Mercator FC557134WH, FC557134BS Specifications Sheet

LUNA LED CEILING FAN

Colour/Finish option

BS, BK, WHITE

Blade

Plywood (Silver / Black / White)

Blade pitch

12˚

Rated input voltage

230-240V~

Rated input frequency

50Hz

Motor power rating

AC 60W

max

Lamp power rating

20W LED

Gross weight

7.5kg

Net weight

6.2kg

Packaging

Colour box

Packaging size (mm)

605 x 285 x 292mm

SKU Model

Bar Code

FC557134BS

9312699177316

FC557134BK

9312699177323

FC557134WH

9312699177330

SPEED

LOW

MED

HIGH

Airflow (m3/hr)

3226

5434

9100

MODEL

600 (mm) EXTENSION RODS

900 (mm) EXTENSION RODS

REMOTE

FC557134BS

FD250600BS

FD250900BS

FRM87 / FRM97

FC557134BK

FD250600BK

FD250900BK

FRM87 / FRM97

FC557134WH

FD250600WH

FD250900WH

FRM87 / FRM97

Visit us @ www.mercator.com.au

Visit us @ www.mercator.com.au

Spec Sheet

Main Features

 3 year in home warranty
 6 year motor warranty
 1300mm (52”) 4 x Plywood blades
 60W High performance AC motor
 20W LED 4000K 1200 lumen
 Tropically rated
 Summer / Winter settings
 Wall controller included
 Remote control adaptable

Product Technical Specifications

Bar Codes

Performance**

**Actual performance may vary.

Optional Accessories (Sold separately)

*This product must be installed by a licensed electrician.

09/02/2017
