Memorex MC2862 User Manual

CD CLOCK RADIO WITH DUAL ALARM

MODEL: MC2862

BEFORE OPERATING THIS PRODUCT, PLEASE READ THESE
INSTRUCTIONS COMPLETELY.

OPERATING INSTRUCTIONS

MC2862 O/M.QXD 9/27/02 10:35 AM Page 19

1

SAFETY PRECAUTIONS

CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE

COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER
SERVICING TO QUALIFIED SERVICE PERSONNEL.

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

The lightning flash with arrowhead symbol, within an
equilateral triangle is intended to alert the user to the
presence of uninsulated ‘dangerous voltage’ within the
product’s enclosure that may be of sufficient magnitude to
constitute a risk of electric shock to persons.

The exclamation point within an equilateral triangle is intended to
alert the user to the presence of important operating and
maintenance (servicing) instructions in
the literature accompanying the appliance.

DANGER:

Invisible and hazardous laser radiation when open and
interlock failed or defeated. Avoid direct exposure to beam.

FCC WARNING:

This equipment may generate or use radio frequency energy. Changes
or modifications to this equipment may cause harmful interference
unless the modifications are expressly approved in the instruction man­ual. The user could lose the authority to operate this equipment if an
unauthorized change or modification is made.

LASER SAFETY: This unit employs a laser. Only qualified service per­sonnel should attempt to service this device due to possible eye injury.

CAUTION: USE OF CONTROLS, ADJUSTMENTS OR PERFOR­MANCE PROCEDURE HEREIN MAY RESULT IN HAZARDOUS
RADIATION EXPOSURE.

PLEASE KEEP ALL PACKAGING MATERIAL FOR AT LEAST 90 DAYS IN
CASE YOU NEED TO RETURN THIS PRODUCT TO YOUR PLACE OF
PURCHASE OR MEMOREX.

MC2862 O/M.QXD 9/27/02 10:35 AM Page 1

Before using the unit, be sure to read all operating
instructions carefully. Please note that these are
general precautions and may not pertain to your
unit. For example, this unit may not have the
capability to be connected to an outdoor antenna.

1. READ INSTRUCTIONS

All the safety and operating instructions should be
read before the product is operated.

2. RETAIN INSTRUCTIONS

The safety and operating instructions should be
retained for future reference.

3. HEED WARNINGS

All warnings on the product and in the operating
instructions should be adhered to.

4. FOLLOW INSTRUCTIONS

All operating and use instructions should be
followed.

5. CLEANING

Unplug this product from the wall outlet before
cleaning. Do not use liquid cleaners or aerosol
cleaners. Use a damp cloth for cleaning.

6. ATTACHMENTS

Do not use attachments not recommended by the
product's manufacturer as they may cause
hazards.

7. WATER AND MOISTURE

Do not use this product near water- for example,
near a bathtub, washbowl, kitchen sink, or
laundry tub, in a wet basement, or near a
swimming pool.

8. ACCESSORIES

Do not place this product on an unstable cart,
stand, tripod, bracket, or table. The product may
fall, causing serious injury and serious damage to
the product. Use only with a cart, stand, tripod,
bracket, or table recommended by the
manufacturer or sold with the product. Any
mounting of the product should follow the
manufacturer’s instructions, and should use a
mounting accessory recommended by the
manufacturer.

8A. An appliance and cart combination

should be moved with care. Quick
stops, excessive force, and uneven
surfaces may cause the appliance
and cart combination to overturn.

9. VENTILATION

Slots and openings in the cabinet and in the back
or bottom are provided for ventilation and to
ensure reliable operation of the product and to
protect it from overheating. These openings must
not be blocked or covered. The openings should
never be blocked by placing the product on a
bed, sofa, rug, or other similar surface. This
product should never be placed near or over a
radiator or heat source. This product should not
be placed in a built-in installation such as a
bookcase or rack unless proper ventilation is
provided or the manufacturer's instructions have
been adhered to.

10. POWER SOURCES

This product should be operated only from the

2

IMPORTANT SAFETY INSTRUCTIONS

INFORMATION

This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential installa­tion. This equipment generates, uses, and can radiate radio frequency energy and,
if not installed and used in accordance with instructions, may cause harmful interfer­ence to radio communications. However, there is no guarantee that interference will
not occur in a particular installation. If this equipment does cause harmful interfer­ence to radio or television reception, which can be determined by turning the equip­ment off and on, the user is encouraged to try to correct the interference by one or
more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

MC2862 O/M.QXD 9/27/02 10:35 AM Page 2

PORTABLE CART WARNING
(symbol provided by RETAC)

type of power source indicated on the marking
label. If you are not sure of the type of power
supply to your home, consult your appliance
dealer or local power company. For products
intended to operate from battery power, or other
sources, refer to the operating instructions.

11. GROUNDING OR POLARIZATION

This product is equipped with a polarized
alternating-current line plug (a plug having one
blade wider than the other). This plug will fit into
the power outlet only one way. This is a safety
feature. If you are unable to insert the plug fully
into the outlet, try reversing the plug. If the plug
should still fail to fit, contact your electrician to
replace your obsolete outlet. Do not defeat the
safety purpose of the polarized plug.

12. POWER-CORD PROTECTION

Power-supply cords should be routed so that they
are not likely to be walked on or pinched by items
placed upon or against them, paying particular
attention to cords at plugs, convenience
receptacles, and the point where they exit from
the appliance.

13. LIGHTNING

To protect your product from a lightning storm, or
when it is left unattended and unused for long
periods of time, unplug it from the wall outlet and
disconnect the antenna or cable system. This will
prevent damage to the product due to lightning
and power-line surges.

14. POWER LINES

An outside antenna system should not be located
in the vicinity of overhead power lines or other
electric light or power circuits, or where it can fall
into such power lines or circuits. When installing
an outside antenna system, extreme care should
be taken to keep from touching such power lines
or circuits as contact with them might be fatal.

15. OVERLOADING

Do not overload wall outlets and extension cords
as this can result in a risk of fire or electric shock.

16. OBJECT AND LIQUID ENTRY

Never push objects of any kind into this product
through openings as they may touch dangerous
voltage points or short out parts that could result in
fire or electric shock. Never spill or spray any type
of liquid on the product.

17. SERVICING

Do not attempt to service this product yourself as
opening or removing covers may expose you to
dangerous voltage or other hazards. Refer all
servicing to qualified service personnel.

18. REPLACEMENT PARTS

When replacement parts are required, be sure
the service technician uses replacement parts
specified by the manufacturer or those that have
the same characteristics as the original part.
Unauthorized substitutions may result in fire,
electric shock or other hazards.

19. SAFETY CHECK

Upon completion of any service or repairs to this
product, ask the service technician to perform
safety checks to determine that the product is in
proper operating condition.

20. WALL OR CEILING MOUNTING

The product should be mounted to a wall or
ceiling only as recommended by the
manufacturer.

21. DAMAGE REQUIRING SERVICE

Unplug the product from the wall outlet and refer
servicing to qualified service personnel under the

following conditions:
a. When the power-supply cord or plug is damaged.
b. If liquid has been spilled, or objects have fallen

into the product.
c. If the product has been exposed to rain or water.
d. If the product does not operate normally by

following the operating instructions. Adjust only

those controls that are covered by the operating

instructions, as an adjustment of other controls

may result in damage and will often require

extensive work by a qualified technician to restore

the product to its normal operation.
e. If the product has been dropped or the cabinet

has been damaged.

f. When the product exhibits a distinct change in

performance - this indicates a need for service.

22. HEAT

The product should be situated away from heat

sources such as radiators, heat registers, stoves,

or other products (including amplifiers) that

produce heat.

23. NOTE TO CATV SYSTEM INSTALLER

This reminder is provided to call the CATV

system installer's attention to Article 820-40 of the

NEC that provides guidelines for proper

grounding and, in particular, specifies that the

cable ground shall be connected to the grounding

system of the building, as close to the point of

cable entry as practical.

24. NONUSE PERIODS

The power cord of the appliance should be

unplugged from the outlet when left unused for a

long period of time.

3

IMPORTANT SAFETY INSTRUCTIONS (CONTINUED)

MC2862 O/M.QXD 9/27/02 10:35 AM Page 3

Dear Customer:

Selecting fine audio equipment such as the unit you’ve just purchased is only the start of your
musical enjoyment. Now it’s time to consider how you can maximize the fun and excitement
your equipment offers. This manufacturer and the Electronic Industries Association’s
Consumer Electronics Group want you to get the most out of your equipment by playing it at a
safe level. One that lets the sound come through loud and clear without annoying blaring or
distortion—and, most importantly, without affecting your sensitive hearing.
Sound can be deceiving. Over time your hearing “comfort level” adapts to higher volumes of
sound. So what sounds “normal” can actually be loud and harmful to your hearing. Guard
against this by setting your equipment at a safe level BEFORE your hearing adapts.

To establish a safe level:

• Start your volume control at a low setting.

• Slowly increase the sound until you can hear it comfortably and clearly, and without
distortion.

Once you have established a comfortable sound level:

• Set the dial and leave it there.

Taking a minute to do this now will help to prevent hearing damage or loss in the future. After
all, we want you listening for a lifetime.

We Want You Listening For A Lifetime

Used wisely, your new sound equipment will provide a lifetime of fun and enjoyment. Since
hearing damage from loud noise is often undetectable until it is too late, this manufacturer and
the Electronic Industries Association’s Consumer Electronics Group recommend you avoid
prolonged exposure to excessive noise. This list of sound levels is included for your protection.

Decibel

Level

Example

30 Quiet library, soft whispers
40 Living room, refrigerator, bedroom away from traffic
50 Light traffic, normal conversation, quiet office
60 Air conditioner at 20 feet, sewing machine
70 Vacuum cleaner, hair dryer, noisy restaurant
80 Average city traffic, garbage disposals, alarm clock at two feet

THE FOLLOWING NOISES CAN BE DANGEROUS UNDER CONSTANT EXPOSURE:

90 Subway, motorcycle, truck traffic, lawn mower
100 Garbage truck, chain saw, pneumatic drill
120 Rock band concert in front of speakers, thunderclap
140 Gunshot blast, jet engine
180 Rocket launching pad

Information courtesy of the Deafness Research Foundation.

4

MC2862 O/M.QXD 9/27/02 10:35 AM Page 4

We
Want You

LISTENING

For A Lifetime

C

I

N

O

R

T

C

E

L

EIA

E

A

EST. 1924

S

S

O

C

I

N

D

U

S

T

R

I

E

S

N

O

I

T

A

I

5

LOCATION OF CONTROLS

1. AL1 (Alarm 1) Button

2. AL2 (Alarm 2) Button

3. DISPLAY Button

4. Alarm (AL1, AL2, DUAL) Switch

5. BUZZER/MUSIC/ALARM OFF
Switch

6. CLOCK Button

7. SLEEP Button

8. POWER ON/OFF, ALARM
OFF Button

9. AC Cord (Rear of Unit)

10. CD Compartment Door

11. Battery Compartment (Bottom
of Unit)

12. SNOOZE Button

13. OPEN/CLOSE Area

14. STOP (■) Button

15. PLAY/PAUSE ( ) Button

16. Function (CD/FM/AM) Switch

17. REPEAT Button

18. PROG (Program) Button

19. SKIP/MINUTE ( ) Button,
SKIP/HOUR ( ) Button

20. VOLUME Control (Side of Unit)

21. TUNING Control (Side of Unit)

22. PM Indicator

23. AL1 Indicator

24. FM ST (Stereo) Indicator

25. POWER Indicator

26. SLEEP Indicator

27. Dial Scale and Pointer

28. PROG Indicator

29. REPEAT Indicator

30. AL2 Indicator

31. Display

MC2862 O/M.QXD 9/27/02 10:35 AM Page 5

42 3 5 10 12 13

6 7

81

1415161718 19 2021119

23

30 3124 25 26 2827 2922
