Melco M342i User Manual
This guide describes the operation of the GSM telephone M342i.
Whilst every effort has been made to ensure the accuracy of the instructions contained in this guide, Melco Mo-
bile Communications Europe S.A. reserves the right to make improvements and changes to the product de-
Edition 1, 2003. © Melco Mobile Communications Europe S.A., 2003
scribed in this guide and/or to the guide itself, without prior notice.
Melco Mobile Communications Europe S.A. is a Mitsubishi Group Company.
Table of contents
TABLE OF CONTENTS
Page 4 Introduction
SAR _______________________________________ 4
Declaration of conformity _______________________ 5
General safety _______________________________ 5
Vehicle safety _______________________________ 5
Emergency calls _____________________________ 6
Care and maintenance ________________________ 6
AC/DC adaptor charger ________________________ 6
Battery use _________________________________ 6
PC cable ___________________________________ 7
Your responsibility ____________________________ 7
Security codes _______________________________ 7
Disposing of waste packaging ___________________ 7
Page 8 Using this guide
Page 11 Getting started
Preparing the phone for operation _______________ 11
Basic operations ____________________________ 11
Page 14 Tools
Diary _____________________________________ 14
Calculator _________________________________ 17
Currency converter __________________________ 17
Alarm clock ________________________________ 18
Infrared port ________________________________ 18
Using your mobile as a modem _________________ 19
Page 20 Messages
Reading a received sms message ______________ 20
Reading stored sms messages _________________ 20
Moving messages to SIM _____________________ 20
Forwarding messages ________________________ 21
Activating or deactivating the message alert tone ___ 21
Preparing the phone to send sms messages ______ 21
Entering text _______________________________ 22
Creating text models _________________________ 24
Editing a text model __________________________ 24
Sending a new SMS message _________________ 24
Signature __________________________________ 25
Outbox and SIM archive emitted messages _______ 25
Status request ______________________________ 25
Storage consumption _________________________ 26
Broadcast - cell broadcast (CB) messages ________ 26
Page 28 Calls & times
Calls log ___________________________________ 28
Call timers _________________________________ 28
Call costs - management ______________________ 29
Recorded call _______________________________ 31
2-
Table of contents
Page 32 Phonebook
Storing names and telephone numbers ___________ 32
Editing a phonebook or a SIM name card _________ 33
Viewing and calling phonebook numbers __________ 34
Voice dialling _______________________________ 34
Free space in the phonebook ___________________ 35
Creating a group of cards ______________________ 35
My card ____________________________________ 36
My number(s) display _________________________ 36
Fixed dialling numbers ________________________ 36
Export _____________________________________ 37
Page 38 Camera
Mobile positioning ____________________________ 38
Taking a picture _____________________________ 38
Adjusting your picture _________________________ 40
Storing/erasing your picture ____________________ 40
Self timer __________________________________ 41
Page 42 Fun & media box
Pictures ___________________________________ 42
Melodies ___________________________________ 44
Games & applications ________________________ 44
Speech notes _______________________________ 45
Others _____________________________________ 46
Storage used _______________________________ 47
Page 48 Calendar
Page 48 Network services
Page 49 i-mode
User interface _______________________________ 49
i-mode menu _______________________________ 49
i-mode applications __________________________ 50
Mail system ________________________________ 52
Mail system settings __________________________ 56
Quick access to i-mode basic features ____________ 57
Page 59 Settings
Tones _____________________________________59
Display ____________________________________ 60
Keypad ____________________________________61
Voice mail __________________________________ 62
Phone settings ______________________________ 62
GSM services _______________________________ 64
Security features ____________________________ 68
Page 70 Appendix
Glossary ___________________________________70
Trouble shooting _____________________________ 71
Error messages _____________________________ 72
Guarantee _________________________________ 74
Page 75 Index
Page 77 Notes
3-
Introduction
INTRODUCTION
T
hank you for purchasing the M342i (GSM, DCS) mobile telephone. The mobile telephone
described in this guide is approved for use on all GSM 900/1800 networks. Some of the
messages displayed on your mobile may be different according to your subscription type and/
or service provider.
As with all types of radio transceivers, this mobile telephone emits electromagnetic waves
and complies with international regulations when it is used under normal conditions and in
accordance with the safety and warning messages given below.
SAR
THIS M342i PHONE MEETS THE EU REQUIREMENTS FOR EXPOSURE TO RADIO
WAVES.
Before a mobile phone is available for sale to the public, compliance with the European R&TTE
directive
(1999/5/EC
protection of the health and the safety for the user and any other person.
Your mobile phone is a radio transmitter and receiver. It is designed and manufactured not to
exceed the limits for exposure to radiofrequency (RF) energy recommended by The Council of
the European Union1. These limits are part of comprehensive guidelines and establish permitted
levels of RF energy for the general population. The guidelines were developed by independent
scientific organisations through periodic and thorough evaluation of scientific studies. The limits
include a substantial safety margin designed to assure the safety of all persons, regardless of
age and health.
The exposure standard for mobile phones (CENELEC standard EN 50360: 2001) employs a unit
of measurement known as the Specific Absorption Rate, or SAR. The SAR limit2 recommended
by The Council of the European Union is 2.0 W/kg. Tests for SAR have been conducted using
standard operating positions (with reference to CENELEC standard EN 50361: 2001) with the
phone transmitting at its highest certified power level in all tested frequency bands3. Although
the SAR is determined at the highest certified power level, the actual SAR level of the phone
while operating can be well below the maximum value. This is because the phone is designed
to operate at multiple power levels so as to use only the power required to reach the network. In
general, the closer you are to a base station antenna, the lower the power output.
The highest SAR value for this M342i model when tested for compliance against the standard
was X,XXXW/kg. While there may be differences between the SAR levels of various phones
and at various positions, they all meet the EU requirements for RF exposure.
Additional information from the World Health Organization (WHO)
Individuals: Present scientific information does not indicate the need for any special precautions for use of mobile phones. If individuals are concerned, they might choose to limit their own
or their children’s’ RF exposure by limiting the length of calls, or using "hands-free" devices to
keep mobile phones away from the head and body.
RF absorbing devices: Scientific evidence does not indicate any need for RF-absorbing
covers or other "absorbing devices" on mobile phones. They cannot be justified on health
grounds and the effectiveness of many such devices in reducing RF exposure is unproven.
Source: WHO Fact Sheet 193, June 2000.
WHO: www.who.int/peh-emf.
) must be shown. This directive includes as one essential requirement the
1. European recommendation 1999/519/EC
2. The SAR limit for mobile phones used by the public is 2.0 watts/kilogram (W/kg) averaged over ten
grams of tissue. The limit incorporates a substantial margin of safety to give additional protection
for the public and to account for any variations in measurements.
3. The maximum level of GSM emitted power is 250mW at 900 MHz and 125 mW at 1800MHz
according to the GSM standard.
4-
Introduction
There are a number of independent sources of information available to users including:
Royal Society of Canada: www.rsc.ca
The International Commission on Non-Ionizing Radiation Protection (ICNIRP): www.icnirp.de
The US Food and Drug Administration: www.fda.gov/cellphones/
The World Health Organization: www.who.int/emf
Melco Mobile Communications Europe S.A. belongs to the MMF, an international association
of radio equipment manufacturers.
The MMF produces information such as this in accordance with its purpose of developing and
presenting industry positions to independent research organisations, government and other
research bodies.
Mobile Manufacturers Forum
Diamant Building, 80 Blvd. A. Reyers
B-1030 Brussels Belgium
www.mmfai.org
Declaration of conformity
Melco Mobile Communications Europe S.A. hereby declares that this M342i (VGM07B) is in compliance with the essential requirements and other relevant provisions of Directive 1999/5/EC.
A copy of the full Declaration of Conformity may be found on our website :
http://www.mitsubishi-telecom.com
General safety
Due to the possibility of radio frequency interference, it is important to follow special regulations regarding the use of radio equipment.
Please follow the safety advice given below.
Switch off your phone and remove the battery when in an aircraft. The use of mobile
telephones in an aircraft may endanger the operation of the aircraft, disrupt the mobile
phone network and is illegal.
Switch off your phone when at any refuelling point or near inflammable material.
Switch off your phone in hospitals and any other place where medical equipment may
be in use.
Respect restrictions on the use of radio equipment in fuel depots, chemical plants or
where blasting operations are in progress.
There may be a hazard associated with the operation of phones close to inadequately
protected personal medical devices such as hearing aids and pacemakers. Consult
your doctor or the manufacturers of the medical device in question to determine
whether it is adequately protected.
Operation of your phone close to other electronic equipment may also cause
interference if the equipment is inadequately protected. Observe any warning signs
and manufacturers recommendations.
Respect national regulations on the use of mobile telephones in vehicles.
Road safety always comes first! Always give your full attention to driving.
- Do not use a hand-held phone while driving. If you do not have a 'hands free' car kit, stop
and park your vehicle safely before using your phone. Please ensure that you are fully aware
of the laws in your country regarding the use of hand-held mobile devices whilst driving.
- If incorrectly installed in a vehicle the operation of mobile telephones can interfere with the
correct operation of the vehicle electronics, such as ABS anti-lock brakes or air bags. To
avoid such problems ensure that only qualified personnel carry out the installation.
- Do not place the phone on the passenger seat or where it could fall during sudden braking
or a collision. Always use the holder.
Vehicle safety
5-
Introduction
Emergency calls
You can make emergency calls by dialling the European standard emergency number 112
even if there is no SIM card in your phone. Emergency calls can even be made if the phone
is PIN or electronically locked or call barred. In some countries local emergency numbers can
still be used for emergency purposes but the phone may have to contain a valid SIM card.
When making an emergency call remember to give all the necessary information as accurately
as possible. As phone may be the only means of communication at the scene of an emergency,
do not cut off the call until told to do so.
Mobile phones rely on wireless and landline networks which cannot be guaranteed in all conditions. You
should therefore never rely solely on wireless phones for essential emergency communications.
Care and maintenance
This mobile telephone is the product of advanced engineering, design and craftsmanship and
should be treated with care. The suggestions below will help you to enjoy this product for
many years.
- Do not expose your phone to any extreme environment where the temperature or humidity is high.
- Do not expose or store your mobile in cold temperatures. When the phone warms up after switch
on, to its normal temperature, moisture may form inside and damage the electrical parts.
- Do not attempt to disassemble the phone. There are no user serviceable parts inside.
- Do not expose your phone to water, rain or spilt beverages. It is not waterproof.
- Do not drop, knock or violently shake your phone. Rough handling may damage it.
- Do not clean your phone with strong chemicals or solvents. Wipe it only with a soft, slightly
dampened cloth.
- Do not place the telephone alongside computer discs, credit or travel cards or other magnetic
media. The information contained on discs or cards may be affected by the phone.
- Do not connect incompatible products. The use of third party equipment or accessories, not
made or authorised by Mitsubishi Electric, invalidates the warranty of your phone and may
be a safety risk.
- Do not remove the labels. The numbers on it are important for aftersales service and other
related purposes.
- Do contact an authorised service centre in case of problem.
AC/DC adaptor charger
This mobile phone was designed to be used only with the supplied AC/DC charger. Use of
any other charger or adaptor invalidates any approval given to this apparatus and may be
dangerous.
Battery use
Batteries may be charged hundreds of times but gradually wear out. When the operating time
(stand-by and talk time) is noticeably shorter than normal, it is time to buy a new battery.
If the battery is totally empty the battery level symbol may not be displayed at once when connecting the battery charger. Moreover the mobile cannot be turned on. Up to 15 minutes may
be necessary to reach the required 4% battery charge to turn your mobile on and allow the
battery charge symbol to be displayed.
- Do not leave batteries connected to a charger longer than necessary. Overcharging shortens
battery life.
- Disconnect battery chargers from the power source when not in use.
- Do not expose batteries to high temperatures or humidity.
- Do not dispose of the batteries in fire. They may explode.
- Avoid putting the batteries into contact with metal objects which can short circuit the battery
terminals (e.g. keys, paper clips, coins, etc.).
- Do not drop or subject the batteries to strong physical shocks.
- Do not try to disassemble any of the battery packs.
- Use only the recommended battery chargers (see above).
- If the battery terminals become soiled, clean them with a soft cloth.
- Batteries may warm up during charging.
6-
Introduction
Battery disposal
In compliance with European environmental protection directives, used batteries must be
returned to the place of sale, where they are collected free of charge.
Don't dispose of your batteries within household waste.
PC cable
The PC cable allows you to connect the GSM mobile telephone to a Personal Computer in
order to exchange data.
Your responsibility
This GSM mobile telephone is your responsibility. Please handle it with care and in respect
of local regulations. Please keep it in a safe place at all times and out of reach of children.
Become familiar with and use the security features to block unauthorised use. If your phone
and/or SIM card are lost or stolen, call your service provider immediately to prevent illegal
use.
When not in use, turn off the phone and remove the battery.
Security codes
The phone and SIM card are delivered to you pre-programmed with codes that protect the
phone and SIM card against unauthorised use. A short description of each follows. See “Security features”, page68 to change your PIN and phonelock codes.
PIN and PIN2 codes (4-8 digits)
All SIM cards have a PIN (Personal Identity Number) that protects the card against unauthorised use.
Entering the wrong PIN code three times disables the SIM card and the message SIM
Blocked is then displayed. Enter PUK: appears.
PUK and PUK2 codes (8 digits).
Please ask your service provider for your PUK code. Use it to unblock a disabled SIM card
(see page “Security features”, page68).
The PUK2 code is required to unblock the PIN2 code (see above).
Call barring password (4 digits)
This password is used to bar various types of calls, made or received, from the phone (see
“Call barring password”, page68).
Phonelock code (4 digits)
This code is set to 0000 on delivery. You can change it. Once changed it cannot be identified by
the manufacturer over the phone. Please refer to “Phone lock code”, page68 for more details.
i-mode lock
The default i-mode lock code is 0000.
It allows you to forbid any unauthorised use of the i-mode feature (see i-mode lock page49).
We advise you remember these codes and make yourself familiar with their purpose and operation.
The packaging used for this phone is made of recyclable materials and as such should be
disposed of in accordance with your national legislation on the protection of the environment.
Please take care to separate the cardboard and plastic elements and to dispose of them in
the correct manner.
Disposing of waste packaging
7-
Using this guide
USING THIS GUIDE
lease carefully read this user guide. It contains information about your phone and the way
that it operates on the network. Some of the features described in this user guide are network dependent. Do not forget to check with your service provider which of these you can use.
You may need to take out additional subscriptions to activate certain features.
Key actions
To help you become quickly familiar with your mobile, here is how to use the keypad.
OK key in the middle of the cursor key (to validate OK on the display and access the
animated Icons menu: see pictures below).
Left softkey (to validate the item above: usually an action).
Right softkey (to validate the action above: usually Exit).
Right arrow on cursor key.
Left arrow on cursor key.
Up arrow on cursor key.
Down arrow on cursor key.
Send and Call key.
In the i-mode menu: access to an options list when indicated.
End, On and Off key.
Icons menu
The availability of the Calendar or Network services menu depends on your
SIM card.
User guide notation
Here is how to follow the instructions contained in this user guide and use your mobile.
Press OK Press the key to select OK (middle of the display).
Press OK. select
Settings.
Select Read (item above
left softkey)
Select ’Cancel’
or ’Exit’ (item above
right softkey)
Select Melodies Use the cursor key to scroll up, down, left or right to the required
View... The ... indicate that more options or sub-menus are available when
From the standby display press the key to access the main menu,
scroll up, down, left or right to the Settings menu item and press OK
to access the sub-menu.
Press the key underneath Read.
From the standby display press once to return to the previous
screen. Press and hold to return to the standby screen (except
whilst in the i-mode menu).
menu item and validate by pressing OK.
E.g. ’Select Melodies’: scroll to Melodies menu item and press the
OK key to validate your selection.
pressing OK.
Using the dynamic scroll panels
When scrolling the menu, the following scroll panel type allows you to have a
clear view of the information to be entered.
8-
Using this guide
1 The list of elements to be entered is displayed. Scroll down to the field(s) you want to fill in
and press OK.
2 Enter the requested information or select the requested item and select OK to validate.
3 Fill in as many fields as necessary and select Save to store all the information entered.
The arrow keys displayed at the bottom of the screen show the scrolling possibilities.
Understanding the graphic display indicators (icons)
Up to eight character lines plus one icons line can be displayed on your mobile screen.
The icons indicate the phone state and operational conditions when in use.
The following icons may be displayed:
SIM memory in use
Phone memory in use: refers to information from the phonebook cards.
GPRS service icon. This indicates that data packet services or connection to the i-mode
are available.
GPRS connection icon. This is displayed when a GPRS connection is in progress.
Roaming. This is displayed when the phone is connected to a network other than its
home network.
Call diverting. This indicates that all incoming calls are being diverted. Call diverting is
network dependent.
Alarm clock.
Vibrator alert.
Keypad lock.
Line 2. This indicates that the second line is in use (subscription dependent).
Silent mode on.
Mute.
Auto-switch-off mode on.
Infrared port. This indicates that the infrared port is active. i.e. that data can be received
via the infrared port.
Short message service (SMS). This is displayed when one or more short messages
have been received and not yet read. flashes when the SMS message box is full
and no new message can be stored. SMS availability is network dependent.
Voice Mail. This is displayed when a Voice Mail message has been received and stored
by the networks Voice Mail centre. Voice Mail availability is network dependent.
Outgoing Call.
Incoming Call.
Withheld number. This is displayed when the caller does not wish his identity to be
shown.
Unanswered call. This is displayed when an incoming has not been answered.
Battery level indicator. This is permanently displayed to show the current battery
charge level. Five levels are shown: from full (5 bars) to low (one bar). If the icon
is empty, the mobile needs recharging.
Signal strength level. There are five strength levels. These show the strength of the
received signal. The more bars, the stronger the signal. If the network cannot be found,
no strength level is displayed.
Tegic edition mode.
9-
Using this guide
Multitap edition mode.
New event. This is displayed on power saver mode to indicate that a new event has
occurred.
Arrow keys. These icons are displayed during menu operation to indicate that more
items in the menu can be access by pressing or .
Secured connection. This icon is displayed when a secured connection is in progress.
Games & Applications software in use.
Games & Applications icon. It is displayed when a game or an application is running.
Problem in launching the Games & Applications connection.
Mail or MMS on mobile
Mail or MMS box on mobile full
Mail on server
MMS on server
Mailbox on server full
MMS box on server full
10-
Getting started
GETTING STARTED
Preparing the phone for operation
Please refer to the Getting started with your M342i booklet.
Basic operations
Turning the phone on
1 Press and hold the On/Off key. A beep sounds at mobile activation. When switching the mobile
on for the first time or if the phone has been incorrectly switched off may be displayed.
2 If your SIM card is PIN protected, Enter PIN is displayed.
Enter the PIN code and select OK.
3 If prompted, enter the date & time settings or select Exit if the settings are correct.
Please refer to "Security codes", page 7 and to "Security features", page 68 for more details on your PIN and
lock codes.
If an image is set as a Welcome screen and/or a melody has been set as a Welcome melody, the
mobile first requests the pin code then shows the selected image/animation and plays the selected
melody before showing the standby display (please see "Setting an image as an Standby display, a
Welcome screen or a Goodbye screen from the pictures folder", page 43 and "Melodies", page 44).
Making a call
The phone can make and receive calls only when it is switched on, when a valid SIM card is
inserted and when it is connected to a GSM or DCS network service.
If the keypad is locked you can receive calls but you cannot make any (see "Keypad lock", page 12).
To make a call:
1 Dial the phone number or select one from your phonebook (press the left arrow key from the
standby display and select one of the available names).
2
Press the Call/Send key ( is displayed).
Whilst in conversation an Options list (AutoDTMF, Hold, Speaker On or Speaker Off, Mute
or Unmute, End call and Record) and Sp.on (Speaker On)/Sp.off (Speaker Off, after the
speaker has been set to On) are available from the left and right softkeys.
In compliance with European regulations, you are obliged to inform your correspondent before
recording a phone conversation.
Answering a call
When receiving a phone call ( is displayed):
1 Press the Call/Send key.
Rejecting a call
When receiving a phone call:
1 Press the On/Off key to reject the call (the call is then forwarded to your mailbox).
11-
Getting started
Ending a call:
1 Press the On/Off key.
Holding your phone (while making or receiving a call)
Avoid
covering the
How to hold
the phone.
When using the hands free mode, do not put the phone to your ear.
The standby display
When switched on, the mobile searches for connection with the network. Once the
connection has been established, a beep sounds and the network and/or service
provider name or logo are displayed together with the time and date, the signal
strength and the battery charge level. If the mobile cannot find a valid network, the
signal strength and the operator name are not displayed.
The four arrows indicate that features can be accesed via the four arrows on the
cursor key.
accessed by pressing the OK key (in the middle of the cursor key).
Mail and i-mode indicate that you can directly access the mailer and the i-mode service by
pressing the softkeys.
indicates that your mobile is attached to a GPRS network.
Keypad lock
When activated, the keypad lock feature prevents accidental action occurrings (e.g. camera activation) whilst the phone is being carried in a pocket or a bag for instance. Incoming calls can however be received and answered. Once the call is over, the keypad lock is automatically reactivated.
To activate the keypad lock from the standby display:
1 Press and hold .Keypad locked is displayed.
To activate the keypad lock from the main menu:
1
2 Select Keypad, then select Keypad lock.
To deactivate the keypad lock:
1 Select Unlock and press or press and hold . Keypad unlocked is displayed.
The oval symbol in the middle of the cursor key indicates that the Menu can be
Press OK. Select Settings.
uper back of the
phone so as to
allow maximum
emission and
reception quality.
12-
Getting started
Turning the phone off
1 Press and hold the On/Off key.
A tone sounds to confirm your action. A Goodbye screen is displayed whilst the mobile switches
off (you can set a Goodbye melody and/or picture to be played/displayed at mobile switch off
(please see "Setting an image as an Standby display, a Welcome screen or a Goodbye screen
from the pictures folder", page 43 and "Melodies", page 44).
Do not take the battery out of the mobile without first turning the phone off. Data might be lost. Should this
happen a first-aid kit symbol is displayed the next time the mobile is activated.
Power saver
To allow you to enjoy optimised use of your mobile a power saver screen is automatically displayed
when the phone has not been used for more than one minute. It displays your service provider
name and the time.
The power saver does not prevent operation. You can therefore receive a call, an SMS, etc.
whilst the power saver is on. The symbol is displayed on power saver mode instead of the
time when an event (new message, unanswered call information,...) has occurred on your mobile. This symbol is displayed until you have read all the new events.
Pressing any key allows you to return to an active screen.
When a PC cable is connected to the mobile and you are using file transfer software, the power saving mode
is not active.
To enjoy optimised use of your mobile standby and talk time, please do not forget to disconnect the PC cable
after use.
13-
Tools
W
TOOLS
hen scrolling to the Tools menu from the main icons menu, direct access to
the Infrared port section is possible by selecting Infrared on the left side of
the display.
The Tools menu allows access to a diary, a calculator, a currency converter,
an alarm clock and the infrared port opening.
Diary
The Diary is divided into three parts:
-The Calendar (to manage events),
-The Tasks list (to manage tasks),
-The Storage used (to provide the diary memory information).
An event is a diary entry that has a direct implication on your timetable (e.g. a meeting).
A task is a diary entry that has no direct implication on your timetable (e.g. organising a journey).
Calendar
The calendar allows you to store up to 100 events scheduled to occur either once, daily, weekly,
monthly or yearly. Each entry can contain up to 50 characters plus a reminder alarm. Events
may be viewed on a daily, a weekly or a monthly basis, and may be sent via the Infrared port
or by SMS.
To enter an event:
1
Press OK. Select Tools.
2 Select Diary.
Select Calendar. A Monthly or Daily view is displayed (the Daily view is displayed if an event
3
is related to the current day).
4 Select Options.
5 Select New event.
An empty new event card is displayed with the following fields:
-Title (up to 10 characters)
-Description (up to 50 characters)
-Starting date & time
-Ending date & time
-Alarm
-Location
-Repetition
6 Enter or select the requested data. Confirm each entry by pressing OK.
7 Select Save to confirm data storage.
To view the current day’s entries:
In the Today view each event is displayed on one line as follows :
-A graphic representation ( ) if an alarm has been set,
-The event starting time,
-The first part of the event title,
Red events indicated that two or more events clash.
1
Press OK. Select Tools.
2 Select Diary.
3 Select Calendar.
4 Select Options.
5 Select View... and then Today to view the current day’s entries or select Day
view to view the selected day’s entries.
14-
Tools
The following actions are available:
ACTIONS PURPOSE
To move down to the next event or loop back to the first one
To move up to the previous event or loop to the last one
To move to the previous day
To move to the next day
An Options list is available. It allows you to change the current View..., Create a new event or
Modify an event, Send it by... infrared port and SMS, Export... it, Delete one event or Delete
all events.
To view weekly entries,
1
Press OK. Select Tools.
2 Select Diary.
3 Select Calendar.
4 Select Options.
5 Select View... and then Week view.
The week’s events are display in chronological order. Each event is represented as a bar (its
length depends on its duration. Red indicates clashes. Purple indicates that the alarm has been
activated).
The following actions are available:
ACTIONS PURPOSE
To move down to the next time interval
To move up to the next time interval
(short press) To move to the previous day
(long press) To scroll to the previous week
(short press) To move to the following day
(long press) To scroll to the following week
An Options list is available. It allows you to change the current View..., Create an event,
Export... the Events in a defined period/All events or Delete all events.
To view monthly entries:
1
Press OK. Select Tools.
2 Select Diary.
3 Select Calendar.
4 Select Options.
5 Select View... and Month view.
The whole month is displayed.
If the selected month is the current one, the date is ringed in a different colour. Colours are used
to indicated the days (and alarm activation) of the stored events.The following actions are available:
ACTIONS PURPOSE
To move down within the current display
To move up within the current display
(short press) To move to the previous day
(long press) To scroll to the previous month
(short press) To move to the following day
(long press) To scroll to the following month
An Options list is available. It allows you to change the current
the
Events in
a defined
period/All events
or
Delete all events
View..., Create
.
an
even
t,
Export...
15-
Tools
Tasks list
This feature allows you to store up to 100 tasks to be done (To do), scheduled with a start and
a due date, with or without a reminder alarm.
To enter a new task:
1
Press OK. Select Tools.
2 Select Diary.
3 Select Tasks list.
4 Select New task and enter the required information.
An empty task card is displayed with the following fields:
- A title (up to 10 characters)
- A description (up to 50 characters)
- A starting date
- A due date
- An audio alarm which can be activated at your specified time
5 Enter or select the requested data. Confirm each entry by pressing OK .
6 Select Save to confirm data storage.
To display a tasks list:
1
Press OK. Select Tools.
2 Select Diary.
3 Select Tasks list .
4 Select Current tasks or Elapsed tasks.
The tasks are displayed in a list, ordered by date. If an alarm is activated for a task is displayed.
An Options list is available. It allows you to create a New task, Modify the current task, Send
a task by... Infrared port or by SMS, to Export... Tasks in period or All tasks, to Delete the
current task or to Delete all tasks period.
Exporting an event/a task
The Export... option allows you to create a file so as to exchange events or tasks with another
device such as a PC or another mobile. The created file can contain all the events or tasks
stored in the calendar or in the tasks list (select All events/tasks) or in a time interval (Select
Events/Tasks in period).
1 Press Options (from the Day, Week or Month view). Scroll down and select Export...
2 Select All events/tasks or select Events/Tasks in period then define the time period
(Between / And) and select Export.
3 The exported file is stored in the Others folder of the Fun & Media box menu. You can then
send it to another device (please see "Others", page 46).
The exported calendar or tasks list item is stored as a .vcs file.
Alarm notification
The alarm notification screen is displayed at the specified time according to the event or task
to which it relates.
If it is not acknowledged, the alarm stops ringing after 60 seconds. It automatically restarts after a
snooze time until it is stopped or up to the beginning/ending time and date of the event/task. If the
phone is off at alarm time, it automatically switches on.
If the phone is locked or if the PIN setting is on, the phone returns to this locked state after the
alarm has rung until you use it.
1 Press Valid to acknowledge the alarm or press Snooze to repeat the alarm after the snooze
period.
Snooze is only available on an event alarm.
16-
Tools
Storage used
This feature displays the number of Diary registered events and tasks. The following actions
are available in the Options menu:
ACTIONS PURPOSE
Delete events To delete the events of the defined time period.
Delete tasks To delete the tasks of the defined time period.
Delete all events To delete all the events stored in Calendar.
Delete all tasks To delete the tasks stored in the Diary.
Calculator
This feature allows you to make simple calculations using + (plus), - (minus), *(multiplication),
/ (division) and % (percentage) functions.
If the currency converter is activated, numbers can be converted during calculations.
To use the calculator,
1
Press OK. Select Tools.
2 Select Calculator .
The phone is ready to perform simple calculations.
Press keys to to enter numbers. Press the multitap (for further details on the multitap
text entry method please see "Entering text", page 22) to get +, -, * and / symbols. Use the
multitap to enter decimal points or %.
Press Clear during a calculation to correct an entry. Press = to get the operation result.
Example 144 x 12 = 1728
In the above example, pressing = again calculates 1728 x 12 = 20736
Pressing Clear deletes the result.
The % function can only be used (entered) as the last operation during a calculation.
e.g.250 - 10% = 225
An integrated currency converter facility is also available. See Currency converter below.
Example
1. This example was made on the basis of the following exchange rate: € 1 = £0.61871
2. The Currency converter feature can be accesed from the Calculator and from the Currency converter submenus.
key sequence display
144
Press 3x *
12
= 1728
using the currency converter £ - €:
€ 154 + € 3 = £ 97.1374
key sequence display
Select Curr.
95.2813
+
1.8561
= 97.1374
Currency converter
This feature allows currency converting. The currencies and exchange rates must be entered
prior to use. The conversion is calculated on the per unit exchange rate of the second selected
currency.
To select the currencies and the exchange rate:
1
Press OK. Select Tools.
17-
Tools
2 Select Currency converter.
3 Select Settings.
4 Enter the first currency name (e.g. Euro). Press OK.
Enter the second currency name (e.g. Dollar). Press OK.
Enter the exchange rate using to enter a decimal point.
5 Press OK to validate the entry. Press Save to confirm data storage.
To calculate the conversion between the selected currencies:
1
Press OK. Select Tools.
2 Select Currency converter.
3 Select one of the first two options.
4 Enter the amount to be converted. Press to insert a decimal point if needed.
5 Press OK. The converted amount and the exchange rate information are displayed.
Alarm clock
This feature allows you to set a daily Reminder Alarm.
To set a time and turn the alarm on:
1
Press OK. Select Tools.
2 Select Alarm clock.
3 Select On and enter the alarm time or press OK to validate the displayed time.
is displayed when reverting to the standby display.
When 'on', the alarm operates at the same time every day until turned off.
If the phone is off at alarm time, it automatically switches on.
If the phone is locked or if the PIN setting is on, the phone returns to this locked state after the
alarm has rung until you use it.
If the alarm is acknowledged but not validated after the 3rd (and final) alarm, the alarm indicators remain on the display for up to 15 minutes (the mobile then either goes back to its 'on' or
'off' previous state).
If a call is in progress at alarm time a 'Call in progress' alert beep sounds and a visual alert is displayed every
3 minutes. Validate or acknowledge the alarm in the usual way.
To use the alarm as a Reminder or a Snooze Alarm:
1 Press No ring, or any other key (except Valid. and OK) to snooze the alarm. The alarm
icons remain on the display and the alarm starts ringing again 3minutes later.
Or press Valid or OK to acknowledge the alarm and stop the alarm clock process.
To turn the alarm off:
1
Press OK. Select Tools.
2 Select Alarm clock .
3 Select Off.
Infrared port
The infrared port allows you to exchange data between the mobile and other devices (provided
they have an infrared port).
You can for instance download or send files such as images for your Standby display (see "Pictures", page 42 ), send or receive name cards,...
To initiate a transfer via the infrared port, your mobile must be facing another infrared port.
Both ports can then be opened and synchronised. The requested transfer can be performed.
Objects (e.g name cards) are transferred one by one.
18-
Tools
Opening the infrared port
Opening the infrared port allows you to receive information via this port.
Once opened, the infrared port can be used for any kind of transfer (data, fax, file transfer,...).
The infrared port is automatically closed after a while.
To open the infrared port,
1
Press OK. Select Tools.
2
Select Infrared port.
3
Select Open. A confirmation message then are displayed to confirm that the port is open.
Closing the infrared port
Closing the infrared port closes all infrared sessions.
To close the infrared port:
1
Press OK. Select Tools.
2 Select Infrared port.
3 Select Close.
The infrared port automatically closes if it remains unused for a while.
Transferring a name card via the infrared port
You can transfer a name card via the infrared port:
1 Place your mobile directly opposite the infrared port of the other device.
2 Open the infrared port of the other device.
3 Select the card you wish to transfer as explained in the section "Viewing and calling phone-
book numbers", page 34.
4 Select Options. Select Send by... Infrared port.
The infrared port open and the transfer is performed.
Using your mobile as a modem
You can use your mobile as a modem for other devices (PC, PDA,...) via the infrared port (on
both devices) or via a PC cable. In order to activate a connection, a standard modem driver
must already be installed in the other appliance:
1 Install the PC cable or open the Infrared port on your PC or PDA.
2 Install the modem driver.
3 Configure the PC according to the instructions given with the modem driver.
Please enter the following parameters:
- Flow control: Hardware
- Data Bits: 8
- Parity: No parity
- Stop Bit: 1 stop Bit
- Speed: 115200b/s
1. The PC cable may not be supplied with your mobile. Please ask your retailer for an M342i compatible PC cable.
2. The compatibility between GPRS and i-mode features is operator dependent.
Your mobile:
1 Plug in the PC cable (please refer to the Getting Started with your M342i booklet).
or:
1 Open your mobile Infrared port.
If your mobile is set to Modem mode, (Please see "Operation mode", page 68) all incoming calls are rejected.
If your mobile is not set to Modem mode, your Internet connection may be interrupted by incoming calls.
Once both devices are ready, the Internet connection can be activated (without any action being
performed on your mobile).
19-
Messages
MESSAGES
T
his section describes the contents of the Messages menu and contains full
information on the Short Message Service. Other types of messages can be
sent and received via your mobile. Please refer to the i-mode section (page49)
for full information on E-mail and MMS.
The Short Message Service (SMS) allows to send or receive text messages to
or from other mobile phones. You can store, edit and forward messages as well
as save any of the numbers they may contain.
SIM card if they are sent by a service provider.
You can access the Messages menu by pressing and holding the Mail softkey from the standby
display.
These SMS are stored on the phone memory; they may also be stored in the
Reading a received sms message
When the phone receives an SMS message, a new SMS alert beep sounds and is displayed
on the Standby display. The message is automatically stored in the phone or in the SIM card.
A flashing indicates that the SIM or the phone memory are full and cannot store any further
messages. Delete messages to allow new messages to be delivered.
1 Press Read to read new messages (from the standby display only).
2
Press Options to View, Reply, Reply (+text), Delete, Delete all, Forward, Send as mail,
Move to SIM or Numbers (to store or call the number(s) contained in the SMS header or
text).
Reading stored sms messages
1 Press OK. Select Messages.Or press and hold the Mail softkey.
2 Select Inbox or SIM archive then select Received messages to display the message list.
Use the arrow key to scroll up and down and access the message you want to read.
3 Select OK or Options/View to read the message text.
Unread messages are indicated by the icon + bold text. Messages that have already been
read are indicated by .
Moving messages to SIM
It is possible to move a message from the Inbox or the Outbox to the SIM memory. However,
according to the message size, the message may be truncated (the 160 first characters only are
moved to the SIM memory). The sending date (for sent messages) and the 'Copy to' addressees
are lost when moving the message to the SIM memory.
To move a message to the SIM memory:
1 Press OK. Select Messages.
2 Select Inbox or Outbox.
3 Choose the message to be moved and select Options .
4 Select Move to SIM.
20-
Messages
Forwarding messages
You can forward a received message to other people/number(s):
1 Press OK. Select Messages.
2 Select Inbox or SIM archive/Received messages.
3 Select the message to be forwarded and select Options.
4 Select Forward.
5 Press OK. Select the To field and select one of the displayed names or select More... if you
want to send your message to another mobile number (directly enter the number). Press OK
to validate.
6 In the Text field enter the message text (see “Entering text”, page22) or select one of the
models (Models) and press OK.
7 If you want to send the message to several addressees, enter one or several phone numbers/
names in the Copy to list (up to 4 more addressees) and press OK then Valid to return to
the previous screen.
8 Select Options.
9 Select Send, Store & send or Store.
10 A warning information displays the number of SMS needed to send the message if it is more
than one. Select Go on if you want to send the message or select Cancel if you do not want
to send it or if you want to amend your message.
Activating or deactivating the message alert tone
Each time a message is received, a new SMS alert tone sounds. To activate or deactivate this tone:
1 Press OK. Select Messages.
2 Select Settings.
3 Select Reception Alert. Select On or Off.
Preparing the phone to send SMS messages
Before sending your first SMS or if you want to register a new profile, the network SMS centre
number (obtainable from your service provider) must be stored:
1 Press OK. Select Messages.
2 Select Settings.
3 Select Sending profile.
4 Enter the message centre number or select a template (if several available) then enter the
following fields (operator dependent).
FIELDS DESCRIPTION DEFAULT
Name To enter the profile name. Profile1
Message
centre
Format To set the message format: text, voice, fax or paging. Text
Validity
period
5 Select Save to validate.
The SMS centre number may already be available in your SIM card and may be automatically
displayed. If you want to select a Sending profile for your message:
1 Press OK. Select Messages.
2 Select Settings.
3 Select Sending profile and select the profile you want to use. Select Options.
4 Select Select.
To enter the centre number. Empty
Time the message remains at the message centre
until delivered.
You may not be allowed to change your sending profile (format and validity period). Please contact your service provider for further details.
Maximum
21-
Messages
Entering text
Some features and functions (storing names in the phonebook or typing SMS text messages,
Tools, Settings,...) require you to know how to enter and edit text in the display.
Three modes are available. They are indicated by in lower case mode, by in upper case
mode and by in numeric mode. Text, figures and alphabet characters can then be entered
or edited directly from the keypad. Press to switch from one mode to another.
There are two methods of entering text characters: the Multitap or Multipress key method, and
the quicker intuitive method, called T9 text input.
Press the down arrow key to swap between the T9 and the Multitap methods. When on T9
mode, is displayed on the upper part of the display to indicate that T9 is the current mode.
is displayed on the lower part of the screen to indicate that the Multitap text method can
be accessed by pressing the down arrow key. When on Multitap mode, is displayed on the
upper part of the display to indicate that Multitap is the current mode. is displayed on the
lower part of the screen to indicate that the T9 method can be accessed by pressing the down
arrow key.
The multitap/multipress method
A brief press on a key displays the first character associated with the key and shows the other
available characters at the top of the display. Here is the list of the available characters (the
available characters list is language dependent):
KEY CHARACTER
Short press: moves the cursor through the text one place to the left or to the right.
To enter text, press the key bearing the required character until it appears in the display. Holding the key displays the number corresponding to the key. If you need to use two characters
from the same key, wait for a few seconds after entering the first character (until the key characters on the upper part of the screen are cleared) or press the right arrow key before pressing
the key again.
Correct mistakes by a short press on Clear.
Holding the Clear key deletes all the text. Use the left or right arrow keys to move the cursor in
the text. Holding allows you access to 25 special characters:
Lower case Upper case
1 . , - ' @ : ?
a b c 2 A B C 2
d e f 3 D E F 3
g h i 4 G H I 4
j k l 5 JK L 5
m n o 6 M N O 6
p q r s 7 P Q R S 7
t u v 8 T U V 8
w x y z 9 W X Y Z 9
0 0
Short press : to switch mode (T9 or multitap) to lower case, upper case or
numeric mode.
Long press : to switch from lower case to upper case. Only the first letter entered
is upper case, the following ones are lower case (e.g.: to write a surname).
Short press: to enter a space.
Long press: to access special characters.
Long press: moves the cursor to the text beginning or end.
Swap between the Multitap/Multipress method and the T9 text input
To select and insert a character into the text:
1 Move the cursor to the required character.
2 Select OK.
The ↵ symbol is only displayed when on SMS and i-mode.
It allows you to go to the following line.
22-
Messages
Multitap method:
Example To type Card:
Press OK and select Messages.
Select Write new.
Fill in the To field (see “Sending a new SMS message”, page24).
In the Text field, press the until is displayed. Press briefly three
times, C is displayed.
Press until is displayed. Press once, a is displayed
Press three times, r is displayed
Press once, d is displayed. The word Card is now displayed.
The T9 method:
A press on the down arrow key allows you to swap between T9 text entry and the Multitap method.
1 Press the key bearing the required letter once only (the requested character may not be dis-
played first).
2 The active word changes as you enter text. Enter all the word characters up to the end of the
word.
3 If the right word is not displayed when all the characters have been entered, press until
you get the required word.
4 If the requested word does not correspond to the one displayed, press the down arrow key to
swap to the multitap method and enter the correct letters.
5 Use the left or right arrow keys to move the cursor around the text to insert or delete charac-
ters.
To insert a text symbol such as :) or :-) or press two or three times. Press as many times as necessary
to change the symbol to :( or :-( etc.
Tips and Operation
KEY ACTION
Short press : to switch mode (T9 or multitap) to lower case, upper case or
numeric mode.
Long press : to switch from lower case to upper case. Only the first letter entered
is upper case, the following ones are lower case (e.g.: to write a surname).
Clear Clear or backspace
Short press: to enter a space.
Long press: to access special characters.
Another matching word
Smart punctuation
Short press: moves the cursor to each word beginning or end .
Long press: moves the cursor to the text beginning or end .
Swap between the T9 and the Multitap method
Example To write card:
Press OK and select Messages.
Select Write new .
Fill in the To field (see “Sending a new SMS message”, page24).
In the Text field, press the down arrow key until is displayed.
Press , a appears.
Press , cc appears.
Press , car appears.
Press , case appears.
If the displayed word is not the one you want, press as many times as
necessary to view card.
23-
Messages
Creating text models
You can create a set of messages to be used as models. These texts can contain up to 50 characters and allows you to add text when you want to use them. These templates are stored in
the mobile memory.
To create text models:
1 Press OK. Select Messages.
2 Select Text models.
3 Choose any blank template ([...]) and press OK.
4 Enter the template text and press OK.
Editing a text model
1 Press OK. Select Messages.
2 Select Text models.
3 Select the text model to be modified and press OK.
4 Edit the text and press OK.
Sending a new SMS message
You can send message texts (up to 918 characters). The standard size for an SMS is 160 characters (your service provider charges you according to the number of SMS used to send your
message). The icon (1 = number of SMS used - it is updated while writing your message
and shows the number of SMS needed to send your message) is displayed on the left corner
of the screen.
To send SMS from the Menu:
1 Press OK. Select Messages.
2 Select Write new.
3 Press OK. Select the To field and choose one of the displayed names or select More... if
you want to send your message to another mobile number (directly enter the number). Press
OK to validate.
4 In the Text field, enter the message text (see “Entering text”, page22) or select one of the
models (Models ) and press OK.
5 If you want to send the message to several addressees, enter one or several phone num-
bers/names in the Copy to list (up to 4 more addressees) and press OK then Valid to
return to the previous screen.
6 Select Options.
7 Select Send, Store & send or Store.
8 A warning information displays the number of SMS needed to send the message if it is more
than one. Select Go on if you want to send the message or select Cancel if you do not want
to send it or if you want to amend your message.
If you have registered an automatic signature, the number of characters used is automatically added to the
message length.
To send SMS from the standby display:
1 Press the left arrow key to access the phonebook. Select one of the available names or numbers.
2 Select Options.
3 Scroll down and select Send SMS to, then proceed as described above.
or:
1 Press and hold the softkey underneath Mail.
2 Select Write new, then proceed as described above.
24-
Loading...
