Notice

Installation Instructions

■ Introduction

Thank you for purchasing MITSUBISHI Integrated FA Software, MELSOFT series.

This document explains how to install and uninstall MELSOFT iQ Works (SW1DND-IQWK-E ). Please read carefully before

installing the product to your personal computer.

• Reprinting or reproducing the part or all of the contents of this document in any form for any purpose without the permission of Mitsubishi Electric Corporation is strictly forbidden.

• Although we have made the utmost effort to follow the revisions of the software and hardware, in some cases, unsynchronized matter may occur.

• The information in this document may be subject to change without notice.

Installation

Install MELSOFT iQ Works or an application to the personal computer.

■ Confirm before installation

• Log on to the personal computer as a user having the "Administrator" (computer administration) privilege.

• Close all the applications running under Microsoft® Windows® Operating System before installation. If the product is installed while other applications are running, it may not operate normally.

■ Batch installation

Install multiple applications in batch.

Start installation

Insert the installation DVD-ROM to the DVD-ROM drive. MELSOFT iQ Works installation starts automatically. If it does not start automatically, double-click the "setup.exe" icon on the DVD-ROM (Disk 1 folder).

Enter "Name", "Company", and "Product ID".

Select the applications to be installed.

Specify the installation destination.

Install programs by following the on-screen instructions.

Select the applications to be displayed on the desktop as shortcuts.

End of installation

*1 : Product ID is written on the "License certificate" included with the product.

Enter the 12-digit number divided into 3 and 9 digits.

■ FX series installation

When using special blocks or special units, installation of the related software is required. The related software of FX-ENET series may be downloaded from MITSUBISHI ELECTRIC FA Global Website.

For the method of obtaining the related software, contact the store where you purchased the product.

■ Individual installation

Each application can be used individually by installing only the required application.

Double-click the "setup.exe" icon in each folder to install the application.

Folder Application Location of "setup.exe"

Disk 1

Disk 2

Disk 3

Disk 4

Disk 5

Disk 6

Disk 7 Data transfer tool Disk 7\ "DataTransfer" folder Disk 8 GT Manual3 1000 Disk 8\ "GTM1000" folder Disk 9 RT ToolBox2 Disk 9 folder

Disk A

*1 : Select MELSOFT Navigator only on the Selection of software dialog box. *2 : When MT Developer2 is installed, MR Configurator2 is installed automatically. *3 : Select GT Designer3(GOT2000) only on the Selection of software dialog box. *4 : "setup.exe" is compressed. For the installation procedure, refer to GX Works2

MELSOFT Navigator MELSOFT FieldDeviceConfigurator GX Works2 Disk 2 folder GX Developer Disk 2\ SUPPORT \ "GXD1" folder MT Developer2

MR Configurator2

GT Designer3(GOT2000) GT Manual3 2000 GT Designer3(GOT2000)Help GT Designer3(GOT1000) Disk 6 folder Document Converter Disk 6\ "DocCNV" folder GT Converter2 Disk 6\ "GTCNV2" folder

LCPU Logging Configuration To ol

GX Configurator-QP

Version 1 Operating Manual (Intelligent Function Module).

Precautions

• Note that not to enter the power save mode (standby, hibernate, sleep) while installing the software.

• The driver install confirmation screen may appear during the software installation.

When using Windows Vista software".

When using Windows XP

• If the cancel button is clicked during the installation, the installation is cancelled. In this case, insert the DVD-ROM, and restart the installation by following the onscreen instructions.

• If a warning message from the security software is displayed, proceed the installation by following the on-screen instructions.

• The newer version software may be downloaded from MITSUBISHI ELECTRIC FA Global Website. After installing MELSOFT iQ Works, confirm the latest version on MITSUBISHI ELECTRIC FA Global Website. In order to download the newer version software, membership registration of MITSUBISHI ELECTRIC FA Global Website is required.

or Windows® 7 or later, select "Install this driver

, click the Continue anyway button.

Disk 1 folder

Disk 1\ "FDConfig" folder

Disk 3 folder

Disk 4 folder

Disk 5 folder

DiskA\ "LLUTL" folder

DiskA\ "Others" folder

■ Product Makeup

■ Operating Environment

Model name Product name Quantity

MELSOFT iQ Works DVD-ROM 1

SW1DND-IQWK-E (English version package)

(Standard license product)

SW1DND-IQWK-EA (English version package)

(Volume license product)

*1 : Number of licenses.

Installation Instructions (This document)

End-user software license agreement 1 Software registration notice 1 License certificate 1 MELSOFT iQ Works DVD-ROM 1 Installation Instructions

(This document) End-user software license agreement 1

Software registration notice 1

License certificate

Acknowledgements

• We do not guarantee those commercially available Microsoft System products that are introduced in this manual.

• This software's copyright is owned by Mitsubishi Electric Corporation.

• This product (including manual) can be used under the Software License Agreement only.

• We do not take any responsibilities for the consequences of operating this product (including manual).

Windows® Operating

Item Contents

Personal computer main body

CPU

Required memory Recommended 1GB or more

Available hard disk capacity

Disk drive CD-ROM supported disk drive Monitor Resolution 1024 x 768 pixels or higher

OS (English version)

Communication

interface

*1 : When a programmable controller CPU is directly connected.

Windows

For desktop PC: Intel® Celeron® Processor Recommended 2.8GHz or more For laptop PC: Intel

When installing MELSOFT iQ Works: HDD available capacity is 4GB or more. When operating MELSOFT iQ Works: Virtual memory available capacity is 512MB or more.

Microsoft® Windows®8 Operating System, Microsoft Microsoft Microsoft® Windows®7 Starter Operating System, Service Pack 1 Microsoft Microsoft Microsoft Microsoft Microsoft

Service Pack 1,2 Microsoft

Service Pack 1,2 Microsoft Microsoft Microsoft Microsoft Microsoft Microsoft RS-232 port USB port Ethernet port

supported personal computer

Pentium® M processor Recommended 1.7GHz or more

Windows®8 Pro Operating System,

Windows®8 Enterprise Operating System,

Windows®7 Home Premium Operating System, Service Pack 1

Windows®7 Professional Operating System, Service Pack 1

Windows®7 Ultimate Operating System, Service Pack 1

Windows®7 Enterprise Operating System, Service Pack 1

Windows Vista® Home Basic Operating System,

Windows Vista® Home Premium Operating System,

Windows Vista® Business Operating System, Service Pack 1,2

Windows Vista® Ultimate Operating System, Service Pack 1,2

Windows Vista® Enterprise Operating System, Service Pack 1,2

Windows® XP Professional, Service Pack 2 and 3

Windows® XP Home Edition, Service Pack 2 and 3

Windows® 2000 Professional, Service Pack 4

• The following functions cannot be used when the computer is running under

Windows perform properly, when these functions are used.

• Use the product as a user having a privilege higher than "USER" for Microsoft

Windows Vista®.

• The screens of this product may not perform properly when multi-display is set on Display Properties.

Uninstallation

Uninstall MELSOFT iQ Works or an application from the personal computer.

Precautions

XP, Windows Vista®, Windows® 7, or Windows® 8. This product may not

• Activating the application with Windows

• Simplified user switch-over

• Remote desktop

• Large font size (Advanced setting of Display Properties)

• DPI setting other than 100% (set the size of text and illustration other than [smaller-100%])

• 64-bit edition

• Windows XP Mode

• Windows Touch or Touch

• Modern UI

• Client Hyper-V

*2 : Supported by Windows

compatible mode.

7 and Windows® 8.

1. In order to uninstall iQ Works, select "MELSOFT iQ Works" or an application in "Add or Remove Programs" from the control

panel of Windows

Microsoft, Windows, Windows Vista are registered trademarks of Microsoft Corporation in the United States and other countries. Intel, Celeron, Pentium are registered trademarks of Intel Corporation in the United States and other countries. All other company names and product names used in this document are trademarks or registered trademarks of their respective companies.

, and click the Remove button.

BCN-P5776-H
