VISION
glass
kettle
makes life easier
Page 2
Read this instruction manual thoroughly
before use and store it for future reference.
1.
2.
3.
8.
4.
5.
7.
6.
(Figure 1.)
Description:
1. Cover
2. Lid open switch
3. ON/OFF Switch
4. Body
5. Handle
6. Sub base
7. Cordless base
8. Filter
Important safety instructions:
1. This appliance is designed for domestic
use and not for commercial applications.
No responsibility is accepted for damage
resulting from improper use or non-compliance with these instructions.
2. Please keep these instructions for future
reference. If the appliance is passed on
to another person this instruction manual
should accompany it.
3. Before inserting the plug into the wall
socket, check that the mains supply voltage and current rating corresponds with
the power supply details shown on the
appliance’s rating label which you will find
under the base.
4. Never allow the heating base or the kettle
to make contact with or be immersed in
water. Should this happen, take the appliance to your nearest authorised service
centre for repair.
5. Do not operate the appliance if:
• The appliance or power cord shows any
signs of damage,
• The appliance has been dropped.
6. Always remove the plug from the wall
socket:
• After each use
• In case of any malfunction
• Before undertaking any cleaning task
7. When removing the plug from the wall
socket, never pull on the power cord.
8. This appliance is not intended for use by
persons (including children) with reduced
physical, sensory or mental capabilities, or
lack of experience and knowledge, unless
they have been given supervision or instruction concerning use of the appliance
by a person responsible for their safety.
9. Do not attempt to remove any parts of the
housing nor insert any metal objects into
the interior of the appliance.
10. To prevent damage to the power cable, do
not let it pass over sharp corners or edges.
11. Do not expose the appliance to rain or
moisture and do not operate the appliance
outdoors or with wet hands.
12. Use only clean cold water.
13. The appliance operates at very high
temperatures and there is a danger of
scalding from escaping water or steam. Do
not touch any part of the kettle except the
handle (when the appliance is in use) and
ensure that the lid has been closed properly. This appliance is designed for heating
up of water only. Never put any other liquid
into the kettle.
14. The appliance must be positioned so that
the plug is accessible.
15. If the kettle is overfilled, boiling water may
be ejected.
16. WARNING – Do not open the lid while the
water is boiling.
17. The kettle is only to be used with the base
provided.
18. CAUTION – Ensure that the kettle is
switched off before removing it from its
base.
Page 3
19. This appliance is intended to be used in
households or other similar environments
such as:
• Staff kitchen areas in shops, offices and
other working environments
• By clients in hotels, motels and other
residential type environments
• Farm houses
• Bed and breakfast type environments
Operating guidelines for first use:
1. Prior to initial use, clean the appliance by
going through several boiling cycles, using
clean water with each cycle and filling the
kettle (4) to its upper marking. The water
will reach boiling point after approximately
5 minutes and will then switch off automatically.
Operation:
(Please refer to Figure 1)
1. Place the cordless base (7) on a firm and
level surface.
2. Pour the desired amount of clean water into
the kettle (4). Do not touch any part of the
kettle except the handle while the appliance
is in use. Ensure that the lid (1) is properly closed. The amount of water can be
measured by the level mark on the outside
of the kettle. Always pay attention to the
minimum and maximum levels and ensure
that the lid (1) is properly and firmly closed.
3. Position the kettle in such a way on the sub
base (6) so that the underside of the kettle
fits precisely into the contact on the base.
Insert the plug into a wall socket.
4. Put the on/off switch (3) to the ‘1’ position
to start the boiling process. The indicator
lamp will light up.
5. As soon as the water reaches boiling point,
the on/off switch (3) will return automatically to the “0” position. The indicator lamp
will go out. The kettle can also be switched
off manually by putting the on/off switch to
the “0” position.
6. The hot water may now be poured safely
through the spout.
7. This kettle is equipped with a safety cut–out
feature to protect the appliance from damage in case of inappropriate use. Should
the appliance be accidentally switched on
without water or if all the water has evapo-
rated, the safety cut out will automatically
switch off the heating element.
8. If point (7) occurs remove the plug from the
wall socket immediately and refill the kettle
after an adequate cooling down period,
about 15 to 20 seconds.
Warning:
1. DO NOT SUBMERSE IN WATER.
2. Only use the base provided with this kettle.
3. If the supply cord is damaged it must be
replaced by the manufacturer or its service
agent or a similarly qualified person in order to avoid a hazard.
Descaling:
1. Should the appliance switch off before
reaching boiling point this is a sign that
descaling is necessary.
2. A regular descaling agent may be used.
Ensure that the instructions for use are
adhered to. In order to avoid spillage do
not fill the kettle up to the max mark as the
descaling agent may cause the water to
foam.
3. To clean the kettle thoroughly of any decalcification residues, boil the kettle several
times using clean water with each cycle.
Rinse the kettle with clean water afterwards.
Cleaning and care:
1. Before cleaning the appliance, ensure that
it is disconnected from the power supply
and has cooled down completely.
2. Do not use abrasives or harsh cleaning
solutions.
3. Do not immerse the base or the kettle
in any liquid. To clean the exterior use a
slightly damp, lint–free cloth.
4. It is advisable to remove lime deposits from
the kettle at regular intervals.
Specifications:
Supply voltage: 220-240V~ 50Hz
Power consumption: 1850-2200W
Volume: 1.7L
