Memorex MM1740 User Manual

User's Manual

17” LCD MONITOR

Please read the user’s manual carefully before using the monitor

TABLE OF CONTENTS

FOR YOUR SAFETY---------------------------------------------- 1

SAFETY PRECAUTIONS -------------------------------------- 2 SPECIAL NOTES ON LCD MONITORS -------------------------- 3

BEFORE YOU OPERATE THE MONITOR ---------------------------- 3

FEATURES -------------------------------------------------- 3 PACKING LIST --------------------------------------------- 4

OPERATING INSTRUCTIONS -------------------------------------- 4

GENERAL INSTRUCTIONS ------------------------------------ 4 HOW TO ADJUST A SETTING---------------------------------- 6 ADJUSTING THE PICTURE ----------------------------------- 7 HOW TO OPTIMIZE THE DOS-MODE ---------------------------- 8 PLUG AND PLAY -------------------------------------------- 9

TECHNICAL SUPPORT(FAQ) ----------------------------------------10

ERROR MESSAGE AND POSSIBLE SOLUTION -------------------- ---11

APPENDIX --------------------------------------------------------12

SPECIFICATIONS------------------------------------------------------------------- -----12 FACTORY PRESET TIMING TABLE---------------------------------14 CONNECTOR PIN ASSIGNMENT ---------------------------------14

Before operating the monitor please read this manual thoroughly. This manunl should be retained for future reference.

FCC Class B Radio Frequency Interference Statement WARNING:(FOR FCC CERTIFIED MODELS) NOTE:This equipment has been tested and found to comply with the limits for a Class B

digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy, and if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

1.Reorient or relocate the receiving antenna.

2.Increase the separation between the equipment and receiver.

3.Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

4.Consult the dealer or an experienced electric technician for help.

NOTICE

1.The changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.

2.The manufacturer is not responsible for any radio or TV interference caused by unauthorized modification to this equipment. It is the responsbilities of the user to correct such interference.

WARNING: To prevent fire or shock hazard, do not expose the monitor to rain or moisture. Dangerously high voltages are present inside the monitor. Do not open the cabinet. Refer servicing to qualified personnel only.

PRECAUTIONS

?? Do not use the monitor near water, or lay it at a moisture place. ?? Openings in the back of the cabinet are provided for ventilation. To ensure reliable

operation of the monitor and to protect it from overheating,be sure these openings are not blocked or covered.

?? The monitor should be operated only from the type of power source indicated on the

label. If you are not sure of the type of power supplied to your home, consult your dealer or local power company.

?? Unplug the unit during a lightning storm or when it will not be used for long periods of

time. This will protect the monitor from damage due to power surges.

?? Do not overload power stripd and extension cords. Overloading can result in fire or

electric shock.

?? Do not attempt to service the monitor yourself,opening or removing covers can expose

you to dangerous voltages and other hazards. Please refer all servicing to qualified service personnel.

?? To ensure satisfactory operation, use the monitor only with UL listed computers which

have appropriate configured receptacles marked between 100-240V AC, Min, 1.0A.

?? The wall socket shall be installed near the equipment and shall be easily accessible.

SPECIAL NOTES ON LCD MONITORS

The following symptoms are normal with LCD monitor and do not indicate a problem.

NOTES

?? Due to the nature of the fluorescent light, the screen may flicker during initial use. Turn

off the Power Switch and then turn it on again to make sure the flicker disappears. Or you can use of AUTO function.

?? You may find slightly uneven brightness on the screen depending on the desktop

pattern you use.

?? The LCD screen has effective pixels of 99.99% or more. It may include blemishes of

0.01% or less such as a missing pixel or a pixel lit all of the time.

?? Due to the nature of the LCD screen, an afterimage of the previous screen may remain

after switching the image,when the same image is displayed for hours. In this case, the screen is recovered slowly by changing the image or turning off the Power Switch for hours.

?? The life of the fluorescent light used in the LCD moniter is approximately 50,000 hours.

Contact your dealer for replacement when the screen is dark, flickeing or not lighting up. Never attempt to replace it by yourself.

BEFORE YOU OPERATE THE MONITOR FEATURES

?? 43.2cm(17?) TFT Color LCD Monitor ?? Crisp, Clear Display for Windows

?? Recommened Resolutions:1280X 1024 @75Hz ?? EPA ENERGY STAR

?? Space Saving, Compact Case Design

CHECKING THE CONTENTS OF THE PACKAGE The product package should include the following items:

1.LCD Monitor 5? Video cable

2.Owner's Manual 6. DVI cable

3.Power Cord 7.Audio cable

4.Adapter 8. warranty card

POWERCORD Power Source:

1.Make sure the power cord is the correct type that required in your area.

2.This LCD monitor has a universal power supply that allows operation in either 100/120V AC or 220/240V AC voltage area(No user adjustment is required.)

3.Connect the AC-power cord into your LCD monitor's External Adapter input socket, and then plug the other end of External adapter to LCD monitor’s DC-power-input. The AC-power cord may be connected to either a wall power outlet or the power outlet socket on your PC, depending on the type of power cord supplied with your LCD monitor.

CONTROLS AND CONNECTORS VIDEO CABLE

Connecting the Video Cable: the LCD monitor comes with a built -in video cable. Plug the signal cable's 15-pin connector into the computer is video port and tighten the two screws on the cable connector. Connecting the Power Cord: Plug the AC-power cord into the External Adapter. Then plug

the DC-jack power cable into DC-IN Inlet. Caution: If the AC outlet is not grounded, install the proper grounding adapter(not supplied).

OPERATING INSTRUCTIONS

GENERAL INSTRUCTIONS

Press the power switch to turn the monitor on or off. The other control knobs are located at front panel of the monitor. By changing these settings, the picture can be adjusted to your personal preferences.

?? The power cord should be connected. ?? Connect the video cable from the monitor to the video card. ?? Press the power switch to turn on the monitor position. The power indicator LED will

light up.
