Mercedes-Benz V-Class, V 200 d, V 220 d, V 220 d 4MATIC, V 250 d Operating Instructions Manual
...
V-Class
Operating Instructions
Mercedes-Benz
Symbols
G
WARNING
Warning notes make you aware of dangers
which could pose a threat to your health or
life, or to the health and life of others.
H
Environmental note
Environmental notes provide you with information on environmentally aware actions or
disposal.
!
Notes on material damage alert you to dangers that could lead to damage to your vehicle.
i
These symbols indicate useful instructions
or further information that could be helpful to
you.
X
This symbol designates an instruction you must follow.
X
Several consecutive symbols indicate an instruction with several
steps.
(Y page)
This symbol tells you where you can
find further information on a topic.
Y Y
This symbol indicates a warning or an
instruction that is continued on the
next page.
Display
This text indicates a message on the
display.
Parts of the software in the vehicle are protected
by copyright © 2005 The Free Type Project
http://www.freetype.org. All rights reserved.
Welcome to the world of Mercedes-Benz
Before you first drive off, read these Operating
Instructions carefully and familiarise yourself
with your vehicle. Please adhere to the information and warning notes in these Operating
Instructions for your own safety and to ensure a
longer operating duration of the vehicle. Failure
to observe the instructions may lead to damage
to the vehicle or personal injury.
The equipment or model designation of your
vehicle may differ according to:
R
model
R
order
R
country specification
R
availability
The illustrations in this manual show a left-handdrive vehicle. The location of vehicle parts and
controls for right-hand drive vehicles differ
accordingly.
Mercedes-Benz is constantly updating its vehicles to the state of the art.
Mercedes-Benz therefore reserves the right to
introduce changes in:
R
design
R
Equipment
R
technical features
Therefore, the descriptions provided may occasionally differ from your own vehicle.
The following are components of the vehicle:
R
Operating Instructions
R
Maintenance or Service Booklet
R
Equipment-dependent supplements
Keep these printed documents in the vehicle at
all times. If you sell the vehicle, always pass the
documents on to the new owner.
i
You can get to know some of the important
features of your vehicle in German and English in the interactive Operating Instructions
on the Internet at:
www.mercedes-benz.de/
betriebsanleitung-transporter
You can also use the Mercedes-Benz Guide
smartphone app:
Please note that the Mercedes-Benz Guide app
may not yet be available in your country.
The technical documentation team at Daimler
AG wishes you safe and pleasant motoring.
4475841703Z102
É4475841703Z1028ËÍ
Index ....................................................... 4
Digital Operating Instructions ........... 27
Introduction ........................................... 27
Operation ............................................... 27
Introduction ......................................... 28
Operating Instructions ........................... 28
Correct use ............................................ 28
Protection of the environment ............... 29
Operating safety and vehicle approval
............................................................... 30
Genuine Mercedes-Benz parts ............... 33
QR code for rescue card ........................ 33
Data stored in the vehicle ...................... 34
Copyright information ............................ 34
At a glance ........................................... 35
Cockpit .................................................. 35
Instrument cluster ................................. 36
Steering wheel with buttons .................. 38
Centre console ...................................... 39
Overhead control panel ......................... 43
Door control panel ................................. 44
Safety ................................................... 45
Useful information ................................. 45
Occupant safety .................................... 45
Children in the vehicle ........................... 59
Pets in the vehicle ................................. 68
Driving safety systems ........................... 69
Anti-theft systems ................................. 72
Opening and closing ........................... 75
Useful information ................................. 75
Key ........................................................ 75
Central locking ...................................... 79
Driver's door and co-driver's door ......... 81
Sliding door ........................................... 82
Electric sliding door ............................... 82
Tailgate .................................................. 85
EASY-PACK tailgate ............................... 86
Separately-opening rear window ........... 88
Side windows ......................................... 89
Panorama sliding sunroof ...................... 91
Seats, steering wheel and mirrors .... 96
Useful information ................................. 96
Seats ..................................................... 96
Steering wheel ..................................... 121
Mirrors ................................................. 122
Memory function ................................. 124
Lights and windscreen wipers ......... 126
Useful information ............................... 126
Exterior lighting ................................... 126
Interior lighting .................................... 131
Replacing bulbs: interior lighting and
ambient lamps ..................................... 132
Replacing bulbs: vehicles with LED
headlamps ........................................... 134
Replacing bulbs: vehicles with halo-
gen headlamps .................................... 134
Windscreen wipers .............................. 138
Climate control ................................. 143
Useful information ............................... 143
Overview of climate control systems ... 143
Operating the climate control system .. 146
Operating the auxiliary heating sys-
tem ...................................................... 157
Adjusting the air vents ......................... 169
Driving and parking .......................... 171
Useful information ............................... 171
Running-in notes .................................. 171
Driving ................................................. 171
Automatic transmission ....................... 178
Refuelling ............................................. 184
Parking ................................................ 189
Driving tips .......................................... 191
Driving systems ................................... 197
Towing a trailer .................................... 239
On-board computer and displays .... 245
Useful information ............................... 245
Important safety notes ........................ 245
Display and operation .......................... 245
Menus and submenus ......................... 248
2
Contents
Display messages ................................ 260
Warning and indicator lamps on the
instrument cluster ............................... 283
Multimedia systems ......................... 293
Introduction ......................................... 293
Overview .............................................. 294
Touchpad ............................................. 296
Favourites ............................................ 300
Calling up vehicle settings ................... 301
Navigation ........................................... 301
Telephone ............................................ 303
Establishing and ending an Internet
connection ........................................... 309
Radio ................................................... 310
Stowing and features ....................... 312
Useful information ............................... 312
Stowage spaces and stowage com-
partments ............................................ 312
Sun visors ............................................ 314
Folding table ........................................ 314
Cup holder ........................................... 318
Bottle holder ........................................ 320
Ashtray ................................................ 320
Cigarette lighter ................................... 320
12 V socket ......................................... 321
230 V socket ....................................... 322
Coolbox in the centre console ............. 323
Mercedes-Benz emergency call sys-
tem ...................................................... 324
MB Contact/Mercedes me connect .... 324
Mobile phone ....................................... 325
iPad® attachment ................................ 327
Additional communications equip-
ment .................................................... 327
Transporting loads with the vehi-
cle ....................................................... 328
Useful information ............................... 328
Loading guidelines ............................... 328
Load distribution ................................. 329
Securing loads ..................................... 330
Load-securing aids .............................. 331
Carrier systems ................................... 334
Maintenance and care
...................... 336
Useful information ............................... 336
Engine compartment ........................... 336
Maintenance ........................................ 343
Battery ................................................. 345
Care ..................................................... 350
Breakdown assistance ..................... 357
Useful information ............................... 357
Where will I find...? .............................. 357
Flat tyre ............................................... 358
Jump-starting ....................................... 358
Tow-starting and towing away ............. 360
Fuses ................................................... 364
Wheels and tyres .............................. 365
Useful information ............................... 365
Important safety notes ........................ 365
Operation ............................................ 366
Winter operation .................................. 367
Tyre pressure ....................................... 369
Changing a wheel ................................ 376
Wheel and tyre combinations .............. 380
Spare wheel ......................................... 382
Technical data ................................... 385
Useful information ............................... 385
Vehicle electronics .............................. 385
Identification plates ............................. 386
Service products and capacities .......... 386
Vehicle data ......................................... 394
Contents
3
1, 2, 3 ...
4MATIC (permanent four-wheel
drive) .................................................. 209
12 V socket
see Sockets
230 V power socket .......................... 322
360° camera
Cleaning ......................................... 354
Function/notes ............................. 234
A
ABS (Anti-lock Braking System)
Display message ............................ 261
Function/notes ................................ 69
Important safety notes .................... 69
Warning lamp ................................. 286
Acceleration
see Kickdown
Accident
Automatic measures after an acci-
dent ................................................. 59
Activating/deactivating air-recir-
culation mode .................................... 155
Activating/deactivating cooling
with air dehumidification ................. 146
Active light function ......................... 129
Active Light System
Display message ............................ 269
Active Parking Assist
Cancelling/stopping active park-
ing assistance ................................ 229
Detecting parking spaces .............. 226
Display message ............................ 276
Exiting a parking space .................. 228
Function/notes ............................. 225
Important safety notes .................. 225
Parking .......................................... 227
Towing a trailer .............................. 225
Active Service System
see Service interval display
Adaptive brake lights .......................... 72
Adaptive Highbeam Assist
Display message ............................ 269
Function/notes ............................. 130
Switching on/off ........................... 130
AdBlue
®
Additive ......................................... 390
Display message ............................ 271
Displaying the level ........................ 256
Driving abroad ............................... 194
Exhaust gas aftertreatment ............. 32
Filler cap ........................................ 187
Filling capacity ............................... 390
Filling pump ................................... 187
Important safety notes .................. 389
Low outside temperatures ............. 390
Notes ............................................. 389
Purity ............................................. 390
Refill bottles .................................. 188
Refill canisters ............................... 188
Topping up ..................................... 186
Additional speedometer ................... 259
Additives
Diesel ............................................ 389
Engine oil ....................................... 391
Adjusting the headlamp range ......... 128
Adjusting the seat sliders ................ 115
Air filter (white display message) .... 273
Air pressure
see Tyre pressure
Air vents
Important safety notes .................. 169
Setting the centre air vents ........... 169
Setting the rear-compartment air
vents .............................................. 169
Setting the side air vents ............... 169
Air-conditioning system
see Climate control
Airbag
Automatic front-passenger front
airbag deactivation .......................... 52
Introduction ..................................... 49
PASSENGER AIR BAG OFF indica-
tor lamp ........................................... 46
Airbags
Display message ............................ 262
Front airbag (driver, front
passenger) ....................................... 51
Important safety guidelines ............. 50
Sidebag ............................................ 51
Triggering ......................................... 57
Windowbag ...................................... 52
4
Index
Alertness assistant
see ATTENTION ASSIST
All-wheel drive
Display message (brake) ................ 264
Downhill Speed Regulation ............ 209
DSR ............................................... 209
Function/notes ............................. 209
Ambient lamp
Changing a bulb (front door) .......... 133
Changing a bulb (vanity mirror) ...... 133
Ambient lighting ................................ 132
Anti-lock braking system
see ABS (Anti-lock Braking System)
Anti-skid chains
see Snow chains
Aquaplaning ....................................... 195
Armrest
Stowage compartment .................. 313
Armrests ............................................ 119
Ashtray ............................................... 320
Assistance display (on-board com-
puter) .................................................. 255
Assistance menu (on-board com-
puter) .................................................. 256
ASSYST
Service interval display .................. 344
ATA (Anti-Theft Alarm system)
Interior motion sensor ..................... 73
Tow-away protection ........................ 73
Attachments/add-on equipment ....... 32
ATTENTION ASSIST
Activating/deactivating ................. 258
Display message ............................ 274
Function/notes ............................. 219
Audio 10
Important safety notes .................. 293
Audio 15
Important safety notes .................. 293
Authorised workshop
see Qualified specialist workshop
AUTO lights
Display message ............................ 269
see Lights
Automatic engine start (ECO start/
stop function) .................................... 176
Automatic engine switch-off (ECO
start/stop function) .......................... 175
Automatic front-passenger front
airbag deactivation system
Operation ......................................... 53
Problems ......................................... 56
System self-test ............................... 55
Automatic headlamp mode .............. 126
Automatic locking ............................... 81
Automatic transmission
Accelerator pedal position ............. 182
Changing gear ............................... 180
DIRECT SELECT lever ..................... 178
Display message ............................ 281
Drive program display .................... 180
Driving tips .................................... 182
DYNAMIC SELECT switch .............. 181
Emergency running mode .............. 184
Engaging drive position .................. 178
Engaging neutral ............................ 178
Engaging reverse gear ................... 178
Engaging the park position ............ 178
Gearshift recommendation ............ 183
Important safety notes .................. 178
Kickdown ....................................... 182
Manual shifting .............................. 182
Overview ........................................ 178
Problem (fault) ............................... 184
Rocking free .................................. 182
Shift ranges ................................... 180
Starting the engine ........................ 173
Steering wheel gearshift paddles ... 182
Trailer towing ................................. 182
Transmission position display
(DIRECT SELECT lever) ................... 180
Transmission positions .................. 179
Automatic transmission emer-
gency running mode ......................... 184
Auxiliary heater
see Auxiliary warm-air heater
see Hot-water auxiliary heater
Auxiliary heating
see Auxiliary warm-air heater
see Hot-water auxiliary heater
Auxiliary ventilation
see Hot-water auxiliary heater
Auxiliary warm-air heater
Function/notes ............................. 162
Heater booster function (Immedi-
ate heating mode) .......................... 165
Index
5
Immediate heating mode ............... 165
Important safety notes .................. 157
Problem (malfunction) ................... 167
Remote control .............................. 163
Setting departure time ................... 165
Switching on/off (remote con-
trol) ................................................ 163
Switching on/off (Timer) ............... 164
Timer ............................................. 164
Axle load, permissible (trailer tow-
ing) ...................................................... 396
B
Back button ....................................... 296
Ball coupling
Fitting ............................................ 241
Removing ....................................... 242
BAS (Brake Assist System)
Function/notes ................................ 69
Basic settings
see Settings
Battery (auxiliary heating remote
control)
Changing (auxiliary warm-air
heater) ........................................... 166
Replacing (hot-water auxiliary
heater) ........................................... 160
Battery (key)
Checking .......................................... 78
Important safety notes .................... 77
Replacing ......................................... 78
Battery (vehicle)
Care ............................................... 349
Charging ........................................ 349
Connecting and fitting ................... 348
Disconnecting and removing ......... 346
Display message ............................ 271
Important safety notes .................. 345
Jump starting ................................. 358
Location ......................................... 346
Bed
see Rear bench seat
Before pulling away
Important safety notes .................. 172
Belt
see Seat belts
Belt tensioner
Activation ......................................... 57
Belt warning ......................................... 49
Bench berth
see Rear bench seat
Bio-diesel ........................................... 388
Bleeding the fuel system .................. 177
Blind Spot Assist
Activating ....................................... 215
Activating/deactivating (on-
board computer) ............................ 257
Collision warning ........................... 215
Display message ............................ 278
Important safety notes .................. 214
Monitoring range of the sensors .... 214
Notes/function .............................. 213
Trailer towing ................................. 215
Warning display ............................. 215
Blower
see Climate control
BlueTEC
Topping up AdBlue® ....................... 186
BlueTEC exhaust gas aftertreatment
Notes ............................................... 32
BlueTEC
®
AdBlue® service product ................ 389
Exhaust gas aftertreatment notes .... 32
Bluetooth
®
Connecting a different mobile
phone ............................................ 306
Entering the passcode ................... 305
Searching for a mobile phone ........ 304
Telephony ...................................... 303
Bonnet
Closing ........................................... 337
Display message ............................ 282
Important safety notes .................. 336
Opening ......................................... 337
Bottle holders .................................... 320
Brake
Display message (all-wheel drive) .. 264
EBD .................................................. 70
Brake Assist
see BAS (Brake Assist System)
Brake assistance
see BAS (Brake Assist System)
6
Index
Brake fluid
Checking the level ......................... 342
Display message ............................ 264
Notes ............................................. 392
Brake force distribution
see EBD (electronic brake force
distribution)
Brake lamp
Replacing bulbs ............................. 137
Trailer display message ................. 269
Brake lamps
Adaptive ........................................... 72
Display message ............................ 270
Brake pads/linings
New ............................................... 195
Brakes
ABS .................................................. 69
Adaptive Brake Assist .................... 212
BAS .................................................. 69
Brake fluid (notes) ......................... 392
Checking brake fluid level .............. 342
Display message ............................ 261
Driving tips .................................... 194
Hill start assist ............................... 175
HOLD function ............................... 221
Important safety notes .................. 194
New brake pads/linings ................ 195
Parking brake ................................ 189
Warning lamp ................................. 285
Breakdown
Fire extinguisher ............................ 358
Vehicle tool kit ............................... 357
see Towing away
Buttons and controller ...................... 295
Buttons on the steering column ...... 246
C
Calling up a fault
see Display messages
Camera
see 360° camera
see Reversing camera
Car
see Vehicle
Car wash
see Care
Car wash (care) ................................. 350
Care
360° camera ................................. 354
Automatic car wash ....................... 350
Carpets .......................................... 356
Chrome parts ................................. 352
Display ........................................... 355
Exterior lighting ............................. 353
Gear or selector lever .................... 356
High-pressure cleaner .................... 351
Interior ........................................... 355
Notes ............................................. 350
Paint .............................................. 351
Plastic trim .................................... 355
Reversing camera .......................... 353
Roof lining ...................................... 356
Seat belt ........................................ 356
Seat cover ..................................... 356
Sensors ......................................... 353
Sliding door ................................... 354
Steering wheel ............................... 356
Tail pipes ....................................... 352
Trim pieces .................................... 356
Washing by hand ........................... 351
Washing the engine ....................... 351
Wheels ........................................... 352
Windows ........................................ 352
Wiper blades .................................. 352
CD player/CD changer(on-board
computer) .......................................... 253
Central locking
Automatic locking ............................ 81
Emergency unlocking ....................... 77
Locking/unlocking (buttons) ........... 79
Locking/unlocking (key) .................. 76
Central locking system
see Central locking
Centre console
Between the driver's and co-driv-
er's seats ......................................... 42
Lower section .................................. 41
Middle section ................................. 40
Upper section .................................. 39
Changing a bulb
Ambient lamp in the front door ...... 133
Boot lamp in the side trim panel .... 133
Halogen headlamps ....................... 134
LED light sources ........................... 134
Mirror lamp in the roof lining ......... 133
Index
7
Rear interior light in the roof lining .. 132
Signal and ambient light in the tail-
gate ............................................... 133
Changing bulbs
Dipped-beam headlamps ............... 135
Fitting/removing a rear lamp clus-
ter .................................................. 137
Fitting/removing the cover in the
front wheel arch ............................. 135
Fitting/removing the tail lamp ....... 137
Overview of lamp types (front
bulbs) ............................................. 135
Overview of lamp types (rear
bulbs) ............................................. 136
Parking lamp (front) ....................... 136
Parking lamp (rear) ........................ 137
Side lamp ....................................... 136
Turn signals (front) ......................... 136
Turn signals (rear) .......................... 137
see Changing light bulbs
Child
Restraint system .............................. 60
Child seat
Forward-facing restraint system ...... 63
ISOFIX .............................................. 61
On the front-passenger seat ............ 62
Rearward-facing restraint system .... 63
Recommendations ........................... 66
Suitable positions ............................ 63
Top Tether ....................................... 61
Child-proof lock
Hinged window ................................ 68
Sliding door ..................................... 68
Child-proof locks
Important safety notes .................... 67
Children in the vehicle
Important safety notes .................... 59
Chrome parts (cleaning instruc-
tions) .................................................. 352
Cigarette lighter ................................ 320
Cleaning
Mirror turn signal ........................... 353
Trailer tow hitch ............................. 354
Climate control
Adjusting airflow ............................ 149
Auxiliary heater .............................. 157
Auxiliary heating/ventilation .......... 157
Auxiliary warm-air heater ............... 162
Controlling automatically ............... 149
Convenience opening/closing
(air-recirculation mode) ................. 155
Cooling with air dehumidification .. 146
Demisting the windows .................. 154
Demisting the windscreen ............. 154
Hot-water auxiliary heater ............. 157
Important safety notes .................. 143
Indicator lamp ................................ 148
Information on TEMPMATIC (air-
conditioning system) ..................... 144
Information on THERMOTRONIC
(3-zone automatic climate con-
trol) ................................................ 146
Problem with the rear window
heating .......................................... 155
Problems with cooling with air
dehumidification ............................ 148
Rear control panel ......................... 144
Setting the air distribution ............. 152
Setting the air vents ...................... 169
Setting the airflow ......................... 153
Setting the climate mode ............... 149
Setting the temperature ................ 152
Switching air-recirculation mode
on/off ............................................ 155
Switching on/off ........................... 146
Switching residual heat on/off ...... 156
Switching the rear window heat-
ing on/off ...................................... 155
Switching the synchronisation
function on and off ........................ 153
Systems overview .......................... 143
TEMPMATIC control panel (air-
conditioning system) ..................... 143
THERMOTRONIC control panel (3-
zone automatic climate control) .... 144
Co-driver's seat
see Seats
Cockpit
Overview .......................................... 35
see Instrument cluster
Coffee cup symbol
see ATTENTION ASSIST
COLLISION PREVENTION ASSIST
Activating/deactivating the dis-
tance warning function .................. 257
Adaptive Brake Assist .................... 212
8
Index
Display message ............................ 276
Distance warning function ............. 211
Operation/notes ............................ 211
Collision warning
see COLLISION PREVENTION ASSIST
COMAND display
Cleaning ......................................... 355
Combination switch .......................... 127
Communications devices
Type approval/frequency .............. 385
Communications equipment
Operation ....................................... 327
Components
Multimedia system ........................ 294
Constant headlamp mode
see Daytime driving lights
Consumption statistics (on-board
computer) .......................................... 249
Control panel
above the windscreen ...................... 43
Centre console ................................ 39
Climate control ................................ 39
Driver's door .................................... 44
Controller ........................................... 296
Convenience closing feature .............. 91
Convenience opening feature ............ 91
Convenience opening/closing (air-
recirculation mode) ........................... 155
Conversions/equipment .................... 32
Coolant (engine)
Checking the level ......................... 340
Display message ............................ 273
Filling capacity ............................... 393
Notes ............................................. 392
Temperature display in the instru-
ment cluster .................................. 246
Topping up ..................................... 341
Warning lamp ................................. 289
Coolbox .............................................. 323
Cooling
see Climate control
Copyright ............................................. 34
Cornering light function
Display message ............................ 268
Function/notes ............................. 129
Crosswind Assist ................................. 72
Cruise control
Activating ....................................... 198
Activation conditions ..................... 198
Calling up the stored speed ........... 198
Cruise control lever ....................... 198
Deactivating ................................... 199
Display message ............................ 278
Displaying the speed ..................... 198
Driving system ............................... 197
Important safety notes .................. 197
LIM indicator lamp ......................... 198
Problem (malfunction) ................... 199
Selecting ........................................ 198
Setting a speed .............................. 199
Storing and maintaining current
speed ............................................. 198
Cup holder
Centre console .............................. 318
Important safety notes .................. 318
Rear compartment ......................... 319
Temperature controlled ................. 319
D
Dashboard
see Cockpit
Dashboard lighting
see Instrument cluster lighting
Data
see Technical data
Date
Setting (auxiliary warm-air
heater) ........................................... 165
Daytime driving lights
Display message ............................ 271
Replacing bulbs ............................. 136
Switching on/off (switch) .............. 126
Declarations of conformity ................. 30
Diagnostics connection
Operating safety and vehicle
approval ........................................... 31
Dialling a number (telephone) .......... 307
Diesel .................................................. 388
Diesel additives
see Additives
Diesel particle filter
Short-distance driving .................... 193
Digital Operating Instructions ........... 28
Index
9
Digital Owner's Manual
Help ................................................. 27
Introduction ..................................... 27
Digital speedometer ......................... 249
Dimensions ........................................ 395
Dipped-beam headlamps
Display message ............................ 268
Driving abroad ............................... 194
Replacing bulbs ............................. 135
Setting for driving on the right/
left ................................................. 258
Switching on/off ........................... 126
DIRECT SELECT lever
Automatic transmission ................. 178
Display
Function/notes ............................. 248
Notes about cleaning ..................... 295
see Display message
see Warning and indicator lamps
Display message
Driving systems ............................. 274
Important safety notes .................. 260
Display messages
Calling up (on-board computer) ..... 260
Engine ............................................ 271
Hiding (on-board computer) ........... 260
Introduction ................................... 260
Key ................................................ 283
Lights ............................................. 268
Safety systems .............................. 261
Service interval display .................. 344
Tyres .............................................. 280
Vehicle ........................................... 281
Display overview (multimedia sys-
tem) .................................................... 294
Distance control
see DISTRONIC PLUS
Distance recorder
see Trip meter
Distance warning function ............... 211
Distance warning signal (warning
lamp) .................................................. 291
DISTRONIC PLUS
Activating ....................................... 204
Activation conditions ..................... 204
Cruise control lever ....................... 203
Deactivating ................................... 207
Display message ............................ 274
Displays in the instrument cluster .. 207
Driving tips .................................... 204
Front-end collision warning ............ 202
Function/notes ............................. 202
Important safety notes .................. 202
Selecting ........................................ 203
Setting the specified minimum
distance ......................................... 206
Setting the speed .......................... 206
Storing and maintaining the cur-
rent speed ..................................... 206
Door
Central locking/unlocking (key) ...... 76
Changing bulbs (ambient lamp) ..... 133
Control panel ................................... 44
Display message ............................ 282
Emergency locking ........................... 77
Emergency unlocking ....................... 77
Downhill Speed Regulation .............. 209
Drive program
Display (DIRECT SELECT lever) ...... 180
Drive programs
Automatic transmission ................. 181
Drive system
DSR ............................................... 209
Driver's door and co-driver's door ..... 81
Driver's seat
see Seats
Driving abroad
AdBlue® ......................................... 194
Dipped-beam headlamps ............... 194
Fuel ................................................ 194
Mercedes-Benz Service ................. 193
Driving on flooded roads .................. 196
Driving safety system
EBD (electronic brake force distri-
bution) ............................................. 70
Driving safety systems
ABS (Anti-lock Braking System) ....... 69
Adaptive brake lights ....................... 72
BAS (Brake Assist System) .............. 69
ESP® (Electronic Stability Pro-
gram) ............................................... 70
Important safety guidelines ............. 69
Overview .......................................... 69
10
Index
Driving system
COLLISION PREVENTION ASSIST .. 211
Driving systems
4MATIC .......................................... 209
360°camera .................................. 234
Active Parking Assist ..................... 225
ATTENTION ASSIST ........................ 219
Blind Spot Assist ............................ 213
Cruise control ................................ 197
Display message ............................ 274
Distronic Plus ................................ 202
HOLD function ............................... 221
Lane Keeping Assist ...................... 215
PARKTRONIC ................................. 222
Reversing camera .......................... 229
SPEEDTRONIC ............................... 199
Traffic Sign Assist .......................... 217
Driving tips
Aquaplaning ................................... 195
Automatic transmission ................. 182
Brakes ........................................... 194
DISTRONIC PLUS ........................... 208
Downhill gradient ........................... 194
Driving abroad ............................... 193
Driving in mountainous areas ........ 197
Driving in winter ............................. 196
Driving on flooded roads ................ 196
Driving on wet roads ...................... 195
General .......................................... 191
Icy road surfaces ........................... 196
Important safety notes .................. 171
Limited braking efficiency on sal-
ted roads ....................................... 195
New brake disks ............................ 195
New brake pads/linings ................ 195
Overrun mode ................................ 191
Running-in tips ............................... 171
Short journeys ............................... 193
Snow chains .................................. 368
Speed limitation ............................. 193
Towing a trailer .............................. 239
Wet road surface ........................... 195
DSR (Downhill Speed Regulation)
Display message ............................ 275
Function/notes ............................. 209
DVD video
Operating (on-board computer) ..... 253
DYNAMIC SELECT switch
Automatic transmission ................. 181
E
E/e mark ............................................ 385
EASY PACK tailgate
Changing bulbs (signal and ambi-
ent light) ........................................ 133
EASY-PACK tailgate
Display messages .......................... 282
Important safety notes .................... 86
Obstacle detection with reversing
feature ............................................. 86
Opening dimensions ...................... 395
Opening/closing .............................. 87
Problems with the tailgate ............... 88
Programming the key button ........... 87
Resetting ......................................... 88
Setting the opening angle of the
tailgate ............................................. 88
EBD (electronic brake force distribution)
Display message ............................ 265
Function/notes ................................ 70
ECO display
Function/notes ............................. 191
ECO start/stop function
Automatic engine start .................. 176
Automatic engine switch-off .......... 175
Deactivating/activating ................. 177
General information ....................... 175
Important safety notes .................. 175
Electric sliding door
Function ........................................... 83
important safety notes ..................... 82
Obstacle detection ........................... 83
Opening/closing from the out-
side .................................................. 83
Problem (malfunction) ..................... 85
Programming the key button ........... 85
Resetting ......................................... 85
Reversing feature ............................. 83
Electric tailgate
see EASY-PACK tailgate
Electrical fuses
see Fuses
Index
11
Electrical sliding door
Opening/closing from the inside ..... 84
Electromagnetic compatibility
Declaration of conformity ................ 30
Electronic brake force distribution
see EBD (electronic brake force
distribution)
Electronic Stability Program
see ESP® (Electronic Stability Program)
Emergency
Automatic measures after an acci-
dent ................................................. 59
Emergency braking
see BAS (Brake Assist System)
Emergency key element
Function/notes ................................ 77
Inserting .......................................... 77
Locking vehicle ................................ 77
Removing ......................................... 77
Emergency unlocking
Vehicle ............................................. 77
Engine
Altitude limit (diesel engine) .......... 197
Changing the power output ............. 31
Cleaning instructions ..................... 351
Display message ............................ 271
ECO start/stop function ................ 175
Engine number ............................... 386
Jump-starting ................................. 358
Operating safety .............................. 31
Running irregularly ......................... 177
Starting .......................................... 173
Starting problems .......................... 177
Stopping ........................................ 190
Technical data ............................... 394
Tow-starting (vehicle) ..................... 363
Warning lamp (engine diagnos-
tics) ............................................... 289
Engine electronics
Notes ............................................. 385
Problem (fault) ............................... 177
Engine jump starting
see Jump starting (engine)
Engine oil
Additives ........................................ 391
Checking the oil level (on-board
computer) ...................................... 338
Checking the oil level using the
dipstick .......................................... 339
Display message ............................ 274
Filling capacity ............................... 391
Information about oil consump-
tion ................................................ 392
Notes about oil grades ................... 390
Oil change ...................................... 392
Oil level (note) ............................... 338
Topping up ..................................... 340
Viscosity ........................................ 391
Environmental protection
Returning an end-of-life vehicle ....... 29
ESC (Electronic Stability Control)
see ESP® (Electronic Stability Program)
ESP® (Electronic Stability Program)
Activating/deactivating ................... 71
Activating/deactivating (on-
board computer) ............................ 256
Crosswind Assist ............................. 72
Display message ............................ 265
Function/notes ................................ 70
Important safety guidelines ............. 70
Trailer stabilisation .......................... 71
Warning lamp ................................. 287
Exhaust filter
see Diesel particle filter
Exhaust tail pipe (cleaning instruc-
tions) .................................................. 352
Exterior lighting
see Lights
Exterior mirrors
Adjusting ....................................... 122
Anti-dazzle mode (automatic) ........ 123
Folding in/out (automatically) ....... 123
Folding in/out (electrically) ........... 123
Out of position (troubleshooting) ... 123
Resetting ....................................... 123
Storing settings (memory func-
tion) ............................................... 124
F
Fault message
see Display messages
Favourites
Adding ........................................... 300
12
Index
Deleting ......................................... 300
Displaying and calling up ............... 300
Overview ........................................ 300
Fire extinguisher ............................... 358
First-aid kit ......................................... 358
Fitting a wheel
Fitting a wheel ............................... 379
Lowering the vehicle ...................... 379
Preparing the vehicle ..................... 377
Raising the vehicle ......................... 378
Removing a wheel .......................... 378
Removing and fitting the spare
wheel ............................................. 383
Securing the vehicle against roll-
ing away ........................................ 377
Flat tyre
Changing a wheel/fitting the
spare wheel ................................... 377
Foglamps (extended range) .............. 129
Folding table
In the rear compartment ................ 314
Frequencies
Mobile phone ................................. 385
Two-way radio ................................ 385
Front-passenger front airbag deactivation system
Operation ......................................... 53
Problems ......................................... 56
System self-test ............................... 55
Fuel
Additives (diesel) ........................... 389
Consumption information .............. 389
Consumption statistics .................. 249
Diesel at very low outside temper-
atures ............................................ 388
Diesel particle filter ....................... 193
Displaying the current consump-
tion ................................................ 249
Displaying the range ...................... 249
Driving abroad ............................... 194
Flow improver ................................ 389
Fuel gauge ....................................... 36
Important safety notes .................. 387
Problem (malfunction) ................... 186
Quality (diesel) ............................... 388
Refuelling ....................................... 184
Tank content/reserve fuel ............. 387
Fuel filter (white display message) .. 272
Fuel level
Calling up the range (on-board
computer) ...................................... 249
Gauge .............................................. 36
Fuel tank
Problem (malfunction) ................... 186
Function overview
Multimedia system ........................ 294
Fuses .................................................. 364
G
Genuine Mercedes-Benz parts ........... 33
Glove compartment .......................... 312
Guide rail
Maximum tensile strength ............. 395
Guide rails
Fitting lashing eyelets .................... 331
H
Handbrake
see Parking brake
Handle for seat sliders ..................... 115
Handling control system
see ESP® (Electronic Stability Program)
Handwriting recognition
Switching text reader function
on/off ............................................ 298
Touchpad ....................................... 298
Hazard warning lamps ...................... 128
Head restraints
Adjusting (electrically) ................... 119
Adjusting (manually) ...................... 118
Important safety notes .................. 118
Removing/fitting ........................... 118
Headlamps
Changing bulbs (halogen head-
lamps) ............................................ 134
Changing bulbs (LED headlamps) .. 134
Misting up ...................................... 131
see Automatic headlamp mode
Heater booster function
see Auxiliary warm-air heater
see Hot-water auxiliary heater
Heating
see Climate control
High-pressure cleaners .................... 351
Index
13
Hill start assist .................................. 175
Hinged window
Child-proof lock ............................... 68
Hinged windows
Opening/closing .............................. 90
HOLD function
Activating ....................................... 221
Activation conditions ..................... 221
Deactivating ................................... 221
Display message ............................ 279
Function/notes ............................. 221
General notes ................................ 221
Hot-water auxiliary heater
Display message ............................ 282
Function/notes ............................. 157
Heater booster function ................. 157
Important safety notes .................. 157
Problem (malfunction) ................... 161
Remote control .............................. 159
Setting a departure time (remote
control) .......................................... 160
Switching on/off ........................... 158
Switching on/off (control panel in
the centre console) ........................ 158
Switching on/off (remote con-
trol) ................................................ 159
I
Immobiliser .......................................... 72
Implied warranty ................................. 28
Indicator and warning lamps
COLLISION PREVENTION ASSIST .. 291
Coolant .......................................... 289
Engine diagnostics ......................... 289
Indicator lamps
Display message ............................ 269
see Warning and indicator lamps
Indicators
see Turn signals
Insect protection on the radiator ...... 33
Inspection
see ASSYST
Instrument cluster
Overview .......................................... 36
Warning and indicator lamps ........... 37
Instrument cluster lighting .............. 245
Intelligent Light System
Activating/deactivating ................. 258
Display message ............................ 270
Overview ........................................ 128
Setting the dipped-beam headlamps for driving on the right/left .. 258
Interior lighting
Ambient lighting ............................. 132
Automatic control system .............. 131
Changing bulbs .............................. 132
General notes ................................ 131
Manual control ............................... 132
Notes on changing bulbs ............... 132
Overview ........................................ 131
Reading lamp ................................. 131
Rear interior light in the grab han-
dle ................................................. 132
Repacing bulbs .............................. 132
Switching the rear compartment
lighting on centrally ....................... 132
Interior motion sensor
Deactivating ..................................... 74
Function ........................................... 73
Priming ............................................ 73
Switching off .................................... 73
Interrupting a traffic announce-
ment ................................................... 311
iPad® attachment .............................. 327
ISOFIX child seat securing system .... 61
J
Jack
Declaration of conformity ................ 30
Jacking points ................................ 378
Storage location ............................ 357
Using ............................................. 378
Jump starting (engine) ...................... 358
K
Key
Changing the battery ....................... 78
Checking the battery ....................... 78
Convenience closing feature ............ 91
Convenience opening feature .......... 91
Display message ............................ 283
Door central locking/unlocking ....... 76
14
Index
Emergency key element ................... 77
Important safety notes .................... 75
Loss ................................................. 79
Modifying the programming ............. 76
Position in the ignition lock ............ 172
Problem (malfunction) ..................... 79
Key positions (ignition lock) ............ 172
Kickdown ........................................... 182
L
Lamps
see Warning and indicator lamps
Lane detection (automatic)
see Lane Keeping Assist
Lane Keeping Assist
Activating/deactivating ................. 216
Display message ............................ 277
Function/information .................... 215
Setting sensitivity (on-board com-
puter) ............................................. 258
Setting the sensitivity .................... 216
Lashing eyelets
Fitting ............................................ 331
Lashing points and lashing materials
Permissible tensile load ................. 395
LED light sources
Replacing ....................................... 134
Licence plate lamp
Display message ............................ 270
Licence plate lighting
Changing bulbs .............................. 134
Light sensor (display message) ....... 269
Lighting
see Lights
Lights
Activating/deactivating the Intel-
ligent Light System ........................ 258
Active light function ....................... 129
Adaptive Highbeam Assist ............. 130
Automatic headlamp mode ............ 126
Changing bulbs (halogen head-
lamps) ............................................ 134
Changing bulbs (interior lights) ...... 132
Cornering light function ................. 129
Dipped-beam headlamps ............... 126
Display message ............................ 268
Driving abroad ............................... 194
Foglamps (extended range) ........... 129
Hazard warning lamps ................... 128
Headlamp flasher ........................... 128
Headlamp range ............................ 128
Important safety notes .................. 126
Intelligent Light System (func-
tion) ............................................... 128
Light switch ................................... 126
Main-beam headlamps ................... 128
Motorway mode ............................. 129
Parking lamps ................................ 126
Rear foglamp ................................. 127
Replacing bulbs (halogen head-
lamps) ............................................ 134
Replacing bulbs (LED headlamps) .. 134
Side lamps ..................................... 126
Switching the daytime driving
lights on/off (switch) ..................... 126
Turn signals ................................... 127
LIM indicator lamp
Cruise control ................................ 198
DISTRONIC PLUS ........................... 203
Variable SPEEDTRONIC ................. 200
Limiting the speed
see SPEEDTRONIC
Load compartment
Options .......................................... 330
Seating .......................................... 100
Load distribution ............................... 329
Load protection net ........................... 331
Load securing aids
Load protection net ....................... 331
Load-securing aids
Load compartment partition .......... 333
Loading guidelines ............................ 328
Loads
Securing ........................................ 330
Transporting .................................. 328
Locking
see Central locking
Locking (doors)
Emergency locking ........................... 77
Locking centrally
see Central locking
Lubricant additives
see Additives
Index
15
Luggage compartment partition
Folding up/down ........................... 333
Important safety notes .................. 333
Removing/fitting ........................... 334
Storage compartments .................. 333
Lumbar support ................................... 98
M
M+S tyres ........................................... 367
Main-beam headlamps
Adaptive Highbeam Assist ............. 130
Display message ............................ 270
Replacing bulbs ............................. 136
Switching on/off ........................... 128
Maintenance ...................................... 343
Maintenance points under the bon-
net ...................................................... 338
Making a call
Using the call lists ......................... 307
Using the phone book .................... 307
Using the telephone menu ............. 307
Manual transmission
Engaging reverse gear ................... 174
Gear lever ...................................... 173
Pulling away ................................... 173
Shift recommendation ................... 174
Starting the engine ........................ 173
Maximum speed
Speed limitation ............................. 193
MB Contact
Breakdown assistance call but-
ton ................................................. 325
Info call button .............................. 325
Media Interface
Connections .................................. 313
Memory card (audio) ......................... 253
Memory function
Seats, steering wheel, exterior
mirrors ........................................... 124
Mercedes me connect
Accident management ................... 308
Audio 20 ........................................ 308
Breakdown assistance call but-
ton ................................................. 325
Breakdown management ............... 309
Calling the Mercedes-Benz Cus-
tomer Centre ................................. 308
COMAND Online ............................ 308
General notes ................................ 308
Info call button .............................. 325
Requirements ................................ 308
Mercedes-Benz Contact
Calling the Mercedes-Benz Cus-
tomer Centre ................................. 308
Mercedes-Benz emergency call
system
Switch in the overhead control
panel .............................................. 324
Mercedes-Benz Service Centre
see Qualified specialist workshop
Mercedes-Benz Service24h .............. 358
Message memory (on-board com-
puter) .................................................. 260
Messages
see Display messages
see Warning and indicator lamps
Mirrors
Exterior mirrors .............................. 122
Important safety notes .................. 122
Rear-view mirror ............................ 122
see Vanity mirror
Misted-up windows
see Climate control
Mobile phone
Authorising .................................... 305
Connecting (Bluetooth® inter-
face) .............................................. 303
Connecting another mobile
phone ............................................ 306
De-authorising ............................... 306
Menu (on-board computer) ............ 254
Notes/placing in the bracket ......... 325
Type approval/frequency .............. 385
Model
see Vehicle identification plate
Modifying the programming (key) ..... 76
Motor oil additives
see Additives
Motorway mode ................................ 129
MP3
Operating ....................................... 253
Multimedia system
Display ........................................... 294
Important safety notes .................. 293
16
Index
Overview ........................................ 294
N
Navigation
Important safety notes .................. 301
Menu (on-board computer) ............ 250
Overview ........................................ 301
Showing/hiding the menu ............. 301
Notes on running in a new vehicle .. 171
O
Occupant safety
Airbags ............................................ 49
Automatic front-passenger front
airbag deactivation .......................... 52
Automatic measures after an acci-
dent ................................................. 59
Belt warning ..................................... 49
Children in the vehicle ..................... 59
Important safety notes .................... 45
PASSENGER AIRBAG indicator
lamp ................................................. 46
Pets in the vehicle ........................... 68
PRE-SAFE® (anticipatory occu-
pant protection) ............................... 58
Restraint system introduction .......... 45
Restraint system warning lamp ........ 45
Seat belts ........................................ 46
Odometer
Displaying ...................................... 248
Oil
see Engine oil
On-board computer
Assistance graphic menu ............... 255
Assistance menu ........................... 256
Checking the oil level ..................... 338
Display messages .......................... 260
Displaying a service message ........ 344
DISTRONIC PLUS ........................... 207
Factory settings ............................. 260
Important safety notes .................. 245
Instrument cluster menu ............... 259
Light menu ..................................... 258
Media menu ................................... 252
Menu overview .............................. 248
Message memory .......................... 260
Navigation menu ............................ 250
Operating video DVD ..................... 253
Operation ....................................... 246
Radio menu ................................... 252
Service menu ................................. 256
Settings menu ............................... 256
Standard display ............................ 248
Telephone menu ............................ 254
Trip menu ...................................... 248
Vehicle menu ................................. 259
Online and Internet functions
Calling up ....................................... 309
Connection status ......................... 309
Ending the connection ................... 309
Establishing/ending a connec-
tion ................................................ 309
Operating Instructions
Before the first journey .................... 28
Digital and printed operating
instructions ...................................... 28
General notes .................................. 28
Implied warranty .............................. 28
Vehicle equipment ........................... 28
Operating safety
Implied warranty .............................. 28
Operating safety and registration
Attachments/add-on equipment ..... 32
Changes in engine performance ...... 31
Installations and conversions ........... 32
Notes on body/equipment
mounting directives ......................... 32
Operating safety and vehicle
approval
BlueTEC exhaust gas aftertreat-
ment ................................................ 32
Correct use ...................................... 28
Declaration of conformity ................ 30
Notes on operating the vehicle ........ 30
Qualified specialist workshops ........ 31
Registering your vehicle ................... 31
Operating system
see On-board computer
Operation
Digital Owner's Manual .................... 27
Outside temperature display ........... 246
Overhead control panel ...................... 43
Overrevving range ............................. 246
Overrun mode .................................... 191
Index
17
P
Paint code .......................................... 386
Paintwork (cleaning instructions) ... 351
Panorama sliding sunroof
Important safety information ........... 91
Opening/closing the roller sun-
blind ................................................. 94
Operating ......................................... 92
Operating the roller sunblinds for
the sliding sunroof ........................... 93
Problem (malfunction) ..................... 94
Rain closing feature ......................... 93
Reversing feature ............................. 92
Parking
360° camera ................................. 234
Important safety notes .................. 189
Parking brake ................................ 189
Reversing camera .......................... 229
see Active Parking Assist
see PARKTRONIC
Parking aid
Active Parking Assist ..................... 225
see 360° camera
see PARKTRONIC
see Reversing camera
Parking brake
Applying automatically ................... 190
Applying or releasing manually ...... 190
Display message ............................ 266
Electric parking brake .................... 189
Emergency braking ........................ 190
Releasing automatically ................. 190
Warning lamp ................................. 288
Parking lamps
Display message ............................ 270
Replacing bulbs (front) ................... 136
Replacing bulbs (rear) .................... 137
Switching on/off ........................... 126
PARKTRONIC
Deactivating/activating ................. 224
Display message ............................ 276
Driving system ............................... 222
Function/notes ............................. 222
Important safety notes .................. 222
Problem (fault) ............................... 224
Roll-back warning .......................... 224
Sensor range ................................. 222
Trailer towing ................................. 224
Warning display ............................. 223
PASSENGER AIR BAG OFF
Indicator lamp .................................. 46
Passenger compartment air-conditioning system
see Climate control
Passenger compartment heating
see Climate control
Pets in the vehicle ............................... 68
Phone call
Dialling ........................................... 307
Plastic trim (cleaning instruc-
tions) .................................................. 355
Power windows
see Side windows
PRE-SAFE® (anticipatory occupant
protection)
Operation ......................................... 58
PRE-SAFE® (preventive occupant
safety system)
Display message ............................ 267
Preparing for a journey
Checks in the vehicle ..................... 172
Visual check of the vehicle exte-
rior ................................................. 172
Preventative passenger protection
see PRE-SAFE® (anticipatory
occupant protection)
Protection of the environment
General notes .................................. 29
Pulling away
Automatic transmission ................. 174
Hill start assist ............................... 175
Manual transmission ...................... 173
Q
QR code
Rescue card ..................................... 33
Qualified specialist workshop ........... 31
R
Radiator cover ..................................... 33
Radio
Displaying radio text ...................... 311
Important safety notes .................. 293
18
Index
Menu overview .............................. 310
Overview ........................................ 310
Selecting a station ......................... 252
Switching on .................................. 310
see separate operating instructions
Radio text ........................................... 311
Radio-based vehicle components
Declaration of conformity ................ 30
Radio/navigation
Important safety notes .................. 293
Rain closing feature
Panorama sliding sunroof ................ 93
Rain sensor
Setting the sensitivity .................... 138
Reading lamp ..................................... 131
Rear bench seat
Adjusting the backrest ................... 103
Basic position ................................ 103
Bed extension (seat/berth combi-
nation) ........................................... 117
EASY-ENTRY/EXIT feature ............. 102
Face-to-face position ..................... 106
Fitting options ................................ 100
Folding up/down ........................... 105
General notes .................................. 99
General notes (seat/berth combi-
nation) ........................................... 112
Moving (seat/bunk combination) .. 113
Removing/fitting ........................... 106
Removing/fitting (seat/berth
combination) .................................. 115
Retainer loops (seat/berth com-
bination) ........................................ 112
Seat anchorage ................................ 99
Seat rails .......................................... 99
Seating variants ............................. 100
Setting up/folding away the berth
(seat/berth combination) .............. 117
Sliding ............................................ 103
Stowage compartments (seat/
bunk combination) ......................... 313
Rear compartment
Activating/deactivating the air
conditioning ................................... 146
Seating variants ............................. 100
Setting the air vents ...................... 169
Setting the temperature ................ 152
Switching interior lighting on/off ... 132
Rear foglamp
Display message ............................ 270
Switching on/off ........................... 127
Rear foglamps
Replacing bulbs ............................. 137
Rear lamps
Replacing bulbs ............................. 137
Rear seat
Adjusting the backrest ................... 108
EASY-ENTRY/EXIT feature ............. 107
Rear seat heating ........................... 120
Rear seat ventilation ...................... 120
Seat anchorage ................................ 99
Seat rails .......................................... 99
Rear seats
Face-to-face position ..................... 111
Folding down/up ........................... 109
General notes .................................. 99
Removing/fitting ........................... 111
Sliding ............................................ 108
Turning .......................................... 108
Rear view camera
Important safety notes .................. 229
Rear window (which can be opened
separately)
Important safety notes .................... 88
Opening/closing .............................. 88
Problem (malfunction) ..................... 89
Programming the key button ........... 89
Rear window heating
Problem (fault) ............................... 155
Switching on/off ........................... 155
Rear window wiper
Replacing the wiper blade .............. 141
Switching on/off ........................... 139
Rear-compartment air-conditioning system
see Climate control
Rear-compartment heating
see Climate control
Rear-view mirror
Anti-dazzle mode (automatic) ........ 123
Dipping (manual) ........................... 122
Recuperation display ........................ 249
Recycling
see Protection of the environment
Reducing agent
see AdBlue
®
Index
19
Refuelling
AdBlue® ......................................... 186
Fuel filler flap ................................. 185
Fuel gauge ....................................... 36
Refuelling process ......................... 185
see Fuel
Regeneration
see Diesel particle filter
Remote control
Auxiliary warm-air heater ............... 163
Changing battery (auxiliary warm-
air heater) ...................................... 166
Hot-water auxiliary heater ............. 159
Replacing the battery (hot-water
auxiliary heater) ............................. 160
see Key
Replacing bulbs
Brake lamps ................................... 137
Daytime driving lights .................... 136
important safety notes ................... 134
Interior lighting .............................. 132
Main-beam headlamps ................... 136
Rear foglamps ................................ 137
Rear lamps ..................................... 137
Reversing lamp .............................. 137
Rescue card ......................................... 33
Reserve (fuel tank)
see Fuel
Reserve fuel
Display message ............................ 274
Warning lamp ................................. 289
Residual heat (climate control) ........ 156
Restraint system
Display message ............................ 268
Introduction ..................................... 45
Warning lamp ................................. 288
Warning lamp (function) ................... 45
Rev counter ........................................ 246
Reversing camera
Cleaning instructions ..................... 353
Coupling up a trailer function ........ 233
Function/notes ............................. 229
General notes ................................ 229
Messages in the display ................. 231
Reverse parking ............................. 232
Switching on/off ........................... 230
Wide-angle function ....................... 234
Reversing feature
Electric sliding door ......................... 83
Panorama sliding sunroof ................ 92
Roller sunblinds ............................... 93
Side windows ................................... 89
Reversing lamp
Replacing bulbs ............................. 137
Reversing lamps
Display message ............................ 270
Roller sunblind
Panorama sliding sunroof ................ 93
Roof carrier
Maximum payload .......................... 395
Notes ............................................. 334
Roof lining and carpets (cleaning
instructions) ...................................... 356
Roof load (roof carrier) ..................... 395
S
Safety
Children in the vehicle ..................... 59
Operating safety .............................. 30
see Occupant safety
Safety system
see Driving safety systems
Seat
Swivel seat ....................................... 98
Seat belt
Correct usage .................................. 48
Seat belts
Adjusting the driver's and front-
passenger seat belt ......................... 49
Adjusting the height ......................... 48
Cleaning ......................................... 356
Fastening ......................................... 48
Important safety guidelines ............. 47
Introduction ..................................... 46
Releasing ......................................... 49
Warning lamp ................................. 284
Warning lamp (function) ................... 49
Seat/berth combination
Rear bench seat ............................. 112
Seats
Adjusting (electrically) ..................... 98
Adjusting (manually) ........................ 97
Adjusting lumbar support ................ 98
Adjusting the head restraint .......... 118
20
Index
Armrest .......................................... 119
Cleaning the cover ......................... 356
Correct driver's seat position ........... 96
Important safety notes .................... 96
Seat heating .................................. 119
Seat ventilation .............................. 120
Storing settings (memory func-
tion) ............................................... 124
Securing loads
Fitting lashing eyelets .................... 331
Selecting stations
Radio ............................................. 310
Selector lever
see Automatic transmission
Sensors (cleaning instructions) ....... 353
Service interval display
ASSYST (active Service System) .... 344
Calling up the service due date ...... 344
Hiding a service message .............. 344
Notes ............................................. 344
Service menu (on-board com-
puter) .................................................. 256
Service phone number ...................... 358
Service products
AdBlue® special additives .............. 389
Bio-diesel ....................................... 388
Brake fluid ..................................... 392
Coolant (engine) ............................ 392
Engine oil ....................................... 390
Fuel ................................................ 387
Important safety notes .................. 386
Washer fluid ................................... 393
Setting the air distribution ............... 152
Setting the airflow ............................ 153
Settings
Factory (on-board computer) ......... 260
On-board computer ....................... 256
Shift recommendation ...................... 248
Short journeys (diesel particle fil-
ter) ...................................................... 193
Side lamps
Replacing bulbs ............................. 136
Side window
Child-proof lock ............................... 68
Side windows
Convenience closing ........................ 91
Convenience opening ...................... 91
Hinged side windows ....................... 89
Important safety notes .................... 89
Opening/closing .............................. 90
Opening/closing the hinged win-
dow .................................................. 90
Overview .......................................... 89
Problem (malfunction) ..................... 91
Resetting ......................................... 91
Sidebag ................................................ 51
Signal and ambient light
Changing a bulb ............................. 133
Sliding door
Child-proof lock ............................... 68
Cleaning ......................................... 354
Important safety notes .................... 82
Opening/closing from outside ......... 82
Opening/closing from the inside ..... 82
see Electrical sliding door
Sliding sunroof
see Panorama sliding sunroof
Snow chains ...................................... 368
Socket (230 V) ................................... 322
Sockets
Centre console .............................. 321
General notes ................................ 321
Rear compartment ......................... 322
Spare wheel
General notes ................................ 383
Important safety notes .................. 382
Removing/fitting ........................... 383
Specialist workshop ............................ 31
Spectacles compartment ................. 312
Speed, controlling
see Cruise control
Speedometer
Activating/deactivating the addi-
tional speedometer ........................ 259
Digital ............................................ 249
General notes ................................ 245
In the Instrument cluster ................. 36
Segments ...................................... 245
Selecting the unit of measure-
ment .............................................. 259
SPEEDTRONIC
Activating variable ......................... 201
Calling up the last speed stored .... 201
Deactivating variable ..................... 201
Index
21
Display message ............................ 277
Displaying the speed ..................... 200
Function/notes ............................. 199
Important safety notes .................. 200
LIM indicator lamp ......................... 200
Permanent ..................................... 201
Problem (malfunction) ................... 202
Selecting ........................................ 200
Setting the speed .......................... 201
Storing the current speed .............. 201
Switching variable SPEEDTRONIC
to passive ...................................... 201
Start/stop function
see ECO start/stop function
Starting
see Starting (engine)
Starting (engine) ................................ 173
Steering
Display message ............................ 283
Warning lamps ............................... 292
Steering wheel
Adjusting ....................................... 121
Button overview ............................... 38
Buttons (on-board computer) ......... 246
Cleaning ......................................... 356
Gearshift paddles ........................... 182
Steering wheel gearshift paddles .... 182
Stickers
General safety notes ........................ 28
Stowage compartments
Armrest (under) ............................. 313
see Stowage spaces and compartments
Stowage net ....................................... 313
Stowage spaces and compartments
Glove compartment ....................... 312
Important safety notes .................. 312
Spectacles compartment ............... 312
Stowage compartment in the
centre console ............................... 313
Stowage spaces and stowage compartments
Folding table .................................. 317
Luggage net ................................... 313
Seat/bunk combination stowage
compartments ............................... 313
Summer opening
see Convenience opening feature
Summer tyres .................................... 367
Sun visor
Changing a bulb (mirror lamp) ....... 133
Overview ........................................ 314
Switching off the alarm (ATA) ............ 72
Switching traffic announcements
on/off
Radio ............................................. 310
Swivel seat ........................................... 98
T
Tail lamp
Trailer display message ................. 269
Tail lamps
Display message ............................ 270
Tailgate
Changing bulbs (signal and ambi-
ent light) ........................................ 133
Display message ............................ 282
Important safety notes .................... 85
Opening dimensions ...................... 395
Opening/closing from the out-
side .................................................. 86
Problem (malfunction) ..................... 86
see EASY-PACK tailgate
Technical data
Capacities ...................................... 386
Engine ............................................ 394
Guide rail ....................................... 395
Lashing points ............................... 395
Roof carrier .................................... 395
Trailer tow hitch ............................. 396
Tyres/wheels ................................. 380
Vehicle data ................................... 394
Vehicle dimensions ........................ 395
Telephone
Accepting a call ............................. 254
Accepting a call (multimedia sys-
tem) ............................................... 307
Authorising a mobile phone (con-
necting) ......................................... 305
Automatically reconnecting
mobile phone ................................. 306
Connecting a Mobile phone (gen-
eral information) ............................ 303
De-authorising (disconnecting) a
mobile phone ................................. 306
22
Index
Display message ............................ 283
Ending an active call ...................... 308
Entering a number ......................... 307
Entering phone numbers ................ 307
Establishing the connection from
the mobile phone ........................... 305
Important safety notes .................. 325
Introduction ................................... 254
Making a call ................................. 307
Menu (on-board computer) ............ 254
Number from the phone book ........ 254
Redialling ....................................... 255
Rejecting a call (multimedia sys-
tem) ............................................... 307
Rejecting/ending a call ................. 254
Switching between mobile
phones ........................................... 306
Using the telephone ....................... 307
Telephone number
Entering ......................................... 307
Temperature
Coolant (display in the instrument
cluster) .......................................... 246
Outside temperature ...................... 246
Setting (auxiliary warm-air
heater) ........................................... 166
Setting (climate control) ................ 152
TEMPOMAT
Function/notes ............................. 197
Theft-deterrent system
ATA (Anti-Theft Alarm system) ......... 72
Immobiliser ...................................... 72
Time
Setting (auxiliary warm-air
heater) ........................................... 165
Setting the time (auxiliary warm-
air heater) ...................................... 165
Timer (auxiliary warm-air heater)
Activating ....................................... 165
Overview ........................................ 164
Setting departure time ................... 165
Setting the heating level ................ 166
Setting the operating duration ....... 165
Setting the temperature ................ 166
Setting the time ............................. 165
Tiredness assistant
see ATTENTION ASSIST
Tool
see Vehicle tool kit
Top Tether ............................................ 61
Total distance recorder
Displaying ...................................... 248
Setting the display unit .................. 259
Touchpad
Calling up quick access for audio .. 297
Changing the station/music
track .............................................. 299
Character suggestions ................... 299
Deleting characters ....................... 299
Entering a space ............................ 299
Entering characters ....................... 298
Gesture control .............................. 296
Handwriting recognition ................ 298
Operating the touchpad ................. 296
Overview ........................................ 296
Quick access for audio .................. 299
Switching ....................................... 296
Switching input line ....................... 299
Tow-away protection
Activating ......................................... 73
Deactivating ..................................... 73
Function ........................................... 73
Tow-starting
Emergency engine starting ............ 363
Important safety notes .................. 360
Towing
Fitting/removing the towing eye ... 362
If the vehicle is stuck ..................... 363
Important safety notes .................. 360
With the rear axle raised ................ 362
Towing a trailer
Active Parking Assist ..................... 225
Axle load, permissible .................... 396
Mounting dimensions .................... 396
Towing away
With both axles on the ground ....... 362
Towing eye ......................................... 357
Traffic Sign Assist
Activating ....................................... 218
Activating/deactivating the warn-
ing function .................................... 257
Display message ............................ 279
Function/notes ............................. 217
Important safety notes .................. 218
Instrument cluster display ............. 218
Index
23
Trailer coupling
see Towing a trailer
Trailer towing
7-pin connector ............................. 244
Blind Spot Assist ............................ 215
Bulb failure indicator for LED
lights .............................................. 244
Cleaning the trailer tow hitch ......... 354
Coupling up a trailer ...................... 243
Decoupling a trailer ....................... 243
Driving tips .................................... 239
ESP® ................................................ 71
Fitting the ball coupling ................. 241
Lights display message .................. 269
Parktronic ...................................... 224
Power supply ................................. 243
Removing the ball coupling ............ 242
Trailer loads ................................... 396
Transmission
see Automatic transmission
see Manual transmission
Transmission positions
Automatic transmission ................. 179
Display (DIRECT SELECT lever) ...... 180
Transport
Fitting lashing eyelets .................... 331
Loading guidelines ......................... 328
Vehicle ........................................... 363
Transport by rail ................................ 194
Transportation
Rail ................................................ 194
Transporting
Load compartment variations ........ 330
Load distribution ............................ 329
Securing a load .............................. 330
Trim pieces (cleaning instruc-
tions) .................................................. 356
Trip computer
Displaying ...................................... 249
Selecting the display unit ............... 259
Trip meter
Calling up ....................................... 248
Resetting (on-board computer) ...... 250
Setting the display unit .................. 259
Turn signal lamp
Trailer display message ................. 269
Turn signals
Replacing bulbs (front) ................... 136
Replacing bulbs (rear) .................... 137
Switching on/off ........................... 127
Two-way radios
Type approval/frequency .............. 385
Type identification plate
see Vehicle identification plate
Tyre pressure
Calling up (on-board computer) ..... 370
Display message ............................ 280
Important safety notes .................. 370
Recommended ............................... 369
Tables ............................................ 373
Tyre pressure monitor
Checking the tyre pressure elec-
tronically ........................................ 371
Function/notes ............................. 370
General notes ................................ 370
Important safety notes .................. 371
Radio type approval for the tyre
pressure monitor ........................... 372
Restarting ...................................... 372
Warning lamp ................................. 292
Warning message .......................... 372
Tyre pressure table ........................... 373
Tyres
Changing a wheel .......................... 376
Checking ........................................ 366
Direction of rotation ...................... 377
Display message ............................ 280
Important safety notes .................. 365
Information on driving .................... 366
M+S tyres ...................................... 367
Replacing ....................................... 376
Service life ..................................... 367
Snow chains .................................. 368
Storing ........................................... 377
Summer tyres ................................ 367
Tyre tread ...................................... 367
Wheel and tyre combinations ........ 381
Wheel/tyre combinations .............. 380
U
Unlocking
Emergency unlocking ....................... 77
From inside the vehicle (central
unlocking button) ............................. 79
With emergency key element ........... 77
24
Index
Upshift indicator ............................... 248
V
Vanity mirror
Changing a bulb (mirror lamp) ....... 133
Sun visor ........................................ 314
Variable SPEEDTRONIC
see SPEEDTRONIC
Vehicle
Data acquisition ............................... 34
Display message ............................ 281
Electronics ..................................... 385
Emergency unlocking ....................... 77
Equipment ....................................... 28
Implied warranty .............................. 28
Individual settings .......................... 256
Leaving parked up ......................... 191
Locking (in an emergency) ............... 77
Locking (key) ................................... 76
Lowering ........................................ 379
Operating safety .............................. 30
Pulling away ................................... 173
Raising ........................................... 378
Registration ..................................... 31
Securing from rolling away ............ 189
Towing away .................................. 360
Transporting .................................. 363
Unlocking (in an emergency) ........... 77
Unlocking (key) ................................ 76
Vehicle battery
see Battery (vehicle)
Vehicle bodies ..................................... 32
Vehicle check
see Preparing for a journey
Vehicle data ....................................... 394
Vehicle dimensions ........................... 395
Vehicle emergency locking ................ 77
Vehicle identification number
see VIN
Vehicle identification plate .............. 386
Vehicle settings ................................. 301
Vehicle tool kit .................................. 357
Ventilation
see Climate control
Video
Operating the DVD ......................... 253
VIN
Engine compartment ..................... 386
Type plate ...................................... 386
W
Warning and indicator lamps
ABS ................................................ 286
Brakes ........................................... 285
Distance warning signal ................. 291
ESP® .............................................. 287
ESP® OFF ....................................... 287
Fuel tank ........................................ 289
General notes ................................ 283
LIM (cruise control) ........................ 198
LIM (DISTRONIC PLUS) .................. 203
LIM (variable SPEEDTRONIC) ......... 200
Overview .......................................... 37
Parking brake ................................ 288
PASSENGER AIR BAG OFF ............... 46
Reserve fuel ................................... 289
Restraint system ............................ 288
Seat belt ........................................ 284
Steering ......................................... 292
Tyre pressure monitor ................... 292
Warning triangle ................................ 358
Warnings
Stickers ........................................... 28
Washer fluid
Display message ............................ 283
Filling capacity ............................... 394
Notes ............................................. 393
Topping up ..................................... 342
Wheel and tyre combinations
see Tyres
Wheel bolt tightening torque ........... 379
Wheels
Changing a wheel .......................... 376
Changing/replacing ....................... 376
Checking ........................................ 366
Cleaning ......................................... 352
Fitting a new wheel ........................ 379
Fitting a wheel ............................... 377
Important safety notes .................. 365
Removing a wheel .......................... 378
Removing and fitting the spare
wheel ............................................. 383
Snow chains .................................. 368
Index
25
Storing ........................................... 377
Tightening torque ........................... 379
Wheel size/tyre size ...................... 380
Wheel/tyre combinations .............. 380
Windowbag
Display message ............................ 268
Operation ......................................... 52
Windows
Cleaning ......................................... 352
see Side windows
Windscreen
Cleaning ......................................... 352
Demisting ...................................... 154
Windscreen washer fluid
Topping up ..................................... 342
Windscreen wipers
Problem (malfunction) ................... 142
Rear window wiper ........................ 139
Replacing the wiper blades ............ 139
Switching on/off ........................... 138
Winter diesel ..................................... 388
Winter driving
General notes ................................ 367
Winter operation
Radiator cover ................................. 33
Slippery road surfaces ................... 196
Snow chains .................................. 368
Winter tyres
Limiting the speed (on-board com-
puter) ............................................. 259
M+S tyres ...................................... 367
Setting a limit speed ...................... 193
Wiper blades
Cleaning ......................................... 352
Important safety notes .................. 139
Replacing (rear window) ................ 141
Replacing (windscreen) .................. 140
Service indicator ............................ 139
Workshop
see Qualified specialist workshop
26
Index
Introduction
You will not incur any costs when calling up the
Digital Operating Instructions. The Digital Operating Instructions work without connecting to
the Internet.
There are three ways to access the topics of the
Digital Operating Instructions:
R
Visual search
The visual search allows you to explore your
vehicle "virtually". Starting from either the
vehicle exterior view or interior view, you can
access many of the different topics covered
by the Digital Operating Instructions. To
access the vehicle interior section, select the
"Interior" view.
R
Contents
You can select individual sections in the contents.
The Digital Operating Instructions is deactivated
for safety reasons while driving.
Operation
Operating the Digital Operating
Instructions
General notes
Observe the information on operating the controller (Y page 296).
Observe the information on operating the touchpad (Y page 296).
Content pages
You can access the content pages by means of
a visual search, a keyword search or using the
contents.
X
To scroll forward and back: turn 3 the
controller.
X
To display in full screen/animation: slide
8 the controller to the left :.
X
To select note texts/save bookmarks:
slide 9 the controller to the right ;.
X
To select a link: slide 6 the controller
downwards =.
X
To exit a content page: actuate the %
symbol ?.
X
To call up the basic menu of the Digital
Operating Instructions: actuate the Þ
symbol A.
X
The selected menu opens. The Digital Operating Instructions remain open in the background.
X
To close the Digital Operating Instructions: press and hold the % button next to
the controller.
X
Confirm 7 the message about whether the
browser should be closed.
Digital Operating Instructions
27
Operating Instructions
Before the first journey
These Operating Instructions, the Maintenance
or Service Booklet and the additional equipment-specific instructions are integral parts of
the vehicle. Always keep these documents in
the vehicle. If you sell the vehicle, always pass
on all documents to the new owner.
Before you first drive off, read these documents
carefully and familiarise yourself with your vehicle.
For your own safety and a longer vehicle life,
follow the instructions and warning notices in
these Operating Instructions. Failure to observe
the instructions may lead to damage to the vehicle or personal injury.
Implied warranty
!
Follow the instructions in this manual about
the proper operation of your vehicle as well as
about possible vehicle damage. Damage to
your vehicle that arises from culpable contraventions against these instructions are not
covered either by Mercedes-Benz implied
warranty or by the New or Used-Vehicle Warranty.
Vehicle equipment
These Operating Instructions describe all models as well as standard and optional equipment
of your vehicle that was available at the time of
going to print. Country-specific variations are
possible. Note that your vehicle may not be
equipped with all of the described functions.
This also applies to safety-relevant systems and
functions. Therefore, your vehicle's equipment
may differ from certain descriptions and illustrations.
The original purchase contract documentation
for your vehicle contains a list of all of the systems in your vehicle.
Should you have any questions concerning
equipment and operation, consult any
Mercedes-Benz Service Centre.
Digital and printed Operating Instructions
The Digital Operating Instructions are not updated electronically. Amendments are only be
made by means of Supplements to the printed
Operating Instructions.
Always observe the printed Operating Instructions as well as the supplements to the Operating Instructions.
Correct use
Observe the following information when driving
your vehicle:
R
the safety notes in these Operating Instructions
R
the technical data in these Operating Instructions
R
traffic rules and regulations
R
laws and safety standards pertaining to motor
vehicles
Various warning stickers are attached to the
vehicle. If you remove any warning stickers, you
or others could fail to recognise certain dangers.
Leave warning stickers in position.
G
WARNING
Modifications to electronic components, their
software as well as wiring could affect their
function and/or the operation of other networked components. This could in particular
also be the case for systems relevant to
safety. They might not function properly anymore and/or jeopardise the operational
safety of the vehicle. There is an increased
risk of an accident and injury.
Do not attempt to modify the wiring as well as
electronic components or their software.
Always have work on electrical and electronic
components carried out at a qualified specialist workshop.
If you carry out modifications to electronic components, their software or wiring, this could
result in the invalidation of your vehicle's operating permit.
28
Correct use
Introduction
G
WARNING
Gases and liquids from substances that constitute a health hazard or react aggressively
can escape, even from securely closed containers. If you transport these substances
inside the vehicle, this may affect your health
and impair your concentration while you are
driving. It may also cause malfunctions or
electrical component system failures. There is
a risk of fire and accident.
Do not store or transport any substances in
the vehicle that are hazardous to health or
react aggressively.
Substances that constitute a health hazard or
react aggressively include, for example:
R
solvents
R
fuel
R
oil and grease
R
cleaning agents
R
acid
Protection of the environment
Economical and environmentally
aware driving
H
Environmental note
Daimler's declared policy is one of comprehensive environmental protection.
Our objectives are to use the natural resources which form the basis of our existence on
this planet sparingly and in a manner which
takes the requirements of both nature and
humanity into consideration.
You too can help to protect the environment
by operating your vehicle in an environmentally-responsible manner.
Fuel consumption and the rate of engine,
transmission, brake and tyre wear depend on
the following factors:
R
operating conditions of your vehicle
R
your personal driving style
You can influence both factors. Therefore,
please bear the following in mind:
Operating conditions:
R
avoid short trips, as these increase fuel
consumption.
R
observe the correct tyre pressure.
R
do not carry any unnecessary weight in the
vehicle.
R
remove the roof rack once you no longer
need it.
R
a regularly serviced vehicle will contribute
to environmental protection. You should
therefore adhere to the service intervals.
R
all maintenance work should be carried out
at a qualified specialist workshop.
Personal driving style:
R
do not depress the accelerator pedal when
starting the engine.
R
do not warm up the engine when the vehicle
is stationary.
R
drive carefully and maintain a safe distance
from the vehicle in front.
R
avoid frequent, sudden acceleration and
braking.
R
change gear in good time and use each gear
only up to Ô of its maximum engine speed.
R
switch off the engine in stationary traffic.
R
monitor the vehicle's fuel consumption.
Returning a used vehicle
Only for EU countries:
Mercedes-Benz will take back your end-of-life
vehicle for environment-friendly disposal in
accordance with the European Union (EU) Endof-Life Vehicles Directive.
A network of vehicle collection points and disassembly plants has been established for you to
return your vehicle. You can leave it at any of
these points free of charge. This makes an
important contribution to closing the recycling
circle and conserving resources.
For further information about recycling and disposing of end-of-life vehicles, and the take-back
conditions, please visit the national MercedesBenz website for your country.
Protection of the environment
29
Introduction
Z
Operating safety and vehicle approval
Notes on driving
There is a risk of damage to the vehicle if:
R
the vehicle becomes stuck, e.g. on a high kerb
or an unpaved road
R
you drive too fast over an obstacle, e.g. a
kerb, a speed bump or a pothole in the road
R
a heavy object strikes the underbody or parts
of the chassis
In such situations, the body/frame, the underbody, chassis parts, wheels or tyres could be
damaged without the damage being visible.
Components damaged in this way can unexpectedly fail or, in the case of an accident, no
longer withstand the strain they are designed
for. If the underbody panelling is damaged, combustible materials such as leaves, grass or twigs
can gather between the underbody and the
underbody panelling. If these materials come in
contact with hot parts of the exhaust system for
an extended period, they can catch fire.
G
WARNING
Flammable material such as leaves, grass or
twigs may ignite if they come into contact with
hot parts of the exhaust system. There is a risk
of fire.
When driving off road or on unpaved roads,
check the vehicle's underside regularly. In
particular, remove parts of plants or other
flammable materials which have become
trapped. In the case of damage, contact a
qualified specialist workshop.
Have the vehicle checked and repaired immediately at a qualified specialist workshop. If, on
continuing your journey, you notice that driving
safety is impaired, pull over and stop the vehicle
immediately, paying attention to road and traffic
conditions. In such cases, consult a qualified
specialist workshop.
Declarations of conformity
Vehicle components which receive
and/or transmit radio waves
The following note refers to all components of
the vehicle which receive and/or transmit radio
waves and the integrated information systems
and communications equipment in the vehicle:
The components of the vehicle which receive
and/or transmit radio waves are compliant with
the basic requirements and all other relevant
regulations stipulated by Directive 1999/5/EC.
You can obtain further information from any
Mercedes-Benz Service Centre.
Electromagnetic compatibility
The electromagnetic compatibility of the vehicle
components has been checked and certified
according to the currently valid version of Directive ECE-R 10.
Jack
Transcript and translation of the original declaration of conformity:
EC declaration of conformity
1. We, the undersigned, being representatives of
Manufacturer:
BRANO a.s.
74741 Hradec nad Moravicí, Opav-
ská 1000,
Czech Republic
Id. No.: 64-387-5933
VAT. Id. No.: CZ64-387-5933
hereby declare under our sole responsi-
bility that the product:
2 .a) Designation:
Jack
Type, number:
A) A 164 580 02 18, A 166 580 01 18
B) A 240 580 00 18
C) A 639 580 02 18
Year of manufacture: 2015
Fulfils all relevant conditions
Directive no. 2006/42/EC
b) Description and intended use:
The jack is intended only for raising the
specified vehicle according to the operating instructions affixed to the jack.
3. Reference to harmonised standards or
specifications
A) ISO 4063, EN ISO 14341-A, DBL
7382.20, MBN 10435, AS 2693
30
Operating safety and vehicle approval
Introduction
B) ISO 4063, ISO 14341-A, DBL 7392.10,
MBN 10435
C) DBL 7392.10, DBL 8230.10
Technical documentation for the product
is held by the manufacturer. Authorised
representative responsible for the compilation of the technical documentation:
manager of the engineering department
of Brano a.s.
4. Hradec nad Moravicí
Place
5. 5 May 2015
Date
Signed by:
Director of Quality
Diagnostics connection
The diagnostics connection is used for connecting diagnostic equipment at a qualified specialist workshop.
G
WARNING
If you connect equipment to a diagnostics
connection in the vehicle, it may affect the
operation of vehicle systems. As a result, the
operating safety of the vehicle could be affected. There is a risk of an accident.
Only connect equipment to a diagnostics connection in the vehicle, which is approved for
your vehicle by Mercedes-Benz.
Modifying the engine output
!
Increased power could:
R
change emission levels
R
cause malfunctions
R
lead to consequential damage
The operating safety of the engine cannot be
guaranteed in all situations.
Any tampering with the engine management
system in order to increase the engine power
output will lead to the loss of warranty entitlements.
If the vehicle's engine power output is
increased:
R
tyres, suspension, brake and engine cooling
systems must be adapted to the increased
engine power output
R
have the vehicle recertified
R
report changes in power output to the vehicle
insurers
This will otherwise lead to the invalidation of the
vehicle's general operating permit and its insurance cover.
If you sell the vehicle, inform the buyer of any
alterations to the vehicle's engine power output.
If you do not inform the buyer, this may constitute a punishable offence under national legislation.
Qualified specialist workshop
A qualified specialist workshop has the necessary specialist knowledge, tools and qualifications to carry out the work required on the vehicle correctly.
This is particularly applicable to work relevant to
safety. Observe the notes in the Maintenance or
Service booklet.
You should always have the following work on
your vehicle carried out at a qualified specialist
workshop:
R
safety-relevant work
R
service and maintenance work
R
repair work
R
modifications as well as installations and conversions
R
work on electronic components
Mercedes-Benz recommends that you use a
Mercedes-Benz Service Centre.
!
Only have work carried out on the engine
electronics and its associated parts, such as
control units, sensors, actuating components
and connector leads, at a qualified specialist
workshop. Vehicle components may otherwise wear more quickly and the vehicle's
operating permit may be invalidated.
Vehicle registration
Mercedes-Benz may ask its Service Centres to
carry out technical inspections on certain vehicles. This is always the case if it is possible to
Operating safety and vehicle approval
31
Introduction
Z
improve quality or safety levels. Mercedes-Benz
can only inform you about vehicle checks if it
has your registration data.
Your registration data are not available if:
R
your vehicle was not purchased at an authorised specialist dealer
R
your vehicle has not yet been inspected at a
Mercedes-Benz Service Centre
It is advisable to register your vehicle with a
Mercedes-Benz Service Centre. Inform
Mercedes-Benz as soon as possible about any
change in address or vehicle ownership.
Exhaust gas aftertreatment
The vehicle must be operated in conjunction
with the reducing agent AdBlue® if the exhaust
gas aftertreatment system in a BlueTEC® vehi-
cle is to function correctly.
If you operate the vehicle without AdBlue® or
with emissions-relevant malfunctions, the operating permit is invalidated. The legal consequence of this is that the vehicle may no longer
be operated on public roads.
Engine management monitors the exhaust gas
aftertreatment components for compliance with
emissions laws and regulations. If you attempt
to operate the vehicle without AdBlue®, with
diluted AdBlue® or with a different reducing
agent, this will be detected by the engine management system. Other emissions-relevant malfunctions, e.g. dosage malfunctions or sensor
errors, are also detected and logged.
Engine management prevents a further engine
start after it has issued warning messages.
Therefore, top up the AdBlue® tank regularly
during vehicle operation or at the latest when
the first warning message is displayed in the onboard computer (Y page 186).
When the AdBlue® supply has dropped to a
reserve level of approximately 2.4 l, the display
shows the Refill AdBlue See Owner’s Man‐
ual message.
When the AdBlue® supply is almost empty, the
display shows the Refill AdBlue Emer.
oper. in ... mi See Owner's Manual or
Emer. oper.: 20km/h No start in: ...
mi See Owner's Manual message in due
course. If you do not top up AdBlue®, you can
only travel the maximum distance that is displayed.
If the display shows the Refill AdBlue Eng.
start not possible message, the AdBlue
®
supply is empty. After parking the vehicle without topping up AdBlue® no further engine starts
are possible.
To start the engine you must first top up with at
least 4 l of AdBlue® and then switch on the ignition for approximately one minute. If, after this,
the new fluid level has been recognised by
engine management, you can then start the
engine.
If there is a malfunction with the exhaust gas
aftertreatment components, have them
checked and repaired at a qualified specialist
workshop.
Before driving your vehicle outside Europe
check the AdBlue® supply (Y page 256) and
consult a qualified specialist workshop.
You will find information on topping up AdBlue
®
in the "Refuelling" (Y page 186) section.
You will find further information on AdBlue® in
the "Service products and capacities"
(Y page 389) section.
Attachments, bodies, equipment and
conversions
Notes on body/equipment mounting
directives
!
For safety reasons, have bodies manufactured and fitted in accordance with the applicable Mercedes-Benz body/equipment
mounting directives. These body/equipment
mounting directives ensure that the chassis
and the body form one unit and that maximum
operating and road safety is achieved.
For safety reasons, Mercedes-Benz recommends that:
R
no other modifications should be made to
the vehicle.
R
approval should be obtained from
Mercedes-Benz in the event of deviations
from approved body/equipment mounting
directives.
Approval from certified inspection agencies
or official approvals cannot rule out risks to
your safety.
Observe the information on genuine MercedesBenz parts (Y page 33).
32
Operating safety and vehicle approval
Introduction
The Mercedes-Benz body/equipment mounting
directives can be found on the Internet at
https://bb-portal.mercedes-benz.com.
There you can also find information on pin
assignment and fuse replacement.
You can obtain further information from any
Mercedes-Benz Service Centre.
Notes on the engine radiator
Even seemingly small changes to the vehicle,
such as attaching a radiator trim for winter driving or as protection against insects, are not permitted. Do not cover the radiator. Do not use
thermal mats, insect protection covers or anything similar.
Doing so can cause the diagnostics system to
display inaccurate values. In some countries,
the recording of engine diagnostics data is a
legal requirement, and must always be verifiable
and accurate.
Genuine Mercedes-Benz parts
!
Airbags and seat belt tensioners, as well as
control units and sensors for these restraint
systems, may be installed in the following
areas of your vehicle:
R
doors
R
door pillars
R
door sills
R
seats
R
dashboard
R
instrument cluster
R
centre console
Do not install accessories such as audio systems in these areas. Do not carry out repairs
or welding. You could impair the operating
efficiency of the restraint systems.
Have accessories retrofitted at a qualified
specialist workshop.
H
Environmental note
Daimler AG also supplies reconditioned
assemblies and parts which are of the same
quality as new parts. For these, the same warranty applies as for new parts.
If you use parts, tyres, wheels or safety-relevant
equipment which has not been approved by
Mercedes-Benz, the operational safety of the
vehicle may be jeopardised. Safety-relevant systems, e.g. the brake system, may malfunction.
Only use genuine Mercedes-Benz parts or parts
of an equivalent quality standard. Only use
tyres, wheels and accessory parts that are
approved for your type of vehicle.
Genuine Mercedes-Benz parts and conversion
parts and accessories that have been approved
for your vehicle are tested by Mercedes-Benz
for:
R
reliability
R
safety
R
suitability
Despite ongoing market research, MercedesBenz is unable to assess other parts. MercedesBenz accepts no responsibility for the use of
such parts in Mercedes-Benz vehicles, even if
they have been independently or officially
approved.
In Germany, certain parts are only officially
approved for installation or modification if they
comply with legal requirements. This also
applies to some other countries. All genuine
Mercedes-Benz parts meet the approval
requirements. The use of non-approved parts
may invalidate the vehicle's general operating
permit.
This is the case if:
R
it results in a change to the vehicle type from
that for which the vehicle's general operating
permit was granted
R
they pose a possible risk for road users
R
they adversely affect the emission or noise
levels
Always specify the vehicle identification number
(VIN) (Y page 386) and engine number when
ordering genuine Mercedes-Benz parts
(Y page 386).
QR code for rescue card
The QR code stickers are affixed to the B-pillar
on the driver's and co-driver's side.
In the event of an accident, rescue services can
use the QR code to quickly determine the corresponding rescue card for your vehicle. The
current rescue card contains, in compact form,
the most important information about your vehicle e.g. the routing of electric cables.
QR code for rescue card
33
Introduction
Z
Further information can be found at http://
www.mercedes-benz.de/qr-code.
Data stored in the vehicle
A wide range of electronic components in your
vehicle contain data memories.
These data memories temporarily or permanently store technical information about:
R
the vehicle's operating status
R
events
R
malfunctions
In general, this technical information documents the state of a component, a module, a
system or the surroundings.
This includes, for example:
R
operating conditions of system components.
For example, fluid levels
R
the vehicle's status messages and those of its
individual components, e.g. number of wheel
revolutions/speed, deceleration in movement, lateral acceleration, accelerator pedal
position
R
malfunctions and defects in important system
components, e.g. lights, brakes.
R
ambient conditions, e.g. outside temperature
This data is exclusively technical in nature and
can be used to:
R
assist in the detection and rectification of
faults and defects
R
analyse vehicle functions, e.g. after an accident
R
optimise vehicle functions
The data cannot be used to trace the vehicle's
movements.
When you use one of the available services,
technical information may be read from the
event data memory and fault data memory.
Services include, for example:
R
repair services
R
service processes
R
warranty claims
R
quality assurance
It is read by service network employees (including the manufacturer) using special diagnostic
testers. Further information is available there if
required.
After a fault has been rectified, the information
is deleted from the fault memory or is continually overwritten.
When operating the vehicle, situations are conceivable in which this technical data, in connection with other information - if necessary, under
consultation with an authorised expert - could
be traced to a person.
Examples include:
R
accident reports
R
damage to the vehicle
R
witness statements
Further additional functions which are contractually agreed upon with the customer likewise
allow specific vehicle data to be obtained from
the vehicle. Such additional functions include
vehicle locating in an emergency, for example.
Copyright information
General notes
Information on licences for free and opensource software used in your vehicle and its
electronic components is available on the following website:
http://www.mercedes-benz.com/opensource
34
Copyright information
Introduction
Cockpit
Function Page
:
Steering wheel gearshift paddles (automatic transmission) 182
;
Combination switch 127
=
Horn
?
Instrument cluster 36
A
DIRECT SELECT selector
lever (automatic transmission) 178
B
Rear-view mirror 122
C
Multimedia system display;
see the separate operating
instructions
D
Overhead control panel 43
E
Glove compartment 312
F
Centre console control panel 39
Gear lever (manual transmis-
sion) 173
Function Page
G
Ignition lock 172
H
Adjusts the steering wheel 121
I
Diagnostics connection 31
Opens the bonnet 337
J
Parking brake 189
K
Door control panel 44
L
Light switch 126
M
• Coin/card holder
• Control panel
Ç Activates/deactivates
Lane Keeping Assist 215
à Deactivates/activates
DSR 209
Ô Activates 360° camera
234
N
Cruise control lever 198
Cockpit
35
At a glance
Instrument cluster
Displays and controls
Function Page
:
Speedometer 245
;
Display 248
=
Rev counter 246
Function Page
?
Coolant temperature gauge 246
A
Fuel level
i
Information on the outside temperature dis-
play can be found under "Outside temperature display" (Y page 246).
36
Instrument cluster
At a glance
Indicator and warning lamps
Function Page
:
å ESP® OFF
287
;
÷ ESP
®
287
=
· Distance warning signal 291
?
Ð Power steering
292
A
#! Turn signal
127
B
! Parking brake (yellow)
288
C
! ABS
286
D
; Engine diagnostics
289
E
% Preglow
173
F
! Parking brake (red)
288
G
J Brakes (red)
285
H
? Coolant
289
Function Page
I
J Brakes (yellow)
inoperative
J
6 Restraint system
45
K
ü Seat belt
284
L
K Main-beam headlamps
128
M
L Dipped-beam headlamps 126
N
æ Reserve fuel
289
O
T Side lamps, licence
plate and instrument cluster
lighting 126
P
R Rear foglamp
127
O Inoperative
Q
h Tyre pressure monitor
292
i
Corresponding messages may also be
shown in the display (Y page 260).
Instrument cluster
37
At a glance
Steering wheel with buttons
Function Page
:
Display 248
; ~
Rejects or ends a call 254
Exits the telephone book/
redial memory
6
Makes or accepts a call 254
Switches to the redial mem-
ory
W X
Adjusts the volume
8
Mutes
ó
For vehicles with Audio 20:
switches on voice-operated
control of the navigation system (see the manufacturer's
operating instructions)
For vehicles with COMAND
Online: switches on LINGUA-
Function Page
TRONIC (see the separate
operating instructions)
= ò
Calls up the main menu
9 :
Selects a menu or submenu
or scrolls through lists 246
a
Confirms a selection 246
Hides display messages 260
%
Back 246
ñ
For vehicles with Audio 20:
switches off voice-operated
control of the navigation system (see the manufacturer's
operating instructions)
For vehicles with COMAND
Online: switches off LINGUATRONIC (see the separate
operating instructions)
38
Steering wheel with buttons
At a glance
Centre console
Centre console, upper section
Function Page
:
Multimedia system display;
see the separate operating
instructions
;
Air-conditioning control
panel 143
=
Multimedia system CD/DVD
drive; see the separate operating instructions
?
£ Switches hazard warning lamps on and off 128
A
Ø Vehicle functions button; see the separate operating instructions
B
% Telephone button; see
the separate operating
instructions
C
PASSENGER AIR BAG indicator lamps 46
Function Page
D
Õ Media button; see the
separate operating instructions
E
$ Radio button; see the
separate operating instructions
F
ß Navigation button; see
the separate operating
instructions
G
þ Ejects a CD; see the
separate operating instructions
V Loads a DVD; see the
separate operating instructions
Centre console
39
At a glance
Centre console, middle section
Vehicle with automatic transmission
Function Page
:
Back button; see the separate operating instructions
;
Multimedia system controller; see the separate operating instructions
=
Favourites button; see the
separate operating instructions
?
Adjusts/mutes the volume;
see the separate operating
instructions
A
Switches the multimedia system on/off; see the separate
operating instructions
B
Æ Opens and closes the
electric sliding door on the
right side of the vehicle 84
Function Page
C
Touchpad (see the separate
operating instructions)
D
è Activates and deactivates the ECO start/stop
function 175
E
Å Opens and closes the
electric sliding door on the
left side of the vehicle 84
F
c Deactivates and activates PARKTRONIC 224
G
DYNAMIC SELECT switch 181
40
Centre console
At a glance
Centre console, lower section
Stowage compartment with cover
Function Page
:
Cover 313
;
12 V socket 321
Cigarette lighter 320
=
Fitting for the mobile phone
bracket 325
?
Media Interface with two
USB ports or with two USB
ports and one SD card slot 313
Function Page
A
Cup holder 318
B
Ashtray 320
C
• Stowage compartment
• Timer for the auxiliary
warm-air heater 162
• Device mounting bracket
for an auxiliary device, e.g. a
tachograph
Centre console
41
At a glance
Centre console between the driver's and co-driver's seats
Centre console between the driver's and co-driver's seats
Function Page
:
Stowage compartment
;
Cup holder 318
=
Stowage compartment 313
Media Interface with two
USB ports and an SD card
slot 313
Coolbox
?
Temperature-controlled cup
holder 319
Function Page
A
Stowage compartment
B
Stowage compartment
C
Cigarette lighter 320
Ashtray 320
or
12 V socket 321
230 V socket 322
42
Centre console
At a glance
Overhead control panel
Function Page
:
Ì Deactivates the interior
motion sensor 73
;
p Switches the left-hand
reading lamp on/off 131
=
| Switches the automatic
interior lighting control
on/off 131
?
c Switches the front interior lighting on/off 132
A
w Switches the rear interior lighting on/off 132
B
p Switches the righthand reading lamp on/off 131
Function Page
C
Ë Deactivates tow-away
protection 73
D
ï Info call button
325
E
3 Opens/closes the panorama sliding sunroof 92
Opens/closes the roller sunblinds 94
F
ATA indicator lamp
G
Spectacles compartment 312
H
G SOS button
324
I
F Breakdown assistance
call button 325
Overhead control panel
43
At a glance
Door control panel
d Vehicles with electrically adjustable front seats e Vehicles with manually adjustable front seats
Function Page
:
Opens the door 81
;
r45= Saves
the seat and exterior mirror
settings 124
=
Í Seat heating
119
?
Î Seat ventilation
120
A
% & Unlocks/locks
the vehicle 79
B
Adjusts the seat electrically 98
Function Page
C
7Zö\
Adjusts and folds the exterior
mirrors out/in electrically 122
D
W Opens/closes the front
side windows 89
E
W Opens/closes rear
hinged windows 89
F
n Disables/enables rearcompartment hinged window
controls (override feature) 68
44
Door control panel
At a glance
Useful information
These Operating Instructions describe all models as well as standard and optional equipment
of your vehicle that were available at the time of
going to print. Country-specific variations are
possible. Note that your vehicle may not be fitted with all of the described functions. This also
applies to safety-relevant systems and functions.
Read the information on qualified specialist
workshops: (Y page 31).
Occupant safety
Restraint system introduction
The restraint system can reduce the risk of vehicle occupants coming into contact with parts of
the vehicle's interior in the event of an accident.
The restraint system can also reduce the forces
to which vehicle occupants are subjected during
an accident.
The restraint system includes the:
R
seat belt system
R
airbags
R
child restraint system
R
child seat securing system
The components of the restraint system work in
conjunction with each other. They can only offer
protection if all vehicle occupants always:
R
have the seat belt correctly fastened
(Y page 48)
R
have the seat and head restraint adjusted
properly (Y page 96)
As the driver, you must also make sure that the
steering wheel is also adjusted properly.
Observe the information on the correct driver's
seat position (Y page 96).
In addition, you must make sure that the airbags
can inflate properly if they are deployed
(Y page 50).
An airbag supplements a correctly worn seat
belt. As an additional safety device, the airbag
increases the level of protection for vehicle
occupants in the event of an accident. The airbags are not deployed, for example, in the event
of an accident in which sufficient protection is
offered by the seat belt. In addition, only those
airbags, which in the applicable accident situations offer additional protection, are deployed in
the event of an accident. However, the seat belt
and airbag generally do not protect against
objects penetrating the vehicle from the outside.
Information on how the restraint system operates can be found under "Deployment of belt
tensioners and airbags" (Y page 57).
See "Children in the vehicle" for information on
children travelling with you in the vehicle as well
as on child restraint systems (Y page 59).
Important safety notes
G
WARNING
If the restraint system is modified, it may no
longer work as intended. The restraint system
may then not perform its intended protective
function by failing in an accident or triggering
unexpectedly, for example. There is an
increased risk of injury, possibly even fatal.
Never modify parts of the restraint system. Do
not attempt to modify the wiring as well as
electronic components or their software.
If it is necessary to adjust the vehicle to accommodate a person with disabilities, contact a
qualified specialist workshop. Mercedes-Benz
recommends that you use a Mercedes-Benz
Service Centre for this.
Restraint system warning lamp
The functions of the restraint system are
checked after the ignition is switched on and at
regular intervals while the engine is running.
Therefore, malfunctions can be detected in
good time.
The 6 restraint system warning lamp on the
instrument cluster lights up when the ignition is
switched on. It goes out no later than a few seconds after the vehicle is started. The components of the restraint system are in operational
readiness.
Occupant safety
45
Safety
Z
A malfunction has occurred if the 6 restraint
system warning lamp:
R
does not light up after the ignition is switched
on
R
does not go out after a few seconds with the
engine running
R
lights up again while the engine is running
G
WARNING
If the restraint system is malfunctioning,
restraint system components may be triggered unintentionally or may not deploy as
intended during an accident. This may affect
the seat belt tensioner or airbag, for example.
This poses an increased risk of injury or even
fatal injury.
Have the restraint system checked and
repaired immediately at a qualified specialist
workshop.
PASSENGER AIR BAG OFF indicator
lamp
PASSENGER AIR BAG OFF indicator lamp : and
PASSENGER AIR BAG ON indicator lamp ; are
part of the automatic deactivation system of the
front-passenger front airbag.
The PASSENGER AIR BAG OFF indicator lamp
informs you about the status of the frontpassenger front airbag.
If the PASSENGER AIR BAG OFF indicator
lamp:
R
lights up, the front-passenger front airbag is
disabled. It will then not be deployed in the
event of an accident.
R
does not light up, the front-passenger front
airbag is enabled. If, in the event of an acci-
dent, all deployment criteria are met, the
front-passenger front airbag is deployed.
The PASSENGER AIR BAG ON indicator lamp is
inoperative. When the ignition is switched on, it
lights up briefly and then goes out again.
Depending on the person in the front-passenger
seat, the front-passenger front airbag must be
either disabled or enabled; see the following
points. You must make sure of this both before
and during a journey.
R
Children in a rearward-facing child
restraint system: the PASSENGER AIR BAG
OFF indicator lamp must be lit. The frontpassenger front airbag is disabled. Make sure
that you read the notes on the "Automatic
front-passenger front airbag deactivation system" (Y page 52) and on "Children in the
vehicle" (Y page 59).
R
Children in a forward-facing child
restraint system: depending on the installed
child restraint system and the age and size of
the child, the front-passenger front airbag is
either disabled or enabled. Therefore, make
sure that you read the notes on the "Automatic front-passenger front airbag deactivation system" (Y page 52) and on "Children in
the vehicle" (Y page 59).
R
All other persons: the PASSENGER AIR BAG
OFF indicator lamp must be off. The frontpassenger front airbag is enabled. Depending
on the build of the person on the frontpassenger seat, the PASSENGER AIR BAG
OFF indicator lamp may light up. The frontpassenger front airbag is disabled. It will then
not be deployed in the event of an accident. In
this case, the front-passenger seat should not
be used.
Make sure that you read the notes on the
"Automatic front-passenger front airbag
deactivation system" (Y page 52) as well as
on "Seat belts" (Y page 46) and "Airbags"
(Y page 49). There, you can also find information on the correct seat position.
Seat belts
Introduction
A correctly worn seat belt is the most effective
means of restraining the movement of vehicle
occupants in the event of a collision or if the
vehicle overturns. This reduces the risk of vehicle occupants coming into contact with parts of
46
Occupant safety
Safety
the vehicle interior or being ejected from it. The
seat belt also helps to keep the vehicle occupants in the best position in relation to the airbag being deployed.
The seat belt system consists of:
R
seat belts
R
belt tensioners for the front seat belts
R
belt force limiters
If the seat belt is pulled quickly or sharply from
the belt outlet, the inertia reel locks. The belt
strap cannot be pulled out any further.
The belt tensioner tightens the seat belt in the
event of a collision so that it fits tightly across
your body. However, it does not pull the vehicle
occupants back in the direction of the seat
backrest.
The belt tensioner does not, however, correct an
incorrect seat position or correct the routing of
a seat belt that is worn incorrectly.
When triggered, seat belt force limiters help to
reduce the peak force exerted by the seat belt
on the vehicle occupant.
The belt force limiters on the front seats are
synchronised with the front airbags, which take
on a part of the deceleration force. This can
reduce the forces to which the vehicle occupants are subjected during an accident.
!
If the co-driver's seat is not occupied, do not
engage the seat belt tongue in the buckle on
the co-driver's seat. Otherwise, the belt tensioner could be triggered in the event of an
accident and would have to be replaced.
Important safety notes
G
WARNING
If the seat belt is worn incorrectly, it cannot
perform its intended protective function. Furthermore, an incorrectly worn seat belt can
cause additional injuries, e.g. in the event of
an accident, heavy braking or sudden
changes of direction. There is an increased
risk of injury, possibly even fatal.
Always ensure that all vehicle occupants have
their seat belts fastened correctly and are sitting properly.
The components of the restraint system work in
conjunction with each other. They can only offer
protection if all vehicle occupants always:
R
have the seat belt correctly fastened
(Y page 48)
R
have the seat and head restraint adjusted
properly (Y page 96)
G
WARNING
The seat belt does not offer the intended level
of protection if you have not moved the backrest to an almost vertical position. When braking or in the event of an accident, you could
slide underneath the seat belt and sustain
abdomen or neck injuries, for example. This
poses an increased risk of injury or even fatal
injury.
Adjust the seat properly before beginning
your journey. Always ensure that the backrest
is in an almost vertical position and that the
shoulder section of your seatbelt is routed
across the centre of your shoulder.
G
WARNING
Persons under 1.50 m tall cannot wear the
seat belts correctly without an additional suitable restraint system. If the seat belt is worn
incorrectly, it cannot perform its intended
protective function. Furthermore, an incorrectly worn seat belt can cause additional
injuries, e.g. in the event of an accident, heavy
braking or sudden changes of direction. There
is an increased risk of injury, possibly even
fatal.
Always secure persons less than 1.50 m tall in
additional suitable restraint systems.
If a child younger than twelve years old and
under 1.50 m in height is travelling in the vehicle:
R
Always secure the child in a child restraint
system suitable for this Mercedes-Benz vehicle. The child restraint system must be appropriate to the age, weight and size of the child
R
Be sure to observe the instructions and safety
notes on the "Automatic front-passenger
Occupant safety
47
Safety
Z
front airbag deactivation system"
(Y page 52)
R
Be sure to observe the instructions and safety
notes on "Children in the vehicle"
(Y page 59) in addition to the manufacturer's operating and installation instructions for
the child restraint system
G
WARNING
Seat belts cannot protect as intended, if:
R
they are damaged, have been modified, are
extremely dirty, bleached or dyed
R
the seat belt buckle is damaged or
extremely dirty
R
modifications have been made to the belt
tensioners, belt anchorages or inertia reels
Seat belts may sustain non-visible damage in
an accident, e.g. due to glass splinters. Modified or damaged seat belts can tear or fail, for
example in the event of an accident. Modified
seat belt tensioners may be deployed unintentionally or not function as intended. There
is an increased risk of injury, possibly even
fatal.
Never modify seat belts, seat belt tensioners,
seat belt anchorages and inertia reels. Ensure
that seat belts are not damaged or worn and
are clean. After an accident, have the seat
belts checked immediately at a qualified specialist workshop.
Mercedes-Benz recommends that you only use
seat belts that have been approved specifically
for your vehicle by Mercedes-Benz. Otherwise,
your vehicle's general operating permit could be
invalidated.
Correct use of the seat belts
Observe the safety notes on the seat belt
(Y page 47).
All vehicle occupants must be wearing the seat
belt correctly before beginning the journey. Also
make sure that all vehicle occupants are always
wearing the seat belt correctly while the vehicle
is in motion.
When fastening a seat belt, always make sure
that:
R
the seat belt buckle tongue is inserted only
into the belt buckle belonging to that seat
R
the seat belt is pulled tight across the body
Avoid wearing bulky clothing, e.g. a winter
coat.
R
the seat belt is not twisted
Only then can any forces that occur be dis-
tributed across the surface of the seat belt.
R
the shoulder section of the belt is routed
across the centre of the shoulder
The shoulder section of the seat belt should
not touch your neck or be routed under your
arm or behind your back. If possible, adjust
the seat belt to the appropriate height.
R
the lap belt is taut and passes across the lap
as low down as possible
The lap belt must always be routed across
your hip joints and never across your abdomen. This applies particularly to pregnant
women. If necessary, press the lap belt down
into your hip joints and pull tight with the
shoulder section of the belt.
R
the seat belt is not routed across sharp, pointed or fragile objects
If you have such items located on or in your
clothing, e.g. pens, keys or spectacles, store
these in a suitable place.
R
only one person is using a seat belt
Infants and children must never travel sitting
on the lap of a vehicle occupant. In the event
of an accident, they could be crushed
between the vehicle occupant and seat belt.
R
objects are never secured with a seat belt if
the seat belt is also being used by one of the
vehicle's occupants
Also ensure that no objects are placed
between a person and the seat. e.g. a cushion.
Seat belts are intended only to secure and
restrain vehicle occupants. Always observe the
"Loading guidelines" for securing objects, luggage or loads (Y page 328).
Fastening and adjusting the seat belts
Observe the safety notes on the seat belt
(Y page 47) and the information on the correct
use of the seat belt (Y page 48).
48
Occupant safety
Safety
Basic illustration
X
Adjust the seat (Y page 96).
The seat backrest must be in an almost
upright position.
X
Pull the seat belt smoothly from the belt outlet
and engage belt tongue ; in belt buckle :.
The seat belt on the driver's seat and the
front-passenger seat may be tightened automatically; see "Belt adjustment"
(Y page 49).
X
If necessary, pull upwards on the seat belt in
front of your chest so that the belt sits tightly
across your body.
The shoulder section of the seat belt must
always be routed across the centre of the shoulder. Adjust the belt outlet if necessary.
X
To raise: slide the belt outlet upwards.
The belt outlet will engage in various positions.
X
To lower: hold belt outlet release = and slide
the belt outlet downwards.
X
Let go of belt outlet release = in the desired
position and make sure that the belt outlet
engages.
Releasing the seat belts
!
Make sure that the seat belt is fully rolled up.
Otherwise, the seat belt or belt tongue will be
trapped in the door or in the seat mechanism.
This could damage the door, the door trim
panel and the seat belt. Damaged seat belts
can no longer fulfil their protective function
and must be replaced. Visit a qualified specialist workshop.
X
Press release button in belt buckle, hold belt
tongue firmly and guide the seat belt back.
Seat belt adjustment
Seat-belt adjustment is an integral part of the
PRE-SAFE® convenience function. With this
function, the driver's and co-driver's seat belts
are adjusted to the upper body of the vehicle
occupant.
The belt strap is tightened slightly when:
R
the belt tongue is engaged in the buckle and
R
the ignition is switched on
The seat belt adjustment will apply a certain
tightening force if any slack is detected between
the vehicle occupant and the seat belt. Do not
hold on to the seat belt tightly while it is adjusting.
You can switch the seat belt adjustment on and
off using the multimedia system. Information on
switching the seat belt adjustment function on
and off can be found in the Digital Operating
Instructions or in the separate multimedia system operating instructions.
Belt warning for driver and co-driver
The 7 seat belt warning lamp in the instrument cluster is a reminder that all vehicle occupants must wear their seat belts. It may light up
continuously or flash. In addition, a warning tone
may sound.
The 7 seat belt warning lamp goes out and
the warning tone ceases when the driver and the
front passenger have fastened their seat belts.
For certain countries only: regardless of
whether the driver and front passenger have
already fastened their seat belts, the 7 seat
belt warning lamp lights up for 6 seconds after
each time the ignition is switched on. After the
engine has been started, it goes out once the
driver and front passenger have fastened their
seat belts.
Airbags
Introduction
The installation location of an airbag is identified
by the AIRBAG symbol.
An airbag supplements a correctly worn seat
belt. It is not a replacement for the seat belt. The
airbag offers additional protection in corresponding accident situations.
Occupant safety
49
Safety
Z
Not all airbags are deployed in an accident. The
different airbag systems work independently of
each other (Y page 57).
However, no system available today can completely eliminate injuries and fatalities.
It is also not possible to completely rule out a
risk of injury caused by an airbag due to the
speed at which the airbag must be deployed.
Important safety notes
G
WARNING
If you deviate from the correct seat position,
the airbag cannot perform its intended protective function and can even cause additional injuries when deployed. There is an
increased risk of serious or even fatal injuries.
In order to avoid such risks, always ensure
that all vehicle occupants:
R
fasten their seatbelts correctly, including
pregnant women
R
are seated correctly and maintain the furthest possible distance from the airbags
R
observe the following notes
Always ensure that there are no objects located between the airbag and the vehicle occupant.
R
Adjust the seats properly before beginning
your journey. Always make sure that the seat
is in an almost upright position. The centre of
the head restraint must support the head at
about eye level.
R
Move the driver's and front-passenger seats
as far back as possible. The driver's seat position must allow the vehicle to be driven safely.
R
Hold the steering wheel only by the rim. This
allows the airbag to be fully deployed.
R
Always lean against the backrest while driving. Do not lean forwards or lean against the
door or side window. You may otherwise be in
the deployment area of the airbags.
R
Always keep your feet in the footwell in front
of the seat. Do not put your feet on the dashboard, for example. Your feet may otherwise
be in the deployment area of the airbag.
R
Always secure persons less than 1.50 m tall in
suitable restraint systems. Up to this height,
the seat belt cannot be worn correctly.
If a child is travelling in your vehicle, also
observe the following notes:
R
Always secure children under twelve years of
age and less than 1.50 m tall in suitable child
restraint systems.
R
Child restraint systems should preferably be
fitted to the rear seats.
R
Secure a child to the front-passenger seat
only when the front-passenger front airbag is
disabled, and then only in a rearward-facing
child restraint system. If the PASSENGER AIR
BAG OFF indicator lamp is permanently lit, the
front-passenger front airbag is disabled
(Y page 46).
R
Be sure to observe the instructions and safety
notes on the "Automatic front-passenger
front airbag deactivation system"
(Y page 52) and on "Children in the vehicle"
(Y page 59) in addition to the manufacturer's operating and installation instructions for
the child restraint system.
Objects in the vehicle interior may prevent
the airbag from functioning correctly. Before
starting your journey and to avoid risks resulting
from the speed of the airbag as it deploys, make
sure that:
R
there are no people, animals or objects
between the vehicle occupants and an airbag
R
there are no objects between the seat, door
and B-pillar
R
there are no hard objects, e.g. coat hangers,
hanging on the grab handles or coat hooks
R
no accessories, such as cup holders, are
attached to the vehicle within the deployment
area of an airbag, e.g. to doors or side windows
R
no heavy, sharp-edged or fragile objects are in
the pockets of your clothing. Store such
objects in a suitable place.
G
WARNING
If you modify an airbag cover or affix objects
such as stickers to it, the airbag can no longer
function correctly. There is an increased risk
of injury.
Never modify an airbag cover or affix objects
to it.
Vehicles with windowbags for all seat rows:
50
Occupant safety
Safety
G
WARNING
Sensors to control the airbags are located in
the doors. Modifications or work not performed correctly to the doors or door panelling, as well as damaged doors, can lead to the
function of the sensors being impaired. The
airbags might therefore not function properly
any more. Consequently, the airbags cannot
protect vehicle occupants as they are
designed to do. This poses an increased risk
of injury.
Never modify the doors or parts of the doors.
Always have work on the doors or door panelling carried out at a qualified specialist
workshop.
Front airbags
!
Do not place heavy objects on the frontpassenger seat. This could cause the system
to identify the seat as being occupied. In the
event of an accident, the restraint systems on
the front-passenger side may be triggered
and have to be replaced.
Driver's airbag : deploys in front of the steering wheel. Front-passenger front airbag ;
deploys in front of and above the glove compartment and centre console.
When deployed, the front airbags offer additional head and thorax protection for the occupants in the front seats.
The PASSENGER AIR BAG OFF indicator lamp
informs you about the status of the frontpassenger front airbag (Y page 46).
The front-passenger front airbag will deploy only
if:
R
the automatic front-passenger front airbag
deactivation system has detected that the
front-passenger seat is occupied
(Y page 52). The PASSENGER AIR BAG OFF
indicator lamp is not lit (Y page 53)
R
the restraint system control unit predicts a
high accident severity
Sidebags
G
WARNING
Unsuitable seat covers may obstruct or even
prevent deployment of the airbags integrated
into the seats. The airbags may then fail to
protect the vehicle occupants as intended.
Operation of the automatic co-driver's front
airbag deactivation system may also be
impaired. There is an increased risk of injury,
possibly even fatal.
Use only seat covers which have been specifically approved for the respective seat by
Mercedes-Benz.
Sidebags : deploy next to the outer bolster of
the seat backrest.
When deployed, the sidebag offers additional
thorax and pelvis protection. However, it does
not protect the:
R
head
R
neck
R
arms
When the restraint system control unit detects a
side impact, the sidebag is deployed on the side
on which the impact occurs.
Occupant safety
51
Safety
Z
Vehicles with the automatic front-passenger
front airbag deactivation system: the sidebag on
the front-passenger side deploys under the following conditions:
R
an occupant is detected in the frontpassenger seat or
R
the seat belt buckle tongue is engaged in the
belt buckle of the front-passenger seat
If the belt tongue is engaged in the belt buckle,
the sidebag on the front-passenger side deploys
if an appropriate accident situation occurs. In
this case, deployment is independent of
whether the front-passenger seat is occupied or
not.
Windowbags
Example: windowbag above the front door
Example: windowbag for all seat rows
Windowbags : or ; are integrated in the side
of the roof frame. Windowbags for all seat
rows ; deploy in the area from the front door
(A-pillar) to the rear side window (D-pillar).
When deployed, the windowbag enhances the
level of protection for the head. However, it does
not protect the chest or arms.
When the restraint system control unit detects a
side impact, the windowbag is deployed on the
side on which the impact occurs.
If the system determines that it can offer additional protection to that provided by the seat
belt, a windowbag may be deployed in other
accident situations (Y page 57).
Automatic co-driver airbag deactivation
Introduction
In order to recognise a child restraint system on
the front-passenger seat, the automatic frontpassenger front airbag deactivation system categorises the person in the front-passenger seat.
Depending on that result, the front-passenger
front airbag is either enabled or disabled. If a
rearward-facing child restraint system is fitted
to the front-passenger seat, the PASSENGER
AIR BAG OFF indicator lamp must light up after
the system self-test and remain lit. The frontpassenger front airbag is disabled.
The system does not disable:
R
the sidebag
R
the windowbag
R
the seat belt tensioner
Make sure that your vehicle is equipped with the
automatic front-passenger front airbag deactivation system (Y page 62). If this is not the
case, always install a child restraint system on a
suitable rear seat (Y page 63).
If it is absolutely necessary to install a child
restraint system on the front-passenger seat, be
sure to observe the correct positioning of the
child restraint system. Never place objects
under or behind the child restraint system, e.g. a
cushion. The entire base of the child restraint
system must always rest on the seat cushion of
the front-passenger seat. The backrest of a
forward-facing child restraint system must, as
far as possible, rest flat against the backrest of
the front-passenger seat. The child restraint system must not touch the roof or be put under
strain by the head restraint. Adjust the angle of
the seat backrest and the head restraint position accordingly. Only then is the correct function of the automatic front-passenger front airbag deactivation system guaranteed. Always
observe the information on suitable positioning
of the child restraint system (Y page 63) in
52
Occupant safety
Safety
addition to the child restraint system manufacturer's installation instructions.
Operation of automatic front-passenger
front airbag deactivation
:
PASSENGER AIR BAG OFF indicator lamp
;
PASSENGER AIR BAG ON indicator lamp
The PASSENGER AIR BAG OFF indicator lamp
shows you whether the front-passenger front
airbag is disabled.
X
Turn the key to position 1 or 2 in the ignition lock.
The system carries out a self-diagnosis.
The PASSENGER AIR BAG ON indicator lamp is
inoperative. When the ignition is switched on, it
lights up briefly and then goes out again.
The PASSENGER AIR BAG OFF indicator lamp
must light up for approximately six seconds.
The PASSENGER AIR BAG OFF indicator lamp
then displays the status of the front-passenger
front airbag. If the status of the front-passenger
front airbag changes while the vehicle is in
motion, an airbag display message may appear
in the instrument cluster (Y page 262). When
the front-passenger seat is occupied, always
pay attention to the PASSENGER AIR BAG OFF
indicator lamp. Be aware of the status of the
front-passenger front airbag both before and
during the journey.
If the PASSENGER AIR BAG OFF indicator
lamp:
R
lights up, the front-passenger front airbag is
disabled. It will then not be deployed in the
event of an accident.
R
does not light up, the front-passenger front
airbag is enabled. If, in the event of an accident, all deployment criteria are met, the
front-passenger front airbag is deployed.
If a person sits in the front-passenger seat, they
must be:
R
seated with the seat belt fastened correctly
R
in an almost upright position with their back
against the seat backrest
R
with their feet resting on the floor, if possible
If the front passenger does not observe these
conditions, the automatic front-passenger front
airbag deactivation system may be influenced,
e.g. because the front passenger:
R
transfers their weight by supporting themselves on a vehicle armrest
R
sits in such a way that their weight is raised
from the seat cushion
The front-passenger front airbag may be disabled by mistake as a result of these or similar
actions. In this case, the PASSENGER AIR BAG
OFF indicator lamp lights up permanently. The
front-passenger front airbag then does not
deploy during an accident.
G
WARNING
If the PASSENGER AIRBAG OFF indicator lamp
is lit, the front-passenger front airbag is disabled. It will not be deployed in the event of an
accident and cannot perform its intended protective function. A person in the frontpassenger seat could then, for example, come
into contact with the vehicle's interior, especially if the person is sitting too close to the
dashboard. This poses an increased risk of
injury or even fatal injury.
When the front-passenger seat is occupied,
always make sure that:
R
the classification of the person in the frontpassenger seat is correct and that the frontpassenger front airbag is enabled or disabled in accordance with the person in the
front-passenger seat.
R
the front-passenger seat has been moved
back as far back as possible.
R
the person is seated correctly.
Make sure, both before and during the journey, that the status of the front-passenger
front airbag is correct.
Occupant safety
53
Safety
Z
G
WARNING
If you secure a child in a child restraint system
on the front-passenger seat and the
PASSENGER AIR BAG OFF indicator lamp is
off, the front-passenger front airbag can
deploy in the event of an accident. The child
could be struck by the airbag. This poses an
increased risk of injury or even fatal injury.
Make sure that the front-passenger front airbag has been disabled. The PASSENGER AIRBAG OFF indicator lamp must be lit.
G
WARNING
If you secure a child in a forward-facing child
restraint system on the front-passenger seat
and you position the front-passenger seat too
close to the dashboard, the child could, in the
event of an accident:
R
come into contact with the vehicle's interior if the PASSENGER AIR BAG OFF indicator lamp is lit, for example
R
be struck by the airbag if the PASSENGER
AIR BAG OFF indicator lamp is off
This poses an increased risk of injury or even
fatal injury.
Move the front-passenger seat as far back as
possible. Always make sure that the shoulder
belt strap is correctly routed from the vehicle
belt sash guide to the shoulder belt guide on
the child restraint system. The shoulder belt
strap must be routed forwards and downwards from the vehicle belt sash guide. If necessary, adjust the vehicle belt sash guide and
the front-passenger seat accordingly. Always
comply with the child restraint system manufacturer's installation instructions.
Always observe the vehicle-specific information
for the correct positioning of the child restraint
system (Y page 63).
If the automatic front-passenger front airbag
deactivation system detects that:
R
the front-passenger seat is unoccupied, the
PASSENGER AIR BAG OFF indicator lamp
lights up after the system self-test and
remains lit. This indicates that the frontpassenger front airbag is disabled.
R
the front-passenger seat is occupied by a
child in a rearward-facing child restraint system, the PASSENGER AIR BAG OFF indicator
lamp lights up after the system self-test and
remains lit. This indicates that the frontpassenger front airbag is disabled.
But in the case of a child in a rearward-facing
child restraint system, the PASSENGER AIR
BAG OFF indicator lamp can also go out after
the system self-test. This indicates that the
front-passenger front airbag is enabled. The
result of the classification is dependent on,
among other factors, the child restraint system and the child's build. It is recommended
that you fit the child restraint system to a
suitable rear seat.
R
the front-passenger seat is occupied by a
child in a forward-facing child restraint system, either the PASSENGER AIR BAG OFF
indicator lamp lights up and remains lit after
the system self-test depending on the result
of the classification, or it goes out. The result
of the classification is dependent on, among
other factors, the child restraint system and
the child's build.
Move the front-passenger seat as far back as
possible. Always observe the information in
"Child restraint systems on the frontpassenger seat" (Y page 62) and in "Suitable positioning of the child restraint system"
(Y page 63). Alternatively, you can fit the
child restraint system to a suitable rear seat.
R
the front-passenger seat is occupied by a person with a smaller build (e.g. a teenager or
small adult), the PASSENGER AIR BAG OFF
indicator lamp lights up and remains lit after
the system self-test depending on the result
of the classification or, alternatively, goes out.
-
If the PASSENGER AIR BAG OFF indicator
lamp is off, move the front-passenger seat
as far back as possible. Alternatively, a person with a small build can sit on a rear seat.
-
If the PASSENGER AIR BAG OFF indicator
lamp is lit, a person with a smaller build
should not use the front-passenger seat.
R
the front-passenger seat is occupied by an
adult or a person with the build of an adult, the
PASSENGER AIR BAG OFF indicator lamp
goes out after the system self-test. This indicates that the front-passenger front airbag is
enabled.
54
Occupant safety
Safety
If children are travelling in the vehicle, be sure to
observe the notes on "Children in the vehicle"
(Y page 59).
If the automatic front-passenger front airbag
deactivation system is malfunctioning, the red
6 restraint system warning lamp on the
instrument cluster and the PASSENGER AIR
BAG OFF indicator lamp light up simultaneously.
The front-passenger front airbag is disabled in
this case and does not deploy during an accident. Have the automatic front-passenger front
airbag deactivation system checked and
repaired immediately at a qualified specialist
workshop. Mercedes-Benz recommends that
you use a Mercedes-Benz Service Centre for this
purpose.
If the front-passenger seat, the seat cover or the
seat cushion are damaged, have the necessary
repair work carried out at a qualified specialist
workshop. Mercedes-Benz recommends that
you use a Mercedes-Benz Service Centre for this
purpose.
For safety reasons, Mercedes-Benz recommends that you use only a child restraint system
that has been tested and approved by
Mercedes-Benz in combination with the automatic front-passenger front airbag deactivation
system.
System self-test
G
DANGER
If the PASSENGER AIR BAG OFF indicator
lamp does not light up during the system selftest, then the system is malfunctioning. The
front-passenger front airbag might be triggered unintentionally or might not be triggered at all in the event of an accident with
high deceleration. This poses an increased
risk of injury or even fatal injury.
In this case the front-passenger seat may not
be used. Do not install a child restraint system
on the front-passenger seat. Have the automatic front-passenger front airbag deactivation system checked and repaired immediately at a qualified specialist workshop.
G
WARNING
If the PASSENGER AIRBAG OFF indicator lamp
remains lit after the system self-test, the
front-passenger front airbag is disabled. It will
not be deployed in the event of an accident. In
this case, the front-passenger front airbag
cannot perform its intended protective function, e.g. when a person is seated in the frontpassenger seat.
That person could, for example, come into
contact with the vehicle's interior, especially
if the person is sitting too close to the dashboard. This poses an increased risk of injury or
even fatal injury.
When the front-passenger seat is occupied,
always ensure that:
R
the classification of the person in the frontpassenger seat is correct and the frontpassenger front airbag is enabled or disabled in accordance with the person in the
front-passenger seat.
R
the person is seated properly with a correctly fastened seat belt.
R
the front-passenger seat has been moved
as far back as possible.
If the PASSENGER AIR BAG OFF indicator
lamp remains lit when it should not, the frontpassenger seat may not be used. Do not
install a child restraint system on the frontpassenger seat. Have the automatic frontpassenger front airbag deactivation system
checked and repaired immediately at a qualified specialist workshop.
G
WARNING
Objects between the seat surface and the
child restraint system could affect the function of the automatic front-passenger front
airbag deactivation system. This could result
in the front-passenger front airbag not functioning as intended during an accident. This
poses an increased risk of injury or even fatal
injury.
Do not place any objects between the seat
surface and the child restraint system. The
entire base of the child restraint system must
always rest on the seat cushion of the frontpassenger seat. The backrest of the forwardsfacing child restraint system must, as far as
Occupant safety
55
Safety
Z
possible, be resting on the backrest of the
rear reclining seat. Always comply with the
child restraint system manufacturer's installation instructions.
After the system self-test, the PASSENGER AIR
BAG OFF indicator lamp displays the status of
the front-passenger front airbag (Y page 53).
Further information can be found under "Problems with the automatic front-passenger front
airbag deactivation system" (Y page 56).
Problems with automatic co-driver airbag deactivation
Be sure to observe the notes on "System self-test" (Y page 55).
Problem
Possible causes/consequences and M Solutions
The PASSENGER AIR
BAG OFF indicator lamp
lights up and remains lit,
even though the frontpassenger seat is occupied by an adult or a person with a build corresponding to that of an
adult.
The classification of the person on the front-passenger seat is false.
X
Make sure the conditions for a correct classification of the person
on the front-passenger seat are met (Y page 53).
X
If the PASSENGER AIR BAG OFF indicator lamp remains lit, the frontpassenger seat may not be used.
X
Have the automatic front-passenger front airbag deactivation system checked immediately at a qualified specialist workshop.
The PASSENGER AIR
BAG OFF indicator lamp
does not light up and/or
does not stay on.
The front-passenger seat
is:
R
empty
R
occupied with a rearward-facing child
restraint system
The automatic front-passenger front airbag deactivation system is
malfunctioning.
X
Make sure there is nothing between the seat and the child restraint
system.
X
Make sure that the entire base of the child restraint system rests on
the seat cushion of the front-passenger seat.
X
When installing the child restraint system, make sure that the seat
belt is tight. Do not pull the seat belt tight with the front-passenger
seat adjustment. This could result in the seat belt and the child
restraint system being pulled too tightly.
X
Check that the child restraint system is installed correctly.
X
Make sure that no objects are applying additional weight to the
seat.
X
If the PASSENGER AIR BAG OFF indicator lamp remains off, do not
install a child restraint system on the front-passenger seat. It is
recommended that you fit the child restraint system to a suitable
rear seat.
X
Have the automatic front-passenger front airbag deactivation system checked immediately at a qualified specialist workshop.
56
Occupant safety
Safety
Deployment of belt tensioners and airbags
Important safety notes
G
WARNING
After the airbag deploys, the airbag parts are
hot. There is a risk of injury.
Do not touch the airbag parts. Have a
deployed airbag replaced at a qualified specialist workshop as soon as possible.
G
WARNING
Pyrotechnical belt tensioners which have
been triggered are no longer operational and
therefore cannot protect as intended. There is
an increased risk of injury, possibly even fatal.
Have pyrotechnic belt tensioners which have
been triggered replaced at a qualified specialist workshop immediately.
Mercedes-Benz recommends that you have the
vehicle towed to a qualified specialist workshop
after an accident. Take this into account, particularly if a seat belt tensioner was triggered or
an airbag was deployed.
An electric motor is used by PRE-SAFE® to trigger the tightening of the seat belt in hazardous
situations. This procedure is reversible.
If the belt tensioners are triggered or an airbag is
deployed, you will hear a bang, and a small
amount of powder may also be released. The
6 restraint system warning lamp lights up.
Only in rare cases will the bang affect your hearing. In general, the powder released is not hazardous to health but may cause short-term
breathing difficulties to persons suffering from
asthma or other pulmonary conditions. Provided
it is safe to do so, you should leave the vehicle
immediately or open the window in order to prevent breathing difficulties.
Operation
During the first stage of a collision, the restraint
system control unit evaluates important physical data relating to vehicle deceleration or acceleration, such as:
R
duration
R
direction
R
intensity
Based on the evaluation of this data, the
restraint system control unit triggers the seat
belt tensioners in the event of a head-on or rear
collision.
A seat belt tensioner can be triggered only if:
R
the ignition is switched on
R
the components of the restraint system are
operational. You can find further information
under: "Restraint system warning lamp"
(Y page 45)
R
the seat belt buckle tongue has engaged in
the belt buckle of the respective front seat
If the restraint system control unit detects a
high-severity accident, in certain head-on collisions, additional components of the restraint
system are deployed independently of each
other:
R
front airbags
R
windowbag, if the system determines that
deployment can offer additional protection to
that provided by the seat belt
On vehicles with the automatic front-passenger
front airbag deactivation system: depending on
the person in the front-passenger seat, the
front-passenger front airbag is either disabled or
enabled. The front-passenger front airbag can
be deployed in an accident only if the
PASSENGER AIR BAG OFF indicator lamp is off.
Observe the information on the PASSENGER AIR
BAG OFF indicator lamp (Y page 46).
Your vehicle has two-stage front airbags. In the
first deployment stage, the front airbag is filled
with propellant gas. The front airbag is fully
deployed if the second deployment stage is activated within a few milliseconds.
The activation threshold for the seat belt tensioners and airbags is determined based on the
evaluation of the vehicle's rate of deceleration
or acceleration at various points in the vehicle.
This process is pre-emptive in nature. The triggering/deployment process should take place
in good time at the start of the collision.
Occupant safety
57
Safety
Z
The rate of vehicle deceleration or acceleration
and the direction of the force are essentially
determined by:
R
the distribution of forces during the collision
R
the collision angle
R
the deformation characteristics of the vehicle
R
the characteristics of the object with which
the vehicle has collided
Factors that can be seen and measured only
after a collision has occurred do not play a decisive role in the deployment of an airbag. Nor do
they provide an indication of airbag deployment.
The vehicle may be deformed significantly without an airbag being deployed. This is the case if
only parts that are relatively easily deformed are
affected and the rate of deceleration is not high.
Conversely, an airbag may be deployed even
though the vehicle suffers only minor deformation. This is the case if, for example, very rigid
vehicle parts such as longitudinal body members are hit, and sufficient deceleration occurs
as a result.
If the restraint system control unit detects a side
impact, the applicable components of the
restraint system are activated independently of
each other.
R
Sidebag on the side on which an impact
occurs, independently of the seat belt tensioner and seat belt usage
Vehicles with the automatic front-passenger
front airbag deactivation system: the sidebag
on the front-passenger side deploys under the
following conditions:
-
an occupant is detected in the frontpassenger seat or
-
the seat belt buckle tongue is engaged in
the belt buckle of the front-passenger seat
R
Windowbag on the side on which an impact
occurs, independently of seat belt usage and
regardless of whether the front-passenger
seat is occupied
R
Seat belt tensioners, if the system determines
that deployment can offer additional protection for the vehicle occupants in this situation
i
Not all airbags are deployed in an accident.
The different airbag systems work independently of each other.
How the airbag system works is determined
by the severity of the accident detected,
especially the vehicle deceleration or acceleration, and the apparent type of accident:
R
frontal collision
R
side impact
PRE-SAFE® (anticipatory occupant
protection)
Introduction
In certain hazardous situations, PRE-SAFE
®
takes pre-emptive measures to protect the vehicle occupants.
Important safety notes
!
Make sure that there are no objects in the
footwell or behind the seats. There is a risk
that the seats and/or the objects could be
damaged when PRE-SAFE® is activated.
Although your vehicle is equipped with PRESAFE®, the possibility of injury in the event of an
accident cannot be ruled out. Always adapt your
driving style to the prevailing road and weather
conditions and maintain a sufficient, safe distance from other road users. Drive carefully.
Function
PRE-SAFE® can detect certain hazardous situations and take pre-emptive measures to protect
the vehicle occupants. PRE-SAFE® can activate
the following components independently of
each other:
R
the front seat belts are pre-tensioned
R
if the vehicle skids, the side windows and the
panorama sliding sunroof are closed
R
vehicles with the memory function: the codriver's seat is adjusted if it is in an unfavourable position
If the hazardous situation passes without resulting in an accident, PRE-SAFE® slackens the belt
pre-tensioning. All settings made by PRE-SAFE
®
can then be reversed.
58
Occupant safety
Safety
If the seat belt pre-tensioning is not reduced:
X
Move the seat backrest or seat back slightly
when the vehicle is stationary.
Seat belt pre-tensioning is reduced and the
locking mechanism is released.
The seat belt adjustment is an integral part of
the PRE-SAFE® convenience function. Informa-
tion about the convenience function can be
found under "Belt adjustment" (Y page 49).
Automatic measures after an accident
Immediately after an accident, the following
measures may be implemented, depending on
the type and severity of the impact:
R
the hazard warning lamps are activated
R
the emergency lighting in the vehicle interior
is activated
R
the vehicle doors are unlocked
R
the front side windows are lowered
R
air-recirculation mode is switched on
R
climate control is switched off
R
the engine is switched off and the fuel supply
is cut off
Children in the vehicle
Important safety notes
Accident statistics show that children secured
on the rear seats are safer than children secured
on the front-passenger seat. For this reason,
Mercedes-Benz strongly advises that you install
the child restraint system on a rear seat. Children are generally better protected there.
If a child younger than twelve years old and
under 1.50 m in height is travelling in the vehicle:
R
always secure the child in a child restraint
system suitable for Mercedes-Benz vehicles.
The child restraint system must be appropriate to the age, weight and size of the child.
R
be sure to observe the instructions and safety
notes in this section in addition to the child
restraint system manufacturer's installation
instructions.
R
be sure to observe the instructions and safety
notes on the automatic front-passenger front
airbag deactivation system (Y page 52).
G
WARNING
If you leave children unattended in the vehicle, they may be able to set the vehicle in
motion if, for example, they:
R
release the parking brake
R
shift the automatic transmission out of park
position P or shift manual transmission into
neutral
R
start the engine
In addition, they may operate vehicle equipment and become trapped. There is a risk of
an accident and injury.
When leaving the vehicle, always take the key
with you and lock the vehicle. Never leave
children unattended in the vehicle.
G
WARNING
If persons (particularly children) are exposed
to heat or cold for a prolonged period, there is
a risk of serious or even fatal injuries. Never
leave persons (particularly children) unattended in the vehicle.
G
WARNING
If the child restraint system is placed in direct
sunlight, the parts could become very hot.
Children could be suffer burns by touching
these parts, in particular on the metallic parts
of the child restraint system. There is a risk of
injury.
If you and your child leave the vehicle, always
make sure that the child restraint system is
not in direct sunlight. Cover it with a blanket,
for example. If the child restraint system has
been exposed to direct sunlight, leave it to
cool down before securing the child in it.
Never leave children unattended in the vehicle.
Always ensure that all vehicle occupants have
their seat belts fastened correctly and are sitting
properly. Particular attention must be paid to
children.
Observe the safety notes on the seat belt
(Y page 47) and the information on the correct
use of the seat belt (Y page 48).
Children in the vehicle
59
Safety
Z
Child restraint system
Observe the instructions for correct use of the
child restraint system (Y page 63).
For safety reasons, Mercedes-Benz recommends that you use only a child restraint system
recommended by Mercedes-Benz
(Y page 66).
G
WARNING
If the child restraint system is incorrectly fitted on the seat position suitable for this purpose, it cannot perform its intended protective function. In the event of an accident,
sharp braking or a sudden change in direction,
the child may not be held securely. There is an
increased risk of serious or even fatal injuries.
Observe the manufacturer's installation
instructions and the correct use for the child
restraint system. Make sure that the entire
surface of the child restraint system is resting
on the seat surface. Never place objects
under or behind the child restraint system,
e.g. cushions. Only use child restraint systems with the original cover designed for
them. Only replace damaged covers with genuine covers.
G
WARNING
If a rearward-facing child restraint system is
mounted facing forwards by mistake, it cannot provide the intended protection. This can,
for example, be the case if a rearward-facing
child restraint system is fitted on a rear seat
which is facing backwards. The child cannot
be restrained in the event of an accident, for
instance. There is an increased risk of injury,
possibly even fatal.
Always ensure the rear seat is facing forwards
before fitting a rearward-facing child restraint
system on it.
G
WARNING
If the child restraint system is fitted incorrectly or is not secured, it can come loose in
the event of an accident, heavy braking or a
sudden change in direction. The child
restraint system could be thrown about, strik-
ing vehicle occupants. There is an increased
risk of injury, possibly even fatal.
Always fit child restraint systems properly,
even if they are not being used. Make sure
that you observe the child restraint system
manufacturer's installation instructions.
You will find further information on stowing
objects, luggage and loads securely under
"Loading guidelines" (Y page 328).
G
WARNING
Child restraint systems or their securing systems that have been damaged or subjected to
a load in an accident cannot perform their
intended protective function. In the event of
an accident, sharp braking or a sudden
change in direction, the child may not be held
securely. There is an increased risk of serious
or even fatal injuries.
Immediately replace child restraint systems
that have been damaged or subjected to a
load in an accident. Have the child restraint
securing systems checked in a qualified specialist workshop before fitting a child restraint
system again.
The securing systems of child restraint systems
are:
R
the seat belt system
R
the ISOFIX securing rings
R
the Top Tether anchorages
If circumstances require you to fit a child
restraint system to the front-passenger seat, be
sure to observe the information on "Child
restraint systems on the front-passenger seat"
(Y page 62).
Observe the warning labels in the vehicle interior and on the child restraint system.
i
It is advisable to use Mercedes-Benz care
products to clean child restraint systems recommended by Mercedes-Benz. Information
can be obtained at a qualified specialist workshop.
60
Children in the vehicle
Safety
ISOFIX child seat securing system
G
WARNING
ISOFIX child restraint systems do not offer
sufficient protective effect for children whose
weight is greater than 22 kg who are secured
using the safety belt integrated in the child
restraint system. The child could, for example,
not be restrained correctly in the event of an
accident. This poses an increased risk of
injury or even fatal injury.
If the child weighs more than 22 kg, only use
ISOFIX child restraint systems with which the
child is also secured with the vehicle seat belt.
Also secure the child restraint system with the
Top Tether belt, if available.
When fitting a child restraint system, be sure to
observe the manufacturer's installation and
operating instructions and the instructions for
correct use of the child restraint system
(Y page 63).
Before installing the child seat, move the rear
seat backrests to an upright position. Do not
adjust the backrest of a seat with an ISOFIX
child restraint system installed.
Before every trip, make sure that the ISOFIX
child restraint system is engaged correctly in
both ISOFIX securing rings.
!
When fitting the child restraint system in
vehicles with a rear bench seat, make sure
that the seat belt for the middle seat does not
get trapped. Otherwise, the seat belt could be
damaged.
:
ISOFIX securing ring (example: individual
seat)
X
Install the ISOFIX child restraint system on
both ISOFIX securing rings :.
ISOFIX is a standardised securing system for
specially designed child restraint systems on
certain rear seats. ISOFIX securing rings : for
an ISOFIX child restraint system are fitted
between the seat cushion and the seat backrest.
Child restraint systems without ISOFIX child
seat securing system should be fitted using the
seat belts in the vehicle. When fitting a child
restraint system, be sure to observe the manufacturer's installation and operating instructions and the instructions for correct use of the
child restraint system (Y page 63).
Top Tether
Introduction
Top Tether provides an additional connection
between the child restraint system secured with
ISOFIX and the vehicle. It helps reduce the risk
of injury even further. If the child restraint system is fitted with a Top Tether belt, this should
always be used.
Top Tether anchorages
Example: individual seat
Top Tether anchorage ; is located at the bottom of the rear side of the rear seat on the cross
brace between the seat or bench seat leg.
X
Move head restraint : upwards.
X
Fit the ISOFIX child restraint system with Top
Tether. Always comply with the child restraint
system manufacturer's installation instructions when doing so.
Children in the vehicle
61
Safety
Z
X
Route Top Tether belt ? under head
restraint : between the two head restraint
bars.
X
Hook Top Tether hook = of Top Tether
belt ? into Top Tether anchorage ;.
Make sure that Top Tether belt ? is not twisted.
X
Tension Top Tether belt ?. Always comply
with the child restraint system manufacturer's installation instructions when doing so.
X
If necessary, move the head restraint : back
down again slightly (Y page 118). Make sure
that you do not interfere with the correct routing of Top Tether belt ?.
Child restraint system on the co-driver's seat
General notes
Accident statistics show that children secured
on the rear seats are safer than children secured
on the front-passenger seat. For this reason,
Mercedes-Benz strongly advises that you install
a child restraint system on a rear seat.
Vehicles with the automatic frontpassenger front airbag deactivation system:
if it is absolutely necessary to fit a child restraint
system to the front-passenger seat, always
observe the information on the "Automatic
front-passenger front airbag deactivation system" (Y page 52).
You can thus avoid the risks that could arise as
a result of:
R
a child restraint system that is not detected
by the automatic front-passenger front airbag
deactivation system
R
unintentional disabling of the front-passenger
front airbag
R
unsuitable positioning of the child restraint
system, e.g. too close to the dashboard
Please observe the warning notice on the
front-passenger sun visor; see illustration.
G
WARNING
If you secure a child in a child restraint system
on the front-passenger seat and the
PASSENGER AIR BAG OFF indicator lamp is
off, the front-passenger front airbag can
deploy in the event of an accident. The child
could be struck by the airbag. This poses an
increased risk of injury or even fatal injury.
Make sure that the front-passenger front airbag has been disabled. The PASSENGER AIR
BAG OFF indicator lamp must be lit.
NEVER use a rearward-facing child restraint
on a seat protected by an ACTIVE AIRBAG in
front of it; DEATH or SERIOUS INJURY to the
child can occur.
62
Children in the vehicle
Safety
Vehicles without the automatic frontpassenger front airbag deactivation
system
If the front-passenger seat of your vehicle is not
equipped with the automatic front-passenger
front airbag deactivation system, this is indicated by a special sticker. The sticker is affixed to
the side of the dashboard on the frontpassenger side. The sticker is visible when you
open the front-passenger door.
If you turn the key to position 2 in the ignition
lock, the PASSENGER AIR BAG OFF and
PASSENGER AIR BAG ON indicator lamps light
up briefly. However, they have no function and
do not indicate that there is an automatic frontpassenger front airbag deactivation system.
In this case, never fit a rearward-facing child
restraint system on the front passenger seat
(Y page 63).
Observe the following information under "Rearward-facing child restraint system"
(Y page 63) and "Forward-facing child
restraint system" (Y page 63) as well as information on the suitable positioning of the child
restraint system (Y page 63).
Rearward-facing child restraint system
If it is absolutely necessary to fit a rearwardfacing child restraint system on the frontpassenger seat, always make sure that the
front-passenger front airbag is disabled. Only if
the PASSENGER AIR BAG OFF indicator lamp is
lit continuously (Y page 46) is the frontpassenger front airbag disabled.
Always observe the information on suitable
positioning of the child restraint system
(Y page 63) in addition to the child restraint
system manufacturer's installation and operating instructions.
Forward-facing child restraint system
If it is absolutely necessary to fit a forwardfacing child restraint system on the frontpassenger seat, always move the frontpassenger seat as far back as possible. The
entire base of the child restraint system must
always rest on the seat cushion of the frontpassenger seat. The backrest of the child
restraint system must, as far as possible, lie flat
against the backrest of the front-passenger
seat. The child restraint system must not touch
the roof or be put under strain by the head
restraint. Adjust the angle of the seat backrest
and the head restraint position accordingly.
Always make sure that the shoulder belt strap is
correctly routed from the vehicle belt outlet to
the shoulder belt guide on the child restraint
system. The shoulder belt strap must be routed
forwards and downwards from the vehicle belt
outlet. If necessary, adjust the vehicle belt outlet and the front-passenger seat accordingly.
Always observe the information on suitable
positioning of the child restraint system
(Y page 63) in addition to the child restraint
system manufacturer's installation and operating instructions.
Suitable positioning of the child
restraint system
Introduction
Only child restraint systems which are approved
in accordance with the ECE standard ECE R44
are permitted for use in the vehicle.
Child restraint systems belonging to the "Universal" category can be recognised by their
orange approval label and the word "Universal".
Example: approval label on the child restraint system
Children in the vehicle
63
Safety
Z
"Universal" category child restraint systems can
be used on the seats indicated with U, UF or IUF
according to the tables "Suitability of the seats
for attaching belt-secured child restraint systems" or "Suitability of the seats for attaching an
ISOFIX child restraint system".
Semi-universal child restraint systems are indicated by the text "Semi-universal" on the
approval label. These can be used if the vehicle
and the seat are listed in the child restraint system manufacturer's vehicle model list. For more
information, contact the child restraint system
manufacturer or visit their website.
Child restraint system on the co-driver's
seat – if it is absolutely necessary to secure a
child in a child restraint system on the co-driver's seat:
X
Always pay attention to the instructions under
"Child restraint system on the co-driver's
seat" (Y page 62).
There you will find instructions on how to correctly route the shoulder belt strap from the
vehicle belt sash guide to the shoulder belt
guide on the child restraint system
(Y page 63).
X
Move the co-driver's seat as far back as possible.
If you secure a child in a forward-facing child
restraint system on the co-driver's seat, you
must also move the co-driver's seat to the
lowest position.
X
Move the backrest to an almost upright position.
The base of the child restraint system must lie
fully on the co-driver's seat cushion. The
backrest of a forwards-facing child restraint
system must, as far as possible, rest on the
backrest of the co-driver's seat.
The child restraint system may not touch the
roof or be put under strain by the head
restraint. Adjust the angle of the seat backrest and the head restraint position accordingly. Also observe the child restraint system
manufacturer's installation instructions.
Suitability of the seats for attaching belt-secured child restraint systems
Legend for the table:
X Seat that is not suitable for children of this weight category.
U Suitable for child restraint systems in the "Universal" category that are approved for use in this
weight category.
UF Suitable for forward-facing child restraint systems that belong to the "Universal" category and
are approved for use in this weight category.
L Suitable for child restraint systems as recommended; see the table of "Recommended child
restraint systems" (Y page 66). Suitable for semi-universal child restraint systems if the
vehicle and the seat are listed in the child restraint system manufacturer's vehicle model list.
Co-driver's seat
Weight category Co-driver's front air-
bag activated
Co-driver's front airbag
deactivated
1
0
up to 10 kg X
U2, L
0+
up to 13 kg X
U2, L
I
9 kg to 18 kg
UF2, L U2, L
II
15 kg to 25 kg
UF2, L U2, L
III
22 kg to 36 kg
UF2, L U2, L
1
The vehicle is fitted with automatic co-driver front airbag deactivation. The PASSENGER AIR BAG OFF indicator lamp must be lit.
2
In combination with a long belt buckle (police seat) not suitable for child restraint systems.
64
Children in the vehicle
Safety
Rear seats
Weight category Rear seat Rear bench seat:
0
up to 10 kg
U
3
U3, L
3
0+
up to 13 kg
U
3
U3, L
3
I
9 kg to 18 kg
U3, L
3
U3, L
3
II
15 kg to 25 kg U, L U, L
III
22 kg to 36 kg U, L U, L
Suitability of the seats for attaching an ISOFIX child restraint system
If you use a baby car seat of category 0 or 0+ or a rearward-facing child restraint system of category
I on a rear seat, the rear seat must be installed in the direction of travel. Adjust the rear seat and/
or the front seat so that the front seat does not come into contact with the child restraint system.
Legend for the table:
X Seat that is not suitable for children of this weight category.
IUF Suitable for forward-facing ISOFIX child seat securing systems that belong to the "Universal"
category which are approved for use in this weight category.
IL Suitable for ISOFIX child restraint systems as recommended; see the following table of "Rec-
ommended child restraint systems" (Y page 66).
The manufacturer will also recommend a suitable ISOFIX child restraint system. For this, your
vehicle and the seat must be listed in the child restraint system manufacturer's model list. For
more information, contact the child restraint system manufacturer or visit their website.
Weight category Size cate-
gories
Equipment Individual
seat
Rear bench
seat:
Carrycot
F ISO/L1 X
IL
4
G ISO/L2 X
IL
5, 6
0
up to 10 kg
up to approximately
6 months
E ISO/R1
IL
5, 6
0+
up to 13 kg
up to approximately
15 months
E ISO/R1
IL
5, 6
D ISO/R2
IL
5, 6
C ISO/R3
IL
5, 6, 7
3
The seat must be installed in the direction of travel.
4
Only in the first rear seat row on a rear bench seat.
5
The seat must be installed in the direction of travel.
6
A seat in the second rear seat row may only be used if there is the maximum distance between the two rear
seat rows. For this, the seat on the second rear seat row must be installed in the rearmost permitted position
and the seat in front of it on the first rear seat row must be installed in the foremost permitted position. If you
use the middle seat on the second rear seat row, all the seats on the first rear seat row must be in the foremost
permitted position.
7
If you are using a child restraint system of size category C (ISO/R3), make sure that the backrest of the front
seat does not rest against the child restraint system. If possible, move the front seat to the highest position
and the front-seat backrest to an upright position.
Children in the vehicle
65
Safety
Z
Weight category Size cate-
gories
Equipment Individual
seat
Rear bench
seat:
I
9 to 18 kg
between approximately
9 months and 4 years
D ISO/R2
IL
5, 6
C ISO/R3
IL
5, 6, 7
B ISO/F2 IUF
B1 ISO/F2X IUF
A ISO/F3 IUF
The child restraint system must not touch the roof or be subjected to a load by the head restraint.
If possible, adjust the angle of the seat backrest and the head restraint position accordingly. Also
observe the child restraint system manufacturer's installation instructions.
Recommended child restraint systems
General notes
Always observe the information on "Child restraint systems on the co-driver's seat" (Y page 62) and
on "Suitable positioning of the child restraint system" (Y page 63).
You can obtain further information about the correct child restraint system from any Mercedes-Benz
Service Centre.
Recommended child restraint systems for securing with vehicle seat belts
Weight categories Manufac-
turer
Type Approval number
(E1 ...)
Order number
(A 000 ...)
8
Category 0:
up to 10 kg
up to approximately
6 months
Britax Römer BABY SAFE
plus II
04 301146 970 36 00
970 57 00
Category 0+:
up to 13 kg
up to approximately
15 months
Britax Römer BABY SAFE
plus II
04 301146 970 36 00
970 57 00
5
The seat must be installed in the direction of travel.
6
A seat in the second rear seat row may only be used if there is the maximum distance between the two rear
seat rows. For this, the seat on the second rear seat row must be installed in the rearmost permitted position
and the seat in front of it on the first rear seat row must be installed in the foremost permitted position. If you
use the middle seat on the second rear seat row, all the seats on the first rear seat row must be in the foremost
permitted position.
7
If you are using a child restraint system of size category C (ISO/R3), make sure that the backrest of the front
seat does not rest against the child restraint system. If possible, move the front seat to the highest position
and the front-seat backrest to an upright position.
8
Colour code 9H95
66
Children in the vehicle
Safety
Weight categories Manufac-
turer
Type Approval number
(E1 ...)
Order number
(A 000 ...)
8
Category I:
9 kg to 18 kg
between approx-
imately 9 months and
4 years
Britax Römer DUO plus 04 301133 970 37 00
970 58 00
Category II/III:
15 kg to 36 kg
between approx-
imately 4 years and
12 years
Britax Römer KIDFIX 04 301198 970 38 00
970 59 00
Britax Römer KIDFIX XP 04 301304 970 61 00
Suggested "Universal"/"Semi-Universal" category ISOFIX child restraint systems
Weight categories
Size categories
Manufacturer
Type Approval
number
(E1 ...)
Order number
8
Category 0+:
up to 13 kg
E Britax Römer BABY-SAFE
plus
04 301146 B6 6 86 8224
Category I:
9 kg to 18 kg
B1 Britax Römer DUO plus 04 301133 A 000 970 37 00
A 000 970 58 00
Child-proof locks
Important safety notes
G
WARNING
If children are travelling in the vehicle, they
could:
R
open doors, thus endangering other people
or road users
R
exit the vehicle and be caught by oncoming
traffic
R
operate vehicle equipment and become
trapped, for example
There is a risk of an accident and injury.
Always activate the child-proof locks and
override feature if children are travelling in the
vehicle. When leaving the vehicle, always take
the key with you and lock the vehicle. Never
leave children unattended in the vehicle.
Child-proof locks for:
R
Sliding doors (Y page 68)
R
Electric hinged windows in the rear compartment (Y page 68)
G
WARNING
If you leave children unattended in the vehicle, they may be able to set the vehicle in
motion if, for example, they:
R
release the parking brake
R
shift the automatic transmission out of park
position P or shift manual transmission into
neutral
R
start the engine
In addition, they may operate vehicle equipment and become trapped. There is a risk of
an accident and injury.
When leaving the vehicle, always take the key
with you and lock the vehicle. Never leave
children unattended in the vehicle.
8
Colour code 9H95
Children in the vehicle
67
Safety
Z
G
WARNING
If persons (particularly children) are exposed
to heat or cold for a prolonged period, there is
a risk of serious or even fatal injuries. Never
leave persons (particularly children) unattended in the vehicle.
G
WARNING
If the child restraint system is placed in direct
sunlight, the parts could become very hot.
Children could be suffer burns by touching
these parts, in particular on the metallic parts
of the child restraint system. There is a risk of
injury.
If you and your child leave the vehicle, always
make sure that the child restraint system is
not in direct sunlight. Cover it with a blanket,
for example. If the child restraint system has
been exposed to direct sunlight, leave it to
cool down before securing the child in it.
Never leave children unattended in the vehicle.
Child-proof locks for sliding door
Sliding door (example: left side of the vehicle)
:
Child safety bolt
2
Sliding door released
3
Sliding door secured – then make sure that
the child-proof locks are working properly.
You can secure each sliding door individually
with the child-proof locks on the sliding doors.
With the exception of the electric sliding door, a
secured sliding door cannot be opened from the
inside. When the vehicle is unlocked, the sliding
door can be opened from the outside. If the
electric sliding door is secured, only the sliding
door rear controls are deactivated. You can
open the electric sliding door at any time using
the corresponding Å or Æ sliding door
button in the centre console (Y page 84).
Child-proof locks for hinged windows
X
To activate/deactivate: press button :.
If the indicator lamp on the button is lit, operation of the rear-compartment electrical
hinged windows is disabled. Operation is then
only possible using the buttons in the driver's
door.
Pets in the vehicle
G
WARNING
If you leave animals unsupervised or unsecured in the vehicle, they may push a button
or a switch, for example.
They could:
R
activate vehicle equipment and become
trapped, for example
R
switch vehicle systems on or off, thus
endangering other road users
In the event of an accident, sudden braking or
abrupt changes of direction, unsecured animals could be flung around the vehicle, injuring the vehicle occupants. There is a risk of an
accident and injury.
Never leave animals unattended in the vehicle. Always secure animals correctly during a
journey, e.g. in an animal transport box.
68
Pets in the vehicle
Safety
Driving safety systems
Overview
This section contains information on the following driving safety systems:
R
EBD (Electronic Brake Force Distribution)
R
ABS (Anti-lock Braking System)
R
BAS (Brake Assist System)
R
ESP® (Electronic Stability Program)
R
Adaptive brake lights
Important safety notes
If you fail to adapt your driving style or if you are
inattentive, the driving safety systems can neither reduce the risk of an accident nor override
the laws of physics. Driving safety systems are
merely aids designed to assist driving. You are
responsible for the distance to the vehicle in
front, for vehicle speed, braking in good time
and for staying in your lane. Always adapt your
driving style to the prevailing road and weather
conditions and maintain a sufficient, safe distance from other road users. Drive carefully.
Please note that the driving safety systems
described only work optimally when:
R
there is adequate contact between the tyres
and the road surface
R
you use winter tyres (M+S tyres), with snow
chains if necessary, when the road conditions
are wintry
R
the speed information determined by the
vehicle is within the legally prescribed display
accuracy
Pay particular attention to the information
regarding tyres, coding of the wheel size groups,
tyre tread and winter operation under "Wheels
and tyres" (Y page 365).
ABS (Anti-lock Braking System)
General notes
ABS controls the braking pressure so that the
wheels do not lock when braking. This maintains
the steerability of your vehicle while braking.
The ! warning lamp in the instrument cluster
lights up when the ignition is switched on. The
lamp goes out when the engine starts running.
Important safety notes
Observe the important safety guidelines for the
driving safety system (Y page 69).
ABS works from a speed of about 8 km/h
upwards, regardless of road surface conditions.
On a slippery road surface, ABS intervenes even
if you only brake gently.
G
WARNING
If ABS is faulty, the wheels could lock when
braking. The steerability and braking characteristics may be severely impaired. Additionally, further driving safety systems are deactivated. There is an increased danger of skidding and accidents.
Drive on carefully. Have ABS checked immediately at a qualified specialist workshop.
If ABS is malfunctioning, the ! warning lamp
(Y page 286) lights up while the engine is running and the display shows a message
(Y page 261). BAS, Hill Start Assist and ESP
®
and its driving safety systems and other driving
systems also fail. Observe the notes on the !
warning lamp and the display messages.
Braking
If ABS intervenes when braking, you will feel a
pulsating in the brake pedal.
The pulsating brake pedal can be an indication
of hazardous road conditions and functions as a
reminder to take extra care while driving.
X
If ABS intervenes: keep the brake pedal
firmly depressed until the braking situation
has passed.
X
To make a full brake application: depress
the brake pedal with full force.
BAS (Brake Assist)
General notes
Brake Assist operates in emergency braking situations. If you depress the brake pedal quickly,
BAS automatically boosts the braking force,
thus shortening the stopping distance.
Driving safety systems
69
Safety
Z
Important safety notes
Observe the important safety guidelines for the
driving safety system (Y page 69).
G
WARNING
If BAS is malfunctioning, the braking distance
in an emergency braking situation is
increased. There is a risk of accident.
In an emergency braking situation, depress
the brake pedal with full force. ABS prevents
the wheels from locking.
If BAS is malfunctioning, the ÷ warning lamp
lights up while the engine is running
(Y page 287) and the display shows a message
(Y page 265).
Braking
X
Keep the brake pedal depressed firmly until
the emergency braking situation is over.
ABS prevents any of the wheels from locking.
When you release the brake pedal, the brakes
function as usual again. BAS is deactivated.
EBD (electronic brake force distribution)
General notes
EBD monitors and controls the brake pressure
to the rear wheels. This enables EBD to improve
handling during braking.
Important safety notes
Observe the important safety guidelines for the
driving safety system (Y page 69).
G
WARNING
If EBD is malfunctioning, the rear wheels can
lock, e.g. under full braking. This increases the
risk of skidding and an accident.
You should therefore adapt your driving style
to the different handling characteristics. Have
the brake system checked at a qualified specialist workshop.
If EBD is malfunctioning, the J warning lamp
(Y page 285) lights up while the engine is running and the display shows a message
(Y page 265). Other driving systems and driving
safety systems then also fail.
ESP® (Electronic Stability Program)
General notes
ESP® monitors driving stability and detects
understeering or oversteering (skidding) in good
time. If ESP® detects that the vehicle is deviating from the direction desired by the driver, one
or more wheels are braked to stabilise the vehicle. The engine output is also modified to keep
the vehicle on the desired course within physical
limits. ESP® can also stabilise the vehicle during
braking.
ESP® also monitors traction, i.e. power transmission between the tyres and the road surface.
The integrated traction control supports you
when pulling away or accelerating on wet, slippery or slick roads. Should the drive wheels spin,
traction control brakes them individually. In
addition, greater drive torque is transmitted to
the wheel or wheels with traction. If traction on
the road surface is not sufficient, even ESP® will
not allow you to pull away without difficulty. The
type of tyres and total weight of the vehicle as
well as the gradient of the road also play a crucial role. Traction control remains active if you
deactivate ESP®.
If the h warning lamp in the instrument clus-
ter goes out before beginning the journey, ESP
®
is automatically active.
The h warning lamp in the instrument cluster
flashes when ESP® intervenes:
X
Do not deactivate ESP® under any circumstances.
X
when pulling away, only depress the accelerator pedal as far as required
X
Adapt your driving style to suit the prevailing
road and weather conditions.
Important safety notes
Observe the important safety guidelines for the
driving safety system (Y page 69).
G
WARNING
If ESP® is malfunctioning it will not provide
any vehicle stabilisation. There is an
increased risk of skidding or of an accident.
70
Driving safety systems
Safety
Exercise caution when continuing to drive.
Have ESP® checked at a qualified specialist
workshop.
!
Do not operate the vehicle on a roller dynamometer (e.g. for performance testing). If you
have to operate the vehicle on a roller dynamometer, please consult a specialist workshop beforehand. You could otherwise damage the drivetrain or the brake system.
If ESP® is malfunctioning, the h warning
lamp (Y page 287) lights up continuously while
the engine is running and the display shows a
message (Y page 265).
ESP® is deactivated if the å warning lamp in
the instrument cluster is lit when the engine is
running.
Use only wheels with the recommended tyre
sizes. Only then will ESP® function properly.
Deactivating or activating ESP
®
G
WARNING
If you deactivate ESP®, ESP® no longer stabilises the vehicle. There is an increased risk
of skidding and an accident.
Only deactivate ESP® in the situations described in the following.
It may be best to deactivate ESP® in the following situations:
R
if snow chains are being used
R
in deep snow
R
on sand or gravel
Activate ESP® as soon as the situations described above no longer apply. Otherwise, ESP
®
assistance for stabilising the vehicle will remain
significantly reduced, even if the vehicle starts
to skid.
If you deactivate ESP®:
R
the å warning lamp in the instrument clus-
ter lights up
R
the ÷ warning lamp in the instrument clus-
ter flashes if the wheels are spinning
R
ESP® assistance for stabilising the vehicle in
the lower speed range up to approximately
60 km/h is significantly reduced
R
engine torque is no longer limited and the
drive wheels are able to spin. The spinning of
the wheels results in a cutting action for better traction on loose surfaces
R
traction control is still activated
R
ESP® still provides support when you brake.
You can activate or deactivate ESP® via the onboard computer when the engine is running
(Y page 256).
Trailer stabilisation
Observe the important safety guidelines for the
driving safety system (Y page 69).
G
WARNING
If road and weather conditions are poor,
trailer stabilisation will not be able to prevent
the vehicle/trailer combination from swerving. Trailers with a high centre of gravity can
tip over before ESP® can detect this. There is
a risk of an accident.
Always adapt your driving style to the prevailing road and weather conditions.
ESP® trailer stabilisation counteracts critical
driving situations in good time and thereby provides considerable assistance when driving with
a trailer. Trailer stabilisation is part of ESP®.
If the sensor system and evaluation logic detect
trailer swinging movements, ESP® trailer stabilisation firstly brakes individual vehicle wheels in
a targeted manner. It thus counteracts swinging
movements. If the swinging movements do not
stop, the vehicle is braked until the vehicle/
trailer combination is stabilised. If necessary,
the vehicle's engine output is limited.
If your vehicle with trailer (vehicle/trailer combination) starts to swerve, you will be able to
stabilise the vehicle/trailer combination only by
braking. ESP® trailer stabilisation helps you to
stabilise the vehicle/trailer combination in this
situation.
ESP® trailer stabilisation is active above speeds
of about 65 km/h.
If ESP® is switched off or deactivated because of
a malfunction, the trailer stabilisation system
will not function.
Driving safety systems
71
Safety
Z
Crosswind Assist
Observe the important safety guidelines for the
driving safety system (Y page 69).
Strong crosswind gusts can impair the roadholding of your vehicle when driving straight
ahead. The Crosswind Assist function integra-
ted in ESP® reduces these impairments.
Depending on the direction and intensity of the
side wind, Crosswind Assist intervenes automatically. ESP® intervenes with stabilising brak-
ing to assist you in keeping the vehicle in the
lane. When Crosswind Assist intervenes, the
display shows the traffic sign for strong side
winds and the Crosswind Assist message.
Crosswind Assist is activated automatically
above a speed of approximately 80 km/h when
driving straight ahead or cornering gently.
Crosswind Assist does not react:
R
in the event of severe jolts and vibrations, e.g.
when driving over uneven surfaces or potholes
R
when grip is reduced, e.g. on snow or ice or
when aquaplaning
Crosswind Assist does not work if ESP® is deactivated or disabled because of a malfunction.
Adaptive brake lights
In an emergency braking situation, the adaptive
brake lights warn following traffic:
R
by flashing brake lamps
R
the hazard warning lamps are activated
If you brake sharply from a speed of more than
50 km/h or if braking is assisted by BAS, the
brake lamps flash rapidly.
If you brake sharply from a speed of more than
70 km/h to a standstill, the hazard warning
lamps are activated automatically. The brake
lamps light up again constantly when you
depress the brake pedal. The hazard warning
lamps switch off automatically if you travel
faster than 10 km/h. You can also switch off the
hazard warning lamps with the hazard warning
lamp button (Y page 128).
Anti-theft systems
Immobiliser
X
To activate: remove the key from the ignition
lock.
X
To deactivate: turn the key to position 2 in
the ignition lock.
The immobiliser prevents your vehicle from
being started without the correct key.
Always take the key with you and lock the vehicle when leaving the vehicle. If you leave the key
in the vehicle, anyone can start the engine.
i
Starting the engine always deactivates the
immobiliser.
ATA (Anti-Theft Alarm system)
X
To prime: lock the vehicle with the key.
Indicator lamp : in the overhead control
panel flashes.
X
To deactivate: unlock the vehicle with the
key.
or
X
Insert the key into the ignition lock.
If the alarm system is primed, a visual and audible alarm is triggered when the following are
opened:
R
a door
R
the vehicle with the emergency key element
R
the tailgate
R
the bonnet
X
To stop the alarm: press the % or &
button on the key.
or
X
Insert the key into the ignition lock.
The alarm stops.
72
Anti-theft systems
Safety
The alarm is not switched off, even if you immediately close the open door that had triggered it,
for example.
Tow-away protection
Function
A visual and audible alarm is triggered if the
inclination of the vehicle changes when towaway protection is primed. This can be the case
if the vehicle is raised on one side, for example.
Activating
X
Make sure that:
R
the doors are closed
R
the tailgate is closed
Only then is the tow-away protection primed.
X
Lock the vehicle with the key.
Tow-away protection is primed after approximately 50 seconds.
Switching off
X
Unlock the vehicle with the key.
or
X
Insert the key into the ignition lock.
Tow-away protection is switched off automatically.
Deactivating
X
Remove the key from the ignition lock.
X
Press button :.
When the button is released, the indicator
lamp in the button lights up for about three
seconds.
X
Lock the vehicle.
Tow-away protection is deactivated.
Tow-away protection remains deactivated until
you lock the vehicle again.
Deactivate tow-away protection when locking
your vehicle and:
R
loading and/or transporting the vehicle, on a
ferry or car transporter, for example
R
parking on a movable surface, such as splitlevel garage
This will prevent false alarms.
Interior motion sensor
Function
If the primed interior motion sensor detects
motion in the vehicle interior, a visual and acoustic alarm is triggered. This can happen if someone reaches into the vehicle interior, for example.
Activating
X
Make sure that:
R
the side windows are closed
R
there are no objects, e.g. mascots, hanging
on the rear-view mirror or on the grab handles on the roof trim.
This will prevent false alarms.
X
Make sure that:
R
the doors are closed
R
the tailgate is closed
Only then is the interior motion sensor
primed.
X
Lock the vehicle with the key.
The interior motion sensor is primed after
approximately 20 seconds.
Switching off
X
Unlock the vehicle with the key.
or
X
Insert the key into the ignition lock.
The interior motion sensor automatically
switches off.
Anti-theft systems
73
Safety
Z
Deactivating
X
Remove the key from the ignition lock.
X
Press button :.
When the button is released, the indicator
lamp in the button lights up for about three
seconds.
X
Lock the vehicle.
The interior motion sensor is deactivated.
The interior motion sensor remains deactivated
until you lock the vehicle again.
Deactivate the interior motion sensor when
locking your vehicle:
R
with people or animals remaining inside
R
when transporting it on a ferry or car transporter, for example
This will prevent false alarms.
74
Anti-theft systems
Safety
Useful information
These Operating Instructions describe all models as well as standard and optional equipment
of your vehicle that were available at the time of
going to print. Country-specific variations are
possible. Note that your vehicle may not be fitted with all of the described functions. This also
applies to safety-relevant systems and functions.
Read the information on qualified specialist
workshops: (Y page 31).
Key
Important safety notes
United Kingdom only:
G
WARNING
When the double locks are activated, the
doors can no longer be opened from the
inside. People in the vehicle can no longer get
out, e.g. in hazardous situations. There is a
risk of injury.
Therefore, do not leave any people unsupervised in the vehicle, particularly children, elderly people or people in need of special assistance. Do not activate the double lock when
people are in the vehicle.
If the vehicle has been locked from the outside,
the double-lock function is activated as standard. It is then not possible to open the doors
from inside the vehicle. You can deactivate the
double lock function by deactivating the interior
motion sensor (Y page 74). The doors can then
be opened from the inside after the vehicle has
been locked from the outside. The anti-theft
alarm system is triggered if a door is opened
from the inside. Switch off the alarm
(Y page 72).
All countries:
G
WARNING
If you leave children unattended in the vehicle, they may be able to set the vehicle in
motion if, for example, they:
R
release the parking brake
R
shift the automatic transmission out of park
position P or shift manual transmission into
neutral
R
start the engine
In addition, they may operate vehicle equipment and become trapped. There is a risk of
an accident and injury.
When leaving the vehicle, always take the key
with you and lock the vehicle. Never leave
children unattended in the vehicle.
G
WARNING
If you attach heavy or large objects to the key,
the key could be unintentionally turned in the
ignition lock. This could cause the engine to
be switched off. There is a risk of an accident.
Do not attach any heavy or large objects to the
key. Remove any bulky keyrings before inserting the key into the ignition lock.
!
Keep the key away from strong magnetic
fields. Otherwise, the remote control function
could be affected.
Strong magnetic fields can occur in the vicinity of powerful electrical installations.
Do not keep the key:
R
with electronic devices, e.g. a mobile phone
or another key
R
with metallic objects, e.g. coins or metal foil
R
in metallic objects, e.g. metal cases
This can affect the key's functionality.
Key
75
Opening and closing
Z
Key functions
Key (example: vehicles with an EASY-PACK tailgate
and/or rear window which can be opened separately)
:
Battery check lamp
;
q To open or close the EASY-PACK tailgate or unlock the rear window which can be
opened separately
=
& To lock the vehicle centrally
?
5 To unlock the EASY-PACK tailgate and
sliding doors or to unlock and open or close
the electric sliding door
A
Emergency key element
B
% To unlock the vehicle centrally or
unlock the front door(s) only
The vehicle's equipment includes two keys.
There is an emergency key element in each key.
The key can be used to unlock the vehicle from
a distance. To prevent theft, only use the key in
the immediate vicinity of the vehicle.
Change the batteries immediately if battery
check lamp : does not light up briefly with
every press of a button (Y page 78).
X
To unlock centrally: press the % button.
The turn signals flash once.
X
To unlock the sliding doors and the tailgate only: press the 5 button.
The turn signals flash once.
If you do not open the vehicle within approximately 40 seconds of unlocking:
R
the vehicle is locked again
R
the anti-theft protection is primed again
X
To lock centrally: press the & button.
The turn signals flash three times if:
R
the anti-theft protection is primed
R
all the doors and the tailgate are closed
X
Check the locking knobs on all the doors.
The locking knobs must all be in the lowered
position.
The key's factory setting enables you to centrally lock and unlock the following:
R
the driver's and the co-driver's door
R
the sliding doors
R
the tailgate
In an emergency, the driver's door can also be
unlocked manually using the emergency key
element (Y page 77).
You can also set an audible signal to confirm
that the vehicle has been locked. The audible
signal can be activated and deactivated via the
multimedia system. Information on activating
and deactivating the audible locking-verification
signal can be found in the separate operating
instructions.
When the surround lighting is activated in the
multimedia system, it comes on when it is dark
after the vehicle is unlocked using the remote
control. Information on activating and deactivating the surround lighting can be found in the
separate operating instructions.
X
To open or close the EASY-PACK tailgate
automatically from the outside: press the
q button until the tailgate opens or closes.
Changing the settings of the locking
system
If you predominantly travel alone, you may wish
to change the settings of the locking system.
Press the % button to unlock the driver's
door.
X
To change the setting: press and hold down
the % and & buttons simultaneously
until the battery check lamp flashes twice
(Y page 76).
If the setting of the locking system is changed
within the signal range of the vehicle, press the
& or % button to:
R
lock or
R
unlock the vehicle
76
Key
Opening and closing
The key now functions as follows:
X
To unlock the driver's door: press the %
button once.
X
To unlock centrally: briefly press the %
button twice.
X
To lock centrally: press the & button.
X
To restore factory settings: press and hold
down the % and & buttons simultaneously until the battery check lamp flashes
twice (Y page 76).
The key unlocks the vehicle centrally again.
Emergency key element
General notes
If the vehicle can no longer be locked or
unlocked with the key, use the emergency key
element.
The anti-theft alarm system (ATA) is triggered
when you unlock and open the vehicle using the
emergency key element (Y page 72).
The alarm can be stopped in the following two
ways:
X
Press the % or & button on the key.
or
X
Insert the key into the ignition lock.
Removing the emergency key element
X
Slide release catch : in the direction of the
arrow and, at the same time, remove emergency key element ; from the key completely.
Inserting the emergency key element
X
Push emergency key element ; completely
into the key until it engages and release
catch : is back in its basic position.
Locking/unlocking the vehicle using
the emergency key element
The door lock for unlocking in an emergency is
on the driver's door.
X
To unlock the driver's door: insert the emergency key element fully into the driver's door
lock and turn it anti-clockwise.
The driver's door is unlocked.
X
To lock the vehicle: lock all doors except the
driver's door from the inside. To do this, push
down the door-locking knobs.
X
Insert the emergency key element fully into
the driver's door lock and turn it clockwise.
On right-hand-drive vehicles, turn the emergency key element anti-clockwise.
The driver's door is locked.
Battery of the key
Important safety notes
G
WARNING
Batteries contain toxic and corrosive substances. If batteries are swallowed, it can result in
severe health problems. There is a risk of fatal
injury.
Keep batteries out of the reach of children. If
a battery is swallowed, seek medical attention
immediately.
H
Environmental note
Batteries contain pollutants.
It is illegal to dispose of them
with the household rubbish.
They must be collected separately and disposed of in an
environmentally responsible
recycling system.
Dispose of batteries in an
environmentally responsible
manner. Take discharged
Key
77
Opening and closing
Z
batteries to a qualified specialist workshop or to a collection point for used batteries.
Mercedes-Benz recommends that you have the
battery changed at a qualified specialist workshop.
Checking the battery
X
Press the & or % button.
If battery check lamp : lights up briefly, the
battery is sufficiently charged.
If battery check lamp : does not light up
briefly, the battery is empty.
X
Change the battery (Y page 78).
If the key battery is checked within the signal
range of the vehicle, pressing the & or %
button results in:
R
locking or
R
unlocking the vehicle
i
The battery may be obtained at any qualified
specialist workshop.
Changing the battery
You need a type CR 2025 3 V cell battery.
X
Pull out the emergency key element from the
key (Y page 77).
X
Push emergency key element ; into the
opening in the key in the direction of the arrow
until battery compartment cover : opens.
When doing so, do not hold battery compartment cover : shut.
X
Remove battery compartment cover :.
X
Tap the key against the palm of your hand so
that battery = falls out of the battery compartment.
X
Insert the new battery into the battery tray
with the positive pole facing upwards. Use a
lint-free cloth to do so.
X
Fit battery compartment cover : to the key
casing with the front lugs first and push
closed.
X
Slide emergency key element ; back into
the key (Y page 77).
X
Check the function of all key buttons on the
vehicle.
78
Key
Opening and closing
Problems with the key
Problem
Possible causes/consequences and M Solutions
It is no longer possible to
lock the vehicle using
the key.
The turn signals do not
flash when the vehicle is
locked.
The doors are not closed properly.
X
Close the doors properly and lock the vehicle again.
The central locking system has malfunctioned.
X
Lock the vehicle using the emergency key element (Y page 77) or
press down the locking knob and then close the doors.
X
Have the central locking system checked as soon as possible at a
qualified specialist workshop.
It is no longer possible to
lock or unlock the vehicle using the key.
The key battery is weak or discharged.
X
Point the tip of the key at the driver's door handle from very close
range and press the % or & button.
If this does not work:
X
Replace the key battery (Y page 78).
or
X
Lock or unlock the vehicle using the emergency key element
(Y page 77).
The key is faulty.
X
Lock the vehicle with the emergency key element (Y page 77).
X
Have the key checked at a qualified specialist workshop.
The engine cannot be
started using the key.
The on-board voltage is too low.
X
Switch off all non-essential consumers, such as interior lighting, and
try to start the engine again.
If this does not work:
X
Check the starter battery and charge it if necessary (Y page 349).
or
X
Jump-start the vehicle (Y page 358).
or
X
Consult a qualified specialist workshop.
You have lost a key.
X
Have the key deactivated at a qualified specialist workshop.
X
Report the loss immediately to the vehicle insurers.
X
If necessary, have the mechanical locks replaced.
You have lost the emergency key element.
X
Report the loss immediately to the vehicle insurers.
X
If necessary, have the mechanical locks replaced.
Central locking
Important safety notes
United Kingdom only:
G
WARNING
When the double locks are activated, the
doors can no longer be opened from the
inside. People in the vehicle can no longer get
Central locking
79
Opening and closing
Z
out, e.g. in hazardous situations. There is a
risk of injury.
Therefore, do not leave any people unsupervised in the vehicle, particularly children, elderly people or people in need of special assistance. Do not activate the double lock when
people are in the vehicle.
If the vehicle has been locked from the outside,
the double-lock function is activated as standard. It is then not possible to open the doors
from inside the vehicle. The doors can be
opened from the inside after the vehicle has
been locked from the outside. The anti-theft
alarm system is triggered if a door is opened
from the inside. Switch off the alarm
(Y page 72).
All countries:
G
WARNING
If children are left unsupervised in the vehicle,
they could:
R
open doors, thereby endangering other persons or road users
R
get out and be struck by oncoming traffic
R
operate vehicle equipment and become
trapped, for example
In addition, the children could also set the
vehicle in motion, for example, if they:
R
release the parking brake
R
shift the automatic transmission out of park
position P or shift manual transmission into
neutral
R
start the engine
There is a risk of an accident and injury.
When leaving the vehicle, always take the key
with you and lock the vehicle. Never leave
children and animals unattended in the vehicle. Keep the keys out of the reach of children.
G
WARNING
If persons (particularly children) are exposed
to heat or cold for a prolonged period, there is
a risk of serious or even fatal injuries. Never
leave persons (particularly children) unattended in the vehicle.
For all countries except the United Kingdom:
You can open a locked door from the inside at
any time. For the sliding doors, the child-proof
locks must be deactivated.
Centrally locking and unlocking the
vehicle from the inside
You can centrally lock and unlock the whole
vehicle from the inside using the central locking
buttons on the driver's door.
Central locking buttons (vehicles with manually
adjustable front seats)
Central locking buttons (vehicles with electrically
adjustable front seats)
X
To unlock: press the % button.
X
To lock: press the & button.
If the driver's or co-driver's door is open, the
open door is not locked.
All other doors and the tailgate are locked.
If a sliding door or the tailgate is open, only the
driver's and co-driver's doors are locked.
You cannot unlock the vehicle centrally from the
inside if the vehicle has been locked with the
key.
If the vehicle has been locked using the locking
button for the central locking and a door is
80
Central locking
Opening and closing
opened from the inside, only the door that has
been opened is unlocked.
For all countries except the United Kingdom:
If the vehicle has previously been locked with
the key, opening a door from the inside will trigger the anti-theft alarm system. Switch off the
alarm (Y page 72).
Automatic locking feature
Central locking buttons (vehicles with manually
adjustable front seats)
Central locking buttons (vehicles with electrically
adjustable front seats)
X
To switch on: press and hold the % button
until an acoustic tone sounds.
X
To switch on: press and hold the & button
until an acoustic tone sounds.
When the ignition is switched on, your vehicle
will lock automatically from a speed of approximately 15 km/h.
You could therefore be locked out if:
R
the vehicle is being pushed.
R
the vehicle is being towed.
R
the vehicle is being tested on a dynamometer.
If the vehicle has been automatically locked and
a front door is opened from the interior while the
vehicle is stationary, the vehicle unlocks centrally.
i
You can also switch the automatic locking
function on and off using the multimedia system (see the separate operating instructions).
Driver's door and co-driver's door
United Kingdom only: if the vehicle has been
locked with the key, the double lock function is
activated as standard. It is then not possible to
open the doors from inside the vehicle. You can
deactivate the double lock function by deactivating the interior motion sensor (Y page 74).
The doors can then be opened from the inside
after the vehicle has been locked from the outside. You can then only open the sliding doors
from inside the vehicle if they are not secured by
the child-proof locks (Y page 68). The anti-theft
alarm system is triggered if a door is opened
from the inside. Switch off the alarm
(Y page 73).
For all countries except the United Kingdom:
You can open the driver's or co-driver's door
from the inside at any time, even if it is locked. If
the vehicle has previously been locked with the
key, opening a door from the inside will trigger
the anti-theft alarm system. Switch off the alarm
(Y page 73).
Door handle (example driver's door)
You can open the driver's or co-driver's door
from the inside at any time, even if it is locked.
X
Pull door handle ;.
If a front door is locked, locking knob : pops
up. The door is unlocked and opens.
Driver's door and co-driver's door
81
Opening and closing
Z
Sliding door
Important safety notes
G
WARNING
When you open the sliding door, the sliding
door could hit other people as it moves backwards. There is a risk of injury.
Only open the sliding door when traffic conditions permit.
G
WARNING
If the open sliding door is not engaged, it could
move on its own if the vehicle is on a slope.
This could trap you or other persons. There is
a risk of injury.
Always make sure that the open sliding door is
engaged.
!
Do not use the lower guide on the sliding
door (carriage) as a step. You could otherwise
damage its trim and/or the mechanism of the
sliding door
Opening and closing from the outside
The sliding door is equipped with an active
retainer, which engages the door at the end stop
when opened.
X
To open: pull door handle : in the direction
of the arrow.
The sliding door opens.
X
Push back the sliding door using door handle : until it engages.
X
Check the sliding door detent.
X
To close: pull door handle : in the direction
of the arrow.
The sliding door is released from its detent.
X
Push the sliding door forwards using door
handle : and close.
Opening and closing from the inside
The sliding door is equipped with an active
retainer, which engages the door at the end stop
when opened.
X
To open: pull back rocker switch :.
If the door is locked, locking knob = pops up.
The sliding door unlocks and opens.
X
Push back the sliding door using door handle ; until it engages
X
Check the sliding door detent.
X
To close: press rocker switch : forwards.
The sliding door is released from its detent.
X
Push the sliding door forwards using door
handle ; and close.
Electric sliding door
Important safety notes
G
WARNING
When you open the sliding door, the sliding
door could hit other people as it moves backwards. There is a risk of injury.
Only open the sliding door when traffic conditions permit.
!
Do not use the lower guide on the sliding
door (carriage) as a step. You could otherwise
damage its trim and/or the mechanism of the
sliding door
82
Electric sliding door
Opening and closing
You must reset the electric sliding door if there
has been a malfunction or an interruption in the
voltage supply (Y page 85).
Obstacle detection with reversing
function
The sliding door is equipped with automatic
obstacle detection with reversing feature. If a
solid object blocks or restricts the sliding door
during the automatic closing process, the sliding door opens again automatically. If the sliding
door is obstructed during the opening procedure, it moves back a few centimetres in the
opposite direction and stops.
Automatic obstacle detection with reversing
feature is only an aid. It is not a substitute for
your attentiveness when closing the electrical
sliding door.
If an obstacle is detected, the display shows the
Left-hand electric sliding door
Obstruction detected message for example,
and five warning tones sound.
G
WARNING
The reversing feature does not react:
R
to soft, light and thin objects, e.g. small fingers
R
over the last 8 mm of the closing movement
The reversing feature therefore cannot prevent someone being trapped in these situations. There is a risk of injury.
When closing, make sure that no-one has any
parts of the body within the closing area.
If someone is trapped:
R
press the 5 button on the key or
R
pull the exterior door handle or
R
press the respective sliding door button in
the centre console or
R
press the button on the door frame or
R
pull the rocker switch on the door handle
Opening/closing from the outside
The sliding door is equipped with an active
retainer, which engages the door at the end stop
when opened.
If the vehicle is fitted with two sliding doors; the
5 button on the key can only be used to open
or close one of the two sliding doors
(Y page 85).
X
To open: pull door handle : in the direction
of the arrow.
or
X
Press the 5 button on the key for longer
than 0.5 seconds.
The sliding door unlocks, automatic operation
is started and the sliding door opens. In addition, you will hear two warning signals.
X
To close: pull door handle : in the direction
of the arrow.
or
X
Press the 5 button on the key for longer
than 0.5 seconds.
The sliding door is released from its lock and
automatic operation is started. The sliding
door closes.
If you press the 5 button on the key, you
will hear two warning signals while the doors
close.
X
To interrupt automatic operation: pull door
handle : again.
or
X
Press the 5 button on the key again.
i
In unfavourable operating conditions, e.g.
frost, ice or heavy soiling, you can press and
hold the relevant sliding door button. The
electric sliding door moves with increased
force. Observe that, in such circumstances,
the obstacle detection is less sensitive. To
Electric sliding door
83
Opening and closing
Z
stop the movement, release the sliding door
button.
Opening/closing from the inside
You can open and close the sliding door from the
inside with these controls:
R
the Å or Æ sliding door button in the
front on the lower centre console
R
the sliding door button on the B-pillar next to
the door sill
R
the rocker switch on the door handle
:
Sliding door button for the sliding door on
the left-hand side
;
Sliding door button for the sliding door on
the right-hand side
=
Rocker switch
?
Locking knob
A
Sliding door button in the door frame
You can only open a sliding door with sliding
door button A in the door sill or with rocker
switch = on the door handle if the child-proof
lock has not been activated.
The sliding door is equipped with an active
retainer, which engages the door at the end stop
when opened.
X
To open: briefly press the respective Å or
Æ sliding door button in the centre con-
sole.
or
X
Briefly press sliding door button A in the
door frame.
or
X
Briefly pull back rocker switch =.
If the door is locked, locking knob ? pops up.
The sliding door unlocks, automatic operation
is started and the sliding door opens.
If you use the Å or Æ sliding door button in the centre console you will hear two
warning signals during the opening procedure.
The indicator lamp in the Å or Æ sliding
door button in the centre console flashes for
the duration of automatic operation.
The indicator lamp in the Å or Æ sliding
door button in the centre console is lit whenever the respective sliding door is open.
Depending on the vehicle equipment, the display can also show the Sliding door open
message.
X
To close: briefly press the respective Å or
Æ sliding door button in the centre con-
sole.
or
X
Briefly press sliding door button A in the
door frame.
or
X
Briefly press rocker switch = forwards.
The sliding door is released from its lock and
automatic operation is started. The sliding
door closes.
If you use the Å or Æ sliding door button in the centre console you will hear two
warning signals during the opening procedure.
The indicator lamp in the respective Å or
Æ sliding door button in the centre console
goes out whenever the sliding door is closed.
X
To interrupt automatic operation: press
the respective Å or Æ sliding door but-
ton in the centre console again.
or
X
Press sliding door button in the door frame
A.
or
X
Briefly pull back rocker switch =.
84
Electric sliding door
Opening and closing
i
In unfavourable operating conditions, e.g.
frost, ice or heavy soiling, you can press and
hold the relevant sliding door button. The
electric sliding door moves with increased
force. Observe that, in such circumstances,
the obstacle detection is less sensitive. To
stop the movement, release the sliding door
button.
Programming the key button for the
sliding door
If the vehicle is fitted with two electric sliding
doors, the 5 sliding door button on the key
can only be programmed for one of the two sliding doors. You can then open or close the selected sliding door with the 5 button on the key.
:
Sliding door button for sliding door on the
left-hand side
;
Sliding door button for sliding door on the
right-hand side
X
Make sure that the sliding door to be programmed is open.
X
Turn the key to position 2 in the ignition lock.
X
Press and hold the Å or Æ sliding door
button in the centre console for the appropriate sliding door until the sliding door is closed
and five tones have sounded.
The display shows the Left-hand elec‐
tric sliding door key programmed/
Right-hand electric sliding door
key programmed message.
Resetting the sliding door
You must reset the sliding door if there has been
a malfunction or an interruption in the voltage
supply.
X
If the sliding door is open: close it by hand.
X
Using the Å or Æ sliding door button on
the centre console, open the sliding door at
least 40 cm and then close the sliding door
completely.
X
When the sliding door is closed, open the sliding door fully using the Å or Æ sliding
door button on the centre console.
The sliding door is reset and operational.
X
Close the sliding door if required.
Problems with the sliding door
The electric sliding door is locked in place.
Unfavourable operating conditions, e.g. frost,
ice or heavy soiling, may obstruct the sliding
door.
X
Press and hold the sliding door button until
the sliding door has opened or closed.
The sliding door moves with increased force.
Observe that, in such circumstances, the
obstacle detection is less sensitive. To stop
the movement, release the sliding door button.
X
Remove the cause of the blockage at the earliest opportunity.
Tailgate
Important safety notes
G
WARNING
Combustion engines emit poisonous exhaust
gases such as carbon monoxide. If the tailgate
is open when the engine is running, particularly if the vehicle is moving, exhaust fumes
could enter the passenger compartment.
There is a risk of poisoning.
Turn off the engine before opening the tailgate. Never drive with the tailgate open.
!
When opening, the tailgate swings up and
out. Therefore, make sure that there is suffi-
Tailgate
85
Opening and closing
Z
cient clearance above and behind the tailgate.
You will find details of the tailgate opening
dimensions under "Technical data"
(Y page 395).
Opening and closing
X
To open: press button : on the handle.
X
Raise the tailgate.
X
To close: pull the tailgate firmly downwards
by strap ; and close it from outside.
Problems with the tailgate
The tailgate cannot be opened.
The voltage supply has been interrupted or the
battery charge is insufficient.
Consult a qualified specialist workshop which
has the necessary specialist knowledge and
tools to carry out the work required.
In an emergency, you can open the tailgate
using the release catch for service purposes.
X
Prise off the cover on the lower part of the
tailgate with a suitable tool, e.g. the screwdriver from the vehicle tool kit.
X
Insert the screwdriver into the opening and
move the release lever until the tailgate
unlocks and opens.
X
Swing the tailgate upwards.
EASY-PACK tailgate
Important safety notes
G
WARNING
Combustion engines emit poisonous exhaust
gases such as carbon monoxide. If the tailgate
is open when the engine is running, particularly if the vehicle is moving, exhaust fumes
could enter the passenger compartment.
There is a risk of poisoning.
Turn off the engine before opening the tailgate. Never drive with the tailgate open.
!
When opening, the tailgate swings up and
out. Therefore, make sure that there is sufficient clearance above and behind the tailgate.
You can set the opening angle of the tailgate
(Y page 88).
You will find details of the maximum tailgate
opening dimensions under "Technical data"
(Y page 395).
Obstacle detection with reversing
function
The tailgate is equipped with automatic obstacle
detection with reversing feature. If a solid object
blocks or restricts the tailgate during the automatic closing process, the tailgate opens again
automatically. Automatic obstacle detection
with reversing feature is only an aid. It is not a
substitute for your attentiveness when closing
the tailgate.
86
EASY-PACK tailgate
Opening and closing
G
WARNING
The reversing feature does not react:
R
to soft, light and thin objects, e.g. small fingers
R
over the last 8 mm of the closing movement
The reversing feature therefore cannot prevent someone being trapped in these situations. There is a risk of injury.
When closing, make sure that no-one has any
parts of the body within the closing area.
If someone is trapped:
R
press the q button on the key or
R
press the closing button on the tailgate or
R
pull the handle on the tailgate
Opening and closing
If your vehicle is equipped with a rear window
which can be opened separately, the q button of the key must be programmed to open/
close the tailgate (Y page 87).
The rear window must be closed and the tailgate
unlocked.
X
To open: briefly press button : in the handle
and step out of the swinging range of the tailgate.
or
X
Check that there is nobody in the swinging
range of the tailgate and press the q but-
ton on the key for longer than 0.5 seconds.
Automatic operation is started. The tailgate
opens and swings upwards. In addition, you
will hear two warning signals.
You can set the opening angle of the tailgate
(Y page 88).
X
To close: press closing button ; in the tail-
gate and step out of the swinging range of the
tailgate.
or
X
Check that there is nobody in the swinging
range of the tailgate and press the q but-
ton on the key for longer than 0.5 seconds.
Automatic operation is started and the tailgate closes. During closing, closing button ;
flashes and two warning tones sound.
X
To interrupt automatic operation: press
button : in the handle again.
or
X
Press closing button ; in the tailgate again.
or
X
Press the q button on the key again for
longer than 0.5 seconds.
Programming the key button for tailgate
If your vehicle is fitted with a rear window which
can be opened separately, you can programme
the q button on the key either to open/close
the tailgate or to open the rear window.
X
Make sure that the tailgate and the rear window are closed.
X
Turn the key to position 2 in the ignition lock.
X
Press the buttons in the handle of the tailgate
and the handle of the rear window at the same
time for approximately 5 seconds.
After successfully switching the function, the
turn signal lamps flash once.
X
Check function of the q button on the key.
EASY-PACK tailgate
87
Opening and closing
Z
Setting the opening angle
You can set the opening angle of the tailgate by
storing the desired position as the stop position.
X
To set the stop position: open the tailgate
and halt the automatic process in the desired
position.
or
X
Open the tailgate and swing manually into the
desired position.
X
Press the q closing button in the tailgate
until an acknowledgement tone sounds once.
The current position of the tailgate is stored
as the stop position.
X
To reset to maximum opening angle: open
the tailgate.
X
Press the q closing button in the tailgate
until an acknowledgement tone sounds twice.
The stored stop position is deleted and the
tailgate opens again to its maximum position.
Resetting the tailgate
You must reset the tailgate if there has been a
malfunction or an interruption in the voltage
supply.
X
If the tailgate is open: close the tailgate by
hand.
X
Briefly press the button in the handle of the
tailgate, step out of the swinging range of the
tailgate and open the tailgate.
X
When the tailgate is fully opened, press the
q closing button in the tailgate and step
out of the swinging range of the tailgate.
The tailgate closes. When the tailgate is fully
closed, it is reset and operational.
When the q button of the key is programmed
for operating the tailgate (Y page 87), you can
also use the key to open and close the tailgate.
Problems with the tailgate
The tailgate cannot be opened.
The voltage supply has been interrupted or the
battery charge is insufficient.
Consult a qualified specialist workshop which
has the necessary specialist knowledge and
tools to carry out the work required.
In an emergency, you can open the tailgate
using the release catch for service purposes.
X
Prise off the cover on the lower part of the
tailgate with a suitable tool, e.g. the screwdriver from the vehicle tool kit.
X
Insert the screwdriver into the opening and
move the release lever until the tailgate
unlocks and opens.
X
Swing the tailgate upwards.
Separately-opening rear window
Important safety notes
G
WARNING
Combustion engines emit poisonous exhaust
gases, such as carbon monoxide. Exhaust
gases can enter the vehicle interior if the rear
window is open when the engine is running,
especially if the vehicle is in motion. There is a
risk of poisoning.
Always switch off the engine before opening
the rear window. Never drive with the rear
window open.
Opening and closing
If your vehicle is equipped with the EASY-PACK
tailgate, the q button of the key must be
programmed to open the rear window
(Y page 89).
The vehicle or the luggage compartment must
be unlocked and the tailgate must be closed.
X
To open: press the q button on the key.
or
X
Press button : in the handle of the tailgate.
88
Separately-opening rear window
Opening and closing
X
Swing the rear window upwards using the
handle.
X
To close: swing the rear window downwards
and push closed.
Programming the key button for the
rear window
If your vehicle is fitted with an EASY-PACK tailgate, you can programme the q button on
the key either to open/close the tailgate or to
open the rear window.
X
Make sure that the tailgate and the rear window are closed.
X
Turn the key to position 2 in the ignition lock.
X
Press the buttons in the handle of the tailgate
and in the handle of the rear window at the
same time for approximately five seconds.
After successfully switching the function, the
turn signal lamps flash once.
X
Check function of the q button on the key.
Problems with the rear window
The tailgate cannot be opened.
The voltage supply has been interrupted or the
battery charge is insufficient.
Consult a qualified specialist workshop which
has the necessary specialist knowledge and
tools to carry out the work required.
In an emergency, you can open the rear window
using the release catch for service purposes.
X
Prise off the cover in the tailgate trim with a
suitable tool, e.g. the screwdriver from the
vehicle tool kit.
X
Insert the screwdriver into the opening and
move the release lever until the rear window
unlocks.
X
Swing the rear window upwards.
Side windows
Important safety notes
G
WARNING
While opening the side windows, body parts
could become trapped between the side win-
dow and the door frame as the side window
moves. There is a risk of injury.
Make sure that nobody touches the side window during the opening procedure. If somebody becomes trapped, release the switch or
pull the switch to close the side window again.
G
WARNING
While closing the side windows, body parts in
the closing area could become trapped. There
is a risk of injury.
When closing make sure that no parts of the
body are in the closing area. If somebody
becomes trapped, release the switch or press
the switch to open the side window again.
G
WARNING
If children operate the side windows they
could become trapped, particularly if they are
left unsupervised. There is a risk of injury.
Activate the override feature for the rear side
windows. When leaving the vehicle, always
take the key with you and lock the vehicle.
Never leave children unattended in the vehicle.
G
WARNING
If persons (particularly children) are exposed
to heat or cold for a prolonged period, there is
a risk of serious or even fatal injuries. Never
leave persons (particularly children) unattended in the vehicle.
Side window reversing feature
The front side windows are equipped with an
automatic reversing feature. If a solid object
blocks or restricts a side window from moving
upwards during the automatic closing process,
the side window opens again automatically. During the manual closing process, the side window
only opens again automatically after the corresponding switch is released. The automatic
reversing feature is only an aid and is no substitute for your attention when closing a side window.
Side windows
89
Opening and closing
Z
G
WARNING
The reversing function does not react:
R
to soft, light and thin objects, e.g. small fingers
R
while resetting
This means that the reversing feature cannot
prevent someone being trapped in these situations. There is a risk of injury.
When closing, make sure that no parts of the
body are in the closing area. If someone
becomes trapped, press the switch to open
the side window again.
Opening and closing the side windows
:
Power window, left
;
Power window, right
The switches on the driver's door take precedence.
X
To open manually: press and hold the corresponding switch.
X
To open fully: press the switch beyond the
point of resistance and release it.
Automatic operation is started.
X
To close manually: pull the corresponding
switch and hold it.
X
To close fully: pull the corresponding switch
beyond the point of resistance and release it.
Automatic operation is started.
X
To interrupt automatic operation: press/
pull the corresponding switch again.
You can continue to operate the side windows
after switching off the engine or removing the
key. This function remains active for about five
minutes or until you open a front door.
Opening and closing the hinged windows
Door control panel on the driver's door
Switch in the rear compartment (example: lefthand side of the vehicle)
:
To operate the left hinged window in the rear
;
To operate the right hinged window in the
rear
=
Override switch for the electric hinged windows in the rear (Y page 68)
?
To operate the hinged window
You can only operate the hinged windows with
switch ? if the override feature has not been
activated (Y page 68).
X
To open manually: press and hold the corresponding switch.
X
To open fully: press the switch beyond the
pressure point and release it.
Automatic operation is started.
X
To interrupt automatic operation: press/
pull the corresponding switch again.
X
To close manually: pull the corresponding
switch and hold it.
You can continue to operate the hinged windows after switching off the engine or removing
90
Side windows
Opening and closing
the key. This function remains active for about
five minutes or until you open a front door.
Convenience opening feature
You can ventilate the vehicle before you start
driving. To do this, the key is used to carry out
the following functions simultaneously:
R
unlocking the vehicle
R
opening the side windows
R
opening the sliding sunroof
R
opening the hinged windows
R
switching on the seat ventilation for the driver's seat
The convenience opening feature can only be
operated using the key. The key must be close to
the driver's door handle.
X
Convenience opening: point the tip of the
key at the driver's door handle.
X
Press and hold the % button until the side
windows are in the desired position.
X
To interrupt convenience opening: release
the % button.
Convenience closing feature
G
WARNING
When using convenience closing, you could
become trapped within the sweep of the closing window. There is a risk of injury.
Monitor the entire closing procedure when
using convenience closing. When closing,
make sure that no one has any parts of the
body within the closing area.
When you lock the vehicle, you can close the
side windows at the same time.
The key must be close to the driver's door handle.
Observe the notes on the automatic reversing
feature for the side windows (Y page 89).
X
Convenience closing feature: point the tip
of the key at the driver's door handle.
X
Press and hold the & button until all the
side windows and the sliding sunroof are fully
closed.
X
Make sure that all side windows are closed.
X
To interrupt convenience closing feature:
release the & button.
Resetting the side windows
You must reset the side windows if there has
been a malfunction or an interruption in the voltage supply.
X
Turn the key to position 2 in the ignition lock.
X
Pull the two power window switches and hold
for approximately one second after closing
the side window.
X
If the side windows remain closed after the
button has been released, they have been
reset correctly. If this is not the case, repeat
the steps above for the open window.
Problems with the side windows
G
WARNING
If you close a side window again immediately
after it has been blocked or reset, the side
window closes with increased or maximum
force. The reversing function is then not
active. Parts of the body could be trapped in
the closing area in the process. This poses an
increased risk of injury or even fatal injury.
Make sure that no parts of the body are in the
closing area. To stop the closing process,
release the switch or push the switch again to
reopen the side window.
If you cannot completely open or close a side
window:
If there are no objects or leaves in the window
guide that prevent the sliding sunroof from closing, there has been a malfunction or the onboard voltage has been interrupted.
X
Reset the side window (Y page 91).
Panorama sliding sunroof
Important safety notes
In this section, the term "sliding sunroof" refers
to the panorama sliding sunroof.
Panorama sliding sunroof
91
Opening and closing
Z
G
WARNING
While opening and closing the sliding sunroof,
body parts in close proximity could become
trapped. There is a risk of injury.
Make sure that no body parts are in close
proximity during the opening and closing procedures.
If somebody becomes trapped:
R
release the switch immediately, or
R
during automatic operation, press the
switch briefly in any direction
The opening or closing procedure will be stopped.
G
WARNING
If children operate the sliding sunroof they
could become trapped, particularly if they are
left unsupervised. There is a risk of injury.
When leaving the vehicle, always take the key
with you and lock the vehicle. Never leave
children unattended in the vehicle.
!
Only open the panorama sliding sunroof if it
is free of snow and ice. Otherwise, malfunctions may occur.
Do not allow anything to protrude from the
sliding sunroof. Otherwise, the seals could be
damaged.
!
When the sliding sunroof is open, water can
get into the vehicle and cause damage. The
vehicle electronics can be damaged if water
enters the vehicle interior. Only clean the sliding sunroof when it is closed.
i
When the sliding sunroof is open, resonance
noise can occur, as well as the usual airflow
noise. These are caused by low-pressure fluctuations in the vehicle interior. Change the
position of the sliding sunroof or open a side
window slightly to reduce or eliminate these
noises.
Sliding sunroof reversing feature
The sliding sunroof is equipped with an automatic reversing feature. If an object blocks or
restricts the sliding sunroof during the closing
process, the sliding sunroof opens again auto-
matically. The automatic reversing feature is
only an aid and is no substitute for your attention
when closing the sliding sunroof.
G
WARNING
The reversing feature does not react:
R
to soft, light and thin objects, e.g. small fingers
R
over the last 4 mm of the closing movement
R
during resetting
R
when closing the sliding sunroof again manually immediately after automatic reversing
This means that the reversing feature cannot
prevent someone being trapped in these situations. There is a risk of injury.
When closing make sure that no body parts
are in the closing area.
If someone is trapped:
R
release the switch immediately or
R
press the switch in any direction during the
automatic closing process
The closing process is stopped.
Operating the sliding sunroof
Opening and closing
:
To raise (ventilation position)
;
To open
=
To close/lower
92
Panorama sliding sunroof
Opening and closing
X
Turn the key to position 1 or 2 in the ignition
lock.
X
Press or pull the 3 button in the corresponding direction.
X
Press the 3 button in direction :.
The sliding sunroof opens or closes to the
ventilation position.
If you press or pull the 3 button beyond the
point of resistance and then release it, automatic operation is started in the corresponding
direction. You can stop automatic operation by
pressing or pulling again.
You can continue to operate the sliding sunroof
after switching off the engine or removing the
key. This function remains active for 30 seconds
or until you open a front door.
Rain-closing feature when the engine is
switched off
When the key is in position 0 in the ignition lock
or is removed, the sliding sunroof closes automatically:
R
if it starts to rain
R
at extreme outside temperatures
R
after six hours
R
if there is a malfunction in the power supply
The sliding sunroof remains raised at the rear in
order to allow ventilation of the vehicle interior.
The sliding sunroof does not close if:
R
it is raised at the rear.
R
it is blocked.
R
no rain is falling on the area of the windscreen
being monitored by the rain sensor, e.g.
because the vehicle is under a bridge.
If the sliding sunroof is obstructed when being
closed by the rain-closing feature, it opens again
slightly. The rain-closing feature is then deactivated.
Operating the roller sunblinds of the
sliding sunroof
Important safety notes
G
WARNING
Parts of the body could become trapped
between the roller sunblind and frame or slid-
ing sunroof during automatic opening or closing. There is a risk of injury.
When opening or closing, make sure that no
body parts are in the sweep of the roller sunblind.
If someone is trapped:
R
release the switch immediately or
R
press the switch in any direction during the
automatic opening/closing process
The opening/closing process is stopped.
The roller sunblinds shield the vehicle interior
from sunlight. The roller sunblinds can only be
opened and closed when the sliding sunroof is
closed.
Roller sunblind reversing feature
The roller sunblinds are equipped with an automatic reversing feature. If a solid object blocks
or restricts the roller blind during the closing
process, the roller blind opens again automatically. The automatic reversing feature is only an
aid, not a substitute for your attention when
closing the roller sunblind.
G
WARNING
The reversing function does not react in particular to soft, light and thin objects, e.g. small
fingers. This means that the reversing feature
cannot prevent someone being trapped in
these situations. There is a risk of injury.
When closing the roller sunblind, make sure
that no body parts are in the sweep.
If someone is trapped:
R
release the switch immediately or
R
press the switch in any direction during the
automatic closing process
The closing process is stopped.
Panorama sliding sunroof
93
Opening and closing
Z
Opening and closing roller sunblinds
You can only close the roller sunblinds when the
sliding sunroof is closed.
X
Turn the key to position 1 or 2 in the ignition
lock.
X
Press the 3 button in direction :.
The roller sunblinds open, then the sliding
roof is raised to the ventilation position.
X
Pull the 3 button in direction ;.
The sunblinds open.
X
Pull the 3 button in direction =.
The roller sunblinds close when the sliding
sunroof is closed.
If you press or pull the 3 button beyond the
point of resistance and then release it, auto-
matic operation is started in the corresponding
direction. You can stop automatic operation by
pressing or pulling again.
Operating from the rear compartment
X
To open/close manually: press or pull button : to the point of resistance and hold it
until the roller sunblinds or the sliding sunroof
have reached the desired position.
X
To open/close fully: press or pull button :
beyond the point of resistance and release it.
When the sliding sunroof is opening or closing
fully, it always moves to the fixed intermediate
position ("ventilation position") first. To open or
close the sliding sunroof fully, button : must
be pressed twice.
Problems with the sliding sunroof
G
WARNING
If you close the sliding sunroof again immediately after it has been blocked or reset, the sliding
sunroof closes with increased or maximum force. The reversing feature is then not active. Parts
of the body could be trapped in the closing area in the process. This poses an increased risk of
injury or even fatal injury.
Make sure that no parts of the body are in the closing area.
If someone is trapped:
R
release the switch immediately or
R
press the switch in any direction during the automatic closing process
The closing process is stopped.
94
Panorama sliding sunroof
Opening and closing
Problem
Possible causes/consequences and M Solutions
The sliding sunroof cannot be closed and you
cannot see the cause.
If the sliding sunroof is obstructed during closing and reopens again
slightly:
X
Immediately after it blocks, pull the 3 button down again to the
point of resistance until the sliding sunroof is closed.
The sliding sunroof is closed with increased force.
If the sliding sunroof is obstructed again during closing and reopens
again slightly:
X
Immediately after it blocks, pull the 3 button down again to the
point of resistance until the sliding sunroof is closed.
The sliding sunroof is closed without the automatic reversing feature.
Panorama sliding sunroof
95
Opening and closing
Z
Useful information
These Operating Instructions describe all models as well as standard and optional equipment
of your vehicle that were available at the time of
going to print. Country-specific variations are
possible. Note that your vehicle may not be fitted with all of the described functions. This also
applies to safety-relevant systems and functions.
Read the information on qualified specialist
workshops: (Y page 31).
Seats
Driver's and co-driver's seats
Important safety notes
G
WARNING
If children adjust the seats, they could
become trapped, especially if they are unattended. There is a risk of injury.
When leaving the vehicle, always take the key
with you and lock the vehicle. Never leave
children unattended in the vehicle.
G
WARNING
You could lose control of the vehicle while
driving if you:
R
adjust the driver's seat, steering wheel or
mirrors
R
fasten the seat belt
There is a risk of an accident.
Adjust the driver's seat, head restraint, steering wheel and mirrors and fasten your seat
belt before starting the engine.
G
WARNING
When adjusting a seat, you or another vehicle
occupant could become trapped by the guide
rail of the seat, for instance. There is a risk of
injury.
Make sure that no one has any part of their
body within the sweep of the seat when
adjusting it.
G
WARNING
If the driver's seat is not correctly engaged, it
could unexpectedly move while driving. This
could cause you to lose control of the vehicle.
There is a risk of an accident.
Always ensure that the driver's seat is
engaged before starting the vehicle.
G
WARNING
If the front seats are positioned too closely to
the dashboard or steering wheel, the front
airbags could cause additional injuries to
vehicle occupants in the front. There is an
increased risk of injury, possibly even fatal.
Always adjust the front seats so that they are
as far away as possible from the front airbags.
In addition, observe the instructions on how to
adjust the seats correctly.
G
WARNING
The seat belt does not offer the intended level
of protection if you have not moved the backrest to an almost vertical position. When braking or in the event of an accident, you could
slide underneath the seat belt and sustain
abdomen or neck injuries, for example. This
poses an increased risk of injury or even fatal
injury.
Adjust the seat properly before beginning
your journey. Always ensure that the backrest
is in an almost vertical position and that the
shoulder section of your seatbelt is routed
across the centre of your shoulder.
G
WARNING
The head restraints cannot provide the intended protection unless they are fitted and
adjusted correctly. There is an increased risk
of injury to the head and neck in the event of
an accident or sudden braking, for example.
Always drive with the head restraints fitted.
Ensure that the centre of the head restraints
support the back of each vehicle occupant's
head at eye level before driving off.
96
Seats
Seats, steering wheel and mirrors
G
WARNING
Vehicles with amplifiers under the driver's
seat:
The amplifier can become hot during operation. You could burn yourself if you touch the
amplifier. There is a risk of injury.
Do not reach underneath the driver's seat.
Adjust the driver's seat carefully.
!
To avoid damage to the seats and the seat
heating, observe the following information:
R
do not spill any liquids on the seats. If liquid
is spilled on the seats, dry them as soon as
possible.
R
if the seat covers are damp or wet, do not
switch on the seat heating. The seat heating should also not be used to dry the seats.
R
clean the seat covers as recommended;
see the "Interior care" section.
R
do not transport heavy loads on the seats.
Do not place sharp objects on the seat
cushions, e.g. knives, nails or tools. The
seats should only be occupied by passengers, if possible.
R
when the seat heating is in operation, do
not cover the seats with insulating materials, e.g. blankets, coats, bags, seat covers,
child seats or booster seats.
You can adjust the seats electrically or manually, depending on the vehicle's equipment.
Your seat must be adjusted in such a way that
you can wear the seat belt correctly.
Observe the following points:
R
position the backrest in an almost vertical
position so that you are sitting virtually
upright. Do not drive with the backrest
reclined too far back.
R
your arms should be slightly bent when you
are holding the steering wheel.
R
avoid seat positions that prevent the seat belt
from being correctly routed. The shoulder
section of the belt must be routed over the
middle of your shoulder and be pulled tight
against your upper body. The lap belt must
always pass across your lap as low down as
possible, i.e. over your hip joints.
R
adjust the head restraint so that it supports
the back of the head at eye level.
R
the distance from the pedals should be such
that you can depress them fully.
Please also observe the important safety notes
on "Airbags" (Y page 50), "Seat belts"
(Y page 47) and "Child restraint systems"
(Y page 60).
Adjusting the seat manually
:
Seat fore-and-aft adjustment
;
Seat cushion angle adjustment
=
Seat height adjustment
?
Seat backrest adjustment
X
To adjust the seat fore-and-aft position:
pull lever : up.
For front swivel seats, the lever in position :
is used to release the swivel seat. The lever to
adjust the fore-and-aft position is in the form
of a bar in front of the seat (Y page 98).
X
Slide the seat forwards or back until you can
depress the pedals.
X
Release lever :.
X
Slide the seat forwards or back until you hear
it engage.
X
To adjust the seat height: press or pull lever
= repeatedly until you have reached the
desired seat height.
X
To adjust the backrest: turn handwheel ?
towards the front.
The seat backrest moves to a vertical position.
X
Turn handwheel ? towards the rear.
The seat backrest tilts towards the rear.
X
To adjust the seat angle: turn handwheel ;
towards the front.
The front of the seat cushion tilts down.
X
Turn handwheel ; towards the rear.
The front of the seat cushion tilts up.
Seats
97
Seats, steering wheel and mirrors
Z
Adjusting the seat electrically
G
WARNING
If children adjust the seats, they could
become trapped, especially if they are unattended. There is a risk of injury.
When leaving the vehicle, always take the key
with you and lock the vehicle. Never leave
children unattended in the vehicle.
The seats can be adjusted when the key is
removed and the door is open.
Buttons for electric seat adjustment on the door
trim
:
Head restraint height adjustment
;
Seat backrest adjustment
=
Seat height adjustment
?
Seat cushion angle adjustment
A
Seat fore-and-aft adjustment
X
Turn the key to position 2 in the ignition lock.
or
X
Open the door.
X
Adjust the seat using the buttons on the door
trim.
If the ignition is not switched on, you can adjust
the seat within 30 seconds of unlocking the
vehicle.
If you wish to adjust the seat electrically after
30 seconds:
X
Pull the key out of the ignition lock and press
the % button.
X
Adjust the seat using the buttons on the door
trim.
i
Vehicles with PRE-SAFE®: if PRE-SAFE
®
intervenes, the co-driver's seat is automatically adjusted from a less favourable position
into one which offers better protection. The
co-driver's seat can only be readjusted after
the hazardous situation is over. Information
about the system can be found under "PRE-
SAFE®" (Y page 58).
i
You can save the settings for the seats with
the memory function (Y page 124).
Adjusting lumbar support
To support the lumbar region, you can set the
backrest contour of each front seat (4-way lumbar support) electrically.
Electrically adjustable lumbar support
:
To raise the backrest contour
;
To soften the backrest contour
=
To lower the backrest contour
?
To harden the backrest contour
Turning the seats
G
WARNING
If the driver's and co-driver's seats are not
engaged facing the direction of travel while
driving, the restraint systems may not be able
to provide the intended protection. There is an
increased risk of injury, possibly even fatal.
Engage the driver's and co-driver's seats so
they are facing the direction of travel before
starting the engine.
!
When rotating the seats, make sure that
there is sufficient space to do so.
Move the seat forward or back first. This will
help to avoid contact with other parts of the
interior.
98
Seats
Seats, steering wheel and mirrors
Loading...
