Memorex MD6440cp User Manual

PERSONAL COMPACT DISC PLAYER WITH 40-SECOND DIGITAL ANTI SKIP PROTECTION

MODEL # MD6440cp

BEFORE OPERATING THIS PRODUCT PLEASE READ THESE INSTRUCTIONS COMPLETELY

OPERATING INSTRUCTIONS

ROHM IC MANUAL COVER

TABLE OF CONTENTS

WARNING AND PRECAUTIONS............................................................................................................. P.1

LOCATION OF CONTROLS & POWER SOURCES ................................................................................P.2

POWER SOURCES ................................................................................................................................... P.3

HEADPHONE AND HI-FI CONNECTION ................................................................................................ P.3

CAR KIT OPERATIONS ............................................................................................................................ P.4

PLAYING A CD IMMEDIATELY................................................................................................................ P.5

CD PLAYBACK .......................................................................................................................................... P.6

LOCATING A PARTICULAR TRACK OR POINT OF THE TRACK .......................................................... P.6

REPEAT PLAYBACK & RANDOM PLAY ( SHUFFLE )............................................................................ P.6

INTRO & SPECIAL FUNCTIONS ............................................................................................................. P.7

PROGRAMMED PLAY .............................................................................................................................. P.8

MAINTENANCE........................................................................................................................................ P.9

PRODUCT SPECIFICATIONS ................................................................................................................... P.10

GENERAL INFORMATION....................................................................................................................... P.11

LIMITED WARRANTY .............................................................................................................................. P.12

WARNINGS

TO REVENT FIRE OR SHOCK HAZARDS, DO NOT EXPOSE THIS UNIT TO RAIN OR MOISTURE.

This symbol is intended to alert the user to the presence of uninsulated "dangerous voltage" within the products enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons.

This symbol is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance.

This product utilizes a Class 1 laser to read Compact Discs. This laser Compact Disc Player is equipped with safety switches to avoid exposure when the CD door is open and the safety interlocks are defeated. Invisible laser radiation is present when the CD Player's lid is open and the system's interlock has failed or been defeated. It is very important that you avoid direct exposure to the laser beam at all times. Please do

not attempt to defeat or bypass the safety switches.

Any use of the controls or an adjustment to the procedures other than those specified herein may result in hazardous radiation.

TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). THERE ARE NO USERSERVICEABLE PARTS INSIDE. PLEASE REFER ANY SERVICING TO QUALIFIED SERVICE PERSONNEL.

PRECAUTIONS

• Do not open the CD compartment while the CD is rotating.

• Always keep the CD compartment closed when not in use.

• Keep all foreign objects out of the CD compartment.

• If TV or radio interference occurs during operation, move the unit to a different location within the room or building.

• Place the unit on a stable surface. A vibration or shock to the unit can cause the CD mechanism to mistrack or skip. If operating the unit under circumstances which may subject the unit to these conditions, utilize the digital Anti-shock, See page 11.

• Playing some CD's at high volume can cause vibration leading to mistracking. In this case, lower the volume or relocate the speakers further away from the unit.

• Avoid installing the unit in the locations described below:

• Where it will be in direct contact with water.

• Where it will be in direct contact with a magnet.

• Places exposed to direct sunlight or close to heat radiating appliances such as electric heaters.

• On top of stereo equipment that radiates too much heat.

• Places lacking ventilation or dusty places.

• Places subject to constant vibration.

• Humid or moist places.

- 1 -

LOCATION OF CONTROLSS

ANTI-SHOCK BUTTON

CD DOOR

DOOR OPEN BUTTON

MODE BUTTON

PROGRAMMED BUTTON

STOP BUTTON

DBBS ( BASS BOOST ) SWITCH

VOLUME CONTROL KNOB

POWER SOURCES

PLAY / PAUSE BUTTON

DISPLAY WINDOW

SKIP / SEARCH BUTTONS

DC JACK

HOLD SWITCH

LINE OUT JACK

HEADPHONES JACK

Using Battery

1. Open the lid of the battery compartment.

2. Insert 2 "AA" Size (UM-3) batteries by matching the ( + and - ) to the diagram inside the battery compartment and close the lid.

Step 3Step 2Step 1

Note: For battery operation the AC power adaptor must be disconnected from DC IN jack.

When to Change the Battery

When the battery is used up, " " indicator flashes in the LCD display. Replace all the batteries with new batteries.

- 2 -

Using on the AC Power Adaptor

Use only the supplied AC power adaptor.

HEADPHONE AND HI-FI CONNECTION

DC 6V

to a wall outlet

120V / 60Hz

AC Power

Adaptor

Listening with the Headphones

Connect the plug of the stereo headphones (included) or earphones (not included) into the PHONES (GREEN) socket. Caution: Avoid excessive volume levels and listening to sound for a long period of time when using headphones, as this may impair your hearing.

Connecting to component audio systems

Connect the patch cord ( Not Included ) into the LINE OUT ( BLACK ) socket of the unit and the CD / AUX inputs of an audio system. Note: Always switch the power off before making any connections between the player and another

unit.

- 3 -

CAR KIT OPERATIONS

The cassette adaptor allows you to use your portable CD player with your car stereo cassette system or protable audio cassette system.

1. Position the cassette adaptor cord so the cord extends out from the cassette player when the

cassette is inserted. Insert the cassette adaptor in the same direction as you would insert an audio cassette tape.

2. If the cassette adaptor cord is on the wrong side of the tape,

reposition the cord to the opposite corner of the channel.

3. Insert the cassette adaptor stereo plug into the headphones jack

on the left side of the CD player.

4. Turn on the cassette player. Press PLAY on the cassette player.

5. Press PLAY on the CD player.

6. Set the volume of the CD player to a mid-level. Adjust the

volume of the cassette player.

Notes: • The cassette adaptor has the play head on one

side only. If you insert the cassette and no sound is heard, try turning the cassette over or pressing the reverse button to change direction.

• The car cassette adaptor may not be

compatible with all makes and models of cassette players.

Use the Cigarette Lighter Adaptor for power when using the CD player in a car.

1. Plug the adaptor into the car cigarette lighter.

2. Plug the pin into the DC jack on the unit.

Notes: The supplied DC car adaptor / cord is designed for use with vehicles equipped with a 12 volt

negative ground electrical system only.

To Cassette Deck

To Headphones Jack

To Cigarette Lighter

- 4 -

To DC Jack
