Page 1
EXECUTIVE
INSIGNIA VACUUM CLEANER
complies with
INTERNATIONAL
IEC60355
SAFETY SPECIFICATIONS
2000W max
Model:
VAC2000
PLEASE READ ALL INSTRUCTIONS BEFORE USE
2 year guarantee
VAC2000_IM.indd 1VAC2000_IM.indd 1 2010/11/22 08:35:33 AM2010/11/22 08:35:33 AM
Page 2
Dear customer,
S
2
3
4
5
6
7
8
9
Many thanks for purchasing a MELLERWARE product. Thanks to its technology, design and operation
and the fact that it goes through strict quality controls - we feel sure you will be entirely satisfied.
D
E
C
B
H
I
G
F
J
K
A
A. Floor tool
B. Extension tube
C. Air regulator vent
D. Hose handle
E. Hose
G. HEPA filter
H. Bagless dust compartment
I. Handle
J. Cord rewind button
K. ON/OFF / speed variation button
F. Hose connector
VAC2000_IM.indd 2VAC2000_IM.indd 2 2010/11/22 08:35:48 AM2010/11/22 08:35:48 AM
Page 3
Safety Warning
For household use only!
1. When using the cleaner, you should adhere to
the following basic safety precautions:
2. Please unplug the appliance when not in use or
before maintenance.
3. In order to reduce the danger of electric shock,
please don’t use outdoors or on a wet surface.
4. Don’t use as a toy for children, please pay close
attention to safety when a child uses or comes
close to the cleaner.
5. Use only the accessories described in the Guide
and provided by the factory.
6. Do not use with damaged cord or plug. If cleaner
is not working as it should, has been dropped,
damaged, left outdoors, or dropped into water,
or if the cord is damaged. Return it to an appointed customer repair center for check, repair
or regulation.
7. The appliance cord should not be used as a
handle to pull and lift the appliance. Do not allow cord to be submerged in tight spaces Ie. between room door and door frame. Do not allow
cord to come into contact with sharp edges and
surfaces. Do not allow the appliance to run over
the cord. Do not allow the cord to come into contact with any heat surface.
8. Do not pull the cord when removing the plug
from the mains socket.
9. Don’t touch the plug or operate the cleaner with
wet hands.
10. Do not allow objects to restrict airflow or to block
airflow.
11. Do not allow any body parts Ie. hair, fingers,
hand etc to block the airflow of the cleaner as
this puts unnecessary strain on the motor and
can cause the motor to burn out.
12. Please don’t use the cleaner to absorb hard or
sharp objects such as the glass, nails, screws,
coins, etc., otherwise the machine or the HEPA
filter will be damaged.
13. Do not use this machine to clean hot objects and
substances as this will cause damage to the appliance.
14. Do not use the appliance unless the bagless
dust compartment and HEPA filter are inserted.
15. Please ensure that the appliance is switched off
before inserting and removing the plug from the
mains socket.
16. Take special care when using the cleaner to
clean a flight of stairs.
17. Please don’t use the cleaner to absorb combustible or inflammable liquids (cleaning liquid,
gasoline, perfume and so on) or use it in the area
where they may possibly exist;
18. Do not use this appliance to clean up toxic substances (bleaching powder, ammonia water and
so on);
19. When connecting or disconnecting hose from
appliance, please ensure that the appliance is
switched off.
20. CAUTION! The appliance has a rapid cord
reel mechanism, please take extra care
when retracting the cord.
21. Do not use the appliance other than for its
intended use and beyond the scope of this
User’s Guide.
22. When using the appliance, please ensure
that the correct voltage supply is administered as the incorrect voltage and current
can cause the cord to heat up and become
soft.
23. This appliance should be stored in a cool
and dry area.
24. When using the appliance take care not to
stumble over the cord!
25. Please don’t immerse the appliance in the
water or other liquids;
26. Please don’t use the appliance to clean
your pets or other animals;
27. Please keep suction inlet away from ear
area due to excessive noise levels when in
operation.
Important points:
If reduced suction occurs, below is a list of
causes:
1. The extension tube or hose could be
blocked. Switch off the appliance and clear
the extension tube or hose before continuing.
2. HEPA filter could be blocked due to not being cleaned regularly, or the bagless dust
compartment is full and should be cleaned.
• While operating the cleaner, one should
keep it far away from a heat or radiant
source;
• Before cleaning commences, please ensure that the appliance with all hoses and
extension tubes are free of large or sharp
objects as this can cause damage to the appliance or accessories.
• When removing the plug from the socket,
do not pull the cord, place hand directly on
the plug and remove from the socket.
• Should the appliance make a strange or
abnormal sound or noise during operation.
switch off the cleaner. Clean out the appliance and all the piping as well as ensure
that all accessories are attached correctly to
the cleaner.
Remarks:
This appliance is fitted with a cord rewinder
mechanism. If the cord, plug or mechanism is
damaged, please take the appliance to the nearest repair centre so that the damaged components can be repaired by the correct personnel.
VAC2000_IM.indd 3VAC2000_IM.indd 3 2010/11/22 08:35:50 AM2010/11/22 08:35:50 AM
Page 4
Use and function
A Guide to Assembling
Caution:
Be sure to cut off power and dismantle accessories before assembling.
Join hose and cleaner by means of joining hose at
suction inlet .
(Fig. 1)
Insert the hose into the suction and turn it clockwise.
Assembling hose handle to extension tube:
To attach the hose handle to the extension tube,
insert the bottom of the hose handle into the top
of the extension tube (as shown in figure 2). The
amount of suction may also be adjusted by using
the air regulator vent on the hose handle.
(Fig. 2)
3. Ideal cord reel method is as follows: Place plug
in one hand and using the other hand, press
cord reel button to rewind cord. By keeping the
plug in one hand, this allows cord to be retracted properly and not allow cord to get tangled
during rewind process.
4. Thermal cut-out:
This appliance has been fitted with a thermal cutout to protect the motor from destruction or harm,
should the operating temperature exceed the safe
operating temperature. If the appliance cuts out, remove the plug from the socket and allow the appliance to cool down. Also check all piping and tubes
for obsticles blocking or restricting airflow. Clean out
bagless dust compartment and HEPA filter. Allow the
appliance to cool down for 1 hour before reuse.
Move and transporting the appliance:
Caution:
A special handle is provided with this appliance
which will enable you to move and transport this
appliance comfortably. There is also a specially
designed grip handle on the bagless dust compartment to move or transport the appliance. Please
note: Do not use the grip handle of the bagless dust
compartment to move or transport the appliance.
This can cause damage to the compartment as well
as cause the appliance to malfunction.
(Fig. 4)
Control of suction force:
Caution:
Once all the accessories have been attached to
the the appliance, remove the desired length of
cord required. The yellow mark on the cord is the
recommended ideal cord length. The cord should
not be removed beyond the red mark.
1. Insert the power plug;
2. Press down the switch button of the cleaner,
keep it ON ; make the suction power stronger
by turning it clockwise and make weaker by
turning it anticlockwise.
(Fig. 3)
Cleaning the HEPA filter:
Warning:
Before any cleaning is done, please ensure that the
appliance is switched off and that the appliance plug
is removed from the socket.
1. Press the release button of the bagless dust
compartment, found on the dust grip handle.
Remove the bagless dust compartment from
the appliance. Release the button of the bagless dust compartment once compartment
has been fully removed.
2. Once the compartment has been removed,
open the hatch of the compartment to empty all
dust and dirt as shown in Fig. 6.
(It is essential to empty bagless dust compartment
once dust level reaches maximum capacity. Also remove HEPA filter and clean separately.)
Switch button Cord rewinder
VAC2000_IM.indd 4VAC2000_IM.indd 4 2010/11/22 08:35:50 AM2010/11/22 08:35:50 AM
button
Page 5
(Fig. 5)
Use the button on
the handle
3. Remove the HEPA filter as shown in Fig. 7
and 8.
(Fig. 6)
Move the clip
on tank bottom
cover
4. When cleaning the HEPA filter, use a gentle
bristle brush to remove fine dust particles.
(Fig. 7) (Fig. 8)
cessories are inserted and attached correctly.
Caution:
The motor filter is installed behind the air outlet
grid, open up the air outlet grid and it may be taken
out;
To remove the motor outlet filter, remove the rear
grid (as shown in Fig. 9). To replace the filter of the
motor outlet filter, insert filter into designated area
followed by inserting the grid into place by clicking
the clips into the slots.
(Fig. 9)
Air Outlet filter
How to replace and clear the air outlet filter:
The air outlet filter should be cleaned or replaced
every 6-12 months of use. Please ensure to correctly replace all filters before switching on the appliance.
1. Ensure the appliance is switched off and that
the plug is removed from the socket.
2. Open the air outlet grid.
3. Remove the filter for cleaning. Also remove
any excess dust which is lying in the air outlet
vent.
4. Replace the filter and insert ait outlet grid into
place until grid “clicks” into slot.
Replace the motor filter:
In order to ensure the best air outlet effect, some-
5. Once HEPA filter cleaning is complete, insert
HEPA filter back into designated area by turning clockwise until filter locks into place.
6. Insert compartment back into appliance until
compartment “clicks” into place. Attach hose
times you need to clear the air outlet filter.
1. Take off the air outlet grid and take out the
filter.
2. Clear the air outlet filter or replace it with a
new filter.
to applance and switch on cleaner to ensure
that cleaner is working correctly.
Caution:
Do not be alarmed if over time the HEPA filter
changes colour. This is normal and will not have
an effect on the operation of the appliance. Should
cleaning of the filter not be successful, rinse the
filter in water. Once complete, allow the filter to dry
naturally for 24 hours.
Key points:
Please note that the appliance is able to operate
without the HEPA filter and bagless dust compartment, but it is not advised as this can cause the
appliance to malfunction. Before using this appliance, always ensure that all compartments and ac-
VAC2000_IM.indd 5VAC2000_IM.indd 5 2010/11/22 08:35:50 AM2010/11/22 08:35:50 AM
Page 6
27 Nourse Avenue Epping 2 Cape Town
P.O. Box 975 Eppindust 7475 South Africa
Tel: +27 21 534 8114 Fax: +27 21 534 8086
Service Centre Share Call: 086 111 5006
web: www.creativehousewares.co.za
VAC2000_IM.indd 6VAC2000_IM.indd 6 2010/11/22 08:35:50 AM2010/11/22 08:35:50 AM
