Mercator FC692134BS, FC692134WH Specifications Sheet

ALTON 1300 CEILING FAN WITH B22 LIGHT

Spec Sheet

Main Features

• 2 year in home warranty

• 5 year motor warranty

• Four 1300mm (52”) plywood blades

• Suits 2 x B22 20W energy saver globes

(globes not included)

• Tropically rated

• Pre-assembled for easy installation

• Summer/Winter energy saving setting

• 3-speed wall controller with

light switch included

• Remote controller compatible

Product Technical Specifications

Colour/Finish option

Brushed Steel, White

Blade

Plywood (Silver / White)

Blade pitch

12˚

Rated input voltage

220-240V~

Rated input frequency

50Hz

Motor power rating

60W

Lamp power rating

Suits 2 x B22 20W CFL or 10W LED (globe not included)

Airflow **

Max 8219 m3/hr

Ceiling to Fan Bottom

365mm

Ceiling to Blade

239mm

Gross weight

9.7kg

Net weight

7.2kg

Packaging

Colour box

Packaging size (mm)

660mm x 320mm x 317mm

Bar Codes

Optional Accessories (Sold separately)

*This product must be installed by a licensed electrician.
**Actual performance may vary.

11/1/2019

SKU Model

Bar Code

FC692134WH

9312699147944

FC692134BS

9312699147937

MODEL

600 (mm) EXTENSION RODS

900 (mm) EXTENSION RODS

REMOTE

FC692134WH

FD250600WH + XFC6403 (loom)

FD250900WH + XFC6404 (loom)

FRM72A /
FRM72L /

FRM87 /
FRM97 /

FRM98

FC692134BS

FD250600BS + XFC6403 (loom)

FD250900BS + XFC6404 (loom)

Visit us @ www.mercator.com.au
