Memorex MC7100 User Manual

MC7100

Suffix A

User’s Guide

CD Clock Radio with

Dual Alarm and

Detachable Speaker

Before operating this product,

please read these instructions completely.

SAFETY PRECAUTIONS

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE

COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SER­VICING TO QUALIFIED SERVICE PERSONNEL.

The lightning flash with arrowhead symbol within an equilat­eral triangle is intended to alert the user to the presence of
uninsulated ‘dangerous voltage’ within the product’s enclo­sure that may be of sufficient magnitude to constitute a risk
of electric shock to persons.

The exclamation point within an equilateral triangle is intend­ed to alert the user to the presence of important operating
and maintenance (servicing) instructions in the literature
accompanying the appliance.

Invisible and hazardous laser radiation when open and inter­lock failed or defeated. Avoid direct exposure to beam.

FCC WARNING:

This equipment may generate or use radio frequency energy. Changes
or modifications to this equipment may cause harmful interference
unless the modifications are expressly approved in the instruction man­ual. The user could lose the authority to operate this equipment if an
unauthorized change or modification is made.

LASER SAFETY: This unit employs a laser. Only qualified service per­sonnel should attempt to service this device due to possible eye injury.

CAUTION: USE OF CONTROLS, ADJUSTMENTS OR PERFOR­MANCE PROCEDURE HEREIN MAY RESULT IN HAZARDOUS
RADIATION EXPOSURE.

PLEASE KEEP ALL PACKAGING MATERIAL FOR AT LEAST 90 DAYS IN
CASE YOU NEED TO RETURN THIS PRODUCT TO YOUR PLACE OF PUR­CHASE OR MEMOREX.

1

PORTABLE CART WARNING

(symbol provided by RETAC)

INFORMATION:

This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential installa­tion. This equipment generates, uses and can radiate radio frequency energy and, if
not installed and used in accordance with instructions, may cause harmful interfer­ence to radio communications. However, there is no guarantee that interference will
not occur in a particular installation. If this equipment does cause harmful interfer­ence to radio or television reception, which can be determined by turning the equip­ment off and on, the user is encouraged to try to correct the interference by one or
more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

IMPORTANT SAFETY INSTRUCTIONS

Before using the unit, be sure to read all operat­ing instructions carefully. Please note that these
are general precautions and may not pertain to
your unit. For example, this unit may not have
the capability to be connected to an outdoor
antenna.

1. READ INSTRUCTIONS

All the safety and operating instructions should be
read before the product is operated.

2. RETAIN INSTRUCTIONS

The safety and operating instructions should be
retained for future reference.

3. HEED WARNINGS

All warnings on the product and in the operating
instructions should be adhered to.

4. FOLLOW INSTRUCTIONS

All operating and use instructions should be fol­lowed.

5. CLEANING

Unplug this product from the wall outlet before
cleaning. Do not use liquid cleaners or aerosol
cleaners. Use a dry cloth for cleaning.

6. ATTACHMENTS

Do not use attachments not recommended by
the product's manufacturer as they may cause
hazards.

7. WATER AND MOISTURE

Do not use this product near water–for example:
near a bathtub, washbowl, kitchen sink or laun­dry tub; in a wet basement; or near a swimming
pool.

8. ACCESSORIES

Do not place this product on an unstable cart,
stand, tripod, bracket or table. The product may
fall, causing serious injury and serious damage
to the product. Use only with a cart, stand, tripod,
bracket or table recommended by the manufac­turer or sold with the product. Any mounting of
the product should follow the manufacturer’s
instructions, and should use a mounting acces­sory recommended by the manufacturer.

8A. An appliance and cart combination

should be moved with care. Quick
stops, excessive force and uneven
surfaces may cause the appliance
and cart combination to overturn.

9. VENTILATION

Slots and openings in the cabinet and in the back
or bottom are provided for ventilation, to ensure
reliable operation of the product and to protect it
from overheating. These openings must not be
blocked or covered. The openings should never
be blocked by placing the product on a bed, sofa,
rug or other similar surface. This product should
never be placed near or over a radiator or heat
source. This product should not be placed in a
built-in installation such as a bookcase or rack
unless proper ventilation is provided or the man­ufacturer's instructions have been adhered to.

10. POWER SOURCES

This product should be operated only from the
type of power source indicated on the marking

2

IMPORTANT SAFETY INSTRUCTIONS (CONTINUED)

label. If you are not sure of the type of power
supply to your home, consult your appliance
dealer or local power company. For products
intended to operate from battery power
sources, refer to the operating instructions.

11. GROUNDING OR POLARIZATION

This product is equipped with a polarized alter­nating-current line plug (a plug having one blade
wider than the other). This plug will fit into the
power outlet only one way. This is a safety fea­ture. If you are unable to insert the plug fully into
the outlet, try reversing the plug. If the plug
should still fail to fit, contact your electrician to
replace your obsolete outlet. Do not defeat the
safety purpose of the polarized plug.

12. POWER-CORD PROTECTION

Power-supply cords should be routed so that
they are not likely to be walked on or pinched by
items placed upon or against them, paying partic­ular attention to cords at plugs, convenience
receptacles, and the point where they exit from
the appliance.

13. LIGHTNING

To protect your product from a lightning storm, or
when it is left unattended and unused for long
periods of time, unplug it from the wall outlet and
disconnect the antenna or cable system. This will
prevent damage to the product due to lightning
and power-line surges.

14. POWER LINES

An outside antenna system should not be locat­ed in the vicinity of overhead power lines or other
electric light or power circuits, or where it can fall
into such power lines or circuits. When installing
an outside antenna system, extreme care should
be taken to keep from touching such power lines
or circuits as contact with them might be fatal.

15. OVERLOADING

Do not overload wall outlets and extension cords
as this can result in a risk of fire or electric shock.

16. OBJECT AND LIQUID ENTRY

Never push objects of any kind into this product
through openings as they may touch dangerous
voltage points or short out parts that could result in
fire or electric shock. Never spill or spray any type
of liquid on the product.

17. SERVICING

Do not attempt to service this product yourself as
opening or removing covers may expose you to
dangerous voltage or other hazards. Refer all
servicing to qualified service personnel.

18. REPLACEMENT PARTS

When replacement parts are required, be sure

, or other

the service technician uses replacement parts
specified by the manufacturer or those that have
the same characteristics as the original part.
Unauthorized substitutions may result in fire,
electric shock or other hazards.

19. SAFETY CHECK

Upon completion of any service or repairs to this
product, ask the service technician to perform
safety checks to determine that the product is in
proper operating condition.

20. WALL OR CEILING MOUNTING

The product should be mounted to a wall or ceil­ing only as recommended by the manufacturer.

21. DAMAGE REQUIRING SERVICE

Unplug the product from the wall outlet and refer
servicing to qualified service personnel under the
following conditions:

a. When the power-supply cord or plug is dam-

aged.

b. If liquid has been spilled or objects have fallen

into the product.
c. If the product has been exposed to rain or water.
d. If the product does not operate normally by fol-

lowing the operating instructions. Adjust only

those controls that are covered by the operating

instructions, as an adjustment of other controls

may result in damage and will often require

extensive work by a qualified technician to

restore the product to its normal operation.
e. If the product has been dropped or the cabinet

has been damaged.

f. When the product exhibits a distinct change in

performance–this indicates a need for service.

22. HEAT

The product should be situated away from heat

sources such as radiators, heat registers, stoves

or other products (including amplifiers) that pro-

duce heat.

23. NOTE TO CATV SYSTEM INSTALLER

This reminder is provided to call the CATV sys-

tem installer's attention to Article 820-40 of the

NEC that provides guidelines for proper ground-

ing and, in particular, specifies that the cable

ground shall be connected to the grounding sys-

tem of the building, as close to the point of cable

entry as practical.

24. NONUSE PERIODS

The power cord of the appliance should be

unplugged from the outlet when left unused for a

long period of time.

3

Dear Customer:

A

S

S

O

C

I

A

T

I

O

N

EST. 1924

E

L

E

C

T

R

O

N

I

C

I

N

D

U

S

T

R

I

E

S

EIA

We

LISTENING

For A Lifetime

Want You

Selecting fine audio equipment such as the unit you’ve just purchased is only the start of your
musical enjoyment. Now it’s time to consider how you can maximize the fun and excitement
your equipment offers. This manufacturer and the Electronic Industries Association’s
Consumer Electronics Group want you to get the most out of your equipment by playing it at a
safe level. One that lets the sound come through loud and clear without annoying blaring or
distortion—and, most importantly, without affecting your sensitive hearing.
Sound can be deceiving. Over time your hearing “comfort level” adapts to higher volumes of
sound. So what sounds “normal” can actually be loud and harmful to your hearing. Guard
against this by setting your equipment at a safe level BEFORE your hearing adapts.

To establish a safe level:

• Start your volume control at a low setting.

• Slowly increase the sound until you can hear it comfortably and clearly, and without distortion.

Once you have established a comfortable sound level:

• Set the dial and leave it there.

Taking a minute to do this now will help to prevent hearing damage or loss in the future. After
all, we want you listening for a lifetime.

We Want You Listening For A Lifetime

Used wisely, your new sound equipment will provide a lifetime of fun and enjoyment. Since hear­ing damage from loud noise is often undetectable until it is too late, this manufacturer and the
Electronic Industries Association’s Consumer Electronics Group recommend you avoid pro­longed exposure to excessive noise. This list of sound levels is included for your protection.

Decibel

Level Example

30 Quiet library, soft whispers
40 Living room, refrigerator, bedroom away from traffic
50 Light traffic, normal conversation, quiet office
60 Air conditioner at 20 feet, sewing machine
70 Vacuum cleaner, hair dryer, noisy restaurant
80 Average city traffic, garbage disposals, alarm clock at two feet

THE FOLLOWING NOISES CAN BE DANGEROUS UNDER CONSTANT EXPOSURE:

90 Subway, motorcycle, truck traffic, lawn mower
100 Garbage truck, chain saw, pneumatic drill
120 Rock band concert in front of speakers, thunderclap
140 Gunshot blast, jet engine
180 Rocket launching pad

Information courtesy of the Deafness Research Foundation.

4

LOCATION OF CONTROLS

21234 5 6 7 9 1081 11

13 14 15

2019 21 242318 22

1617

FRONT

REAR

1. Left Detachable
Speaker

2. POWER Button

3. RADIO/BAND Button

4. SNOOZE Button

5. ALARM 1/2 ON/OFF
Button

6. REPEAT/ALARM 1/2
SET Button

7. VOLUME Down Button

8. Display

9. VOLUME Up Button

10. DOOR OPEN Switch

11. Right Speaker

12. Play/Pause
Button

13. PROG./CH SAVE
Button

14. STOP (
Button

15. Tune/Skip/Search/Hr
o Button

16. MODE/CH+/ALARM
SELECT Button

17. Tune/Skip/Search/Min
n Button

18. FM Antenna Wire

19. Stand

20. Battery Compartment

21. DC Jack

22. Left Speaker Jack

23. Left Speaker Wire

24. SNOOZE Button

®p)/CD

(

■)/CLOCK SET

5

INSTALLATION

++

AC ADAPTER CONNECTION

Connect the AC adapter (included) to an AC outlet having 120V, 60Hz AC only.
Plug the small end into the DC jack on the rear of the unit.
CAUTION: Do not touch the AC adapter with wet hands. Fully insert the plug with­out exposing any part of the blade.

DC 6V

INSERTING BATTERIES

Two AAA size batteries can also be used to power and/or to provide a backup for
the clock and alarm time for this unit as follows:

1. Open the battery door by sliding it towards the bottom of the unit.

2. Insert two (2) “AAA” batteries as shown. Alkaline batteries are recommended

3. Slide the battery door back on.
NOTE: The batteries are used to back-up the clock and alarm time only when the
AC adapter is disconnected or if there is a power failure.

Z

for the longest playing time.

BATTERY PRECAUTIONS

Follow these precautions when using batteries in this device:

1. Use only the size and type of batteries specified.

2. Be sure to follow the correct polarity when installing the batteries as indicated in the
battery compartment. Reversed batteries may cause damage to the device.

3. Do not mix different types of batteries together (e.g. Alkaline, Rechargeable and
Carbon-zinc) or old batteries with fresh ones.

4. If the device is not to be used for a long period of time, remove the batteries to pre­vent damage or injury from possible battery leakage.

5. Do not try to recharge batteries not intended to be recharged; they can overheat and
rupture. (Follow battery manufacturer’s directions.)

BACKLIGHT

If the power supply is connected to the DC 6V IN jack, the backlight will always
light on in the display.

6
