Mekotron Hoverboard User Manual

User Manual
Руководство пользователя
Thank you for purchasing our product. For optimum performance and safety, please read these instructions
carefully before operating the product. Please keep this manual for future reference.
Package content: Hoverboard, power supply, user manual
Модели: HB-0060K, HB-0060W
Ver. 1.3 03/2018
2. Product Description.....................................................................................1
3. Operating Principles....................................................................................1
5. Weight and Speed Limitations.............................................................3
6. Operating Range...........................................................................................4
7. Battery Information and Specifications........................................4
8. Charging your Hoverboard....................................................................4
9. Safety Alerts....................................................................................................5
10. Inspection, Maintenance, and Storage........................................5
11. Hoverboard Specifications...................................................................5
12. Thank You........................................................................................................5
1. Обзор продукта............................................................................................7
2. Описание продукта...................................................................................7
3. Принципы работы.......................................................................................7
4. Меры безопасности.................................................................................9
5. Ограничения веса и скорости.........................................................9
7. Информация о батарее и спецификации............................10
8. Зарядка ховерборда.............................................................................10
9. Предупреждающие сигналы..........................................................10
10. Осмотр, техническое обслуживание и хранение........11
11. Технические характеристики........................................................11
12. Спасибо..........................................................................................................11
Congratulations on the purchase of your new MEKOTRON Hoverboard. The information in this User Manual will help you better understand, enjoy and maintain your hoverboard. PLEASE READ THE USER MANUAL THOROUGHLY BEFORE OPERATING and we highly recommend you start your hoverboard experience with a friend. Having
a spotter during initial use will increase your confidence and help you get used to your hoverboard. Always wear the proper safety gear before operating. Enjoy your MEKOTRON Hoverboard!
WARNING! IMPROPER USE OF THE HOVERBOARD AND/OR FAILURE TO READ THIS USER MANUAL MAY LEAD TO SERIOUS BODILY INJURY AND DEATH.
Self-balancing hoverboards are powered vehicles and they are illegal to ride on the pavement or roads of the UK under section 72 of the Highway Act 1835, and in Scotland under the Roads (Scotland Act 1984).
For more information, please visit http://www.cps.gov.uk/legal/p_to_r/road_traffic_offences/#dot.
1. Product Overview
1.1. General Information
The original hoverboard is an intuitive, technologically advanced solution that provides the user personal transportation based on dynamic balancing principles calculating the user’s center of gravity using gyroscope and acceleration sensors. Using the latest technology and production processes, each hoverboard
undergoes strict testing for quality and durability. With its lightweight, portable design, ease of use, range, and low carbon footprint.
1.2. What You Need To Know
Before you first experience your hoverboard, please read the USER MANUAL thoroughly and learn the basics to ensure your safety and the safety of others. It is highly recommended that your initial hoverboard experience be with a spotter who can assist you in centering your balance. Once you keep your center of gravity even, you will be able to stand on the hoverboard without moving, similar to standing on the ground. The most important thing to do is stay relaxed and
confident. The hoverboard is very intuitive and senses the slightest motion, so finding your center of balance is the key. Step on quickly, confidently, and evenly, but remember to keep your body still. Please refrain from flaying your arms, leaning too far forward and/or backwards, or stepping on your hoverboard unevenly,
as this will cause you to lose control and increase your probability of injury. Please follow the detailed directions outlined in the USER MANUAL in Section 3 under
Operating Principles.
1.3. WARNING
Failure to follow the basic instructions and safety precautions listed in the USER MANUAL, can lead to damages to your hoverboard, other property damages, serious bodily injury, and even death.
2. Product Description
2.1. Description of the hoverboard
The hoverboard has two wheels that balance and transport the user using battery powered brushless motors. The hoverboard uses digital gyroscope modules and acceleration sensors to calculate the user’s center of gravity and move the device accordingly. The hoverboard can move forwards, backwards, turn in either direction or turn in place. The compact footprint and zero degree turning radius allow you to enjoy your hoverboard both indoors and outdoors.
2.2. Description of Hoverboard Components
1. Fender
2. Footprint & Sensors
3. Displays
4. Engine & Tire
5. LED
6. Underbody protection
1 5 6 156
4
2 23 3
3. Operating Principles
3.1. How the Hoverboard works
The hoverboard uses digital electronic gyroscopes and acceleration sensors to control balance and motion intelligently, depending on the user’s center of gravity. The device also uses an intelligent control system to drive the brushless motors that are located within the wheels. The hoverboard has a built-in inertia dynamic stabilization system that can help assist with balance when moving forward and backwards, but not while turning. To increase your stability, you must shift your weight in order to overcome the centrifugal force during turns, especially when entering a turn at higher speeds.
3.2. PLEASE READ THE FOLLOWING INSTRUCTIONS CAREFULLY Step 1: Getting Started - Take your hoverboard out of the box and place it flat on the floor. Press the power button, located on the front of your hoverboard, next
to the 3-pin charging port.
Power button
Step 2: Checking the Display Board - located in the center of your hoverboard. The hoverboard should power on and beep indicating it is on. The Battery indicator
light should be lit, indicating there is power.
Battery Indicator
A. Battery Indicator: The solid LED light indicates the hoverboard is charged and when the remaining battery capacity is down to 10% a buzzer will alarm
telling you to recharge the device.
B. Running Indicator: As soon as you step onto the footmats,, the Running Indicator LED will light up, which means that the system enters the running state; when the system has an error during operation, the running LED light will turn red and you will hear the system alert you with a beep.
1 | English
3-pin Charging Port
Running Indicator
Step 3: Charging your hoverboard - Make sure the hoverboard is fully charged before
your initial use. For charging instructions, please follow details in Section 8 under Charging your Hoverboard. Step 4: Protective Gear - Wear all proper protective gear, including, but not limited to a helmet, knee pads, elbow pads, and wrist guards.
Helmet
Elbow Pads
NOTE – Stay relaxed, stand evenly, and apply an equal amount of pressure on both sides of the device. Relax your muscles as much as you can. Taking a deep breath and exhaling can help you achieve this. Slightly bending your knees can also help. Once you can stand IDLE and STOP, you are ready for the next step.
Wrist Guards
Knee Pads
Step 5: Stepping On - Stand directly behind your hoverboard. Place one foot
on the hoverboard. Keep all your weight on your back foot still on the ground. Otherwise, your device will begin to move, making it difficult to step on evenly with your other foot.
When you are ready, shift your weight to the foot already placed on the device and step on with your second foot quickly and evenly (as described in the diagram below).
If you begin to turn in a particular direction, focus on turning in the opposite direction to stop turning. When you first begin using your hoverboard, the
fastest way to move in your desired direction is to focus in that direction. You
will notice that just thinking about which way you would like to go will shift your
center of gravity, and that subtle movement will propel you in that direction.
Step 7: Riding your hoverboard - Keeping in mind what we learned in Step 6, apply the following general principles to the operation of your hoverboard.
TO MOVE BACKWARDS TO STOP TO MOVE FORWARDS
Notice in the diagram above, your center of gravity determines which
direction you move, accelerate, decelerate, and come to a complete stop.
CAUTION - Try staying relaxed and focus on finding your center of gravity to maintain full control. Tilt your center of gravity in the direction you wish to move. To turn, focus on the direction you wish to turn and stay relaxed. The more comfortable you get on the hoverboard, the easier you will maneuver. Remember at higher speeds, it is necessary to shift your weight to overcome the centrifu­gal force. For bumps or uneven roads, bend your knees.
CAUTION – Stay relaxed and step on quickly, confidently and evenly. Imagine climbing a stair, one foot, then the other. Once your feet are even, try to look up and once on the hoverboard it will take a few seconds to adjust the center of gravity according to your weight and friction on the road.
Step 6: Staying Balanced - Find your center of gravity. If your weight is distributed correctly on the foot mats, and your center of gravity is level, you should be able to stand on your hoverboard, just as if you were standing on the ground. IF NOT, you may feel like you are moving in a particular direction, turning, spinning in place, wobbling back and forth, or simply uncomfortable with the device.
CAUTION – On average, it takes 3-5 minutes just to get comfortable standing on the hoverboard and maintaining proper balance. Having a spotter will help you feel more secure. The hoverboard is an incredibly intuitive device; it senses even the slightest bit of motion, so having any anxiety or reservation about stepping on may cause you to panic and trigger movement that is not otherwise natural to you. The best way to overcome that initial anxiety is by having a spotter.
Step 8: The Dismount - Stepping off of the hoverboard can be one of the easiest steps, yet when done improperly, may cause you to fall. To properly dismount, from a stopped position, lift one leg up and set your foot back down on the ground (STEPPING BACK). Then step off completely.
CAUTION - A common error is to try and step forward.
A B
FIRST THEN
WARNING – make sure to lift your leg completely off to clear the device when stepping back, otherwise you can get sent into a tailspin.
English | 2
