Page 1
SL
Operator’s Manual
Page 2
SL 500
SL 600
Page 3
Our company and staff congratulate you on the purchase of your new Mercedes-Benz.
Your selection of our product is a demonstration of your trust in our company name. Further, it exemplifies your desire
to own an automobile that will be as easy as possible to operate and provide years of service.
Your Mercedes-Benz represents the efforts of many skilled engineers and craftsmen. To ensure your pleasure of
ownership, and for your safety and that of your passengers, we ask you to make a small investment of your time:
• Please read this manual carefully before putting it aside. Then return it to your vehicle where it will be handy for
your reference.
• Please abide by the recommendations contained in this manual. They are designed to acquaint you with the
operation of your Mercedes-Benz.
• Please abide by the warnings and cautions contained in this manual. They are designed to help improve the safety
of the vehicle operator and occupants.
We extend our best wishes for many miles of safe, pleasurable driving.
DaimlerChrysler AG
Page 4
Introduction
Product information .......................... 7
Operator’s manual ............................. 8
Where to find it ................................ 13
Problems with your vehicle ........... 14
Reporting Safety Defects ................ 15
Instruments and controls
Instruments and controls ............... 18
Door control panel .......................20
Overhead control panel ...............21
Dashboard .....................................22
Center console ..............................24
Operation
Vehicle keys ......................................28
Remote control with
folding master key .......................28
Central locking system ...................29
Remote control .............................29
Locking and unlocking ................30
Choosing global or
selective mode on
remote control ...............................31
Opening the trunk ........................31
Panic button ................................. 32
Start lock-out .................................... 33
General notes on the
central locking system ............... 33
Doors ................................................. 34
Central locking switch .................... 36
Automatic central locking .......... 37
Emergency unlocking in case of
accident ........................................ 38
Trunk ................................................. 38
Trunk lid release switch ................ 39
Trunk lid emergency release ........ 40
Power windows .................................41
Antitheft alarm system ................... 42
Tow-away alarm ............................... 43
Power seats ....................................... 44
Storing position in memory ....... 46
Backrest ............................................ 48
Multicontour seats .......................... 49
Seat heater ........................................ 50
Seat belts and integrated
restraint system ..........................52
Seat belts ...........................................52
Seat belt nonusage
warning system ............................53
Fastening of seat belts .................54
TM
BabySmart
airbag
deactivation system ....................58
TM
Self-test BabySmart
without special child
seat installed ................................58
Supplemental restraint
system (SRS) ................................59
Emergency tensioning
retractor (ETR) .............................59
Airbags ..............................................60
Front airbags ................................62
Side impact airbags .....................62
Safety guidelines for the
seat belt, emergency tensioning
retractor and airbag .....................67
Infant and child
restraint systems ..........................68
Adjusting steering column .............70
1Contents
Page 5
2Contents
Storing steering column
position in memory .....................70
Rear view mirrors ............................ 71
Inside rear view mirror ...............71
Antiglare night position .............. 71
Exterior rear view mirrors ..........72
Storing mirror positions in
memory ..........................................73
Instrument cluster ........................... 74
Indicator lamps in the
instrument cluster ....................... 76
Additional function indicator
lamps ..............................................77
Instrument lamps .........................77
Display illumination ....................77
Coolant temperature gauge ........78
Outside temperature
indicator ........................................78
Trip odometer ...............................79
Clock ..............................................79
Tachometer ....................................79
Flexible service system (FSS) ........80
Engine oil level indicator in odometer
display field .................................82
Fuel consumption gauge ................ 83
Engine oil temperature gauge ....... 83
Engine oil consumption ................. 83
Exterior lamp switch ....................... 84
Standing lamps ............................ 85
Night security illumination ....... 85
Combination switch ........................ 86
Blocked windshield wiper .......... 88
Windshield wiper smears .......... 88
Windshield and
headlamp washer fluid
mixing ratio .................................. 88
Hazard warning flasher
switch ........................................... 89
Automatic climate control .............. 90
Display and controls ................... 92
Basic setting -
automatic mode ........................... 93
Economy ........................................ 93
Special settings ............................ 94
Audio and telephone, operation .... 98
Power windows ...............................116
Express opening of
door windows ..............................117
Synchronizing
power windows ............................117
Roll bar .............................................118
Interior lighting ............................. 120
Interior lamps .............................120
Reading lamps ............................120
Entrance lamps in footwells,
exit lamps in doors ....................120
Sunshade, manual .........................121
Power sunshade .............................122
Sun visors .......................................123
Illuminated vanity mirror ............123
Interior ............................................124
Storage compartment
(eyeglasses compartment)
in the dashboard .......................124
Interior central
locking system ............................125
Integration with vehicle
central locking system ..............126
Separate locking of storage
compartments .............................126
Armrest ........................................... 127
Console storage compartments ... 127
Page 6
Cup holder ......................................128
Parcel net in
passenger footwell ....................128
Door pockets ...................................129
Rear storage compartment ...........129
Ashtray with lighter ......................130
Lighter ............................................. 131
Telephone, general ........................132
Garage door opener .......................133
Hardtop or panorama roof ............ 137
Removing hardtop ......................137
Attaching hardtop ......................140
Soft top ............................................143
Lowering soft top ........................ 144
Raising soft top ...........................145
Wind screen .................................... 148
Antenna ........................................... 151
Driving
Control and operation of radio
transmitters ............................... 154
Radio and telephone ..................154
Telephones and
two-way radio ..............................154
The first 1 000 miles
(1 500 km) ..................................155
Maintenance ...................................155
Tele Aid ............................................156
Catalytic converter .........................163
Emission control .............................164
Steering lock ...................................165
Starting and turning off
the engine ...................................167
Before starting .............................167
Starting .........................................167
Turning off ...................................167
Automatic transmission ................168
Driving .........................................168
Accelerator Position ...................169
Selector lever positions .............169
Maneuvering .............................. 172
Stopping ...................................... 172
Program mode
selector switch ........................... 173
Emergency Operation ................174
Parking brake ................................ 175
Driving instructions .......................176
Drive sensibly - Save fuel ..........176
Drinking and driving ................. 176
Pedals ........................................... 176
Power assistance ........................177
Brakes ..........................................177
Driving off ...................................178
Parking ........................................178
Tires .............................................179
Aquaplaning ...............................180
Tire traction ................................ 180
Tire speed rating ........................ 181
Snow chains ................................ 181
Vehicles with
sport package ..............................181
Deep water .................................. 182
Winter driving
instructions .................................182
Winter driving ............................183
Block heater ................................ 183
Traveling abroad ........................183
Cruise control .................................184
Brake assist system
(BAS) ...........................................188
Antilock brake system
(ABS) ........................................... 190
3Contents
Page 7
4Contents
ABS control ................................. 191
Electronic Stability Program
(ESP) ...........................................192
Synchronizing ESP ....................193
ESP Control Switch .................... 194
Level control system ...................... 196
Level control
switch positions .......................... 196
Normal Level ............................... 197
Wheel Change Switch ............... 198
Adaptive Damping System
(ADS) ........................................... 199
Adaptive damping system
adjustment .................................. 199
What you should know
at the gas station .......................200
Fuel supply ..................................200
Fuel ...............................................200
Check regularly and
before a long trip .......................202
Instrument cluster display
Malfunction and indicator
lamps in the
instrument cluster .................... 204
On-board
diagnostic system ......................204
Check engine malfunction
indicator lamp ............................204
Brake warning lamp .................. 205
Brake pad wear
indicator lamp ............................205
Seat belt warning lamp ............. 206
Supplemental
restraint system
(SRS) indicator lamp ................. 206
Fuel reserve and fuel cap
placement warning ................... 207
Electronic stability program
(ESP)- warning lamp ................. 207
BAS/ESP malfunction
indicator lamp ............................207
ABS malfunction
indicator lamp ............................208
Low engine coolant
level warning lamp ....................209
Low windshield and
headlamp washer
system fluid level
warning lamp .............................. 210
Low engine oil level
warning lamp .............................. 210
Charge indicator lamp ............... 211
Exterior lamp failure
indicator lamp ............................. 211
Roll bar warning lamp ............... 212
ADS indicator lamp ....................212
High beam
indicator lamp ............................. 213
Additional function
indicator lamps
(in the odometer display) .......... 213
Malfunction and
indicator lamp
(in the dashboard) .................... 213
Passenger airbag
indicator lamp ............................. 213
Page 8
Practical hints
First aid kit ..................................... 216
Stowing things in the vehicle ...... 216
Vehicle tools .................................... 217
Vehicle jack ..................................... 218
Fuses ................................................ 219
Hood .................................................220
Automatic transmission
fluid level ...................................222
Checking engine oil level .............222
Coolant level ...................................224
Adding coolant ...............................225
Windshield and
headlamp washer
fluid mixing ratio ......................226
Wheels .............................................227
Tire replacement ............................227
Rotating wheels ..............................228
Spare wheel ....................................229
Changing wheels ...........................231
Tire inflation pressure ..................235
Battery .............................................237
Battery Recycling .......................238
Jump starting ................................. 239
Towing the vehicle ........................ 241
Exterior lamps ............................... 243
Headlamp assembly
(Halogen) .................................... 244
Taillamp assemblies ..................250
Changing batteries in the
remote control ...........................252
Synchronizing ............................253
Raising soft top manually ............ 254
Replacing wiper blade ................. 258
Manual release of
fuel filler flap ............................260
Trunk lamp ..................................... 260
Vehicle care
Cleaning and care
of the vehicle ............................. 262
Power washer .............................263
Tar stains ....................................263
Paintwork, Painted Body
Components ................................263
Engine cleaning .........................264
Vehicle washing ......................... 264
Ornamental moldings ................264
Headlamps, taillamps,
turn signal lenses ......................264
Window cleaning .......................265
Light alloy wheels ......................265
Instrument cluster .....................265
Steering wheel and
gear selector lever ......................265
Cup holder ...................................265
Seat belts .....................................266
Headliner, shelf behind
roll bars, and other hard
plastic trim items .......................266
Soft top .........................................266
Headliner .....................................267
Wind screen ................................267
Automatic antenna .....................267
Wiper blade .................................267
Headlamp cleaning
system ..........................................267
Leather upholstery .....................268
Plastic and rubber parts ............268
Illuminated door sill panels .....268
5Contents
Page 9
6Contents
Technical data
Spare parts service ........................270
Warranty coverage .........................270
Identification labels .......................271
Layout of poly-V-belt drive ............272
Engine ..............................................273
Rims - Tires .....................................274
Weights ............................................ 276
Main Dimensions ........................... 276
Fuels, coolants, lubricants etc. -
capacities ...................................277
Engine oils ......................................279
Engine oil additives .......................279
Air conditioner refrigerant ...........279
Brake fluid ......................................279
Premium unleaded gasoline ........280
Fuel requirements .........................280
Gasoline additives .........................281
Coolants ...........................................281
Consumer information ..................283
Index
Index ...............................................285
Page 10
Product information
Kindly observe the following in your own best interest:
We recommend using Mercedes-Benz original parts as well as conversion parts and accessories
explicitly approved by us for your vehicle model.
We have tested these parts to determine their reliability, safety and their special
suitability for Mercedes-Benz vehicles.
We are unable to make an assessment for other products and therefore cannot be held responsible
for them, even if in individual cases an official approval or authorization by governmental or other
agencies should exist. Use of such parts and accessories could adversely affect the safety, performance
or reliability of your vehicle. Please do not use them.
Mercedes-Benz original parts as well as conversion parts and accessories approved by us are available
at your authorized Mercedes-Benz Center where you will receive comprehensive information, also on
permissible technical modifications, and where proper installation will be performed.
7Introduction
Page 11
8Introduction
Operator’s manual
This Operator’s Manual contains a great deal of useful information. We urge you to read it carefully and familiarize
yourself with the vehicle before driving.
For your own safety and longer service life of the vehicle, we urge you to follow the instructions and warnings
contained in this manual. Ignoring them could result in damage to the vehicle or personal injury to you or others.
Vehicle damage caused by failure to follow instructions is not covered by the Mercedes-Benz Limited Warranty.
Your vehicle may have some or all of the equipment described in this manual. Therefore, you may find explanations
for optional equipment not installed in your vehicle. If you have any questions about the operation of any equipment,
your authorized Mercedes-Benz Center will be glad to demonstrate the proper procedures.
Service and warranty information
The Service and Warranty Information Booklet contains detailed information about the warranties covering your
Mercedes-Benz, including:
• New Car Limited Warranty,
• Emission System Warranty,
• Emission Performance Warranty,
• California, Massachusetts, and Vermont Emission Control System Warranty
(California, Massachusetts, and Vermont only),
• State Warranty Enforcement Laws (Lemon Laws).
Page 12
Important notice for California retail buyers of Mercedes-Benz automobiles
Under California law you may be entitled to a replacement of your vehicle or a refund of the purchase price, if
Mercedes-Benz USA,LLC or its authorized Mercedes-Benz Center fails to conform the vehicle to its express warranties
after a reasonable number of repair attempts during the period of one year or 12 000 miles from original delivery of
the vehicle. A reasonable number of repair attempts is presumed for a retail buyer (1) if the vehicle is out of service by
reason of repair of substantial nonconformities for a cumulative total of more than 30 calendar days or (2) the same
substantial non-conformity has been subject to repair four or more times and you have at least once directly
notified us in writing of the need to repair the non-conformity and have given us an opportunity to perform the
repair ourselves. Notifications should be sent to the nearest Mercedes-Benz Regional Office listed in the
Service and Warranty Information Booklet.
Maintenance
The Service Booklet describes all the necessary maintenance work which should be performed at regular intervals.
Always have the Service Booklet with you when you take the vehicle to your authorized Mercedes-Benz Center for
service. The service advisor will record each service in the booklet for you.
9Introduction
Page 13
10Introduction
Roadside assistance
The Mercedes-Benz Roadside Assistance Program provides factory trained technical help in the event of a breakdown.
Calls to the toll-free Roadside Assistance number:
1-800-FOR-MERCedes (in the USA)
1-800-387-0100 (in Canada)
will be answered by Mercedes-Benz Client Assistance Representatives 24 hours a day, 365 days a year.
For additional information refer to the Mercedes-Benz Roadside Assistance Program brochure in your glove box.
Change of address or ownership
If you change your address, be sure to send in the “Change of Address Notice” found in the Service and Warranty
Information Booklet, or simply call the Mercedes-Benz Client Assistance Center (in the USA) at
1-800-FOR-MERCedes, or Customer Service (in Canada) at 1-800-387-0100. It is in your own interest that we can
contact you should the need arise.
If you sell your Mercedes, please leave all literature with the vehicle to make it available to the next operator.
If you bought this vehicle used, be sure to send in the “Notice of Purchase of Used Car” found in the Service and
Warranty Information Booklet, or call the Mercedes-Benz Client Assistance Center (in the USA) at
1-800-FOR-MERCedes, or Customer Service (in Canada) at 1-800-387-0100.
Page 14
Operating your vehicle outside the USA or Canada
If you plan to operate your vehicle in foreign countries, please be aware that:
• Service facilities or replacement parts may not be readily available,
• unleaded gasoline for vehicles with catalytic converters may not be available; the use of leaded fuels will damage
the catalysts,
• gasoline may have a considerably lower octane rating, and improper fuel can cause engine damage.
Certain Mercedes-Benz models are available for delivery in Europe under our European Delivery Program. For details,
consult your authorized Mercedes-Benz Center or write to:
In the USA: In Canada:
Mercedes-Benz USA, LLC
European Delivery Department
One Mercedes Drive
Montvale, NJ 07645-0350
Mercedes-Benz Canada, Inc.
European Delivery Department
849 Eglinton Avenue East
Toronto, Ontar io M4G 2 L5
11Introduction
Page 15
12Introduction
We continuously strive to improve our product, and ask for your understanding that we reserve the right to make
changes in design and equipment. Therefore, information, illustrations and descriptions in this Operator’s Manual
might differ from your vehicle.
Optional equipment is also described in this manual, including operating instructions wherever necessary. Since they
are special-order items, the descriptions and illustrations herein may vary slightly from the actual equipment of your
vehicle.
If there are any equipment details that are not shown or described in this Operator’s Manual, your authorized
Mercedes-Benz Center will be glad to inform you of correct care and operating procedures.
The Operator’s Manual and Service Booklet are important documents and should be kept with the vehicle.
Page 16
Where to find it
The Operator’s Manual is divided into eight sections:
• Instruments and controls: An overview of all the controls that can be operated from the driver’s seat.
• Operation: Information on the vehicle’s equipment and its operation.
• Driving: Important information on driving.
• Instrument cluster display: Displays and indicator lamps on the instrument cluster with brief instructions.
• Practical hints: Assistance and instructions in the event of an emergency.
• Car care: Instructions on caring for your vehicle.
• Technical data: All the important technical data for your vehicle as well as consumer information such as fuels,
coolants, lubricants etc. is contained here.
• Index: Key terms to help you find a topic quickly.
Other documents may also be supplied, depending on your vehicle’s equipment.
Explanation of color used:
Warning notices for the protection of yourself and
others appear on red background.
13Introduction
Page 17
14Introduction
Problems with your vehicle
If you should experience a problem with your vehicle, particularly one that you believe may affect
its safe operation, we urge you to immediately contact your authorized Mercedes-Benz Center to
have the problem diagnosed and corrected if required. If the matter is not handled to your
satisfaction, please discuss the problem with the Mercedes-Benz Center management, or if
necessary contact us at the following addresses:
In the USA: Client Assistance Center
Mercedes-Benz USA, LLC
One Mercedes Drive
Montvale, NJ 07645-0350
In Canada: Customer Relations Department
Mercedes-Benz Canada, Inc.
849 Eglinton Avenue East
Toronto, Ontario, M4G 2L5
Page 18
For the USA only:
The following text is published as required of manufacturers under Title 49, Code of U.S. Federal Regulations,
Part 575 pursuant to the “National Traffic and Motor Vehicle Safety Act of 1966”.
Reporting Safety Defects
If you believe that your vehicle has a defect which could cause a crash or could cause injury or
death, you should immediately inform the National Highway Traffic Safety Administration
(NHTSA) in addition to notifying Mercedes-Benz USA, LLC.
If NHTSA receives similar complaints, it may open an investigation, and if it finds that a safety
defect exists in a group of vehicles, it may order a recall and remedy campaign. However, NHTSA
cannot become involved in individual problems between you, your retailer, or Mercedes-Benz USA,
Inc.
To contact NHTSA, you may either call the Auto Safety Hotline toll-free at 1-800-424-9393
(or 366-0123 in Washington, D.C. area) or write to: NHTSA, U.S. Department of Transportation,
Washington, D.C. 20590. You can also obtain other information about motor vehicle safety from
the Hotline.
15Introduction
Page 19
Page 20
Instruments and controls
Instruments and controls ............... 18
Door control panel .......................20
Overhead control panel ...............21
Dashboard .....................................22
Center console ..............................24
Instruments
and controls
Operation Driving
Instrument
cluster display
17Contents - Instruments and controls
Practical hints Car care Index
Technica l
data
Page 21
Instruments
and controls
Operation Driving
Instruments and controls
Instrument
cluster display
Practical hints Car care Index
Technica l
data
18Instruments and controls
1
2
3
Page 22
1 Door control panel, see page 20
2 Overhead control panel, see page 21
3 Dashboard, see page 22
4 Center console, see page 24
Instruments
and controls
Operation Driving
Instrument
cluster display
19Instruments and controls
Practical hints Car care Index
Technica l
data
Page 23
Instruments
and controls
Operation Driving
Instrument
cluster display
Practical hints Car care Index
Technica l
20Instruments and controls
Door control panel 1 Door handle, pull to open, see page 34
2 Front seat adjustment, see page 44
Memory function (for storing seat, head restraint,
steering wheel and exterior rear view mirror
settings), see page 46
data
Page 24
Overhead control panel 1 Hands-free microphone for Tele Aid, and optional
telephone with voice recognition system
2 Interior lighting, see page 120
3 Tele Aid (emergency call system), see page 156
4 Rear view mirror, see page 71
5 Garage door opener, see page 133
Instruments
and controls
Operation Driving
Instrument
cluster display
21Instruments and controls
Practical hints Car care Index
Technica l
data
Page 25
Instruments
and controls
Operation Driving
Dashboard
Instrument
cluster display
Practical hints Car care Index
22Instruments and controls
Technica l
data
Page 26
1 Side air outlet, adjustable, see page 91
2 Level control switch and wheel change switch,
see page 196
3 Exterior lamp switch, see page 86
4 Parking brake release, see page 175
5 Hood lock release, see page 220
6 Parking brake pedal, see page 175
7 Combination switch, see page 86
8 Cruise control switch, see page 184
9 Horn
10 Airbag, see page 60
11 Voice recognition system switch, see separate
operating instructions
12 Instrument cluster, see page 74
13 Steering lock with ignition/starter switch,
see page 165
14 Center air outlets adjustable, see page 91
15 Heated air supply button - center air outlet,
see page 91
16 Non-heated/cooled air supply button - center air
outlet, see page 91
17 Storage/eyeglasses compartment, see page 124
18 Air volume control for left air outlet, see page 91
19 Air volume control for center air outlets, see page 91
20 Air volume control for right air outlet, see page 91
21 Airbag off indicator lamp, see page 213
22 Automatic climate control, see page 90
Rear window defroster switch, see page 95
23 Audio system, see page 98
24 Trunk lid release switch, see page 39
25 Switch for tow-away alarm, see page 43
Indicator lamp for antitheft alarm system,
see page 42
26 Central locking switch, see page 36
27 Hazard warning flasher switch, see page 89
28 Adaptive damping system adjustment switch,
see page 199
29 ESP control switch, see page 194
30 Roll bar operation switch, see page 118
Instruments
and controls
Operation Driving
Instrument
cluster display
23Instruments and controls
Practical hints Car care Index
Technica l
data
Page 27
Instruments
and controls
Operation Driving
Instrument
cluster display
Practical hints Car care Index
Technica l
data
24Instruments and controls
Center console 31 Ashtray with lighter (to open press bottom of cover),
see page 130
32 Mirror adjustment switch, see page 72
33 Soft/hardtop operation switch, see page 143
34 Seat heater switch, see page 50
35 Power window switch, see page 116
Page 28
Instruments
and controls
Operation Driving
Instrument
cluster display
Practical hints Car care Index
25Instruments and controls
Technica l
data
Page 29
Page 30
Instruments
and controls
Operation Driving
Instrument
cluster display
Practical hints Car care Index
Technica l
data
26Contents - Operation
Operation
Vehicle keys ......................................28
Remote control with
folding master key .......................28
Central locking system ...................29
Remote control .............................29
Locking and unlocking ................30
Choosing global or selective
mode on remote control .............. 31
Opening the trunk ....................... 31
Panic button ..................................32
Start lock-out ....................................33
General notes on the
central locking system ...............33
Doors ..................................................34
Central locking switch ....................36
Automatic central locking ..........37
Emergency unlocking in case of
accident ........................................38
Trunk .................................................38
Trunk lid release switch .................39
Trunk lid emergency release ......... 40
Power windows ................................. 41
Antitheft alarm system ................... 42
Tow-away alarm ............................... 43
Power seats ....................................... 44
Storing position in memory ....... 46
Backrest ............................................ 48
Multicontour seats .......................... 49
Seat heater ........................................ 50
Seat belts and integrated
restraint system .......................... 52
Seat belts .......................................... 52
Seat belt nonusage
warning system ............................ 53
Fastening of seat belts ................ 54
TM
BabySmart
airbag
deactivation system ................... 58
TM
Self-test BabySmart
without special child
seat installed ............................... 58
Supplemental restraint
system (SRS) ............................... 59
Emergency tensioning
retractor (ETR) ............................ 59
Airbags .............................................. 60
Front airbags ................................ 62
Side impact airbags .....................62
Safety guidelines for the
seat belt, emergency tensioning
retractor and airbag .....................67
Infant and child
restraint systems ..........................68
Adjusting steering column .............70
Storing steering column
position in memory .....................70
Rear view mirrors ............................ 71
Inside rear view mirror ............... 71
Antiglare night position .............. 71
Exterior rear view mirrors .......... 72
Storing mirror positions in
memory ..........................................73
Instrument cluster ........................... 74
Flexible service system (FSS) ........80
Engine oil level indicator in odometer
display field .................................82
Fuel consumption gauge ................83
Engine oil temperature gauge ........83
Engine oil consumption ..................83
Exterior lamp switch .......................84
Standing lamps .............................85
Page 31
Night security illumination ........85
Combination switch ........................86
Blocked windshield wiper ..........88
Windshield wiper smears ...........88
Windshield and
headlamp washer fluid
mixing ratio ..................................88
Hazard warning flasher switch .....89
Automatic climate control ..............90
Display and controls ....................92
Basic setting -
automatic mode ............................93
Economy ........................................93
Special settings ............................94
Audio and telephone, operation ....98
Power windows ................................116
Express opening of
door windows ...............................117
Synchronizing
power windows ............................117
Roll bar .............................................118
Interior lighting ............................. 120
Interior lamps ............................. 120
Reading lamps ............................ 120
Entrance lamps in footwells,
exit lamps in doors .................... 120
Sunshade, manual ..........................121
Power sunshade ............................. 122
Sun visors ....................................... 123
Illuminated vanity mirror ............ 123
Interior ............................................ 124
Storage compartment
(eyeglasses compartment)
in the dashboard ...................... 124
Interior central
locking system ........................... 125
Integration with vehicle
central locking system .............. 126
Separate locking of storage
compartments ............................ 126
Armrest ........................................... 127
Console storage compartments ... 127
Cup holder ......................................128
Parcel net in
passenger footwell ....................128
Door pockets ...................................129
Rear storage compartment ...........129
Ashtray with lighter ......................130
Lighter .............................................131
Telephone, general ........................132
Garage door opener ....................... 133
Hardtop or panorama roof ............137
Removing hardtop ...................... 137
Attaching hardtop ...................... 140
Soft top ............................................143
Lowering soft top ........................144
Raising soft top ........................... 145
Wind screen ....................................148
Antenna ........................................... 151
Instruments
and controls
Operation Driving
Instrument
cluster display
27Contents - Operation
Practical hints Car care Index
Technica l
data
Page 32
Instruments
and controls
Operation Driving
Instrument
cluster display
Practical hints Car care Index
Technica l
data
28Central locking system
Vehicl e keys
Included with your vehicle are 2 remote controls with
folding master keys.
War ning!
When leaving the vehicle always remove the key
from the steering lock, and lock your vehicle. Do
not leave children unattended in the vehicle, or
with access to an unlocked vehicle. Unsupervised
use of vehicle equipment may cause serious
personal injury.
Remote control with folding master key
1
The remote control operates all locks on the vehicle.
To release the key, press button (1). The key unfolds
from the holder by itself.
The transmitter for the remote control is located in the
key ho lder.
The infrared receivers are located in the door handles.
Page 33
Note:
Do not give the master key to an unauthorized person.
Obtaining replacement keys
Your vehicle is equipped with a theft deterrent locking
system requiring a special key manufacturing process.
For security reasons, replacement keys can only be
obtained from your authorized Mercedes-Benz Center.
Central locking system
Remote control
Due to the extended operational range of the remote
control, it could be possible to unintentionally lock or
unlock the vehicle by pressing the transmit button.
The vehicle doors, trunk, storage compartment in
armrest, and fuel filler flap can be centrally locked and
unlocked via remote control.
1 Transmit button
‹ Locking
ΠUnlocking
Š Opening trunk
2 PANIC button
3 Release button for master key
4 Transmitter eye and lamp for battery check
Instruments
and controls
Operation Driving
Instrument
cluster display
29Central locking system
Practical hints Car care Index
Technica l
data
Page 34
Instruments
and controls
Operation Driving
Instrument
cluster display
Practical hints Car care Index
Technica l
data
30Central locking system
Locking and unlocking with remote control
Unlocking:
Press transmit button Œ. All turn signal lamps blink
once to indicate that the vehicle is unlocked.
The remote control can be programmed for two kinds of
unlocking modes (see below):
Selective unlocking mode –
Press transmit button Œ once to unlock driver’s door,
storage compartment in armrest, and fuel filler flap.
Press transmit button Πtwice to unlock both doors,
storage compartment in armrest, fuel filler flap, and
trunk.
Global unlocking mode –
Press transmit button Πonce to unlock both doors,
storage compartment in armrest, fuel filler flap, and
trunk.
Notes:
If the trunk was previously locked separately, it will
remain locked, see page 38.
The presently active unlocking mode (selective or
global) can only be determined by unlocking the vehicle
with the remote control (see below for changing mode).
If within 40 seconds of unlocking with the remote
control, neither door is opened, the key is not inserted
in the steering lock, or the central locking switch is not
activated, the vehicle will automatically lock.
Locking:
Press transmit button ‹ once. All turn signal lamps
blink three times to indicate that the vehicle is locked.
Note:
If the vehicle cannot be locked or unlocked by pressing
the transmit button, then it may be necessary to change
the batteries in the remote control (if ok, battery check
lamp in transmitter will light briefly when transmitting)
or to synchronize the remote control, see page 252 and
page 253.
Page 35
Choosing global or selective mode on remote control
Press and hold transmit buttons ‹ and Œ
simultaneously for five seconds to reprogram the
remote control. Battery check lamp will blink two times
indicating the completed mode change.
Opening the trunk
Press the transmit button Š until the trunk lid is
open.
Important!
Do not place remote control in trunk since trunk is
locked when the lid is closed if the vehicle is centrally
locked.
Note:
If the trunk was previously locked separately, it will
remain locked. See page 38.
Instruments
and controls
Operation Driving
Instrument
cluster display
31Central locking system
Practical hints Car care Index
Technica l
data
Page 36
Instruments
and controls
Operation Driving
Instrument
cluster display
Practical hints Car care Index
Technica l
data
32Central locking system
Panic button
To activate press and hold button (1) for at least one
second. An audible alarm and blinking exterior lamps
will operate for approximately 3 minutes.
To deactivate press button (1) again, or turn key in
steering lock to position 2.
Note:
For operation in the USA only: This device complies
with Part 15, Subpart C, Section 209 of the FCC Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) this device must accept any interference received,
including interference that may cause undesired
operation.
Warning: Changes or modification not expressly
approved by party responsible for compliance could void
the user’ s authority to operate the equipment.
Page 37
Start lock-out
Important!
Removing the key from the steering lock activates the
start lock-out. The engine cannot be started.
Turning the key in the steering lock to position 2
deactivates the start lock-out.
Note:
In case the engine cannot be started (vehicle’s battery is
in order), and Á and î are shown in the
odometer display field, the system is not operational.
Contact an authorized Mercedes-Benz Center or call
1-800-FOR-MERCedes (in the USA), or 1-800-387-0100
(in Canada).
General notes on the central locking system
If the key in the steering lock is in position 2, the
vehicle cannot be locked or unlocked with the remote
control.
If the vehicle cannot be locked or unlocked:
• Aim transmitter eye at a receiver of either door
handle and press button ‹ or Œ.
• Check the batteries of the remote control,
see page 252.
• Synchronize the remote control,
see page 253.
Instruments
and controls
Operation Driving
Instrument
cluster display
33Central locking system
Practical hints Car care Index
Technica l
data
Page 38
Instruments
and controls
Operation Driving
Doors
Instrument
cluster display
Practical hints Car care Index
Technica l
data
34Central locking system
1 Opening – pull handle
2 Unlock ing
3 Locking
4 Individual door from inside:
• Push lock button down to lock.
• Pull inside door handle to unlock.
The entire vehicle may be locked or unlocked by either
using the master key in driver’s door or trunk locks, or
central locking switch located in center console. The
master key also locks or unlocks the storage
compartment in the armrest, and the fuel filler flap.
Note:
If the fuel filler flap cannot be opened, see page 260.
Page 39
When you lock the vehicle, both door lock buttons
should move down. If any one stays up, the respective
door is not properly closed.
You should then unlock the vehicle, open and reclose
this door, and lock the vehicle again. Each individual
door can be locked with door lock button – the driver’s
door can only be locked when it is closed.
If the vehicle has previously been locked from the
outside, only the door being opened from the inside will
unlock, and the alarm will come on. The other door, the
trunk, the interior storage compartments, and fuel filler
flap remain locked.
Notes:
In case of a malfunction in the central locking system
the doors can be locked and unlocked individually.
To lock, turn key in driver’s door lock to position 3 or
push down lock buttons.
To unlock, turn key in driver’s door lock to position 2 or
pull inside door handles.
Instruments
and controls
Operation Driving
Instrument
cluster display
35Central locking system
Practical hints Car care Index
Technica l
data
Page 40
Instruments
and controls
Operation Driving
Instrument
cluster display
Practical hints Car care Index
Technica l
data
36Central locking system
Central locking switch
1
2
P54.25-0314-26
1 Locking
2 Unlock ing
The central locking switch is located in the center
console.
The doors and trunk can only be locked with the central
locking switch, if both doors are closed.
Notes:
If the vehicle was previously locked with the remote
control or key, the doors and trunk cannot be unlocked
with the central locking switch.
Opening a door with the inside door handle will cause
the alarm to come on. To switch the alarm off,
press Πbutton or insert key in steering lock and
turn it to position 1.
If the vehicle was previously locked with the central
locking switch, while in the selective remote control
mode, only the door opened from the inside is unlocked.
If the vehicle was previously locked with the central
locking switch, while in the global remote control mode,
the complete vehicle is unlocked when a door is opened
from the inside.
Note:
The storage compartment in the armrest as well as the
fuel filler flap cannot be locked or unlocked with the
central locking switch.
Page 41
Automatic central locking
The central locking switch also operates the automatic
central locking.
With the automatic central locking system activated, the
doors and trunk are locked at vehicle speeds of approx.
9 mph (15 km/h) or more. The fuel filler flap remains
unlocked.
To a ctivate:
With key in steering lock position 2 hold upper portion
of switch (1) for a minimum of 5 seconds.
To deactivate:
With key in steering lock position 2 hold lower portion
of switch (2) for a minimum of 5 seconds.
Notes:
If doors are unlocked with the central locking switch
after activating the automatic central locking, and
neither door is opened, then the doors remain unlocked
even at vehicle speeds of approx. 9 mph (15 km/h) or
more.
If a door is opened from the inside at speeds of approx.
9 mph (15 km/h) or less with the automatic central
locking activated, the door will again be automatically
locked at speeds of approx. 9 mph (15 km/h) or more.
Important!
When towing the vehicle, or with the vehicle on a
dynamometer test stand, please, note the following:
With the automatic central locking activated and the
key in steering lock position 2, the vehicle doors will
lock if the left front wheel as well as the right rear
wheel spin are turning at vehicle speeds of approx.
9mph (15km/h) or more.
To prevent the vehicle door locks from locking,
deactivate the automatic central locking.
Emergency unlocking in case of accident
The doors unlock automatically a short time after a
strong deceleration is detected, such as in a collision
(this is intended to aid rescue and exit). Driving on
rough roads may cause the vehicle to unlock. If
necessary, the vehicle can be locked again with the
interior central locking switch.
Instruments
and controls
Operation Driving
Instrument
cluster display
37Central locking system
Practical hints Car care Index
Technica l
data
Page 42
Instruments
and controls
Operation Driving
Instrument
cluster display
Practical hints Car care Index
Technica l
data
38Central locking system
Trunk
0 Neutral position – push to open (arrow)
1 Unlock ing
2 Locking (detent)
3 Separate locking of trunk – remove key in this
position.
When the trunk is separately locked, it remains locked
when centrally unlocking the vehicle.
To deny any unauthorized person access to the trunk,
lock it separately with the mechanical key.
Notes:
In case of a malfunction in the central locking system
the trunk can be locked and unlocked individually.
To lock, turn key to position 2 or 3.
To unlock and open the trunk lid, turn key to position 1,
hold and push to open.
If the fuel filler flap cannot be opened, see page 260.
Important!
Do not place key inside trunk, since trunk is locked
again when closing the lid.
Lower trunk lid using handle and close it with hands
placed flat on edges of trunk.
Page 43
Trunk lid release switch
1
1 Indicator lamp in switch located in center console
To release the trunk lid, the vehicle must be at standstill
and unlocked with the remote control. Press symbol
side of switch until trunk lid is released.
The indicator lamp (1) in the switch remains on with
trunk lid released.
Notes:
With vehicle centrally locked, the trunk can also be
released by using the remote control. Press Š button
one second.
The trunk lid cannot be released by the switch when
previously locked separately with the key. To open,
see page 38.
The trunk lid cannot be opened with the trunk lid
release switch when the vehicle was previously locked
with the remote control. To unlock vehicle with the
remote control, see page 29.
Instruments
and controls
Operation Driving
Instrument
cluster display
39Central locking system
Practical hints Car care Index
Technica l
data
Page 44
Instruments
and controls
Operation Driving
Instrument
cluster display
Practical hints Car care Index
Technica l
data
40Central locking system
Trunk lid emergency release
1
The emergency release button (1) is located in the
center of the inside trunck rear wall.
Briefly press emergency release button (1).
All doors, the fuel filler f lap, and the trunk unlock; and
the trunk lid opens.
Note:
The emergency release button (1) only unlocks and
opens the trunk while the vehicle is standing.
Important!
The emergency trunk lid release button (1) does not
open the trunk lid, if:
• the vehicle battery is discharged or disconnected,
• the trunk lid was previously locked separately with
the mechanical key, see page 38.
Illumination of the emergency release button (1):
The button will blink for 30 minutes after opening the
trunk.
The button will blink for 60 minutes after closing the
trunk.
Page 45
Power windows
1 Opening
2 Interrupting
3 Closing
When locking doors or trunk, turn key in door lock or
trunk lock to position 3 and hold. The windows begin to
close automatically after approximately 1 second.
To interrupt the closing procedure, turn key to
position 2.
When unlocking doors or trunk, turn key in door lock or
trunk lock to position 1 and hold. The windows begin to
open automatically after approximately 1 second.
To interrupt the opening procedure, turn key to
position 2.
Warn ing!
Never operate the windows if there is the
possibility of anyone being harmed by the
procedure.
In case the procedure causes potential danger, the
procedure can be immediately reversed by turning
the key to the reversed operational direction within
10 seconds:
• for opening position (1),
• for closing position (3).
Note:
If the opening/closing procedure is interrupted, it can
only be continued by first turning the key to the
interrupting position (2) and then again to the opening/
closing position (1 or 3) and hold.
Instruments
and controls
Operation Driving
Instrument
cluster display
41Central locking system
Practical hints Car care Index
Technica l
data
Page 46
Instruments
and controls
Operation Driving
Instrument
cluster display
Practical hints Car care Index
Technica l
data
42Antitheft alarm system
Antitheft alarm system
1 Indicator lamp in switch located in center console
The antitheft alarm is automatically armed or disarmed
with the remote control or any of your vehicle’s keys by
locking or unlocking the vehicle.
The antitheft alarm is armed within approximately
10 seconds after locking the vehicle.
A blinking lamp (1) indicates that the alarm is armed.
Operation:
Once the alarm system has been armed, the exterior
vehicle lamps will flash and an alarm will sound when
someone:
• opens a door,
• opens the trunk,
•opens the hood,
• opens the storage compartment between the front
seats,
• attempts to raise the vehicle.
The alarm will last approximately 3 minutes in form of
flashing exterior lamps. At the same time an alarm will
sound for 30 seconds. The alarm will stay on even if, for
example, an opened door is immediately closed again. If
the alarm stays on for more than 20 seconds, an
emergency call is initiated automatically. See Tele Aid
on page 156.
The antitheft alarm system is switched off automatically
if the vehicle is unlocked with the electronic main key.
Page 47
Tow -away alarm
The switch is located in the center console.
1 Press to switch off
2 Indicator lamp
Once the alarm system has been armed, the exterior
vehicle lamps will flash and an alarm will sound when
someone attempts to raise the vehicle.
The alarm will last approximately 3 minutes in the form
of flashing exterior lamps. At the same time an alarm
will sound for 30 seconds. The alarm will stay on even if
the vehicle is immediately lowered.
The tow-away alarm system is switched off automatically
if the vehicle is unlocked with the electronic main key.
If the alarm stays on for more than 20 seconds, an
emergency call is initiated automatically. See Tele Aid
on page 156.
To prevent triggering the tow-away alarm feature, switch
off the tow-away alarm before towing the vehicle, or
when parking on a surface subject to movement, such
as a ferry or auto train.
To do so, turn key in steering lock to position 1 or 0, or
remove key from steering lock. Press tow-away alarm
switch (1). The indicator lamp (2) illuminates briefly.
Exit vehicle, and lock vehicle with key or remote
control.
The tow-away alarm remains switched off until the
vehicle is locked again with key or remote control, at
which time it is automatically reactivated.
Instruments
and controls
Operation Driving
Instrument
cluster display
43Tow-away protection
Practical hints Car care Index
Technica l
data
Page 48
Instruments
and controls
Operation Driving
Instrument
cluster display
Practical hints Car care Index
Technica l
data
44Seats
Power seats
2
1
212
3
The switches are located in both doors.
Turn key in steering lock to position 1 or 2 (with either
door open, the power seats can also be operated with the
key removed or in steering lock position 0).
The position should be as far rearward as possible,
consistent with ability to properly operate controls.
We recommend to adjust the power seat in the following
order:
1 Seat, up/down
Press the switch (up/down direction) until
comfortable seating position with still sufficient
headroom is reached.
2 Seat adjustment, fore/aft
Press the switch (fore/aft direction) until a
comfortable seating position is reached that still
allows you to reach the accelerator/brake pedal
safely.
3 Seat cushion tilt
Press the switch in the direction of the arrow until
your legs are lightly supported.
4 Backrest tilt
Press the switch in the direction of the arrow until
the backrest is in an almost upright position. Adjust
the steering wheel until your arms are slightly
angled when holding the steering wheel. For
steering wheel adjustment see page 70.
Page 49
5 Head restraint
(with shoulder belt height adjustment)
Adjust the head restraint so that the upper portion
of the shoulder belt is located as close as possible to
the middle of the shoulder. The head restraint can
be tilted forward by hand.
Note:
To prevent the backrest from touching the soft top
storage compartment cover when the seat is moved
back, the backrest will automatically move to a more
upright position.
When reclining the backrest, the seat will automatically
move forward to prevent the backrest from touching the
soft top storage compartment cover.
War ning!
When leaving the vehicle always remove the key
from the steering lock, and lock the vehicle.
The power seats can also be operated with a door
open. Do not leave children unattended in the
vehicle, or with access to an unlocked vehicle.
Unsupervised use of vehicle equipment may cause
serious personal injury.
Do not adjust the driver’s seat while driving.
Adjusting the seat while driving could cause the
driver to lose control of the vehicle.
Never ride in a moving vehicle with the backrest
reclined.
Sitting in an excessively reclined position can be
dangerous. You could slide under the seat belt in a
collision. If you slide under it, the belt would apply
force at the abdomen or neck. That could cause
serious or even fatal injuries. The backrest and seat
belt provide the best restraint when the wearer is
in an upright position and the belt is properly
positioned on the body.
The rear storage area should never be occupied by
passengers since the vehicle is a 2 seater.
Furthermore, there is a risk of injury in the rear by
adjusting the power assisted front seats.
Never place hands under seat or near any moving
parts while a seat is being adjusted.
Instruments
and controls
Operation Driving
Instrument
cluster display
45Seats
Practical hints Car care Index
Technica l
data
Page 50
Instruments
and controls
Operation Driving
Instrument
cluster display
Practical hints Car care Index
Technica l
data
46Seats
Storing position in memory
2
1
212
3
6 Memory button
7 Position buttons “1”, “2” and “3”
After the seat and head restraint are positioned, push
memory button (6), release, and within 3 seconds push
position button “1”. Two additional sets of positions
may be stored into memory using position buttons “2”
and “3”.
Using the same position button, the steering wheel
position and exterior rear view mirror positions will
also be stored together with the seat position. For
adjusting steering wheel and mirrors see page 70.
Recalling stored positions
Press position button “1”, “2” or “3” and hold until seat/
head restraint/steering wheel/exterior rear view mirror
movement has stopped.
Note:
For safety reasons, the seat/head restraint/steering
wheel/exterior rear view mirror movement stops after
releasing the position button.
Page 51
Important!
Prior to operating the vehicle, the driver should adjust
the seat height for proper vision as well as fore/aft
placement and backrest angle to insure adequate
control, reach, operation, and comfort. The head
restraint should also be adjusted for proper height.
Adjust head restraint to support the back of the head
approximately at ear level. See also airbag section for
proper seat positioning on page 60.
In addition, also adjust the steering wheel to ensure
adequate control, reach, operation and comfort.
Both the inside and outside rear view mirrors should be
adjusted for adequate rearward vision.
Fasten seat belts. Infants and small children should be
seated in a properly secured restraint system that
complies with U.S. Federal Motor Vehicle Safety
Standard 213 and Canadian Motor Vehicle Safety
Standard 213.
All seat, head restraint, rear view mirror, and steering
wheel adjustments as well as fastening of seat belts
should be done before the vehicle is put into motion.
Warn ing!
Children 12 years old and under must never ride in
this vehicle, except in a Mercedes-Benz authorized
BabySmart
with the BabySmart
TM
compatible child seat, which operates
TM
system installed in the
vehicle to deactivate the passenger side front
airbag when it is properly installed.
Otherwise they will be struck by the airbag when it
inflates in a crash. If this happens, serious or fatal
injury will result.
Infants and small children must be seated in an
appropriate infant or child restraint system, which
is properly secured with the vehicle’s seat belt,
fully in accordance with the child seat
manufacturer’s instructions.
A child’s risk of serious or fatal injuries is
significantly increased if the child restraints are
not properly secured in the vehicle and the child is
not properly secured in the child restraint.
Instruments
and controls
Operation Driving
Instrument
cluster display
47Seats
Practical hints Car care Index
Technica l
data
Page 52
Instruments
and controls
Operation Driving
Instrument
cluster display
Practical hints Car care Index
Technica l
data
48Seats
Backrest
P91.10-0461-26
Folding forward:
Lift lever and fold forwards.
Folding back:
Fold backrest back until it audibly locks in place.
Warn ing
The seat belts provide protection only with the
backrest locked in place and, therefore, it must be
locked in place with the vehicle in motion. Do not
drive the vehicle when the backrest is not locked in
place.
Note:
If the backrest and seat belt warning lamp < does
not go out, but is instead lit continuously, then a
backrest is not engaged in its lock.
Always provide sufficient room behind the backrest and
fold the backrest all the way back until it can be heard
locking in place.
The warning lamp goes out as soon as both backrests
are locked in place.
If both backrests are locked in place and the warning
lamp does not go out, have the system checked at your
authorized Mercedes-Benz Center immediately.
Page 53
Multicontour seats (optional)
1
2
3
4
P91.25-0298-26
Switch is located on side of seat.
We recommend to adjust the multicontour seat in the
following order:
1 Seat cushion depth
2 Backrest bottom
3 Backrest center
4 Side bolster adjustment
Some models may be eq uipped with multicontour seats.
These seats have movable seat cushions, and inflatable
air cushions built into the backrest to provide additional
lumbar and side support.
The seat cushion movement and amount of backrest
cushion height and curvature can be continuously
varied with regulators (1, 2 and 3) after turning the key
in steering lock to position 2.
The side bolsters of the backrest can be adjusted with
rocker switch (4):
• press down forward end increase side support,
• press down rearward end decrease side support.
If the engine is turned off, the last cushion setting is
retained in memory, and automatically adjusts the
cushion to this setting when the engine is restarted.
Instruments
and controls
Operation Driving
Instrument
cluster display
49Seats
Practical hints Car care Index
Technica l
data
Page 54
Instruments
and controls
Operation Driving
Instrument
cluster display
Practical hints Car care Index
Technica l
data
50Seats
Seat heater (SL 500 optional)
1
2
P91.30-0270-26
The seat heater switches are located on the center
console.
The seat heaters can be switched on with the key in
steering lock positions 1 or 2.
Press switch to turn on seat heater:
1 Normal seat heating mode. One indicator lamp in
the switch lights up.
2 Rapid seat heating mode. Both indicator lamps in
the switch light up. After approximately 5 minutes
in the rapid seat heating mode, the seat heater
automatically switches to normal operation and only
one indicator lamp will stay on.
Turning off seat heater:
If one indicator lamp is on, press upper half of switch.
If both indicator lamps are one, press lower half of
switch.
If left on, the seat heater automatically turns off after
approximately 30 minutes of operation.
Page 55
Note:
When in operation, the seat heater consumes a large
amount of electrical power. It is not advisable to use the
seat heater longer than necessary.
The seat heaters may automatically switch off if too
many power consumers are switched on at the same
time, or if the battery charge is low. When this occurs,
the indicator lamp in the switch will blink (both
indicator lamps blink during rapid seat heating mode).
The seat heaters will switch on again automatically as
soon as sufficient voltage is available.
If the blinking of the indicator lamps is distracting to
you, the seat heaters can be switched off.
Instruments
and controls
Operation Driving
Instrument
cluster display
51Seats
Practical hints Car care Index
Technica l
data
Page 56
Instruments
and controls
Operation Driving
Instrument
cluster display
Practical hints Car care Index
Technica l
data
52Restraint systems
Seat belts and integrated restraint system
Your vehicle is equipped with lap-shoulder seat belts,
emergency tensioning retractors for the seat belts, as
well as airbags and knee bolsters.
Seat belts
Important!
Laws in most states and all Canadian provinces require
seat belt use.
All states and provinces require use of child restraints
that comply with U.S. Federal Motor Vehicle Safety
Standard 213 and Canadian Motor Vehicle Safety
Standard 213.
All child restraint systems are designed to be secured in
vehicle seats by lap belts or the lap belt portion of a lapshoulder belt.
For your safety and that of your passenger we strongly
recommend their use.
Note:
For cleaning and care of the seat belts, see page 266.
Warn ing!
The seat belts provide protection only with the
backrest locked in place. If the seat belt warning
lamp < does not go out, but is instead lit
continuously, then a backrest is not engaged in its
lock.
Never ride in a moving vehicle with the backrest
reclined. Sitting in an excessively reclined position
can be dangerous. You could slide under the seat
belt in a collision. If you slide under it, the belt
would apply force at the abdomen or neck. That
could cause serious or even fatal injuries. The
backrest and seat belt provide the best restraint
when the wearer is in an upright position and the
belt is properly positioned on the body.
Page 57
Seat belt nonusage warning system
With the key in steering lock position 2, a warning
sounds for a short time if the driver’s seat belt is not
fastened.
War ning!
Failure to wear and properly fasten and position
your seat belt greatly increases your risk of
injuries and their likely severity in an accident.
You and your passenger should always wear seat
belts.
If you are ever in an accident, your injuries can be
considerably more severe without your seat belt
properly buckled. Without your seat belt buckled,
you are much more likely to hit the interior of the
vehicle or be ejected from it. You can be seriously
injured or killed.
In the same crash, the possibility of injury or death
is lessened if you are wearing your seat belt.
Never let more people ride in the vehicle than there
are seat belts available. Be sure everyone riding in
the vehicle is correctly restrained with a separate
seat belt.
Warn ing!
Children 12 years old and under must never ride in
this vehicle, except in a Mercedes-Benz authorized
BabySmart
with the BabySmart
TM
compatible child seat, which operates
TM
system installed in the
vehicle to deactivate the passenger side front
airbag when it is properly installed. Otherwise they
will be struck by the airbag when it inflates in a
crash. If this happens, serious or fatal injury can
result.
Infants and small children must be seated in an
appropriate infant or child restraint system, which
is properly secured with the vehicle’s seat belt,
fully in accordance with the child seat
manufacturer’s instructions.
A child’s risk of serious or fatal injuries is
significantly increased if the child restraints are
not properly secured in the vehicle and the child is
not properly secured in the child restraint.
BabySmartTM is a trademark of Siemens Automotive Corp.
Instruments
and controls
Operation Driving
Instrument
cluster display
53Restraint systems
Practical hints Car care Index
Technica l
data
Page 58
Instruments
and controls
Operation Driving
Instrument
cluster display
Practical hints Car care Index
54Restraint systems
Fastening of seat belts 1 Latch plate
2 Buckle
3 Release button
Pull belt with latch plate (1) across shoulder and lap.
Push latch plate (1) into buckle (2) until it clicks.
To help avoid severe or fatal injuries, the lap belt should
be positioned as low as possible on your hips and not
across the abdomen.
Warn ing!
Always fasten your seat belt before driving off.
Always make sure your passenger is properly
restrained.
Do not twist the belt. A twisted seat belt may cause
injury.
Technica l
data
Page 59
4
1
2
3
P91.40-0346-26
Press switch (4) to adjust the height of the seat belt
outlet so that the shoulder portion is located as close as
possible to the middle of your shoulder.
The shoulder portion of the seat belt must be pulled
snug and checked for snugness immediately after
engaging it and during driving. Tighten the lap portion
to a snug fit by pulling shoulder portion up.
Operation of seat belts
The inertia reel stops the belt from unwinding during
sudden vehicle stops or when quickly pulling on the
belt.
The locking function of the reel may be checked by
quickly pulling out the belt.
Instruments
and controls
Operation Driving
Instrument
cluster display
55Restraint systems
Practical hints Car care Index
Technica l
data
Page 60
Instruments
and controls
Operation Driving
Instrument
cluster display
Practical hints Car care Index
Technica l
data
56Restraint systems
Caution!
For safety reasons, avoid adjusting the seat or backrest
into positions which could affect the correct seat belt
positioning.
Unfastening of seat belts
Push the release button (3) in the belt buckle (2).
Allow the retractor to completely rewind the seat belt by
guiding the latch plate (1).
Warn ing!
USE SEAT BELTS PROPERLY.
• Each occupant should wear their seat belt at all
times, because seat belts help reduce the
likelihood of and potential severity of injuries
in accidents, including rollovers. The
integrated restraint system includes “SRS”
(driver airbag, passenger airbag, door mounted
side impact airbags), “ETR” (seat belt
emergency tensioning retractors), and front
seat knee bolsters. The system is designed to
enhance the protection offered to properly
belted occupants in certain frontal (front
airbags) and side (side impact airbags) impacts
which exceed preset deployment thresholds.
• Never wear belts over rigid or breakable
objects in or on your clothing, such as
eyeglasses, pens, keys etc., as these might
cause injuries.
• Position the lap belt as low as possible on your
hips and not across the abdomen. If the belt is
positioned across your abdomen, it can cause
serious injuries in a crash.
Page 61
• Never wear the shoulder belt under your arm,
against you neck or off your shoulder. In a
crash, your body would move too far forward.
That would increase the chance of head and
neck injuries. The belt would also apply too
much force to the ribs or abdomen, which
could severely injure internal organs such as
your liver or spleen.
• Each seat belt must never be used for more
than one person at a time. Do not fasten a seat
belt around a person and another person or
other objects.
• Belts should not be worn twisted. In a crash,
you wouldn’t have the full width of the belt to
manage impact forces. The twisted belt against
your body could cause injuries.
• Pregnant women should also use a lapshoulder belt. The lap belt portion should be
positioned as low as possible on the hips to
avoid pressure on the abdomen.
• Never place your feet on the instrument panel
or on the seat. Always keep both feet on the
floor in front of the seat.
Warn ing!
USE CHILD RESTRAINTS PROPERLY.
Children 12 years old and under must never ride in
this vehicle, except in a Mercedes-Benz authorized
BabySmart
with the BabySmart
TM
compatible child seat, which operates
TM
system installed in the
vehicle to deactivate the passenger side front
airbag when it is properly installed. Otherwise they
will be struck by the airbag when it inflates in a
crash. If this happens, serious or fatal injury will
result.
Infants and small children must be seated in an
appropriate infant or child restraint system, which
is properly secured with the vehicle’s seat belt,
fully in accordance with the child seat
manufacturer’s instructions.
A child’s risk of serious or fatal injuries is
significantly increased if the child restraints are
not properly secured in the vehicle and the child is
not properly secured in the child restraint.
Adjust the passenger seat as far as possible
rearward from the dashboard when the seat is
occupied.
Instruments
and controls
Operation Driving
Instrument
cluster display
57Restraint systems
Practical hints Car care Index
Technica l
data
Page 62
Instruments
and controls
Operation Driving
TM
BabySmart
Special BabySmart
airbag deactivation system
TM
compatible child seats, designed
Instrument
cluster display
for use with the Mercedes-Benz system and available at
any authorized Mercedes-Benz Center are required for
use with the BabySmart
TM
airbag deactivation system.
With the special child seat properly installed, the
passenger side front airbag will not deploy. The 7
indicator lamp located in the dashboard will be
illuminated, except with key removed or in steering lock
position 0. The system does not deactivate the door
mounted side impact airbag.
War ning!
TM
The BabySmart
airbag deactivation system will
ONLY work with a special child seat designed to
operate with it. It will not work with child seats
which are not BabySmart
TM
compatible.
Never place anything between seat cushion and
child seat (e.g. pillow), since it reduces the
effectiveness of the deactivation system.
Follow the manufacturer’s instructions for
installation of special child seats.
The passenger front airbag will not deploy only if
the 7 indicator lamp remains illuminated.
Practical hints Car care Index
Technica l
data
58Restraint systems
Please be sure to check the indicator every time
you use the special system child seat.
Should the light go out while the restraint is
installed, please check installation. If the light
remains out, do not use the BabySmart
TM
restraint
to transport children on the front passenger seat
until the system has been repaired.
Self-test BabySmart
TM
without special child seat installed
After turning key in steering lock to position 1 or 2, the
7 indicator lamp located in the dashboard comes on
for approx. 6 seconds and then extinguishes.
If the indicator lamp should not come on or is
continuously lit, the system is not functioning. You must
see an authorized Mercedes-Benz Center before seating
any child on the front passenger seat.
BabySmartTM is a trademark of Siemens Automotive Corp.
Page 63
Supplemental restraint system (SRS)
Airbags are intended as a supplement to seat belts.
Airbags alone cannot protect as well as airbags plus
seat belts in impacts for which the airbags were
designed to operate, and do not afford any protection
whatsoever in crashes for which the airbags are not
designed to deploy.
The SRS uses two crash severity levels (thresholds) to
activate either the emergency tensioning retractor (ETR)
or front airbag or both. Activation depends on the
direction and severity of the impact exceeding the
preset thresholds and whether the seat belt is fastened.
Seat belt fastened
• first threshold exceeded:
ETR activates
• second threshold exceeded:
airbag also activates
Seat belt not fastened
• first threshold exceeded:
airbag activates, but not ETR
Driver and passenger systems operate independently of
each other.
Emergency tensioning retractor (ETR)
The seat belts are equipped with emergency tensioning
retractors. These tensioning retractors are located in
each belt’s inertia reel and become operationally ready
with the key in steering lock position 1 or 2.
The emergency tensioning retractors are designed to
activate only when the seat belts are fastened during
frontal and front-angled impacts and rear impacts
exceeding the first threshold of the SRS and in rear
impacts exceeding a preset severity level. They remove
slack from the belts in such a way that the seat belts fit
more snugly against the body restricting its forward
movement as much as possible.
In cases of other frontal impacts, rollovers, certain side
impacts, rear collisions or other accidents without
sufficient frontal or rear impact forces, the emergency
tensioning retractors will not be activated. The driver
and passenger will then be protected by the fastened
seat belts and inertia reel in the usual manner.
For seat belt and emergency tensioning retractor safety
guidelines see page 67.
Instruments
and controls
Operation Driving
Instrument
cluster display
59Restraint systems
Practical hints Car care Index
Technica l
data
Page 64
Instruments
and controls
Operation Driving
Instrument
cluster display
Practical hints Car care Index
60Restraint systems
Airbags 1 Driver airbag
2 Passenger front airbag
3 Side impact airbags
The most effective occupant restraint system yet
developed for use in production vehicles is the seat belt.
In some cases, however, the protective effect of a seat
belt can be further enhanced by an airbag.
In conjunction with wearing the seat belts, the driver
and passenger airbags can provide increased protection
for the driver and passenger in certain frontal impacts
exceeding preset thresholds. Door mounted side impact
airbags can provide increased protection to belted
occupants on the impacted side of the vehicle in side
impacts exceeding its preset thresholds.
The operational readiness of the airbag system is
verified by the indicator lamp "SRS" in the instrument
cluster when turning the key in steering lock to
position 2. If no fault is detected, the lamp will go out
after approximately 4 seconds: after the lamp goes out,
the system continues to monitor the components and
circuitry of the airbag system and will indicate a
malfunction by coming on again. If the lamp does not
Technica l
data
Page 65
come on at all or if it fails to extinguish after
approximately 4 seconds or if it comes on thereafter, a
malfunction in the system has been detected.
The following system components are monitored or
undergo a selfcheck: crash-sensor(s), airbag ignition
circuits, seat belt buckles, emergency tensioning
retractors, seat sensor.
Initially, when the key is turned from steering lock
position 0 to positions 1 or 2, malfunctions in the crashsensor are detected and indicated (the “SRS” indicator
lamp stays on longer than 4 seconds or does not come
on). In the operational mode, after the indicator lamp
has gone out following the initial check, interruptions or
short circuits in the airbag ignition circuit and in the
driver and passenger seat belt buckle harnesses, and
low voltage in the entire system are detected and
indicated.
Have the system checked at your authorized
Mercedes-Benz Center immediately.
Warn ing!
In the event a malfunction of the “SRS” is indicated
as outlined above, the “SRS” may not be
operational. For your safety, we strongly
recommend that you visit an authorized
Mercedes-Benz Center immediately to have the
system checked; otherwise the “SRS” may not be
activated when needed in an accident, which could
result in serious or fatal injury, or it might deploy
unexpectedly and unnecessary which could also
result in injury.
Instruments
and controls
Operation Driving
Instrument
cluster display
61Restraint systems
Practical hints Car care Index
Technica l
data
Page 66
Instruments
and controls
Operation Driving
Instrument
cluster display
Practical hints Car care Index
Technica l
data
62Restraint systems
Front airbags
The driver and passenger front airbags are designed to
activate only in certain frontal impacts exceeding a
preset threshold.
The passenger front airbag deploys only if the front
passenger seat is occupied, and the 7 indicator lamp
in the dashboard is not illuminated.
Note:
Heavy objects on the passenger seat can appear to the
“SRS” to indicate the presence of an occupant in that
seat which causes the passenger front airbag to deploy
in a crash exceeding the appropriate threshold.
Side impact airbags
The side impact airbags are designed to activate only in
certain side impacts exceeding a preset threshold. Only
the side impact airbag on the impacted side of the
vehicle deploy.
The passenger side impact airbag deploys only if the
passenger seat is occupied.
Side impact airbags operate best in conjunction with a
properly positioned and fastened seat belt.
Note:
Heavy objects on passenger seat can cause the
passenger door side impact airbag to deploy in a crash.
Important!
Airbags are designed to activate only in certain
frontal (front airbags) impacts, or side (side impact
airbags) impacts which exceed preset thresholds.
Only during these types of impacts, if of sufficient
severity to meet the deployment thresholds, will
they provide their supplemental protection.
The driver and passenger must always wear their
seat belts, otherwise it is not possible for the airbags
to provide their intended supplemental protection.
Page 67
In cases of other frontal impacts, angled impacts,
roll-overs, other side impacts, rear collisions, or
other accidents in which the airbags are not
designed to deploy, the airbags will not be activated.
The driver and passenger will then be protected by
the fastened seat belts.
We caution you not to rely on the presence of the
airbags in order to avoid wearing your seat belt.
Your vehicle was originally equipped with airbags
which are designed to activate in certain impacts
exceeding a preset threshold to reduce the potential
and severity of injury. It is important to your safety
and that of your passenger that you replace deployed
airbags and repair any malfunctioning airbags to
ensure the vehicle will continue to provide crash
protections for occupants.
Warn ing!
Airbags are designed to reduce the potential of
injury in certain frontal (front airbags) impacts,
and side (side impact airbags) impacts which may
cause significant injuries, however, no system
available today can totally eliminate injuries and
fatalities.
The activation of the “SRS” temporarily releases a
small amount of dust from the airbags. This dust,
however, is neither injurious to your health, nor
does it indicate a fire in the vehicle. The dust might
cause some temporary breathing difficulty for
people with asthma or other breathing trouble. To
avoid this, you may wish to get out of the vehicle as
soon as it is safe to do so. If you have any breathing
difficulty but cannot get out of the vehicle after the
airbag inflates, then get fresh air by opening a
window or door.
The service life of the airbags extends to the date
indicated on the label located on the driverside
door latch post. To provide continued reliability
after that date, they should be inspected by an
authorized Mercedes-Benz Center at that time and
replaced when necessary.
Instruments
and controls
Operation Driving
Instrument
cluster display
63Restraint systems
Practical hints Car care Index
Technica l
data
Page 68
Instruments
and controls
Operation Driving
Instrument
cluster display
Practical hints Car care Index
Technica l
data
64Restraint systems
To reduce the risk of injury when the front airbags
inflate, it is very important for the driver and front
passenger to always be in a properly seated
position and to wear their seat belts.
For maximum protection in the event of a collision
always be in normal seated position with your back
against the backrest. Fasten your seat belt and
ensure that it is properly positioned on your body.
For unobstructive inflation of door side impact
airbags, keep door pocket lids closed.
Since the airbag inflates with considerable speed
and force, a proper seating and hands on steering
wheel position will help to keep you at a safe
distance from the airbag.
Occupants who are unbelted, out of position or too
close to the airbag can be seriously injured by an
airbag as it inflates with great force in the blink of
an eye:
• Sit properly belted in an upright position with
your back against the backrest.
• Adjust the driver’s seat as far as possible
rearward, still permitting proper operation of
vehicle controls. Adjust the driver’s seat as far
as possible rearward, still permitting proper
operation of vehicle controls. The distance
from the center of the driver’s breastbone to
the center of the airbag cover on the steering
wheel must be at least ten inches (25 cm) or
more. You should be able to accomplish this by
a combination of adjustments to the seat and
steering wheel. If you have any problems,
please see your authorized Mercedes-Benz
Center.
• Do not lean with your head or chest close to the
steering wheel or dashboard.
• Keep hands on the outside of steering wheel
rim. Placing hands and arms inside the rim
can increase the risk and potential severity of
hand/arm injury when the driver front airbag
inflates.
• Do not lean against doors.
Page 69
• Occupants, especially children, should never
lean their heads in the area of the door where
the side airbag inflates. This could result in
serious injuries or death should the airbag be
triggered. Always sit upright, use the seatbelts,
and appropriate size infant or child restraint
system.
• Adjust the passenger seat as far as possible
rearward from the dashboard when the seat is
occupied.
• Children 12 years old and under must never
ride in this vehicle, except in a Mercedes-Benz
authorized BabySmart
which operates with the BabySmart
TM
compatible child seat,
TM
system
installed in the vehicle to deactivate the
passenger front airbag when it is properly
installed. Otherwise they will be struck by the
airbag when it inflates in a crash. If this
happens, serious or fatal injury can result.
Failure to follow these instructions can result in
severe or fatal injuries to you or other occupants.
Instruments
and controls
Operation Driving
Instrument
cluster display
65Restraint systems
Practical hints Car care Index
Technica l
data
Page 70
Instruments
and controls
Operation Driving
Instrument
cluster display
Practical hints Car care Index
Technica l
data
66Restraint systems
War ning!
Should you choose to place a child 12 years old or
under in the front passenger seat of your vehicle,
you must properly use a BabySmart
restraint. A BabySmartTM child restraint will turn
off the passenger side front airbag. BabySmart
TM
child
TM
will not, however, turn off the side impact airbag.
It should be noted that there is a possibility for a
side airbag related injury if occupants, especially
children, are not properly seated or restrained
when next to a side airbag which needs to deploy
rapidly in a side impact in order to do its job.
To help avoid the possibility of injury, please follow
these guidelines: (1) occupants, especially
children, should never place their bodies or lean
their heads in the area of the door where the side
airbag inflates. This could result in serious
injuries or death should the side airbag be
activated; (2) always sit upright, properly use the
seat belts and use an appropriately sized infant or
child restraint system for all children 12 years old
or under; and (3) always wear seat belts properly.
If you believe that, even with the use of these
guidelines, it would be safer for your front
passenger seat occupant to have the passenger side
door mounted side airbag deactivated, then
deactivation can be accomplished upon your
written election to do so at your authorized
Mercedes-Benz Center at an additional cost. Please
contact your local authorized Mercedes-Benz
Center or call our Client Assistance Center at
1-800-FOR-MERCedes (1-800-367-6372) for details.
Page 71
Safety guidelines for the seat belt, emergency
tensioning retractor and airbag
War ning!
• Damaged seat belts or belts that were highly
stressed in an accident must be replaced and
their anchoring points must also be checked.
Use only belts installed or supplied by an
authorized Mercedes-Benz Center.
• Do not pass belts over sharp edges.
• Do not make any modification that could
change the effectiveness of the belts.
• Airbags and ETR’s are designed to function on
a one-time-only basis. An airbag or emergency
tensioning retractor (ETR) that was activated
must be replaced.
• No modifications of any kind may be made to
any components or wiring of the “SRS”. This
includes changing or removing any component
or part of the “SRS”, the installation of
additional trim material, badges etc. over the
steering wheel hub, passenger airbag cover, or
door trim panels, and installation of additional
electrical/electronic equipment on or near
“SRS” components and wiring. Keep area
between airbags and occupants free of objects
(e.g. packages, purses, umbrellas, etc.).
• An airbag system component within the
steering wheel gets hot after the airbag has
inflated. Do not touch.
• Improper work on the system, including
incorrect installation and removal, can lead to
possible injury through an unintended
activation of the “SRS”.
• In addition, through improper work there is
the risk of rendering the “SRS” inoperative or
causing unintended airbag deployment. Work
on the “SRS” must therefore only be performed
by an authorized Mercedes-Benz Center.
Instruments
and controls
Operation Driving
Instrument
cluster display
67Restraint systems
Practical hints Car care Index
Technica l
data
Page 72
Instruments
and controls
Operation Driving
Instrument
cluster display
Practical hints Car care Index
Technica l
data
68Restraint systems
• For your protection and the protection of
others, when scrapping the airbag unit or
emergency tensioning retractor, our safety
instructions must be followed. These
instructions are available at your authorized
Mercedes-Benz Center.
• Given the considerable deployment speed and
the textile structure of the airbags, there is the
possibility abrasions or other injuries
resulting from airbag deployment.
When you sell the vehicle we strongly urge you to give
notice to the subsequent owner that it is equipped with
an “SRS” by alerting him to the applicable section in the
Operator’s Manual.
Infant and child restraint systems
TM
Use only a BabySmart
compatible child restraint in
this vehicle.
We recommend that all infants and children be properly
restrained at all times while the vehicle is in motion.
The passenger lap-shoulder belt has a special seat belt
retractor for secure fastening of a child restraint.
To fasten a child restraint follow child restraint
instructions for routing. Then pull shoulder belt out
completely. Slide switch located on side of passenger
seat to position N. Let the belt retract. During the
seat belt retraction a ratcheting sound can be heard to
indicate that the special seat belt retractor is activated.
The belt is now locked. Push down on child restraint to
take up any slack.
To deactivate, release seat belt buckle and let seat belt
retract completely. The seat belt can again be used in
the usual manner.
Warn ing!
Never release the seat belt buckle while vehicle is
in motion, since the special seat belt retractor will
be deactivated.
Page 73
Important!
The use of infant or child restraints is required by law in
all 50 states and all Canadian provinces.
Infants and small children should be seated in an
appropriate infant or child restraint system properly
secured by a lap-shoulder belt, and that complies with
U.S. Federal Motor Vehicle Safety Standard 213 and
Canadian Motor Vehicle Safety Standard 213.
A statement by the child restraint manufacturer of
compliance with this standard can be found on the
instruction label on the restraint and in the instruction
manual provided with the restraint.
When using any infant or child restraint system, be sure
to carefully read and follow all manufacturer’s
instructions for installation and use.
Please read and observe warning labels affixed to inside
of vehicle and to infant or child restraints.
Warn ing!
Children 12 years old and under must never ride in
this vehicle, except in a Mercedes-Benz authorized
BabySmart
with the BabySmart
TM
compatible child seat, which operates
TM
system installed in the
vehicle to deactivate the passenger front airbag
when it is properly installed. Otherwise they will
be struck by the airbag when it inflates in a crash.
If this happens, serious or fatal injury can result.
Infants and small children must be seated in an
appropriate infant or child restraint system, which
is properly secured with the vehicle’s seat belt,
fully in accordance with the child seat
manufacturer’s instructions.
Infants and small children should never share a
seat belt with another occupant. During an
accident, they could be crushed between the
occupant and seat belt.
When the child restraint is not in use, remove it
from the vehicle or secure it with the seat belt to
prevent the child restraint from becoming a
projectile in the event of an accident.
U.S.A. Models only:
Since 1986 all U.S. child restraints comply with
U.S. regulations without the use of a tether strap.
Instruments
and controls
Operation Driving
Instrument
cluster display
69Restraint systems
Practical hints Car care Index
Technica l
data
Page 74
Instruments
and controls
Operation Driving
Instrument
cluster display
Practical hints Car care Index
Technica l
data
70Adjusting steering column
Adjusting steering column
Turn key in steering lock to position 1 or 2 (with either
door open, the steering column can be operated with the
key removed or in steering lock position 0).
To extend or retract:
Move switch (1) in desired direction.
To raise or lower:
Move switch (1) in desired direction.
Storing steering column position in memory
The steering column position is stored in memory
together with the seat/head restraint/exterior rear view
mirror position and can be recalled when necessary,
see memory recalling on page 46.
Warn ing!
Do not adjust the steering wheel while driving.
Adjusting the steering wheel while driving, or
driving without the telescoping adjustment locked
could cause the driver to lose control of the vehicle.
Page 75
Rear view mirrors
Inside rear view mirror
Manually adjust the mirror.
Use your inside mirror to determine the size and
distance of objects seen in the passenger side convex
mirror.
Antiglare night position
With the key in steering lock position 2, the mirror
reflection brightness responds to changes in light
sensitivity.
With gear selector lever in position “R”, or with the
interior lamp switched on, the mirror brightness does
not respond to changes in light sensitivity.
Note:
The automatic antiglare function does not react, if
incoming light is not aimed directly at sensors in the
mirror.
Warn ing!
In the case of an accident liquid electrolyte may
escape the mirror housing when the mirror glass
breaks.
Electrolyte has an irritating effect. Do not allow the
liquid come into contact with eyes, skin, clothing,
or respiratory system. In cases it does, immediately
flush affected area with water, and seek medical
help if necessary.
Instruments
and controls
Operation Driving
Instrument
cluster display
71Rear view mirrors
Practical hints Car care Index
Technica l
data
Page 76
Instruments
and controls
Operation Driving
Instrument
cluster display
Practical hints Car care Index
Technica l
data
72Rear view mirrors
Exterior rear view mirrors
2
1
P82.00-0359-26
The switch is located on the center console.
Turn key in steering lock to position 2.
First select the mirror to be adjusted - turn switch:
1 Left mirror
2 Right mirror
To adjust, toggle the switch forward, backward or to
either side.
With the key in steering lock position 2, the driver’s
side mirror reflection brightness responds to changes in
light sensitivity.
With gear selector lever in position “R”, or with the
interior lamp switched on, the driver’s side mirror
brightness does not respond to changes in light
sensitivity.
Warn ing!
Exercise care when using the passenger-side
mirror. The passenger-side exterior mirror is
convex (outwardly curved surface for a wider field
of view). Objects in mirror are closer than they
appear. Check your inside rear view mirror or
glance over your shoulder before changing lanes.
Notes:
The exterior mirrors have electrically heated glass. The
heater switches on automatically, depending on outside
temperature.
If the mirror housing is forcibly pivoted from its normal
position, it must be repositioned by applying firm
pressure until it snaps into place.
Page 77
War ning!
In the case of an accident liquid electrolyte may
escape the mirror housing when the mirror glass
breaks.
Electrolyte has an irritating effect. Do not allow the
liquid come into contact with eyes, skin, clothing,
or respiratory system. In cases it does, immediately
flush affected area with water, and seek medical
help if necessary.
Important!
Electrolyte drops coming into contact with the vehicle
paint finish can only be completely removed while in
their liquid state, by applying plenty of water.
Storing mirror positions in memory
The exterior rear view mirror positions are stored in
memory with the seat/head restraint/steering column
position and can be recalled when necessary,
see memory recalling on page 46.
Instruments
and controls
Operation Driving
Instrument
cluster display
73Rear view mirrors
Practical hints Car care Index
Technica l
data
Page 78
Instruments
and controls
Operation Driving
Instrument cluster
Instrument
cluster display
Practical hints Car care Index
74Instrument cluster
Technica l
data
Page 79
1 Fuel gauge with reserve and fuel cap placement
warning lamp (yellow), see page 207
2 Coolant temperature gauge, see page 78
3 Fuel consumption gauge, see page 83
4 Engine oil temperature gauge, see page 83
5 Left turn signal indicator lamp (green),
see combination switch on page 86
6 Knob for intensity of instrum ent lamps, see page 77,
for resetting trip odometer, see page 79 and
for calling up FSS indicator, see page 80
7 Speedometer
8 EPS warning lamp (yellow), see page 207
9 Odometer display field, see page 82
10 Main/trip odometer, see page 79
or FSS indicator, see page 80
or engine oil level indicator, see page 82
11 Outside temperature indicator, see page 78
12 Right turn signal indicator lamp (green),
see combination switch on page 86
13 Tachometer, see page 79
14 Knob for setting clock, see page 79
15 Clock, see page 79
Instruments
and controls
Operation Driving
Instrument
cluster display
75Instrument cluster
Practical hints Car care Index
Technica l
data
Page 80
Instruments
and controls
Operation Driving
Instrument
cluster display
Practical hints Car care Index
Technica l
data
76Instrument cluster
Indicator lamps in the instrument cluster
Fuel reserve and fuel cap placement
warning, see page 207
High beam, see page 86
Battery not being charged properly,
see page 211
Low windshield and headlamp washer
system fluid level see page 210
Coolant level low, see page 209
Engine oil level low, see page 210
Exterior lamp failure indicator lamp,
see page 211
Roll bar warning lamp, see page 212
ESP warning lamp. Adjust driving to road
condition, see page 207
ADS indicator lamp, see page 212
BAS/ESP malfunction, see page 207
ABS malfunction, see page 208
ABS
Brake pads worn down, see page 205
Brake fluid low (except Canada)
Parking brake engaged, see page 205
Brake fluid low (Canada only)
Parking brake engaged, see page 205
SRS malfunction, see page 206
Fasten seat belt, see page 206
If the lamp comes on when the engine is
running, it indicates a malfunction of the
fuel management system or the emission
control system, or the fuel cap is not closed
tight. In all cases, we recommend that you
have the malfunction checked as soon as
possible, see page 204.
Page 81
Additional function indicator lamps
(in the odometer display)
FSS indicator (distance, Service A),
seepage80.
FSS indicator (distance, Service B),
seepage80.
FSS indicator (days, Service A),
seepage80.
FSS indicator (days, Service B),
seepage80.
Start lock-out malfunction, see page 33.
Instrument lamps
1 Adjusting knob
Rotate adjusting knob (1) to vary intensity of instrument
lamps.
Display illumination
Press adjusting knob (1) to briefly illuminate the display
(with key removed or in steering lock position 0 or 1).
Instruments
and controls
Operation Driving
Instrument
cluster display
77Instrument cluster
Practical hints Car care Index
Technica l
data
Page 82
Instruments
and controls
Operation Driving
Instrument
cluster display
Practical hints Car care Index
Technica l
data
78Instrument cluster
Coolant temperature gauge
During severe operating conditions and stop-and-go city
traffic, the coolant temperature may rise close to the red
marking.
The engine should not be operated with the coolant
temperature in the red zone. Doing so may cause
serious engine damage which is not covered by the
Mercedes-Benz Limited Warranty.
War ning!
• Driving when your engine is badly overheated
can cause some fluids which may have leaked
into the engine compartment to catch fire. You
could be seriously burned.
• Steam from an overheated engine can cause
serious burns and can occur just by opening
the engine hood. Stay away from the engine if
you see or hear steam coming from it.
Turn off the engine, get out of the vehicle and do
not stand near the vehicle until it cools down.
Outside temperature indicator
The temperature sensor is located in the front bumper
area. Due to its location, the sensor can be affected by
road or engine heat during idling or slow driving. This
means that the accuracy of the displayed temperature
can only be verified by comparison to a thermometer
placed next to the sensor, not by comparison to external
displays (e.g. bank signs etc.).
Adaptation to ambient temperature takes place in steps
and depends on the prevailing driving conditions (stopand-go or moderate, constant driving) and amount of
temperature change.
Warn ing!
The outside temperature indicator is not designed
to serve as an Ice-Warning Device and is therefore
unsuitable for that purpose. Indicated
temperatures just above the freezing point do not
guarantee that the road surface is free of ice.
Page 83
Trip odometer
Clock
Adjusting clock one minute ahead or back:
Pull out adjustment knob (2), briefly turn to the right
respectively left and release knob.
Adjusting clock more than one minute ahead or
back:
Pull out adjustment knob (2), turn to the right
respectively left and hold until the desired time is set.
Within the first 2 seconds, the minute hand advances
8 minutes and advances another 8 minutes every
additional second thereafter.
Instruments
and controls
To reset:
• Press adjusting knob (1) once (with key in steering
lock position 2).
• Press adjusting knob (1) twice (with key removed or
in steering lock position 0 or 1).
Operation Driving
Instrument
cluster display
Tachometer
The red marking on the tachometer denotes excessive
engine speed.
Avoid this engine speed, as it may result in serious
engine damage that is not covered by the
Mercedes-Benz Limited Warranty.
To help protect the engine, the fuel supply is interrupted
if the engine is operated within the red marking.
79Instrument cluster
Practical hints Car care Index
Technica l
data
Page 84
Instruments
and controls
Operation Driving
Instrument
cluster display
Practical hints Car care Index
Technica l
data
80Flexible service system
Flexible service system (FSS)
(service indicator)
The FSS permits a flexible service schedule that is
directly related to the operating conditions of the
vehicle.
The symbol 9 or š appears in the main odometer
display field prior to the next suggested service.
Depending on operating conditions throughout the year,
the next service is calculated and displayed in days
š or distance 9 remaining.
The symbols 9 or ´ indicate the type of service
to be performed:
9 Service A
´ Service B
The message is displayed for approximately 10 seconds
when turning the key in steering lock to position 2, or
while driving when reaching the service warning
threshold. It can be canceled manually by pressing
button (1).
Once the suggested term has passed, the message plus
symbol 9 or š, preceded by a – (minus symbol)
blinks for approx. 30 seconds and a signal sounds every
time when turning the key in steering lock to position 2.
The FSS display can also be called up for approx.
10 seconds with display illuminated by pressing
button (1) twice within 1 second.
Following a completed A or B service the Mercedes-Benz
Center sets the counter to 10 000 miles (Canada: 15 000
km) and 365 days.
Page 85
The counter can also be set by any individual. To do so:
1. Turn key in steering lock to position 2.
2. Within 4 seconds press button (1) twice.
3. The present status for days or distance is displayed.
Within 10 seconds turn key in steering lock to
position 0.
4. Press and hold button (1), while turning key in
steering lock to position 2 again. The present status
for days or distance is displayed once more.
Continue to hold button (1).
After approx. 10 seconds a signal sounds, and the
display shows 10 000 miles (Canada: 15 000 km) for
approx. 10 seconds.
5. Release button (1).
If the FSS counter was inadvertently reset, have a
Mercedes-Benz Center correct it.
Note:
When disconnecting vehicle battery for one or more
days at a time, such days will not be counted. Any such
days not counted by FSS can be added by your
Mercedes-Benz Center.
The interval between services is determined by the kind
of vehicle operation. For example driving at extreme
speeds, and cold starts combined with short distance
driving in which the engine does not reach normal
operating temperature, reduce the interval between
services.
Model SL 500
The FSS allows for distances between 10 000 miles
(Canada: 15 000 km) and 20 000 miles (Canada:
30 000 km), or from 365 to 730 days between services.
Model SL 600
The FSS allows for distances between 10 000 miles
(Canada: 15 000 km) and 16 000 miles (Canada:
25 000 km), or from 365 to 730 days between services.
However you choose to set your reference numbers, the
scheduled services as posted in the Service Booklet
must be followed to properly care for your vehicle.
Instruments
and controls
Operation Driving
Instrument
cluster display
81Flexible service system
Practical hints Car care Index
Technica l
data
Page 86
Instruments
and controls
Operation Driving
Instrument
cluster display
Practical hints Car care Index
Technica l
data
82Checking engine oil level
Engine oil level indicator in odometer display field
(Model SL 500)
Turn electronic key in steering lock to position 2 and
wait until the symbols : and I appear in the
odometer display field.
Within 1 second press button “1” twice.
The following messages are available:
“OK”
“-1.0 Q” (Canada: -1.0 L)
“-1.5 Q” (Canada: -1.5 L)
“-2.0 Q” (Canada: -2.0 L)
If the message “-2.0 Q” (Canada: -2.0 L) blinks and a
signal sounds, add oil to upper (max) mark of the
dipstick.
“HI”
The message “HI” blinks and a signal sounds.
Do not overfill the engine.
Excessive oil must be drained or siphoned. It could
cause damage to engine and catalytic converter not
covered by the Mercedes-Benz Limited Warranty.
The symbol I flashes in the odometer display field if
a proper oil level check cannot be performed.
The oil level check can be repeated after a short time.
Perform the oil level check with the dipstick, if it cannot
be completed via the odometer display field.
In this case we recommend that you have the system
checked at a Mercedes-Benz Center.
Page 87
Notes:
If the symbols : and I are continuously
illuminated after pressing button (1) twice and there is
no change in the odometer display field or the low
engine oil level warning lamp comes on, a malfunction
has occurred to the system. Perform the engine oil level
check with the dipstick.
If no oil leaks are noted continue to drive to the nearest
Mercedes-Benz Center to have the system checked.
Observe the engine oil temperature gauge.
Fuel consumption gauge
While driving, instantaneous fuel consumption is
indicated in miles per gallon (mpg), or in Canada liters
per 100 kilometers (l/100 km).
With the engine switched off, the needle reads “0”.
Due to system design, minimum consumption is
indicated at idle speed.
Engine oil temperature gauge
Normal operating engine oil temperatures are from
175°F (80°C) to 250°F (120°C).
During severe operating conditions and stop-and-go
traffic, the engine oil temperature may rise close to the
red marking.
The engine should not be operated with the engine oil
temperature in the red zone. Doing so may cause
serious engine damage which is not covered by the
Mercedes-Benz Limited Warranty.
When the engine oil temperature is close to the red
marking, relieve the load on the engine by decreasing
vehicle speed to lower engine oil temperature.
Once the engine oil temperature returns to the normal
temperature range, the engine oil level should be
checked. See page 82 or 222.
Engine oil consumption
Engine oil consumption checks should only be made
after the break-in period. During the break-in period,
higher oil consumption may be noticed and is normal.
Frequent driving at high engine speeds results in
increased consumption.
Instruments
and controls
Operation Driving
Instrument
cluster display
83Checking engine oil level
Practical hints Car care Index
Technica l
data
Page 88
Instruments
and controls
Operation Driving
Instrument
cluster display
Practical hints Car care Index
Technica l
data
84Exterior lamp switch
Exterior lamp switch
D Off
C Parking lamps (also side marker lamps, taillamps,
licence plate lamps, instrument panel lamps)
Canada only: When the engine is running, the low
beam is additionally switched on.
B Parking lamps plus low beam or high beam
headlamps (combination switch pushed forward).
ˆ Standing lamps, right (turn left one stop)
‚ Standing lamps, left (turn left two stops)
… Front fog lamps (pull out one stop) with parking
lamps and/or low beam headlamps on. Green
indicator in lamp switch comes on.
„ Rear fog lamp (pull out to second detent) in
addition to the front fog lamps. Yellow indicator in
lamp switch comes on.
Note:
With the key removed and a door open, a warning
sounds if the vehicle’s exterior lamps (except standing
lamps) are not switched off.
Fog lamps will operate with the parking lamps and/or
the low beam headlamps on. Fog lamps should only be
used in conjunction with low beam headlamps. Consult
your State or Province Motor Vehicle Regulations
regarding allowable lamp operation.
Fog lamps are automatically switched off when the
exterior lamp switch is turned to position D.
Page 89
Standing lamps
When the vehicle is parked on the street the standing
lamps (right or left side parking lamps) can be turned
on, making the vehicle more visible to passing vehicles.
The standing lamps cannot be operated with the key in
steering lock position 2.
Daytime running lamp mode
When the engine is running and the selector lever is in
a driving position, the low beam headlamps (includes
parking lamps, side marker lamps, taillamps and
license plate lamps) are automatically switched on.
When shifting from a driving position to position “N”
or “P”, the low beam switches off (2 seconds delay).
For nighttime driving the exterior lamp switch should
be turned to position B to permit activation of the
high beam headlamps.
Night security illumination
When exiting the vehicle after driving with the exterior
lamps on, they switch on again for added illumination
for approximately 30 seconds after closing the last door.
The lamp-on time period can be changed at your
Mercedes-Benz Center.
Instruments
and controls
Operation Driving
Instrument
cluster display
85Exterior lamp switch
Practical hints Car care Index
Technica l
data
Page 90
Instruments
and controls
Operation Driving
Instrument
cluster display
Practical hints Car care Index
Technica l
data
86Combination switch
Combination switch
1 Low beam (exterior lamp switch position B)
2 High beam (exterior lamp switch position B)
3 High beam flasher (high beam available
independent of exterior lamp switch position)
4 Turn signals, right
5 Turn signals, left
To signal minor directional changes, such as changing
lanes on a highway, move combination switch to the
point of resistance only and hold it there.
To operate the turn signals continuously, move the
combination switch past the point of resistance (up or
down). The switch is automatically canceled when the
steering wheel is turned to a large enough degree.
Turn signal failure
If one of the turn signal lamps fails, the turn signal
indicator system flashes and sounds at a faster than
normal rate.
Page 91
7
6
P54.25-0313-26
6 Press switch briefly:
One wipe without washer water
(select only if windshield is wet).
Press switch past resistance point:
Windshield washer, windshield wiper;
headlamp cleaning system only in exterior lamp
switch positions C or B (except xenon
lamps).
Canada only: also in position D when the engine
is running.
7 Windshield wiper
0Wiper off
I Intermittent wiping
One initial wipe, pauses between wipes are
automatically controlled by a rain sensor
monitoring the wetness of the windshield.
Notes:
With switch in this position, one wipe occurs
when turning the key in steering lock from
position 0.
Do not leave in intermittent setting when vehicle
is taken to an automatic car wash or during
windshield cleaning. Wiper will operate in
presence of water spray at windshield, and wiper
may be damaged as a result.
II Normal wiper speed
III Fast wiper speed
Note:
The windshield washer reservoir, hoses and nozzles are
automatically heated.
Instruments
and controls
Operation Driving
Instrument
cluster display
87Combination switch
Practical hints Car care Index
Technica l
data
Page 92
Instruments
and controls
Operation Driving
Instrument
cluster display
Practical hints Car care Index
Technica l
data
88Combination switch
Blocked windshield wiper
If the windshield wiper becomes blocked (for example,
due to snow), switch off the wiper.
For safety reasons before removing ice or snow, remove
key from steering lock. Remove blockage.
Activate combination switch again (key in steering lock
position 1).
Windshield wiper smears
If the windshield wiper smears the windshield, even
during rain, activate the washer system as often as
necessary. The fluid in the washer reservoir should be
mixed in the correct ratio.
Windshield and headlamp washer fluid mixing ratio
For temperatures above freezing:
MB Windshield Washer Concentrate “S” and water
1 part “S” to 100 parts water
(40 ml “S” to 1 gallon water).
For temperature below freezing:
MB Windshield Washer Concentrate “S” and
commercially available premixed windshield washer
solvent/antifreeze.
1 part “S” to 100 parts solvent
(40 ml “S” to 1 gallon solvent).
Page 93
Hazard warning flasher switch The hazard warning flasher can be activated manually
via the switch located in the dashboard.
To activate hazard warning flasher, press switch once.
To deactivate, press switch again.
Note:
With the hazard warning flasher activated, and the
combination switch in position for either left or right
turn with key in steering lock position 2, only the
respective left or right side turn signals will operate.
P82.25-2055-26
Instruments
and controls
Operation Driving
Instrument
cluster display
89Hazard warning flasher switch
Practical hints Car care Index
Technica l
data
Page 94
Instruments
and controls
Operation Driving
Automatic climate control
Instrument
cluster display
Practical hints Car care Index
90Automatic climate control
Technica l
data
Page 95
1 Air volume control for left air outlet, turn left to
open.
2 Air volume control for center air outlets, turn left to
open.
3 Air volume control for right air outlet, turn left to
open.
4 Center air outlets, adjustable
5 Side air outlet, left and right, adjustable
Push-buttons for center air outlets
6 Heated air supply
7 Non-heated/cooled air supply
Basic mode:
None of the push-buttons (6 or 7) is pressed.
8 Display and controls, see page 92
The system is always at operational readiness, except
when manually switched off.
The automatic climate control only operates with the
engine running.
The temperature selector should be left at the desired
temperature setting. The temperature selected is
reached as quickly as possible.
The system will not heat or cool any quicker by setting a
higher or lower temperature.
The automatic climate control removes considerable
moisture from the air during operation in the cooling
mode. It is normal for water to drip on the ground
through ducts in the underbody.
Important!
This vehicle is equipped with an air conditioner system
that uses R-134a (HFC: hydrofluorocarbon) as a
refrigerant. Repairs should always be performed by a
qualified technician, and refrigerant should be collected
in a recovery system for recycling.
Instruments
and controls
Operation Driving
Instrument
cluster display
91Automatic climate control
Practical hints Car care Index
Technica l
data
Page 96
Instruments
and controls
Operation Driving
Instrument
cluster display
Practical hints Car care Index
Technica l
data
92Automatic climate control
Display and controls Press the desired button to activate, indicator lamp is on
while activated.
U Autom atic mode
f Raise temperature
g Lower temperature
P Defrost
O Air recirculation
F Rear window defroster
b Air distribution, manual
S Economy mode
ï Air volume, manual
T Residual engine heat utilization
Page 97
Basic setting - automatic mode
Press U button for automatic mode.
Simultaneously press both f and g buttons for
temperature setting of 72°F.
Air volume and distribution are controlled
automatically.
This setting can be used all year around.
Economy
The function of this setting corresponds to the
automatic mode. However, because the air conditioning
compressor will not engage (fuel savings), it is not
possible to air condition in this setting.
Press S button to activate.
Press S button once again to return to previous
setting.
Instruments
and controls
Operation Driving
Instrument
cluster display
93Automatic climate control
Practical hints Car care Index
Technica l
data
Page 98
Instruments
and controls
Operation Driving
Instrument
cluster display
Practical hints Car care Index
Technica l
data
94Automatic climate control
Special settings (use only for short duration)
Defogging windows
Switch off O button.
Press U button.
Press b button repeatedly until air is directed
upward.
Turn wheels (1 and 3) left to open left and right side air
outlets (5).
Defrosting
Turn wheels (1 and 3) left to open left and right side air
outlets (5).
Press P button. Maximum heated and automatically
controlled amount of air is directed to the windshield
and side windows.
Press P button once again to return to previous
setting.
Page 99
Rear window defroster
(only functions with hardtop installed)
Turn electronic key in steering lock to position 2.
To select, press F button.
To cancel, press F button again.
Note:
Heavy accumulation of snow and ice should be removed
before activating the defroster.
The rear window defroster uses a large amount of power.
To keep the battery drain to a minimum, turn off the
defroster as soon as the window is clear.
The defroster is automatically turned off after a
maximum of 12 minutes of operation.
If several power consumers are turned on
simultaneously, or the battery is only partially charged,
it is possible that the defroster will automatically turn
itself off. When this happens, the indicator lamp inside
the switch starts blinking.
As soon as the battery has sufficient voltage, the
defroster automatically turns itself back on.
Air distribution
Press b button repeatedly until the requested
symbol is displayed.
Air volume
Press “-” or “+” side of rocker switch ï until the
requested blower speed is attained. A choice of 7 blower
speeds is available.
To switch the automatic climate control off, press
“-” side of rocker switch ï until symbol OFF is
displayed.
The fresh air supply to the car interior is shut off.
While driving, use this setting only temporarily,
otherwise the windshield could fog up.
To switch the automatic climate control on again,
press U, P, or “+” side of ï.
Instruments
and controls
Operation Driving
Instrument
cluster display
95Automatic climate control
Practical hints Car care Index
Technica l
data
Page 100
Instruments
and controls
Operation Driving
Instrument
cluster display
Practical hints Car care Index
Technica l
data
96Automatic climate control
Air recirculation
This mode can be selected to temporarily reduce the
entry of annoying odors or dust into the vehicle’s
interior.
Outside air is not supplied to the car’s interior.
To select, press O button.
To cancel, press O button again.
The system will automatically switch from recirculated
air to fresh air:
• after approx. 5 minutes at outside temperatures
below approx. 40°F (5°C),
• after approx. 30 minutes, at outside temperatures
above approx. 40°F (5°C),
• after approx. 5 minutes, if button S is pressed.
Notes:
If the windows should fog up from the inside, switch
from recirculated air back to fresh air.
At high outside temperatures, the system automatically
engages the recirculated air mode thereby increasing
the cooling capacity performance, switching to partially
fresh air within 20 minutes.
Residual engine heat utilization
With the engine switched off, it is possible to continue
heating the interior for a short while.
Air volume and distribution are controlled
automatically.
To select:
Turn electronic key in steering lock to position 1 or 0 or
remove electronic key.
Press T button.
This function selection will not activate if the battery
charge level is insufficient.
To cancel:
Press T button.
The system will automatically shut off:
• If you turn electronic key in steering lock to
position 2,
•after approx. 30minutes,
• if the battery voltage drops.
Loading...
