Memorex MX3905 User Manual
HOME AUDIO SYSTEM WITH CD
PLAYER AND AM/FM STEREO RADIO
MODEL: MX3905
BEFORE OPERATING THIS PRODUCT, PLEASE READ THESE
INSTRUCTIONS COMPLETELY.
OPERATING INSTRUCTIONS
MX3905.O/M.QXD 2/20/03 7:06 AM Page 21
1
WARNING
CAUTION: TO REDUCE THE RISK OF ELECTRIC
SHOCK, DO NOT REMOVE COVER (OR BACK). NO
USER-SERVICEABLE PARTS INSIDE. REFER
SERVICING TO QUALIFIED SERVICE PERSONNEL.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
DANGEROUS VOLTAGE:
The lightning flash with arrowhead symbol,
within an equilateral triangle is intended to alert
the user to the presence of uninsulated
dangerous voltage within the product’s
enclosure that may be of sufficient magnitude to
constitute a risk of electric shock to persons.
ATTENTION:
The exclamation point within an equilateral
triangle is intended to alert the user to the
presence of important operating and
maintenance (servicing) instructions in the
literature accompanying the appliance.
DANGER:
Invisible and hazardous laser radiation when
open and interlock failed or defeated. Avoid
direct exposure to beam.
FCC WARNING:
This equipment may generate or use radio
frequency energy. Changes or modifications to
this equipment may cause harmful interference
unless the modifications are expressly
approved in the instruction manual. The user
could lose the authority to operate this
equipment if an unauthorized change or
modification is made.
SURGE PROTECTORS:
It is recommended to use a surge protector for
AC connection. Lightning and power surges
ARE NOT covered under warranty for this
product.
LASER SAFETY: This unit employs a laser. Only
qualified service personnel should attempt to
service this device due to possible eye injury.
CAUTION: USE OF CONTROLS,
ADJUSTMENTS OR PERFORMANCE
PROCEDURE HEREIN MAY RESULT IN
HAZARDOUS RADIATION EXPOSURE.
INFORMATION:
This equipment has been tested and found to
comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These
limits are designed to provide reasonable
protection against harmful interference in a
residential installation. This equipment generates,
uses, and can radiate radio frequency energy
and, if not installed and used in accordance with
the instructions, may cause harmful interference
to radio communications. However, there is no
guarantee that interference will not occur in a
particular installation. If this equipment does
cause harmful interference to radio or television
reception, which can be determined by turning
the equipment off and on, the user is encouraged
to try to correct the interference by one or more
of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment
and receiver.
• Connect the equipment into an outlet on a
circuit different from that to which the receiver is
connected.
• Consult the dealer or an experienced radio/TV
technician for help.
MX3905.O/M.QXD 2/20/03 7:06 AM Page 1
2
Before using the unit, be sure to read all operating instructions
carefully. Please note that these are general precautions and may not
pertain to your unit. For example, this unit may not have the capability
to be connected to an outdoor antenna.
1. READ INSTRUCTIONS
All the safety and operating instructions should be read before the
product is operated.
2. RETAIN INSTRUCTIONS
The safety and operating instructions should be retained for future reference.
3. HEED WARNINGS
All warnings on the product and in the operating instructions should be
adhered to.
4. FOLLOW INSTRUCTIONS
All operating and use instructions should be followed.
5. CLEANING
Unplug this product from the wall outlet before cleaning. Do not use
liquid cleaners or aerosol cleaners. Use a damp cloth for cleaning.
6. ATTACHMENTS
Do not use attachments not recommended by the product's
manufacturer as they may cause hazards.
7. WATER AND MOISTURE
Do not use this product near water- for example, near a bathtub,
washbowl, kitchen sink, or laundry tub, in a wet basement, or near a
swimming pool.
8. ACCESSORIES
Do not place this product on an unstable cart, stand, tripod, bracket, or
table. The product may fall, causing serious injury and serious damage to
the product. Use only with a cart, stand, tripod, bracket, or table
recommended by the manufacturer or sold with the
product. Any mounting of the product should follow the
manufacturer’s instructions, and should use a mounting
accessory recommended by the manufacturer.
8A. An appliance and cart combination should be moved
with care. Quick stops, excessive force, and uneven
surfaces may cause the appliance and cart
combination to overturn.
9. VENTILATION
Slots and openings in the cabinet and in the back or bottom are
provided for ventilation and to ensure reliable operation of the product
and to protect it from overheating. These openings must not be blocked
or covered. The openings should never be blocked by placing the
product on a bed, sofa, rug, or other similar surface. This product
should never be placed near or over a radiator or heat source. This
product should not be placed in a built-in installation such as a
bookcase or rack unless proper ventilation is provided or the
manufacturer's instructions have been adhered to.
10. POWER SOURCES
This product should be operated only from the type of power source
indicated on the marking label. If you are not sure of the type of power
supply to your home, consult your appliance dealer or local power
company. For products intended to operate from battery power, or
other sources, refer to the operating instructions.
11. GROUNDING OR POLARIZATION
This product is equipped with a polarized alternating-current line plug
(a plug having one blade wider than the other). This plug will fit into the
power outlet only one way. This is a safety feature. If you are unable to
insert the plug fully into the outlet, try reversing the plug. If the plug
should still fail to fit, contact your electrician to replace your obsolete
outlet. Do not defeat the safety purpose of the polarized plug.
12. POWER-CORD PROTECTION
Power-supply cords should be routed so that they are not likely to be
walked on or pinched by items placed upon or against them, paying
particular attention to cords at plugs, convenience receptacles, and the
point where they exit from the appliance.
13. LIGHTNING
To protect your product from a lightning storm, or when it is left
unattended and unused for long periods of time, unplug it from the wall
outlet and disconnect the antenna or cable system. This will prevent
damage to the product due to lightning and power-line surges.
14. POWER LINES
An outside antenna system should not be located in the vicinity of
overhead power lines or other electric light or power circuits, or where it
can fall into such power lines or circuits. When installing an outside
antenna system, extreme care should be taken to keep from touching
such power lines or circuits as contact with them might be fatal.
15. OVERLOADING
Do not overload wall outlets and extension cords as this can result in a
risk of fire or electric shock.
16. OBJECT AND LIQUID ENTRY
Never push objects of any kind into this product through openings as they
may touch dangerous voltage points or short out parts that could result in
fire or electric shock. Never spill or spray any type of liquid on the product.
17. OUTDOOR ANTENNA GROUNDING
If an outside antenna is connected to the product, be sure the antenna
system is grounded so as to provide some protection against voltage
surges and built-up static charges. Section 810 of the National Electric
Code, ANSI/NFPA 70, provides information with respect to proper
grounding of the mast and supporting structure, grounding of the leadin wire to an antenna discharge product, size of grounding conductors,
location of antenna discharge product, connection to grounding
electrodes, and requirements for grounding electrode.
18. SERVICING
Do not attempt to service this product yourself as opening or removing
covers may expose you to dangerous voltage or other hazards. Refer
all servicing to qualified service personnel.
19. REPLACEMENT PARTS
When replacement parts are required, be sure the service technician
uses replacement parts specified by the manufacturer or those that
have the same characteristics as the original part. Unauthorized
substitutions may result in fire, electric shock or other hazards.
20. SAFETY CHECK
Upon completion of any service or repairs to this product, ask the
service technician to perform safety checks to determine that the
product is in proper operating condition.
21. WALL OR CEILING MOUNTING
The product should be mounted to a wall or ceiling only as
recommended by the manufacturer.
22. DAMAGE REQUIRING SERVICE
Unplug the product from the wall outlet and refer servicing to qualified
service personnel under the following conditions:
a. When the power-supply cord or plug is damaged.
b. If liquid has been spilled, or objects have fallen into the product.
c. If the product has been exposed to rain or water.
d. If the product does not operate normally by following the operating
instructions. Adjust only those controls that are covered by the
operating instructions, as an adjustment of other controls may result
in damage and will often require extensive work by a qualified
technician to restore the product to its normal operation.
e. If the product has been dropped or the cabinet has been damaged.
f. When the product exhibits a distinct change in performance - this
indicates a need for service.
23. HEAT
The product should be situated away from heat sources such as
radiators, heat registers, stoves, or other products (including amplifiers)
that produce heat.
24. NOTE TO CATV SYSTEM INSTALLER
This reminder is provided to call the CATV system installer's attention
to Article 820-40 of the NEC that provides guidelines for proper
grounding and, in particular, specifies that the cable ground shall be
connected to the grounding system of the building, as close to the point
of cable entry as practical.
EXAMPLE OF ANTENNA GROUNDING AS PER
NATIONAL ELECTRICAL CODE
IMPORTANT SERVICE SAFETY INSTRUCTIONS
MX3905.O/M.QXD 2/20/03 7:06 AM Page 2
PORTABLE CART WARNING
(symbol provided by RETAC)
3
PREPARATION FOR USE
AC OPERATION
Unwind the AC power cord and extend it to its full length. Insert the AC power cord into any convenient
120V 60Hz household outlet.
Please note that this unit is equipped with a polarized AC
plug which has one blade wider than the other. This is a
safety feature to reduce the likelihood of electric shock. This
polarized AC plug will only fit in a polarized AC outlet. If you
find that you cannot insert this plug into your outlet, you
may have an obsolete non-polarized outlet. Please do not
try to defeat this safety feature by using a non-polarized
adapter or by filing the wider blade to make it fit into your
outlet. If this plug does not fit into your outlet, you should
contact a qualified licensed electrician to replace your obsolete outlet.
SPEAKER CONNECTION
1. Place the speakers in convenient locations on either
side of the unit. Usually a distance of five to eight feet
between speakers provides the best stereo effect, but
this may vary depending on the size and acoustics of
the room.
2. Locate the Speaker Terminals on the rear of the unit
and connect the solid black wires to the red (+) terminals
and connect the striped wires to the black (–) terminals.
3. To connect the speakers, press the terminal down, insert
the speaker wire and press the terminal back to the lock
position.
4. Pull lightly on the connection to make sure it is secure.
5. Connect the Speaker Light cable to the Speaker Light
jacks. These will light up the logo and bottom of the
speakers.
CAUTION: Only connect the speakers which are supplied
with the unit. The use of any other or additional speakers
may cause damage to the unit. Never operate the unit
without the speakers connected.
MX3905.O/M.QXD 2/20/03 7:06 AM Page 3
AC Outlet
AC Plug
RL
4
PREPARATION FOR USE (CONTINUED)
BATTERY OPERATION
The battery compartment is located on the rear of the remote control.
• Remove the battery compartment door by pressing down and sliding the door in
the direction of the arrow.
• Insert two (2) AA size batteries into the battery compartment as shown to the right.
Be sure to observe the polarity markings which are engraved inside the battery
compartment. If the batteries are inserted incorrectly, the remote control will not
operate.
• Replace the battery compartment door.
REMOTE SENSOR:
To operate the unit with the remote control, point the remote at the remote sensor on the front of the main
unit and press the appropriate button. The remote control has an effective operating range of approximately
15 feet and an angle of no more than 30°.
NOTE: Bright sunlight may interfere with the operation of the remote control.
BATTERY PRECAUTIONS
Follow these precautions when using batteries in this device:
1. Use only the size and type of batteries specified.
2. Be sure to follow the correct polarity when installing the batteries as indicated in the battery
compartment. Reversed batteries may cause damage to the device.
3. Do not mix different types of batteries together (e.g. Alkaline and Carbon-zinc) or old batteries with fresh
ones.
4. If the device is not to be used for a long period of time, remove the batteries to prevent damage or injury
from possible battery leakage.
5. Do not try to recharge batteries not intended to be recharged; they can overheat and rupture.
(Follow battery manufacturer’s directions.)
MX3905.O/M.QXD 2/20/03 7:06 AM Page 4
+
—
—
+
5
LOCATION OF CONTROLS AND INDICATORS
1. COLOR MODE Button
2. VOLUME +/– Buttons
3. DISPLAY Button
4. TUNING/CD Skip/Search /
Buttons
5. MEMORY/CLOCK SET Button
6. STOP(■)/BAND Button
7. PLAY/PAUSE
( ) Button
8. CD Function Button
9. TUNER Button
10. PRESET EQ Button
11. Speaker/Speaker Light Terminals (Rear
of Unit)
12. AC Cord (Rear of Unit)
13. FM Wire Antenna (Rear of Unit)
14. POWER Button
15. CD Compartment
16. Display
17. RANDOM Button
18. REPEAT/MEMORY UP Button
19. Headphones Jack
20. CD OPEN/CLOSE Button
MAIN UNIT
MX3905.O/M.QXD 2/20/03 7:06 AM Page 5
12 3
45 789106
171612 1311 18 19 2014 15
6
LOCATION OF CONTROLS AND INDICATORS
1. FUNCTION Button
2. Direct Track Selection Buttons
3. OVER Button
4. PLAY/PAUSE Button
5. STOP/BAND Button
6. TUNING DN/UP Buttons
7. RANDOM Button
8. DISPLAY Button
9. INTRO Button
10. REP (Repeat)/MEM (Memory Up)
Button
11. SNOOZE Button
12. TIMER Button
13. POWER Button
14. MUTE Button
15. VOLUME +/– Buttons
16. PRESET EQ Button
17. MEM (Memory)/CLOCK Button
18. SLEEP Button
REMOTE
MX3905.O/M.QXD 2/20/03 7:06 AM Page 6
113
2
10
11
12
3
4
5
6
7
8
9
14
15
16
17
18
Loading...
