Memorex MVT2137 User Manual

OWNER’S MANUAL
MANUAL DE INSTRUCCIONES

AC/DC COMBINATION 13" COLOR TELEVISION
AND VIDEO CASSETTE RECORDER
CA/CD COMBINACION DE 13" TELEVISOR A
COLOR Y VIDEO GRABADOR

MVT2137

ATTENTION

ATENCION

If you purchase a universal remote control from your local retailer, please
contact the remote manufacturer for the required programming code.
Si usted a comprado un control remoto universal, por favor comunicace con
el fabricante para el codico de programaccion requerido.

ENGLISH

ESPAÑOL

When shipped from the factory , the TV/CATV menu option is set to the "CA TV"

SELECCION DE MODO DE TV/CATV

(Cable Television) mode.
If not using CATV, set this menu option to the "TV" position.
Al salir la unidad de fábrica, la opción de menú de TV/CATV se ajusta al modo
de "CATV" (Televisión por cable).
Si no utiliza CATV, ajuste esta opción de menú al modo de "TV".

Before operating the unit, please read this manual thoroughly.
Antes de usar la unidad, lea detenidadmente este manual de instrucciones.

5A3A901A E COV. 3/18/02, 10:06 PM1

TV/CATV MODE SELECTION

ENGLISH

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

CAUTION:

TO REDUCE THE RISK OF ELECTRIC SHOCK, DO
NOT REMOVE COVER (OR BACK). NO USER­SERVICEABLE PAR TS INSIDE. REFER SER VICING
TO QUALIFIED SERVICE PERSONNEL.

The lightning flash with arrowhead symbol,
within an equilateral triangle is intended to
alert the user to the presence of uninsulated
dangerous voltage within the product's
enclosure that may be of sufficient magnitude
to constitute a risk of electric shock.

The exclamation point within an equilateral
triangle is intended to alert the user to the
presence of important operating and
maintenance (servicing) instructions in
the literature accompanying the appliance.

WARNING:

NOTE:

Please keep all packaging material for at least 90 days in case you need to return this product to your place of purchase
or Memorex.

WARNING:

This equipment has been tested and found to comply
with the limits for a Class B digital device, pursuant to
Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interfer­ence in a residential installation. This equipment
generates, uses and can radiate radio frequency energy
and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio
communications.
However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does
cause harmful interference to radio or television recep­tion, which can be determined by turning the equipment
off and on, the user is encouraged to try to correct the

TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR
MOISTURE.

interference by one or more of the following measures:

- Reorient or relocate the receiving antenna.

- Increase the separation between the equipment and
receiver.

- Connect the equipment into an outlet on a circuit
different from that to which the receiver is connected.

- Consult the dealer or an experienced radio/TV
technician for help.

CAUTION:

Changes or modifications not expressly approved by the
party responsible for compliance with the FCC Rules
could void the user's authority to operate this equipment.

IMPORTANT SAFEGUARDS

1. READ INSTRUCTIONS

All the safety and operating instructions should be
read before the unit is operated.

2. RETAIN INSTRUCTIONS

The safety and operating instructions should be
retained for future reference.

3. HEED WARNINGS

All warnings on the unit and in the operating
instructions should be adhered to.

4. FOLLOW INSTRUCTIONS

All operating and use instructions should be followed.

5. CLEANING

Unplug this unit from the wall outlet before cleaning.
Do not use liquid cleaners or aerosol cleaners.
Use a damp cloth for cleaning the exterior cabinet only.

6. ATTACHMENTS

The manufacturer of this unit does not make any
recommendations for attachments, as they may
cause hazards.

7. WA TER AND MOISTURE

Do not use this unit near water. For example, near a
bathtub, washbowl, kitchen sink, laundry tub, in a
wet basement, or near a swimming pool.

8. ACCESSORIES

Do not place this unit on an unstable cart, stand,

tripod, bracket, or table.
The unit may fall, causing serious injury, and
serious damage to the unit.

8A. An appliance and cart

combination should be
moved with care.
Quick stops, excessive
force, and uneven
surfaces may cause
the appliance and cart
combination to overturn.

PORTABLE CART WARNING

(symbol provided by RETAC)

S3126A

2

5A3A901A E P02-11 3/18/02, 10:06 PM2

IMPORTANT SAFEGUARDS

9. VENTILATION

Slots and openings in the cabinet back or bottom
are provided for ventilation, and to ensure reliable
operation of the unit, and to protect it from overheat­ing. These openings must not be blocked or
covered. The openings should never be blocked by
placing the unit on a bed, sofa, rug, or other similar
surface. This unit should never be placed near or
over a radiator or heat source. This unit should not
be placed in a built-in installation such as a
bookcase or rack unless proper ventilation is
provided or the manufacturer’s instructions have
been adhered to.

10. POWER SOURCES

This unit should be operated only from the type of
power source indicated on the rating plate. If you
are not sure of the type of power supply to your
home, consult your appliance dealer or local power
company. For units intended to operate from battery
power, or other sources, refer to the operating
instructions.

11. GROUNDING OR POLARIZATION

This unit is equipped with a polarized alternating­current line plug (a plug having one blade wider
than the other). This plug will fit into the power outlet
only one way. This is a safety feature. If you are
unable to insert the plug fully into the outlet, try
reversing the plug. If the plug should still fail to fit,
contact your electrician to replace your obsolete
outlet. Do not defeat the safety purpose of the
polarized plug, if your unit is equipped with a 3-wire
grounding-type plug, a plug having a third (ground­ing) pin. This plug will only fit into a grounding-type
power outlet. This too, is a safety feature. If you are
unable to insert the plug into the outlet, contact your
electrician to replace your obsolete outlet.
Do not defeat the safety purpose of the grounding­type plug.

12. POWER-CORD PROTECTION

Power-supply cords should be routed so that they are
not likely to be walked on or pinched by items placed
upon or against them, paying particular attention to
cords at plugs, convenience receptacles, and the point
where they exit from the appliance.

13. LIGHTNING

To protect your unit from a lightning storm, or when
it is left unattended and unused for long periods of
time, unplug it from the wall outlet and disconnect
the antenna or cable system. This will prevent
damage to the unit due to lightning and power line
surges.

14. POWER LINES

An outside antenna system should not be located in
the vicinity of overhead power lines or other electric
light or power circuits, or where it can fall into such
power lines or circuits. When installing an outside
antenna system, extreme care should be taken to
keep from touching such power lines or circuits, as
contact with them might be fatal.

15. OVERLOADING

Do not overload wall outlets and extension cords, as
this can result in a risk of fire or electric shock.

16. OBJECT AND LIQUID ENTRY

Do not push objects through any openings in this unit,
as they may touch dangerous voltage points or short
out parts that could result in fire or electric shock. Never
spill or spray any type of liquid into the unit.

17. OUTDOOR ANTENNA GROUNDING

If an outside antenna or cable system is connected
to the unit, be sure the antenna or cable system is
grounded to provide some protection against
voltage surges and built-up static charges, Section
810 of the National Electrical Code, ANSI/NFPA 70,
provides information with respect to proper ground­ing of the mast and supporting structure, grounding
of the lead-in wire to an antenna discharge unit, size
of grounding conductors, location of antenna
discharge unit, connection to grounding electrodes,
and requirements for the grounding electrode.

18. SERVICING

Do not attempt to service this unit yourself as
opening or removing covers may expose you to
dangerous voltage or other hazards. Refer all
servicing to qualified service personnel.

ENGLISH

5A3A901A E P02-11 3/18/02, 10:06 PM3

3

IMPORTANT SAFEGUARDS

19. DAMAGE REQUIRING SERVICE

Unplug this unit from the wall outlet and refer
servicing to qualified service personnel under the
following conditions:

a. When the power-supply cord or plug is damaged.
b. If liquid has been spilled, or objects have fallen

into the unit.
c. If the unit has been exposed to rain or water.
d. If the unit does not operate normally by

following the operating instructions. Adjust only

those controls that are covered by the operat-

ing instructions, as an improper adjustment of

other controls may result in damage and will

often require extensive work by a qualified

technician to restore the unit to its normal

operation.
e. If the unit has been dropped or the cabinet has

been damaged.

. When the unit exhibits a distinct change in

f

performance, this indicates a need for service.

20. REPLACEMENT PARTS

When replacement parts are required, be sure the
service technician uses replacement parts specified
by the manufacturer or those that have the same
characteristics as the original part.
Unauthorized substitutions may result in fire, electric
shock or other hazards.

21. SAFETY CHECK

Upon completion of any service or repairs to this
unit, ask the service technician to perform safety
checks to determine that the unit is in proper
operating condition.

22. WALL OR CEILING MOUNTING

The product should be mounted to a wall or ceiling
only as recommended by the manufacturer.

23. HEAT

The product should be situated away from heat
sources such as radiators, heat registers, stoves, or
other products (including amplifiers) that produce heat.

24. NOTE TO CATV SYSTEM INSTALLER

This reminder is provided to call the CATV system
installer’s attention to Article 820-40 of the NEC that
provides guidelines for proper grounding and, in
particular, specifies that the cable ground shall be
connected to the grounding system of the building,
as close to the point of cable entry as practical.

EXAMPLE OF ANTENNA GROUNDING AS PER THE

ELECTRIC SERVICE

EQUIPMENT

NEC-NATIONAL ELECTRICAL CODE

S2898A

4

5A3A901A E P02-11 3/18/02, 10:06 PM4

NATIONAL ELECTRICAL CODE

ANTENNA LEAD IN WIRE

GROUND CLAMP

ANTENNA DISCHARGE UNIT
(NEC SECTION 810-20)

GROUNDING CONDUCTORS
(NEC SECTION 810-21)

GROUND CLAMPS
POWER SERVICE GROUNDING

ELECTRODE SYSTEM
(NEC ART 250, PART H)

SAFETY PRECAUTIONS

MOISTURE CONDENSATION

DO NOT OPERATE ANY FUNCTIONS ON THIS UNIT
FOR AT LEAST TWO OR THREE HOURS WHEN
MOISTURE IN THE AIR CONDENSES ON IT. LET THE
UNIT STAND WITH POWER ON (SEE BELOW).

■ WHAT IS MOISTURE CONDENSATION?

When a cold liquid is poured into a glass, for example,
water vapor in the air will condense on the surface of
the glass. This is called moisture condensation.

■ MOISTURE WILL CONDENSE ON THE UNIT IN

THE FOLLOWING CASES:

• When you move the unit from a cold to a warm place.

• After heating a cold room or under extremely humid

conditions.

■ WHEN YOU EXPERIENCE THE ABOVE CONDI-

TIONS,

"DEW" appears on the screen and all the function
buttons except the EJECT button (or the STOP/
EJECT button on the unit) are made non-operational
to protect the video heads. In this case, eject the
video cassette, leave the unit turned on and let it
remain at room temperature until moisture condensa­tion disappears. Depending on the surrounding
conditions, this may take two or three hours.

LOCA TION AND HANDLE

• If you cause a static discharge when touching the unit,
and the unit fails to function, simply unplug the unit
from the wall outlet, wait one hour and plug it back in.
The unit should return to normal operation.

• Avoid extreme heat or cold (41˚F/5˚C-104˚F/40˚C).

• Do not place the unit on or near appliances which may

cause electromagnetic interference (e.g. speakers,
etc). Doing so may cause erratic operation of the unit
including picture and/or sound distortion or noise.

• Avoid extreme moisture and dust.

• The ventilation holes prevent overheating. Do not

block or cover these holes. Especially avoid covering
the holes with soft materials such as cloth or paper.

• Do not insert fingers or any other objects into the
cassette loading slot. Do not spray cleaner or wax
directly on the unit or use forced air to remove dust.

• Avoid places subject to strong vibration. Use in a
horizontal (flat) position only.

• Keep the unit away from flower vases, sinks, etc.
If liquids should be spilled into the unit, serious damage
will result. If you spill any liquids into the unit, unplug the
AC power cord immediately and consult qualified
service personnel before attempting to use it again.

• When you finish operating the unit, always unload the
cassette and turn off the power.

• When you leave your home for a long time, unplug the
AC power cord.

• To protect the unit from a lightning storm, unplug the
AC power cord from the wall outlet and disconnect the
antenna.

INSTALL THE TV/VCR IN YOUR CAR

• For a car equipped with air bags, be sure to follow the
manufacturer’s instructions whenever performing any
electrical wiring work. Incorrect wiring can cause the air
bag system of a car to malfunction.

• Never cut the insulation from the power supply lead in
an attempt to draw power for another device.
Doing so can overload the current capacity of the
lead, creating the danger of fire and electric shock.

• For proper installation and wiring, special technical
knowledge is required. If you have any doubts about
where to position or how to install components,
contact the retailer where you purchased the product,
your automobile dealership, or an automotive service
provider. Note that you will be charged separately for
installation work.

• Use all of the components that come with this product
only as directed. Improper use of components can
damage interior components or result in improper
anchoring of components, which creates the danger of
accident and personal injury.

• Improper installation creates the danger of fire and
accident.

• Take care so wires are not pinched between chassis
parts, by screws, or by the seat as it slides on its rails,
etc. Such conditions can cut wires and cause shorts,
creating the danger of accident, electric shock, and fire.

• Avoid installation in areas subject to strong vibration
and areas where secure anchoring cannot be
achieved. Components installed in such areas can
work loose, creating the danger of accident and
personal injury.

• Never install the TV/VCR on the dashboard or in any
other location where it obstructs forward vision.

• Never attach the stand to the roof of your car. Doing
so creates the danger of the TV/VCR falling down.

• Never attach the stand to a sharply angled surface or to
a surface that causes the TV/VCR to face downwards.
Such installation can cause the TV/VCR to fall.

• Be sure to turn the ignition key of the car to the “OFF”
position before connecting or disconnecting wires and
cables. Failure to do so creates the danger of electric
shock and personal injury.

5

ENGLISH

5A3A901A E P02-11 3/18/02, 10:06 PM5

SAFETY PRECAUTIONS

WARNING!

DRIVING SAFETY

• Never watch the TV/VCR or try to adjust settings while driv­ing. Doing so creates the danger of traffic accident. Before
operating the TV/VCR, be sure to stop the car in a safe area.

• Never install the unit on the dashboard or in any other
location where it obstructs forward vision. Items that
obstruct forward vision in a motor car may be illegal.
Also, make sure that all components are installed where
they do not interfere with operation of the steering wheel,
shift lever, brake pedal, etc., for example under the driver’s
seat, and where they do not endanger passengers.
Improper installation creates the danger of traffic accident
and personal injury.

• Make sure all cables are bundled together so they do not
interfere with car operation, as described in this manual.
Improperly installed cables create the danger of entangle­ment with the steering wheel, shift lever, brake pedal, etc.

IMPORTANT NOTES:

• The unit is designed for use with a 12V DC automotive
power supply. Never use it in a truck, bus, or any other
car that has a 24V power supply.

• Be sure to stop your car in a safe area before watching or
adjusting the TV/VCR.

• Operating the TV/VCR for a long time with the engine of
your car stopped can run down your car’s battery.

• Never leave the TV/VCR in areas exposed to temperature
extremes or strong direct sunlight. Leaving it in a closed
car, in direct sunlight, near a heater, etc. can cause
deformation of the case. Using this product in areas that
are colder than 5°C (41°F) or hotter than 40°C (104°F)
can result in poor image quality.

• Never use benzene or other chemical agents for cleaning.
Chemicals can damage the case and remove markings.
Use a soft cloth moistened with a weak solution of water
and mild neutral detergent. Wring out all excess moisture
from the cloth before wiping.

• Never drop the TV/VCR or otherwise subject it to strong
impact.

• Should the TV/VCR ever begin to emit smoke, abnormal
odor, or a strange noise, immediately turn off power and
unplug the unit from the cigarette lighter socket. Contin­ued use of the TV/VCR under any of these conditions
creates the danger of fire and electric shock.

• Do not continue to use the TV/VCR if it is malfunctioning
and does not produce a video image or sound.
Whenever you notice such symptoms, immediately turn
off power, unplug the TV/VCR from the cigarette lighter
socket. Continued use of the TV/VCR creates the danger
of fire and electric shock.

6

• When you leave your car unattended for long periods, be
sure to unplug the TV/VCR from the cigarette lighter
socket. Leaving the TV/VCR plugged in can run down the
car’s battery.

FEATURES

Color TV With Video Cassette Recorder - Unique space

saving design combines a color TV and a video cassette
recorder.

High Quality Picture Technology - This TV/VCR equipped
“HQ” incorporates VHS High Quality technology . A built-in
detail enhancer is used to boost the recorded signal and
provide maximum picture quality during playback. It is
compatible with other VHS video cassette recorders.

120V AC or DC Operation - This TV/VCR is designed to
operate from household AC current or from a 12V DC car
cigarette lighter socket.

181 Channel Tuner - Receives standard VHF and UHF
broadcast channels and up to 113 cable channels. The
actual number of channels received depends upon channel
reception in your area or your cable system.

Closed Caption Decoder With Full Text Mode - Displays
text captions or full screen text on the screen for hearing
impaired viewers.

8-Programs/1-Month Programmable Timer With Every­day/Every Week Capability - The built-in timer allows

automatic absentee recording of up to 8 TV programs within
1 month. It is also possible to record a program which is
broadcast at the same time everyday or every week.

Automatic Clock Set - Once your TV/VCR is connected to
an antenna or Cable TV, and also connected into the AC
outlet, it automatically sets the correct date and time.

On-Screen TV Display And VCR Programming - When
you select a channel or make other changes, the TV will
show an indicator on the screen for a few seconds. Timer
recording can be programmed and confirmed on the screen.

Picture Adjustments Using The Remote Control - The
On-Screen display allows precise remote control adjustment
of BRIGHTNESS, CONTRAST, COLOR, TINT and SHARP­NESS.

Automatic Playback/Rewind-Stop-Eject - When loading a
cassette tape without the erase prevention tab, this TV/VCR
will automatically play back the cassette tape at the correct
speed. When a tape reaches its end during play-back,
recording

(except during OTR and Timer Record) and fast
forward, it will automatically stop, rewind, stop and eject the
tape.

5A3A901A E P02-11 3/18/02, 10:06 PM6

FEATURES TABLE OF CONTENTS

Programmable ON/OFF Timer - Allows you to automatically

turn on or off the TV/VCR at a set time.

Programmable TV Sleep Timer - Operable from the remote
control, the TV can be programmed up to 120 minutes to turn
off automatically.

Automatic Repeat Play System - When Auto Repeat option
is turned on, the TV/VCR will automatically play back the
same cassette tape repeatedly.

One-touch Timer Recording (OTR) - Simply by pressing
the REC/OTR button, the TV/VCR can be programmed for
up to 5 hours of recording with an immediate start.

Audio/Video Input /Output Jacks - A VCR or other video
device may be hooked up to this TV/VCR for dubbing or
playback purposes.

Skip Search - When the SKIP SEARCH button on the
remote control is pressed during playback, the TV/VCR will
automatically search forward in 30 second increments to a
maximum of 3 minutes with each press of the SKIP SEARCH
button, and then return to normal playback.

2 Speed Picture Search - 3 or 5 times normal speed in SP
mode (7X or 9X in LP and 9X or 15X in SLP).

3 Speed Playback - Plays three tape speeds (SP, LP, SLP).

2 Speed Record - Records two tape speeds (SP , SLP).

Real Time Tape Counter With Zero Return - The counter

displays the real tape time and the zero return can be used
to return the tape to a pre-selected position (00:00:00) while
the counter can be used to locate programs.

Digital Auto Tracking - Automatically adjusts tracking
during playback for the best possible picture.

On-Screen 3 Language Display - You can select one of 3
languages, English, Spanish or French for on-screen
programming.

TV Monitor - When the TV MONI. button on the remote
control is pressed during playback, the TV channel selected
on the TV/VCR can be viewed.

CAUTIONS

IMPORTANT SAFEGUARDS ..................................... 2

SAFETY PRECAUTIONS ........................................... 5

PREPARATION

FEATURES................................................................. 6

LOCATION OF CONTROLS....................................... 8

REMOTE CONTROL .................................................. 9

POWER SOURCES ................................................. 10

ANTENNA CONNECTIONS ..................................... 11

CABLE TV CONNECTIONS ..................................... 12

SETTING THE LANGUAGE ..................................... 12

AUTO CLOCK SETTING.......................................... 13

MANUAL CLOCK SETTING ..................................... 14

TV OPERATION

TV OPERATION ....................................................... 14

TO MEMORIZE CHANNELS .................................... 16

SETTING THE V-CHIP ............................................. 17

TO SET THE ON TIMER .......................................... 18

TO SET THE OFF TIMER......................................... 19

PICTURE CONTROL ADJUSTMENTS.................... 19

PLAYBACK

LOADING AND UNLOADING.....................................

PLAYBACK............................................................... 20

SPECIAL PLAYBACK ............................................... 21

20

RECORDING

RECORDING A TV PROGRAM................................ 21

ONE-TOUCH TIMER RECORDING (OTR) .............. 22

TIMER RECORDING................................................ 22

ADDITIONAL INFORMATION

USING THE REAL TIME TAPE COUNTER.............. 23

USING ZERO RETURN ........................................... 23

DUPLICATING A VIDEO TAPE................................. 24

RECEPTION DISTURBANCES................................ 25

VIDEO HEAD CLEANING ........................................ 25

TROUBLESHOOTING GUIDE ................................. 26

SPECIFICATIONS.................................................... 28

ENGLISH

V-Chip - The V-Chip function can read the rating of a TV

program or movie content if the program is encoded with this
information. V-chip will allow you to set a restriction level.

5A3A901A E P02-11 3/18/02, 10:06 PM7

7

LOCATION OF CONTROLS

REARFRONT

20

1

4

5

14

Rec/OtrPower

6

7

T-Re c

Video – In – Audio

Phones Power

8

2

Volu me

9

Channel

10

3

Stop/
Eject

Rew Play F.Fwd

11

Rec/Otr

1312

DESCRIPTION OF CONTROLS

FRONT:

1. Cassette Loading Slot - To insert or remove a

video tape.

2. POWER Button - Press to turn the TV/VCR on or off.

3. STOP/EJECT Button - Press once to stop the tape in

any mode. Press again to eject the tape.

4. F.FWD (Fast Forward) Button - In the Stop mode,
this button rapidly winds the tape forward. In the Play
mode, this button activates forward search.

5. POWER Indicator - Lights when the power is turned
on.

6. REC/OTR Indicator - Lights when the TV/VCR is re­cording.

7. T-REC Indicator - This lights when the TIMER REC
button is pressed.

8. PHONES Jack - Plug monaural headphones or an
earphone with an 1/8" miniplug into one or both of
these jacks for private listening. Two people can use
these jacks at the same time.

9. VOLUME ▲ / ▼ Buttons - Press to raise or lower
the volume of the sound.

CHANNEL ▲ / ▼ Buttons - Press to select a channel

10.

for viewing or recording.

11. REW (Rewind) Button - In the Stop mode, this
button rapidly winds the tape backwards. In the Play
mode, this button activates reverse search.

8

VIDEO

AUDIO

LINE1OUT

16

1817

19

15

12. PLAY Button - Press to play a prerecorded tape.

13. REC/OTR Button - Press once to start normal

recording. Additional presses activate One-touch
Timer Recording.

14. Remote Sensor - Signals from the Remote Control
are received here.

15. Audio/Video In (LINE 2) Jacks - Audio and video
signal cables from an external source can be
connected here.

REAR:

16. VHF/UHF Antenna Jack - Connect the 75 ohm

coaxial cable from the antenna or Cable TV service
to this jack.

17. AUDIO/VIDEO OUT Jacks - Used to output audio
and video signals to a TV, amplifier or VCR.

18. AUDIO/VIDEO IN (LINE 1) Jacks - Audio and video
signal cables from an external source can be
connected here.

19. AC Power Cord - Connect to a 120V, 60Hz outlet.

20. DC Input Jack - Connect the 12V DC car cord

(supplied) here for DC operation.

5A3A901A E P02-11 3/18/02, 10:07 PM8

REMOTE CONTROL

POWER SLEEP TV MONI. EJECT

QUICK VIEW

MUTINGINPUT SELECT

REC/OTR

SPEED

PLAY

STOP

F.FWDREW

MENU

AUTO

TRACKING

TV/CAP/

TEXT

SKIP

SEARCH

COUNTER

RESET

ZERO

RETURN

PROGRAM

ENTER

TIMER REC

PAUSE/STILL

CHANNEL

CALL

123

456

7809

–

+

VOLUME

–

+

– +

SET/TRACKING

CANCEL

1

2

3

7809

4

5

6
7

8
9

1. POWER Button - Press to turn the TV/VCR on.

Press again to turn the TV/VCR off.

2. Direct Channel Selection Buttons (0-9) - Allows
direct access to any channel.

3. CALL Button - Displays the present time/day of the
week, channel, counter, speed selection (and VCR
mode if VCR is playing) on the TV screen.

4. REC/OTR Button - Press once to start normal
recording. Additional presses activate One-touch
Timer Recording.

5. REW (Rewind) Button - In the Stop mode, this
button rapidly winds the tape backwards. In the Play
mode, this button activates reverse search.

6. SPEED Button - Sets the tape speed for recording.

7. MENU Button - Press to display the On-Screen

menu function.

8. PROGRAM Button - Press to confirm the pro­grammed timer recording and ON/OFF timer.

9. SKIP SEARCH Button - Press in the playback
mode to search forward in 30 second increments to
a maximum of 3 minutes.

10. TV MONI. Button - Used to temporarily view a TV
channel selected on the TV/VCR while in the
playback mode.

11. CHANNEL Up / Down Buttons - Press the Up
button to change to a higher numbered channel set
into memory. Press the Down button to change to a
lower numbered channel set into memory.

12. QUICK VIEW Button - Switches between the present
channel and the last channel selected.

13. MUTING Button - Press to turn off the sound. Press
again to turn the sound back on.

14. F.FWD (Fast Forward) Button - In the Stop mode,
this button rapidly winds the tape forward. In the
Play mode, this button activates forward search.

5A3A901A E P02-11 3/18/02, 10:07 PM9

POWER SLEEP TV MONI. EJECT

123

456

CALL

QUICK VIEW

REC/OTR

PLAY

SPEED

STOP

SET/TRACKING

– +

MENU

AUTO

TV/CAP/

TRACKING

TEXT

PROGRAM

COUNTER

SKIP

RESET

SEARCH

CHANNEL

VOLUME

MUTINGINPUT SELECT

PAUSE/STILL

F.FWDREW

ENTER

CANCEL

TIMER REC

ZERO

RETURN

10

+

–

+

–

11

12

13

14

15

16

17

18

19

20

21

DESCRIPTION OF CONTROLS

15. AUTO TRACKING Button - Allows automatic

adjustment of tracking to minimize picture noise
during playback.

16. TV/CAP/TEXT Button - Switches between Caption,
Text and TV modes for Closed-Captioned programs.

17. SLEEP Button - Sets the TV to turn off automati­cally after up to 120 minutes.

18. INPUT SELECT Button - Switches the program for
viewing between the TV/VCR and external input
sources.

19. PLAY Button - Press to play a prerecorded tape.

20. SET/TRACKING + / – Buttons - Used to set or

adjust in the menu mode. During playback, they are
used to adjust tracking manually.

21. COUNTER RESET Button - Used to reset the
counter to 00:00:00.

22. EJECT Button - Press to eject the tape.

23. VOLUME Up / Down Buttons - Press the Up

button to increase, or the Down button to decrease
the volume level.

24. PAUSE/STILL Button - During recording, this
button temporarily stops the tape. During playback,
it stops the tape and displays a still image on the TV
screen.

25. STOP Button - Press once to stop the tape.

26. ENTER Button - Press to enter or select information

for on-screen operations.

27. CANCEL Button - Used to clear the selected
program and to move the cursor backward.

28. TIMER REC Button - Used to set the TV/VCR to
start recording at a preset time (Timer program must
be set).

29. ZERO RETURN Button - Used to stop the tape
when the counter reaches 00:00:00.

22

23

ENGLISH

24

25
26

27
28
29

9

REMOTE CONTROL

POWER SOURCES

BATTERY INSTALLATION

Slide the battery compartment cover.
Install two “AAA” batteries (not supplied), paying

attention to the polarity diagram in the battery compart­ment.

Replace the compartment cover.

BATTERY PRECAUTIONS

The precautions below should be followed when using
batteries in this device:

1 Use only the size and type of batteries specified.
2 Be sure to follow the correct polarity when installing

the batteries as indicated in the battery compartment.
Reversed batteries may cause damage to the device.

3 Do not mix different types of batteries together (e.g. Al-

kaline and Carbon-zinc) or old batteries with fresh ones.

4 If the device is not to be used for a long period of time,

remove the batteries to prevent damage or injury from
possible battery leakage.

5 Do not try to recharge batteries not intended to be

recharged; they can overheat and rupture (Follow
battery manufacturer’s directions).

EFFECTIVE DISTANCE OF THE
REMOTE CONTROL

Use the AC polarized line cord provided for operation on
AC. Insert the AC cord plug into a standard 120V 60Hz
polarized AC outlet.

NOTES: • Never connect the AC line cord plug to

anything other than the specified voltage (120V
60Hz). Use the attached power cord only.

• If the polarized AC cord does not fit into a
nonpolarized AC outlet, do not attempt to file
or cut the blade. It is the user's responsibility
to have an electrician replace the obsolete
outlet.

• If you cause a static discharge when touching
the unit, and the unit fails to function, simply
unplug the unit from the wall outlet, wait one
hour and plug it back in. The unit should return
to normal operation.

AC Outlet

Wider Hole
and Blade

Polarized AC Cord Plug
(One blade is wider than the other.)

TO USE DC POWER

By using the DC car cord supplied with the TV/VCR, you
can operate this TV/VCR from a cigarette lighter socket
in any car that utilizes a negative ground system.
The fused 12V DC car cord has been designed to power
the set from the external DC power (12 volt negative
ground) through the TV/VCR DC input jack.

Connect the smaller plug on the end of the cord to the
DC input jack on the rear of the TV/VCR, then insert the
other end of the car cord into the cigarette lighter socket
of your car. Make sure that the cord makes a firm
connection.
It may be necessary to try several insertions, rotating
the plug for proper electrical connection.

15 PIES (5m)

15 FEET

30˚

30˚

NOTES: • When there is an obstacle between the TV/VCR

and the remote control, the remote control may
not operate.

• When direct sunlight, an incandescent lamp,
fluorescent lamp or any other strong light
shines on the Remote sensor of the TV/VCR,
the remote operation may be unstable.

10

5A3A901A E P02-11 3/18/02, 10:07 PM10

TV/VCR

CAR

To Cigarette

Lighter Socket

To DC Input Jack

Car Cord (supplied)

NOTES: • ALWA YS TURN OFF TV/VCR FIRST BEFORE

SWITCH ON OR OFF THE IGNITION OF CAR
ENGINE.

• Make sure that the negative terminal of the
battery is grounded. This set is designed for
use with negative ground system only.

• Use the supplied car cord only.

• When the TV/VCR is not in use, always

disconnect it from the car cigarette lighter
socket to avoid a battery drain.

• If the TV/VCR is to be directly connected to a
12V DC power source, for example, recrea­tional vehicle (RV) applications, make sure
the power cord is connected after the ignition
switch to avoid battery drain.

• Do not operate the TV/VCR if the car battery
is weak. Peak current from the car alternator
could blow the DC fuse.

• Check the battery’s charge level regularly
when the TV/VCR is used in a vehicle.

REPLACING THE FUSE IN THE CAR
CORD PLUG

If the fuse in the car cord plug blows, replace it with a
new 8 A fuse (Fast Blow Type) as shown below.
Unscrew the tip of the plug to remove.

PLUG

8A FUSE

TIP

ANTENNA CONNECTIONS

If you are using an indoor or outdoor antenna, follow
the instructions below that correspond to your
antenna system. If you are using a cable TV service
(CATV), see page 12 for Cable TV connections.

Combination VHF/UHF Antenna
(

Single 75 ohm cable or 300 ohm

twin-lead wire

Connect the 75 ohm cable from the combination VHF/
UHF antenna to the Antenna Jack.
If your combination VHF/UHF antenna has a 300 ohm
twin-lead wire, the use of the 300-75 ohm Matching
Transformer may be necessary.
Connect the VHF 75 ohm cable and UHF 300 ohm

75 ohm
Coaxial
Cable

Combination VHF/UHF Antenna
(

Separate VHF and UHF 300 ohm

twin-lead wires

Connect the UHF 300 ohm twin-lead wire to the Combiner
(not supplied). Connect the VHF 300 ohm twin-lead
wire to the 300-75 ohm Matching Transformer. Attach
the Transformer to the Combiner, then attach the
Combiner to the Antenna Jack.

Antenna Jack

UHF/
VHF

Combiner

UHF 300 ohm

)

Antenna Jack Antenna Jack

U

H

F

/

V

H

F

300-75 ohm Matching Transformer

U

H

F

/

V

H

F

)

300-75 ohm Matching
Transformer

VHF 300 ohm

ENGLISH

5A3A901A E P02-11 3/18/02, 10:07 PM11

Separate VHF/UHF Antennas
(

75 ohm VHF cable and 300 ohm UHF

twin-lead wires

Connect the VHF 75 ohm cable and UHF 300 ohm
twin-lead wire to the Combiner (not supplied). Attach
the Combiner to the Antenna Jack.

Antenna Jack

UHF/
VHF

Combiner

)

VHF 75 ohm

UHF 300 ohm

11

CABLE TV CONNECTIONS

This TV/VCR has an extended tuning range and can tune most cable channels without using a Cable TV
converter box. Some cable companies offer "premium pay channels" in which the signal is scrambled.
Descrambling these signals for normal viewing requires the use of a descrambler device which is generally
provided by the cable company.

FOR SUBSCRIBERS TO BASIC CABLE TV SERVICE

For basic cable service not requiring a Converter/Descrambler box,
connect the CATV 75 ohm Coaxial Cable directly to the Antenna Jack
on the back of the TV/VCR.

75 ohm
Coaxial Cable

FOR SUBSCRIBERS TO SCRAMBLED CABLE TV SERVICE

If you subscribe to a cable TV service which requires the use of a Converter/Descrambler box, connect the incoming
75 ohm Coaxial Cable to the Converter/Descrambler box. Using another 75 ohm Coaxial Cable, connect the output jack
of the Converter/Descrambler box to the Antenna Jack on the TV/VCR. Follow the connections shown below. Set the
TV/VCR to the output channel of the Converter/Descrambler box (usually channel 3 or 4) and use the Converter/
Descrambler box to select channels.

Incoming 75 ohm
CATV cable

Converter/Descrambler

75 ohm Cable to TV/VCR

FOR SUBSCRIBERS TO UNSCRAMBLED BASIC CABLE TV SERVICE WITH
SCRAMBLED PREMIUM CHANNELS

If you subscribe to a cable TV service in which basic channels are unscrambled and premium channels require the
use of a Converter/Descrambler box, you may wish to use a signal splitter and an A/B Switch box (available from the
Cable company or an electronics supply store). Follow the connections shown below. With the switch in the "B"
position, you can directly tune any nonscrambled channels on your TV/VCR. With the switch in the "A" position, tune
your TV/VCR to the output of the Converter/Descrambler box (usually channel 3 or 4) and use the Converter/
Descrambler box to tune scrambled channels.

Antenna Jack

UHF/
VHF

Antenna Jack

UHF/
VHF

Incoming

Converter/Descrambler

75 ohm
CATV cable

Splitter

SETTING THE LANGUAGE

This TV/VCR can display the on screen language in
English, Spanish or French.
On-screen language selection (step 3) will automati­cally appear on the screen when you press the MENU
button initially. Select the language you prefer first,
then proceed with the other menu options.

1 Press the MENU button.

Press the SET/TRACKING + or –

button to select the SYSTEM
SET-UP option, then press the
ENTER button.

M E N U
TIMER REC SET
TV SET-UP
CH SET-UP
AUTO REPEAT ON OFF
SYSTEM SET-UP

〈

+/–/ENTER/MENU

12

5A3A901A E P12-19 3/18/02, 10:07 PM12

A/B Switch

〉

75 ohm cable

A

to TV/VCR

B

2 Press the SET/TRACKING + or

– button to select the LAN­GUAGE option, then press the
ENTER button.

3 Press the SET/TRACKING + or

– button to select the desired
language: English (ENGLISH),
Spanish (ESPAÑOL) or French
(FRANCAIS), then press the
ENTER button.

4 Press the MENU button until the

MENU screen is cleared.

Antenna Jack

UHF/
VHF

SYSTEM SET-UP
CLOCK SET
LANGUAGE/IDIOMA/LANGUE
AUTO CLOCK ON OFF
STANDARD TIME
DAYLIGHT SAVING TIME

〈

+/–/ENTER/MENU

LANGUAGE/IDIOMA/LANGUE

ENGLISH
ESPAÑOL
FRANCAIS

〈

+/–/ENTER/MENU

〉

〉

AUTO CLOCK SETTING

The Auto Clock function will automatically set the
built-in clock (Month, Day, Year and Time) when the
TV/VCR is connected to an Antenna or Cable system
and it is turned off. As the TV/VCR searches for a
receivable station in your area, it will also receive a
broadcast signal for Auto Clock which will automati­cally set the clock and date.The Auto Clock needs sev­eral minutes to set itself.

AUTO CLOCK SETTING

1 Connect the Antenna or Cable system.

• If you use a cable box, turn it on.

2 Plug the AC Power cord to the AC outlet.
3 Make sure the TV/VCR is turned off.

• If you press the POWER button, the Auto Clock set is

not effective.

4 Wait at least three minutes and press the POWER

button.

5 Press the CALL button to check the clock on the screen.
6 If the clock is not set, check the Antenna condition. The

Auto Clock may not function properly if the reception
condition is not good.

AUTO CLOCK ADJUSTMENT

The Auto Clock Adjustment will be performed at 12:00 PM
everyday if you turn off the TV/VCR.

• If you use a cable box and you want Auto Clock adjust-

ment to be performed, the cable box must be left on.

• The Auto Clock Adjustment is not effective when there

is a difference of more than 5 minutes between the
built-in clock time and the actual time.

TO SET AUTO CLOCK TO OFF

When shipped from factory the AUTO CLOCK option is
set to ON.
But if you do not want Auto Clock set (Adjustment):

1 Turn on the TV/VCR.
2 Press the MENU button.
3 Press the SET/TRACKING + or – button to select the

SYSTEM SET-UP option, then press the ENTER
button.

4 Press the SET/TRACKING + or – button to select the

AUTO CLOCK option.

5 Press the ENTER button to select OFF.
6 Press the MENU button repeatedly to return to the

normal screen.

• When the AUTO CLOCK is set to OFF , the Auto Clock

adjustment does not function.

• Set the clock manually (see page 14).

TO SET STANDARD TIME

In the rare event that you live within broadcast range of
two stations in two different time zones, the TV/VCR
may recognize the wrong station for the Auto Clock set.
To correct the situation:

1 Press the MENU button.
2 Press the SET/TRACKING + or – button to select the

SYSTEM SET-UP option, then press the ENTER button.

3 Press the SET/TRACKING + or – button to select the

STANDARD TIME option, then Press the ENTER
button.

4 Press the SET/TRACKING + or – button to select your

time zone, then press the ENTER button.

ATLANTIC : GMT – 4 hours

(GMT: Greenwich Mean Time)

EASTERN : GMT – 5 hours
CENTRAL : GMT – 6 hours
MOUNTAIN : GMT – 7 hours
PACIFIC : GMT – 8 hours
ALASKA : GMT – 9 hours
HAWAII : GMT – 10 hours
AUTO : AUTO SET

5 Press the MENU button twice to return to the normal

screen.

NOTE: To be able to select the standard time, the clock

must first be set by “AUTO CLOCK” once.

DAYLIGHT SAVING TIME SETTING

You can set the Daylight saving time automatically or
manually.

1 Press the MENU button. Press

the SET/TRACKING + or – button
to select the SYSTEM SET-UP
option, then press the ENTER
button.

M E N U
TIMER REC SET
TV SET-UP
CH SET-UP
AUTO REPEAT ON OFF
SYSTEM SET-UP

〈

+/–/ENTER/MENU

〉

2 Press the SET/TRACKING + or –

button to select the DAYLIGHT
SAVING TIME option, then press
the ENTER button.

3 Press the SET/TRACKING + or –

button to select one of the
options, then press the ENTER
button. Press the MENU button
until the MENU screen is cleared.
ON: for manual setting

(forward one hour)

OFF: for manual setting

(back one hour)

AUTO: for automatic setting

(read XDS in the signal)

When you want to set the Daylight Saving Time manually,
on the first Sunday in April you set to “ON”, and on the last
Sunday in October you set to “OFF”.

NOTES: • When shipped from factory, the DAYLIGHT

SAVING TIME option is set to AUTO position.

• When the clock is not set, Daylight Saving
Time setting is not available.

• When there is no Daylight Saving T ime in your
area, always select OFF position in step 3.

SYSTEM SET-UP
CLOCK SET
LANGUAGE/IDIOMA/LANGUE
AUTO CLOCK ON OFF
STANDARD TIME
DAYLIGHT SAVING TIME

〈

+/–/ENTER/MENU

DAYLIGHT SAVING TIME

〈

+/–/ENTER/MENU

〉

ON
OFF
AUTO

〉

13

ENGLISH

5A3A901A E P12-19 3/18/02, 10:07 PM13

MANUAL CLOCK SETTING

TV OPERATION

You must set the date and time manually for Timer
Recordings, ON/OFF Timer and Daylight Saving Time
if the Auto Clock process did not set them correctly.

EXAMPLE: Setting the clock to “8:30 AM”, 26th (SAT)

October, 2002.

1 Press the MENU button.

Press the SET
button to select the SYSTEM
SET-UP option, then press the
ENTER button.

/TRACKING

+ or –

2 Press the SET/TRACKING + or –

button to select the CLOCK SET
option, then press the ENTER
button.

3 Press the SET/TRACKING + or –

button to set the month, then press
the ENTER button.

4 Set the day, year and time as in

step 3.

After setting the clock, time and date,
the time starts functioning automati­cally.

M E N U
TIMER REC SET
TV SET-UP
CH SET-UP
AUTO REPEAT ON OFF
SYSTEM SET-UP

〈

+/–/ENTER/MENU

〈

+/–/ENTER/MENU

CLOCK SET

〈

+/–/ENTER/CANCEL/MENU

CLOCK SET

〈

+/–/ENTER/CANCEL/MENU

〉

SYSTEM SET-UP
CLOCK SET
LANGUAGE/IDIOMA/LANGUE
AUTO CLOCK ON OFF
STANDARD TIME
DAYLIGHT SAVING TIME

〉

MONTH

10

DAY

1 (SUN)

YEAR

2000

TIME

12 : 00 AM

MONTH

10

DAY

26 (SAT)

YEAR

2002

TIME

8 : 30 AM

8 : 30 AM SAT

NOTES: •After a power failure or disconnection of the

power plug, the time display will be lost. In
this case, set the present time again if the
Auto Clock did not set correctly.

•To move cursor backward, press the CANCEL

button.

1 To turn on the TV/VCR, press the POWER button.
2 Adjust the volume level by

pressing the VOLUME Up or Down
button. The volume level will be
indicated on the screen by green
bars. As the volume level

VOLUME 32

increases, so do the number of
bars. If the volume decreases, the number of green
bars also decreases.

3 Set the TV/CATV menu option to the appropriate

position (See page 16).

TV - VHF/UHF Channels
CATV - CABLE TV Channels

VHF/UHF/CATV CHANNELS

TV

VHF
2-13

UHF

14-69

〉

CATV

VHF
2-13

STD/HRC/IRC

14-36 (A) (W)

37-59 (AA) (WW)

60-85 (AAA) (ZZZ)

86-94 (86) (94)

95-99 (A-5) (A-1)

100-125 (100)(125)

01 (5A)

4 Press the Direct Channel selection buttons to select

the channel.

〉

• TV mode direct channel selection

When the TV/CATV menu option is in the TV
position, all channels can be instantly selected by
using two buttons (for example, to select channel 2,
press "0", then "2". If you press only "2", channel
selection will be delayed for a few seconds). For
channels 10 and above, press the 2 digits in order.

• CATV mode direct channel selection

When the TV/CA TV menu option is in the CATV
position, channels can be selected as follows:

• TO SELECT CATV CHANNELS:

1-9 Press "0" twice, then 1-9 as needed.
10-12 Press "0", then the remaining 2 digits.
13-99 Press the 2 digits in order.
100-125 Press the 3 digits in order.

NOTE FOR CHANNELS 1-12:

If only 1 or 2 buttons are pressed,
the corresponding channel will be
selected in 2 seconds.

Example, to select channel 2, press "002".
Example, to select channel 12, press "012".
Example, to select channel 36, press "36".
Example, to select channel 120, press "120".

CH 012

14

5A3A901A E P12-19 3/18/02, 10:07 PM14

NOTES: •If a channel with no broadcast is selected,

the sound will automatically be muted.

•If a station being viewed stops broadcasting,

the TV will automatically shut itself off after
15 minutes.

TV OPERATION

MUTING

Press MUTING button to switch off
the sound. The TV/VCR’s sound will
be silenced and “MUTING” will
briefly appear on the screen. The
sound can be switched back on by
pressing this button again or one of
the VOLUME Up or Down buttons.

MUTING

CHANNEL UP / DOWN

Press and release the CHANNEL
Up or Down button. The channel
automatically stops at the next
channel set into memory. For proper
operation, before selecting chan­nels, they should be set into the
memory.
See pages 16 and 17 “To memorize channels”.

CH 012

CALL

Press the CALL button. The clock, date, channel number ,
real time tape counter, tape speed and VCR operation will
be indicated.
Press CALL button again to remove the call display.

Current time

8:47AM THU CH 012

00:04:38 SP

Real Time Counter

NOTE: To listen through the headphone, insert a

headphone (not supplied) with a 1/8" mini plug
into one of the PHONES jacks (One or 2
headphones can be used for private listening.)
on the front. The sound from the TV speaker is
muted.

Channel No.
Auto Repeat

Tape In

T ape Speed

VCR operation

: Play
: Rewind
: Fast-forward
: Eject
: Recording
: Pause
: Stop

SLEEP

To set the TV/VCR to turn off after a preset amount of
time, press the SLEEP button on the remote control.
The clock will count down 10 minutes for each press of
the SLEEP button (120, 1 10, ...10, 0). After the sleep time
is programmed, the display will appear briefly every ten
minutes to remind you that the sleep timer is operating.
To confirm the sleep timer setting,
press the SLEEP button and the
remaining time will be momentarily
displayed. T o cancel the sleep timer ,
press the SLEEP button repeatedly
until the display turns to 0.

SLEEP

120

QUICK VIEW

This button allows you to go back
to the last channel selected by
pressing the QUICK VIEW button.
Press this button again to return to
the last channel you were watch­ing.

CH 012

TV/CAPTION/TEXT

Press TV/CAP/TEXT button to
switch between normal TV and the
two closed caption modes (captions
and full screen text). Closed
captioning will display text on the
screen for hearing impaired viewers.

NOTES:

• If using an indoor antenna or if TV reception

is very poor, the Closed Caption Decoder text
may not appear. In this case, adjust the
antenna for better reception or use an outdoor
antenna.

•When activating the Closed Captioned

Decoder, there will be a short delay before
the Closed Captioned text appears on the
screen.

•Closed Captioned TV programs can be

recorded and played back on a VCR with the
Closed Captioned text intact. The Closed
Captioning text will disappear during Cue,
Rewind and Pause modes or if the VCR
tracking is not adjusted properly.

•Closed Captioned text is only displayed in

locations where it is available.

•If the Call display is on, the Closed Captioning

text will not appear.

WHAT IS CLOSED CAPTIONING?

This television has the capability to decode and display
Closed Captioned television programs. Closed Captioning
will display text on the screen for hearing impaired
viewers or it will translate and display text in another
language.

CLOSED CAPTIONING WITH A VCR

Closed Captioned programs can be recorded and played
back on a VCR with the Closed Captioned text intact.
The Closed Captioned text will disappear during Cue
(Fast Forward Search), Review (Rewind Search) and
Pause Modes or if the VCR tracking is not adjusted
properly.

TO VIEW CLOSED CAPTIONS

Press the TV/CAP/TEXT button on the remote control to
switch between normal TV and the two Closed Caption
Modes (Captions and Full Screen Text).

CAPTION CH 1

ENGLISH

5A3A901A E P12-19 3/18/02, 10:07 PM15

15

TV OPERATION

Captions: This Closed Caption Mode will display text on

the screen in English or another language (depending
on the setting of the Closed Captions CH. 1 or 2).
Generally, Closed Captions in English are transmitted on
Captions Channel 1 and Closed Captions in other
languages are transmitted on Captions Channel 2.
The Captions will appear in places on the screen where
they will least interfere with the picture, usually on the
bottom of the screen. News programs will usually show
three-line Closed Captions which scroll onto the screen.
Most other shows provide two or three lined Captions
placed near the character who is speaking so the viewer
can follow the dialogue.
Words in italics or underlined describe titles, words in
foreign languages or words requiring emphasis. Words
that are sung usually appear enclosed by musical notes.

Text: The Text Closed Caption Mode will usually fill the
screen with a programming schedule or other information.
After selecting a Closed Caption Mode, it will stay in
effect until it is changed, even if the channel is changed.
If the Captions signal is lost due to a commercial or a
break in the signal, the Captions will reappear when the
signal is received again. If the channels are changed,
the Captions will be delayed approximately 10 seconds.
For television programs broadcasting with Closed Cap­tions, look in your TV guide for the Closed Captions
symbol (CC).

TO MEMORIZE CHANNELS

This TV/VCR is equipped with a channel memory
feature which allows channels to skip up or down to
the next channel set into memory, skipping over
unwanted channels. Before selecting channels, they
must be programmed into the TV/VCR’s memory. In
addition to normal VHF and UHF channels, this TV/
VCR can receive up to 113 Cable TV channels. To
use this TV/VCR with an antenna, set the TV/CATV
menu option to the TV mode. When shipped from the
factory, this menu option is in the CATV mode.

TV/CATV SELECTION

1 Press the MENU button.
2 Press the SET/TRACKING + or

– button to select the CH SET-UP
mode, then press the ENTER
button.

VHF/UHF/CATV CHANNELS

TV

VHF
2-13

UHF

14-69

STD/HRC/IRC

14-36 (A) (W)

37-59 (AA) (WW)

60-85 (AAA) (ZZZ)

86-94 (86) (94)

95-99 (A-5) (A-1)

100-125 (100)(125)

M E N U
TIMER REC SET
TV SET-UP
CH SET-UP
AUTO REPEAT ON OFF
SYSTEM SET-UP

〈

+/–/ENTER/MENU

CATV

VHF
2-13

01 (5A)

〉

• When selecting Closed Captions, the captioning will
be delayed approximately 10 seconds.

• If no caption signal is received, no captions will
appear, but the television will remain in the Caption
Mode.

• When Captions are being displayed, on-screen
displays, such as volume and mute may not be seen
or may interfere with Closed Captions.

• Misspellings or unusual characters may occasionally
appear during Closed Captioning. This is normal with
Closed Captioning, especially with live programs. This
is because during live programs, captions are also
entered live. These transmissions do not allow time for
editing.

• Some cable systems and copy protection systems
may interfere with the Closed Captioned signal.

• If using an indoor antenna or if TV reception is very
poor, the Closed Caption Decoder may not appear or
may appear with strange characters or misspelled
words. In this case, adjust the antenna for better
reception or use an outdoor antenna.

16

3 Press the SET/TRACKING + or

– button to select the TV/CATV
mode.

4 Press the ENTER button to

select the TV or CATV mode.

CH SET-UP
TV CATV
AUTO CH MEMORY
ADD/DELETE

〈

+/–/ENTER/MENU

〉

The arrow indicates the selected
mode.

TV - VHF/UHF channels
CATV - CABLE TV channels

5 Press the MENU button until the MENU screen is cleared.

AUTOMATIC MEMORY TUNING

1 Press the MENU button.
2 Press the SET/TRACKING + or

– button to select the CH SET-UP
mode, then press the ENTER
button.

3 Press the SET/TRACKING + or

– button to select the AUTO CH
MEMORY mode, then press the
ENTER button. The TV/VCR will
begin memorizing all the chan­nels available in your area.
Channel numbers will remain red
until auto memorizing is complete.

4 Press the MENU button until the MENU screen is

cleared.

M E N U
TIMER REC SET
TV SET-UP
CH SET-UP
AUTO REPEAT ON OFF
SYSTEM SET-UP

〈

+/–/ENTER/MENU

〈

+/–/ENTER/MENU

〉

CH SET-UP
TV CATV
AUTO CH MEMORY
ADD/DELETE

〉

5A3A901A E P12-19 3/18/02, 10:07 PM16

TO MEMORIZE CHANNELS

SETTING THE V-CHIP

TO ADD/DELETE CHANNELS

1 Press the MENU button.
2 Press the SET/TRACKING + or

– button to select the CH SET-UP
mode, then press the ENTER
button.

3 Press the SET/TRACKING + or

– button to select the ADD/
DELETE mode, then press the
ENTER button.

4 Select the desired channel to be

memorized or deleted using SET/
TRACKING + or – button, or
using the Direct Channel.
Selection buttons (10 keys, 0-9),
or CHANNEL Up or Down button.

5 Press the ENTER button to

select the ADD or DELETE.
If you select an unmemorized channel, the Channel
indication will be red. If you select the ADD mode, the
Channel indication changes from red to green and the
channel will be memorized. If you select a memorized
channel, the Channel indication will be green. If you
select the DELETE mode, the Channel indication
changes from green to red and the channel will be
deleted from the memory.

6 Press the MENU button until the MENU screen is

cleared.

M E N U
TIMER REC SET
TV SET-UP
CH SET-UP
AUTO REPEAT ON OFF
SYSTEM SET-UP

〈

+/–/ENTER/MENU

CH SET-UP
TV CATV
AUTO CH MEMORY
ADD/DELETE

〈

+/–/ENTER/MENU

〈

0–9/+/–/ENTER/MENU

〉

〉

CH 003ADD

〉

SETTING THE V-CHIP

An age limitation can be set to forbid children to see
and hear violent scenes or pictures for adults, etc.
The TV/VCR responds to "TV RATING" and "MOVIE
RATING". To use the V-Chip function, you must
register a password.

1 Press the MENU button.
2 Press the SET/TRACKING + or –

button to select the TV SET-UP
option, then press the ENTER
button.

3 Press the SET/TRACKING + or –

button to select the V-CHIP SET
then press the ENTER button.

4 Enter the password (4 digits) us-

ing the Direct Channel Selection
buttons (0-9), then press the EN­TER button.

" "appears instead of the number.

5 Enter the same password again

for safety, then press the ENTER
button.

M E N U
TIMER REC SET
TV SET-UP
CH SET-UP
AUTO REPEAT ON OFF
SYSTEM SET-UP

〈

+/–/ENTER/MENU

〈

+/–/ENTER/MENU

V-CHIP SET

〈

0–9/ENTER/CANCEL/MENU

TV SET-UP
V-CHIP SET
ON/OFF TIMER

NEW
PASSWORD:

〉

〉

V-CHIP SET menu appears.

NOTES:

When you dislocated or lost the password,

•

you can cancel the existing password by
the following procedure:

- Press VOLUME ▼ button of main unit.

- Keep pressing VOLUME ▼ button and press "0" key of
remote control simultaneously for a few seconds.

• If you are changing channels using a cable box, while the TV/
VCR remains on channel 3 or 4, the V-Chip operates
differently. When you enter your password to temporarily
release the block on any channel, you have completely
disabled the V-Chip function for all stations. To reset the V­Chip turn your TV/VCR off and back on.

• Some cable boxes are built with a delay feature, in some
cases it can take up to 10 seconds for a program to appear
after the password has been input.

V-CHIP SET

CONFIRM
PASSWORD:

〈

0–9/ENTER/CANCEL/MENU

TO SET THE V-CHIP

1 In the V-CHIP SET menu, press

the SET/TRACKING + or –
button to select the TV RATING,
then press the ENTER button.

2 Press the SET/TRACKING + or

– button to display the desired
setting, then press the ENTER
button.

OFF : TV RATING is not set
TV-Y : All children
TV-Y7 : 7 years old and above
TV-G : General Audience
TV-PG : Parental guidance
TV-14 : 14 years old and above
TV-MA : 17 years old and above

• When you select TV- Y7, TV-PG, TV-14 or TV-MA,

press the CALL button to explain the rating. Press
the SET/TRACKING + or – button to select the
desired rating you want. Press the ENTER button
to select the setting ON or OFF.

3 Press the SET/TRACKING + or

– button to select the MOVIE
RATING, then press the ENTER
button.
The V-Chip function is acti­vated only on programs and
tapes that have the rating
signal.

4 Press the SET/TRACKING + or

– button to select desired rating,
then press the ENTER button.

OFF : MOVIE RATING is not set
G:All ages
PG : Parental guidance

〉

PG-13 : Parental guidance less than 13 years old
R:Under 17 years old Parental guidance

suggested

NC17 : 17 years old and above
X:Adult only

V-CHIP SET
V-CHIP : OFF
TV RATING : TV–PG
MOVIE RATING : PG–13
CHANGE PASSWORD

〈

+/–/ENTER/MENU

V-CHIP SET
V-CHIP : OFF
TV RATING : TV–PG
MOVIE RATING : PG–13
CHANGE PASSWORD

〈

+/–/ENTER/MENU

V-CHIP SET
V-CHIP : OFF
TV RATING : TV–PG
MOVIE RATING : PG–13
CHANGE PASSWORD

〈

+/–/ENTER/MENU

V-CHIP SET
V-CHIP : OFF
TV RATING : TV–PG
MOVIE RATING : PG–13
CHANGE PASSWORD

〈

+/–/ENTER/MENU

〉

ENGLISH

〉

〉

〉

〉

17

5A3A901A E P12-19 3/18/02, 10:07 PM17

ON/OFF TIMER

〈

+/–/ENTER/CANCEL/MENU

〉

ON TIMER

7:00AM CH001

MON-SAT CANCEL

OFF TIMER

12:00AM CANCEL

SETTING THE V-CHIP

TO SET THE ON TIMER

5 Press the SET/TRACKING + or

– button to select V-CHIP.

6 Press the ENTER button to

display ON.

7 Press the MENU button until the

MENU screen is cleared.

V-CHIP SET
V-CHIP : OFF
TV RATING : TV–PG
MOVIE RATING : PG–13
CHANGE PASSWORD

〈

+/–/ENTER/MENU

〈

+/–/ENTER/MENU

〉

V-CHIP SET
V-CHIP : ON
TV RATING : TV–PG
MOVIE RATING : PG–13
CHANGE PASSWORD

〉

NOTE : The V-Chip function is activated only on pro­grams and tapes that have the rating signal.

To use the TV after the TV is protected.

When the program applied to the V-Chip setting is
received, enter the password, then press the ENTER
button. When the password is entered correctly the
protection will be temporarily overridden.

TO CHANGE PASSWORD

1 Press the MENU button.
2 Press the SET/TRACKING + or

– button to select the TV SET-UP,
then press the ENTER button.

3 Press the SET/TRACKING + or

– button to select the V-CHIP
SET, then press the ENTER
button.

4 Enter the Password using the

Direct Channel Selection
button (0-9), then press the
ENTER button.

5 Press the SET/TRACKING +

or – button to select CHANGE
PASSWORD, then press the
ENTER button.

6 Enter the new password using

the Direct Channel Selection
button (0-9), then press the
ENTER button.

7 Enter the same password

again to confirm, then press the
ENTER button.

8 Press the MENU button

repeatedly to return to normal
screen.

M E N U
TIMER REC SET
TV SET-UP
CH SET-UP
AUTO REPEAT ON OFF
SYSTEM SET-UP

〈

+/–/ENTER/MENU

〈

+/–/ENTER/MENU

V-CHIP SET

〈

0–9/ENTER/CANCEL/MENU

+

〈

〈

0–9/ENTER/CANCEL/MENU

〈

0–9/ENTER/CANCEL/MENU

〉

TV SET-UP
V-CHIP SET
ON/OFF TIMER

〉

PASSWORD: – – – –

V-CHIP SET
V-CHIP : ON
TV RATING : TV–PG
MOVIE RATING : PG–13
CHANGE PASSWORD

/–/ENTER/CANCEL/MENU

V-CHIP SET
V-CHIP : ON
TV RATING : TV–PG
MOVIE RATING : PG–13
CHANGE PASSWORD
NEW
PASSWORD: – – – –

V-CHIP SET
V-CHIP : ON
TV RATING : TV–PG
MOVIE RATING : PG–13
CHANGE PASSWORD
CONFIRM
PASSWORD: – – – –

18

This feature allows you to have the TV/VCR automati­cally turn “ON” at a predetermined time. If you
program the “ON” timer once, the TV/VCR will turn
“on” on the programmed day (daily/weekly) at the
same time to the same channel.
EXAMPLE: Turning on the TV to channel 12 at 7:00 AM,

MONDAY-FRIDAY.

1 Press the MENU button.

Press the SET/TRACKING + or
– button to select the TV SET-UP
option, then press the ENTER
button.

2 Press the SET/TRACKING + or

– button to select the ON/OFF
TIMER option, then press the

M E N U
TIMER REC SET
TV SET-UP
CH SET-UP
AUTO REPEAT ON OFF
SYSTEM SET-UP

〈

+/–/ENTER/MENU

TV SET-UP
V-CHIP SET
ON/OFF TIMER

ENTER button.

〈

+/–/ENTER/MENU

3 Press the SET/TRACKING + or

– button to select the ON TIMER
option, then press the ENTER
button.

ON/OFF TIMER
ON TIMER

12:00AM CH001
MON-SAT CANCEL

OFF TIMER

12:00AM CANCEL

〈

+/–/ENTER/CANCEL/MENU

4 Press the SET/TRACKING + or

– button to set the desired hour,
then press the ENTER button.

5 Set the desired minute, channel

and daily or weekly timer date
as in step 4.

6 Press the SET/TRACKING + or –

button to select the SET mode,
then press the ENTER button.

〉

Press the MENU button repeat­edly to return to normal screen.

NOTES: • The TV/VCR will automatically turn off approxi-

〉

〉

〉

mately 1 hour later after the ON TIMER turns on
if no OFF TIMER has been set. To continue
watching the TV, press any button to cancel the
one hour automatic shut off.

• To cancel ON timer, follow above steps 1-5, then
press the SET/TRACKING + or – button to select
the CANCEL. Press the MENU button repeatedly
to return to the normal screen.

• After setting the ON TIMER, "
will flash on and off. If you wish to set the OFF
TIMER, press the ENTER button then follow the
steps 4-6 on " TO SET THE OFF TIMER" .

• If you want to correct the digits while setting,
press the CANCEL button until the item you
want to correct, then press the SET/TRACKING
+ or – button to correct the desired setting.

ON/OFF TIMER
ON TIMER

7:00AM CH012

MON-FRI CANCEL

OFF TIMER

12:00AM CANCEL

〈

+/–/ENTER/CANCEL/MENU

ON/OFF TIMER
ON TIMER

7:00AM CH012

MON-FRI SET

OFF TIMER

12:00AM CANCEL

〈

+/–/ENTER/CANCEL/MENU

" of the OFF TIMER

〉

〉

〉

〉

〉

5A3A901A E P12-19 3/18/02, 10:07 PM18

TO SET THE OFF TIMER

This feature allows you to have the TV/VCR turn
“OFF” automatically at a predetermined time. If you
program the OFF TIMER once, the TV/VCR will
automatically turn off at the same time everyday.

EXAMPLE: Turning off the TV at 11:30 PM.

1 Press the MENU button.

Press the SET/TRACKING + or –
button to select the TV SET-UP
option, then press the ENTER
button.

2 Press the SET/TRACKING + or –

button to select the ON/OFF
TIMER option, then press the

M E N U
TIMER REC SET
TV SET-UP
CH SET-UP
AUTO REPEAT ON OFF
SYSTEM SET-UP

〈

+/–/ENTER/MENU

TV SET-UP
V-CHIP SET
ON/OFF TIMER

〉

ENTER button.

3 Press the SET/TRACKING + or –

button to select the OFF TIMER
option, then press the ENTER
button.

〈

+/–/ENTER/MENU

〈

+/–/ENTER/CANCEL/MENU

〉

ON/OFF TIMER
ON TIMER

7:00AM CH012

MON-FRI SET

OFF TIMER

12:00AM CANCEL

4 Press the SET/TRACKING + or –

button to set the desired hour,
then press the ENTER button.

5 Press the SET/TRACKING + or –

button to set the desired minute,
then press the ENTER button.

6 Press the SET/TRACKING + or –

button to select the SET mode,
then press the MENU button
repeatedly to return to the normal
screen.

NOTES: • To cancel OFF timer, follow

〉

above step 1-5, then press
the SET/TRACKING + or –
button to select the
CANCEL. Press the MENU
button to return to the
normal screen.

• To confirm the ON/OFF TIMER:
Press the PROGRAM button twice to indicate
the programs on the screen.

PICTURE CONTROL ADJUSTMENTS

Picture controls are factory preset but you can adjust
them individually as follows:

1 To display the picture adjustment

screen, press the MENU button.
Press the SET/TRACKING + or –
button to select the TV SET-UP
option, then press the ENTER
button.

2 Press the SET/TRACKING + or –

button to select the PICTURE
option, then press the ENTER
button.

M E N U
TIMER REC SET
TV SET-UP
CH SET-UP
AUTO REPEAT ON OFF
SYSTEM SET-UP

〈

+/–/ENTER/MENU

〈

+/–/ENTER/MENU

TV SET-UP
V-CHIP SET
ON/OFF TIMER

〉

〉

BRIGHTNESS

Press the ENTER button until
“BRIGHTNESS” appears on the
screen, then press the SET/
TRACKING + or – button to adjust
the brightness of the picture. When
the SET/TRACKING + button is

BRIGHTNESS 0

〈

+/–/ENTER/CANCEL/MENU

pressed, the darker portions of the
picture become lighter.

CONTRAST

Press the ENTER button until
“CONTRAST” appears on the screen,
then press the SET/TRACKING +
or – button to adjust the contrast of
the picture. Pictures look sharpest
in the daytime (bright light) by
increasing the contrast. At night
(dim light), the sharpest picture is obtained by reducing
the contrast.

NOTE: The CONTRAST default setting is set to maximum

at the factory.

CONTRAST 32

〈

+/–/ENTER/CANCEL/MENU

COLOR

Press the ENTER button until
“COLOR” appears on the screen,
then press the SET/TRACKING + or
– button to adjust the color intensity
of the picture. The control should be
set when colors appear normal in
intensity and brilliance.

TINT

Press the ENTER button until “TINT”
appears on the screen, then press
the SET/TRACKING + or – button to
adjust the tint of the picture. This
determines how accurately the
colors are reproduced by the TV.
Adjusting the tint for natural facial tone is the best method of
obtaining accurate color reproduction of the entire picture.

SHARPNESS

〉

Press the ENTER button until
“SHARPNESS” appears on the
screen, then press the SET/
TRACKING + or – button to adjust
the sharpness of the picture.

CANCEL

Pressing the CANCEL button while making picture
adjustments will return all adjustments to the factory

〉

preset levels.
NOTE: The On-screen display will disappear 6 seconds

after finishing an adjustment or by pressing the
MENU button three times. The settings can only be
adjusted when they are displayed on the TV screen.

ON/OFF TIMER
ON TIMER

7:00AM CH012

MON-FRI SET

OFF TIMER

11:00PM CANCEL

〈

+/–/ENTER/CANCEL/MENU

ON/OFF TIMER
ON TIMER

7:00AM CH012

MON-FRI SET

OFF TIMER

11:30PM CANCEL

〈

+/–/ENTER/CANCEL/MENU

ON/OFF TIMER
ON TIMER

7:00AM CH012

MON-FRI SET

OFF TIMER

11:30PM SET

〈

+/–/ENTER/CANCEL/MENU

COLOR 0

〈

+/–/ENTER/CANCEL/MENU

TINT 0

〈

+/–/ENTER/CANCEL/MENU

SHARPNESS 0

〈

+/–/ENTER/CANCEL/MENU

19

〉

ENGLISH

〉

〉

〉

〉

〉

5A3A901A E P12-19 3/18/02, 10:08 PM19

LOADING AND UNLOADING

PLAYBACK

Use only video cassette tapes marked

.

LOADING

Push the center of the tape until it is automatically
retracted into the TV/VCR.

AUTOMATIC POWER ON AND PLAY

When loading a cassette tape without the erase preven­tion tab intact, the TV/VCR will turn on automatically
and playback will start immediately.

Insert the cassette with its labeled side facing you.
An inverted video cassette cannot be inserted.

UNLOADING

To unload a video cassette, press
the EJECT button on the remote
control, or press the STOP/EJECT
button on the TV/VCR twice.
The first press will stop the tape in
any mode. The second press will
eject the tape.

AUTOMA TIC EJECT

If the TV/VCR automatically rewinds the tape to the
beginning (AUTO REWIND FEATURE), the tape will
be ejected automatically (See NOTE on page 21).

NOTES: • Always eject the tape when not in use.

• The cassette tape can be ejected even if the

POWER is “OFF”.

TO PREVENT ACCIDENTAL ERASURE

After recording, break off the erase prevention tab if
you do not wish to record over the tape.

Screwdriver

To play a prerecorded tape.

TO START PLAYBACK

Load a prerecorded tape (When
loading a cassette tape without the
erase prevention tab, playback will
start automatically).

Press the PLAY button to begin
playback.

“

” will appear on the screen.

NOTE: This TV/VCR selects the playback tape speed

SP, LP or SLP automatically.

TO STOP PLAYBACK

Press the STOP button once.
The tape will stop, but remain fully
loaded and ready to play.
“

” will appear on the screen.

TO REWIND OR FORWARD THE
TAPE RAPIDLY

Press the REW (Rewind) or F.FWD (Fast Forward)
button in the Stop mode.

” or “ ” will appear on the screen.

“

FORWARD/REVERSE PICTURE SEARCH

If you want to see the tape during REW or FWD mode,
press and hold the REW or F.FWD button. The back­ward or forward visual search picture will be seen on the
screen. Release to return to the REW or FWD mode.

Erase prevention tab

TO RECORD AGAIN

Cover the hole with adhesive tape.
Be careful the tape does not extend past the edges of
the video cassette housing.

Adhesive tape

20

5A3A901A E P20-Back 3/18/02, 10:08 PM20

DIGITAL TRACKING CONTROLS

When a tape is played, the Digital
Auto Tracking system automatically
adjusts the tracking to obtain the
best possible picture. If noise bars
appear during playback, adjust the
tracking manually as follows:

• Press the SET/TRACKING + or –
button to obtain the best possible
picture. “MANUAL TR.” will appear
for 4 seconds on the screen.
To resume automatic tracking,
press the AUTO TRACKING button.
“AUTO TR.” will appear for 4 seconds on the screen.

MANUAL TR.

–

AUTO TR

.

+

TO MONITOR A TV PROGRAM

Press the TV MONI. button while in the playback mode.The
video tape will continue to play while the picture switches to
the TV channel selected on the TV/VCR. Press the button
to return to the playback picture.

SPECIAL PLAYBACK

RECORDING A TV PROGRAM

TO VISUALLY SEARCH FOR DESIRED
POINTS

When either the F.FWD or REW button is pressed in the
PLAYBACK mode, the speed search picture will appear.
When pressed twice, the search picture will increase
speed. Speed search time depends upon the speed
used (SP, LP or SLP) during recording. See chart below.
To visually search backward or forward, press the REW
or F.FWD button once or twice in the PLAYBACK mode.
Press the PLAY button to resume normal viewing speed.

SPEED SEARCH TIMES

TAPE SPEED

SP (Standard Play)
LP (Long Play)
SLP (Super Long Play)

PICTURE SEARCH SPEED

PRESS ONCE

PRESS ONCE

3 X
7 X
9 X

PRESS TWICE

PRESS TWICE

5 X
9 X

15 X

SKIP SEARCH

Press the SKIP SEARCH button in the PLAY mode. The VCR
will search forward through approximately 30 seconds of the tape
(e.g. unwanted commercial time) for each press of the SKIP SEARCH
button (maximum six presses) and then resume normal playback.

TO WATCH STILL PICTURE

Press the PAUSE/STILL button in the PLAYBACK mode.
Press the PLAY button or PAUSE/STILL button to resume
normal playback.

NOTES: • "SP" is more appropriate as less noise

appeared during search and still playback for
tape recorded in SP.

• The audio output is muted during Speed

Search and Still.

• A few noise bars will appear on the TV screen

during Speed Search and Still.

• T o prevent damage to the tape, Still and Speed

Search mode is automatically changed to the
Playback mode after 5 minutes.

TO WATCH A TAPE REPEATEDLY

1 Press the MENU button.
2 Press the SET/TRACKING + or

– button to select the AUTO
REPEAT option.

3 Press the ENTER button to select

the ON position.

4 Press the MENU button. If you press the PLAY button,

the tape will play over and over until the repeat mode is
canceled.

NOTE: To cancel repeat mode, follow above steps 1 and

2, then press the ENTER button to select the OFF
position. Press the MENU button to return to the
TV. The repeat function is canceled automatically
when the unit is switched off or the tape is ejected.

M E N U
TIMER REC SET
TV SET-UP
CH SET-UP
AUTO REPEAT ON OFF
SYSTEM SET-UP

〈

+/–/ENTER/MENU

〉

RECORDING AND VIEWING THE
SAME TV PROGRAM

1 Load a cassette tape with the erase prevention tab

intact.

2 Press the SPEED button to

select the desired tape speed
SP or SLP. The counter and SP
or SLP will appear on the screen
about 4 seconds.

00:00:00 SP

3 Set the TV/CATV option to the appropriate position

(See page 16).

TV - VHF/UHF channels
CATV - CABLE TV channels

NOTES: • If power is switched off during recording,

the TV set goes off and the VCR continues
to record. Press the STOP button to halt
the recording and turn off the VCR.

• The TV/VCR Channel cannot be changed
during recording.

4 Press the Direct Channel Selection buttons or

CHANNEL Up or Down button to select the channel
to be recorded.

5 Press the REC/OTR button.

" ● " and the channel number will
appear on the screen and the
REC/OTR indicator will light.

CH 012

TO STOP RECORDING

Press the STOP button to stop recording.
“ ■ ” will appear on the screen.

TO STOP RECORDING TEMPORARILY

Press the PAUSE/STILL button to avoid recording
unwanted material.

“

” will appear on the screen and the REC/OTR

indicator will blink on and off. Press the PAUSE/STILL
button or the REC/OTR button to continue the recording.

NOTE: The PAUSE mode will be changed to STOP mode

after five minutes to prevent damage to the tape.

NOTES: • AUTO REWIND FEATURE

This TV/VCR will automatically rewind the video
cassette when the tape has ended (except
during OTR and Timer Record). It will also eject
the video cassette.

• If the erase prevention tab is removed, the tape
will eject when the REC/OTR button is pressed
for recording.

ENGLISH

5A3A901A E P20-Back 3/18/02, 10:08 PM21

21

ONE-TOUCH TIMER

Press
once
twice
3 times
4 times
5 times
6 times
7 times
8 times
9 times

)

00:00:00 SP

OTR 0 : 30

Recording time

NORMAL REC

0:30
1:00
1:30
2:00
3:00
4:00
5:00

NORMAL REC

CH 012

RECORDING (OTR

The One-Touch Timer Recording feature provides a
simple and convenient way to make a timed recording.

EXAMPLE: One-touch Timer Recording for 30 minutes.

1 Press the POWER button to turn on the TV/VCR.
2 Load a video cassette with the erase prevention tab

intact.

3 Press the SPEED button to

select the desired tape speed
(SP or SLP). SP or SLP will
appear on the screen.

4 Set the TV/CATV option to the

appropriate setting (See page 17).

TV - VHF/UHF channels
CATV - CABLE TV channels

5 Press the Direct Channel Selection buttons or

CHANNEL Up or Down button to select the channel
to be recorded.

6 Press the REC/OTR button to

begin recording. Press the button
again to stop recording after 30
minutes. Each additional press of
the REC/OTR button will increase
recording time as shown below,
up to a maximum of 5 hours.
“OTR” will appear on the screen.

NOTES: • Press the REC/OTR

button to increase the
time needed for recording
(See the chart right).

• To cancel OTR, press
the STOP button.

• The TV/VCR channel
cannot be changed
during recording.

TIMER RECORDING

Timer recording can be programmed on-screen with
the remote control. The built-in timer allows automatic
unattended recording of up to 8 programs within 1
month.

EXAMPLE: Program a timer recording for 23rd day, channel

007 (CATV), 7:00 - 9:30 PM (Tape speed : SLP).

• Load a video cassette with the erase prevention tab
intact. The TV/VCR will automatically turn on.

• Set the TV/CATV selection to the appropriate position
(See page 16).

1 Press the MENU button.
2 Check the TIMER REC SET

option is selected, then press
the ENTER button.

M E N U
TIMER REC SET
TV SET-UP
CH SET-UP
AUTO REPEAT ON OFF
SYSTEM SET-UP

〈

+/–/ENTER/MENU

〉

22

TIMER RECORDING

3 Press the SET/TRACKING + or –

button to select the PROGRAM
position, then press the ENTER
button.

4 Press the SET/TRACKING + or –

button to select the date, then
press the ENTER button.

5 Set the start time, end time,

channel and tape speed as in step 4.

TIMER REC SET

DATE

23 (THU)

START

7 : 00 PM

END

9 : 30 PM

CH

007

SPEED

SLP

〈

+/–/ENTER/CANCEL/MENU

〉

23 TH

----- --:-- --- -

----- --

----- --- -

----- --- -

----- --- -

----- --- -

----- --- -

〈

+/–/ENTER/CANCEL/MENU

6 To set the timer for another program, press the SET/

TRACKING + or – button until the number of the
second program blinks, then press the ENTER
button. Repeat steps 4 to 5 to set the second pro­gram.

7 Press the TIMER REC button. The T-REC indicator

will light. The Timer is programed, when the programed
time is reached, the recording is automatically started.

To cancel timer recording, press the button again and
T-REC indicator will go out.

NOTES: • If programming is performed without a tape in

the TV/VCR, or with a tape without an erase
prevention tab, the Timer Recording is not
possible. If a tape without an erase prevention
tab is in the TV/VCR, the tape will be ejected.

• To record from the external equipment press
the SET/TRACKING + or – button repeatedly
until "L 1 (from AUDIO/VIDEO LINE1 jacks on
the rear)" or "L 2 (from AUDIO/VIDEO IN jacks
on the front)" appears when setting the
channel in step 5.

• The VCR section cannot be used while the
T-REC indicator is lit. If you want to use the
VCR operation, press the TIMER REC button
to deactivate the timer.

• After a power failure or disconnection of the
power plug, all programmed recording setting
and time display will be lost upon resumption of
power. In this case, reset the clock (see pages
13-14) and reprogram any timer recordings.

• If you want to correct the digits while setting,
press the CANCEL button until the item you
want to correct, then press the SET/TRACKING
+ or – button to correct the desired setting.

:

-- --- ---:--

----- --

----- --:-- --- -

----- --

----- --- -

----- --- -

----- --- -

----- --- -

----- --- -

〈

+/–/ENTER/CANCEL/MENU

TIMER REC SET

〈

+/–/ENTER/CANCEL/MENU

7:00PM9:30

:

--

--

:

--

--

:

--

--

:

--

--

:

--

--

:

--

--

--

--

--

--

DATE
START
END
CH
SPEED

:

--

--

--:--

--

:

--

--

:

--

--

:

--

--

:

--

--

:

--

:

--

:

--

:

--

:

--

:

--

:

--

PM

:

--

-­:

--

--

--

:

--

--

:

--

--

:

--

--

:

--

--

:

--

23 (THU)
8 : 30 AM

-- : -­012
SP

007

SLP

--- -

〉

--- -

〉

〉

5A3A901A E P20-Back 3/18/02, 10:08 PM22

TO SET DAILY/WEEKLY TIMER

When setting the date in the step 4 on page 22, press the SET/
TRACKING – button repeatedly when the current day is displayed.
The setting changes as follows:

Example

The current day (Friday) SUN-SAT (Sunday to Saturday)

MON-SAT (Monday to Saturday)
One month later
minus one day MON-FRI (Monday to Friday)

WKL-WED WKL-THU (Weekly Thursday)
(Weekly Wednesday)

TO CONFIRM THE SETTINGS

Press the PROGRAM button once. The TV screen
displays the timer program list. Press the PROGRAM
button again. The TV screen displays the ON/OFF timer
setting.

(once)

007

--

--:--

--

--

--

--

--

SLP

PM

:

--

--- -

:

--

:

--

:

--

:

--

:

--

23 TH

7:00PM9:30

----- --:-- --- -

----- --

:

--

----- --- -

--

:

--

----- --- -

--

:

--

----- --- -

--

:

--

----- --- -

--

:

--

----- --- -

--

:

--

〈

+/–/ENTER/CANCEL/MENU

(twice)

ON/OFF TIMER
ON TIMER

7:00AM CH012

MON-FRI SET

OFF TIMER

11:30PM SET

〈

〉

+/–/ENTER/CANCEL/MENU

〉

Press the PROGRAM button 3 times. The screen returns
to the normal screen.

TO CANCEL A PROGRAM

Press the SET/TRACKING + or –
button to select the TIMER REC
SET option in the MENU, then
press the ENTER button.
Press the SET/TRACKING + or –
button to select the unnecessary
program, and press the CANCEL
button to cancel the program.

:

-- --- ---:--

----- --

----- --:-- --- -

----- --

----- --- -

----- --- -

----- --- -

----- --- -

----- --- -

〈

+/–/ENTER/CANCEL/MENU

:

--

--

--- -

:

--

:

--

--

--

--

:

--

:

--

--

--

:

--

:

--

--

--

:

--

:

--

--

--

:

--

:

--

--

--

:

--

:

--

〉

IF THE PROGRAM OVERLAPS ANOTHER

NOTE: Do not overlap programs as portions of the

conflicting programs will be lost. The first
recording time has priority over the next recording
time as shown in the diagram.

Program 1
Program 2

Program 3

Recording
Control Settings

NOTES: • The everyday/every week recording can be

• During timer recording, the automatic

• You can correct or cancel the programmed

8 : 00

Prog.1

9 : 00

Deleted Parts

Non Recorded Portion Parts

Prog.2 Prog.3

10 : 00

11 : 00

made continuously until the recording is
canceled or the tape reaches the end.

rewinding mechanism does not function.
setting in program confirm mode.

USING THE REAL TIME
TAPE COUNTER

The On-Screen Real Time Tape Counter shows the tape
running time in Hours, Minutes and Seconds.
You can easily determine how long the tape has been
running or how much time is left on the tape.

TO VIEW THE COUNTER DISPLAY

1 Press the CALL button.
2 Press the COUNTER RESET

button to set the counter to
“00:00:00”.

3 Begin Playback or Recording to

start the tape, the counter will
display the elapsed time.

4 When you wish to make the

counter disappear, press the
CALL button once again.

NOTES: • If you rewind the tape from “00:00:00”, a minus

sign (“–”) will be displayed in front of the time.

• When you load a tape, the counter will reset to
“00:00:00”.

• The counter does not function on nonrecorded
(blank) sections of the tape. When you rewind,
fast forward or play tapes through blank
sections, the counter stops.

8:40AM THU

9:00AM THU

CH 012

00:00:00

SP

CH 012

00:30:00 SP

USING ZERO RETURN

The zero return function provides a convenient
method of rapidly returning to the starting point of
recording or playback. The starting point can be
indexed for any location on the tape by pressing the
COUNTER RESET button and ZERO RETURN button.

1 Press the CALL button.

2 Before playback or recording,

press the COUNTER RESET

8:40AM THU

8:40AM THU

00:30:50

CH 012

SP

CH 012

button to set the counter to
“00:00:00”.

00:00:00 SP

3 Begin playback or recording.
4 Press the STOP button.

5 Press the ZERO RETURN

button. The tape will rewind

9:00AM THU

9:00AM THU

CH 012

00:20:00 SP

CH 012

and automatically stop at the
“00:00:00” position.

00:00:00 SP

23

ENGLISH

5A3A901A E P20-Back 3/18/02, 10:08 PM23

DUPLICATING A VIDEO TAPE

If you connect the TV/VCR to another VCR or
Camcorder, you can duplicate a previously recorded
tape. Make all connections before turning on the power.

1 Insert a blank cassette with the erase prevention tab

intact into the TV/VCR.
Insert a previously recorded cassette into the play­back VCR or Camcorder.

2 Press the INPUT SELECT button

twice to select AUDIO/VIDEO
input position. The "LINE 2" will
appear on the screen.

NOTE: You can also use the rear AUDIO/VIDEO

LINE1 Jacks. Select "LINE 1" by pressing the
INPUT SELECT button.

LINE 2

3 Press the REC/OTR button on the remote control of

the TV/VCR, then press the PAUSE/STILL button.

4 Press the PLAY Button on the playback VCR, then

press the PAUSE/STILL button.

5 Press the PAUSE/STILL buttons on both units

simultaneously to begin the duplicating process.

NOTES: • It is recommended that the tape speed be set

to the SP mode on the TV/VCR for best result.

• Unauthorized recording of copyrighted
television programs, films, video cassettes
and other materials may infringe the rights of
copyright owners and be contrary to copyright
laws.

CONNECTION TO ANOTHER VCR

Recording TV/VCR

Playback VCR

To VIDEO

OUT

To AUDIO
OUT

Audio/Video Cord (not supplied)

To Video In

To
Audio In

CONNECTION TO CAMCORDER

For duplicating a previously recorded tape from a
camcorder, follow the camcorder manufacturer’s instruc­tions. A typical camcorder dubbing hookup is shown
below.

Recording TV/VCR

Playback
Camcorder

To AV Jack

To Video/Audio In

Audio/Video Cord (not supplied)

24

5A3A901A E P20-Back 3/18/02, 10:08 PM24

RECEPTION DISTURBANCES

Most types of television interference can be remedied
by adjusting the height and position of the VHF/UHF
antenna. Outdoor antennas are recommended for
best results. The most common types of television
interference are shown below. If one of these symptoms
appear when the TV/VCR is connected to a Cable TV
system, the disturbance may be caused by the local
Cable TV company broadcast.

IGNITION

Black spots or horizontal streaks
may appear, the picture may
flutter or drift. Usually caused by
interference from automobile
ignition systems, neon lamps or
AC powered tools and
appliances such as drills or hair
dryers.

GHOSTS

Ghosts are caused by the
television signal following two
paths. One is the direct path and
the other is reflected by tall
buildings, hills or other large
objects. Changing the direction
or position of the antenna may
improve the reception.

CARE AND MAINTENANCE

To prevent fire or shock hazard, disconnect the TV/VCR
from the AC power sources before cleaning.
The finish on the cabinet may be cleaned with mild soap
and a soft, damp cloth and cared for as other furniture.
Use caution when cleaning or wiping the plastic parts.

ENGLISH

VIDEO HEAD CLEANING

VIDEO HEAD CLOGGING

The video heads are the means by which the TV/VCR
reads the picture from the tape during playback. In the
unlikely event that the heads become dirty enough to be
clogged, no picture will be played back. This can easily
be determined if, during playback of a known good tape,
there is good sound, but no picture (picture is extremely
snowy). If this is the case, use a high quality head
cleaning system or have them cleaned professionally.

SNOW

If the TV/VCR is located far from
the TV station, in a fringe
reception area where the signal
is weak, small dots may appear
in the picture. If the signal is
extremely weak, the installation
of a larger external antenna may
be necessary.

RADIO FREQUENCY INTERFERENCE
(RFI)

Caused by two-way radios, this
type of interference produces
moving ripples or diagonal
streaks in the picture. Some
cases may cause a loss of
contrast in the picture. Changing
the direction and position of the
antenna or installing an RFI filter
may improve the picture.

PICTURE SIZE VARIATION

A slight picture size variation is
normal when you adjust the
CONTRAST or BRIGHTNESS
settings.

Good Picture Snowy Picture

VIDEO HEAD CLEANING

Video head cleaning is needed when the playback
picture becomes unclear. This signifies that the heads
are getting dirty and can occur when playing poor quality
or damaged tapes. If the heads require cleaning, use a
equivalent high quality chemical non-abrasive (wet)
head cleaning tape or have them cleaned professionally.
If playing a head cleaning tape in the VCR once does
not improve the picture, play it several times before
requesting service.

DO NOT ATTEMPT TO CLEAN THE VIDEO HEADS OR
SERVICE THE UNIT BY REMOVING THE TOP COVER.

NOTES: • Video heads may eventually wear out and

should be replaced when they fail to produce
clear pictures.

• To help prevent video head clogging, use
only good quality VHS tapes. Discard worn
out tapes.

25

5A3A901A E P20-Back 3/18/02, 10:08 PM25

TROUBLESHOOTING GUIDE

Check the following chart before requesting service.

SYMPTOM CAUSE POSSIBLE SOLUTION PAGE

POWER

The AC power cord is not connected.

No power.

Although the power is on,
the TV/VCR does not
operate.

TV BROADCAST RECEPTION

Poor or no picture.

Poor or no color.

Picture wobbles or drifts.

No CATV reception.

No reception above
channel 13.

Poor or no sound.

The DC car cord is not plugged into
the cigarette lighter socket.

The DC car cord fuse is blown.
Cassette is not inserted.
TIMER REC button is depressed.
Moisture condenses on the video

heads.

TV station experiencing problems.
Picture control is not adjusted.
Possible local interference.

Antenna (CATV) connector is not
connected or possible
localinterference.

TV station experiencing problems.
Picture control is not adjusted.
Possible local interference.

Antenna (CATV) connector is not
connected or possible local
interference.

TV station experiencing problems.
Antenna (CATV) connector is not

connected or possible local
interference.

Cable TV channel is scrambled.
CATV connector is not connected.
TV/CATV Mode menu option is set to

the TV mode.
Cable TV service interrupted.
TV/CATV Mode menu option is not

set to the appropriate mode.
UHF antenna is not connected.
TV station experiencing problems.
Antenna (CATV) connector is not

connected or possible local
interference.

Possible local interference.

MUTING button is depressed.

Connect the AC power cord to the
AC outlet.

Connect the DC car cord to the
cigarette lighter socket.

Replace fuse.
Insert a video cassette.
Press the TIMER REC button.
"DEW" appears on the screen. Wait

two or three hours until it goes off.

Try another channel.
Check picture control adjustments.
Check for source of reception

disturbance.
Check CATV connection or VHF/

UHF antenna, reposition or rotate
antenna.

Try another channel.
Check picture control adjustments.
Check for source of reception

disturbance.
Check CATV connection or VHF/

UHF antenna, reposition or rotate
antenna.

Try another channel.
Check CATV connection or VHF/

UHF antenna, reposition or rotate
antenna.

Try another channel.
Check all CATV connections.
Set the TV/CATV Menu option to

the CATV mode.
Contact your Cable TV company.
Make sure TV/CATV menu option is

in the appropriate mode.
Check UHF antenna.
Try another channel.
Check CATV connection or VHF/

UHF antenna, reposition or rotate
antenna.

Check for source of reception
disturbance.

Check that MUTING button has not
been pressed.

10

10
11

20
22

5

14
19

25

11,12

14
19

25

11,12

14

11,12

14
12

16
12
16
11

14

11, 12

25

15

26

5A3A901A E P20-Back 3/18/02, 10:08 PM26

SYMPTOM CAUSE POSSIBLE SOLUTION PAGE

Tune new channel.
Set Sleep Timer to "0".
Cancel OFF timer.

Reset your password.
Try another channel.

Check CATV connection of VHF/
UHF antenna, reposition or rotate
antenna.

Press the TV/CAP/TEXT button to
turn on the closed caption.

Place a piece of vinyl tape over the
hole.

Reset the present time.
Reset the start/end time.

Press the TIMER REC button (The
T-REC indicator is lit).

Replace the tape.
Adjust tracking manually using the

SET/TRACKING + or – buttons on
the remote control.

Clean the video heads.

Aim the remote control at the
remote sensor.

Operate within 15 feet or reduce
the light of the room.

Clear the path of the beam.

Replace the batteries.
Insert correctly.

TV shuts off.

No reception

Closed caption is not
activated.

RECORDING

TV recording does not work.

Timer recording does not
work.

PLAYBACK

Noise bars appear on the
screen.

REMOTE CONTROL

Remote control does not
operate.

TV station stopped broadcasting.
Sleep timer is set.
OFF timer is set.

Lost your password.
TV station experiencing problems or

program tuned is not closed caption.
TV signal is weak.

The TV/CAP/TEXT button is not
depressed.

The video cassette's erase prevention
tab is broken off.

The time is not set correctly.
The recording start/end time is not

set correctly.
The TIMER REC button has not been

pressed (The T-REC indicator is not lit).

Tape is old or worn.
Tracking adjustment is beyond range

of automatic tracking circuit.

Video heads are dirty.

The remote control is not aimed at
the sensor.

Distance is too far or too much light
in the room.

There is an obstacle in the path of
the beam.

The batteries are weak.
The batteries are not inserted

correctly.

14
15

19
17

14

11,12

15

20
14
22

22

—

20

25

10

10

10
10

10

ENGLISH

FOR ADDITIONAL SET-UP OR OPERATING ASSISTANCE, PLEASE VISIT OUR WEBSITE AT

WWW.MEMCORPINC.COM OR CONTACT CUSTOMER SERVICE AT 1-800-919-3647

PLEASE KEEP ALL PACKAGING MATERIAL FOR AT LEAST 90 DAYS IN CASE YOU NEED TO RETURN THIS

PRODUCT TO YOUR PLACE OF PURCHASE OR MEMOREX.

FOR PAR TS AND ACCESSORIES, CONT ACT FOX INT'L A T 1-800-321-6993.

5A3A901A E P20-Back 3/18/02, 10:08 PM27

27

27

SPECIFICATIONS

TELEVISION

Picture Tube: 13" (measured diagonally)
Horizontal Resolution: 230 lines

Tuner T ype: Quartz PLL Frequency Synthesized
Receiving Channels: VHF 2-13

Antenna Input: VHF/UHF In 75 ohms coaxial
Speaker: 1.5" x 2.5", 8 ohm x 1

Audio Output Power: 1.5W

VCR

Video System: VHS, 2 Rotary Heads Helical Scanning System.
Video Signal: NTSC Color
Cassette Tape: VHS
Audio Track: 1 Track
Tape Speed: SP: 33.35 mm/sec.

F .FWD/REW T ime at 25˚C(77˚F): F.FWD: Approx. 4 minutes 50 seconds

Speed Search: SP 3 & 5 x Normal Speed

GENERAL

Power Source: AC 120V 60Hz

Power Consumption: 65 Watts (AC 120V), 54 Watts (DC12 V)
Dimensions: W 14-1/4" x D 14-9/16" x H 15-1/16"
Weight: 27.6 Ibs

Inputs/Outputs: Video: IN (RCA) 1V p-p/75 ohm

Storage Temperature: –20°C to 60°C (–4°F to 140°F)
Operating Temperature: 5°C to 40°C (41°F to 104°F)
Remote Control: Infrared, Direct Access, 2 x AAA batteries (not supplied)

UHF 14-69
CATV 14-36 (A)-(W)

37-59 (AA)-(WW)
60-85 (AAA)-(ZZZ)
86-94 (86)-(94)
95-99 (A-5)-(A-1)
100-125 (100)-(125)
01 (5A)

LP: 16.67 mm/sec.
SLP: 11.12 mm/sec.

REW: Approx. 2 minutes 30 seconds
(T-120 Cassette)

LP 7 & 9 x Normal Speed
SLP 9 & 15 x Normal Speed

DC 12V

OUT (RCA) 1Vp-p/75 ohm

Audio: IN (RCA) –8 dB/50K ohm

OUT (RCA) –8 dB/1K ohm

Accessories: Remote Control

Specifications are subject to change without notice.

T elescopic Antenna
12V DC Car Cord

28

5A3A901A E P20-Back 3/18/02, 10:08 PM28

MEMO

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

ENGLISH

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

29

5A3A901A E P20-Back 3/18/02, 10:08 PM29
