Memorex MPH6929 User Manual
PRECAUTIONS
Before you read anything else, please observe the following:
Warning!
The manufacturer DOES NOT represent this unit to be waterproof. To reduce the risk of fire, electrical shock, or
damage to the unit, DO NOT expose this to rain or moisture.
Rechargeable Nickel-Cadmium Battery Warning
& This equipment contains a rechargeable nickel-cadmium battery.
& Cadmium is a chemical known to the State of California to cause cancer.
& The rechargeable nickel-cadmium battery contained in this equipment may explode if disposed of in a fire.
& Do not short-circuit the battery.
& Do not charge the rechargeable nickel-cadmium battery used in this equipment in any charger other than the
one designed to charge this battery as specified in the owner's manual. Using another charge may damage the
battery or cause the battery to explode.
RECHARGEABLE NICKEL-CADMIUM BATTERIES MUST BE RECYCLED OR
DISPOSED OF PROPERLY
May be covered under one or more of the following U.S. patents:
4,511,761 4,523,058 4,595,795 4,797,916 5,381,460 5,426,690
5,434,905 5,491,745 5,533,010 5,574,727 5,650,790 5,650,269
5,661,780 5,663,981 5,671,248 5,717,312 5754,407 5,768,345
5,787,356 5,838,721 5,864,619 5,893,034 5,912,968 5,915,227
5,929,598 5,930,720 5,960,358 5987,330
©2000 Memorex is a registered trademark of Memorex Telex N.V.
All rights reserved. Printed in China UCZZ01237BC
Color profile: Disabled
Composite Default screen
Fold out the back cover of
this owner’s manual to use
the handy “Controls and
Functions” page
for reference.
CONTENTS
CONTENTS
Precautions!
Controls and Functions
Important Safety Instructions
Introduction
Welcome
•
Features
•
Included in Your Package
•
Important Electrical Considerations
•
Installing and Adjusting Your Phone
Installation Considerations
•
Adapter Safety Features
•
Desk/Tabletop Installation
•
Wall Installation
•
Installing the Handset Battery Pack
•
Charging the Battery Pack
•
Cleaning the Battery Contacts
•
Page
•
Setting the Pulse/Tone Switch
•
Adjusting the Ringer Controls
•
Automatic Digital Code Security
•
Using Your New Phone
Making and Receiving Calls............................................16
•
Flash and Call Waiting................................................16
•
Storing a Phone Number in Memory ....................................17
•
Dialing a STORED Number ............................................17
•
Chain Dialing .......................................................18
•
Erasing a Stored Number from Memory..................................18
•
• Redial .............................................................19
• Tone..............................................................19
•
Traveling Out-of-Range ...............................................19
•
Channel ...........................................................19
•
Using the SpeakerPhone ..............................................19
•
Three-way call ......................................................19
Setting Up the Integrated Answering Device........................20
•
OF YOUR OWNER’S MANUAL
The Integrated Answering Device
•
Features
•
Turning the Answering System On/Off
•
Setting the Clock
•
Setting Your Outgoing Message (Greeting)
•
Selecting the Message RECORD Time
•
Selecting a Pin Code
•
Calling Party Control Feature
•
Setting the Toll Saver Switch
•
Using the Reset Button
Using the Integrated Answering Device
•
Playing Your Messages
•
Repeating a Message
•
Skipping a Message
•
Deleting a Message
•
Memo
•
Recording a Conversation
•
Remote Access Away from Home
•
Remote Room Monitor
Troubleshooting
•
Quick Reference Chart
Specifications
•
General
•
Base
•
Handset
Memorex Limited Warranty
...................................
..........................
.....................................
...................................................
............................................................
............................................................
..............................................................
...........................................................
.............................................................
................................................
............................................................
..............................................................
...........................................................
..............................................
......................................
.............................................
................................................
..............................................
......................................................
.............................................
.........................................
....................................................
.................................................
...........................................
...............................................
................................................
.................................................
..................................................
..................................................
.............................................
................................................
..............................................
................................................
...............................
.....................................
..........................................
..........................................
..........................................
........................................
.......................................
...................................
................................
....................................
..........................................
............................
........................................
.....................................
Back Cover Fold-out
Back Cover Fold-out
16
26
32
35
36
i
1
1
1
2
3
5
5
6
7
8
12
12
13
13
14
14
15
20
20
21
21
22
23
24
24
25
25
26
26
27
28
28
29
29
31
32
35
35
35
F:...MPH6929ENG.VP
Thu Jun 14 15:46:54 2001
Color profile: Disabled
Composite Default screen
IMPORTANT SAFETY INSTRUCTIONS
When using your telephone equipment, these basic safety precautions should always be followed
to reduce the risk of fire, electrical shock, and injury to persons:
1. Read and understand all instructions.
2. Follow all warnings and instructions marked on the product.
3. Unplug this product from the wall outlet before cleaning. Use a dry cloth for cleaning without
liquid or aerosol cleaners.
4. Do not use this product near water; for example, near a bath tub, wash bowl, kitchen sink or
laundry tub, in a wet basement, or near a swimming pool.
5. Do not place this product on an unstable cart, stand, or table. The telephone may fall, causing
serious damage to the unit.
6. Slots and openings in the cabinet and the back or bottom are provided for ventilation. To protect
the product from overheating, these openings must not be blocked or covered. This product
should never be placed near or over a radiator or heat register. This product should not be
placed in a built-in installation unless proper ventilation is provided.
7. This product should be operated only from the type of power source indicated on the marking
label. If you are not sure of the type of power supply to your home, consult your dealer or local
power company.
8. Do not allow anything to rest on the power cord. Do not locate this product where the cord will
be damaged by persons walking on it.
9. Do not overload wall outlets and extension cords, as this can result in the risk of fire or
electrical shock.
10.Never push objects of any kind into this product through cabinet slots, as they may touch
dangerous voltage points or short out parts that could result in a risk of fire or electric shock.
Never spill liquid of any kind on the product.
11. To reduce the risk of electric shock, do not disassemble this product. Take it to qualified service
personnel when service or repair work is required. Opening or removing covers may expose you to
dangerous voltages or other risks. Incorrect reassembly can cause electric shock when the
appliance is subsequently used.
12.Unplug this product from the wall outlet and refer servicing to qualified service personnel under
the following conditions:
A. When the power supply cord is damaged or frayed.
B. If liquid has been spilled into the product.
C. If the product has been exposed to rain or water.
i
F:...MPH6929ENG.VP
Thu Jun 14 15:46:54 2001
Color profile: Disabled
Composite Default screen
D. If the product does not operate normally when following the operating instructions.
(Adjust only those controls that are covered by the operating instructions. Improper
adjustment of other controls may result in damage and will often require extensive repair work
by a qualified technician.)
E. If the product has been dropped or the cabinet has been damaged.
F. If the product exhibits a distinct change in performance.
13.Do not use the telephone to report a gas leak in the vicinity of the leak.
Additional Battery Safety Precautions
▼
Caution! To reduce the risk of fire or injury to persons by the battery, read and follow these
instructions:
1. Use only the appropriate type and size battery pack specified in the reference guide.
2. Do not dispose of the battery pack in a fire. The cell may explode.
3. Do not open or mutilate the battery pack. Released electrolyte is corrosive and may cause
damage to the eyes or skin. It may be toxic if swallowed.
4. Exercise care in handling the battery in order not to short the battery with conducting materials
such as rings, bracelets, and keys. The battery or conductor may overheat and cause burns.
5. Charge the battery pack provided with or identified for use with this product only in accordance with the
instructions and limitations specified in the reference guide provided for this product.
6. Observe proper polarity orientation between the battery pack and battery charger.
▼
Cordless Telephone Privacy
Note! Cordless telephones are radio devices. Communications between the handset and
base of your cordless telephone are accomplished by means of radio waves which are broadcast
over the open airways. Because of the inherent physical properties of radio waves, your
communications can be received by radio receiving devices other than your own cordless
telephone unit. Consequently, any communications using your cordless telephone may not be
private.
F:...MPH6929ENG.VP
Thu Jun 14 15:46:54 2001
ii
Color profile: Disabled
Composite Default screen
WELCOME
Congratulations on your purchase of the Memorex MPH6929 cordless
telephone and answering system. This phone is designed and engineered
to exacting standards for reliability, long life, and outstanding
performance.
FEATURES
900 MHz Extended Range Technology
•
Integrated Telephone Answering Device (ITAD)
•
TO YOUR NEW PHONE
10 Number Memory Dialing
•
3 Instant Dial Priority Keys
•
32 Digit Redial
•
Flash and Pause
•
• Pulse/Tone Dialing
• Page/Find
• 7 Hour Talk Time
• Handset Earpiece and Ringer Volume Control
• Hearing Aid Compatible
The MPH6929 features include Instant Talk and Auto Disconnect. Instant Talk
allows you to answer a call by just removing the handset from the base so you
don’t have to waste time pushing buttons or flipping switches. Auto Disconnect
allows you to hang up by simply returning the handset to the base.
The Mega Clear Plus true compander circuitry virtually eliminates
background noise. This innovative technology, together with 40 different
channels, provides you with the best possible reception during all your
conversations.
To protect you against misbilled calls which might result from your phone
being activated by other equipment, the MPH6929 has a digital security
system which automatically selects one of over 65,000 digital security codes
for the handset and base. Also, the MegaSecure feature electronically locks
your phone when the handset is in the base.
To get the most from your phone, please read this owner’s manual thoroughly.
Also, be sure to complete the product registration form and mail it in.
Memorex® is a registered trademark of the Memorex Telex N.V.
INTRODUCTION
1
F:...MPH6929ENG.VP
Thu Jun 14 15:46:55 2001
Color profile: Disabled
Composite Default screen
To get the most from your
phone, please read this
owner’s manual thoroughly.
Also be sure to complete
and mail the product
registration form.
INTRODUCTION
INCLUDED IN YOUR PACKAGE
Handset
Rechargeable Battery
(Located inside handset)
Also included:
•
This Owner’s Manual
Base
Wall Mount Adapter
AC Adapter
Telephone Cord
F:...MPH6929ENG.VP
Thu Jun 14 15:47:00 2001
2
Color profile: Disabled
Composite Default screen
WARNING
Please do not attempt
to unplug any
appliance during an
electrical storm.
IMPORTANT ELECTRICAL CONSIDERATIONS
Unplug all electrical appliances when you know an electrical storm is
approaching. Lightning can pass through your household wiring and
damage any device connected to it. This phone is no exception.
The FCC Wants You To Know
Changes or modifications to this product not expressly approved by the
manufacturer, or operation of this product in any way other than as
detailed by the reference guide, could void your authority to operate
this product. The equipment cannot be used on public coin phone
service provided by the telephone company. Connection to party line
service is subject to state tariffs. (Contact the state public utility
commission, public service commission or corporation commission
for information.)
Range
Your new phone is designed to achieve the maximum possible range by
transmitting and receiving according to the highest specifications set
forth by the FCC. We have rated this phone to operate at a maximum
distance with the qualification that the range depends upon the
environment in which the telephone is used. Many factors limit range,
and it would be impossible to include all the variables in our rating.
The Maximum Range rating of this phone is meant to be used as a
means of comparison against other range claims.
Telephone Line Problems
The FCC has granted the telephone company the right to disconnect
service in the event that your phone causes problems on the telephone
line. Also, the telephone company may make changes in facilities and
services which may affect the operation of your unit. However, your
telephone company must give adequate notice in writing prior to such
actions to allow you time for making necessary arrangements to
continue uninterrupted service.
If you are having trouble with your telephone service, you must first
disconnect your phone to determine if it is the cause of your problem.
If you determine that it is the cause, you must leave it disconnected
until the trouble has been corrected.
3
F:...MPH6929ENG.VP
Thu Jun 14 15:47:01 2001
Color profile: Disabled
Composite Default screen
INTRODUCTION
Radio Interference
Radio interference may occasionally cause buzzing and humming in
your cordless handset, or clicking noises in the base. This interference
is caused by an external source such as a TV, refrigerator, vacuum
cleaner, fluorescent lighting, or electrical storm. Your unit is NOT
DEFECTIVE. If these noises continue and are too distracting, please
check around your home to see what appliances may be causing the
problem. In addition, we recommend that the base not be plugged into
a circuit that also powers a major appliance because of the potential for
interference. Be certain the antenna is kept in the vertical position.
In the unlikely event that you consistently hear other voices or
distracting transmissions on your phone, you may be receiving radio
signals from another cordless telephone or other source of interference.
If you cannot eliminate this type of interference, you need to change to
a different channel.
Finally, it should be noted that some cordless telephones operate at
frequencies that may cause interference to nearby TVs and VCRs. To
minimize or prevent such interference, the base of the cordless
telephone should not be placed near or on top of a TV or VCR. If
interference is experienced, moving the cordless telephone farther
away from the TV or VCR will often reduce or eliminate
the interference.
More Than One Cordless Telephone
If you want to use more than one cordless telephone in your home,
they must operate on different channels. Press the channel key to select
a channel that provides the clearest communication.
F:...MPH6929ENG.VP
Thu Jun 14 15:47:01 2001
4
Color profile: Disabled
Composite Default screen
INSTALLATION CONSIDERATIONS
Selecting a Location
Before choosing a location for your new phone, there are some
important guidelines you should consider:
The location should be close to both a phone jack and continuous
•
power outlet. (A continuous power outlet is an AC outlet which
does not have a switch to interrupt its power.)
Keep the base and handset away from
•
sources of electrical noise such as motors
or fluorescent lighting.
Be sure there is sufficient space to fully
•
extend the base antenna.
The base can be placed on a desk or
•
tabletop or mounted on a standard AT&T
or GTE wall plate.
• You should charge your new phone for 15-
20 hours before completing the installation or using the handset.
Telephone Line Outlets
There are two types of phone outlets:
▼
Modular Jack
Most phone equipment available now uses modular jacks. Phone cords
are fitted with a molded plastic connector which plugs into this type of
jack. If you do not have modular phone jacks, contact your local
AND ADJUSTING YOUR PHONE
telephone company for information about their installation.
▼
Hardwired Jack
Some equipment is wired directly to a phone jack, and these types of
installations require a modular jack converter. This type of installation
is not difficult; however, you should contact your local telephone
dealer or a telephone supply store for advice about the proper adapter
or converter for your particular situation.
INSTALLING
5
F:...MPH6929ENG.VP
Thu Jun 14 15:47:01 2001
Color profile: Disabled
Composite Default screen
Connecting the Telephone Cords
Consider these safety guidelines before connecting the telephone cords:
Place the power cord so
that it does not create a
trip hazard or where it
could become chafed and
create an electrical hazard
or fire.
Before using your phone,
fully charge the NickelCadmium battery pack for
15-20 hours.
Caution!
Never install telephone wiring during a lightning storm.
•
Never touch uninsulated telephone wires or terminals unless the
•
telephone line has been disconnected.
Use caution when installing or modifying telephone lines.
•
Applying Power to the Base
This phone requires an AC outlet, without a switch to interrupt power,
and the included AC adapter. To relieve strain on the DC plug when the
phone is placed on a desk or table, wrap the power cord around the
strain relief notch on the bottom of the base.
ADAPTER SAFETY FEATURES
If the AC adapter furnished with this phone has a polarized line plug (a
plug having one blade wider than the other), this plug will fit into the
power outlet only one way. If you are unable to insert the plug fully into
the outlet, try reversing the plug.
Do not alter the shape of the blades of the polarized plug!
NOTE: If you cannot plug the
AC adapter into the outlet,
contact someone about
replacing the outlet.
INSTALLING AND ADJUSTING
F:...MPH6929ENG.VP
Thu Jun 14 15:47:03 2001
Plug the AC Adapter into a
standard 120 V AC wall outlet.
Do not use an outlet controlled
by a wall switch. Use only the
AC Adapter supplied with
this phone.
AC
ADAPTER
Wide
Blade
6
Color profile: Disabled
Composite Default screen
Before choosing a location
for your phone, read the
“Installation Considerations”
included in the “Precautions
and Important Safety
Instructions” brochure.
Installingand Adjusting YourPhone
DESK/TABLETOP INSTALLATION
1) Plug the AC adapter cord into the9VDCinputjack on the back of
the base.
2) Wrap the AC adapter cord around the strain relief notch.
Place the power cord so that it does not create a trip
hazard or where it could become chafed and create a fire
or electrical hazard.
3) Plug the AC adapter into a standard 120 V AC wall outlet.
Use only the supplied AC adapter supplied with this phone
and DO NOT use an outlet controlled by a wall switch.
4) Charge the battery (refer to “Charging the Battery Pack,” page 12).
5) Plug one end of the telephone cord into the
TEL LINE jack on the
back of the base.
6) Plug the other end of the cord into your telephone jack on the wall.
7
F:...MPH6929ENG.VP
Thu Jun 14 15:47:05 2001
Color profile: Disabled
Composite Default screen
Before using your phone,
fully charge the NickelCadmium battery pack for
15-20 hours.
Place the power cord so
that it does not create a
trip hazard or where it
could become chafed and
create a fire or electrical
hazard.
7) Set the base on a desk or tabletop, and
place the handset into the base
as shown. Then, raise the antenna
to a vertical position.
WALL INSTALLATION
Standard wall plate mounting
▼
This phone can be mounted on any standard AT&T or GTE wall plate.
1) Slide the wall mount adapter into
the notches at the top of the base.
2) Rotate the wall mount adapter
down and snap it into place at the
bottom of the base.
INSTALLING AND ADJUSTING
F:...MPH6929ENG.VP
Thu Jun 14 15:47:10 2001
3) Plug the AC adapter into the base.
4) Put the AC adapter cord inside the
molded wiring channel, then
wrap it around the strain relief
notch. Plug the AC adapter into a
standard 120 V AC wall outlet.
8
Loading...
