OWNER'S MANUAL
MANUAL DE INSTRUCCIONES

VIDEO CASSETTE RECORDER
VIDEOGRABADOR DE CASSETTE

MVR4041

ATTENTION

ATENCION

If you purchase a universal remote control from your local retailer, please contact the
remote manufacturer for the required programming code.
Si usted a comprado un control de remoto universal, por favor comunicace con el
para el codico de programaccion requerido.

fabricante

ENGLISH

ESPAÑOL

When shipped from the factory, the TV/CATV menu option is set to the "CATV" (Cable
Television) mode.
If not using CATV (Cable TV), set this menu option to the "TV" mode.
A la salida de fábrica, la opción de menú TV/CATV está en el modo "CATV" (televisión por cable).
Si no se va a utilizar el CATV (TV cable), cambie la opción de este menú al modo TV.

Before operating the unit, please read this manual thoroughly.
Antes de utilizar su aparato favor de leer las siguientes instrucciones.

4E40401A E COV-07 4/1/01, 5:03 PM1

TV/CATV MODE SELECTION

SELECCION DE MODO DE TV/CATV

1

ENGLISH

CAUTION

RISK OF ELECTRIC SHOCK
DO NOT OPEN

CAUTION: TO REDUCE THE RISK OF ELECTRIC

SHOCK, DO NOT REMOVE COVER
(OR BACK). NO USER-SERVICEABLE
PARTS INSIDE. REFER SERVICING TO
QUALIFIED SERVICE PERSONNEL.

The lightning flash with arrowhead symbol
within an equilateral triangle is intended to
alert the user to the presence of uninsulated
dangerous voltage within the product's
enclosure that may be of sufficient magnitude
to constitute a risk of electric shock.

The exclamation point within an equilateral
triangle is intended to alert the user to the
presence of important operating and
maintenance (servicing) instructions in the
literature accompanying the appliance.

WARNING: TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE THIS APPLIANCE TO RAIN

WARNING: This equipment has been tested and found

to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against
harmful interference in a residential installation. This
equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful
interference to radio communications.
However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does
cause harmful interference to radio or television recep­tion, which can be determined by turning the equipment
off and on, the user is encouraged to try to correct the

OR MOISTURE.

interference by one or more of the following measures:

- Reorient or relocate the receiving antenna.

- Increase the separation between the equipment and
receiver.

- Connect the equipment into an outlet on a circuit
different from that to which the receiver is connected.

- Consult the dealer or an experienced radio/TV techni­cian for help.

CAUTION: Changes or modifications not expressly
approved by the partly responsible for compliance with
the FCC Rules could void the user's authority to operate
this equipment.

IMPORTANT SAFEGUARDS

1. READ INSTRUCTIONS

All the safety and operating instructions should be
read before the unit is operated.

2. RETAIN INSTRUCTIONS

The safety and operating instructions should be
retained for future reference.

3. HEED WARNINGS

All warnings on the unit and in the operating
instructions should be adhered to.

4. FOLLOW INSTRUCTIONS

All operating and use instructions should be followed.

5. CLEANING

Unplug this unit from the wall outlet before cleaning.
Do not use liquid cleaners or aerosol cleaners.
Use a damp cloth for cleaning.

6. ATTACHMENTS

The manufacturer of this unit does not make any
recommendations for attachments, as they may cause
hazards.

2

2

7. WATER AND MOISTURE

Do not use this unit near water. For example, near a
bathtub, washbowl, kitchen sink, or laundry tub, in a
wet basement, or near a swimming pool.

8. ACCESSORIES

Do not place this unit on an unstable cart, stand,
tripod, bracket, or table. The unit may fall, causing
serious injury, and serious damage to the unit.

8A. An appliance and cart combination should be moved

with care. Quick stops, excessive force, and uneven
surfaces may cause the appliance and cart combina­tion to overturn.

PORTABLE CART WARNING

(symbol provided by RETAC)

S3125A

4E40401A E COV-07 4/1/01, 5:03 PM2

IMPORTANT SAFEGUARDS

9. VENTILATION

Slots and openings in the cabinet back or bottom
are provided for ventilation and to ensure reliable
operation of the unit and to protect it from overheating.
These openings must not be blocked or covered.
The openings should never be blocked by placing
the unit on a bed, sofa, rug, or other similar surface.
This unit should never be placed near or over a
radiator or heat source. This unit should not be
placed in built-in installations such as a bookcase or
rack unless proper ventilation is provided or the
manufacturer's instructions have been adhered to.

10. POWER SOURCES

This unit should be operated only from the type of
power source indicated on the rating plate. If you are
not sure of the type of power supply to your home,
consult your appliance dealer or local power com­pany. For units intended to operate from battery
power, or other sources, refer to the operating
instructions.

11. GROUNDING OR POLARIZATION

This unit is equipped with a polarized alternating­current line plug (a plug having one blade wider than
the other). This plug will fit into the power outlet only
one way. This is a safety feature. If you are unable
to insert the plug fully into the outlet, try reversing
the plug. If the plug should still fail to fit, contact your
electrician to replace your obsolete outlet. Do not
defeat the safety purpose of the polarized plug If your
unit is equipped with a 3-wire grounding-type plug, a
plug having a third (grounding) pin, this plug will only
fit into a grounding-type power outlet. This too, is a
safety feature. If you are unable to insert the plug
into the outlet, contact your electrician to replace
your obsolete outlet.
Do not defeat the safety purpose of the grounding­type plug.

12. POWER-CORD PROTECTION

Power-supply cords should be routed so that they
are not likely to be walked on or pinched by items
placed upon or against them, paying particular
attention to cords at plugs, convenience receptacles,
and the point where they exit from the appliance.

13. LIGHTNING

To protect your unit from a lightning storm, or when
it is left unattended and unused for long periods of
time, unplug it from the wall outlet and disconnect
the antenna or cable system. This will prevent
damage to the unit due to lightning and power line
surges.

14. POWER LINES

An outside antenna system should not be located in
the vicinity of overhead power lines or other electric
light or power circuits, or where it can fall into such
power lines or circuits. When installing an outside
antenna system, extreme care should be taken to
keep from touching such power lines or circuits, as
contact with them might be fatal.

15. OVERLOADING

Do not overload wall outlets and extension cords, as
this can result in a risk of fire or electric shock.

16. OBJECT AND LIQUID ENTRY

Do not push objects through any openings in this unit
as they may touch dangerous voltage points or short
out parts that could result in fire or electric shock.
Never spill or spray any type of liquid into the unit.

17. OUTDOOR ANTENNA GROUNDING

If an outside antenna or cable system is connected
to the unit, be sure the antenna or cable system is
grounded to provide some protection against voltage
surges and built-up static charges. Section 810 of
the National Electrical Code, ANSI/NFPA 70,
provides information with respect to proper grounding
of the mast and supporting structure, grounding of
the lead-in wire to an antenna discharge unit, size of
grounding conductors, location of antenna discharge
unit, connection to grounding electrodes, and
requirements for the grounding electrode.

18. SERVICING

Do not attempt to service this unit yourself as
opening or removing covers may expose you to
dangerous voltage or other hazards. Refer all
servicing to qualified service personnel.

ENGLISH

ENGLISH

4E40401A E COV-07 4/1/01, 5:03 PM3

3

3

IMPORTANT SAFEGUARDS

19. DAMAGE REQUIRING SERVICE

Unplug this unit from the wall outlet and refer
servicing to qualified service personnel under the
following conditions:

a. When the power-supply cord or plug is damaged.
b. If liquid has been spilled, or objects have fallen

into the unit.
c. If the unit has been exposed to rain or water.
d. If the unit does not operate normally by

following the operating instructions. Adjust only

those controls that are covered by the operating

instructions, as an improper adjustment of

other controls may result in damage and will

often require extensive work by a qualified

technician to restore the unit to its normal

operation.
e. If the unit has been dropped or the cabinet has

been damaged.

f. When the unit exhibits a distinct change in

performance, this indicates a need for service.

EXAMPLE OF ANTENNA GROUNDING AS PER THE

NATIONAL ELECTRICAL CODE

20. REPLACEMENT PARTS

When replacement parts are required, be sure the
service technician uses replacement parts specified
by the manufacturer or those that have the same
characteristics as the original parts.
Unauthorized substitutions may result in fire, electric
shock or other hazards.

21. SAFETY CHECK

Upon completion of any service or repairs to this
unit, ask the service technician to perform safety
checks to determine that the unit is in proper
operating condition.

22. HEAT

The product should be situated away from heat
sources such as radiators, heat registers, stoves, or
other products (including amplifiers) that produce heat.

23. NOTE TO CATV SYSTEM INSTALLER

This reminder is provided to call the CATV system
installer's attention to Article 820-40 of the NEC that
provides guidelines for proper grounding and, in
particular, specifies that the cable ground shall be
connected to the grounding system of the building,
as close to the point of cable entry as practical.

ELECTRIC SERVICE

EQUIPMENT

NEC-NATIONAL ELECTRICAL CODE

S2898A

4

4E40401A E COV-07 4/1/01, 5:03 PM4

ANTENNA LEAD IN WIRE

GROUND CLAMP

ANTENNA DISCHARGE UNIT
(NEC SECTION 810-20)

GROUNDING CONDUCTORS

(NEC SECTION 810-21)
GROUND CLAMPS
POWER SERVICE GROUNDING

ELECTRODE SYSTEM
(NEC ART 250, PART H)

PRECAUTIONS

MOISTURE CONDENSATION

DO NOT OPERATE THIS VCR FOR AT LEAST TWO
OR THREE HOURS WHEN MOISTURE IN THE AIR
CONDENSES ON THE VCR.

WHAT IS MOISTURE CONDENSATION?

When a cold liquid is poured into a glass, for example,
water vapor in the air will condense on the surface of the
glass. This is called moisture condensation.

MOISTURE WILL CONDENSE ON THE UNIT IN THE
FOLLOWING CASES;

• When you move this VCR from a cold to a warm place.

• After heating a cold room or under extremely humid

conditions.

WHEN YOU EXPERIENCE THE ABOVE CONDITIONS,

Plug the power cord into an AC outlet, press the POWER
button to turn on and leave the unit at room temperature
until moisture condensation disappears.
Depending on the surrounding conditions, this may take
two or three hours.

LOCATION AND HANDLE

• If you cause a static discharge when touching the VCR,
and the VCR fails to function, simply unplug the unit
from the wall outlet, wait 10 minutes and plug it back
in. The VCR should return to normal operation.

• Avoid extreme heat or cold. (41˚F/5˚C-104˚F/40˚C)

• Do not place the VCR on or near appliances which

may cause electromagnetic interference, e.g. TV,
speakers, etc. Doing so may cause erratic operation
of the VCR including picture and/or sound distortion or
noise.

• Avoid extreme moisture and dust.

• The ventilation holes prevent overheating. Do not

block or cover these holes. Especially avoid covering
the holes with soft materials such as cloth or paper.

• Do not insert fingers or any other objects into the
cassette loading slot. Do not spray cleaner or wax
directly on the VCR or use forced air to remove dust.

• Avoid places subject to strong vibration. Use in a
horizontal (flat) position only.

• Keep the VCR away from flower vases, sinks, etc.
If liquids should be spilled into the VCR, serious
damage will result. If you spill any liquids into the
VCR, unplug the AC power cord immediately and
consult qualified service personnel before attempting
to use the VCR again.

• When you finish operating the VCR, always unload
the cassette and turn off the power.

• When you leave your home for a long time, unplug the
AC power cord.

• To protect the VCR from a lightning storm, unplug the
AC power cord from the wall outlet and disconnect the
antenna.

POWER SOURCE

TO USE AC POWER SOURCE

Use the AC polarized line cord provided for operation on
AC. Insert the AC cord plug into a standard 120V 60Hz
polarized AC outlet.

NOTES:

1. Never connect the AC line cord plug to other than the

specified voltage (120V 60Hz). Use the attached
power cord only.

2. If the polarized AC cord does not fit into a non-polarized

AC outlet, do not attempt to file or cut the blade. It is the
user’s responsibility to have an electrician replace the
obsolete outlet.

AC Outlet

Wider Hole
and Blade

Polarized AC Cord Plug

(One blade is wider than the other)

ENGLISH

5

4E40401A E COV-07 4/1/01, 5:03 PM5

PRECAUTIONS FEATURES

BATTERY CAUTIONS

Follow these precautions when using batteries in this
device:

• Use only the size and type of batteries specified.

• Be sure to follow the correct polarity when installing

the batteries as indicated in the battery compartment.
Reversed batteries may cause damage to the device.

• Do not mix different types of batteries together (e.g.
Alkaline and Carbon-zinc) or old batteries with fresh
ones.

• If the device is not to be used for a long period of
time, remove the batteries to prevent damage or
injury from possible battery leakage.

• Do not try to recharge batteries not intended to be
recharged; they can overheat and rupture (Follow
battery manufacturer's directions).

BATTERY INSTALLATION

• Open the battery

compartment cover.

• Install two "AAA"

batteries.

• Replace the cover.

EFFECTIVE DISTANCE OF THE
REMOTE CONTROL

High Quality Picture Technology - This video cassette

recorder marked "HQ" incorporates VHS high quality
technology. A built-in detail enhancer is used to boost
the recorded signal and provide maximum picture
quality in playback. It is compatible with other VHS video
cassette recorders.

4 Video Heads - Provides optimal picture quality for
special effects playback.

Hi-Fi Stereo Sound - With a frequency response of 20
to 20,000 Hz and a dynamic range of better than 90dB,
this VCR provides a level of excellence that rivals
compact discs.

8-Program/1-Month Programmable Timer with
Everyday/Every Week Capability - The built-in timer

allows automatic absentee recording of up to 8 TV
programs within 1month. It is also possible to record a
program which is broadcast at the same time everyday
or every week.

On-Screen Display and Programming - When you
select a channel or make other changes, the TV will
show an indicator on the screen for a few seconds.
Clock settings, timer setting and other set-up operations
can be carried out using the on-screen display menu
system.

Digital Auto Tracking - Automatically adjusts tracking
during playback for the best possible picture.

181 Channel Tuner - Receives standard VHF and UHF
broadcast channels and up to 113 cable channels.

One-touch Timer Recording (OTR) - Simply by
pressing the REC/OTR button, the VCR can be pro­grammed for up to 5 hours of recording with an immedi­ate start.

30˚ 30˚

15 FEET

NOTES: • When direct sunlight, an incandescent lamp,

fluorescent lamp or any other strong light
shines on the Remote Sensor, the remote
operation may be unstable.

• When there is an obstacle between the VCR
and the remote control, the remote control
may not operate.

6

4E40401A E COV-07 4/1/01, 5:03 PM6

Automatic Power On - When loading a cassette tape,
this VCR will automatically turn on.

Automatic Playback - When loading a cassette tape with­out the erase prevention tab, this VCR will automatically
turn on and play back the cassette tape at the correct
speed.

Automatic Rewind-Stop-Eject-Power Off - When a
tape reaches its end during playback and recording, it
will automatically stop, rewind, stop, eject the tape and
the VCR will turn off.

TABLE OF CONTENTS

Automatic Repeat Play System - When the AUTO

REPEAT option is turned on, this VCR will automatically
play back the same cassette tape repeatedly.

On-Screen 3 Language Display - This TV can display
the on screen language in English, Spanish or French.

Slow Motion - This VCR provides slow motion which of­fers steady, noise free playback at 1/10 normal speed.

Frame by Frame Advance - Press the SLOW button
during still playback to advance the tape one frame at
a time.

Real Time Tape Counter with Zero Return - The
counter displays real tape time and the zero return
function can be used to return the tape to a preselected
position (00:00:00) while the counter can be used to
locate programs.

Channel Skip - An unwanted channel can be deleted
when using the CHANNEL ▲ or ▼ button.

Fluorescent Multi-Function Display - Selected
functions are immediately indicated on the display.

2 Speed Picture Search - 3 or 5 times normal speed in
SP mode (7X or 9X in LP and 9X or 15X in SLP).

3 Speed Playback - Plays three tape speeds (SP, LP,
SLP).

2 Speed Record - Records two tape speeds (SP, SLP).
Stereo/SAP Reception - This VCR is designed to receive

stereo and separate audio program (SAP) broadcasts
where available.

Front Audio/Video In Jacks - A VCR or other video
device may be hooked up for dubbing.

CAUTIONS

IMPORTANT SAFEGUARDS ....................................2

PRECAUTIONS .........................................................5

PREPARATION

ENGLISH

FEATURES ................................................................6

LOCATION OF CONTROLS...................................... 8

BASIC CONNECTIONS........................................... 10

CATV (CABLE TV) CONNECTIONS .......................12

AUDIO/VIDEO CONNECTIONS ..............................14

SETTING THE VIDEO CHANNEL ...........................15

ON-SCREEN LANGUAGE SELECTION .................15

SETTING THE CLOCK ............................................ 15

SETTING THE CHANNELS..................................... 16

NOISE ELIMINATION (BLUE SCREEN) .................16

PLAYBACK

LOADING AND UNLOADING ..................................17

PLAYBACK ..............................................................17

SPECIAL PLAYBACK .............................................. 18

RECORDING

RECORDING A TV PROGRAM...............................18

ONE-TOUCH TIMER RECORDING (OTR) .............20

SETTING THE TIMER RECORDING ......................20

ADDITIONAL INFORMATION

ON-SCREEN FUNCTION DISPLAY........................ 21

STEREO RECORDING AND PLAYBACK............... 22

SEPARATE AUDIO PROGRAM (SAP) ................... 22

USING ZERO RETURN........................................... 22

DUPLICATING A VIDEO TAPE ............................... 23

VIDEO HEAD CLEANING........................................ 23

BEFORE REQUESTING SERVICE......................... 24

SPECIFICATIONS ................................................... 25

4E40401A E COV-07 4/1/01, 5:03 PM7

7

LOCATION OF CONTROLS

FRONT

MONO

VIDEO IN

AUDIO IN

L R

10

REMOTE CONTROL

POWER

5

123

11

6

3

2

12

13

14

15

16

17

18

456
7

89

0

REC/OTR

REW

MENU

–

TRACKING

TIMER REC

TRACKING

CLOCK/

COUNTER

COUNTER

RESET

TV/VCR SPEED

8

PLAY

STOP

SET

AUTO

SLOW

AUDIO

SELECT

CHANNEL

PAUSE/STILL

+

CANCEL

RETURN

SELECT

ENTER

ZERO

INPUT

CALL

F.FWD

1 2

CHANNEL

9

8

REW

3

PLAY

STOP/EJECT

45

F.F WD

1. Cassette Loading Slot - To insert or remove a
video tape.

2. REW button - In the STOP mode, this button
rapidly winds the tape backwards. In the PLAY
mode, this button activates Reverse Search.

3. PLAY button - Press to play a prerecorded tape.

4. F. FWD button - In the STOP mode, this button

8

rapidly winds the tape forward. In the PLAY mode,
this button activates Forward Search.

5. POWER button - Turns the VCR power on and off.

19

6. REC/OTR button - Press once to start normal

recording. Additional presses activate One-touch
Timer Recording.

7. STOP/EJECT button - Press once to stop the tape
in any mode. Press again to eject the tape.

4

8. CHANNEL ▼ / ▲ buttons - Used to select a

20

21
22
23
24
25
26
27
28

channel for viewing or recording.

9. Remote Sensor - Signals from the Remote Control
are received here.

10. AUDIO (L/R)/VIDEO In Jacks - Audio and video
signal cables from an external source can be
connected here.

11. Direct Channel Selection buttons (0-9) - Allows
direct access to any channel.

12. STOP button - Press to stop the tape.

13. MENU button - Press to display the on-screen menu

function.

14. TIMER REC button - Used to set the VCR to start
recording at a preset time.

15. SLOW button - Press to play back a tape in slow
motion or to advance the tape one frame at a time
during still playback.

POWER

REC/OTR

67

4E40401A E P08-13 4/1/01, 5:03 PM8

REAR

33

29

OUT

VIDEO

AUDIO

L

R

34

32

30

UHF/VHF

IN(ANT)

OUT(TV)

31

ENGLISH

16. CLOCK/COUNTER selector button - Switches

between the clock and the real time tape counter.

17. COUNTER RESET button - Resets the Real Time
Tape Counter to 00:00:00.

18. TV/VCR selector button - Switches between TV
and VCR.

19. PAUSE/STILL button - During recording, this
button temporarily stops the tape. The "

" will
appear on the screen. During playback, it stops the
tape and displays a still image on the TV screen.

20. TRACKING/SET + / – buttons - During playback, they
are used to adjust tracking manually. Used to set or
adjust in the menu mode.

21. ENTER button - Used to enter the information in
the menu mode.

22. AUTO TRACKING buttons - Allows automatic ad­justment of tracking to minimize picture noise during
playback.

23. CANCEL button - Used to clear the selected timer
recording program.

FLUORESCENT DISPLAY

One-touch Timer

Recording

Timer Record

Tape Speed

OTR

SLP

24. ZERO RETURN button - Used to stop the tape
when the counter reaches "00:00:00".

25. AUDIO SELECT button - Switches sound between
mono and stereo, and SAP when receiving broad­casts in stereo or SAP.

26. INPUT SELECT button - Switches the program for
viewing between the VCR and external input sources.

27. CALL button - Displays the present time/day of the
week, channel, counter, speed selection and VCR
mode on the TV screen.

28. SPEED (SP/SLP) selector button - Sets the tape
speed for recording.

29. AUDIO(L/R)/VIDEO OUT Jacks - Use to output audio
and video signal to a TV, amplifier or VCR.

30. UHF/VHF IN (ANT) Jack - Connect a UHF/VHF
antenna or CATV cable to this jack.

31. UHF/VHF OUT (TV) Jack - Use to output UHF/VHF
or CATV signal to a TV.

32. 3/4 Channel Selector Switch - Selects the channel
through which the VCR outputs its signal to a TV.

33. AC Power Cord - Connect to a 120V 60Hz outlet.

POWER indicator

VCR

VCR
ATR
APM

ATR (Auto Tracking)
AM/PM

4E40401A E P08-13 4/1/01, 5:03 PM9

Multi-Function Display

9
