Memup K-18 Instruction Manual

User manual

Music Player

Lecteur Audio

Video Player

Baladeur Vidéo

Photo Player

Album Photo

MicroSDTM Card reader

Lecteur de carte MicroSD

TM

Notice

• Download latest user manual from www.memup.com if there is a difference in the instructions
given in this manual.

• Do not disconnect the player when it is being formatted or uploading /downloading data.

• Do not subject the device to severe impact or drop it from high position.

• Do not use the player in extreme hot or cold, dusty or damp field. Do not expose it to direct sunshine.

• Back up the data frequently in case of accident data loss.

• Avoid using the player in strong magnetic field.

• Keep the device away from water or other liquids. In the event that water or other liquids enter the device,

power off the product immediately, and clean the device.

• Do not use chemical solution to clean the device in order to avoid corrosion. Clean it with a dry cloth.

• Do not attempt to disassemble, repair or modify the product. This will invalidate guarantee.

TABLE OF CONTENTS

Description 2

1. Display 2

2. Use 3

3. Main menu 4

3.1. Music mode 4-5

3.2. Video mode 5-6

3.3. Record 6

3.4. Voice 7

3.5. E-Book 8

3.6. Photo 8-9

3.7. Games 8

3.8. System setup 9-10

Specifications 11

1

Introduction

The high integration reduces the device weight and the dimensions and the use is comfortable. The big
display with TFT technology offers clear and sharp information and the USB 2.0 High Speed interface make
easier the data transfer operation from/to the computer. The K18 MP3 Player has built-in a Lithium battery
rechargeable by computer USB port. By the microphone inside it is possible to record voice messages and
play them directly with the device or by computer.
Before using this product, please read this manual and retain the instruction fo r future reference.

Description

Here below you will find a product description

1. MICRO SD Card slot

2. Menu

3. Previous []/ Backward[]

4. VOL-(Decrease the V olume)

5. USB Connector

6. Earphone Connector

7. Play [] / Pause []

8. Next [] / Forward []
9: Record
10: VOL +(Increase the Volume)
11: Power ON/OFF
12: Strap eyelet

1. Display

Here below you will find a display description

1. Total Number of Songs

2. Current Song Location

3. Volume

4. File Format

5. Elapsed Time

6. Total Time

7. EQ Animation

8. Song Name

9. Repeat Mode

10. Battery Life

11. EQ Mode

12. Play Rate

2

2. Use

2.1 Power ON/OFF

The MP3 player has built-in a rechargeable battery. At the first use we suggest to recharge the battery for a
long period (around 8 hours). To recharge the battery please connect the MP3 player to USB computer port.
Powering On:
Turn on On/Off button to On position
Powering Off:
Hold the Play [] / Pause [] key until the power-off animation begins
Then, turn the On/Off button to Off position.

2.2 Recharge the Player

The player can be recharged by the provided USB cable by connecting to the PC. During charging, an icon
on the right will show. You should first turn on you PC, and then connect the player to the PC through the
USB cable. The player should be fully charged in 3 to 4 hours.

3. Main Menu

After powering on the MP3 player, you can see the main menu with 8 submenus (optional), which allow you
to select different functions and options.
By using the [] or [] buttons, you can select the desire option, and then press Play button to confirm the
selection.
To access at the main menu while you are inside any of these submenus, press and hold MENU [M] switch
for a few seconds. (Short pressing the MENU [M] switch usually opens the submenu option of each submenu)

3
