Page 1
VISION GLASS KETTLE
complies with
INTERNATIONAL
IEC60335
SAFETY SPECIFICATIONS
18502200W
Model:
22400
PLEASE READ ALL INSTRUCTIONS BEFORE USE
2 year guarantee
22400_IM.indd 1 2012/05/24 11:21:06 AM
Page 2
Read this instruction manual thoroughly before use and store it for
future reference.
1.
2.
8.
3.
4.
5.
6.
7.
(Figure 1.)
Description:
1. Cover
2. Lid open switch
3. ON/OFF Switch
4. Body
5. Handle
6. Sub base
7. Cordless base
8. Filter
Important safety instructions:
1. This appliance is designed for domestic use and not for commercial
applications. No responsibility is
accepted for damage resulting from
improper use or non-compliance
with these instructions.
2. Please keep these instructions for
future reference. If the appliance is
passed on to another person this
instruction manual should accompany it.
3. Before inserting the plug into the
wall socket, check that the mains
supply voltage and current rating
corresponds with the power supply
details shown on the appliance’s
rating label which you will find under
the base.
4. Never allow the heating base or
the kettle to make contact with or
be immersed in water. Should this
happen, take the appliance to your
nearest authorised service centre for
repair.
5. Do not operate the appliance if:
• The appliance or power cord shows
any signs of damage,
• The appliance has been dropped.
6. Always remove the plug from the
wall socket:
• After each use
• In case of any malfunction
• Before undertaking any cleaning
task
7. When removing the plug from the
wall socket, never pull on the power
cord.
8. This appliance is not intended for
use by persons (including children)
with reduced physical, sensory
or mental capabilities, or lack of
experience and knowledge, unless
they have been given supervision
or instruction concerning use of the
appliance by a person responsible
for their safety.
9. Do not attempt to remove any parts
of the housing nor insert any metal
objects into the interior of the appliance.
10. To prevent damage to the power
cable, do not let it pass over sharp
corners or edges.
22400_IM.indd 2 2012/05/24 11:21:06 AM
Page 3
11. Do not expose the appliance to
rain or moisture and do not operate
the appliance outdoors or with wet
hands.
12. Use only clean cold water.
13. The appliance operates at very high
temperatures and there is a danger
of scalding from escaping water or
steam. Do not touch any part of the
kettle except the handle (when the
appliance is in use) and ensure that
the lid has been closed properly.
This appliance is designed for heating up of water only. Never put any
other liquid into the kettle.
14. The appliance must be positioned
so that the plug is accessible.
15. If the kettle is overfilled, boiling water may be ejected.
16. WARNING – Do not open the lid
while the water is boiling.
17. The kettle is only to be used with the
base provided.
18. CAUTION – Ensure that the kettle is
switched off before removing it from
its base.
19. This appliance is intended to be
used in households or other similar
environments such as:
• Staff kitchen areas in shops, offices
and other working environments
• By clients in hotels, motels and
other residential type environments
• Farm houses
• Bed and breakfast type environ-
ments
Operating guidelines for first use:
1. Prior to initial use, clean the appliance by going through several
boiling cycles, using clean water
with each cycle and filling the kettle
(4) to its upper marking. The water
will reach boiling point after approximately 5 minutes and will then
switch off automatically.
Operation:
(Please refer to Figure 1)
1. Place the cordless base (7) on a firm
and level surface.
2. Pour the desired amount of clean
water into the kettle (4). Do not touch
any part of the kettle except the
handle while the appliance is in use.
Ensure that the lid (1) is properly
closed. The amount of water can be
measured by the level mark on the
outside of the kettle. Always pay attention to the minimum and maximum levels and ensure that the lid
(1) is properly and firmly closed.
3. Position the kettle in such a way on
the sub base (6) so that the underside of the kettle fits precisely into
the contact on the base. Insert the
plug into a wall socket.
4. Put the on/off switch (3) to the ‘1’
position to start the boiling process.
The indicator lamp will light up.
5. As soon as the water reaches boiling
point, the on/off switch (3) will return
automatically to the “0” position. The
indicator lamp will go out. The kettle
can also be switched off manually by
putting the on/off switch to the “0”
position.
6. The hot water may now be poured
safely through the spout.
7. This kettle is equipped with a safety
cut–out feature to protect the appliance from damage in case of inappropriate use. Should the appliance
be accidentally switched on without
water or if all the water has evaporated, the safety cut out will automati-
22400_IM.indd 3 2012/05/24 11:21:06 AM
Page 4
cally switch off the heating element.
8. If point (7) occurs remove the plug
from the wall socket immediately
and refill the kettle after an adequate
cooling down period, about 15 to 20
seconds.
Warning:
1. DO NOT SUBMERSE IN WATER.
2. Only use the base provided with this
kettle.
3. If the supply cord is damaged it must
be replaced by the manufacturer
or its service agent or a similarly
qualified person in order to avoid a
hazard.
Descaling:
1. Should the appliance switch off
before reaching boiling point this is a
sign that descaling is necessary.
2. A regular descaling agent may be
used. Ensure that the instructions for
use are adhered to. In order to avoid
spillage do not fill the kettle up to
the max mark as the descaling agent
may cause the water to foam.
3. To clean the kettle thoroughly of any
decalcification residues, boil the
kettle several times using clean water with each cycle. Rinse the kettle
with clean water afterwards.
use a slightly damp, lint–free cloth.
4. It is advisable to remove lime deposits from the kettle at regular intervals.
Specifications:
Supply voltage: 220-240V~ 50Hz
Power consumption: 1850-2200W
Volume: 1.7L
Cleaning and care:
1. Before cleaning the appliance, ensure that it is disconnected from the
power supply and has cooled down
completely.
2. Do not use abrasives or harsh cleaning solutions.
3. Do not immerse the base or the kettle in any liquid. To clean the exterior
22400_IM.indd 4 2012/05/24 11:21:06 AM
