Mercury MTB01, MTB02 User Manual

Please read this manual thoroughly and ensure
all contents are fully understood before use of
the apparatus.

WARNING

MTB01, MTB02

Digital Multimeter

Item Ref:

600.101UK, 600.102UK

600.101/102UK User Manual

Warning
To avoid possible electric shock or personal injury, and to
avoid possible damage to the Meter or to the equipment
under test, adhere to the following rules:
➢ Before using the Meter inspect the case. Do not

use the Meter if it is damaged or the case (or part
of the case) is removed. Look for cracks or missing
plastic. Pay attention to the insulation around the
connectors.

➢ Inspect the test leads for damaged insulation or

exposed metal. Check the test leads for continuity.

➢ Do not apply more than the rated voltage, as

marked on the meter, between the terminals or
between any terminal and grounding.

➢ The rotary switch should be placed in the right

position and no changeover of range shall be
made during measurement being conducted to
prevent damage of the Meter.

➢ When the meter working at an effective voltage

over 60V in DC or 30Vrms in AC, special care
should be taken for there is danger of electric
shock.

➢ Use the proper terminals, function, and range for

your measurements.

➢ Do not use or store the meter in an environment of

high temperature, humidity, explosive,
inflammable, and strong magnetic field. The
performance of the meter may deteriorate after
dampened.

➢ When using the test leads, keep your fingers

600.101/102UK User Manual

behind the finger guards.

➢ Disconnect circuit power and discharge all

high-voltage capacitors before testing resistance,
continuity, diodes or hFE.

➢ Replace the battery as soon as the battery

indicator appears. With a low battery, the
meter may produce false readings that can lead to
electric shock and personal injury.

➢ Remove the connection between the testing leads

and the circuit being tested and turn the meter
power off before opening the meter case.

➢ The internal circuit of the meter shall not be

altered at will to avoid damage of the meter and
any accident.

➢ Soft cloth and mild detergent should be used to

clean the surface of the meter in regular basis. No
abrasive and solvent should be used to prevent
the surface of the meter from corrosion, damage
and accident.

➢ The meter is suitable for indoor use only.
➢ Turn the meter power off when it is not in use and

take out the battery when not using for a long time.
Check the battery at regular basis as it may leak
when it has been using for some time, replace the
battery as soon as leaking appears. A leaking
battery will damage the meter.
