Memup K-PEARL User Guide
Feel Design
User guide
Instruction Manual
Please read this manual carefully before operation.
Important Safety Instruction
1. Read and follow Instructions: All the safety and operating instructions should be read before the product is
operated.
2. Cleaning: Unplug this product from the wall outlet before cleaning. Do not use liquid cleaners or aerosol cleaners.
Use a damp cloth for cleaning.
3. Attachments: Use only attachments recommended by Memup.
4. Water and Moisture: Do not use this product near water.
5. Accessories: Use only with carts, stands, tripods, brackets, or tables recommended by Memup or sold with the
product.
A product and cart combination should be moved with care. Quick stop s, excessive force, and uneven surfa ces may
cause the product and cart combination to overturn.
6. Ventilation: Slots and openings in the cabinet are provided for ventilation to ensure reliable operation of the
product and to protect it from overheating. These openings should never be blocked by placing the product on a bed,
sofa, rug, or other similar surface.
7. Power Sources: This product should be operated only from the type of power source indicated on the rating
label. For products intended to operate from battery power or other sources, refer to the operating instructions.
8. Lightning: For added protection for this product, unp lug it from the wall o utlet and disconnect the antenna or ca ble
system during a lightning storm or when it is le ft unattended and unused for long periods of time. This will prevent
damage to the product due to lightning or power-line surges.
9. Object and Liquid Entry: Never push objects of any kind into this product through openings as they may touch
dangerous voltage points or shout-out parts that could result in a fire or electric shock. Never spill liquid of any kind
on the product.
10. Servicing: Do not attempt to service this product yourself as opening or removing covers may expose you to
dangerous voltage or other hazards. Refer all servicing to qualified service personnel.
11. Damage Requiring Service: Unplug this product from the wall outlet and refer servicing to qualified service
personnel under the following conditions: a) when the power-supply or plug is damaged; b) if liquid has been spilled
or if objects have fallen into the product; c) if the product has been exposed to rain or water; d) if the product does
not operate normally by following the operating instructions. Adjust only those controls that are covered by the
operating instructions as improper adjustment of other controls may result in damage and will often require
extensive work by a qualified technician to restore the product to its normal operation; e) if the product has been
dropped or damaged in any way; f) when the product exhibits a distinct change in performance—this indicates a
need for service.
Wall or Ceiling Mounting: The product should be mounted to a wall or ceiling only as recommended by the
12.
manufacturer.
Heat: The product should be situated away from heat sources such as radiators, heat registers, stoves, or other
13.
products (including amplifiers) that produce heat.
1
CONTROLS............................................... 3
GETTING STARTING ............................... 4
MAIN MENU.............................................. 5
MUSIC MODE…………………………….. 5-7
PHOTO MODE…………….…………….. 7-9
MODE VIDEO............................................ 10-11
MODE RADIO FM..................................... 11-12
E-BOOKS MODE…………………………… 13-14
EXPLORER MODE ……………………….. 15
SETTING MODE …………………………… 15-16
TRANSFERS FILES……………. ………… 16-17
CONVERSION TOOL…..…………………. 18
TROUBLESHOOTING………………… …...19
SPECIFICATIONS………………………… 20
FEATURES
Easy-to-use trackball control
2.2” TFT LCD Full-color display
Plays Music, Video, Photos and Text
ID3 and LRC Support for song and synchronized lyric information display
Integrated FM Radio
USB 2.0 Hi-speed for fast file transfers
2
CONTROLS
Top View
1. Hold/Power Switch
Slide the switch left for Hold.
Slide and hold the switch right for Power.
Front View
2. LCD Display
Roll up UP
Roll down DOWN
3. Trackball
Bottom View
4. 3.5mm Headphone Jack
5. USB/Charge Port
Rear View
6. Reset Button
Roll left LEFT
Roll right RIGHT
Press the trackball to select OK
HOLD/POWER
3
Using the Trackball
Your player comes equipped with an easy-to-use trackball that controls all of its functions. To activate the controls,
roll the trackball in any of four directions, or press the trackball like a button.
Some functions require you to press and hold the trackball.
Try varying the speed at which you roll the trackball for different results.
Disabling the Controls (Hold)
When the Power/Hold switch is engaged, your player’s controls are disabled.
To disable the controls, slide the Power/Hold switch to the left until it clicks into the Lock position.
To enable the controls, slide the Power/Hold switch back to the right.
You may want to disable the controls to avoid turning on the player or activating the controls accidentally when it is
in your pocket or bag.
A lock icon will appear on the screen when the controls are disabled. Re-enable the controls to continue.
GETTING STARTED
Charging the Battery
K-Pearl has an integrated rechargeable battery. Upon initial use, the battery should be charged fully to ensure
optimal performance and battery life.
If the player has not been used in a while, the battery may need to be recharged.
The battery used in this device may present a fire or chemical burn if mistreated. Do not disassemble, incinerate,
or heat the battery. Do not leave the battery in a place subject to direct sunlight or in a car with its windows closed.
Do not connect the player to a power source other than that which is indicated here or on the label as this may
result in the risk of fire or electric shock.
Charging with a Computer
Your player can be charged through a USB computer connection. Use the supplied USB cable to connect the playe r
to a high-power USB port of a computer. The computer must be powered on and not in sleep mode.
When the player is connected and charging, a USB symbol will be displayed on the player’s screen.
Turning the Player On/Off
To turn the player on, slide the Hold/Power switch to the right and hold it until the screen turns on.
To turn the player off, slide the Hold/Power switch to the right and hold it until the screen turns off.
Resetting the Player
Reset the player if it should freeze and not respond or otherwise malfunction.
1. Disconnect your player if it is connected to a computer.
2. Use a paper clip to gently press the Reset button located on the rear of the player.
4
MAIN MENU
When you turn on K-Pearl, you will see the Main menu. The Main menu gives you access to the different function
modes. These modes are:
Music: Browse and play music.
Pictures: Browse and view pictures.
Movies: Browse and play movies.
FM Radio: Listen to FM radio broadcasts.
E-Books: Browse and read text files.
Explorer: Browse and play all files.
Setup: Adjust the player’s options.
To browse through the different modes, roll the trackball up or down.
To select a mode, press the trackball [press OK].
To return to the Main menu, press and hold the trackball [hold OK].
MUSIC MODE
Browse for and play your music files.
For more information about how to get music onto your player, please refer to the section “Transferring Files to the
Player”.
Music Browser Controls
When you choose MUSIC mode from the Main menu, you will see the Music Browser screen. You can choose to
browse your music by artist, album, track, genre, or playlist, or you may choose Folder Explorer to view the music
files and folders on the player.
Function Key Action
To browse through a list Roll UP or DOWN
To select/play an item Press OK
To return to the previous screen Roll LEFT
To return to the Main menu Hold OK
If your music files contain ID3 song information tags, you will be able to view your tracks by Artist, Album, or Genre.
To view all files (including those that do not contain ID3 information), select “Tracks” or use the Folder Explorer
option. If music is already playing, you will have the additional option to return to the Now Playing scre en.
Music Playback Controls (Now Playing)
To start playing music, browse for a song and then press OK to start playback. When a song is playing, the Now
Playing screen appears (see below). The following functions may be performed from the Now Playing screen.
5
Function Key Action
Play the next track. Roll RIGHT
Play the previous track. Roll LEFT
Adjust the volume level. Roll UP or DOWN
Access the Extended Controls menu
(see section below for more information).
Press OK
Return to the Main menu. Hold OK
Extended Controls Menu
To access the Extended Controls menu from the Now Playing screen, press the trackball.
To browse through the controls, roll LEFT or DOWN .
To select a control, press OK .
Function Icon
Reverse-scan through the current track. Press OK again to
resume playback at normal speed.
Return to the Music Browser to find more music.
Pause/resume playback.
Access the Quick Settings menu (see section below for
more information).
Start A-B Repeat mode to set a repeat a track segment in a
loop.
¾ To set the start point “A”, press to select A-B Repeat
mode from the menu.
¾ To set the end point “B” of the loop, press OK again. The
loop will now play from point “A” to point “B”.
¾ To resume normal playback, press again.
6
