Memup MEDIADISK DNX User Guide

User Manual User Manual

MEDIADISK DNX SeriesMEDIADISK DNX Series

Feel Design

USER GUIDE




1. SAFETY AND OTHER INSTRUCTIONS 1

2. SPECIFICATIONS 2

3. REMOTE CONTROL 3

4. TV CONNECTION 4

5. LAN CONNECTION 5

6. SETUP MENU 6

7.MULTIMEDIA PLAY 10

8. BACKUP FUNCTION AND PLAYLIST 12

9. NETWORK BASED DATA SHARING WITH PC 13

10. DNX NETWORK SETTINGS 17

11. SPECIFICATIONS 18

12. TROUBLESHOOTING

19



Mediadisk DNX Series is a Home Media Center, with a built-in 3.5“ HDD, can record and play media files
(movies, audios and photos) through TV and when connected to PC, can also play shared files via network.

SAFETY AND OTHER INSTRUCTIONS

Please use DNX carefully and read following instructions.

- Copyright

Software, audio, video or any intellectual
properties are protected by copyright and
international laws.
It is user’s responsibility when reproducing or
distributing content(s).

- Codec Check

This product may not support some media formats.
Please check available codec types.

- Data Backup

Please backup datas stored in this product in a
safe place. We are not responsible for any data
loss or damage.

- Drop / Shock

Do not give shock or drop the DNX. This may
damage it.

- Foreign Substance

Do not insert any metal or inflammable foreign
substances into player. This may damage it.

- Disassembly / Modification
Do not attempt to disassemble or modify any part
of DNX. This may damage it.
Any product modification may void the warranty.

- Load
Do not place any heavy object on the top of the
DNX. This may damage it.

- Chemicals
Do not clean product using chemicals cleaners.
This may damage the DNX.

- Water / Moisture
Do not contact the DNX with water or liquid.
This may cause fire or electric shock. If any
conductive liquid enters, turn off the DNX and
disconnect power adapter immediately.

- Magnet or Magnetic Properties
Do not place the DNX near a magnetic field. This
may cause a malfunction or damage stored data.

- Heat

Do not place the DNX under direct sunlight or near
a heat source. Do not keep it for long time in high
temperature. This may damage it.

- Vision / Hearing

Do not watch TV or hear loud sound for long time.
This may cause vision or hearing problem.

- Fire
During DNX use, if you detect smoke or unusual
smell, turn off product, disconnect adapter
immediately, and call the aftersales department if
required.

- Children
Do not let children touch the DNX. They may
damage it.

- Power

Do not use many electronic products with single
outlet.
Firmly insert power plug. When working, do not
unplug.

- 1 -

SPECIFICATIONS

Product view:





Power (connect to power adapter)



HDMI Output



Composite Output



Audio Output (stereo)



S-VIDEO Output



USB-M (Host)



Cooling fan

Extension IR Receiver (option)



USB-S (Slave)



S/PDIF (Coaxial)



Component Output (YPbPr)



S/PDIF (Optical)



LAN (wireless LAN is option)



- 2 -



REMOTE CONTROL

BUTTONS FUNCTIONS
[Power]
[Mute]
[Setup]
[TV-out]
[Eject]
[Numeric]
[– button]

[ Back]
[Bookmark]
[Subtitle]

[Subaudio]
[Sleep]
[SKIP -/+]
[CH /]

[

]

/

[OK]
[MENU]
[STOP]

[I

]







[

I]







[

]







[

]







[Ratio]
[Screen]
[Angle]
[Zoom]
[Goto]
[Interval]
[Caption]
[Scroll]
[INFO]
[F1], [F2]
[New
Folder]
[Copy]
[Paste]
[DEL]
[Playlist]
[Add]
[DEL]
[Move]

- 3 -

Turn on/off the DNX.
Mute on/off in media playback.
Move to setup menu.
Change the Video Out mode.
Eject DVD/CD.
English/Number input function in folder creation.
In Photo playback, start/stop photo slideshow.
In Audio playback (Play/File Repeat/Folder Repeat/Shuffle).
Delete previous letter in folder name creation.
In media file playback. Start from the bookmark position.
Display subtitle during movie playback.
Press again to change languages subtitles.
Press to change audio with available languages.
Set up the sleep time (120-90-60-30-Off).
Skip the frame in certain interval during playback.
Move Up/Down in List and Menu.
Move Left/Right in List and Menu.

File Play/Pause/Select function.
Go to Main Menu.
Stop playback/Go.
Play previous file or play previous chapter in DVD mode.

Play next file and or play previous chapter in DVD mode.
Rewind the media file.
Fast forward the media file.
Change media file ratio.

Setup Screen Brightness, Darkness and Color Depth.
Photo: Rotate 90 degrees clockwise. DVD: angle change.
Zoom screen. Press 'Stop' and go back standard screen.
Start playback from the position you want.
Change skips interval time.
Adjust and select location/size/color of subtitle.
Re-position function on/off.
Display media file information.
No function buttons but for future usage
Make new folder and change mode (capital, small letter or
Number) by pressing [Sleep] button.
Copy selected file.
Paste copied file in current folder.
Delete folder or file.
Switch Playlist or Normal mode.
Add file to Playlist.
Delete file in Playlist.
Move files location in Playlist.



TV CONNECTION

The DNX supports four different types of video output (Component, HDMI, SVHS, CVBS).

Composite Cable Connection

- Connect DNX and your TV using a composite video cable (Yellow).

- Select correct 'AV' as video input on your TV.

- Press the 'TV-OUT' button on DNX Remote Control until image appears.

S-VHS Cable Connection (Optional)

- Connect DNX and your TV using a S-Video Cable, connect audio with L/R RCA cable

- Press the 'TV-OUT' button on the DNX Remote Control until image appears.

Component Cable Connection (Optional)

- Connect DNX to your TV using a component video cable (YPbPr - green, blue, red)

- Select correct 'AV' as video input on your TV.

- Press the 'TV-OUT' button on DNX Remote Control until image appears.
You can choose and select the correct display resolution (1080i, 720P, 480P) in AV setting.

- 4 -



HDMI Cable Connection (Optional)

- Connect DNX and your TV using an HDMI Video/Audio cable.

- Select 'HDMI' as video input on your TV.
Press the 'TV-OUT' button on DNX Remote Control until image appears.
You can select display resolution (1080P, 1080i, 720P, 480P) in the AV setting.

Digital Audio - Cable Connection

2.6.1 Connection to a 5.1 CH receiver
If you use the DNX with a multi-channel decoder/amplifier with optical/coaxial input

If there is no sound after connection the optical cable, you have to change the A/V setup
into Digital via the SETUP menu.

LAN CONNECTION

Direct connection

Connect a LAN cable directly to the LAN ports of the DNX and a PC.

- 5 -

LAN cable should be cross cable type.
