Memphis DC12V Instruction Manual

INSTRUCTION MANUAL

3 Way Gas fridge

DC12V /AC 240V /LPG GAS

LEISURE SERIES

CUSTOMER SUPPORT

1300 366 144

AUSTRALIA

0800 283 533

NEW ZEALAND

After sales support TEL: [phone]

GENERAL SAFETY

• Do not operate the device it is visibly damaged.

• Do not damage the cooling system.

• Do not place any electrical devices inside the cooler.

• Ensure that the ventilation slots are not covered.

• Keep to the following distances:

-A gap of at least 10cm at the rear.

-A gap of at least 5cm on either side.

• The cooling device is not suitable for transporting caustic materials or materials containing
solvents.

• Pull out the connection cable or disconnect the hose connection.

-Before cleaning and maintenance.

-After use.

• If the supply cord is damaged, it must be replaced by the manufacturer, its service agent, or

OPERATING THE DEVICE SAFELY

• Electronic devices are not toys.

• This appliance is not intended for use by persons (including young children) with reduced physical,

sensory or mental capabilities, or lack of experience and knowledge, unless they have been given
supervision or instruction concerning use of the appliance by a person responsible for their safety.

• Danger of fatal injury:

Do not touch exposed cables with your bare hands. This is especially applies when operating the
device with an AC mains power supply.

• Never immerse the device in water.

• Protect the device against splashing water.

• Protect the device against and the cable against heat and moisture.

• Only use the device in well vented areas.

• The device may give

a smell for a short time when it is operated.

• Only operate the device from a single energy source.

• Do not place the device near

or other heat sources (heater, direct sunlight, gas ovens).

• Do not

the inner container with ice or

INTENDED USE

The cooler is suitable for cooling foods and drinks. The device is suitable for camping.

The cooler has been designed for operation with a 12V DC voltage source (eg. the cigarette lighter of a
vehicle) or alternatively for operation with a mains voltage of 220-240V AC.

The cooler can be operated independently a voltage supply with liquid gas (LPG).

IMPORTANT:
Place the cooler on a rm and level base. Check the horizontal position
with a spirit level if necessary.
Please note this cooler is an absorbtion cooler which is a silent operation.

OPERATING THE COOLER

Before starting your new cooler for the time, you should clean it inside and outside with a damp
cloth for hygienic reasons. Never use an abrasive product to clean the cooler.

USING THE COOLER:

Cool the cooler for 24 hours before starting your journey using electricity from the mains.
This ensures that your cooler will attain the required cooling capacity faster when you reach
your destination. It is recommended that food and drink is pre cooled before placing into
this appliance. Meat should be pre frozen.

• The ambient temperature.

• Amount of food to be conserved.

• The frequency in which the lid is opened.

Cools to 25˚C below ambient temperature and runs for 28 days on a 9kg gas bottle.

OPERATING THE DEVICE SAFELY WITH GAS

This appliance shall only be used in an above ground open air situation with natural ventilation,
without stagnant areas, where gas leakage and products of combustion are rapidly dispersed by
wind and natural convection.

• Only operate the device with gas outdoors.

• Do not use gas to operate the devise in cars, boats or enclosed spaces.

• When using the device in tents, awnings and on level patios, ensure that there is

air

circulation an ventilation.

• Compare the pressure information on the type plate with the pressure information on the LPG
gas cylinder.

• Do not use another source of energy at the same time (mains).

• The label at the rear of the appliance gives the recommended gas supply pressure other than the

• Store the gas cylinder in a cool, dry and ventilated area, protected from the sunlight and do not

expose to temperatures above 50ºC.

The safety pilot light automatically maintains the gas supply to the burner, as long as it remains lit.

CONNECTING TO A GAS SOURCE

• Only use LPG gas bottles with an approved pressure regulator

• Position the gas bottle vertically at a distance of at least 1 meter away from the burner, on the

back of the cooler.

• Check if the valve on the gas bottle is closed.

• It is recommended that the regulator supplied with this unit is used.

• Connect the hose line to the head of the valve on the gas bottle and the cooler.

• Note: It is possible to convert the POL regulator tting to a 3/4" BSP thread by purchasing

a converter from a reputable camping store.

• The cooler can be operated independently of a voltage supply with liquied petroleum gas (LPG).

• Operation of this appliance should be in accordance with any local gas regulation of AS5601.

• The hose and regulator as supplied is designed to t a standard POL gas tting.
