MC1886
User’s Guide
AM/FM CLOCK RADIO
WITH DUAL ALARM
Before operating this product,
please read these instructions completely.
SAFETY PRECAUTIONS
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER
(OR BACK) OR EXPOSE TO RAIN OR MOISTURE. NO USER-SERVICEABLE PARTS
INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
DANGEROUS VOLTAGE
Uninsulated Dangerous Voltage, that may be of sufficient
magnitude to constitute a risk of electric shock to persons is
present within this product’s enclosure.
ATTENTION
The Owner’s Manual contains important operating and
maintenance instructions.
For your safety, it is necessary to refer to the manual.
• Place the unit on a stable surface.
• Avoid installing the unit in locations described below:
• Places exposed to direct sunlight or close to heat radiating appliances such
as electric heaters.
• On top of other stereo equipment that radiates too much heat.
• Places lacking ventilation or dusty places.
• Places subject to constant vibration.
• Humid or moist places.
SURGE PROTECTORS:
It is recommended to use a surge protector for AC connection. Lightning and power
surges ARE NOT covered under warranty for this product.
FCC WARNING:
This equipment may generate or use radio frequency energy. Changes
or modifications to this equipment may cause harmful interference
unless the modifications are expressly approved in the instruction manual. The user could lose the authority to operate this equipment if an
unauthorized change or modification is made.
PLEASE KEEP ALL PACKAGING MATERIAL FOR AT LEAST 90 DAYS IN
CASE YOU NEED TO RETURN THIS PRODUCT TO YOUR PLACE OF
PURCHASE OR MEMOREX.
1
PORTABLE CART WARNING
(symbol provided by RETAC)
INFORMATION
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if
not installed and used in accordance with instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will
not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or
more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
IMPORTANT SAFETY INSTRUCTIONS
Before using the unit, be sure to read all operating
instructions carefully. Please note that these are general
precautions and may not pertain to your unit. For
example, this unit may not have the capability to be
connected to an outdoor antenna.
1. READ INSTRUCTIONS
All the safety and operating instructions should be read
before the product is operated.
2. RETAIN INSTRUCTIONS
The safety and operating instructions should be
retained for future reference.
3. HEED WARNINGS
All warnings on the product and in the operating
instructions should be adhered to.
4. FOLLOW INSTRUCTIONS
All operating and use instructions should be followed.
5. CLEANING
Unplug this product from the wall outlet before
cleaning. Do not use liquid cleaners or aerosol
cleaners. Use a dry cloth for cleaning.
6. ATTACHMENTS
Do not use attachments not recommended by the
product's manufacturer as they may cause hazards.
7. WATER AND MOISTURE
Do not use this product near water–for example: near
a bathtub, washbowl, kitchen sink or laundry tub; in a
wet basement; or near a swimming pool.
8. ACCESSORIES
Do not place this product on an unstable cart, stand,
tripod, bracket or table. The product may fall, causing
serious injury and serious damage to the product. Use
only with a cart, stand, tripod, bracket or table
recommended by the manufacturer or sold with the
product. Any mounting of the product should follow the
manufacturer’s instructions, and should use a
mounting accessory recommended by the
manufacturer.
8A. An appliance and cart combination should be moved
with care. Quick stops, excessive force and uneven
surfaces may cause the appliance and cart
combination to overturn.
9. VENTILATION
Slots and openings in the cabinet and in the back or
bottom are provided for ventilation, to ensure reliable
operation of the product and to protect it from
overheating. These openings must not be blocked or
covered. The openings should never be
blocked by placing the product on a bed,
sofa, rug or other similar surface. This
product should never be placed near or
over a radiator or heat source. This
product should not be placed in a built-in
installation such as a bookcase or rack
unless proper ventilation is provided or the
manufacturer's instructions have been adhered to.
10. POWER SOURCES
This product should be operated only from the type of
power source indicated on the marking label. If you are
not sure of the type of power supply to your home,
consult your appliance dealer or local power company.
For products intended to operate from battery power,
or other sources, refer to the operating instructions.
11. GROUNDING OR POLARIZATION
This product is equipped with a polarized alternatingcurrent line plug (a plug having one blade wider than
the other). This plug will fit into the power outlet only
one way. This is a safety feature. If you are unable to
insert the plug fully into the outlet, try reversing the
plug. If the plug should still fail to fit, contact your
electrician to replace your obsolete outlet. Do not
2
IMPORTANT SAFETY INSTRUCTIONS
ANTENNA
LEAD IN
WIRE
ANTENNA
DISCHARGE UNIT
(NEC SECTION 810-20)
GROUNDING CONDUCTORS
(NEC SECTION 810-21)
GROUND CLAMPS
POWER SERVICE GROUNDING
ELECTRODE SYSTEM
(NEC ART 250, PART H)
NEC - NATIONAL ELECTRICAL CODE
ELECTRIC
SERVICE
EQUIPMENT
GROUND
CLAMP
S2898A
defeat the safety purpose of the polarized plug.
2. POWER-CORD PROTECTION
1
Power-supply cords should be routed so that they are
ot likely to be walked on or pinched by items placed
n
upon or against them, paying particular attention to
cords at plugs, convenience receptacles, and the point
here they exit from the appliance.
w
3. LIGHTNING
1
o protect your product from a lightning storm, or when
T
it is left unattended and unused for long periods of
time, unplug it from the wall outlet and disconnect the
antenna or cable system. This will prevent damage to
the product due to lightning and power-line surges.
14. POWER LINES
An outside antenna system should not be located in
the vicinity of overhead power lines or other electric
light or power circuits, or where it can fall into such
power lines or circuits. When installing an outside
antenna system, extreme care should be taken to keep
from touching such power lines or circuits as contact
with them might be fatal.
15. OVERLOADING
Do not overload wall outlets and extension cords as
this can result in a risk of fire or electric shock.
16. OBJECT AND LIQUID ENTRY
Never push objects of any kind into this product through
openings as they may touch dangerous voltage points or
short out parts that could result in fire or electric shock.
Never spill or spray any type of liquid on the product.
17. OUTDOOR ANTENNA GROUNDING
EXAMPLE OF ANTENNA GROUNDING AS PER
NATIONAL ELECTRICAL CODE
If an outside antenna is connected to the product,
be sure the antenna system is grounded so as to
provide some protection against voltage surges and
built-up static charges. Section 810 of the National
Electric Code, ANSI/NFPA 70, provides information
with respect to proper grounding of the mast and
supporting structure, grounding of the lead-in wire
to an antenna discharge product, size of grounding
conductors, location of antenna discharge product,
connection to grounding electrodes and
requirements for grounding electrodes.
18. SERVICING
o not attempt to service this product yourself as
D
opening or removing covers may expose you to
angerous voltage or other hazards. Refer all
d
servicing to qualified service personnel.
19. REPLACEMENT PARTS
hen replacement parts are required, be sure the
W
ervice technician uses replacement parts specified
s
y the manufacturer or those that have the same
b
characteristics as the original part. Unauthorized
substitutions may result in fire, electric shock or
other hazards.
20. SAFETY CHECK
Upon completion of any service or repairs to this
product, ask the service technician to perform
safety checks to determine that the product is in
proper operating condition.
21. WALL OR CEILING MOUNTING
The product should be mounted to a wall or ceiling
only as recommended by the manufacturer.
22. DAMAGE REQUIRING SERVICE
Unplug the product from the wall outlet and refer
servicing to qualified service personnel under the
following conditions:
a. When the power-supply cord or plug is
damaged.
b. If liquid has been spilled or objects have fallen
into the product.
c. If the product has been exposed to rain or
water.
d. If the product does not operate normally by
following the operating instructions. Adjust
only those controls that are covered by the
operating instructions, as an adjustment of
other controls may result in damage and will
often require extensive work by a qualified
technician to restore the product to its normal
operation.
e. If the product has been dropped or the cabinet
has been damaged.
f. When the product exhibits a distinct change in
performance–this indicates a need for service.
23. HEAT
The product should be situated away from heat
sources such as radiators, heat registers, stoves or
other products (including amplifiers) that produce
heat.
24. NOTE TO CATV SYSTEM INSTALLER
This reminder is provided to call the CATV system
installer's attention to Article 820-40 of the NEC that
provides guidelines for proper grounding and, in
particular, specifies that the cable ground shall be
connected to the grounding system of the building,
as close to the point of cable entry as practical.
3
LOCATION OF CONTROLS
2
1
13
3
5
6
7
8
10
9
11
4
14
15
16
18
17
20
22
12
19
21
1. SNOOZE Button
2. Alarm (1/1+2/2) Switch
3. SLEEP Button
4. ALARM Button
5. FUNCTION
(ON/OFF/RADIO/BUZZ)
Switch
6. PM Indicator
7. TIME Button
8. Alarm 1 Indicator
9. FM Antenna Wire (Rear of
Unit)
10. VOLUME Control
11. AM/FM Dial Scale and
Pointer
12. Speaker (Rear of Unit)
13. DIMMER (HI/LOW) Switch
14. FAST Button (For adjusting
the Clock/Alarm Time)
15. SLOW Button (For adjusting
the Clock/Alarm Time)
16. Band (AM/FM) Switch
17. Time Display
18. ALARM OFF Button
19. Alarm 2 Indicator
20. AC Cord (Rear of Unit)
21. TUNING Control
22. Battery Compartment
(Bottom of Unit)
4
INSTALLATION
AC Plug
AC Outlet
9V
CAUTION:
TO PREVENT ELECTRIC SHOCK, MATCH
THE WIDE BLADE OF THE PLUG TO THE
WIDE SLOT, FULLY INSERT.
Unravel the AC cord and connect it to a
conveniently located AC outlet having 120V
and 60Hz only. The Clock Display will
illuminate and “12:00” will blink in the window.
NOTE: If the AC plug does not fit into a nonpolarized outlet, do not file or cut the
wide blade.
If the AC cord is disconnected or if there is a power failure, this electronic clock is
designed to continue operating internally (without showing the time on the Clock
Display) with a 9 volt battery (not included). To install the battery, remove the
battery compartment cover by pressing in on the tab, then connect the battery to
the terminals of the battery snap inside the
compartment (use of an alkaline battery is
recommended). Replace the battery compartment
cover.
Be sure to check the condition of the battery
periodically by disconnecting the AC cord and
connecting it again 2 or 3 minutes later. The preset
times should continue operating. If the present time
does not appear, it indicates the battery is dead or not connected properly.
Follow these precautions when using a battery in this device:
1. Use only the size and type of battery specified.
2. Be sure to follow the correct polarity when installing the battery as indicated in the
battery compartment. Reversed batteries may cause damage to the device.
3. If the device is not to be used for a long period of time, remove the battery to prevent
damage or injury from possible battery leakage.
4. Do not try to recharge batteries not intended to be recharged; they can overheat and
rupture. (Follow battery manufacturer’s directions.)
BATTERY PRECAUTIONS
5
1
2
TO LISTEN TO THE RADIO
OPERATION
1
Slide the FUNCTION switch 1 to the
ON position. Slide the Band switch 2
to the AM or FM position as desired.
3
Adjust the VOLUME control as
desired.
2
Tune a station by turning the TUNING
control.
4
To turn the radio off, slide the
FUNCTION switch to the OFF
position.
Antennas
FM: Extend the FM Antenna Wire for best reception.
AM: Turn the unit for better AM reception.
6
OPERATION (CONTINUED)
2
1
1
2
3
1
2
3
TO SET OR RESET THE ACTUAL TIME
1
Press and hold the TIME button.
TO SET OR RESET THE ALARM TIME
While holding the TIME button 1,
press the FAST button 2 (for rapid
search) and/or SLOW button
slow search) to set the present time.
1
2
3 (for
2
Slide the ALARM switch 1 to the 1
position to set alarm 1 or the 2
position to set alarm 2.
Press and hold the ALARM button
While holding the ALARM button 1,
press the FAST button
2.
7
SLOW button
alarm time.
3 to set the desired
2 and/or
OPERATION (CONTINUED)
3
1
2
TO SET THE ALARM TO WAKE TO RADIO
1
Set the alarm time as previously
instructed. Slide the FUNCTION
switch to the ON position.
NOTE: Please make sure the volume is not set to the minimum, otherwise, when
it reaches the alarm time, you will not hear the radio sound.
3
Slide the FUNCTION Switch to the
RADIO position.
2
Slide the Band switch 1 to the AM or
FM position, then tune a station using
the TUNING control 2. Make sure the
VOLUME control
3 is set as desired.
4
Slide the Alarm switch to the 1, 2 or
1+2 position. Select 1+2 to activate
both alarms. When the actual time
matches the selected preset alarm
time(s), the unit automatically turns
on.
To shut off the alarm, see TO SHUT
THE ALARM OFF section on the next
page.
8
OPERATION (CONTINUED)
2
1
TO SET THE ALARM TO WAKE TO BUZZER
1
Set the alarm time as previously
instructed. Slide the Alarm switch to
the 1, 2 or 1+2 position. Select 1+2 to
activate both alarms.
TO SHUT THE ALARM OFF
1
SNOOZE
1
The alarm can be temporarily turned off manually by
pressing the SNOOZE button; the alarm will turn back
on automatically 7 minutes later. It can be repeated
endlessly. With the actual time showing in the display,
press and hold the SNOOZE button, the display will
change to show the last digit of the minute (at the left
digit) of the actual time and the seconds (at the right
two digits). ( i.e. If the actual time is "12:28" when you
press and hold the SNOOZE button, then the left digit
will show "8" and the right two digits will count up for
the seconds of the actual time.)
2
Slide the FUNCTION switch to the BUZZ
position. When the actual time matches
the selected preset alarm time(s), the
unit automatically turns on.
To shut off the alarm, see TO SHUT THE
ALARM OFF section below.
To shut the alarm off, press the
ALARM OFF button
alarm time will be reset for the next
day. Slide the FUNCTION switch
to the OFF position to turn off the
alarm and not set it for the next day.
❶ once and the
❷
NOTE: In Dual Alarm mode, if both alarms are set, the Snooze feature will only
operate up to the next alarm. If the next alarm time is reached, the unit
automatically turns on for 59 minutes and then shuts off.
9
OPERATION (CONTINUED)
1
2
4
3
TO ACTIVATE THE SLEEP FUNCTION
1
Tune a desired radio station as
previously instructed and slide the
FUNCTION switch to the OFF
position.
3
DIMMER SWITCH
2
Press the SLEEP button and 0:59 will
appear on the clock display, then
release the button; the radio will turn
on.
To adjust the sleep time, press and
hold the SLEEP button
the FAST 2 and/or SLOW 3 button to
select for the Sleep Time, i.e. "0:01" to
turning on the radio for one minute,
"0:59" to turn on the radio for 59
minutes. Press the ALARM OFF
button
cancel the sleep function.
4 to turn off the radio and
1, then press
1
Slide to the HI position for a brighter
display. Slide to the LOW position for
a less bright display.
10
TROUBLESHOOTING GUIDE
If you experience a problem with this unit, check the chart below before
calling for service.
SYMPTOM
GENERAL
Power does AC line cord not Insert plug firmly
not come on. plugged in. into AC outlet.
RADIO
No sound. FUNCTION switch not Set FUNCTION switch
Noise or sound AM–Interference from Turn the radio for
distorted on AM traffic. better AM reception.
or FM. FM–Antenna Wire Extend Antenna Wire.
Radio does not FUNCTION switch Set FUNCTION
turn off with not in OFF position. switch to the
SLEEP feature. OFF position.
CLOCK
Flashing time. Battery connected Check the battery.
Alarm does not FUNCTION switch Set FUNCTION
turn on. not in RADIO or switch to the RADIO
POSSIBLE POSSIBLE
CAUSE SOLUTION
set to ON position. to ON position.
VOLUME control at Turn the VOLUME
minimum position. control up.
not extended.
improperly, not con-
nected or dead.
Clock not set. Set the clock.
BUZZ position. or BUZZ position.
Clock is not set. Set the clock.
Alarm time not set. Set alarm time.
11
Cleaning the Unit
• To prevent fire or shock hazard, disconnect your unit from the AC power
source when cleaning.
• The finish on your unit may be cleaned with a dust cloth and cared for as other
furniture. Use caution when cleaning and wiping the plastic parts.
• Mild soap and a damp cloth may be used on the front panel.
FOR ADDITIONAL SET-UP OR OPERATING ASSISTANCE,
PLEASE VISIT OUR WEBSITE AT
WWW.MEMOREXELECTRONICS.COM
OR CONTACT CUSTOMER SERVICE AT (954) 660-7100.
PLEASE KEEP ALL PACKAGING MATERIAL FOR AT LEAST 90
DAYS IN CASE YOU NEED TO RETURN THIS PRODUCT TO YOUR
PLACE OF PURCHASE OR MEMOREX.
FOR PARTS AND ACCESSORIES, CONTACT FOX INTERNATIONAL
AT 1-800-321-6993.
12
Memcorp, Inc.
Weston, FL
Printed in Hong Kong
Visit our website at www.memorexelectronics.com
Loading...
