Page 1
Pad Sound Sample Example: 0
A - Cajon Bass
B - Cajon Slap
C - Cajon Slap
D - Tambourine
Sample List:
0 - Meinl Subwoofer Cajon + Meinl Tambourine
1 - Meinl Snarecraft Cajon + Meinl Splash Cymbal
2 - Meinl Cantina Line Artisan Cajon + Meinl Closed Hihat Cymbal
3 - Meinl Slaptop Cajon + Hand Clap
4 - Meinl Woodcraft Cajon + Meinl Crash Cymbal
5 - Rock Drum Kit + Meinl Closed Hihat Cymbal
6 - Drum Machine + Meinl Ride Cymbal
7 - Meinl Marathon
8 - Meinl Fibercraft Bongos + Meinl Percussion Block
9 - Meinl Diego Galé Signature Timbales + Meinl Steel Craft Cowbell
®
Classic Congas
ATTENTION
Please do not attempt to disassemble the product
Please do not store the product in a hot or humid environment
Keep the product dry at all times and avoid contact with moisture
MEINL PERCUSSION
DIGITAL CAJON
INFO SHEET
Roland Meinl Musikinstrumente GmbH & Co. KG
Musik-Meinl-Straße 1
91468 Gutenstetten
GERMANY
Made in Chinameinlpercussion.com
Page 2
WHAT IS THE
MEINL PERCUSSION DIGITAL CAJON?
Panel Descriptions:
Top Panel:
Seating surface
This full-sized cajon is completely digital to expand your sound
options in an instant and allow for silent practice. The Meinl Digital
Cajon body is made of birch and is equipped with four rubber trigger
pads on the playing surface that respond with pre-programmed digital
samples of Meinl instruments and other drums. From cajons and bongos
to rock drums, cymbals and tambourines, The Meinl Digital Cajon creates
a full percussion set or drum kit experience! The durable pads are placed
in a natural cajon playing position for a comfortable feel and have a
sensitive touch for seamless playing. Each pad creates its own sampled
digital sound so you’re free to move around them to get creative with
your rhythms. Ten sound combinations are available to choose from, and
they may be selected hands-free by tapping the included foot pedal or by
pressing the buttons located on the top of the cajon. The Digital Cajon is
perfect for mixing up performances with an acoustic band or delivering
a powerful rhythmic foundation in plugged-in settings. Stereo and mono
quarter-inch output jacks allow you to send your signal to any amp or PA
syst em. Adjust your volum e as needed with t he volume dial. When it ’s time
for practice or silent playing by yourself, plug your headphones into the
cajon through the eighth-inch headphone jack, and enjoy the rich sounds
while not disturbing anyone around you.
Main Specifications:
• Foot switch with cable
• Power supply with international
adapters
• Volume control dial
• 1/8” headphone jack
Materials:
• Cajon body / 9mm birch ply
• Trigger pads / durabl e rubber
with textured surface and
9mm open cell acoustic foam
underneath
• 1/4” jacks for stereo or mono out
Rear Panel:
Foot switch jack
Power switch
9V/1A DC
ON / OFF
Top panel
Rubber trigger
pads
Volume knob
PRG UP
5
4
3
2
1
0
VOLUME
Use the two
buttons to switch
between the ten
sound samples.
Stereo jack
6
7
8
9
1
0
SELECT
SC1
STEREO
Left - Out - Right
Sample
number
select button
MONO
Main Features:
• Digital Cajon for expanded sound options and silent practice
• Four rubber trigger pads in a natural cajon playing position
• Ten pre-programmed digital sound combinations of Meinl cajons,
percussion instruments, drums and cymbals
• Birch body (black)
• Perfect for plugged-in settings
Power supply 9V/1A DC
Headphone jack
Mono jack
