MEITRACK MVT100/MVT340/MVT380 GPRS Protocol

MEITRACK MVT100/MVT340/MVT380

GPRS Protocol

Applicable Model: MVT100/MVT340/MVT380

MEITRACK MVT100/MVT340/MVT380 GPRS Protocol

File Name

MEITRACK MVT100/MVT340/MVT380

GPRS Protocol

Created By

Kyle Lv

Project

MVT100/MVT340/MVT380

Creation Date

Update Date

2017-01-20

Subproject

GPRS Protocol

Total Pages

23

Version

V1.0

Confidential

Internal Documentation

Change History

MEITRACK MVT100/MVT340/MVT380 GPRS Protocol

Contents

1 Command Format ..........................................................................................................................................................................- 5 -

1.1 GPRS Command Format .....................................................................................................................................................- 5 -

1.2 Tracker Command Format ..................................................................................................................................................- 5 -

1.3 Event Code ..........................................................................................................................................................................- 8 -

2 Command List ................................................................................................................................................................................- 9 -

3 Command Details ........................................................................................................................................................................- 10 -

3.1 Real-Time Location Query – A10 ......................................................................................................................................- 10 -

3.2 Setting a Heartbeat Packet Reporting Interval – A11 ........................................................................................................- 10 -

3.3 Tracking by Time Interval – A12 ........................................................................................................................................- 10 -

3.4 Setting the Cornering Report Function – A13 ...................................................................................................................- 11 -

3.5 Tracking by Distance – A14 ...............................................................................................................................................- 11 -

3.6 Setting the Parking Scheduled Tracking Function – A15 ...................................................................................................- 12 -

3.7 Enabling the Parking Scheduled Tracking Function – A16 .................................................................................................- 12 -

3.8 Setting GPRS Parameters – A21 ........................................................................................................................................- 12 -

3.9 Setting the DNS Server IP Address – A22 ..........................................................................................................................- 13 -

3.10 Setting the Standby GPRS Server – A23 ..........................................................................................................................- 13 -

3.11 Reading All Authorized Phone Numbers – A70 ...............................................................................................................- 14 -

3.12 Setting Authorized Phone Numbers – A71 .....................................................................................................................- 14 -

3.13 Setting Listen-in Phone Numbers – A72 .........................................................................................................................- 14 -

3.14 Setting the Smart Sleep Mode – A73 ..............................................................................................................................- 15 -

3.15 Automatic Event Report – AAA .......................................................................................................................................- 15 -

3.16 Deleting a GPRS Event in the Buffer – AFF ......................................................................................................................- 15 -

3.17 Setting a Geo-Fence – B05 ..............................................................................................................................................- 16 -

3.18 Deleting a Geo-Fence – B06 ............................................................................................................................................- 16 -

3.19 Setting the Speeding Alarm Function – B07 ...................................................................................................................- 17 -

3.20 Setting the Towing Alarm Function – B08 .......................................................................................................................- 17 -

3.21 Setting the Anti-Theft Function – B21 ............................................................................................................................- 17 -

3.22 Turning off the LED Indicator – B31 ................................................................................................................................- 18 -

3.23 Setting a Log Interval – B34 ............................................................................................................................................- 18 -

3.24 Setting the SMS Time Zone – B35 ...................................................................................................................................- 18 -

3.25 Setting the GPRS Time Zone – B36 .................................................................................................................................- 19 -

3.26 Checking the Engine First to Determine Tracker Running Status – B60 .........................................................................- 19 -

3.27 Setting SMS Event Characters – B91 ...............................................................................................................................- 19 -

3.28 Setting Event Authorization – B99 ..................................................................................................................................- 20 -

3.29 Controlling Output Status – C01 .....................................................................................................................................- 20 -

3.30 Notifying the Tracker of Sending an SMS – C02 ..............................................................................................................- 21 -

3.31 Setting a GPRS Event Transmission Mode – C03 .............................................................................................................- 21 -

3.32 Reading Device's Firmware Version and SN – E91 ..........................................................................................................- 22 -

3.33 Restarting the GSM Module – F01 ..................................................................................................................................- 22 -

3.34 Restarting the GPS Module – F02 ...................................................................................................................................- 22 -

3.35 Setting the Mileage and Run Time – F08 ........................................................................................................................- 22 -

3.36 Deleting SMS/GPRS Cache Data – F09 ............................................................................................................................- 23 -

MEITRACK MVT100/MVT340/MVT380 GPRS Protocol

3.37 Restoring Initial Settings – F11 ........................................................................................................................................- 23 -

MEITRACK MVT100/MVT340/MVT380 GPRS Protocol

Parameter

Description

Example

@@

Indicates the GPRS data packet header sent from the server to the

tracker. The header type is ASCII. (Hexadecimal is represented as

0x40.)

@@

$$

Indicates the GPRS data packet header sent from the tracker to the

server. The header type is ASCII. (Hexadecimal is represented as

0x24.)

$$

Data identifier

Contains 1 byte. The type is the ASCII, and its value ranges from

0x41 to 0x7A.

Q

Data length

Indicates the length of characters from the first comma (,) to \r\n.

Decimal.

Example: $$<Data identifier><Data length>,<IMEI>,<Command

type>,<Command><* Checksum>\r\n

25

IMEI

Indicates the tracker IMEI number. The number type is ASCII. It has

15 digits generally.

353358017784062

Command type

Hexadecimal

For details, see chapter 2 and chapter 3.

AAA

Event code

Decimal

For details, see section 1.3 "Event Code."

1

Latitude

(-)yy.dddddd

Unit: degree

Decimal

When a minus (-) exists, the tracker is in the southern hemisphere.

22.756325 (indicates

22.756325°N)

-23.256438 (indicates

1 Command Format

1.1 GPRS Command Format

 GPRS command sent from the server to the tracker:

@@<Data identifier><Data length>,<IMEI>,<Command type>,<Command><*Checksum>\r\n

 GPRS command sent from the tracker to the server:

$$<Data identifier><Data length>,<IMEI>,<Command type>,<Command><*Checksum>\r\n

1.2 Tracker Command Format

$$<Data identifier><Data length>,<IMEI>,<Command type>,<Event code>,<(-)Latitude>,<(-)Longitude>,<Date and

time>,<Positioning status>,<Number of satellites>,<GSM signal strength>,<Speed>,<Direction>,<Horizontal dilution of precision

(HDOP)>,<Altitude>,<Mileage>,<Run time>,<Base station info>,<I/O port status>,<Analog input value>,<Geo-fence

number><*Checksum>\r\n

Note:

 A comma (,) is used to separate data characters. The character type is the American Standard Code for Information

Interchange (ASCII). (Hexadecimal is represented as 0x2C.)

 Symbols "<" and ">" will not be present in actual data, only for documentation purpose only.  All multi-byte data complies with the following rule: High bytes are prior to low bytes.  The size of a GPRS data packet is about 160 bytes.

Descriptions about GPRS packets from the tracker are as follows:

MEITRACK MVT100/MVT340/MVT380 GPRS Protocol

When no minus (-) exists, the tracker is in the northern hemisphere.

yy indicates the degree.

dddddd indicates the decimal part.

23.256438°S)

Longitude

(-)xxx.dddddd

Unit: degree

Decimal

When a minus (-) exists, the tracker is in the western hemisphere.

When no minus (-) exists, the tracker is in the eastern hemisphere.

xxx indicates the degree.

dddddd indicates the decimal part.

114.752146 (indicates

114.752146°E)

-114.821453 (indicates

114.821453°W)

Date and time

yymmddHHMMSS

yy indicates year.

mm indicates month.

dd indicates day.

HH indicates hour.

MM indicates minute.

SS indicates second.

Decimal

091221102631

Indicates 21 December

2009, 10:26:31 am.

Positioning status

Indicates the GPS signal status.

A = Valid

V = Invalid

A

The GPS is valid.

Number of satellites

Indicates the number of received GPS satellites.

Decimal

5

Five GPS satellites are

received.

GSM signal strength

Value: 0–31

Decimal

12

The signal strength is 12.

Speed

Unit: km/h

Decimal

58

The speed is 58 km/h.

Direction

Indicates the driving direction. The unit is degree. When the value is

0, the direction is north. The value ranges from 0 to 359.

Decimal

45: indicates that the

location is at northeast.

90: indicates that the

location is at east.

HDOP

The value ranges from 0.5 to 99.9. The smaller the value is, the

more the accuracy is.

Decimal

When the accuracy value is 0, the signal is invalid.

0.5–1: Perfect

2–3: Wonderful

4–6: Good

7–8: Medium

9–20: Below average

21–99.9: Poor

5

The HDOP is 5.

Altitude

Unit: meter

Decimal

118

Mileage

Unit: meter

564870

MEITRACK MVT100/MVT340/MVT380 GPRS Protocol

Decimal

Indicates the total mileage. The maximum value is 4294967295. If

the value exceeds the maximum value, it will be automatically

cleared.

Run time

Unit: second

Decimal

Indicates the total time. The maximum value is 4294967295. If the

value exceeds the maximum value, it will be automatically cleared.

2546321

Base station info

The base station information includes:

MCC|MNC|LAC|CI

The MCC and MNC are decimal, while the LAC and CI are

hexadecimal.

Note: Base station information in an SMS is empty.

460|0|E166|A08B

I/O port status

Hexadecimal

Status values of eight input ports and eight output ports:

Bit0 to Bit7 corresponds to status of output ports 1 to 8.

Bit8 to Bit15 corresponds to status of input ports 1 to 8.

0421 (hexadecimal) =

0000 0100 0010 0001

Analog input value

Separated by "|".

Hexadecimal

AD1|AD2|AD3|Battery analog|External power analog

Note: Analog input values in an SMS report are empty.

Voltage formula of analog AD (AD1, AD2, and AD3):

MVT340/MVT380: (AD x 6)/1024

MVT100: (AD x 3.3 x 2)/4096

Voltage formula of battery analog (AD4):

MVT340/MVT380: (AD4 x 3 x 2)/1024

MVT100: (AD4 x 3.3 x 2)/4096

Voltage formula of external power supply (AD5):

MVT340/MVT380: (AD5 x 3 x 16)/1024

MVT100: (AD5 x 3.3 x 16)/4096

123|456|235|1456|222

(Hexadecimal)

Geo-fence number

32-bit unsigned

Only available by GPRS event code 20 or 21.

02 00 00 00 (indicates

geo-fence 2)

*

Separates commands from checksums.

1 byte and ASCII (Hexadecimal is represented as 0x2A)

*

Checksum

2 bytes. The parameter indicates the sum of all data (excluding the

checksum and ending mark). It is a hexadecimal character.

Example: $$<Data identifier><Data length>,<IMEI>,<Command

type>,<Command><*Checksum>\r\n

BE

\r\n

2 bytes. The parameter is an ending character. The type is ASCII.

(Hexadecimal value: 0x0d 0x0a)

\r\n

MEITRACK MVT100/MVT340/MVT380 GPRS Protocol

Event Code

Event

Default SMS Header (At Most 16 Bytes)

1

SOS Pressed

SOS

2

Input 2 Active

Ignition On: MVT100&MVT340

Door Open: MVT380

3

Input 3 Active

In3 Active

4

Input 4 Active

Ignition On: MVT380

5

Input 5 Active

In5 Active

9

Input 1 Inactive

In1 Inactive

10

Input 2 Inactive

Ignition Off: MVT100&MVT340

Door Close: MVT380

11

Input 3 Inactive

In3 Inactive

12

Input 4 Inactive

Ignition Off: MVT380

13

Input 5 Inactive

In5 Inactive

17

Low Battery

18

Low External Battery

Low Ext-Battery

19

Speeding

20

Enter Geo-fence

Enter Fence N (N means the number of the fence)

21

Exit Geo-fence

Exit Fence N (N means the number of the fence)

22

External Battery On

Ext-Battery On

23

External Battery Cut

Ext-Battery Cut

24

GPS Signal Lost

25

GPS Signal Recovery

GPS Recovery

26

Enter Sleep

27

Exit Sleep

28

GPS Antenna Cut

29

Device Reboot

Power On

31

Heartbeat

/

32

Cornering

33

Track By Distance

Distance

34

Reply Current (Passive)

Now

35

Track By Time Interval

Interval

36

Tow

65

Press Input 1 (SOS) to Call

/

66

Press Input 2 to Call

/

67

Press Input 3 to Call

/

68

Press Input 4 to Call

/

69

Press Input 5 to Call

/

70

Reject Incoming Call

/

71

Get Location by Call

/

72

Auto Answer Incoming Call

/

1.3 Event Code

MEITRACK MVT100/MVT340/MVT380 GPRS Protocol

73

Listen-in (Voice Monitoring)

/

Command

Command Description

A10

Real-Time Location Query

A11

Setting a Heartbeat Packet Reporting Interval

A12

Tracking by Time Interval

A13

Setting the Cornering Report Function

A14

Tracking by Distance

A15

Setting the Parking Scheduled Tracking Function

A16

Enabling the Parking Scheduled Tracking Function

A21

Setting GPRS Parameters

A22

Setting the DNS Server IP Address

A23

Setting the Standby GPRS Server

A70

Reading All Authorized Phone Numbers

A71

Setting Authorized Phone Numbers

A72

Setting Listen-in Phone Numbers

A73

Setting the Smart Sleep Mode

AAA

Automatic Event Report

AFF

Deleting a GPRS Event in the Buffer

B05

Setting a Geo-Fence

B06

Deleting a Geo-Fence

B07

Setting the Speeding Alarm Function

B08

Setting the Towing Alarm Function

B21

Setting the Anti-Theft Function

B31

Turning off the LED Indicator

B34

Setting a Log Interval

B35

Setting the SMS Time Zone

B36

Setting the GPRS Time Zone

B60

Checking the Engine First to Determine Tracker Running Status

B91

Setting SMS Event Characters

B99

Setting Event Authorization

C01

Output Control

C02

Notifying the Tracker of Sending an SMS

C03

Setting a GPRS Event Transmission Mode

E91

Reading Device's Firmware Version and SN

F01

Restarting the GSM Module

F02

Restarting the GPS Module

F08

Setting the Mileage and Run Time

F09

Deleting SMS/GPRS Cache Data

F11

Restoring Initial Settings

2 Command List

MEITRACK MVT100/MVT340/MVT380 GPRS Protocol

GPRS Sending

A10

GPRS Reply

AAA,34,(-)Latitude,(-)Longitude,Date and time,Positioning status,Number of

satellites,GSM signal strength,Speed,Direction,HDOP,Altitude,Mileage,Run time,Base

station info,I/O port status,Analog input value

Description

34: indicates the GPRS command event code.

Example

GPRS Sending

@@Q25,353358017784062,A10*6A\r\n

GPRS Reply

$$Q128,353358017784062,AAA,34,22.543176,114.078448,100313093738,A,5,22,2,205

,5,-14,0,60,0|0|10133|4110,0000,149|153|173|2707|914,*91\r\n

GPRS Sending

A11,Interval

GPRS Reply

A11,OK

Description

The heartbeat packet function is used to keep the Transmission Control Protocol (TCP)

connection open when the interval of scheduled GPRS reporting is long.

Interval = 0: function disabled (default).

Interval = [1…65535]: function enabled. Unit: minute.

The heartbeat function is available only in conjunction with deep sleep mode. When the

device enters deep sleep mode, heartbeat reports will be sent at the specified interval.

A heartbeat report is to confirm the device is online, but positioning data is invalid.

Example

GPRS Sending

@@S28,353358017784062,A11,10*FD\r\n

GPRS Reply

$$S28,353358017784062,A11,OK*FE\r\n

After the above command is run successfully, the tracker will send the following GPRS

heartbeat packet to the platform every 10 minutes in sleep mode:

$$a131,353358017784062,AAA,31,22.913458,114.083183,080229123628,V,9,23,21,83,

1,18,1350,127,0|0|10133|4110,0000,169|181|184|2714|919,*60

GPRS Sending

A12,Interval

GPRS Reply

A12,OK

Description

Unit: x10 seconds

Interval = 0: function disabled.

The maximum time interval is 65535 x 10 seconds.

6 x 10 seconds are recommended.

Example

GPRS Sending

@@V27,353358017784062,A12,6*D5\r\n

3 Command Details

3.1 Real-Time Location Query – A10

3.2 Setting a Heartbeat Packet Reporting Interval – A11

3.3 Tracking by Time Interval – A12

MEITRACK MVT100/MVT340/MVT380 GPRS Protocol

GPRS Reply

$$V28,353358017784062,A12,OK*02\r\n

After the above command is run successfully, the tracker will send the following GPRS

data packet to the platform every 1 minute:

$$W129,353358017784062,AAA,35,22.540113,114.076141,100313094354,A,5,22,1,17

4,4,129,0,435,0|0|10133|4110,0000,166|224|193|2704|916,*BE\r\n

GPRS Sending

A13,Angle

GPRS Reply

A13,OK

Description

When the driving angle exceeds the preset value, the tracker will send a GPRS data

packet with location information to the server, which ensures a smoother route on the

platform.

Angle = 0: function disabled (default).

Angle = [1…359]: function enabled. Recommended value: 30.

Example

GPRS Sending

@@X29,353358017784062,A13,120*37\r\n

GPRS Reply

$$X28,353358017784062,A13,OK*05\r\n

After the above command is run successfully, if the cornering angle is greater than 120

degree, the tracker will send the following GPRS data pakcet to the server:

$$Y129,353358017784062,AAA,32,22.540968,114.077455,100313094534,A,4,22,1,166,

3,175,0,534,0|0|10133|4110,0000,141|138|159|2691|904,*D9\r\n

GPRS Sending

A14,Distance

GPRS Reply

A14,OK

Description

Distance = 0: function disabled (default).

Distance = [1…65535]: function enabled. Unit: meter.

Note: When both the GPRS time interval and distance tracking functions are enabled,

the "first reach first report" rule will be applied. For example, set the time interval to 6 x

10 seconds and distance to 200 meters. If the road is clear, a distance data packet will be

reported first; if there is heavy traffic on the road, a time interval data packet will be

reported first. Then both the time interval and distance counters will be reset to 0.

300 is recommended.

Example

GPRS Sending

@@D30,353358017784062,A14,1000*4A\r\n

GPRS Reply

$$D28,353358017784062,A14,OK*F2\r\n

After the above command is run successfully, if the driving distance reaches 1000m, the

tracker will send a data packet to the server.

$$D131,353358017784062,AAA,33,22.547271,114.047405,080310080929,A,8,21,13,89

,1,12,8525,561,0|0|10133|4110,0000,163|185|186|2712|939,*31\r\n

3.4 Setting the Cornering Report Function – A13

3.5 Tracking by Distance – A14

MEITRACK MVT100/MVT340/MVT380 GPRS Protocol

GPRS Sending

A15,Interval

GPRS Reply

A15,OK

Description

The function is available for vehicle trackers only. With the function, the number of

GPRS messages is reduced, and thus GPRS traffic is saved.

After the A15 function is set, the A16 function is automatically enabled. For details

about engine status, see section 3.7 "Enabling the Parking Scheduled Tracking Function

– A16."

Interval unit: x10 seconds

Interval = 0: function disabled.

The maximum interval is 65535 x 10 seconds.

Note: If data needs to be sent at the specified interval after the vehicle starts or stops,

the function needs to work with the A12 function.

Example

GPRS Sending

@@E27,353358017784062,A15,6*C7\r\n

GPRS Reply

$$E28,353358017784062,A15,OK*F4\r\n

GPRS Sending

A16,Status

GPRS Reply

A16,OK

Description

The first positive input port (high level) of a vehicle tracker

(MVT100/MVT340/MVT380) must connect to engine detection. Otherwise, the

function is unavailable.

When the activation status is 1, the parking scheduled tracking function is enabled.

GPRS data is sent at the following interval:

 Interval of the A12 function when the engine is on  Interval of the A15 function when the engine is off

When the activation status is 0, the function is disabled. GPRS data is sent at the

following interval:

 Interval of the A12 function when the engine is on  Interval of the A12 function when the engine is off

Example

GPRS Sending

@@F27,353358017784062,A16,0*C3\r\n

GPRS Reply

$$F28,353358017784062,A16,OK*F6\r\n

GPRS Sending

A21,Connection mode,IP address,Port,APN,APN user name,APN password

GPRS Reply

A21,OK

Description

Connection mode = 0: function disabled.

Connection mode = 1: function enabled; use TCP/IP reporting mode.

3.6 Setting the Parking Scheduled Tracking Function – A15

3.7 Enabling the Parking Scheduled Tracking Function – A16

3.8 Setting GPRS Parameters – A21

MEITRACK MVT100/MVT340/MVT380 GPRS Protocol

Connection mode = 2: function enabled; use UDP reporting mode.

IP address: IP address or domain name. A maximum of 32 bytes are supported.

Port: a maximum of 5 digits.

APN/APN user name/APN password: a maximum of 32 bytes respectively.

If no user name and password are required, leave them blank.

Note:

1. If you want to change a parameter (named A), the parameter before A cannot be

empty.

2. If you do not want to change the parameters after A, no comma is required when

you edit the command.

3. If you want to clear the parameters after A, commas are required when you edit

the command.

For example, if you want to change the IP address and port only, send

A21,1,192.168.1.1,8800.

Example

GPRS Sending

@@H48,353358017784062,A21,1,67.203.13.26,8800,,,*C9

GPRS Reply

$$H28,353358017784062,A21,OK*F4\r\n

GPRS Sending

A22,DNS server IP address

GPRS Reply

A22,OK

Description

An incorrect DNS server IP address may lead to GPRS data reporting failures after the

A21 command is used. Use the A22 command to set the DNS server IP address (confirm

the IP address with your domain name provider.). Then use the A21 command to reset

the domain name.

DNS server IP address: a maximum of 16 bytes

Example

GPRS Sending

@@K38,353358017784062,A22,75.127.67.90*FD\r\n

GPRS Reply

$$K28,353358017784062,A22,OK*F8\r\n

GPRS Sending

A23,IP address,Port

GPRS Reply

A23,OK

Description

IP address: a maximum of 32 bytes

Port: a maximum of 5 digits

When the tracker fails to send data to the active server set by command A21, data is

automatically sent to the standby server to prevent data loss.

Example

GPRS Sending

@@S43,353358017784062,A23,67.203.13.26,8800*F0

GPRS Reply

$$S28,353358017784062,A23,OK*01\r\n

3.9 Setting the DNS Server IP Address – A22

3.10 Setting the Standby GPRS Server – A23

MEITRACK MVT100/MVT340/MVT380 GPRS Protocol

GPRS Sending

A70

GPRS Reply

A70,SOS phone number 1,SOS phone number 2,SOS phone number 3,Listen-in phone

number 1,Listen-in phone number 2

Description

Read all authorized phone numbers.

Example

GPRS Sending

@@T25, 353358017784062,A70*93\r\n

GPRS Reply

$$T85,353358017784062,A70,13811111111,13822222222,13833333333,13844444444,

13855555555*21\r\n

GPRS Sending

A71,Phone number 1,Phone number 2,Phone number 3

GPRS Reply

A71,OK

Description

Phone number: A phone number has a maximum of 16 bytes. If no phone numbers are

set, leave them blank. Phone numbers are empty by default.

Phone number 1: SOS phone number. When you call the tracker by using the phone

number, you will receive SMS notification about the location, geo-fence alarm and low

power alarm.

When the SOS button is pressed, the tracker will dial phone numbers 1, 2, and 3 in

sequence. The tracker stops dialing when a phone number responds.

Example

GPRS Sending

@@U61,353358017784062,A71,13811111111,13822222222,13833333333*7D\r\n

GPRS Reply

$$U28,353358017784062,A71,OK*06\r\n

GPRS Sending

A72,Listen-in phone number 1,Listen-in phone number 2

GPRS Reply

A72,OK

Description

When you call the tracker by using authorized listen-in phone numbers, the tracker will

answer the call automatically and enter the listen-in state. In this way, the tracker will

not make any sound.

A maximum of two phone numbers can be set. Each phone number has a maximum of

16 digits. If no phone numbers are set, leave them blank. Phone numbers are empty by

default.

If no phone numbers are set and commas are remained, phone numbers set before will

be deleted.

Applicable Model

MVT380

Example

GPRS Sending

@@V49,353358017784062,A72,13844444444,13855555555*55\r\n

GPRS Reply

$$V28,353358017784062,A72,OK*08\r\n

3.11 Reading All Authorized Phone Numbers – A70

3.12 Setting Authorized Phone Numbers – A71

3.13 Setting Listen-in Phone Numbers – A72

MEITRACK MVT100/MVT340/MVT380 GPRS Protocol

GPRS Sending

A73,Sleep level

GPRS Reply

A73,OK

Description

Set the automatic smart sleep mode when the tracker is idle.

Sleep level = 0: function disabled (default).

Sleep level = 1: normal sleep. The GSM module always works, and the GPS module

occasionally enters the sleep mode. The tracker works 25% longer in the normal sleep

mode than that in the normal working mode. This mode is not recommended for short

interval tracking; this will affect the route precision.

Sleep level = 2: deep sleep. If no event is triggered after five minutes, the GPS module

will stop working and the GSM module will enter sleep mode. Once an event is

triggered, the GPS and GSM modules will be woken up. A heartbeat event will be

triggered only in the deep sleep mode, which will be uploaded every one hour by

default.

Triggering events include: SOS alarm, low internal/external battery, external power

status, GPS antenna cutoff alarm, towing alarm, high temperature, low temperature,

fuel theft, vehicle theft, ACC ON, (button) changes on any input port, vibration,

incoming call, SMS receiving, call, and heartbeat event (The GPS is disabled during

heartbeat wakeup.).

Example

GPRS Sending

@@W27,353358017784062,A73,2*D9\r\n

GPRS Reply

$$W28,353358017784062,A73,OK*0A\r\n

GPRS Event Report

AAA,Command type,(-)Latitude,(-)Longitude,Date and time,Positioning status,Number

of satellites,GSM signal strength,Speed,Direction,HDOP,Altitude,Mileage,Run time,Base

station info,I/O port status,Analog input value

Description

When an event occurs, the tracker automatically reports the event to the server.

Example

GPRS Reply

When you press the SOS button, the tracker will send the following information to the

server:

$$G127,353358017784062,AAA,1,22.538169,114.075958,100313095653,A,3,21,4,46,5,

581,0,148,0|0|10133|4172,0000,166|204|205|2709|878,*77\r\n

GPRS Sending

AFF,Number of deleted GPRS events

GPRS Reply

Use the AFF command to clear the existing data when the GPRS connection mode is

UDP.

AFF,Number of remaining cache,Command type, (-)Latitude,(-)Longitude,Data and

time,Positioning status,Number of satellites,GSM signal

3.14 Setting the Smart Sleep Mode – A73

3.15 Automatic Event Report – AAA

3.16 Deleting a GPRS Event in the Buffer – AFF

MEITRACK MVT100/MVT340/MVT380 GPRS Protocol

strength,Speed,Direction,HDOP,Altitude,Mileage,Run time,Base station info,I/O port

status,Analog input value

Description

Number of deleted GPRS events: hexadecimal. In general, the number is 1.

Number of remaining cache: indicates the number of events in the buffer; hexadecimal.

Example

GPRS Sending

@@h27,353358017784062,AFF,1*0B\r\n

GPRS Reply

$$h28,353358017784062,AFF,OK*3D\r\n

GPRS Sending

B05,Geo-fence number,Latitude,Longitude,Radius,IN Geo-fence alarm,OUT Geo-fence

alarm

GPRS Reply

B05,OK

Description

Geo-fence number: 1–8. A maximum of eight geo-fences can be set.

Latitude: latitude of the geo-fence center; decimal; accurate to 6 digits after the decimal

point. If there are only 4 digits after the decimal point, add two digits 0. Otherwise, the

command cannot be used successfully.

Longitude: longitude of the geo-fence center; decimal; accurate to 6 digits after the

decimal point. If there are only 4 digits after the decimal point, add two digits 0.

Otherwise, the command cannot be used successfully.

Radius: The value ranges from 1 to 4294967295. The unit is meter.

IN Geo-fence alarm = 0: function disabled.

IN Geo-fence alarm = 1: function enabled.

OUT Geo-fence alarm = 0: function disabled.

OUT Geo-fence alarm = 1: function enabled.

Example

GPRS Sending

@@H57,353358017784062,B05,1,22.913191,114.079882,1000,0,1*96\r\n

GPRS Reply

$$H28,353358017784062,B05,OK*F7\r\n

When the tracker exits the geo-fence (latitude: 22.913191; longitude: 114.079882; radiu:

1000m), it will send the following GPRS data packet to the server:

$$J132,353358017784062,AAA,21,22.918046,114.089726,080229123812,A,10,22,12,32,

1,21,6667,847,0|0|10133|4110,0000,124|181|183|2714|922,*5A\r\n

GPRS Sending

B06,Geo-fence number

GPRS Reply

B06,OK

Description

Geo-fence number: 1–8. Only one geo-fence can be deleted each time by SMS or GPRS

command.

Example

GPRS Sending

@@J27,353358017784062,B06,1*C8\r\n

GPRS Reply

$$J28,353358017784062,B06,OK*FA\r\n

After the above command is run successfully, the first geo-fence will be deleted.

3.17 Setting a Geo-Fence – B05

3.18 Deleting a Geo-Fence – B06

MEITRACK MVT100/MVT340/MVT380 GPRS Protocol

GPRS Sending

B07,Driving speed

GPRS Reply

B07,OK

Description

Driving speed = 0: function disabled (default).

Driving speed = [1…255]: function enabled. Unit: km/h. When the driving speed reaches

the preset value, a speeding alarm will be generated.

Example

GPRS Sending

@@P28,353358017784062,B07,60*05\r\n

GPRS Reply

$$P28,353358017784062,B07,OK*01\r\n

When the tracker driving speed reaches 60 km/h, it will send the following information to

the server:

$$k134,353358017784062,AAA,19,22.916675,114.088813,080229123718,A,10,22,61,31

,1,21,

6635,395,460|0|10133|4110,0000,164|185|181|2712|915,*F7\r\n

GPRS Sending

B08,Vibration duration

GPRS Reply

B08,OK

Description

When the tracker's vibration duration exceeds the preset value, the tracker will send an

alarm to an authorized phone number or the server. Before using the towing alarm

function, use the A73 command to set the smart sleep level to 2 and use the B08

command to set the consecutive vibration duration. Otherwise, the towing alarm

function is unavailable.

Vibration duration = 0: function disabled (default).

Vibration duration = [1…255]: function enabled. Unit: second.

Example

GPRS Sending

@@I27,353358017784062,B08,3*CB\r\n

GPRS Reply

$$I28,353358017784062,B08,OK*FB\r\n

When the tracker vibrates for more than consecutive 3 seconds, it will send the following

information to the server:

$$K133,353358017784062,AAA,36,22.916675,114.088813,080229123718,A,10,22,61,3

1,1,21,6635,395,460|0|1013|4110,0000,164|185|181|2712|915,*A2

GPRS Sending

B21,Status

GPRS Reply

B21,OK

Description

Status = 1: function enabled (default). An alarm is generated when the first negative

input and first positive input of vehicle trackers excluding SOS are activated.

Status = 0: function disabled. No alarm is generated when the first negative input and

first positive input of vehicle trackers excluding SOS are activated.

3.19 Setting the Speeding Alarm Function – B07

3.20 Setting the Towing Alarm Function – B08

3.21 Setting the Anti-Theft Function – B21

MEITRACK MVT100/MVT340/MVT380 GPRS Protocol

The following lists inputs of trackers:

Tracker

Negative Input

Positive Input

MVT100 - Input 2

MVT340 - Input 2

MVT380

Input 2

Input 4

Example

GPRS Sending

@@C27,353358017784062,B21,1*BE\r\n

GPRS Reply

$$C28,353358017784062,B21,OK*F0\r\n

GPRS Sending

B31,A

GPRS Reply

B31,OK

Description

When A is 00, the tracker's indicator is turned on (default). You can query the device's

running status according to the indicator status.

When A is 10, the tracker's indicator is turned off.

Example

GPRS Sending

@@J28,353358017784062,B31,10*F7\r\n

GPRS Reply

$$J28,353358017784062,B31,OK*F8\r\n

GPRS Sending

B34,Log interval

GPRS Reply

B34,OK

Description

Set the interval for recording data to device's memory when the GPS signal is valid.

Recorded logs can only be read by GPSLog or Meitrack Manager software.

Log interval = 0: function disabled (default).

Log interval = [1…65535]: function enabled. Unit: second.

Applicable Model

MVT100/MVT380

Example

GPRS Sending

@@N28,353358017784062,B34,60*03\r\n

GPRS Reply

$$N28,353358017784062,B34,OK*FF\r\n

GPRS Sending

B35,SMS minute

GPRS Reply

B35,OK

Description

The default time zone of the tracker is GMT 0. You can run the B35 command to change

the SMS report time zone to the local time zone. The SMS report time zone is different

from the GPRS data packet time zone.

When SMS minute is 0, the time zone is GMT 0.

When SMS minute is a value ranging from -32768 to 32767, set time zones.

3.22 Turning off the LED Indicator – B31

3.23 Setting a Log Interval – B34

3.24 Setting the SMS Time Zone – B35

MEITRACK MVT100/MVT340/MVT380 GPRS Protocol

Example

GPRS Sending

@@O29,353358017784062,B35,480*3C\r\n

GPRS Reply

$$O28,353358017784062,B35,OK*01\r\n

After the above command is run successfully, the tracker SMS time zone is changed to

UTC+08:00 (China time zone).

GPRS Sending

B36,GPRS minute

GPRS Reply

B36,OK

Description

When GPRS minute is 0, the time zone is GMT 0 (default). The MS02 can automatically

detect the user time zone, so that the GPRS time zone does not need to be changed.

Otherwise, inaccurate data occurs.

When GPRS minute is a value ranging from -32768 to 32767, set time zones.

Example

GPRS Sending

@@P29,353358017784062,B36,480*3E\r\n

GPRS Reply

$$P28,353358017784062,B36,OK*03\r\n

After the above command is run successfully, the GPRS time zone is changed to

UTC+08:00 (China time zone).

GPRS Sending

B60,X

GPRS Reply

B60,OK

Description

X = 0: function disabled (default).

X = 1: function enabled. When the device detects ACC OFF, device's longitude and

latitude will not be updated, so as to avoid static drift.

The first positive input of the tracker connects to engine detection by default.

Example

GPRS Sending

@@U27,353358017784062,B60,1*D3\r\n

GPRS Reply

$$U28,353358017784062,B60,OK*05\r\n

GPRS Sending

B91,SMS event code,SMS header

GPRS Reply

B91,OK

Description

Header: a maximum of 16 bytes

Example

GPRS Sending

@@R31,353358017784062,B91,1,SOS*F0\r\n

GPRS Reply

$$R28,353358017784062,B91,OK*06\r\n

After you press the SOS button (input 1), the tracker will send an alarm SMS whose

header is SOS to a preset authorized phone number.

3.25 Setting the GPRS Time Zone – B36

3.26 Checking the Engine First to Determine Tracker Running Status – B60

3.27 Setting SMS Event Characters – B91

MEITRACK MVT100/MVT340/MVT380 GPRS Protocol

GPRS Sending

B99,<SMS>/<0>,<Phone number location>/<Authorized phone number>,<Operation

code>, [Event code 1]……[Event code n]

B99,<CALL>/<1>,<Phone number location>/<Authorized phone number>,<Operation

code>, [Event code 1]……[Event code n]

B99,<GPRS>/<2>,<Operation code>, [Event code 1]……[Event code n]

B99,<CAMERA>/<3>,<Operation code>, [Event code 1]……[Event code n]

B99,<BUZZER>/<4>,<Operation code>, [Event code 1]……[Event code n].

GPRS Reply

B99,<SMS>/<0>,<Phone number location>,<Authorized phone number>, [Event code

1]……[Event code n]

B99,<CALL>/<1>,<Phone number location>,<Authorized phone number>, [Event code

1]……[Event code n]

B99,<GPRS>/<2>,[Event code 1]……[Event code n]

B99,<CAMERA>/<3>,[Event code 1]……[Event code n]

B99,<BUZZER>/<4>,[Event code 1]……[Event code n]

Description

Fields SMS, CALL, CAMERA, GPRS, and BUZZER can be presented by 0–4 in decimal

string.

Operation codes GET, SET, ADD, and DEL can be presented by 0–3 in decimal string.

These characters are not case-sensitive.

Note: Ensure that an authorized phone number is set by using the A71 command or the

parameter configuration tool before the B99 command is used to set the SMS/CALL

event code. The tracker compares the authorized phone number issued by B99 with the

authorized phone number (excluding +86 characters) of the tracker. If the phone

numbers are the same, the new event code will be stored. If the phone numbers are

inconsistent, an error SMS will be sent.

GPRS Sending

@@B34,863070010825791,B99,gprs,get*BC\r\n

GPRS Reply

$$B33,863070010825791,B99,1,17,18*B5\r\n GPRS Sending

C01,Speed,ABCDE

GPRS Reply

C01,OK

Description

When the speed is 0, no speed limit exists. That is, when the tracker receives a

command, the output control takes effect immediately.

When the speed is a value ranging from 1 to 255 (unit: km/h), set the speed limit for

output control. When the driving speed is lower than the speed limit, the output control

takes effect.

A=0, close output (OUT1) - open drain

A=1, open output (OUT1) - connect to GND

A=2, remain previous status.

B=0, close output (OUT2) - open drain

3.28 Setting Event Authorization – B99

Example

3.29 Controlling Output Status – C01

MEITRACK MVT100/MVT340/MVT380 GPRS Protocol

B=1, open output (OUT2) - connect to GND

B=2, remain previous status.

C=0, close output (OUT3) - open drain

C=1, open output (OUT3) - connect to GND

C=2, remain previous status.

D=0, close output (OUT4) - open drain

D=1, open output (OUT4) - connect to GND

D=2, remain previous status.

E=0, close output (OUT5) - open drain

E=1, open output (OUT5) - connect to GND

E=2, remain previous status.

Example

GPRS Sending

@@M34,353358017784062,C01,20,10122*18\r\n

GPRS Reply

$$M28,353358017784062,C01,OK*F9\r\n

GPRS Sending

C02, X,Phone number,Content

GPRS Reply

C02,OK

Description

Used for the platform to notify the tracker of sending an SMS to a mobile phone.

X = 0: in TEXT mode

X = 1: in Unicode mode

Phone number: a maximum of 16 digits

Content: a maximum of 140 characters

After receiving the message, the tracker sends Content information to specified phone

numbers.

Example

GPRS Sending

@@f47,353358017784062,C02,0,15360853789,Meitrack*B1\r\n

GPRS Reply

$$f28,353358017784062,C02,OK*13\r\n

GPRS Sending

C03, X

GPRS Reply

C03,OK

Description

X = 0: automatic event report (default)

X = 1: Before another event can be transmitted, existing event reports need to be

confirmed and deleted on the server by the AFF command. Select this mode when GPRS

uses UDP.

Example

GPRS Sending

@@f27,353358017784062,C03,0*E1\r\n

GPRS Reply

$$f28,353358017784062,C03,OK*14\r\n

3.30 Notifying the Tracker of Sending an SMS – C02

3.31 Setting a GPRS Event Transmission Mode – C03

MEITRACK MVT100/MVT340/MVT380 GPRS Protocol

GPRS Sending

E91

GPRS Reply

E91,Version,SN

Description

Read the tracker's firmware version and SN.

Example

GPRS Sending

@@W25,353358017784062,E91*7D\r\n

GPRS Reply

$$W38,353358017784062,FWV1.00,12345678*1C\r\n

GPRS Sending

F01

GPRS Reply

F01,OK

Description

Restart the GSM module.

Example

GPRS Sending

@@j25,353358017784062,F01*88\r\n

GPRS Reply

$$j28,353358017784062,F01,OK*19\r\n

GPRS Sending

F02

GPRS Reply

F02,OK

Description

Restart the GPS module.

Example

GPRS Sending

@@Z25,353358017784062,F02*79\r\n

GPRS Reply

$$Z28,353358017784062,F02,OK*0A\r\n

GPRS Sending

F08,Run time,Mileage

GPRS Reply

F08,OK

Description

Run time:

 Value range: [0…4294967295]  Decimal  Unit: second

If you do not want to set the parameter, leave it blank.

Mileage:

 Value range: [0…4294967295]  Decimal  Unit: meter

If you do not want to set the parameter, leave it blank.

Example

3.32 Reading Device's Firmware Version and SN – E91

3.33 Restarting the GSM Module – F01

3.34 Restarting the GPS Module – F02

3.35 Setting the Mileage and Run Time – F08

MEITRACK MVT100/MVT340/MVT380 GPRS Protocol

GPRS Sending

@@D40,353358017784062,F08,0,4825000*51\r\n

GPRS Reply

$$D28,353358017784062,F08,OK*FA\r\n

GPRS Sending

F09,Number

GPRS Reply

F09,OK

Description

If the number is 1, SMS cache data to be sent is deleted.

If the number is 2, GPRS cache data to be sent is deleted.

If the number is 3, SMS and GPRS cache data to be sent is deleted.

Example

GPRS Sending

@@E27,353358017784062,F09,1*CA\r\n

GPRS Reply

$$E28,353358017784062,F09,OK*FC\r\n

GPRS Sending

F11

GPRS Reply

F11,OK

Description

Restore initial settings except the SMS password.

Example

GPRS Sending

@@[25,353358017784062,F11*7A\r\n

GPRS Reply

$$[28,353358017784062,F11,OK*0B\r\n

3.36 Deleting SMS/GPRS Cache Data – F09

3.37 Restoring Initial Settings – F11

If you have any questions, do not hesitate to email us at [email protected].
