Page 1

OPERATING INSTRUCTIONS

OI c5 eng V9 / 18.08.2006 © Cafina / Melitta

Item no. : Cafina - 2954076

Item no. : Melitta SystemService - 2954082

Page 2

OPERATING INSTRUCTIONS

RETAIN FOR FUTURE USE !

The copyright of these Operating Instructions, which are entrusted to the recipient personally, remains with the Cafina / Melitta company.

The content may not be disclosed or made available to any third party without the express consent of the Cafina / Melitta company.

These Operating Instructions must be read and applied by anyone performing work with or on the equipment described.

In particular, it is imperative that all such persons familiarise themselves with the safety instructions.

Page 3

TABLE OF CONTENTS

OI c5 eng V9 / 18.08.2006 i © Cafina / Melitta

1 Description

1.1 Design . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 - 1

1.1.1 External parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 - 1

1.1.2 Internal parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 - 2

1.2 Mode of operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 - 3

1.2.1 c5 coffee maker . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 - 3

1.2.2 "Installed EF milk cooler" option . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 - 3

1.2.3 "External FC milk cooler" option . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 - 3

1.2.4 "Draw hot water" option . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 - 3

1.2.5 "Draw steam" option . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 - 3

1.2.6 "cw cup warmer" option . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 - 4

1.2.7 "Second coffee bean grinder" option . . . . . . . . . . . . . . . . . . . . . . . . . 1 - 4

1.2.8 "Raised bean hopper" option . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 - 4

1.2.9 "Bean hopper lockable" option . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 - 4

1.2.10 "Milk level monitoring" option . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 - 4

1.2.11 "Raised feet" option . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 - 4

1.2.12 "Waste water container level monitoring" option . . . . . . . . . . . . . . . . 1 - 4

1.2.13 Shift function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 - 4

1.2.14 TWIN function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 - 4

1.2.15 Key cards . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 - 5

1.2.15.1 "user" key card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 - 5

1.2.15.2 "manager" key card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 - 5

1.2.15.3 "memory" key card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 - 5

1.2.15.4 "free vend" key card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 - 5

1.2.15.5 "vip" key card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 - 5

1.2.15.6 "external" key card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 - 5

1.2.15.7 "key lock" key card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 - 5

1.2.15.8 "engineer" key card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 - 5

1.3 Technical data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 - 6

1.3.1 Coffee maker types . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 - 6

1.3.2 Machine identification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 - 7

1.3.2.1 Switzerland . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 - 7

1.3.2.2 Export . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 - 7

1.3.3 Dimensions and weights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 - 8

1.3.4 Filling data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 - 8

1.3.5 Operating performance data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 - 9

1.3.6 Environmental conditions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 - 9

1.3.6.1 Temperature and humidity . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 - 9

1.3.6.2 Space requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 - 9

Page 4

TABLE OF CONTENTS

2 Safety instructions

2.1 Warnings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 - 1

2.1.1 Warnings symbols used (depending on nationality) . . . . . . . . . . . . . 2 - 1

2.1.2 Places where warning symbols

are affixed (depending on nationality) . . . . . . . . . . . . . . . . . . . . . . . . 2 - 1

2.1.3 Safety information in these Operating Instructions . . . . . . . . . . . . . . 2 - 1

2.2 Basic safety instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 - 2

2.2.1 Proper use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 - 2

2.2.1.1 General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 - 2

2.2.1.2 c5 coffee maker . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 - 2

2.2.1.3 Installed EF milk cooler . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 - 2

2.2.1.4 cw cup warmer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 - 2

2.2.2 Specific hazards and instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 - 3

2.2.2.1 c5 coffee maker . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 - 3

2.2.2.2 Installed EF milk cooler . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 - 5

2.2.2.3 cw cup warmer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 - 5

2.2.2.4 Key cards . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 - 6

2.2.3 Personal safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 - 6

2.3 Safety mechanisms . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 - 7

2.3.1 Power switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 - 7

2.3.2 Pressure relief valve . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 - 7

2.4 Authorised persons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 - 7

2.4.1 General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 - 7

2.4.2 Areas of responsibility of personnel . . . . . . . . . . . . . . . . . . . . . . . . . . 2 - 7

2.4.2.1 Operator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 - 7

2.4.2.2 User . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 - 8

2.4.2.3 Maintenance personnel (service technician) . . . . . . . . . . . . . . 2 - 8

2.4.3 Minimum training and qualifications of authorised personnel . . . . . . 2 - 8

2.4.3.1 Operator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 - 8

2.4.3.2 User . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 - 8

2.4.3.3 Maintenance personnel (service technician) . . . . . . . . . . . . . . 2 - 8

2.5 Maintenance duty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 - 8

2.6 Availability of these Operating Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . 2 - 8

Page 5

TABLE OF CONTENTS

OI c5 eng V9 / 18.08.2006 iii © Cafina / Melitta

3 Controls and indicators

3.1 Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 - 1

3.2 Operating modes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 - 3

4 Initial start-up

4.1 Normal initial start-up . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 - 1

4.1.1 c5 coffee maker . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 - 1

4.1.2 Installed EF milk cooler . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 - 1

4.1.3 cw cup warmer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 - 1

4.2 Return to service after the machine

has been out of service for a limited time . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 - 1

4.2.1 c5 coffee maker . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 - 1

4.2.2 Installed EF milk cooler . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 - 1

4.2.3 cw cup warmer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 - 1

4.3 Return to service after a fault . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 - 2

4.3.1 c5 coffee maker . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 - 2

4.3.2 Installed EF milk cooler . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 - 2

4.3.3 cw cup warmer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 - 2

5 Operation

5.1 Power supply connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 1

5.1.1 c5 coffee maker . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 1

5.1.2 Installed EF milk cooler . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 1

5.1.3 cw cup warmer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 1

5.1.4 Temperature regulator unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 2

5.1.4.1 Control panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 2

5.1.4.2 Brief description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 2

5.1.4.3 Cooling operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 2

5.1.4.4 Checking the desired milk temperature . . . . . . . . . . . . . . . . . . 5 - 3

5.1.4.5 Programming the desired milk temperature . . . . . . . . . . . . . . 5 - 3

5.2 Water connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 4

5.2.1 Water intake . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 4

5.2.2 Water drainage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 4

5.3 Switching on and off . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 5

5.3.1 Switching on the c5 coffee maker . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 5

5.3.2 Switching off the c5 coffee maker . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 6

5.3.3 Switching the cw cup warmer on and off . . . . . . . . . . . . . . . . . . . . . . 5 - 8

Page 6

TABLE OF CONTENTS

5.4 Dispensing of beverages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 9

5.4.1 Dispensing normal coffee . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 9

5.4.1.1 General sequence . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 9

5.4.1.2 Dispensing a level 1 beverage . . . . . . . . . . . . . . . . . . . . . . . 5 - 10

5.4.1.3 Dispensing a level 2 beverage . . . . . . . . . . . . . . . . . . . . . . . 5 - 12

5.4.2 Dispensing decaffeinated coffee . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 14

5.4.3 Dispensing milk . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 15

5.4.4 Dispensing of hot water . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 16

5.4.5 Drawing steam . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 17

5.4.6 Frothing milk manually . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 18

5.5 Routine work . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 19

5.5.1 Refilling fresh water canister . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 19

5.5.2 Emptying the waste water canister . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 19

5.5.3 Refill coffee beans . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 20

5.5.4 Refill milk . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 22

5.5.5 Emptying the coffee dregs drawer . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 23

5.5.6 Cleaning the drip tray . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 24

5.6 System work . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 25

5.6.1 Control panel and button layout . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 25

5.6.2 Structure of the functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 26

5.6.2.1 Overview and adjustment values . . . . . . . . . . . . . . . . . . . . . 5 - 26

5.6.3 Brief description of functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 27

5.6.3.1 Cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 27

5.6.3.2 Daily counter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 27

5.6.3.3 Total counter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 27

5.6.3.4 Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 27

5.6.3.5 Water quantity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 27

5.6.3.6 Coffee quantity ±1g . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 28

5.6.3.7 Flow period hot water . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 28

5.6.3.8 Pre-infusion 1 milk . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 28

5.6.3.9 Pre-infusion 2 milk . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 28

5.6.3.10 Post-infusion milk . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 28

5.6.3.11 Flow period milk . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 28

5.6.3.12 Flow period steam . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 28

5.6.3.13 Price . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 28

5.6.3.14 No charge . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 28

5.6.3.15 Time / date . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 28

Page 7

TABLE OF CONTENTS

OI c5 eng V9 / 18.08.2006 v © Cafina / Melitta

5.6.4 Use of the functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 29

5.6.4.1 Cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 29

5.6.4.2 Daily counter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 29

5.6.4.3 Total counter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 30

5.6.4.4 Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 31

5.6.4.5 Water quantity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 32

5.6.4.6 Coffee quantity ±1g . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 32

5.6.4.7 Flow period water . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 33

5.6.4.8 Pre-infusion 1 milk . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 33

5.6.4.9 Pre-infusion 2 milk . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 34

5.6.4.10 Post-infusion milk . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 34

5.6.4.11 Flow period milk . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 35

5.6.4.12 Flow period steam . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 35

5.6.4.13 Price . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 36

5.6.4.14 No charge . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 36

5.6.4.15 Time / date . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 37

5.6.5 Resetting to initial installation default settings . . . . . . . . . . . . . . . . . 5 - 38

5.6.5.1 Coffee maker reset . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 38

6 Maintenance

6.1 Maintenance schedule . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 - 1

6.1.1 Intervals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 - 1

6.1.1.1 Cleaning intervals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 - 1

6.1.1.2 Intervals between services . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 - 2

6.2 Cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 - 2

6.2.1 Cleaning work . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 - 2

6.2.2 Cleaning procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 - 4

6.2.2.1 c5 coffee maker . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 - 5

6.2.2.2 Installed EF milk cooler / external FC milk cooler . . . . . . . . . . 6 - 7

6.3 Maintenance log . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 - 8

7 Troubleshooting

7.1 Fault display, troubleshooting and fault acknowledgement . . . . . . . . . . . . . 7 - 1

7.2 Checklist for fault diagnosis and troubleshooting . . . . . . . . . . . . . . . . . . . . . 7 - 2

7.2.1 Textual error messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7 - 2

7.2.2 Error messages displayed via diagnosis points (DP) . . . . . . . . . . . . . 7 - 6

Page 8

TABLE OF CONTENTS

8 Taking out of service and storage

8.1 Taking out of service for a

limited time / taking out of service for good . . . . . . . . . . . . . . . . . . . . . . . . . 8 - 1

8.2 Storage for a limited period / permanent storage . . . . . . . . . . . . . . . . . . . . . 8 - 1

9 Packing and transportation

10 Disposal

11 Guarantee, consumables, spare parts, ordering procedure

12 "Service Technician" maintenance log

Page 9

DESCRIPTION

OI c5 eng V9 / 18.08.2006 1 - 1 © Cafina / Melitta

1 Description

1.1 Design

1.1.1 External parts

1 Installed EF milk cooler

2 Bean hoppers 1 and 2

3 Temperature regulator unit

4 Filling chute with lid

5 Liquid crystal display

6 Control panel cover

7 Shift/Stop button

8 Beverage selection buttons

9 Hot water button

10 Steam tap

11 Beverage outlet, height-adjustable

12 Drip tray with drip grille

13 Steam outlet

14 Milk cooler door

15 c5 coffee maker

16 cw cup warmer

17 "Key card" slot

18 Coffee dregs drawer

19 Hot water outlet

20 Power switch for cw cup warmer

21 Cleaning container

22 COMBI-Tabs container

23 AMC powder bag

3 4

7 8

9 10

13 14

Page 10

DESCRIPTION

1.1.2 Internal parts

1 Liquid crystal display

2 Shift/Stop button

3 Buttons [ + , - ]

4 Navigation buttons [ !

, " , # , $ ]

5 Milk level monitoring

6 Milk container

7 Milk intake lines

Page 11

DESCRIPTION

OI c5 eng V9 / 18.08.2006 1 - 3 © Cafina / Melitta

1.2 Mode of operation

1.2.1 c5 coffee maker

The c5 coffee maker is a fully automatic coffee making machine which, in the basic version, can dispense pre-programmed coffee products through a height-adjustable product outlet into the container. The beverage required is selected via five beverage selection buttons.

The beverage selection buttons employ a click pushbutton design that provides both tactile and visual feedback. Large, illuminated product fields indicate the beverage currently selected.

A filling chute enables pre-ground, decaffeinated varieties of coffee to be processed.

The c5 coffee maker exhibits the latest marks of conformity, indicating that it satisfies the necessary certification standards.

For hot milk processing with integrated, fully automatic cleaning, the c5 coffee maker satisfies the HACCP hygiene requirements.

The patented, Automatic Coffeequality System (ACS) quality monitoring system continually monitors relevant parameters such as fineness of grind, coffee powder weighed-in quantity, infusion time and water temperature.

The piston system is optimally controlled via a Variable Pressure System (VPS).

The water supply can be directly connected to the water mains or to a water can.

1.2.2 "Installed EF milk cooler" option

The installed EF milk cooler consists of a compressor cooling unit, a separate pump system, a temperature regulator unit and a 6 litre capacity milk container.

The milk is automatically added to the relevant coffee products. The milk cooler door can be lockable.

1.2.3 "External FC milk cooler" option

The external FC milk cooler consists of an industry-standard refrigerator.

If the c5 coffee maker is fitted with an additional external FC milk cooler, the c5 coffee maker will contain an extra pump system for the automatic addition of milk into the relevant coffee products.

1.2.4 "Draw hot water" option

It is possible to draw hot water in user-defined quantities by pressing a button.

1.2.5 "Draw steam" option

Steam can be drawn from the steam tap, and is continuously adjustable.

Page 12

DESCRIPTION

1.2.6 "cw cup warmer" option

The autonomous cw cup warmer has three levels with built-in heating elements.

1.2.7 "Second coffee bean grinder" option

The second coffee bean grinder option allows a second variety of coffee to be used. Without this option, the second bean hopper is locked.

1.2.8 "Raised bean hopper" option

A higher been hopper (a unit) can be placed on top of the bean hopper(s) to increase the coffee bean capacitiy.

1.2.9 "Bean hopper lockable" option

Lockable versions of both the standard and raised bean hoppers are available.

1.2.10 "Milk level monitoring" option

Milk level monitoring is used in conjunction with the installed EF milk cooler. It is coupled to the c5 coffee maker control system.

Warnings on the LCD enable the user to keep an eye on the level of milk while the machine is in operation.

1.2.11 "Raised feet" option

To clean the area underneath the machines, all the machines can be fitted with raised feet.

1.2.12 "Waste water container level monitoring" option

If the c5 coffee maker is connected to fresh water and waste water cans, it is possible to monitor the level of the waste water can (see also section «5.2 Water connection, 5 - 4»). The level monitoring is coupled to the control system. The control system outputs level-specific information to the LCD.

1.2.13 Shift function

The five beverage selection buttons are allocated as standard at two levels with one pre-programmed beverage per level in each case.

The Shift function switches the beverage selection buttons to the second level and back again.

1.2.14 TWIN function

Normally, one pass of coffee grinding with subsequent infusion operation produces a single quantity of the selected coffee (coffee + milk) product.

With the TWIN function, one pass of coffee grinding with one subsequent infusion operation produces a double quantity of the selected coffee (coffee + milk) product.

The TWIN function has to be activated by the Technical Customer Service.

Page 13

DESCRIPTION

OI c5 eng V9 / 18.08.2006 1 - 5 © Cafina / Melitta

1.2.15 Key cards

Key cards are needed to access the functions of the c5 coffee maker.

Functions such as switch on/switch off, counter readout or programming can only be used if one has the relevant authorised key card.

1.2.15.1 "user" key card

The "user" key card is the card of the person who operates the c5 coffee maker. This card can be configured as a multi-user card for up to six c5 coffee makers.

1.2.15.2 "manager" key card

The "manager" key card is the card of the person (manager), who uses this card to gain access to the higher-level functions. This card can be configured as a multi-user card for up to six c5 coffee makers.

1.2.15.3 "memory" key card

The "memory" key card contains all the system data for the c5 coffee maker, as it was configured at the time of (first) installation by the service technician.

The "memory" key card enables the coffee maker to be reset following an emergency.

1.2.15.4 "free vend" key card

The "free vend" key card enables beverages to be dispensed at no charge, using external billing modules.

1.2.15.5 "vip" key card

The "vip" key card enables the self-service mode to be enabled or disabled without having to delve into the programming of the c5 coffee maker.

1.2.15.6 "external" key card

The "external" key card enables external modules, such as coin-operation units or coin-checking devices, to be enabled or disabled without having to delve into the programming of the c5 coffee maker.

1.2.15.7 "key lock" key card

The "key lock" key card enables the control buttons to be locked or released without having to delve into the programming of the c5 coffee maker.

1.2.15.8 "engineer" key card

The "engineer" key card is reserved for the service technician. It allows the technician to access every area of the system software, read the statistical data and directly control hardware components for test purposes.

Page 14

DESCRIPTION

1.3 Technical data

1.3.1 Coffee maker types

( 1 ) Hot water drawn through the coffee outlet

( 2 ) Coffee and hot water dispensed simultaneously

( 3 ) Coffee, hot water and steam dispensed simultaneously

Standard options

The following options can be used with every machine configuration:

- "cw cup warmer"

- "Bean hopper" (optionally lockable)

- "Second coffee bean grinder"

- "Raised bean hopper" (optionally lockable)

- "Raised feet"

The milk cooler door of the installed EF milk cooler is available in a lockable version.

Description Standard

model

Shift

function

TWIN

function

Hot water

outlet

Steam

outlet

Separate hot

water outlet

Installed EF

milk cooler

External FC

milk cooler

Milk level

monitoring

c5-1 X X X

c5 Office X

( 1 )

X X X Optional

c5-1 W X X X X X

c5-1 C X X X X X X

c5-12 W X

( 2 )

X X X X

c5-1 C EF X X X X X X X Optional

c5-12 C X

( 3 )

X X X X X

c5-12 C EF X

( 3 )

X X X X X X Optional

c5-1 C FC X X X X X X X

c5-12 C FC X

( 3 )

X X X X X X

Page 15

DESCRIPTION

OI c5 eng V9 / 18.08.2006 1 - 7 © Cafina / Melitta

1.3.2 Machine identification

Position of identification plate

• c5 coffee maker

Switzerland and EU: Behind the coffee dregs drawer in the slide-in tray, at the top of the inside wall.

USA: On the front left-hand side.

• Installed EF milk cooler

Switzerland, EU: In the chill compartment at the top lefthand side of the inside wall.

• cw cup warmer

Switzerland, EU and USA: In the lower cup compartment at the top of the back wall.

1.3.2.1 Switzerland

1.3.2.2 Export

CH-5502 HUNZENSCHWIL

Type

Instr. sheet Model year

Serial-No.

Model year

Serial-No.

CH-5502 HUNZENSCHWIL

Water lowest level

Max. temperature

Max. overpressure

Heater power

Serial-No.

Test overpressure and design comply with the Ordinance on Steam Boilers

Through heater Boiler

liters

°C

bar

Type

Page 16

DESCRIPTION

1.3.3 Dimensions and weights

1.3.4 Filling data

Description Width [ mm ] Height [ mm ] Depth [ mm ] Weight [ kg ]

c5-1 450

680 600

c5 Office 450 49

c5-1 W 450 50

c5-1 C 450 50

c5-12 W 450 58

c5-1 C EF 700 90

c5-12 C 450 58

c5-12 C EF 700 94

c5-1 C FC 450 53

c5-12 C FC 450 61

cw 250 12

EF 250 26

Raised bean hopper 140

Raised feet 25.4 ( 1" )

50.8 ( 2" )

76.2 ( 3" )

101.6 ( 4" )

Description Coffee

beans:

first

bean

hopper

[ kg ]

Coffee beans:

second

bean

hopper

[ kg ]

Number

of cups which

can be

accommodated

Standard

size

Number

of cups which

can be

accommodated

Espresso

size

Refilling the

milk container

[ litres ]

Refilling the

canisters

[ litres ]

c5-1

1.4 1.4 8 20

c5 Office

c5-1 W

c5-1 C

c5-12 W

c5-1 C EF 6

c5-12 C

c5-12 C EF 6

c5-1 C FC

c5-12 C FC

Water intake

(fresh water container)

Water outlet

(waste water container)

cw Approx. 100 (mixed)

EF 6

Raised

bean hopper

+ 1.6 + 1.6

Page 17

DESCRIPTION

OI c5 eng V9 / 18.08.2006 1 - 9 © Cafina / Melitta

1.3.5 Operating performance data

1.3.6 Environmental conditions

1.3.6.1 Temperature and humidity

! Operating and storage temperatures:

min. + 5 °C max. + 30 °C

! Operating and storage humidity:

max. 80 %

1.3.6.2 Space requirements

! Minimum space required for operation:

180 mm from the top edge of the bean hopper must be kept clear to allow for replenishment of beans.

Description White coffee:

c5 output [ kW ] = standard cups / h

Espresso:

c5 output [ kW ] =

Espressos / h

Cappuccino:

c5 output [ kW ] =

Cappuccinos / h

Hot water:

c5 output [ kW ] =

litres / h

c5-1 2.3 kW = 170

3.4 kW = 200

2.3 kW = 250

3.4 kW = 250

c5 Office 2.3 kW = 170

3.4 kW = 200

2.3 kW = 250

3.4 kW = 250

c5-1 W 2.3 kW = 170

3.4 kW = 200

2.3 kW = 250

3.4 kW = 250

c5-1 C 6.0 kW = 200

3.6 kW = 170

6.0 kW = 250

3.6 kW = 250

6.0 kW = 30

3.6 kW = 20

c5-12 W 7.4 kW = 200 7.4 kW = 250 7.4 kW = 40

c5-1 C EF 6.1 kW = 200 6.1 kW = 250 6.1 kW = 200 6.1 kW = 30

c5-12 C 7.4 kW = 200 7.4 kW = 250 7.4 kW = 40

c5-12 C EF 6.1 kW = 200

7.5 kW = 200

6.1 kW = 250

7.5 kW = 250

6.1 kW = 200

7.5 kW = 200

6.1 kW = 30

7.5 kW = 40

c5-1 C FC 6.0 kW = 200 6.0 kW = 250 6.0 kW = 200 6.0 kW = 30

c5-12 C FC 7.4 kW = 200 7.4 kW = 250 7.4 kW = 200 7.4 kW = 40

Page 18

DESCRIPTION

Page 19

SAFETY INSTRUCTIONS

OI c5 eng V9 / 18.08.2006 2 - 1 © Cafina / Melitta

2 Safety instructions

2.1 Warnings

2.1.1 Warnings symbols used (depending on nationality)

The following warnings symbols may be affixed to the equipment.

2.1.2 Places where warning symbols are affixed (depending on nationality)

2.1.3 Safety information in these Operating Instructions

In these Operating Instructions, you will find the following three levels of safety information:

! Level 1

Low voltage

• Warning of dangerous elec-

trical voltage.

• Electric shocks can lead to

serious injury or death.

• Only authorised technical

personnel may perform work on electrical installations.

• The technical safety instruc-

tions must be followed.

• Unplug equipment before

carrying out any work on electrical installations.

Hot surface / hot internal components

• Warning of heat which could

lead to injury.

• Allow hot surfaces and com-

ponents to cool before carrying out any work on these component parts.

• If necessary, wear heat-re-

sistant gloves.

NOTE

• The equipment comes sup-

plied with warning symbols (stickers) affixed wherever appropriate.

• If any of the warning sym-

bols should fall off during operation or following cleaning work, the operator must stick these warning symbols back again immediately.

WARNING

• A warning refers to signifi-

cant hazards. Failure to follow the relevant safety instruction could lead to injury or death.

Page 20

SAFETY INSTRUCTIONS

Depending on the type of danger, instead of STOP, one of the following symbols could be combined with the word WARNING.

! Level 2

! Level 3

2.2 Basic safety instructions

2.2.1 Proper use

2.2.1.1 General

Proper use includes, in addition to the specific provisions set out below, observing these Operating Instructions and complying with the supplier’s obligatory maintenance and repair instructions.

2.2.1.2 c5 coffee maker

The c5 coffee maker is used solely to dispense coffee products, coffee and milk combined products, hot water, steam and to heat and froth milk.

No other use of the c5 coffee maker will be deemed to be proper.

2.2.1.3 Installed EF milk cooler

The installed milk cooler is used exclusively to keep milk cold.

No other use of the installed EF milk cooler will be deemed to be proper.

2.2.1.4 cw cup warmer

The cw cup warmer is intended solely to keep cups warm.

No other use of the cw cup warmer will be deemed to be proper.

WARNING

• Warning of electric shock.

WARNING

• Warning of heat.

CAUTION

• The CAUTION symbol

stresses important instructions. Failure to observe these instructions could lead to damage to the equipment or to other material assets.

NOTE

• Notes contain additional in-

formation aimed at raising the general level of safety and at lightening the user’s workload.

Page 21

SAFETY INSTRUCTIONS

OI c5 eng V9 / 18.08.2006 2 - 3 © Cafina / Melitta

2.2.2 Specific hazards and instructions

2.2.2.1 c5 coffee maker

WARNING

• Never insert either the

hands or any rod-shaped object into a bean hopper or into the filling chute while the c5 coffee maker is connected to the mains power supply.

• Only coffee beans may be

introduced to the bean hopper.

• Only ground coffee may be

introduced to the filling chute.

WARNING

• When handling the combi-

nation cleaning tablets "COMBI-Tabs", the manufacturer’s warnings and instructions that are printed on the cleaning tablet container must be observed and complied with.

WARNING

• When handling the AMC

powder, the manufacturer’s warnings and instructions that are printed on the bag must be observed and complied with.

WARNING

• Hot air comes out from the

bottom of the steam outlet. There is a danger of scalding.

• The bottom of the steam

pipe is hot after it has been giving off steam. There is a danger of burns.

• Hot liquid comes out from

the bottom of the beverage outlet. There is a danger of scalding.

• Hot liquid comes out from

the bottom of the hot water outlet. There is a danger of scalding.

• The bottom of the hot water

outlet is hot after it has been dispensing liquid. There is a danger of burns.

WARNING

• Never interfere with the

electricity supply connection or modify it. This could result in fatal injury.

• Never remove the screw-

mounted covers. There is a danger of fatal injury upon contact with live components.

Page 22

SAFETY INSTRUCTIONS

NOTE

• Regardless of type configu-

ration, the c5 coffee maker should not be used in large kitchens.

• Electrical equipment which

does not have adequate electro-magnetic protection should not be operated close to the c5 coffee maker or the installed EF milk cooler.

• The drip tray serves solely

to collect drip water. It must not be used as a sink.

CAUTION

• Never interfere with the wa-

ter mains connection or modify it. There is a danger of flooding.

• The c5 coffee maker must

be disconnected from the water supply after it has been switched off, e.g. for the overnight period of inactivity, i.e. it is imperative that the tap is closed.

• Only operate the c5 coffee

maker in covered locations, avoid places where there is a risk of water splash. There is a risk of damage.

CAUTION

• Never spray the c5 coffee

maker with a water hose during cleaning. There is a risk of damage.

• Always empty the coffee

dregs drawer in the correct manner. There is a danger of overflow.

• Always insert the key card

dry and in the correct position into the slot. Do not insert any foreign objects or chip cards for other systems into the slot. There is a risk of damage.

• Do not leave key card in the

slot during operation.

• If the internal relieve pres-

sure valve is actuated due to excessive pressure or temperature increase, switch the c5 coffee maker off immediately. Secure the c5 coffee maker against unintentional switching on and report to Customer Support.

Page 23

SAFETY INSTRUCTIONS

OI c5 eng V9 / 18.08.2006 2 - 5 © Cafina / Melitta

2.2.2.2 Installed EF milk cooler 2.2.2.3 cw cup warmer

WARNING

• Never interfere with the

electricity supply connection or modify it. This could result in fatal injury.

• Never remove the screw-

mounted covers. There is a danger of fatal injury upon contact with live components.

CAUTION

• Only use the milk container

supplied and always keep it clean. There is a hygiene risk.

• When refilling with milk,

always use pre-cooled milk that is no hotter than 1 - 5 °C. There is a hygiene risk.

• When refilling with milk, cov-

er the lip seals on the inside of the milk cooler door with a cloth. If any milk is left in the lip seals, there is a hygiene risk.

• Always close the milk cooler

door. There is a hygiene risk.

WARNING

• Never interfere with the

electricity supply connection or modify it. This could result in fatal injury.

• Always check that the power

switch is working properly. The signal lamp must be illuminated.

• Never remove the screw-

mounted covers. There is a danger of fatal injury upon contact with live components.

WARNING

• The surfaces of the cup stor-

age area are heated. There is a danger of burns to the skin if touched for a prolonged period.

CAUTION

• Only operate the cw cup

warmer in covered locations, avoid places where there is a risk of water splash. There is a risk of damage.

• Never spray the cw cup

warmer with a water hose during cleaning. There is a risk of damage.

Page 24

SAFETY INSTRUCTIONS

2.2.2.4 Key cards

2.2.3 Personal safety

CAUTION

• Keep key cards dry, cool

and in the plastic pockets provided for this purpose. There is a risk of damage.

• Never put a key card on a

hot surface or expose to direct sunlight. There is a risk of damage.

• Never put a key card down

in an environment where there is a risk of water splash. There is a risk of damage.

• Always clean key cards in-

cluding chip contacts with a clean, slightly moist cloth without using any household cleaner. There is a risk of damage.

• Never bend or fold a key

card or use it as a tool. There is a risk of damage.

• In an environment that is

likely to be electrostatic, always ensure that you have earthed yourself (e.g. by touching a radiator) before handling a key card. There is a risk of damage.

WARNING

If handled improperly, the equipment could cause serious or fatal injury.

Anyone using and maintaining the equipment must be trained in the correct handling of the equipment and must have read and understood the safety instructions in these Operating Instructions before starting to use or maintain the equipment.

WARNING

Never modify or remove any safety mechanisms.

Do not disable any safety mechanisms by modifying the equipment.

If there are any warning symbols affixed to the equipment (dependent on nationality), never remove these. Replace any lost or defective warnings symbols immediately.

WARNING

Never operate the equipment in a damaged condition.

Report any irregularities to your superior immediately, especially if they affect safety.

Page 25

SAFETY INSTRUCTIONS

OI c5 eng V9 / 18.08.2006 2 - 7 © Cafina / Melitta

2.3 Safety mechanisms

As well as the warning symbols (dependent on nationality) affixed to the equipment, the equipment also has several active safety mechanisms.

2.3.1 Power switch

- c5 coffee maker power switch.

Activation with key card.

- cw cup warmer power switch (toggle

switch with integrated light)

2.3.2 Pressure relief valve

The c5 coffee maker is equipped with internal pressure relief valves which monitor the flow heater pressure and the boiler pressure.

2.4 Authorised persons

2.4.1 General

Only persons who are authorised to do so may work on or with the equipment.

A person is deemed to be authorised if he/ she satisfies the minimum training and knowledge requirements listed in this chapter and has been assigned a fixed area of responsibility.

2.4.2 Areas of responsibility of personnel

2.4.2.1 Operator

As the most senior person from the legal point of view, the operator is responsible for the proper use of the equipment and for the training and deployment of authorised personnel.

He records the competencies and of authorised persons, including whether they have the authority to give orders, for his business.

His tasks include the following:

- He sets or resets the equipment to the

beverages that are currently to be dispensed, if he wishes to dispense different beverages than those that the supplier configured upon delivery or installation of the equipment.

Page 26

SAFETY INSTRUCTIONS

2.4.2.2 User

He is responsible for the following tasks:

- He adjusts the equipment to the bever-

ages currently to be dispensed.

- He loads the equipment with the bever-

ages to be handled.

- He starts the equipment up and moni-

tors it.

- He cleans and services the equipment

in accordance with the work described in chapters «6 Maintenance, 6 - 1» and «7 Troubleshooting, 7 - 1».

- He pinpoints problems and organises

problem rectification.

2.4.2.3 Maintenance personnel (service technician)

He is responsible for the following tasks:

- He services and repairs the equipment

in accordance with the work described in chapters «6 Maintenance, 6 - 1» and «7 Troubleshooting, 7 - 1».

- He takes the equipment apart, stores it

and disposes of it.

2.4.3 Minimum training and qualifications of authorised personnel

2.4.3.1 Operator

- He has a commercial background and

performs a managerial function.

- He has specialist experience in risk as-

sessment and staff management.

- He has read and understood chapter

«2 Safety instructions, 2 - 1».

2.4.3.2 User

This is a person who has been instructed in how to use the equipment and is aware of the hazards that exist.

2.4.3.3 Maintenance personnel (service technician)

These are people who have completed specialist vocational training, are familiar with maintenance of the equipment and through their work they have acquired the skills needed.

Maintenance work on the mechanical and electrical aspects of the equipment may only be carried out by Customer Support.

2.5 Maintenance duty

The operator has an obligation to maintain and clean the equipment at regular intervals.

- to operate the equipment only in a fully

operational and undamaged condition;

- to use only OEM consumables and

spare parts;

- to test the security mechanisms to en-

sure that they are working properly following any maintenance or repair work (see section «2.3 Safety mechanisms, 2 - 7»).

2.6 Availability of these Operating Instructions

A copy of these Operating Instructions in the vicinity of the equipment must be available to staff using the equipment at all times.

Page 27

CONTROLS AND INDICATORS

OI c5 eng V9 / 18.08.2006 3 - 1 © Cafina / Melitta

3 Controls and

indicators

3.1 Overview

Steam tap, can be swivelled 90°

2 Product fields,

top line level 1, bottom line level 2

3 Control panel cover,

can be swivelled upwards, underneath it are the navigation and "+ / -" buttons.

4 LCD,

text display on two lines

5 Filling chute with lid,

chute for "decaffeinated" coffee powder

6 Bean hopper cover

7 Shift/Stop button,

level change in dispensing of beverages, acknowledgement function in the programming

8 Beverage selection buttons,

dual assignment for dispensing of beverages, selection and modification function in the programming (only topmost and bottom-most beverage selection buttons)

9 Power switch for cw cup warmer

10 Hot water button

11 Pull-out coffee dregs drawer

12 Beverage outlet, height-adjustable

13 Drip grille

14 Milk cooler door

15 Digit light spot "setting mode"

16 Above: "Compressor" symbol,

below: digit light spot

17 Rocker switch

18 ENTER function

19 UP function

20 DOWN function

21 Display (3 digits)

1 2

3 4

10 11

16 17

18 19

20 21

Page 28

CONTROLS AND INDICATORS

3.2 Operating modes

Operating mode (incl. sample display)

Description

In operation In this condition, the c5 coffee maker is connected to the power supply

and water mains or to the canisters.

There are no restrictions on the dispensing of beverages.

Out of order (de-energised)

In this condition the c5 coffee maker is disconnected from the power supply and water mains but is still connected to the canisters.

It is not possible to dispense any beverages.

Operation with critical problem

In this condition, the c5 coffee maker is connected to the power supply and water mains or to the canisters.

It is not possible to dispense any beverages.

Operation with non-critical problem

In this condition, the c5 coffee maker is connected to the power supply and water mains or to the canisters.

There are restrictions on the dispensing of beverages.

"Stand by" operation (switched off)

In this condition, the c5 coffee maker is connected to the power supply and water mains or to the canisters.

It is not possible to dispense any beverages.

Select beverage

DPxx

Select beverage Error coffee part DP16

c5 12:10 14.06.2004

Page 29

INITIAL START-UP

OI c5 eng V9 / 18.08.2006 4 - 1 © Cafina / Melitta

4 Initial start-up

4.1 Normal initial start-up

4.1.1 c5 coffee maker

Normal initial start-up assumes that the c5 coffee maker is connected to the mains power supply.

Once the coffee bean level and the water connection have been checked, the c5 coffee maker can be switched on.

4.1.2 Installed EF milk cooler

Normal initial start-up assumes that the installed EF milk cooler (together with the c5 coffee maker) are connected to the mains.

Once the full milk container has been inserted, the installed EF milk container is ready for operation.

4.1.3 cw cup warmer

The machine is started up normally by pressing the power switch.

The cw cup warmer is ready for operation once it has been filled with cups.

4.2 Return to service after the machine has been out of service for a limited time

4.2.1 c5 coffee maker

Initial start-up after the machine has been out of service for a limited time assumes that the c5 coffee maker will normally have been disconnected from the mains.

After the machine has been connected to the mains and the coffee bean level and water connection have been checked, the c5 coffee maker can be switched on. It is recommended carrying out the cleaning procedure described in section «6.2.2.1 c5 coffee maker, 6 - 5» immediately after switching on.

4.2.2 Installed EF milk cooler

Initial start-up after the machine has been out of service for a limited time assumes that the installed EF milk cooler (together with the c5 coffee maker) will normally have been disconnected from the mains. Once the machine has been connected to the mains power supply and the full milk container has been inserted, the installed EF milk cooler is switched on. It is recommended carrying out the cleaning procedure described in section «6.2.2.2 Installed EF milk cooler / external FC milk cooler, 6 - 7» immediately after switching on.

4.2.3 cw cup warmer

If the plug for the cw cup warmer has been pulled out of the socket, it must be plugged into the socket first. To start the machine for the first time after it has been out of service for a limited time, press the power switch. The cup warmer is ready for operation once it has been filled with cups.

Page 30

INITIAL START-UP

4.3 Return to service after a fault

4.3.1 c5 coffee maker

Normal initial start-up after a failure assumes that the c5 coffee maker has not been disconnected from the mains.

Before the c5 coffee maker can be operational again, the fault must have been cleared in accordance with chapter «7 Troubleshooting, 7 - 1».

4.3.2 Installed EF milk cooler

Normal initial start-up after a failure assumes that the installed EF milk cooler (together with the c5 coffee maker) have not been disconnected from the mains.

Before the installed EF milk cooler can be operational again, the fault must have been cleared in accordance with chapter «7 Troubleshooting, 7 - 1».

4.3.3 cw cup warmer

The cw cup warmer does not have any fault-monitoring software.

After a fault, the plug for the cw cup warmer must be re-inserted into the socket and the power switch activated.

Page 31

OPERATION

OI c5 eng V9 / 18.08.2006 5 - 1 © Cafina / Melitta

5 Operation

5.1 Power supply connection

Connection to the power supply is a matter for the installation company and is taken for granted below.

5.1.1 c5 coffee maker

The c5 coffee maker is permanently connected to the power supply during normal operation.

Depending on the form of the power connection, the c5 coffee maker is disconnected from the power supply via power plug and socket or, in the case of a permanent connection, via a switch on the mains.

5.1.2 Installed EF milk cooler

The installed EF milk cooler is connected to the mains power supply via the c5 coffee maker.

If the coffee maker, having been connected to the mains, is then disconnected from the mains, the installed EF milk cooler will be deactivated accordingly.

5.1.3 cw cup warmer

The cw cup warmer is connected to the power supply independently of the "c5 coffee maker / installed EF milk cooler" unit.

The cw cup warmer is connected to the power supply via the toggle switch and is switched off by this means.

NOTE

• The c5 coffee maker does

not have a power switch of its own.

NOTE

• The EF installed milk cooler

does not have a power switch of its own.

NOTE

• The cw cup warmer has a

separate power switch.

Page 32

OPERATION

5.1.4 Temperature regulator unit

5.1.4.1 Control panel

1 Digit light spot "setting mode"

2 Above: "Compressor" symbol,

below: digit light spot

3 Rocker switch

4 ENTER function

5 UP function

6 DOWN function

7 Display (3 digits)

5.1.4.2 Brief description

The temperature regulator unit controls the compressor for the installed EF milk cooler. During operation, the display shows the approximate actual temperature of the milk in the milk container. The actual milk temperature is taken from the plate on which the milk container stands.

5.1.4.3 Cooling operation

The digit light spot beneath the "Compressor" symbol is illuminated as long as the compressor is in operation.

2 3

4 5

6 7

NOTE

• Pre-cooled milk that is no

hotter than 1 - 5 °C should be used. See also section «5.5.4 Refill milk, 5 - 22».

• The temperature indicator

on the display shows the approximate actual temperature of the milk in the milk container, not the internal temperature of the installed EF milk cooler.

NOTE

• The compressor is switched

on by the temperature regulator unit when the actual milk temperature is 2 °C above the setting for the desired milk temperature.

Page 33

OPERATION

OI c5 eng V9 / 18.08.2006 5 - 3 © Cafina / Melitta

5.1.4.4 Checking the desired milk temperature

1. Press ENTER for approx. 2 seconds ...

- On the display, the word "SET" will appear.

2. Press ENTER a second time, but this

time only briefly ...

- The digit light spot "Setting mode" will flash for approx. 12 seconds.

- On the display, the desired milk temperature will appear.

3. Press ENTER for approx. 2 seconds or

wait until the digit light spot "Setting mode" stops flashing.

5.1.4.5 Programming the desired milk temperature

1. Press ENTER for approx. 2 seconds ...

- On the display, the word "SET" will appear.

2. Press ENTER a second time, but this

time only briefly ...

- The digit light spot "Setting mode" will flash for approx. 12 seconds.

- On the display, the current desired milk temperature will appear.

- To set the desired milk temperature, press the UP / DOWN buttons as required.

3. Press ENTER for approx. 2 seconds or

wait until the digit light spot "Setting mode" stops flashing.

- The desired milk temperature is now set, and the approximate actual milk temperature is indicated on the display.

NOTE

• Alternative settings for the

desired milk temperature will be found in the separate specification for the temperature regulator unit.

NOTE

• Factory setting: 5 °C

• Adjustment range:

between 3 °C and 6 °C

Page 34

OPERATION

5.2 Water connection

Connection to the water mains is a matter for the installation company and is taken for granted below.

5.2.1 Water intake

The c5 coffee maker is supplied with water from ...

! ... the mains water supply, with perma-

nent connection to the pipe system.

! ... from a fresh water canister with de-

tachable hose coupling.

5.2.2 Water drainage

Water is drained from the c5 coffee maker ...

! ... into the waste water system, with

permanent connection to the pipe system.

! ... into a waste water canister fitted with

a cap with a hole in it.

! ... into a wastewater canister in combi-

nation with the "Waste water container level monitoring" option (hose is placed above the connection pipe).

CAUTION

• It is not permissible to com-

bine a permanent connection to the mains water supply with the use of a waste water canister.

• Ideally, either "permanent

connection to permanent connection" or "canister to canister" should be used as the connection type.

• The "Waste water container

level monitoring" option can reduce the risk of overflows.

Page 35

OPERATION

OI c5 eng V9 / 18.08.2006 5 - 5 © Cafina / Melitta

5.3 Switching on and off

5.3.1 Switching on the c5 coffee maker

When the c5 coffee maker is switched on, it moves from "standby" to operating mode.

None of the product fields are lit up.

1. Turn on the tap.

2. Insert "user" / "manager" key card and

then remove.

3. This c5 coffee maker heats up. The

second line flashes.

4. After the c5 coffee maker has heated

up, the "Refill milk" prompt will appear. You should now fill it up with milk, i.e. replenish with milk if the milk level is too low, or else insert the milk container.

5. All five product fields are illuminated.

The c5 coffee maker is now ready to dispense beverages.

NOTE

• The c5 coffee maker has a

"standby" operating mode.

• The installed EF milk cooler

is set to "standby" or operating mode at the same time as the c5 coffee maker.

c5 10:25 14.06.2004

" #

NOTE

• Move steam and hot water

outlets to the vertical position.

• Close steam tap tightly.

• Pull beverage outlet right

down. Hot water and steam will come out.

TURN ON prog. 86 °C act.

TURN ON Steam temp. too low

Select beverage Refill milk

Select beverage

Page 36

OPERATION

5.3.2 Switching off the c5 coffee maker

When the c5 coffee maker is switched off, it moves from operating mode to "standby" mode.

It can be switched off in the following ways, provided that "yes" is selected.

! No beverages have been dispensed

since the last switch-on:

The c5 coffee maker goes straight to "standby" mode without the cleaning procedure.

! Only coffee or only milk beverages

have been dispensed since the last switch-on:

The c5 coffee maker runs through the relevant cleaning procedure and then goes to "standby" mode.

! Both coffee and milk beverages have

been dispensed since the last switchon:

The c5 coffee maker runs through the full cleaning procedure and then goes to "standby" mode.

NOTE

• The c5 coffee maker has a

"standby" operating mode.

• The installed EF milk cooler

is set to "standby" or operating mode at the same time as the c5 coffee maker.

NOTE

• Details on the cleaning

procedure can be found in

sections «6.2.2.1 c5 coffee maker, 6 - 5» and «6.2.2.2 Installed EF milk cooler / external FC milk cooler, 6 - 7».

CAUTION

• Waste water canister almost

or completely full?

• Depending on the cleaning

procedure, the throughput of water may be high. If the waste water canister has little remaining capacity, it could overflow.

• Check waste water canister

prior to switching off the machine!

OFF after cleaning? [1]yes [5]no

Page 37

OPERATION

OI c5 eng V9 / 18.08.2006 5 - 7 © Cafina / Melitta

We now describe as an example how the machine is switched off after both coffee and milk beverages have been dispensed in the operating mode.

1. Insert "user" / "manager" key card and

then remove.

2. Before switching off, the cleaning

process starts up. (For details, see also section «6.2.2 Cleaning procedure, 6 - 4»).

Tell the c5 coffee maker to switch off after the cleaning process.

For "yes", press the topmost beverage selection button [ ].

3. You will now be prompted to empty the

coffee dregs drawer.

Pull out the coffee dregs drawer so that you can empty it. The following message appears ...

Push the empty coffee dregs drawer back in. The following message appears ...

4. Now press the Shift/Stop button [ ]

on the control panel.

NOTE

•

Coffee system: Only use combination cleaning tablets "COMBITabs".

• Get out two combination cleaning

tablets "COMBI-Tabs" or one combination cleaning tablet "COMBI-Tabs" and a AMC powder bag.

• Get the cleaning container.

Select beverage

" #

OFF after cleaning? [1]yes [5]no

Empty drawer!

Drawer missing!

Drawer emptied Please confirm (

)

Page 38

OPERATION

Now empty the milk, i.e. replace the milk container with the empty cleaning container (into which you have placed one combination cleaning tablet "COMBI-Tabs" or the content of a AMC powder bag). Leave the milk cooler door open.

5. Now press the Shift/Stop button [ ]

on the control panel.

The following message appears during the rinse operation ...

The cover of the filling chute folds open. Now insert the other combination cleaning tablet "COMBI-Tabs" in the filling chute.

6. Now press the Shift/Stop button [ ]

on the control panel.

7. The following message appears ...

8. When the cleaning process has

finished, the following message appears ...

Take the cleaning container out of the installed EF milk cooler.

The c5 coffee maker is switched off.

9. Turn off the tap.

5.3.3 Switching the cw cup warmer on and off

The cw cup warmer is switched on and off via the illuminated toggle switch.

Insert the cleaning container

Please confirm (SH)

Rinsing

Put cleaning agent in Please confirm (

)

Cleaning

Cleaning milk

NOTE

• The cw cup warmer does

not have a "standby" mode. It is always switched to full heat output.

c5 12:10 14.06.2004

Page 39

OPERATION

OI c5 eng V9 / 18.08.2006 5 - 9 © Cafina / Melitta

5.4 Dispensing of beverages

5.4.1 Dispensing normal coffee

The following description of how to dispense beverages assumes the following allocation to the beverage selection buttons:

Product fields from top to bottom ...

Espresso [ ] Ristretto

Coffee Cream [ ] Coffee Special

Cappuccino [ ] Macchiatto

Cup of [ ] cold milk

Hot milk [ ] Decaffeinated

Level assignment ...

Level 1 ....... [ ]

Level 2 .......

Reference products ...

Stopping the product flow ...

You can interrupt the flow of beverage at any time by pressing the Shift/Stop button [ ], if this has been configured on the control side.

5.4.1.1 General sequence

1. Push the beverage outlet upwards.

2. Place coffee cup(s) under the bever-

age outlet.

3. Push the beverage outlet downwards

until the coffee cup(s) can be removed without having to push the beverage outlet upwards again.

4. When this message is displayed, the

coffee maker is ready to dispense beverages ...

5. Decide your beverage dispensing strat-

egy.

! Level 1 beverage

! Level 2 beverage

! One cup from a single infusion oper-

ation

! More than one cup from a single in-

fusion operation

! Two cups from a single, combined

infusion operation (TWIN function)

! Several cups (two each) from a sin-

gle, combined infusion operation (TWIN function)

6. Dispense the beverages.

NOTE

* after the product in the display means "reference product from bean hopper 1".

** after the product in the display means "reference product from bean hopper 2".

NOTE

• The TWIN function can only

be used if it has been activated by Customer Support!

Select beverage

Page 40

OPERATION

5.4.1.2 Dispensing a level 1 beverage

! You want to dispense a single shot

of the same beverage.

Dispensing information:

! One grinding operation per shot.

! One infusion operation per shot.

See also section «5.4.1.1 General sequence, 5 - 9»

1. Press beverage selection button

Espresso / Ristretto [ ] once.

The following message appears ...

2. Preparation of the beverage is initiated.

3. The beverage is dispensed.

! You want to dispense multiple shots

of the same beverage (no TWIN function).

Dispensing information:

! One grinding operation per shot.

! One infusion operation per shot.

See also section «5.4.1.1 General sequence, 5 - 9»

1. Press beverage selection button Espresso / Ristretto [ ] five times

at two-second intervals, for example. The following message appears ...

2. Preparation of the beverage is initiated.

3. The beverages are dispensed continu-

ously.

1 Espresso**

5 Espresso**

Page 41

OPERATION

OI c5 eng V9 / 18.08.2006 5 - 11 © Cafina / Melitta

! You want to dispense a double shot

of the same beverage (with TWIN function).

Dispensing information:

! One grinding operation per double

shot

! One infusion operation per double

shot.

See also section «5.4.1.1 General sequence, 5 - 9»

1. Press beverage selection button Espresso / Ristretto [ ] twice in

quick succession. The following message appears ...

2. Preparation of the beverage is initiated.

3. The two beverages are dispensed.

! You want to dispense more than one

double shot of the same beverage (with TWIN function).

Dispensing information:

! One grinding operation per double

shot

! One infusion operation per double

shot.

See also section «5.4.1.1 General sequence, 5 - 9»

1. Press beverage selection button Espresso / Ristretto [ ] four times

in quick succession, for example. The following message appears ...

2. Preparation of the beverage is initiated.

3. The two double beverages are dis-

pensed continuously.

2 Espresso

4 Espresso

Page 42

OPERATION

5.4.1.3 Dispensing a level 2 beverage

! You want to dispense a single shot

of the same beverage.

Dispensing information:

! One grinding operation per shot.

! One infusion operation per shot.

See also section «5.4.1.1 General sequence, 5 - 9»

1. Press the Shift/Stop button [ ] on

the control panel. The following message appears ...

An acoustic signal is heard. If no beverage selection button is pressed within 5 seconds, then the beverage selection will revert to level 1.

2. Press beverage selection button Espresso / Ristretto [ ] once.

The following message appears ...

3. Preparation of the beverage is initiated.

4. The beverage is dispensed.

! You want to dispense more than one

double shot of the same beverage (no TWIN function).

Dispensing information:

! One grinding operation per double

shot

! One infusion operation per double

shot.

See also section «5.4.1.1 General sequence, 5 - 9»

1. Press the Shift/Stop button [ ] on

the control panel. The following message appears ...

An acoustic signal is heard. If no beverage selection button is pressed within 5 seconds, then the beverage selection will revert to level 1.

2. Press beverage selection button Espresso / Ristretto [ ] five times

at two-second intervals, for example. The following message appears ...

3. Preparation of the beverage is initiated.

4. The beverages are dispensed continu-

ously.

Select beverage

1 Ristretto

Select beverage

5 Ristretto

Page 43

OPERATION

OI c5 eng V9 / 18.08.2006 5 - 13 © Cafina / Melitta

! You want to dispense a double shot

of the same beverage (with TWIN function).

Dispensing information:

! One grinding operation per double

shot

! One infusion operation per double

shot.

See also section «5.4.1.1 General sequence, 5 - 9»

1. Press the Shift/Stop button [ ] on

the control panel. The following message appears ...

An acoustic signal is heard. If no beverage selection button is pressed within 5 seconds, then the beverage selection will revert to level 1.

2. Press beverage selection button Espresso / Ristretto [ ] twice in

quick succession. The following message appears ...

3. Preparation of the beverage is initiated.

4. The two beverages are dispensed.

! You want to dispense more than one

double shot of the same beverage (with TWIN function).

Dispensing information:

! One grinding operation per double

shot

! One infusion operation per double

shot.

See also section «5.4.1.1 General sequence, 5 - 9»

1. Press the Shift/Stop button [ ] on

the control panel. The following message appears ...

An acoustic signal is heard. If no beverage selection button is pressed within 5 seconds, then the beverage selection will revert to level 1.

2. Press beverage selection button Espresso / Ristretto [ ] four times

in quick succession. The following message appears ...

3. Preparation of the beverage is initiated.

4. The two double beverages are dis-

pensed continuously.

Select beverage

2 Ristretto

Select beverage

4 Ristretto

Page 44

OPERATION

5.4.2 Dispensing decaffeinated coffee

As well as the nine pre-programmed beverages, which can be dispensed using the beverage selection buttons, it is also possible to dispense a tenth beverage.

This tenth product is assigned for the purposes of beverage dispensing to one overriding product from the range of beverage selection buttons.

This tenth product has to be in powder form and is inserted into the filling chute using the measuring spoon.

(For an overview see also section «5.4.1.1 General sequence, 5 - 9».)

1. When this message is displayed, the

coffee maker is ready to dispense beverages ...

2. Press the Shift/Stop button [ ] on

the control panel. The following message appears ...

An acoustic signal is heard. If no beverage selection button is pressed within 5 seconds, then the beverage selection will revert to level 1.

3. Press beverage selection button Hot milk / Decaffeinated [ ] once.

The following message appears ...

4. Shortly afterwards the following message appears ...

The lid of the filling chute opens.

5. Shortly afterwards the following message appears ...

The lid of the filling chute remains open for approx. 20 seconds.

6. Put pre-prepared powder from the measuring beaker filled up to the line into the filling chute.

7. For example, press beverage selection

button Espresso / Ristretto [ ] once. The following message appears ...

8. Preparation of the beverage is initiated.

9. The beverage is dispensed.

CAUTION

•

"Powder form" is understood to mean coffee ground from coffee beans. Different forms of coffee or other powder products than coffee must not be used.

Select beverage

Please wait

Put coffee in

Select beverage

1 Espresso**

Page 45

OPERATION

OI c5 eng V9 / 18.08.2006 5 - 15 © Cafina / Melitta

5.4.3 Dispensing milk

Depending on the configuration of the c5 coffee maker, it is possible to dispense cold or hot milk either manually or in portions.

A milk beverage selection button can only be allocated the functions of "manual" or "portion".

! Manual dispensing of milk

Keep the beverage selection button pressed down until the desired quantity of milk has been dispensed.

! Dispensing a portion of milk

Keep the beverage selection button pressed down and wait until the programmed quantity of milk has been dispensed.

An example of how a portion of hot milk is dispensed is now described.

1. Push the beverage outlet upwards.

2. Place milk jug under the beverage out-

let.

3. Push the beverage outlet downwards until the milk jug can be removed without having to push the beverage outlet upwards again.

4. When this message is displayed, the coffee maker is ready to dispense beverages ...

5. Press beverage selection button Hot milk / Decaffeinated [ ] once.

The following message appears ...

6. Preparation of the beverage is initiated.

7. The beverage is dispensed.

NOTE

• Replenishment of milk is not

allowed while "milk" is being dispensed.

• The first portion of milk

should not be used ...

- if no milk has been dispensed for over four hours.

- immediately after the machine has been started up (c5 coffee maker / installed EF milk cooler).

- in the morning, if the milk was in the installed EF milk cooler overnight.

NOTE

• Pressing the beverage se- lection button Hot milk / Decaffeinated [ ] while

the beverage is being dispensed stops the flow of beverage.

Select beverage

1 Port. hot milk

Page 46

OPERATION

5.4.4 Dispensing of hot water

Depending on the configuration of the c5 coffee maker, it is possible to dispense hot water either manually or in portions.

The hot water button can only be allocated the functions of "manual" or "portion".

! Manual drawing of hot water

Keep the hot water button [ ] pressed down until the desired quantity of hot water has been dispensed.

! Drawing a portion of hot water

Keep the hot water button [ ] pressed down and wait until the programmed quantity of hot water has been dispensed.

An example of how a portion of hot milk is drawn is now described.

1. Rotate hot water outlet to the vertical

position.

2. Place cup under hot water outlet.

3. When this message is displayed, the

coffee maker is ready to dispense beverages ...

4. Press hot water button [ ] once.

The following message appears ...

5. Preparation of the beverage is initiated.

6. The beverage is dispensed.

CAUTION

• Hot water outlet is hot.

• Danger of burns and scald-

ing.

• Be careful when touching

the hot water outlet.

NOTE

• Pressing the hot water but-

ton [ ] while the beverage is being dispensed stops the flow of beverage.

Select beverage

1 Hot water

Page 47

OPERATION

OI c5 eng V9 / 18.08.2006 5 - 17 © Cafina / Melitta

5.4.5 Drawing steam

The steam is used to heat up cold and preheated drinks.

The steam tap [ ] can be rotated up to 90° max.

Operational status of steam tap:

- Steam tap closed [ ]

- Steam tap open to the maximum possible [ ]

1. Rotate hot water outlet to the vertical

position.

2. Rotate steam tap [ ] slightly down-

wards so as to allow the condensed water that is still in the steam outlet to run off into the drip tray.

Keep the steam tap [ ] rotated until only steam comes out of the nozzle.

3. Rotate the steam tap [ ] until it is

right back in position.

4. Rotate the steam outlet forwards and

dip it into the drink that is to be heated.

With larger receptacles, moved the steam outlet together with the receptacles towards the c5 coffee maker and then place the receptacle on the drip grille.

5. Rotate steam tap [ ] downwards in

a controlled way and keep it in this position until the drink has reached the desired temperature.

If necessary, move the receptacle upwards and sideways during the heating operation.

6. Once the heating operation has fin-

ished, rotate the steam tap [ ] right back into its normal position.

7. Pull receptacle forwards and put aside.

8. Wipe steam outlet clean with a moist

cloth.

9. Rotate hot water outlet to the vertical

position.

10. Rotate steam tap [ ] slightly down-

wards so as to allow the residual fluid that is still in the steam outlet to run off into the drip tray.

CAUTION

• Steam outlet is hot.

• Danger of burns and scald-

ing.

• Be careful when touching

the hot steam outlet.

Page 48

OPERATION

5.4.6 Frothing milk manually

Steam can be used to froth milk.

The steam tap [ ] can be rotated up to 90°.

Operational status of steam tap:

- Steam tap closed [ ]

- Steam tap open to the maximum possible [ ]

1. Align steam outlet vertically.

2. Rotate steam tap [ ] slightly down-

wards so as to allow the condensed water that is still in the steam outlet to run off into the drip tray.

3. Rotate steam outlet forwards and dip

the end of the steam nozzle into the drink to be frothed right down to the bottom of the receptacle.

4. Rotate the steam tap [ ] down-

wards in a controlled way.

At the same time lower the receptacle so that the end of the steam nozzle is just above the surface of the liquid.

During the frothing operation, watch the formation of froth and continually adjust the distance between the "end of the steam nozzle and the surface of the liquid" (this will differ according to the physical properties of the steam nozzle).

5. When the desired degree of froth has

been achieved, rotate the steam tap [ ] back into its normal position (closed) to terminate the operation.

6. Pull receptacle forwards and put aside.

7. Wipe steam outlet clean with a moist

cloth.

8. Align steam outlet vertically.

9. Rotate steam tap [ ] slightly down-

wards so as to allow the residual fluid that is still in the steam outlet to run off into the drip tray.

CAUTION

• Beware hot steam outlet

and/or splash from hot milk.

• Danger of burns and scald-

ing.

• Be careful when touching

the hot steam outlet. Observe distance between end of steam nozzle and surface of liquid.

NOTE

• The milk used should be

cool so as to comply with the hygiene regulations.

Page 49

OPERATION

OI c5 eng V9 / 18.08.2006 5 - 19 © Cafina / Melitta

5.5 Routine work

5.5.1 Refilling fresh water

canister

The fresh water canister (20 litres) must be refilled at least once a day with cold, thoroughly hygienic mains water.

5.5.2 Emptying the waste water

canister

The waste water canister (10 litres) must be emptied and thoroughly rinsed at least once a day.

1. If the option "Waste water container

level monitoring" option has been selected, the following message will appear when the canister is full ...

2. Empty the waste water canister imme-

diately. The following message appears ...

Press Shift/Stop button [ ].

3. The following message appears ...

4. You can now dispense beverages as

required.

NOTE

• Never refill completely de-

calcified fresh water.

• Always take care to correct-

ly connect the rapid action coupling of the water line that runs between the fresh water canister and the c5 coffee maker.

• Fresh water pipe must not

have any kinks in it.

NOTE

• Always take care to ensure

that the waste water hose is pushed down through the hole in the cap of the waste water canister to a sufficient depth.

• If the option "Waste water

container level monitoring" was selected during installation, take care to ensure that the waste water hose fits snugly and sufficiently far on the connection pipe.

• Waste water hose must not

have any kinks in it.

NOTE

• It will not be possible to dis-

pense any further beverages using the c5 coffee maker until the waste water canister has been emptied.

Select beverage Waste water full

Waste water emptied Please confirm (

)

Select beverage

Page 50

OPERATION

5.5.3 Refill coffee beans

The bean hoppers are monitored as regards coffee bean content. If a bean hopper becomes empty, this is displayed for the relevant bean hopper during the dispensing of a beverage.

In the example below, bean hopper 1 is empty. The associated reference product is "Coffee cream*".

1. Beverage selection key Coffee cream

/ Coffee Special [ ] has been

pressed once. The following message appears ...

2. Pour coffee beans into bean hopper 1

up to about 2 cm below the bean hopper rim.

The position of bean hopper 1 is visible on the inside of the bean hopper cover.

3. Press beverage selection button Coffee cream / Coffee Special [ ]

again.

4. If bean hopper 2 is also empty, the following message will appear briefly ...

5. Preparation of the beverage is initiated.

6. The beverage is dispensed.

NOTE

• The description which fol-

lows applies by analogy to the bean hopper 2.

1 Coffee cream* Bean hopper 1 empty

NOTE

• Do not press the Shift/Stop

button or insert any key card.

1 Coffee cream* Bean hopper 2 empty

Page 51

OPERATION

OI c5 eng V9 / 18.08.2006 5 - 21 © Cafina / Melitta

In the example below, bean hopper 1 is empty. The associated reference product is "Coffee cream*".

The Shift/Stop button was pressed by mistake.

1. Beverage selection key Coffee cream / Coffee Special [ ] has been

pressed once. The following message appears ...

2. The Shift/Stop button [ ] was pressed by mistake.

3. The following message appears ...

According to the illuminated product fields, only the beverages served by bean hopper 2 and also pure milk beverages are available for selection using the relevant beverage selection buttons.

As before, there are no restrictions on the drawing of hot water and steam.

4. Pour coffee beans into bean hopper 1

up to about 2 cm below the bean hopper rim.

The position of bean hopper 1 is visible on the inside of the bean hopper cover.

5. Insert "user" / "manager" key card. The

following message appears ...

6. Remove "user" / "manager" key card.

The following message appears ...

According to the illuminated product fields, all the products are now available for selection via the associated beverage selection buttons.

7. Select beverage.

8. Preparation of the beverage is initiated.

9. The beverage is dispensed.

1 Coffee cream* Bean hopper 1 empty

Select beverage Bean hopper 1 empty

Fault confirmed

Select beverage

Page 52

OPERATION

5.5.4 Refill milk

The description of the procedure below applies to both the installed EF milk cooler and the external FC milk cooler.

! The installed EF milk cooler can option-

ally be fitted with a milk level monitoring system.

1. The following message indicates that

there is either no milk or insufficient milk or else that the milk container itself is not inside the installed EF milk cooler ...

2. Replenish milk supply. This will result

in the following message ...

3. Pull beverage outlet right down.

4. Open control panel cover and press the

[ $

] button.

A little milk will be released to fill the lines.

5. You can now dispense beverages as

required.

NOTE

•

The milk container for the installed EF milk cooler holds approx. six litres of milk.

• If the installed EF milk cooler is

fitted with milk level monitoring, then this will be activated when the milk supply in the milk container has dropped to about 1 litre or when the milk container is not in the installed EF milk cooler.

• When replenishing the milk

supply, always cover the lip seals of the milk cooler door of the installed EF milk cooler.

• The milk used to replenish

the milk container must be pre-cooled, i.e. it must not be any hotter than 1 - 5 °C. If hotter milk is used, the milk will overheat when "milky coffee" beverages are dispensed, insufficient froth will be created and it will not be possible to comply with the hygiene regulations.

• If the milk container is empty

when the machine comes to dispense beverages that include milk, the c5 coffee maker will dispense steam instead of milk.

CAUTION

• If the milk container is emp-

ty:

the addition of steam instead of milk to beverages can result in splashing of hot liquid, causing scalds.

• Replenish the milk supply

immediately.

Select beverage Refill milk

Select beverage

Please wait

Page 53

OPERATION

OI c5 eng V9 / 18.08.2006 5 - 23 © Cafina / Melitta

5.5.5 Emptying the coffee

dregs drawer

Once an infusion operation is complete, empty the resulting block of coffee dregs into the coffee dregs drawer.

Monitoring of how full the coffee dregs drawer is is based on adding up the weight of the individual blocks of coffee dregs discarded.

1. The following displays indicate how full

the coffee dregs drawer is ...

... Coffee dregs drawer 80 % full.

... Coffee dregs drawer 100 % full.

2. Push the beverage outlet all the way

up.

3. Pull out coffee dregs drawer. The fol-

lowing message appears ...

4. Empty coffee dregs drawer, clean with warm water (not with hot water from the c5 coffee maker) and dry.

5. Push coffee dregs drawer in. The following message appears ...

Press Shift/Stop button [ ].

6. The following message appears ...

7. You can now dispense beverages as

required.

NOTE

• The coffee dregs drawer is

full to capacity when it contains a weight of 0.7 kg.

When this occurs, the message "Empty drawer!" is displayed.

• The coffee dregs drawer is

80 % full when it contains a weight of 0.56 kg.

When this occurs, the message "Drawer nearly full!" is displayed.

CAUTION

• If the coffee dregs drawer

overflows, this will cause serious dirt accumulation inside the c5 coffee maker.

• Always empty coffee dregs

drawer correctly when the c5 coffee maker is switched on.

1 Coffee cream* Drawer nearly full!

Select beverage Empty drawer!

Select beverage Drawer missing!

Drawer emptied Please confirm (

)

Select beverage

Page 54

OPERATION

5.5.6 Cleaning the drip tray

The drip grille and drip tray must be cleaned at regular intervals.

1. Press the drip grille at the back right or

back left corner downwards a little.

2. Remove drip grille and clean.

3. Clean drip tray and clean out the drain

holes if they are blocked.

4. Place the drip grille in the correct posi-

tion on the drip tray, i.e. with the transverse rods underneath.

Page 55

OPERATION

OI c5 eng V9 / 18.08.2006 5 - 25 © Cafina / Melitta

5.6 System work

5.6.1 Control panel and button layout

! Liquid crystal display

- Displays information on the corresponding function.

! Navigation button [ #

]

- One level higher in the structure

- Used to confirm queries / or adjustment values

! Navigation button [ $

]

- One level down in the structure

! Navigation button [ "

]

- One position horizontally to the right in the structure

! Navigation button [ !

]

- One position horizontally to the left in the structure

! Shift/Stop button [ ]

- Not allocated

! [ + ] button

- Used to raise the adjustment value in predefined steps

- Used to enter "Yes"

! [ – ] button

- Used to lower the adjustment value in predefined steps

- Used to enter "No"

! [ ] button (no. invisible)

- 1 = "Yes" in response to textual questions

- 2 to 4 unallocated

- 5 = "No" in response to textual questions

Cards

Card handling:

1. Insert key card.

2. Wait until LCD display changes.

3. Remove key card.

! "user" key card

- Insertion of the card has the effect of switching the c5 coffee machine on or off

- Insertion of the card has the effect of granting access to basic functions

! "manager" key card

- Insertion of the card has the effect of granting access to advanced functions

- Insertion of the card after the adjustment values have been changed has the effect of confirming the new settings

Page 56

OPERATION

5.6.2 Structure of the functions

5.6.2.1 Overview and adjustment values

Access with the "user" key card

Access with the "manager" key card

User menu Function Setting In steps of ...

Cleaning - OFF after cleaning ?

- Clean coffee ?

- Clean milk ?

(1)yes / (5)no (1)yes / (5)no (1)yes / (5)no

Daily counter - Coffee total

- Other products

0 - 100.000 0 - 100.000

Manager menu Function Setting In steps of ...

Cleaning - OFF after cleaning ?

- Clean coffee ?

- Clean milk ?

(1)yes / (5)no (1)yes / (5)no (1)yes / (5)no

Daily counter - Coffee total

- Other products

- Reset counter

0 - 100.000 0 - 100.000

yes / no

Total counter - Coffee total

- Tea total

- Steam total

- Milk total

0 - 1.000.000 0 - 1.000.000 0 - 1.000.000 0 - 1.000.000

Functions - EXTERNAL

- Self-service

- ON / OFF timer

- Memoswitch

- Milk

- Disable buttons

yes / no yes / no yes / no yes / no yes / no yes / no

Water quantity - Coffee products 0-995 ml ± 0.5 ml

Coff. quant. ±1g - Coffee products ± 1 g ± 0.1 g

Flow period water - Hot water products 0.4 - 120 s ± 0.2 s

Pre-infusion 1 milk - Milk / coffee products 0.0 - 50 s ± 0.5 s

Pre-infusion 2 milk - Milk / coffee products 0.0 - 50 s ± 0.5 s

Post-infusion milk - Milk / coffee products 0.0 - 50 s ± 0.5 s

Flow period milk - Milk products 0.4 - 120 s ± 0.2 s

Flow period steam - Steam products 0.4 - 120 s ± 0.2 s

Price - For all products 0.00 - 25.00 ± 0.10

No charge - For all products Yes / No -

Time / date - Hours

- Minutes

- Day

- Month

- Year

HH: MM DD. MM.

Page 57

OPERATION

OI c5 eng V9 / 18.08.2006 5 - 27 © Cafina / Melitta

5.6.3 Brief description of functions

5.6.3.1 Cleaning

! OFF after cleaning?

Specifies whether the c5 coffee maker will switch off after the individual cleaning procedures are complete or remain in operation.

! Clean coffee?

Specifies whether the cleaning procedure will apply to the coffee system.

! Clean milk?

Specifies whether the cleaning procedure will apply to the milk system.

5.6.3.2 Daily counter

[ i ] The daily counters must not be used for

billing purposes as different counting methods are used. Billing will only be correct with a registration system.

! With "user" key card

Queries the current counter status for all products. Deletion of counters is not possible.

! With "manager" key card

Queries the current counter status for all products. Deletion of counters is generally possible.

5.6.3.3 Total counter

[ i ] The total counters must not be used for

billing purposes as different counting methods are used. Billing will only be correct with a registration system.

! Coffee / Tea / Steam / Milk

Queries the current counter status for specified products.

Deletion of counters is not possible.

5.6.3.4 Functions

! EXTERNAL

Addition and removal of external modules such as coin-operation units or coin-checking devices (analogous to "external" key card) etc.

! Self-service

Switches c5 coffee maker to self-service operation (analogous to "vip" key card).

The products intended can be dispensed directly.

! ON / OFF timer

Sets c5 coffee maker to automatic switching on and off.

The switch-on/switch-off times must have been previously specified.

! Memoswitch

The c5 coffee maker can take note of the usage behaviour of the user up to a point and simplify operation.

! Milk

Addition and removal of the installed EF milk cooler.

! Disable buttons

Locking and release of the control buttons on the c5 coffee maker (analogous to "key lock" key card).

5.6.3.5 Water quantity

! Every individual coffee product

The water quantity can be altered in predefined steps.

Page 58

OPERATION

5.6.3.6 Coffee quantity ±1g

! Every individual coffee product

The powder quantity can be altered in predefined steps.

5.6.3.7 Flow period hot water

! Hot water beverages

The flow time can be altered in predefined steps.

5.6.3.8 Pre-infusion 1 milk

! Every "coffee-milk" beverage

The milk flow time can be altered in predefined steps.

Coffee is then added.

5.6.3.9 Pre-infusion 2 milk

! Every "coffee-milk" beverage

The milk flow time can be altered in predefined steps.

Coffee is then added.

5.6.3.10 Post-infusion milk

! Every "coffee-milk" beverage

The milk flow time can be altered in predefined steps.

Coffee is output first.

5.6.3.11 Flow period milk

! Cold milk

The flow time can be altered in predefined steps.

! Hot milk

The flow time can be altered in predefined steps.

5.6.3.12 Flow period steam

! "Steam button" option

The flow time can be altered in predefined steps.

5.6.3.13 Price

! Every beverage

Allows a price to be stored for every beverage, e.g. for a connected, external billing system.

5.6.3.14 No charge

! Every beverage

Allows a price to be stored for every beverage, e.g. for a connected, external billing system.

5.6.3.15 Time / date

! Time

Used to set the time in the format "12:34".

! Date

Used to set the date in the format "Wednesday 16.06.2004".

Page 59

OPERATION

OI c5 eng V9 / 18.08.2006 5 - 29 © Cafina / Melitta

5.6.4 Use of the functions

5.6.4.1 Cleaning

! Card: "user" key card

1. Insert / remove card

2. [ ] button (5)

3. [ ] button (1)

4. [ ] button (1)

5. Start of cleaning procedure

5.6.4.2 Daily counter

! Card: "user" key card

1. Insert / remove card

2. 1 x [ "

] button

3. 1 x [ $

] button

4. [ "

] or [ ! ] button

5. Insert / remove card

! Card: "manager" key card

1. Insert / remove card

2. 1 x [ "

] button

3. 1 x [ $

] button

4. [ "

] or [ ! ] button

5. [ "

] or [ ! ] button

6. 1 x [ + ] button

7. 1 x [ #

]

8. Insert / remove card

OFF after cleaning? (1)yes (5)no

Clean coffee? (1)yes (5)no

Clean milk? (1)yes (5)no

Daily counter

Coffee total 25

Other beverages yy

Select beverage

Daily counter

Coffee total 25

Other beverages yy

Reset counter no

Reset counter yes

Daily counter

Select beverage

Page 60

OPERATION

5.6.4.3 Total counter

! Card: "manager" key card

1. Insert / remove card

2. 2 x [ "

] button

3. 1 x [ $

] button

4. 1 x [ "

] button

5. 1 x [ "

] button

6. 1 x [ "

] button

7. 1 x [ #

] button

8. Insert / remove card

Total counter

Coffee total 130

Tea total 25

Steam total 15

Milk total 10

Total counter

Select beverage

Page 61

OPERATION

OI c5 eng V9 / 18.08.2006 5 - 31 © Cafina / Melitta

5.6.4.4 Functions

! Card: "manager" key card

1. Insert / remove card

2. 3 x [ "

] button

3. 1 x [ $

] button

1 x [ "

] button

1 x [ "

] button

1 x [ "

] button

1 x [ "

] button

1 x [ "

] button

4. 1 x [ + ] button

1 x [ + ] button

5. 1 x [ #

]

6. Insert / remove card

NOTE

• Only those functions which

have a grey background (activated) can be altered.

Functions

EXTERNAL no

Self-service no

ON / OFF timer no

Memoswitch no

Milk no

Disable buttons no

EXTERNAL yes

Self-service yes

ON / OFF timer yes

Memoswitch yes

Milk yes

Disable buttons yes

Functions

Select beverage

Page 62

OPERATION

5.6.4.5 Water quantity

! Card: "manager" key card

1. Insert / remove card

2. 4 x [ "

] button

3. 1 x [ $

] button

4. e.g. 1 x [ – ] button

5. e.g. 2 x [ + ] button

6. 1 x [ #

]

7. 1 x [ $

] button

8. [ "

] or [ ! ] button

9. 1 x [ #

]

10. Insert / remove card

5.6.4.6 Coffee quantity ±1g

! Card: "manager" key card

1. Insert / remove card

2. 5 x [ "

] button

3. 1 x [ $

] button

4. e.g. 1 x [ – ] button

5. e.g. 2 x [ + ] button

6. 1 x [ #

]

7. 1 x [ $

] button

8. [ "

] or [ ! ] button

9. 1 x [ #

]

10. Insert / remove card

Water quantity

Espresso** 11 Water quantity 40 ml

Espresso** 11 Water quantity 35 ml

Espresso** 11 Water quantity 45 ml

Water quantity

Espresso** 11 Water quantity 45 ml

Other beverages xx Text yyy ml

Water quantity

Select beverage

Coff. quant. ±1g

Espresso** 11 Coffee quantity 8.5 g

Espresso** 11 Coffee quantity 8.4 g

Espresso** 11 Coffee quantity 8.6 g

Coff. quant. ±1g

Espresso** 11 Coffee quantity 8.6 g

Other beverages xx Text y.y g

Coff. quant. ±1g

Select beverage

Page 63

OPERATION

OI c5 eng V9 / 18.08.2006 5 - 33 © Cafina / Melitta

5.6.4.7 Flow period water

! Card: "manager" key card

1. Insert / remove card

2. 6 x [ "

] button

3. 1 x [ $

] button

4. e.g. 1 x [ – ] button

5. e.g. 2 x [ + ] button

6. 1 x [ #

]

7. Insert / remove card

5.6.4.8 Pre-infusion 1 milk

! Card: "manager" key card

1. Insert / remove card

2. 7 x [ "

] button

3. 1 x [ $

] button

4. 2 x [ "

] button

5. e.g. 1 x [ – ] button

6. e.g. 2 x [ + ] button

7. 1 x [ #

]

8. Insert / remove card

Flow period water

Hot water 01 Flow period water\6.0s

Hot water 01 Flow period water\5.8s

Hot water 01 Flow period water\6.2s

Flow period water

Select beverage

Pre-infusion 1 milk

Espresso** 11 Pre-inf. 1 milk 0.0s

Cappuccino 13 Pre-inf. 1 milk 1.5s

Cappuccino 13 Pre-inf. 1 milk 1.0s

Cappuccino 13 Pre-inf. 1 milk 2.0s

Pre-infusion 1 milk

Select beverage

Page 64

OPERATION

5.6.4.9 Pre-infusion 2 milk

! Card: "manager" key card

1. Insert / remove card

2. 7 x [ !

] button

3. 1 x [ $

] button

4. 2 x [ "

] button

5. e.g. 1 x [ – ] button

6. e.g. 2 x [ + ] button

7. 1 x [ #

]

8. Insert / remove card

5.6.4.10 Post-infusion milk

! Card: "manager" key card

1. Insert / remove card

2. 6 x [ ! ] button

3. 1 x [ $

] button

4. 2 x [ "

] button

5. e.g. 1 x [ – ] button

6. e.g. 2 x [ + ] button

7. 1 x [ #

]

8. Insert / remove card

Pre-infusion 2 milk

Espresso** 11 Pre-inf. 2 milk 0.0s

Cappuccino 13 Pre-inf. 2 milk 10.0s

Cappuccino 13 Pre-inf. 2 milk 9.5s

Cappuccino 13 Pre-inf. 2 milk 10.5s

Pre-infusion 2 milk

Select beverage

Post-infusion milk

Espresso** 11 Post-infusion milk0.0s

Cappuccino 13 Post-infusion milk1.0s

Cappuccino 13 Post-infusion milk0.5s

Cappuccino 13 Post-infusion milk1.5s

Post-infusion milk

Select beverage

Page 65

OPERATION

OI c5 eng V9 / 18.08.2006 5 - 35 © Cafina / Melitta

5.6.4.11 Flow period milk

! Card: "manager" key card

1. Insert / remove card

2. 5 x [ !

] button

3. 1 x [ $

] button

1 x [ "

] button

4. e.g. 1 x [ – ] button ]

5. e.g. 2 x [ + ] button

6. 1 x [ #

]

7. Insert / remove card

5.6.4.12 Flow period steam

! Card: "manager" key card

1. Insert / remove card

2. 4 x [ !

] button

3. 1 x [ $

] button

4. e.g. 1 x [ – ] button

5. e.g. 2 x [ + ] button

6. 1 x [ #

]

7. Insert / remove card

Flow period milk

Port. hot milk 15 Flow period milk 25.0s

Port. cold milk 24 Flow period milk 25.0s

Port. hot milk 15 Flow period milk 24.5s

Cold milk port. 24 Flow period milk 24.5s

Port. hot milk 15 Flow period milk 25.5s

Cold milk port. 24 Flow period milk 25.5s

Flow period milk

Select beverage

Flow period steam

**** 02 Flow period steam15.0s

**** 02 Flow period steam14.8s

**** 02 Flow period steam15.2s

Flow period steam

Select beverage

Page 66

OPERATION

5.6.4.13 Price

! Card: "manager" key card

1. Insert / remove card

2. 3 x [ !

] button

3. 1 x [ $

] button

4. e.g. 1 x [ – ] button

5. e.g. 2 x [ + ] button

6. 1 x [ #

]

7. Insert / remove card

5.6.4.14 No charge

! Card: "manager" key card

1. Insert / remove card

2. 2 x [ !

] button

3. 1 x [ $

] button

4. 1 x [ + ] button

5. [ "

] or [ ! ] button

6. 1 x [ + ] button

7. 1 x [ #

]

8. Insert / remove card

Price

Hot water 01 Price 2.00

Hot water 01 Price 1.90

Hot water 01 Price 2.10

Price

Select beverage

No charge

Hot water 01 No charge no

Hot water 01 No charge yes

Other beverages xx Text Text

Other beverages xx Text yes

No charge

Select beverage

Page 67

OPERATION

OI c5 eng V9 / 18.08.2006 5 - 37 © Cafina / Melitta

5.6.4.15 Time / date

! Card: "manager" key card

1. Insert / remove card

2. 1 x [ !

] button

3. 1 x [ $

] button

4. e.g. 1 x [ + ] button

5. 1 x [ "

] button

6. e.g. 5 x [ + ] button

7. 1 x [ "

] button

8. e.g. 1 x [ + ] button

9. 1 x [ "

] button

10. e.g. 1 x [ + ] button

11. 1 x [ "

] button

12. e.g. 1 x [ + ] button

13. 1 x [ #

] button

14. Insert / remove card

After switching off the c5 coffee maker, a message like this appears ...

Time / date

Time / date Hours 14:20

Time / date Hours 15:20

Time / date Minutes 15:20

Time / date Minutes 15:25

Time / date Day Thursday 17.06.2004

Time / date Day Friday 18.06.2004

Time / date Month Friday 18.06.2004

Time / date Month Sunday 18.07.2004

Time / date Month Monday 18.07.2005

Time / date

Select beverage

c5 15:35 18.07.2005

Page 68

OPERATION

5.6.5 Resetting to initial installation default settings

5.6.5.1 Coffee maker reset

This function is used to reset the c5 coffee maker software to the default settings that applied upon first installation.

The c5 coffee maker reads in from the "memory" key card all the data which the service technician wrote to the card ("memory" key card) last time.

! Card: "memory" key card

! Card: "user" key card

1. To disconnect c5 coffee maker from

the mains power supply.

! pull out the plug

! set separate power switch to OFF

2. Insert card ("memory" key card)

3. To connect c5 coffee maker to the

mains power supply:

! insert plug

! set separate power switch to ON

4. The following message appears ...

5. 1 x [ + ] button

6. Remove card ("memory" key card)

7. Insert / remove card ("user" key card)

8. Coffee maker reset is complete

NOTE

• All the software modifica-

tions which have been made to the functions using the "manager" key card are lost when machine is reset!

• Empty the waste water can-

ister and fill the fresh water canister prior to activating the coffee maker reset so as to accommodate the higher water throughput that this causes.

Read memory card (+) 14:45 17.06.2004

Reading memory card 14:45 17.06.2004

Remove card 14:45 17.06.2004

c5 15:45 17.06.2004

Calibration 14:45 17.06.2004

Please wait 14:45 17.06.2004

TURN ON Text

Select beverage

Page 69

MAINTENANCE

6 Maintenance

This chapter deals exclusively with preventive maintenance of the equipment. In case of problems, please consult chapter «7 Troubleshooting, 7 - 1».

6.1 Maintenance schedule

6.1.1 Intervals

6.1.1.1 Cleaning intervals

Cleaning area Daily Weekly Monthly

Cover of beverage outlet

Waste water canister

External / internal "EF / FC"

External / internal cup warmer

Outside of c5 coffee maker

Control buttons and steam tap

Steam outlet

Filling chute with lid

Bean hopper

Fresh water canister

Hot water outlet

Coffee dregs drawer

Liquid crystal display

Milk container “EF / FC”

Milk hoses "EF / FC"

Recess for coffee dregs drawer

Beverage outlet

Cleaning procedure "EF / FC" ! (2 x)

Cleaning procedure c5 coffee maker ! (1 x)

Area underneath the equipment (c5 / EF / cw)

Drip grille

Drip tray

Page 70

MAINTENANCE

6.1.1.2 Intervals between services

The c5 coffee maker is designed for a maximum of 100,000 cups per year.

The built-in safety mechanisms (relieve pressure valves) must be checked once a year to ensure that they are working properly. We recommend that this check is carried out during an (A) service of the whole system.

- "A" service

An "A" service of the whole system is required every 50,000 cups or no later than one year since the last "A" service. The following display message indicates the need for maintenance:

Contact Customer Support.

- "B" service

If the coffee maker has a milk system (EF or FC), than a "B" service of the milk system is required every 15.000 milk or coffee-plus-milk beverages (e.g. hot milk, cappuccino, latte macciato etc.). The following display messages indicate the need for maintenance:

Contact Customer Support.

6.2 Cleaning

6.2.1 Cleaning work

CAUTION

• Only use non-corrosive, non-abrasive household cleaners.

• Only use non-abrasive cloths.

• Do not use any of the normal (rapid) decalcifying agents.

• Only use combination cleaning tablets "COMBI-Tabs" for cleaning proce-

dures.

Select beverage Maintenance Coffee

Select beverage Maintenance Milk

Page 71

MAINTENANCE

Cleaning area Cleaning work

Cover of beverage outlet - Clean using damp cloth.

Waste water canister - Clean using household cleaner and

bottle brush.

External / internal "EF / FC" - Clean using damp cloth.

External / internal cup warmer - Clean using damp cloth.

Outside of c5 coffee maker - Clean using damp cloth.

Control buttons and steam tap - Clean using damp cloth.

Steam outlet - Clean using damp cloth.

- Be sure to blow out sufficiently after

every frothing operation (especially with milk).

Filling chute with lid - Clean using dry cloth.

Bean hopper - Clean using dry cloth.

Fresh water canister - Clean using bottle brush.

- Do not use any cleaning agent.

Hot water outlet - Clean using damp cloth.

Coffee dregs drawer - Rinse out with warm (not hot) water

every time that it is emptied.

- Rub dry with cloth.

Liquid crystal display - Clean using dry cloth.

Milk container "EF / FC" - Clean using household cleaner and

(bottle) brush.

Milk hoses "EF / FC" - Following the cleaning procedure,

clean only the outside of the milk hose, using a dry cloth.

Recess for coffee dregs drawer - Clean using damp cloth.

Beverage outlet - Clean using damp cloth.

Cleaning procedure "EF / FC" - For further details, see section

«6.2.2.2 Installed EF milk cooler / external FC milk cooler, 6 - 7»

Cleaning procedure c5 coffee maker - For further details, see section

«6.2.2.1 c5 coffee maker, 6 - 5»

Drip grille - Clean using damp cloth.

Drip tray - Clean using damp cloth.

Page 72

MAINTENANCE

6.2.2 Cleaning procedure

The c5 coffee maker and the installed EF milk cooler or external FC milk cooler are cleaned in separate cleaning procedures.

The following applies:

! The two cleaning procedures can be

carried out separately or one after the other.

! The c5 coffee maker can be kept in op-

eration or automatically switched off after one or both cleaning procedures.

! The cleaning procedure for the c5 cof-

fee maker requires one combination cleaning tablet "COMBI-Tabs".

! The cleaning procedure for the in-

stalled EF milk cooler or external FC milk cooler requires one combination cleaning tablet "COMBI-Tabs" or one AMC powder bag.

NOTE

• Information on consum-

ables

Use only:

Only use combination cleaning tablets "COMBITabs", article no. 2900018

Only use AMC powder, article no. 2904013

NOTE

• Check the level of water in

the fresh water canister prior to every cleaning procedure.

CAUTION

• Depending on the cleaning

procedure, the throughput of water may be high. If the waste water canister has little remaining capacity, it could overflow.

• Check waste water canister

prior to initiating the cleaning procedure!

Page 73

MAINTENANCE

6.2.2.1 c5 coffee maker

Brief description of the cleaning procedure, following which the coffee maker remains switched on:

! Duration of the cleaning procedure:

approx. 7.5 min.

- Insert / remove "user" / "manager" key

card.

- Choose the option whereby the c5 cof-

fee maker does not switch off after the cleaning procedure.

- Specify that the c5 coffee maker is to

be cleaned.

- Specify that the EF / FC is not to be

cleaned.

- You may now be prompted to empty

the coffee dregs drawer.

- Start of rinse operation.

- Insert one combination cleaning

tablet "COMBI-Tabs", article no.

2900018.

- Start of cleaning process.

- Bring the c5 coffee maker up to

operating temperature.

- Ready to dispense beverages.

Detailed sequence of operations in the cleaning procedure:

1. Initial situation with the following dis-

play ...

2. Insert / remove "user" / "manager" key

card.

3. [ ] button (5)

4. [ ] button (1)

5. [ ] button (5)

6. You may now be prompted to empty

the coffee dregs drawer.

Pull out the coffee dregs drawer so that you can empty it. The following message appears ...

Push the empty coffee dregs drawer back in. The following message appears ...

7. Now press the Shift/Stop button [ ]

on the control panel.

Select beverage

OFF after cleaning? [1]yes [5]no

Clean coffee? [1]yes [5]no

Clean milk? [1]yes [5]no

Empty drawer!

Drawer missing!

Drawer emptied Please confirm (

)

Page 74

MAINTENANCE

8. The following message now appears ...

9. This message now appears ...

10. Lid of filling chute opens. Insert one

combination cleaning tablet "COMBITabs" in the filling chute and confirm.

If the lid has closed before the tablet is inserted (timeout) the following message appears ...

Press Shift/Stop button [ ] again.

11. Shift/Stop button [ ]

12. Once the cleaning operation is over,

the following message will appear ...

13. If the operating temperature appears to

have been achieved ...

Rinsing

Put cleaning agent in Please confirm (SH)

Start cleaning

CAUTION

• Hot suds will come out of the

beverage outlet.

Cleaning

TURN ON prog. 86°C act. 25°C

Select beverage

Page 75

MAINTENANCE

6.2.2.2 Installed EF milk cooler / external FC milk cooler

Brief description of the cleaning procedure, following which the coffee maker remains switched on:

! Duration of the cleaning procedure:

approx. 17.5 min.

- Insert / remove "user" / "manager" key

card.

- Choose the option whereby the c5 cof-

fee maker does not switch off after the cleaning procedure.

- Specify that the c5 coffee maker is not

to be cleaned.

- Specify that the EF / FC is to be

cleaned.

- Only insert one combination cleaning tablet "COMBI-Tabs", article no. 2900018 or the content of one AMC powder bag, article no. 2904013 in

the empty cleaning container and replace the milk container with the cleaning container (place both the milk intake lines in the cleaning container).

- The cleaning container is filled and then rinsed six times (cleaning container emptied).

- Bring the c5 coffee maker up to operating temperature.

- Replace the empty cleaning container with the full milk container.

- Ready to dispense beverages.

Detailed sequence of operations in the cleaning procedure:

1. Initial situation with the following dis-

play ...

2. Insert / remove "user" / "manager" key card.

3. [ ] button (5)

4. [ ] button (5)

NOTE

• Once a week, the AMC powder bag must be placed in the cleaning container instead of a combination cleaning "COMBITabs".

• The use of AMC powder

prevents the accumulation of milk scale and residues in the milk system.

• Together with the daily alkali cleaning (combination cleaning "COMBI-Tabs") the acid cleaner (AMC powder) ensures the optimum hygienic condition of the milk system.

Select beverage

OFF after cleaning? [1]yes [5]no

Clean coffee? [1]yes [5]no

Clean milk? [1]yes [5]no

Page 76

MAINTENANCE

5. [ ] button (1)

Place one combination cleaning tablet "COMBI-Tabs" or the content of one AMC powder bag in the empty cleaning receptacle. Replace milk container with cleaning receptacle (place both milk intake lines in the cleaning container). Leave the milk cooler door open.

6. Shift/Stop button [ ]

The cleaning container is filled and then rinsed six times (cleaning container emptied).

7. Once the cleaning operation is over,

the following message will appear...

8. Replace cleaning container with full

milk container. Close milk cooler door.

9. Shift/Stop button [ ]

6.3 Maintenance log

The service technician from Customer Support maintains the maintenance log for the installation and subsequent maintenance work.

For this purpose he enters the necessary data into the table cells in chapter «12 "Service Technician" maintenance log, 12 - 1».

Insert the cleaning container

Please confirm (SH)

Cleaning milk

TURN ON prog. 86°C act. 80°C

Refill milk Please confirm (

)

Select beverage

Page 77

TROUBLESHOOTING

7 Troubleshooting

7.1 Fault display, troubleshooting and fault acknowledgement

During operation, the control system monitors the operating status continually. Faults are displayed on the liquid crystal display. In case of malfunction s, the user / operator can intervene in accordance with the procedures described in this chapter and attempt to troubleshoot the problem.

Brief description of troubleshooting process:

- Analyse message on the liquid crystal

display. The possibilities are as follows:

! text message

! text message plus diagnosis point

(DP) display

- First of all insert / remove the "user" /

"manager" key card. If this clears the malfunction, then the c5 coffee maker will be once more ready to dispense beverages. Otherwise, see below.

- To troubleshoot the problem, proceed

as described in sections «7.2.1 Textual error messages, 7 - 2» and «7.2.2 Error messages displayed via diagnosis points (DP), 7 - 6».

- Insert / remove "user" / "manager" key

card a second time.

- If this clears the malfunction, then the

c5 coffee maker will be once more ready to dispense beverages. If not, the malfunction will not clear itself, and "disconnect from the power supply / connect to the power supply" is not possible. If the malfunction is still unresolved, then Customer Support must be contacted.

Detailed sequence of stages involved in troubleshooting - example initial situation:

Too much coffee powder was placed in the filling chute following selection of "Decaffeinated".

1. The normal beverage selection "Decaf-

feinated" was made in the "Coffee cream" quantity.

2. Three heaped measuring spoons of

coffee powder were put in the filling chute.

The following message appears ...

3. Insert "user" / "manager" key card.

The following message appears ...

4. Remove "user" / "manager" key card.

The following message appears ...

5. Insert "user" key card.

The following message appears ...

6. This message now appears ...

7. The fault has been cleared and the

c5 coffee maker is ready to dispense beverages.

Select beverage Error coffee partDP 16

Fault confirmed

c5 13:00 22.06.2004

TURN ON Text

Select beverage

Page 78

TROUBLESHOOTING

7.2 Checklist for fault diagnosis and troubleshooting

7.2.1 Textual error messages

LCD textual error messages Cause of fault Troubleshooting measure(s)

Temp. too high

Temp. too low

Boiler temp. too high

Boiler temp. too low

Unknown hardware or software error

Static charge

Effect of storm (overvoltage due to storm)

Disconnect / connect to mains power supply.

1. Disconnect c5 coffee mak-

er from the mains power supply.

2. Wait at least 30 seconds.

3. Connect c5 coffee maker

to the mains power supply.

4. Switch on c5 coffee mak-

er.

5. Decision:

If the textual error message is no longer shown, there is no need for any action.

If the textual error message is still on view, notify Customer Support.

Refill milk Milk level too low. If milk level monitoring is in-

stalled:

- check milk level.

- replenish milk supply.

See also section «5.5.4 Refill milk, 5 - 22».

Page 79

TROUBLESHOOTING

LCD textual error messages Cause of fault Troubleshooting measure(s)

Refill milk Milk level too low. If no milk level monitoring in-

stalled:

- check milk level.

- replenish milk supply.

- disconnect / connect to

mains power supply.

1. Disconnect c5 coffee mak-

er from the mains power supply.

2. Wait at least 30 seconds.

3. Connect c5 coffee maker

to the mains power supply.

4. Switch on c5 coffee maker.

5. Decision:

If the textual error message is no longer shown, there is no need for any action.

If the textual error message is still on view, notify Customer Support.

See also section «5.5.4 Refill milk, 5 - 22».

Page 80

TROUBLESHOOTING

LCD textual error messages Cause of fault Troubleshooting measure(s)

Drawer missing! Coffee dregs drawer not in-

serted or not pushed in far enough.

Use coffee dregs drawer correctly.

See also section «5.5.5 Emptying the coffee dregs drawer, 5 - 23».

No water Check water connection. Open stopcock in the external

fresh water feeder pipe.

Check pressure on external fresh water feeder pipe (should be 3 to 5 bar).

Refill fresh water canister.

Straighten out kink in water line to the fresh water canister.

If one of the c5 coffee maker’s feet is standing on the water line, release water line.

Clean or replace external water filter.

Check external water pump.

See also section «5.5.1 Refilling fresh water canister, 5 - 19».

Waste water full The "waste water

container level monitoring" option is installed and is reporting that the waste water canister is full.

Empty waste water canister immediately.

See also section «5.5.2 Emptying the waste water canister, 5 - 19».

Bean hoppers (1 or 2) Bean hopper 1 or 2

is empty.

Replenish coffee beans.

See also section «5.5.3 Refill coffee beans, 5 - 20».

Page 81

TROUBLESHOOTING

LCD textual error messages Cause of fault Troubleshooting measure(s)

Boiler level Water level too low.

Too much time elapses during the filling operation.

There may be a water leak or the water feed may be insufficient.

The c5 coffee maker is still in operation; however it is necessary to keep an eye on it.

Contact Customer Support.

Filter Water filter is worn and

must be replaced.

The c5 coffee maker is still in operation; however it is necessary to keep an eye on it.

Contact Customer Support.

Grinding correction The automatic coffee bean

grinding calibration is not working. This results in reduced quality of the beverages dispensed.

The c5 coffee maker is still in operation; however it is necessary to keep an eye on it.

Contact Customer Support.

Maintenance Coffee The whole system needs

servicing.

The c5 coffee maker is still in operation; however it is necessary to keep an eye on it.

Contact Customer Support.

Page 82

TROUBLESHOOTING

Specifically for the temperature regulator unit

7.2.2 Error messages displayed via diagnosis points (DP)

NOTE

• The error messages for the temperature regulator unit are shown in the tem-

perature regulator unit display!

Displayed error message Cause of fault Troubleshooting measure(s)

PrF Temperature sensor fault Contact Customer Support.

EEE EEPROM error

(loss of program data)

Contact Customer Support.

Diagnosis point (DP) Cause of fault Troubleshooting measure(s)

0 / 1 / 2 / 4 / 5 System fault Contact Customer Support.

7 Coffee dregs block

too high

Check coffee dregs drawer:

- empty coffee dregs drawer correctly.

See also section «5.5.5 Emptying the coffee dregs drawer, 5 - 23».

If the fault persists, contact Customer Support.

8 / 9 / 10 / 16 / 17 / 18 / 22 / 23

System fault Contact Customer Support.

Page 83

TAKING OUT OF SERVICE AND STORAGE

8 Taking out of

service and storage

8.1 Taking out of service for a limited time / taking out of service for good

Both when the coffee maker is taken out of service for a limited (but prolonged) period and also when it is taken out of service for good, the "c5 coffee maker / installed EF milk cooler / external FC milk cooler" and the cw cup warmer must be disconnected from the mains power supply.

All raw materials which are used to prepare beverages must be removed from the c5 coffee maker, the installed EF milk cooler and the external FC milk cooler.

All the components must be cleaned thoroughly (see also sections «5.3.2 Switching off the c5 coffee maker, 5 - 6» and «6.2.2 Cleaning procedure, 6 - 4»).

If the equipment is to be out of service for an extended period, to avoid (frost) damage, it should be expertly drained by Customer Support.

8.2 Storage for a limited period / permanent storage

If the "c5 coffee maker / installed EF milk cooler / external FC milk cooler" and the cw cup warmer are to be stored either for a limited period or permanently, it is essential that they are taken out of service correctly see section 8.1.

When storing the equipment, the requirements specified in section «1.3.6 Environmental conditions, 1 - 9» must be observed.

Page 84

TAKING OUT OF SERVICE AND STORAGE

Page 85

PACKING AND TRANSPORTATION

9 Packing and

transportation

When packing and transporting the equipment, the following requirements must be observed:

1. Disconnect equipment from power and

water mains.

2. Remove any product raw materials,

such as coffee beans and milk, from the equipment.

3. Empty coffee dregs drawer.

4. Empty hoses and drain. This is a matter

for Customer Support.

5. Clean equipment.

6. If possible, pack equipment in the orig-

inal packaging.

7. Place the equipment (... in the original

packaging) on a suitable transport base in an upright position and attach to the transport base.

WARNING

• Only persons with experi-

ence of haulage and transportation are authorised to pack and transport the equipment.

• The requirements set out in

chapter «2 Safety instructions, 2 - 1» must be strictly observed!

CAUTION

• When securing the equip-

ment (... in the original packaging) on the transport base, take care not to cause any chafe marks.

Page 86

PACKING AND TRANSPORTATION

Page 87

DISPOSAL

10 Disposal

The following requirements must be observed in the case of disposal:

1. Disconnect equipment from power and

water mains.

2. Remove any product raw materials,

such as coffee beans and milk, from the equipment.

3. Empty coffee dregs drawer.

4. Take the equipment apart.

5. Recycle individual parts according to

material type.

6. Dispose of non-recyclable materials

according to type.

WARNING

• Disassembly and disposal

of the equipment may only be carried out by persons who satisfy the necessary qualification and training requirements.

• The requirements set

out in chapter «2 Safety instructions, 2 - 1» must be strictly observed!

NOTE

• Information on disposal

organisations and collection points can be obtained from your local administrative authority.

• During disposal, it is

necessary in any case to comply with the pertinent national and regional laws and directives.

• The machines do not

contain any materials whose disposal requires special approval.

Page 88

DISPOSAL

Page 89

GUARANTEE, CONSUMABLES, SPARE PARTS, ORDERING PROCEDURE

11 Guarantee, con-

sumables, spare parts, ordering procedure

Guarantee

We guarantee the trouble-free function of this machine for 12 months or a maximum 100'000 beverage dispensions. The start of the guarantee period is the day of installation.

During the guarantee period any defects, which can be traced back to material faults, defective workmanship or faulty construction, will be rectified free by us or by a company authorized by us. The precondition here is the proper use and correct handling of the machine according to the relevant descriptions in this operating manual.

Accordingly we will not accept any liability for the following cases:

- Faults caused by contamination as a result

of improper cleaning (e.g. blocked valves or mixer)

- Faults due to limescale build-up or other de-

posits when operated with water softening equipment (e.g. boiler or water pumps)

- Faults due to excess electrical voltages

(e.g. burned PCBs)

We will accept no liability for damage to all devices arising from poor maintenance and care by the customer.

We will accept no liability for defects and faults in our equipment, which can be traced back to inexpert repairs or the installation of spare parts which do not correspond with the original versions.

Normal wear of all parts, which are subject to natural wear, is excluded from the guarantee.

This includes:

- Seals

- Filters

- Complete piston spray

- Complete piston plunger

- Paint coatings

- Grinding discs

- Hoses for the peristaltic pump

To validate the guarantee claim the defective part must be returned to the manufacturer. After inspecting the returned part the manufacturer reserves the right to reject a guarantee claim if one of the conditions referred to above exists.

The acceptance of a guarantee claim for damage due to a fault is only possible following the written report of the manufacturer.

Quality settings, which were not carried out on the basis of the fault, are excluded from the guarantee.

Any work carried out during the guarantee period will not extend its term.

Consumables, spare parts, ordering procedure

This normally affects service technicians, third-party customers or resellers:

To avoid misunderstandings when ordering consumable materials or spare parts, we request that you always provide the following data with your order:

! Device identification according to the type

plate.

! Description and article number of the consum-

able material or spare part.

! Quantity of the required consumable materials

or spare parts.

Device-specific consumable materials or spare parts must only be procured from the customer service location in the respective country.

Only device-specific spare parts made by the manufacturer are to be used.

The manufacturer rejects any liability for the situation in which it is found that non device-specific spare parts have been installed in the respective machine.

Page 90

GUARANTEE, CONSUMABLES, SPARE PARTS, ORDERING PROCEDURE

A Adresses of service AUS Adresses of service B Serviceadressen

CH Adresses of service D Adresses of service

DK Serviceadresser E Servico Tecnicos F Services Techniques

FIN Huoltopisteiden osoitteita GB Adresses of service J Adresses of service

N Serviceadresser NL Serviceadressen RC Adresses of service

RUS Service S Serviceadresser TH Adresses of service

USA Adresses of service KR Adresses of service TW Adresses of service

MELITTA System Service International GmbH Rottfeld 9A 5020 Salzburg Fon 0043-662 / 88 28 88-33 Fax 0043-662 / 88 28 88-99

AUS

Global Coffee So lu tions Pty L td 5/7 7 Jardine St.

Fairy Meadow NSW 2519 Fon 0061 1300 552 883 Fax 0061 02 4284 6099

MELITTA System Service Benelux Bijkantoor MELITTA Syst. Service Brandstraat, 8 9160 Lokeren Fon 0032-9 / 331 52 30 Fax 0032-9 / 331 52 35

CAFINA AG Römerstrasse 2 5502 Hunzenschwil Fon 0041-62 / 889 42 42 Fax 0041-62 / 889 42 89 Instruktionsnummer: 17098

MELITTA System Service GmbH & Co. KG Zechenstrasse 60 32429 Minden-Dützen Fon 0049-571 / 50 49-0 Fax 0049-571 / 50 49-233

DK N

aromateknik a/s Industrivej 44 4000 Roskilde

Fon 0045-46 / 75 33 66 Fax 0045-46 / 75 38 10

Tecnimel Hosteleria, S.L. Avda. Esparteros, 15 Pol. S. J. de Valderas Sanahuja 28918 Leganés (Madrid) Fon 0034-91 / 644 81 30 Fax 0034-91 / 644 81 31

MELITTA System Service France SA 16 Rue P.H. Spaak Saint Thibault des Vignes 77462 LAGNY sur Marne Cedex Fon 0033-1 / 6430 32 95 Fax 0031-1 / 6430 33 40

FIN

Hackman Metos Oy AB Ahjonkaarre 04220 Kerava

Fon 00358-204 / 39 13 Fax 00358-204 / 39 44 33

M.S.S. (UK) Limited 21 Grove Park White Waltham Maidenhead Berkshire SL6 3LW Fon 0044-1628 / 82 98 88 Fax 0044-1628 / 82 51 11

MELITTA Japan Ltd. 9F abc Kaikan 2-6-3, Shiba-koen, Minato-ku Tokyo 105-0011 Japan

Fon 0081-3 / 5470-2770 Fax 0081-3 / 5470-2774

Edward Keller (Korea) Ltd. 3F. Nasan Bldg. 1024 Daechi-dong Kangnam-gu Seoul 135-173 Fon 0082-2 / 2192-9541 Fax 0082-2 / 2192-9590

MELLITA System Service Benelux BV Industriestraat 6 3371 XD HARDINXVELD GIESSENDAM Fon 0031-18 467 / 16 60 Fax 0031-18 461 / 04 14

Edward Keller 21/F Southmark 11 Yip Hing St. Wong Chuk Hang Hongkong / China Fon 00852 / 28 95-96 20 Fax 00852 / 28 95-00 39

RUS

MELITTA Russland Sofiskaya 14 of. 805 192236 St. Petersburg

Fon 007-812 / 3 26 65 56 Fax 007-812 / 3 26 65 57

aromateknik A/S Radiovägen 2 Box 662 13526 Tyresö

Fon 0046-8 / 7 98 77 88 Fax 0046-8 / 7 98 90 18

Great Earth International Co., Ltd. 5th Floor, M Thai Tower, All Seasons Place 87 Wireless Road, Patumwan Bangkok 10330 Fon 0066-2 / 654-1118 Fax 0066-2 / 654-1119

USA

Michaelo Espresso, Inc. 3801 Stone Way N. Seattle, WA 98 103

Fon 001-206 / 548-9000 Fax 001-206 / 695-4951

JAS Corporation B1, No. 17, Lane 28 Sec. 1, Huan Shan Rd., Nei Hu Area Taipei Fon 00886-2 / 2727-0630 Fax 00886-2 / 2727-0640

Page 91

"SERVICE TECHNICIAN" MAINTENANCE LOG

12 "Service Technician" maintenance log

Installation Serial-No.:

Key:

[ A ] = Service of whole system

[ B ] = Service of milk system

[ S ] = Annual check of safety mechanisms

[ F ] = Water filter replaced

* = Check applicable fields

= Untreated water before the filter

= Water at the beverage outlet

Date: Installed water filter type:

Service Technician No.: Bypass %:

Water measured values on ...

... IN

... OUT

Signature: GH°:

kH°:

pH:

Date: Service * Water values Notes:

[ A ] [ B ] [ S ] [ F ] Bypass %:

Service Technician No.:

Counter reading

Water measured values on ...

Coffee:

Milk:

... IN

... OUT

Signature:

Next service

GH°:

Coffee:

kH°:

Milk:

pH:

Date: Service * Water values Notes:

[ A ] [ B ] [ S ] [ F ] Bypass %:

Service Technician No.:

Counter reading

Water measured values on ...

Coffee:

Milk:

... IN

... OUT

Signature:

Next service

GH°:

Coffee:

kH°:

Milk:

pH:

Date: Service * Water values Notes:

[ A ] [ B ] [ S ] [ F ] Bypass %:

Service Technician No.:

Counter reading

Water measured values on ...

Coffee:

Milk:

... IN

... OUT

Signature:

Next service

GH°:

Coffee:

kH°:

Milk:

pH:

Page 92

"SERVICE TECHNICIAN" MAINTENANCE LOG

Date: Service * Water values Notes:

[ A ] [ B ] [ S ] [ F ] Bypass %:

Service Technician No.:

Counter reading

Water measured values on ...

Coffee:

Milk:

... IN

... OUT

Signature:

Next service

GH°:

Coffee:

kH°:

Milk:

pH:

Date: Service * Water values Notes:

[ A ] [ B ] [ S ] [ F ] Bypass %:

Service Technician No.:

Counter reading

Water measured values on ...

Coffee:

Milk:

... IN

... OUT

Signature:

Next service

GH°:

Coffee:

kH°:

Milk:

pH:

Date: Service * Water values Notes:

[ A ] [ B ] [ S ] [ F ] Bypass %:

Service Technician No.:

Counter reading

Water measured values on ...

Coffee:

Milk:

... IN

... OUT

Signature:

Next service

GH°:

Coffee:

kH°:

Milk:

pH:

Date: Service * Water values Notes:

[ A ] [ B ] [ S ] [ F ] Bypass %:

Service Technician No.:

Counter reading

Water measured values on ...

Coffee:

Milk:

... IN

... OUT

Signature:

Next service

GH°:

Coffee:

kH°:

Milk:

pH:

Page 93

"SERVICE TECHNICIAN" MAINTENANCE LOG

Date: Service * Water values Notes:

[ A ] [ B ] [ S ] [ F ] Bypass %:

Service Technician No.:

Counter reading

Water measured values on ...

Coffee:

Milk:

... IN

... OUT

Signature:

Next service

GH°:

Coffee:

kH°:

Milk:

pH:

Date: Service * Water values Notes:

[ A ] [ B ] [ S ] [ F ] Bypass %:

Service Technician No.:

Counter reading

Water measured values on ...

Coffee:

Milk:

... IN

... OUT

Signature:

Next service

GH°:

Coffee:

kH°:

Milk:

pH:

Date: Service * Water values Notes:

[ A ] [ B ] [ S ] [ F ] Bypass %:

Service Technician No.:

Counter reading

Water measured values on ...

Coffee:

Milk:

... IN

... OUT

Signature:

Next service

GH°:

Coffee:

kH°:

Milk:

pH:

Date: Service * Water values Notes:

[ A ] [ B ] [ S ] [ F ] Bypass %:

Service Technician No.:

Counter reading

Water measured values on ...

Coffee:

Milk:

... IN

... OUT

Signature:

Next service

GH°:

Coffee:

kH°:

Milk:

pH:

Page 94

"SERVICE TECHNICIAN" MAINTENANCE LOG

Date: Service * Water values Notes:

[ A ] [ B ] [ S ] [ F ] Bypass %:

Service Technician No.:

Counter reading

Water measured values on ...

Coffee:

Milk:

... IN

... OUT

Signature:

Next service

GH°:

Coffee:

kH°:

Milk:

pH:

Date: Service * Water values Notes:

[ A ] [ B ] [ S ] [ F ] Bypass %:

Service Technician No.:

Counter reading

Water measured values on ...

Coffee:

Milk:

... IN

... OUT

Signature:

Next service

GH°:

Coffee:

kH°:

Milk:

pH:

Date: Service * Water values Notes:

[ A ] [ B ] [ S ] [ F ] Bypass %:

Service Technician No.:

Counter reading

Water measured values on ...

Coffee:

Milk:

... IN

... OUT

Signature:

Next service

GH°:

Coffee:

kH°:

Milk:

pH:

Date: Service * Water values Notes:

[ A ] [ B ] [ S ] [ F ] Bypass %:

Service Technician No.:

Counter reading

Water measured values on ...

Coffee:

Milk:

... IN

... OUT

Signature:

Next service

GH°:

Coffee:

kH°:

Milk:

pH:

Page 95

INDEX

Page Page

Adresses of service . . . . . . . . . . . 11 - 2

authorised persons . . . . . . . . . . . . . 2 - 7

basic safety instructions . . . . . . . . . 2 - 2

button layout

on the control panel . . . . . . . . . . . 5 - 25

cleaning

procedure . . . . . . . . . . . . . . . . . . 6 - 4

work . . . . . . . . . . . . . . . . . . . . . . 6 - 2

coffee maker reset . . . . . . . . . . . . 5 - 38

Consumables . . . . . . . . . . . . . . . . 11 - 1

control panel . . . . . . . . . . . . . . . . . 5 - 25

controls . . . . . . . . . . . . . . . . . . . . . . 3 - 1

decaffeinated

coffee dispensing . . . . . . . . . . . . . 5 - 14

description . . . . . . . . . . . . . . . . . . . 1 - 1

design . . . . . . . . . . . . . . . . . . . . . . . 1 - 1

dimensions . . . . . . . . . . . . . . . . . . . 1 - 8

dispensing of beverages . . . . . . . . . 5 - 9

disposal . . . . . . . . . . . . . . . . . . . . 10 - 1

emptying the

coffee dregs drawer . . . . . . . . . . . 5 - 23

environmental conditions . . . . . . . . 1 - 9

fault

acknowledgement . . . . . . . . . . . . 7 - 1

checklist . . . . . . . . . . . . . . . . . . . . 7 - 2

displays . . . . . . . . . . . . . . . . . . . . 7 - 1

rectification . . . . . . . . . . . . . . . . . . 7 - 1

foam quality . . . . . . . . . . . 5 - 18, 5 - 22

frothing milk manually . . . . . . . . . . 5 - 18

functions

brief description . . . . . . . . . . . . . 5 - 27

structure, over-

view, adjustment values . . . . . . . 5 - 26

use . . . . . . . . . . . . . . . . . . . . . . . 5 - 29

Guarantee . . . . . . . . . . . . . . . . . . . 11 - 1

indicators . . . . . . . . . . . . . . . . . . . . . 3 - 1

initial start-up . . . . . . . . . . . . . . . . . . 4 - 1

key cards . . . . . . . . . . . . . . . . . . . . . 1 - 5

maintenance . . . . . . . . . . . . . . . . . . 6 - 1

minimum training and qualifications of

authorised personnel . . . . . . . . . . . . 2 - 8

mode of operation . . . . . . . . . . . . . . 1 - 3

Page 96

INDEX

Page Page

operating modes . . . . . . . . . . . . . . . 3 - 3

operating performance data . . . . . . 1 - 9

operation . . . . . . . . . . . . . . . . . . . . . 5 - 1

Operator maintenance log . . . . . . . 6 - 8

options . . . . . . . . . . . . . . . . . 1 - 3, 1 - 4

Ordering procedure . . . . . . . . . . . 11 - 1

packing . . . . . . . . . . . . . . . . . . . . . . 9 - 1

personal safety . . . . . . . . . . . . . . . . 2 - 6

power supply connection . . . . . . . . 5 - 1

power switch . . . . . . . . . . . . . . . . . . 2 - 7

preventive maintenance plan

Intervals . . . . . . . . . . . . . . . . . . . 6 - 1

refill coffee beans . . . . . . . . . . . . . 5 - 20

Refill milk . . . . . . . . . . . . . . . . . . . 5 - 22

relief pressure valve . . . . . . . . . . . . 2 - 7

reset of coffee maker . . . . . . . . . . 5 - 38

routine work . . . . . . . . . . . . . . . . . 5 - 19

safety instructions . . . . . . . . . . . . . . 2 - 1

safety mechanisms . . . . . . . . . . . . . 2 - 7

Service Techni-

cian maintenance log . . . . . . . . . . . 12 - 1

Shift function . . . . . . . . . . . . . . . . . . 1 - 4

space requirements . . . . . . . . . . . . . 1 - 9

Spare part . . . . . . . . . . . . . . . . . . . 11 - 1

specific haz-

ards and instructions . . . . . . . . . . . . 2 - 3

storage . . . . . . . . . . . . . . . . . . . . . . . 8 - 1

switching off . . . . . . . . . . . . . . . . . . . 5 - 5

switching on . . . . . . . . . . . . . . . . . . . 5 - 5

system work . . . . . . . . . . . . . . . . . . 5 - 25

taking out of service . . . . . . . . . . . . . 8 - 1

technical data . . . . . . . . . . . . . . . . . . 1 - 6

transportation . . . . . . . . . . . . . . . . . . 9 - 1

troubleshooting . . . . . . . . . . . . . . . . 7 - 1

TWIN function . . . . . . . . . . . . . . . . . 1 - 4

warnings . . . . . . . . . . . . . . . . . . . . . . 2 - 1

water connection . . . . . . . . . . . . . . . 5 - 4

weights . . . . . . . . . . . . . . . . . . . . . . . 1 - 8
