Teaching a New Token
The following procedure must be followed in order to
teach a new token into channel 1.
NOTE:- Rotary data switch position “E” is used to
program tight window token limits and ‘F’ standard
window token limits.
1.Switch OFF the power to the validator.
2.Set the 4 way DIL teach switches 2, 3 & 4 to
ON, ON & OFF (channel 1) or OFF, ON & ON
for (channel 0)
3.Set rotary data switch to position “F”
standard window limit.
4.Switch ON the power to the product.
(The LED will start flashing).
5.Insert 10 to 20 (minimum 10) of the desired
tokens through the validator.
6.Return the 4 way DIL switches 2, 3 & 4 to
Normal Operation settings.
(LED will stop flashing and stay ON to indicate
success).
If the LED continues to flash OFF a number
of times this indicates a failure to teach the
new token. See LED Assistance Codes table
for help and then restart procedure again.
7.Token is now programmed and ready to use.
(New token information has been stored in
coin channel “1” which is rotary switch position
“1”). Any previous taught token information
in this channel will be overwritten).
NOTE:- If token self teach is successful but token
taught is rejected i.e. gives 3 flashes of the LED,
check that channel “1” is enabled.
To enable the new token set the rotary data switch
to position “1” then refer to enabling coin or tokens
configuration procedure).
MEI,
Internet: http://www.meigroup.com
CashFlow® 130
Quick Reference Guide
Applies to Product Version G1
MADE IN THE E.C. (UK)
PATENTED
Internet:http://www.meiglobal.com
Yes
A
£2 Tight10A
Yes£199
Yes
F
£188
Yes50p new77
Yes50p new66
No
E
50p old55
Coin
Enabled
Coin
Output
Coin
Type
Channel
Affected

To achieve a successful change to the configuration of
the validator the following procedure must be followed.
1.Switch OFF the power to the validator.
2.Set the 4 way DIL switches to the
configuration settings required. (See Product
Configuration Table)
3.Select the required data / channel position
using the rotary data switch. (see product
configuration table)
4.Switch the validator power ON. (The LED will
start flashing).
5.Return the 4 way DIL teach switches back to
Normal Operation Settings. (Switches 2,3 & 4
set to all ON or all OFF).
6.The LED will stop flashing and will stay ON.
This will indicate a successful change and that
the validator is ready for normal operation.
NOTE:- If teach is entered by mistake, switch OFF
the power to the validator before moving the 4 way
DIL switch positions else the mech. may learn
something unintentionally.
No power to validatorOFF
Validator is set in teach modeFlashing
Coin inhibited by validator or machine4 x Flash
Coin inhibited by validator 3 x Flash
Coin rejected as unrecognised2 x Flash
Reject lever pressed or coin accepted1 x Flash
Power is ON validator is O.K.ON
MEANINGSTATE
What Is The Green LED Doing?
Product Configuration
Normal Operation Settings
2 3 4
ON
1
2 3 4
ON
1
Set switches 2, 3 & 4 to
OFF or ON
-FAuto configuration
-DParallel output ONOFFOFF
-CBinary coded output
Selecting Machine Interface Types
E or F
Self teach a token for channel 1
ONONOFF -
E or F
Self teach a token for channel 0
OFFOFFON-0 - FEnable a coin or token channel
OFFONOFF-0 - FInhibit a coin or token channel
SW4SW3SW2SW1
2 3 4
ON
1
2 3 4
ON
1
Channel
Position
Product Configuration Table
What Do You Want To Do?
w E = Tight Window Limits. Channel F = Standard Window
Limits
x 8
Token material outside
acceptable limits
x 7
Token diameter outside
acceptable limits
x 6
Check that there are no mixed
sample tokens
Ensure that the rotary switch is
Ensure at least 10 tokens have
No activity was registered
within 30 seconds
Validator timed outx 2
for Code
LED
Flashes
Teaching Token (LED Assistance Codes)
