User’s Guide
Orb Speaker System
MSS4001
Before operating this product,
please read these instructions completely.
1
SAFETY PRECAUTIONS
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER (OR BACK). NO USERSERVICEABLE PARTS INSIDE. REFER SERVICING TO
QUALIFIED SERVICE PERSONNEL.
This Caution Marking is located at the bottom enclosure of the unit.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
DANGEROUS VOL
TAGE:
The lightning flash with arrowhead symbol within an
equilateral triangle is intended to alert the user to the
presence of uninsulated dangerous voltage within the
product’s enclosure that may be of sufficient magnitude to
constitute a risk of electric shock to persons.
ATTENTION:
The exclamation point within an equilateral triangle is
intended to alert the user to the presence of important
operating and maintenance (servicing) instructions in the
literature accompanying the appliance.
FCC WARNING:
This equipment may generate or use radio frequency energy.
Changes or modifications to this equipment may cause harmful
interference unless the modifications are expressly approved in the
instruction manual. The user could lose the authority to operate this
equipment if an unauthorized change or modification is made.
ATTENTION:
POUR ÉVITER LES CHOC ÉLECTRIQUES, INTRODUIRE LA LAME LA
PLUS LARGE DE LA FICHE DANS LA BORNE CORRESPONDANTE DE
LA PRISES ET POUSSER JUSQU’AU FOND.
INFORMATION:
This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the
following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
2
SAFETY PRECAUTIONS
WARNING: TO PREVENT FIRE OR SHOCK
HAZARD, DO NOT EXPOSE THIS UNIT TO RAIN
OR MOISTURE.
SURGE PROTECTORS:
It is recommended to use a surge protector for AC connection.
Lightning and power surges ARE NOT covered under warranty
for this product.
This Class B digital apparatus complies with Canadian
ICES-003.
Cet appareil numérique de la classe B est conforme à la
norme NMB-003 du Canada.
3
LOCATION OF CONTROLS
1. Left Speaker with Interchangeable Speaker Rings
2. Speaker Stand
3. Power/Volume Control
4. Right Speaker with Interchangeable Speaker Rings
5. Power Indicator
1. LINE IN Jack
2. DC IN Jack
3. L (Left) Audio Out Jack
4. Audio In Jack
5. Battery Compartment (Bottom of Right Speaker)
FRONT
REAR
4
USING AN ADAPTER (INCLUDED)
1. Plug the small end of the AC adapter into the DC
IN jack on the rear of the right speaker.
2. Connect the other end (with two blades) into an
AC outlet having 120V, 60Hz AC only.
NOTES:
• Only use the supplied AC adapter which has the
following specs: DC 9V, 800mA
z.
• The batteries are automatically disconnected when the AC adapter is used.
CAUTION: When not using AC power, disconnect the AC adapter from the
wall outlet by pulling the plug (not the cord). Do not touch the AC adapter
with wet hands. Fully insert the plug without exposing any part of the blade.
BATTERY INSTALLATION
To use this unit with battery power, remove the battery door on the bottom of the
right speaker by pressing on the tab and then lifting the battery door up. Insert four
(4) ‘AA’ size batteries following the illustration below.
NOTE: The AC power cord must be disconnected from the DC IN jack on the rear
of the right speaker in order for the unit to operate on battery power.
POWER SOURCE
–
+
–
+
–
+
–
+
BATTERY PRECAUTIONS
Follow these precautions when using batteries in this device:
1. Use only the size and type of batteries specified.
2. Be sure to follow the correct polarity when installing the batteries as indicated in the
battery compartment. Reversed batteries may cause damage to the device.
3. Do not mix different types of batteries together (e.g. Alkaline, Rechargeable and Carbonzinc) or old batteries with fresh ones.
4. If the device is not to be used for a long period of time, remove the batteries to prevent
damage or injury from possible battery leakage.
5. Do not try to recharge batteries not intended to be recharged; they can overheat and
rupture. (Follow battery manufacturer
’s directions.)
Right Speaker
Front Side
5
OPERATION
Plug the unit in or insert batteries as described on page 4. Place each
speaker on the Speaker stand, if desired.
–
+
–
+
–
+
–
+
1
Insert one side of the audio cable's plug into the L (Left) Audio Out Jack
on the Right speaker and the other side into the Audio In Jack on the left
speaker.
2
Connect the other audio cable’s
plug into the LINE IN jack on the
Right speaker and the other end
into a LINE OUT jack on an
external unit.
3
Turn on the external unit. Rotate the
Power/Volume control clockwise until a
click is heard to turn the speakers on;
the Power indicator will light. Rotate to
adjust the volume as desired. Rotate
counterclockwise until a click is heard
to turn the speakers off.
All other functions can be performed
directly on the external unit.
4
6
CHANGING THE SPEAKER RINGS
Four Speaker Rings are included and can be changed as follows:
To remove speaker ring, push in
on the speaker ring, then rotate it
counter-clockwise.
1
Gently pull the speaker ring out.
2
To replace, position the tabs of the
speaker ring onto the speaker as
shown.
3
Rotate the speaker ring clockwise
until it is locked into place
4
7
SPECIFICATIONS
GENERAL:
Power requirements.....DC 6V (4 x 1.5 "AA" size batteries),
...............................Alkaline is recommended for longer life
......................................DC IN 9V adapter (center positive)
Speaker. .............................................................2 x 4 Ohms
Output Power .......................................................... 2 x 3W
FOR ADDITIONAL SET-UP OR OPERATING ASSISTANCE,
PLEASE VISIT OUR WEBSITE AT:
WWW.MEMOREXELECTRONICS.COM
OR CONTACT CUSTOMER SERVICE AT (954) 660-7100.
PLEASE KEEP ALL PACKAGING MATERIAL FOR AT LEAST 90
DAYS IN CASE YOU NEED TO RETURN THIS PRODUCT TO YOUR
PLACE OF PURCHASE OR MEMOREX.
FOR PARTS AND ACCESSORIES, CONTACT FOX
INTERNATIONAL AT 1-800-321-6993.
