Memorex MX3300 Multimedia User guide

Office Keyboard

MX3300 Multimedia

SER’S

UIDE

VERSION 1.0

IMPORTANT

The information in this document is subject to change without notice and does not represent a commitment on the part of the vendor.

No warranty of representation, either expressed or implied, is made with respect to the quality, accuracy or fitness for any particular purpose of this document. The manufacturer reserves the right to make changes to the content of this document and/or the products associated with it at any time without obligation to notify any person or organization of such changes.

In no event will the manufacturer be liable for direct, indirect, special, incidental or consequential damages arising out of the use or inability to use this product or documentation, even if advised of the possibility of such damages.

IBM, PC/AT and PS/2 are registered trademarks of International Business Machines Corporation.

NOTICE!

Microsoft, Windows, and Windows NT are registered trademarks of Microsoft Corporation in the United States of America and/or other countries.

All other trademarks are trademarks of their respective holders.

TABLE OF CONTENTS

1.Introduction 1

What's in this package 1

2.System Requirements 2

3.Software Installation 2

4.Hardware Installation 3

5.Smart Office Keyboard Software 3

5.1 To Display the "KeyMaestro" Dialogue Box 3

5.2 To Display the "Configure Button" Dialogue Box 4

6.Hot Keys Features 5

6.1 Office Application Keys 5

6.2 Internet Keys 6

6.3 Application Keys 6

6.4 Multimedia Keys 7

6.5 Enhanced Function Keys 7

6.6 Programmable Scroll Wheel 8

6.7 Clipboard Keys 9

7.Uninstall Key Maestro Driver Software 9

8.Troubleshooting 10

1. Introduction

Congratulations on your purchase of the Memorex MX3300 Smart Office Keyboard! This unique keyboard provides quick access to applications, clipboard and multimedia functions with minimal mouse movement and an ergonomic design.

The Memorex MX3300 Smart Office Keyboard is divided into 6 blocks plus the normal alpha-numeric keys. The 6 blocks are Office Application Keys, Enhanced Function Keys, Internet Keys, Application Keys, Multimedia Keys and Clipboard Keys. These keys make your keyboard more powerful than ever. The applications and functions you use everyday are included in these blocks; at the touch of a button you can access them all immediately and save time in your daily computer usage.

The Memorex MX3300 Smart Office Keyboard is creatively designed to use the built-in Office and clipboard hot keys. The built-in programmable scroll wheel helps save hand-movement between the keyboard and the mouse.

The Memorex MX3300 Smart Office Keyboard is compatible with Windows

95*/98/Me/NT 4.0**/2000/XP.

In order to enjoy the full potential of the Memorex MX3300 Smart Office Keyboard, please read this manual carefully.

* OSR2 or higher version ** PS/2 connection only. Service pack 6 or higher

What’s in this package

• Smart Office Keyboard with USB connector

• Software CD

• USB to PS/2 Adapter

• Removable Ergonomic Wrist Rest

• Instruction Manual

2. System Requirements

Note: For Windows®95* and Windows®NT 4.0** operating system users or users with a system with only a PS/2 port, please use USB to PS/2 adapter (enclosed in the package) to connect the keyboard.

• Microsoft Windows®95/98/Me/NT 4.0/2000/XP

• Microsoft

Internet Explorer 5.0 or later version (for the Internet keys)

• CD-ROM or DVD drive (for CD or Video operation)

• Standard sound card (for CD or Video operation)

• USB port or PS/2 port

• Microsoft

Office 97 or later version (for Office Application keys and

Enhanced Function keys)

• System support for ACPI or APM II (for power management buttons)

•ATX mother board and ATX power supply (for power management buttons)

* OSR2 or higher version ** PS/2 connection only. Service pack 6 or higher

3. Software Installation

After completing the hardware installation and turning the PC power on you will have immediate access to the alpha-numeric keys of the keyboard. In order to utilize the specialty keys you must first install the keyboard software using the CD included in the box.

O INSTALL THE KEYBOARD SOFTWARE:

Step 1: Remove any existing keyboard software from the computer.

Refer to your keyboard manufacturer’s user guide.

Step 2: Insert the software CD in your computer's CD-ROM drive and

the software should auto start.

Step 3: If using the USB to PS/2 Adapter, select "Install Memorex MX3300

Office Keyboard Series (For PS/2)".

Step 4: If using the USB Keyboard plug, select "Install Memorex MX3300

Office Keyboard Series (For USB)". Step 5: Follow onscreen instructions to finish the installation procedure. Step 6: If the software installation does not auto start, then:

I. Double click on "My Computer" on your computer's desktop.

II. Double Click on your CD-ROM drive.

III. Double click on either "Memorex MX3300 Office Keyboard

Series (For USB)" or "MX3300 Office Keyboard Series (For PS/2)" and follow the onscreen instructions.
