!
CAUTION
Avoid injury due to the sudden shifting of weight when deploying the motor or
adjusting the motor depth. When raising or lowering the motor, firmly grasp
the motor column with one hand before loosening the depth collar knob.
Adjust the depth of the motor to improve the trolling motor performance in
various water depths.
IMPORTANT: When adjusting the motor depth, ensure that the lower unit is
fully submerged a minimum of 30 cm (12 in.) to avoid propeller cavitation.
53460
a
TROLLING MOTOR OPERATION
eng 25
1. Firmly grasp the column with one hand while loosening the depth collar
knob so the column moves freely.
a - Depth collar knob
b - Depth collar
2. Raise or lower the column to the desired depth. Tighten the depth collar
knob to secure the column.
Foot Pedal Operation
!
WARNING
Rotating propellers can cause serious injury or death. Never start or operate
the motor out of water.
!
WARNING
Avoid possible serious injury from unexpected acceleration and boat
movement when activating the trolling motor. When using the foot‑pedal, the
motor will start up at the last selected speed and course settings. Before
pressing the foot‑pedal, hold on to a seat or handhold, and advise
passengers to do the same.
a
b
53461
TROLLING MOTOR OPERATION
26 eng
To operate the trolling motor using the foot pedal, sync the foot pedal to the
trolling motor receiver. Refer to Activating the Wireless Foot Pedal in the
Product Installation, Wiring, and Battery Information section of this manual.
a - Toe‑down position—
right turn
b - Propeller momentary
on/off
c - Propeller constant
on/off
d - Heel‑down position—
left turn
e - Anchor button—
models with GPS
installed; also foot
pedal on/off
f - Speed control dial
TURNING THE FOOT PEDAL ON OR OFF
Press and hold the anchor button. One short beep from the foot pedal
indicates that the foot pedal is turned on; two short beeps indicate that the foot
pedal is turned off.
c
e
f
a
b
51747
d
TROLLING MOTOR OPERATION
eng 27
DIRECTION CONTROL
Pivot the foot pedal toe‑down to steer right, or heel‑down to steer left. To stop
turning, allow the pedal to return to its center detent position without pressing
down on the heel or toe of the pedal. To operate the motor in reverse, continue
to press the foot pedal down in either direction until the head is pointing to the
desired direction of travel. The available steering range will allow the operator
to steer the trolling motor past 360° in either direction.
a - Toe‑down position—right turn
b - Center detent position—steering off
c - Heel‑down position—left turn
SPEED CONTROL
!
WARNING
Avoid possible serious injury from unexpected acceleration and boat
movement when activating the trolling motor. When using the foot‑pedal, the
motor will start up at the last selected speed and course settings. Before
pressing the foot‑pedal, hold on to a seat or handhold, and advise
passengers to do the same.
51752
a
c
b
TROLLING MOTOR OPERATION
28 eng
Control the speed of the trolling motor by adjusting the speed control dial on the
foot pedal. Rotate the dial forward to increase motor speed, and rotate it
backward to reduce speed. Press and hold the momentary button to operate
the motor at the selected speed. Release the momentary button to stop the
motor. Press the propeller constant on/off button once to run the motor at the
selected speed. Press the button again to turn the motor off. The motor speed
can be adjusted while the motor is running.
a - Speed control dial—
rotate forward to
increase speed
b - Momentary button
c - Propeller constant
on/off button
b
a
c
51753
TROLLING MOTOR OPERATION
eng 29
Handheld Remote Operation
!
WARNING
Rotating propellers can cause serious injury or death. Never start or operate
the motor out of water.
To operate the trolling motor using the handheld remote, sync the foot pedal to
the trolling motor receiver. Refer to Activating the Handheld Remote in the
Product Installation, Wiring, and Battery Information section of this manual.
a - Increase speed
b - Propeller on/off
c - Right turn
d - Decrease speed
e - Left turn
TURNING THE HANDHELD REMOTE ON OR OFF
The handheld remote is always on, and is ready for use anytime that the trolling
motor is powered up and in the deployed position.
STEERING
•
To turn left, press the left turn button on the handheld remote.
•
To turn right, press the right turn button on the handheld remote.
• The available steering range allows the trolling motor to turn beyond 360°
for operation in reverse.
SPEED CONTROL
•
Press the propeller on/off button once to start the propeller, and press
the propeller on/off button again to stop the propeller.
•
The system is equipped with 20 speed levels. Press the increase speed
(+) button to increase motor speed by one level, and press the decrease
speed (–) button to reduce motor speed by one level.
51842
b
a
c
d
e
TROLLING MOTOR OPERATION
30 eng
•
Holding the increase speed (+) or decrease speed (–) will cause the
speed level to increase or decrease until the speed level limit is reached.
Holding the increase speed (+) or decrease speed (–) button for 2.5
seconds will ramp up the speed level from 0% to 100%, or decrease from
100% to 0%, respectively. The trolling motor will emit two beeps when it
reaches the 100% or 0% speed level.
TROLLING MOTOR OPERATION
eng 31
Trolling Motor Care
To keep your trolling motor in the best operating condition and retain its
dependability, your trolling motor must receive periodic inspections and
maintenance. Keep it maintained properly to ensure the safety of you and your
passengers.
!
WARNING
Neglecting to inspect, maintain, or repair your trolling motor can result in
product damage or serious injury or death. Do not perform maintenance or
service on your trolling motor if you are not familiar with the correct service
and safety procedures.
Record all maintenance performed and save maintenance work orders and
receipts.
SELECTING REPLACEMENT PARTS
Use only original MotorGuide replacement parts.
Inspection and Maintenance Schedule
BEFORE EACH USE
• Inspect for loose or corroded wiring connections.
• Check the tightness of the battery cable connections. Nylock nuts are
recommended for securing the battery cables to their terminals.
• Check the tightness of the propeller nut.
• Check the propeller blades for damage.
• Check the tightness of the mount to the deck of the boat.
AFTER EACH USE
• Disconnect the battery cables from the power source or unplug the motor
from the boat.
• Check each side of the propeller and propeller shaft for debris such as
weeds and fishing line. Remove all debris.
• Check the tightness of the propeller nut.
• Wash the trolling motor with clean water and a mild soap such as
Attwood® Premium Boat Wash to remove dirt and dust that may scratch
the surface.
IMPORTANT: Do not use harsh cleaners such as bleach or citrus cleaners to
clean the trolling motor. These cleaners can damage the finish on the trolling
motor.
IMPORTANT: Do not power wash the trolling motor.
EVERY 100 HOURS OF USE OR ANNUALLY (WHICHEVER OCCURS
FIRST)
1. Apply 2‑4‑C with PTFE to the depth collar knob screw threads.
MAINTENANCE AND STORAGE
32 eng
NOTE: 2‑4‑C with PTFE is a marine grease available at marine supply stores
and your MotorGuide dealer.
Tube Ref
No.
Description Where Used Part No.
95
2-4-C with PTFE Depth collar knob screw threads 92-802859A 1
2. Remove the side panels by removing the two screws on each side of the
mount. Gently pull the cover away from the mount and towards the foot
release lever.
a - Depth collar knob screw threads
b - Screws securing the side panel
b
b
53465
a
MAINTENANCE AND STORAGE
eng 33
3. Apply 2‑4‑C with PTFE to the slot on the foot release lever linkage on
each side of the deck mount. Press the foot release lever and apply more
2‑4‑C with PTFE to the slot, equally distributing the grease along the
length of the slot.
a - Slot
IMPORTANT: Never use an aerosol lubricant or solvent‑based lubricant to
grease or oil any part of the trolling motor. Many aerosol lubricants contain
harmful propellants that can cause damage to various parts of the trolling
motor.
Tube Ref
No.
Description Where Used Part No.
95
2-4-C with PTFE Slot on the foot release lever linkage 92-802859A 1
4. Install the side panels onto the deck mount and tighten the screws.
5. Check the tightness of the mounting screws, nuts, and other fasteners.
6.
Inspect the battery. Refer to Battery Inspection.
Storage Preparation
The major consideration in preparing your trolling motor for storage is to protect
it from corrosion and damage caused by freezing of trapped water. It is also
recommended that batteries are disconnected prior to storage and that the
batteries are stored indoors in a dry location during long‑term storage. The
batteries should also be removed from the handheld remote and wireless foot
pedal for long‑term storage.
a
53466
MAINTENANCE AND STORAGE
34 eng
Refer to the Inspection and Maintenance Schedule and complete the
appropriate care instructions to prepare your trolling motor for storage. Store
the trolling motor in a dry location where it will not be affected by temperatures
below –29 °C (–20 °F).
IMPORTANT: Trolling motors stored in temperatures below 0 °C (32 °F) should
be operated slowly for a minimum of 15 minutes before going above 30%
throttle.
Battery Inspection
The battery should be inspected at periodic intervals to ensure proper trolling
motor operation.
IMPORTANT: Read the safety and maintenance instructions that accompany
your battery.
1. Ensure that the battery is secured to the vessel.
2. Ensure that the battery cable terminals are clean, tight, and correctly
installed. For installation instructions, refer to Battery Connection in the
Product Installation, Wiring, and Battery Information section of this
manual.
3. Ensure that the battery is equipped with a battery box to prevent
accidental shorting of the battery terminals.
Propeller Replacement
!
WARNING
Performing service or maintenance without first disconnecting the battery can
cause product damage, personal injury, or death due to fire, explosion,
electrical shock, or unexpected motor starting. Always disconnect the battery
cables from the battery before maintaining, servicing, installing, or removing
motor components.
REMOVING THE PROPELLER
1. Disconnect the power cables from the battery.
2. While holding the propeller blade with one gloved hand, use a 9/16 in.
wrench or a ratchet and a 9/16 in. socket to remove the propeller nut.
Remove the propeller nut and washer (or anode, for saltwater models).
IMPORTANT: Remove the propeller nut with a wrench or a ratchet and socket.
Using another tool may damage the propeller nut or shaft. If the propeller
cannot be removed easily, use a rubber mallet to lightly tap the back side of
the opposite blade. If the propeller cannot be removed, have the propeller
removed by an authorized dealer.
MAINTENANCE AND STORAGE
eng 35
NOTE: If the propeller pin is bent, replace the propeller pin.
53442
44663
INSTALLING THE PROPELLER
1. Rotate the motor shaft to insert the propeller pin horizontally.
a - Propeller pin
2. Install the propeller onto the motor shaft by engaging the propeller onto
the propeller pin.
44663
a
44664
MAINTENANCE AND STORAGE
36 eng
3. Install the washer (or anode, for saltwater models) onto the propeller shaft
then install the propeller nut. Tighten the propeller nut securely.
53442
4. Tighten the propeller nut another ¼ turn.
MAINTENANCE AND STORAGE
eng 37
Troubleshooting
NOTE: For service information, contact any certified MotorGuide service
center. For a full listing of MotorGuide service centers, go to
www.motorguide.com or contact any Mercury Marine service office.
Symptom Possible Cause Resolution
Trolling motor does not
respond to wireless
commands
Weak trolling motor
batteries
Check the battery
charge indicator
on the trolling
motor. Recharge
or replace
batteries as
required.
Weak handheld remote
battery or weak foot pedal
battery
Replace the
handheld remote
battery (one
AAA‑size) or foot
pedal batteries
(two AA‑size).
Wireless controllers not
synced
Refer to
Activating the
Wireless Foot
Pedal or
Activating the
Handheld
Remote.
OWNER SERVICE ASSISTANCE
38 eng
Symptom Possible Cause Resolution
Loss of power
Weak trolling motor
batteries
Check the battery
charge indicator
on the trolling
motor. Recharge
or replace the
batteries as
required.
Loose or corroded battery
connections
Inspect battery
connections for
cleanliness and
tightness.
Propeller is loose, damaged,
or off‑balance
Refer to
Propeller
Replacement.
Wiring or electrical
connection faulty
Wire gauge from
the battery to the
trolling motor is
insufficient.
6‑gauge wire is
recommended.
Magnets cracked or chipped
The motor will
whine or grind.
Contact a
Service Center.
Water intrusion in the lower
unit
Contact a
Service Center.
OWNER SERVICE ASSISTANCE
eng 39
Symptom Possible Cause Resolution
Excessive noise or
vibration
Propeller is loose, damaged,
or off‑balance
Refer to
Propeller
Replacement.
Damaged bearings or
bushings
Contact a
Service Center.
Magnets interfering with
armature
Turn off the
power and
manually rotate
the propeller. If
the propeller
does not rotate
freely with a
slight magnetic
drag, contact a
Service Center.
Magnets cracked or chipped
The motor will
whine or grind.
Contact a
Service Center.
Motor failure
(motor runs at partial
speed)
Loose electrical connections
Connections in
the head may be
loose or
damaged.
Contact a
Service Center.
Thermal protection is
overloaded
Temperature
exceeds
specification.
Contact a
Service Center.
Propeller is loose, damaged,
or off‑balance
Refer to
Propeller
Replacement.
OWNER SERVICE ASSISTANCE
40 eng
Symptom Possible Cause Resolution
Motor failure
(motor does not run)
Weak trolling motor
batteries
Check the battery
charge indicator
on the trolling
motor. Recharge
or replace the
battery as
required.
Loose or corroded battery
connections
Inspect battery
connections for
cleanliness and
tightness.
Wiring or electrical
connection faulty
Wire gauge from
the battery to the
trolling motor is
insufficient.
6‑gauge wire is
recommended.
Loose electrical connections
Inspect
connections for
cleanliness and
tightness.
Thermal protection is
overloaded
Disconnect the
trolling motor
batteries and
check for weeds
or debris around
the propeller.
Temperature
exceeds
specification.
Contact a
Service Center.
Fuse or circuit breaker is
open
Replace the fuse
or reset the
circuit breaker
only after
determining the
root cause of the
problem.
Magnets interfering with
armature
Turn off the
power and
manually rotate
the propeller. If
the propeller
does not rotate
freely with a
OWNER SERVICE ASSISTANCE
eng 41
Symptom Possible Cause Resolution
Inaccurate temperature
reading (models with
internal sonar)
Lower unit not fully
submerged
Adjust the depth
of the motor.
Ensure the lower
unit is fully
submerged.
Refer to
Adjusting the
Motor Depth.
Damaged nose cone
Contact a
Service Center.
Damaged sonar cable
Contact a
Service Center.
Motor is difficult to deploy
or return to stowed
position
Sticking latch mechanism
Lubricate the
latch mechanism.
Refer to
Inspection and
Maintenance
Schedule.
Difficulty removing
propeller
Bent propeller pin
Hold one blade
and lightly tap the
opposite blade
with a rubber
mallet.
Use a putty knife
on both sides of
the propeller to
apply equal
pressure.
Bent armature shaft
Contact a
Service Center.
Troubleshooting the Foot Pedal and Handheld Remote
ERASING THE RECEIVER'S MEMORY
Erasing the receiver's memory will erase all electronic ID numbers that are
stored in the receiver's memory.
1. Plug in the battery cable to a power source. In less than ten seconds,
press the left arrow, right arrow, +, and – buttons on the handheld
remote simultaneously.
2. Listen for a long beep indicating the receiver has erased all stored
electronic ID numbers.
OWNER SERVICE ASSISTANCE
42 eng
NOTE: If all four buttons on the remote are not pressed simultaneously within
ten seconds, or a long beep is not heard, unplug the battery cables from the
power source and then refer to
Activating the Wireless Foot Pedal
and
Activating the Handheld Remote
in the
Product Installation, Wiring, and
Battery Information
section of this manual.
REPROGRAMMING THE WIRELESS FOOT PEDAL OR REMOTE
NOTE: This activation procedure applies to the foot pedal and handheld
remote.
IMPORTANT: To activate multiple foot pedals or remotes, the motor must be
unplugged from the power source and then plugged back into the power source
between activating each control device.
1. Unplug the battery cables from the power source. Wait 30 seconds and
then plug the motor into the power source.
2.
In less than ten seconds, press and hold the left arrow and right arrow
buttons on the handheld remote. For the foot pedal controller, hold the
propeller and anchor button simultaneously.
FOOT PEDAL BATTERY REPLACEMENT
Battery required: Two AA alkaline batteries
1. Remove the two screws securing the battery cover plate. Remove the
battery cover plate.
a - Battery cover plate
b - Screws
2. Remove the batteries from the battery holder.
3. Install the new batteries in the proper orientation for correct polarity.
a
b
a
51760
OWNER SERVICE ASSISTANCE
eng 43
4. Ensure the rubber seal is positioned correctly around the battery cover
plate.
a - AA alkaline batteries
b - Rubber seal
5. Replace the battery cover plate and install the two screws. Tighten the
screws securely.
a - Battery cover plate
b - Screws
HANDHELD REMOTE BATTERY REPLACEMENT
Battery required: One AAA alkaline battery
51761
a
b
a
b
a
51760
OWNER SERVICE ASSISTANCE
44 eng
1. Remove the four screws from the back of the handheld remote. Remove
the back cover.
a - Screws (4)
2. Remove the old battery from the battery holder.
51838
3. Insert the new battery with the positive (+) side facing the positive (+) end
of the battery holder.
a
a
a a
51837
OWNER SERVICE ASSISTANCE
eng 45
4. Replace the handheld remote back plate and install the four screws.
Ensure that the rubber seal is positioned correctly between the two halves
of the handheld remote. Tighten the screws securely.
a - Negative (–) end of battery holder
b - Battery
c - Positive (+) end of battery holder
d - Rubber seal
Service Assistance
Your satisfaction with your product is very important to us. If you have a
problem or question about your motor, contact your dealer or any certified
MotorGuide Service Center. For more service assistance information, refer to
Warranty Information.
The following information will be needed by the service office:
• Your name and address
• Daytime telephone number
• Model and serial number of your trolling motor
• Proof of purchase or registration verification
• Nature of problem
Mercury Marine Service Offices
For assistance, call, fax, or write. Please include your daytime telephone
number with mail and fax correspondence.
United States, Canada
Telephone
English ‑ (920) 929‑5040
Français ‑ (905) 636‑4751
Mercury Marine
W6250 W. Pioneer Road
P.O. Box 1939
Fond du Lac, WI 54936-1939
Fax
English ‑ (920) 929‑5893
Français ‑ (905) 636‑1704
Website www.mercurymarine.com
a
b
c
d
51839
OWNER SERVICE ASSISTANCE
46 eng
Australia, Pacific
Telephone (61) (3) 9791‑5822 Brunswick Asia Pacific Group
41–71 Bessemer Drive
Dandenong South, Victoria 3175
Australia
Fax (61) (3) 9706‑7228
Europe, Middle East, Africa
Telephone (32) (87) 32 • 32 • 11 Brunswick Marine Europe
Parc Industriel de Petit-Rechain
B-4800 Verviers,
Belgium
Fax (32) (87) 31 • 19 • 65
Mexico, Central America, South America, Caribbean
Telephone (954) 744‑3500 Mercury Marine
11650 Interchange Circle North
Miramar, FL 33025
U.S.A.
Fax (954) 744‑3535
Japan
Telephone 072‑233‑8888 Kisaka Co., Ltd.
4-130 Kannabecho Sakai-shi Sakai-ku
5900984 Osaka,
Japan
Fax 072‑233‑8833
Asia, Singapore
Telephone (65) 65466160 Brunswick Asia Pacific Group
T/A Mercury Marine Singapore Pte Ltd
29 Loyang Drive
Singapore, 508944
Fax (65) 65467789
OWNER SERVICE ASSISTANCE
eng 47
