Memup NG-9716, NG-708, NG-808 Operating Instructions

User ManualUser Manual

User Manual

CONTENT

SAFETY AND OTHER INSTRUCTIONS
PRODUCT VIEW 2
ANDROID APPLICATIONS 3
FIRST STEPS 4

ANDROIDTM INTERFACE 6
COMPUTER CONNECTION 9
CONNECT TO TV 9
OTHER CONNECTIONS 10
WIFI CONNECTION 11
PHOTO GALLERY 12
USING CAMCORDER 13
MOVIE CLIPS 13
READING EBOOKS 14
PLAY MUSIC 15

1

PLAY VIDEO 16
SET EMAIL ACCOUNT 17
MANAGING APPLICATIONS 18
WEB BROWSING 19
SETTINGS 20
GETJAR MARKET 22
SPECIFICATIONS 23
SAFETY NOTICES 24
LEGAL AND TRADEMARK NOTICES 25
TROUBLESHOOTING 26

>>> Copyright

properties are protected by copyright and

>>> Water / Moisture

under direct

Welcome and thank you for choosing SlidePad NG. Our tab is a multimedia computer running Android
with a built-in flash memory, you will then enjoy multimedia content, some applications and access to the
Internet connected to the Wifi.

SAFETY AND OTHER INSTRUCTIONS

Please use SlidePad NG carefully and read following instructions.

Software, audio, video or any intellectual

international laws.
It is user’s responsibility when reproducing or
distributing content(s).

>>> Codec Check

This product may not support some media formats.
Please check available codec types.

>>> Data Backup

Please backup datas stored in this product in a
safe place. We are not responsible for any data
loss or damage.

>>> Drop / Shock

Do not give shock or drop the SlidePad NG. This
may damage it.

>>> Foreign Substance

Do not insert any metal or inflammable foreign
substances into player. This may damage it.

>>> Disassembly / Modification
Do not attempt to disassemble or modify any part
of SlidePad NG. This may damage it.
Any product modification may void the warranty.

>>> Load
Do not place any heavy object on the top of the
SlidePad NG. This may damage it.

>>> Chemicals
Do not clean product using chemicals cleaners.
This may damage the SlidePad NG.

Do not contact the SlidePad NG with water or
liquid.
This may cause fire or electric shock. If any
conductive liquid enters, turn off the SlidePad NG
and disconnect power adapter immediately.

>>> Magnet or Magnetic Properties
Do not place the SlidePad NG near a magnetic
field. This may cause a malfunction or damage
stored data.

>>> Heat

Do not place the SlidePad NG
sunlight or near a heat source. Do not keep it for
long time in high temperature. This may damage it.

>>> Vision / Hearing

Do not watch movies or hear loud sound for long
time. This may cause vision or hearing problem.

>>> Fire
During SlidePad NG use, if you detect smoke or
unusual smell, turn off product, disconnect adapter
immediately, and call the aftersales department if
required.

>>> Power

Do not use many electronic products with single
outlet.
Firmly insert power plug. When working, do not
unplug.

>>> Glass breakage

The SlidePad NG touch screen panel can be
damaged. Any glass breakage isn’t included in the
warranty.

TM

,

- 1 -

PRODUCT VIEW

The buttons locations depend on the SlidePad NG you have.

SlidePad NG 708

SlidePad NG 808

SlidePad NG 9716

- 2 -

G

Connect to a PC
Connect the adapter to plug external HDD or USB key

Press to reset the SlidePad NG if it freezes or behaves abnormally (use a
paperclip or other small object to press this key.)

Name Definition

A Screen TFT screen for 7’’ and 8’’ and IPS screen for 9,7’’
B Webcam Front-facing camera

C Audio in Connect to headphones
D Speakers Stereo speakers.
E Vol + Press to increase the volume level.

F Vol - Press to decrease the volume level.

Power on/off Press to turn the unit on, or to turn the screen on and off.

H USB in

I HDMI out Connect to a HD TV

J AC in Charge and power the SlidePad NG with the included power adapter.

K Micro SD slot Load external microSD memory card here.

L Reset hole

ANDROID APPLICATIONS

Make sure you are connected to the Network when downloading applications (check Wifi connection).

Download and install applications

Download platforms: You have access to a few download platforms that already exist to easily get
Android applications. For example: SlideMe, AndAppStore, Getjar, …
These platforms are built-in applications to access directly to a market where you can download free or
paid applications.
The new SlidePad NG are delivered with Getjar to easily download applications.

Applications access: Beyond the Internet access, make sure you agree with the different demands to be
authorized when you download and install a software from a download platform.
The software will ask to access for example personal datas, your profile, …

Applications format: You can also download directly from a few websites some applications, with apk
extension and then paste file to install it. Make sure you have authorized installation from unknown source
before installation.

Remove applications

1/ Tap the Settings shortcut in the Home Screen to display setting menus.
2/ Select “Applications”.
3/ Tab on the application that you want to uninstall.
4/ Tab on “Uninstall” to uninstall the application.
Uninstall to save space or because applications are not satisfying. The file will be deleted permanently and
you’ll have to download and install it again if you want to use it one more time.

- 3 -

FIRST STEPS

Package contents

Please make sure that the items shown below are included in the package.

- Memup Internet SlidePad NG

- USB cable

- USB host adapter

- Stereo Earphones

- Power adapter

Features

- Browse the Web.

- Check your e-mail. Keep in touch with friends and family

- Watch videos

- Read your favorite books with the included E-book reader *

- Discover thousands of apps for Android™ download apps

- Connect to the Internet wirelessly High-speed Wifi 802.11 b/g/n networking

- HDMI™ output to your TV ** Enjoy videos, photos and more in the comfort of your living room.

- Enjoy your media library anywhere. SlidePad NG plays popular music, video, and photo formats

- MicroSD memory card reader Increase your storage capacity (up to 32 GB)

- Built-in front-facing camera

* Reading books in the ePub format requires the included E-book reader application
** Requires optional HDMI cable (Type A-to-Type C). 1080p HD video playback requires a video file encoded at 1080p. Streami ng v ideo qual i ty
will be affected by the source, and the quality and condition of your network connection.

Touchscreen

Use your finger tip to touch the area of the screen where a control icon is displayed. If you touch and hold
the screen, it will register as a continuous button press.
To avoid damaging the screen, do not touch it with excessive force or with any object other than your finger.
For best response, make sure your hands are clean before using the touchscreen controls.

Protective film

A thin film has been applied to the touchscreen to protect it during shipping. It could be removed.

Battery charge

Only use the SlideP ad NG included AC adapter, don’t use other plug to charge the SlidePad NG, it could
damage it. the Status Indicator will light green when the battery is fully charged

The orientation sensor

The SlideP ad NG c ontains a sensor that will automatically change the orientation of most screens as you
rotate the SlidePad NG. The orientation sensor can be turned on and off in the Display settings menu.

.

- 4 -

Touchscreen Actions

To control the SlidePad NG with the touchscreen, use your finger to manipulate icons, buttons, menu items,
the onscreen keyboard, and other items displayed on the screen. You can perform the following actions on
the touchscreen using your fingertip.

Touch: To activate an on-screen item (application icons, buttons, menu items, and the letter/symbols of the
on-screen keyboard), simply touch them on-screen.

Touch and hold: Some on-screen items have an alternate action if you touch and hold it (opening an
alternate menu, or draging icons). Touch the item and do not lift your fngertip until the action occurs.

Drag: Drag an on-screen item to change its position.Touch and hold it for a moment, then without lifting
your finger, move until the item reaches its target destination.

Swipe: Swipe up/down on the screen to scroll th rough a list. On some sc reens, you may be able to swi pe
left/right. Touch screen and then quickly move your fingertip across the screen without lifting your finger.

Double tap: Quickly tap the screen twice on a webpage or other application screen to zoom (when
supported).

Inserting a memory card

The SlidePad NG accepts microSD memory cards to:

- Increase the memory capacity of your SlidePad NG

- Play media fles stored on the memory card (music video, or photo fles).
To insert a memory card:

1. Align the memory card with the card slot. The metal contacts of the memory card should face down away
from the LCD screen.

2. Slide the card into the spring-loaded slot. Push the card in until it clicks into place.

Note:

Do not attempt to insert objects other than a microSD memory card into the card slot. A compatible memory
card should easily fit into the slot, if you encounter resistance, check the alignment of the card. Do not force
the card in and avoid touching the gold connector of the microSD.
To avoid damage and data corruption, do not remove a memory card while data is being written or read
from the card.

- 5 -

ANDROIDTM INTERFACE

Getting started

To turn the SlidePad NG on:

Press and hold the Power key until the LCD screen turns on. Wait until the Home screen ap pears; the
SlidePad NG is now ready for use.

To turn the SlidePad NG off:

1. Press and hold the Power key until a confrmation message appears.

2. Touch OK to turn off the SlidePad NG.

Stand by

When the SlidePad NG is on, you can turn off the screen to save battery power.
Simply press the Power key once to turn the screen off. Press it again to turn the screen back on.

Note:

To save battery power, the screen can be set to turn off automatically when the SlidePad NG is not used
(between 15 s and 30 mn). This option is available in the Display settings menu.

Unlock the screen

When the screen turns off, you will have to unlock the screen when you turn it on. To unlock the screen,
drag the lock icon across the screen towards the lock icon.

If a password has been set, enter it to finish unlock.
The Screen Unlock password can be set in the Location and security settings menu.

- 6 -

2

3

Multi tasks

It will display all opened applications to navigate from one to the other

4

Note: You can swipe left and right to view additional screens.

6

Time

It displays current time

7

8

Battery status

Shows the battery level before recharging the SlidePad NG

It’s the right part of the bar, move this bar from bottom to top to open it and
download failure, wifi status, notifications, battery status, ...

1 5 2

3 4 6 7 8

9

The welcome page

The interface is made of 5 virtual pages, each page could be customized with your own selected
applications, move your finger on screen from right to left to use different applications/page.
In these pages, you can add shortcuts, widgets, bookmarks, to ease your SlidePad NG navigation and use.

Name Definition

1 Return Get back to previous screen or cancel action

Home Shortcut to the welcome screen

Google search Shortcut to reach Google search by connecting the Internet

5

Application
folder

On the right side, you access the different applications installed in your
SlidePad NG, long press on icon to move it to one of the 5 different pages.

Wifi connection It displays the wifi signal

9 Notification bar

check the different actities on the SlidePad NG such as installed softwares,

You can add or remove from the 5 pages the different widgets or applications you want to customize in your
SlidePad NGs, these are only shortcuts, it won’t affect their installation. Uninstalling a program is different.
You can also add widget to display application with a l arger display, programs are used and automatically
refreshed by Internet access when selected and available.
It can be moved or deleted easily. Long press in empty space to add a new widget. You can also check into
the applications shortcut to add a widget.

Note:

Some applications request Internet access to be used.

- 7 -
