DSN30 Switch-Rated Plugs & Receptacles – 30 A
UL/CSA Ratings
• Max Amperage & Voltage
30 A, 600 VAC
• Switch-Rating (AC Only)
Branch Circuit & Motor Circuit
Disconnect Switching
• Horsepower Ratings
1Ø
120V
240V
1Ø 3 hp
208V
3Ø 5 hp
240V
3Ø 5 hp
480V
3Ø
600V
3Ø 15 hp
2 hp
15 hp
• Short Circuit Rating
100kA Close & Withstand
Testing was performed with RK1
current limiting fuses sized at 400%
of the highest full load motor
ampacity associated with the
devices hp rating.
• Environmental Ratings
Type 4X/IP69/IP69K*
*Also meets IP66/IP67 requirements
• Temperature Range
Min -40°F/Max 140°F
8 for temps below -15°F.
See pg 25
• Wiring Capacity
Min 14 AWG Max 8 AWG Aux
Contacts - 14 AWG
• Certifications
UL 2682, UL 1682, CSA 182.1
Don’t forget to add installation
accessories to your order
!
Voltage Polarity
120V
120 208V
125V
125 250V
208V
208V
250V
250V
277V
277 480V
347 600V
480V
480V
600V
600V
1P+N+G 63-34165 63-38165
3P+N+G 63-34167 63-38167
1P+N+G 63-34075 63-38075
2P+N+G 63-34076 63-38076
1P+N+G 63-34045 63-38045
3P+N+G 63-34047 63-38047
3P+N+G 63-34147 63-38147
Receptacle
(female)
North American UL/CSA Congurations
Part # Part #
Poly Poly
2P+G 63-34162 63-38162
3P+G 63-34163 63-38163
2P+G 63-34072 63-38072
3P+G 63-34073 63-38073
2P+G 63-34042 63-38042
3P+G 63-34043 63-38043
2P+G 63-34142 63-38142
3P+G 63-34143 63-38143
(male)
Inlet
Main Options
5/16”
hole
See pages 235-244 for detailed
information on these options
!
29
Auxiliary/Pilot
Contacts
Mushroom
Pawl
Padlock Pawl
Closed Lid
Configuration
Recommended for cord
applications to keep lid
tucked in to avoid damage.
Receptacle Options Suffix # Inlet Options Suffix #
With 2 Auxiliary/Pilot Contacts
Straight Insertion
Self-Ejecting Connector Release
Mushroom Pawl
Padlock Pawl
Padlockable Mushroom Pawl
Metal Pawl
Closed Lid Configuration
With Auxiliary Switch
Notes: + Not UL/CSA listed.
Order Example: 480V DSN30 + 2 auxiliary contacts
DSN30 Inlet 3P+G = 63-38043-972
Recept # - 972
Recept # - 352
Recept # - 354
Recept # - 375
Recept # - 843
Recept # - 375-843
Recept # - 824
Recept # - NC
Recept # - 270+
With 2 Auxiliary/Pilot Contacts
Self-Ejecting Plug Release
With No Lockout Hole
For Auxiliary Switch
Notes: * Order inlet with P+N+G configuration and receptacle with
P+G configuration.
Inlet # - 972
Inlet # - 338
Inlet # - A155
Inlet # - NNF*
INSTALLATION ACCESSORIES – SIZE 2
DSN30
DSN
HANDLE w/NPT
1/2” 512P0N05 592P0N05
Poly
HANDLESANGLES
3/4” 512P0N07 592P0N07
1” 512P0N10 592P0N10
Metal
1 1/4”
For available cord grips, see page 167.
POLY HANDLE w/CORD GRIP
METAL HANDLE w/CORD GRIP
POLY HANDLE
POLY HANDLE w/CLAMP & BUSHING
Part # Poly Part # Metal
512P0N12 –
Cable Range Part #
.350 - .520" 712P0BP6
.520 - .680" 712P0CP5
.680 - .980" 712P0DP4
.980 - 1.260" 712P0EP4
.438 - .500" 792P0BS3
.500 - .562" 792P0BS4
.562 - .625" 792P0CS2
.625 - .750" 792P0CS4
.750 - .875" 792P0DS1
.875 - 1.000" 792P0DS3
.20 - .82
.750 - .875” 712P0S14
.875 - 1.000” 712P0S16
1.000 - 1.125” 712P0S18
1.125 - 1.250” 712P0S20
1.250 - 1.375” 712P0S22
” 512P0D21
POLY CONDUIT ENTRY w/NPT
BOXESMISCELLANEOUS ACCESSORIES
30° 1/2” 512B3N05
30° 3/4” 512B3N07
3
* 8.5 in
Part #
POLY WALL BOX w/ANGLE
70° 512C7000
3
* 82.0 in
Ground Bar 51AA089
POLY ANGLE w/ALUMINUM WALL BOX w/NPT
70° 1/2” 712C7N05
70° 3/4” 712C7N07
70° 1” 712C7N10
* 74.6in
3
70° 1 1/4” 712C7N12
70° 1 1/2” 712C7N15
METAL BOX w/NPT
0° 1/2” 7T1F0N05
0° 3/4” 7T1F0N07
0° 1” 7T1F0N10
0° 1 1/4” 7T1F0N12
POLY ANGLE w/METAL BOX w/NPT
* 28.7 in
30°
30° 3/4” 712C3N07
30° 1” 712C3N10
3
30° 1 1/4” 712C3N12
1/2”
712C3N05
NPT on top or bottom (if rotated). For other NPT configurations, contact customer service.
* Interior volume with
receptacle installed.
70° poly boxes are
not drilled. Contact
customer service
if factory drilled is
required.
* Interior volume with
receptacle installed.
* Interior volume with
receptacle installed.
* Interior volume with
receptacle installed.
POLY ANGLE
METAL ANGLE
30° 512M3
70° 512M7
0° 592M0
30° 592M3
FS/FD Box 30° 792M3FS
* Base measures
approximately 4.2” x
2.7”. Due to the
variation in sizes of
FS boxes, please
verify that your FS
box matches our
dimensions, if not call
Customer Service for
other solutions.
FINGER DRAWPLATES
61-3A346
Set of Two (2)
Recommended for cord to cord assembly applications,
for easier connector closure.
PROTECTIVE INLET/PLUG CAP
61-3A426 For Inlets/Plugs Only.
PADLOCKABLE INLET/PLUG CAP
61-3A826 For Inlets/Plugs Only.
SPRING-LOADED PADLOCKABLE INLET/PLUG CAP
61-3A226
Metal – For Inlets/Plugs Only.
-A155 suffix required to maintain water ingress protection.
SCREWDRIVER FOR TERMINAL SCREWS
SD18 Klein 608-3 1/8” cabinet with 3” round shank.
RECEPTACLE LOCKING PIN
LP-843 Requires Padlockable Pawl option (-843) on receptacle.
