DSN DIMENSIONS – Provided in inches
PLUG
INLET
D
ØE
C
G
F
INLET
ØE
G
F
RECEPTACLE
CONNECTOR
G
F
C
D
ØE
H
DSN150 DRAW BAR EXTENT
RECEPTACLE
G
F
H
DSN150 DRAW BAR EXTENT
H
DSN150 DRAW BAR EXTENT
DSN150 DRAW BAR EXTENT
Dimensions are for reference only and may change depending on accessories used. For precise dimensions contact MELTRIC Engineering.
Plug
C
Inlet
F
G
B
D
A
PRODUCT
DSN20 5.28 2.40 1.65 1.65 0.17 2.46 1.87
DSN30 5.75 2.91 1.89 1.89 0.18 2.56 1.97
DSN60 6.30 3.46 2.17 2.17 0.19 2.8 2.21
DSN150 8.33 4.59 3.20 3.2 0.24 4.14 3.04
Connector
A
A B C D øE F G
Receptacle Extended Draw bars
B
ØE
C
D
F
G
H
PRODUCT
DSN20 5.26 5.60 1.65 1.65 0.19 3.15 2.10 N/A
DSN30 7.05 6.93 1.89 1.89 0.18 3.53 2.88 N/A
DSN60 7.74 7.22 2.17 2.17 0.2 3.64 3.09 N/A
DSN150 11.04 10.02 3.20 3.2 0.23 5.71 4.74 11.25
Box /30° Angle/
A B C D øE F G H
A
C
Receptacle/Plug
D
B
ØE
PRODUCT
DSN20 7.80 7.25 4.19 2.75 0.27
DSN30 9.85 7.60 4.19 2.75 0.27
DSN60 10.48 8.20 4.19 2.75 0.27
DSN150 16.06 10.33 6.75 4.25 0.31
A B C D øE
37
DSN
DSN
A
C
30° Angle/Receptacle/Plug
D
B
ØE
PRODUCT A B C D øE
DSN20 7.80 7.10 2.50 3.75 0.18
DSN30 9.85 8.50 2.50 3.75 0.22
DSN60 10.48 9.02 2.50 3.75 0.22
DSN150 16.06 12.05 4.83 4.83 0.28
70° Wall Box/
Receptacle
A
C
D
Ø
F
E
B
PRODUCT A B C D E øF
DSN20 7.51 8.30 2.80 4.60 4.15 0.26
DSN30 7.93 9.51 2.80 4.60 4.15 0.26
DSN60* 8.91 11.55 2.80 6.17 5.73 0.26
* Box has 4 mounting feet
Plug/Connector
A
B
PRODUCT A B
DSN20 9.09 3.50
DSN30/DSN24 10.43 4.57
DSN60/DSN37 11.26 4.80
DSN150 19.53 8.03
38
