Megatron ingenium BLU User guide

Manual

All Lamps

Groups SetupAll Lamps

Ceiling Lamp

70%

All Lamps

Groups SetupAll Lamps

Group List

Groups SetupAll Lamps

Bedroom

100%

Setup

Version 1.01

www.ingenium.cc

®

MEGAMAN

General

Smart living is just two steps away.

1. Install INGENIUM® BLU LED lamps into your
existing fi xtures

2. Download the INGENIUM® BLU app

3. Control your lighting using your smart device

Features include:

Power

Turn the lights on and off

Dimming

Adjust brightness level with linear dimming functions

Timer

Pre-set the time to light up the lamp from lowest to
full brightness

Grouping

Control lighting devices room-by-room

Scenes

Set programmes for your favourite settings for
repeated use

INGENIUM® BLU with the latest Bluetooth 4.0 technology

is a step forward for high quality living. Simple, stylish
and intelligent, its advantages include easy installation,
availability of direct LED retrofi t, wireless compatibility,
dimmable without dimmer, precision scene setting and
greater energy saving using the app.

Bluetooth version 4.0
Expected coverage 10 metres
Maximum number of lamps /
modules to be connected at the
same time
Maximum number of groups 8 groups per app
Maximum number of lamps
per group
Maximum number of scene set
per group
Control unit Smart device with app

Network topology Star
Applications Household use,

4 pieces in each
covered area

4 pieces in each group

4 scenes in each
group

(iOS or Android)

showroom, lounge,
function room,
reception area, etc.

®

MEGAMAN

2 3 4 5 6 7

Installation

Lamps

INGENIUM® BLU LED lamps have an integrated

Bluetooth module so you can simply remove the existing
lamp and install the INGENIUM® BLU LED lamp, no
additional device or wiring is needed.

Note:

• INGENIUM® BLU LED lamps operate in 220V to 240V.

• Make sure INGENIUM® BLU LED lamps are not
installed in dimming circuitry to avoid malfunction.

App

Download the INGENIUM® BLU app to your smart device
from iOS App Store or Android Google Play Market.

For iOS users For Android users

https://itunes.apple.com/
hk/app/INGENIUMBLU/
id900416627?mt=8

https://play.google.com/
store/apps/details?id=cc.
megaman.led

Supported Devices

iOS Devices

(Recommended iOS version 6.0 or above)
iPhone 4S or later
iPad (3rd generation or later)
iPod Touch (5th generation)
iPad Mini (all generations)

Android Devices

(Recommended Android version 4.3 or above)
Samsung Galaxy S4
Nexus 7 (2013)

Note:
These are verifi ed models which can perfectly work with
the App but not limited to them.

MEGAMAN

®

Operation

Let’s Start

Welcome to the INGENIUM® BLU smart lighting control
application. In the following chapter, we will go through all
of the app’s functions.

All Lamps

Groups SetupAll Lamps

Ceiling Lamp

MEGAMAN

70%

Floor Lamp

60%

Table Lamp

60%

®

Smart Lighting

START

Automatic Pairing

In order to control your INGENIUM® BLU LED lamps, you
fi rst have to pair them to your smart device. Please follow
the following steps for the automatic pairing.

• Restart the lamp (switch off and then switch on)

• Open the INGENIUM® BLU app within 30 seconds

• Press “START” button on the welcome page of
the INGENIUM® BLU app, you may notice that the
Bluetooth symbol on of your device will fast fl ash,
which means the app is trying to connect with the

INGENIUM® BLU LED lamps within covered area.

• Tap on the Bluetooth icon next to the lamps in
“All Lamps” list

Note:

• Each lamp has a unique code (i.e.: Bulb 06d4). It is

a default name of a lamp and can be changed in the

setting option .

• Pairing is needed to be done one time only for each

lamp.

Control a Lamp

Connecting to your lamps
After pairing, simply press the Bluetooth icon in dark
grey to get connection, the icon fl ashes with green during

the connection, and become steady green when the
lamp and smart device are connected.

The colour of the Bluetooth icon shows the
connection status. There are 3 statuses:

Dark Grey

A paired lamp exists in cover area and the
lamp is ready for connection. Press the
Bluetooth icon to connect the lamp and
smart device.

Green

The lamp is connected and it is ready to
be controlled. Press the Bluetooth icon to
disconnect.

Light Grey

The lamp does not exist in the cover area or
not power on.

Ceiling Lamp

70%

Switch On/Off

Press power icon to turn on or off the INGENIUM®
BLU lamp.

Dark Grey

The lamp is power off. Press the button to
turn the lamp on.

Green

The lamp is power on. Press the button to
turn the lamp off.

Floor Lamp

60%

Dimming Control

Slide the dimming bar to adjust the dimming level of the
lamp. The number beside the dimming bar is to indicate
the dimming percentage from 1% to 100%.

100%

®

MEGAMAN

Setting Options

Tap the settings icon , to edit the settings of an
individual lamp.

Floor Lamp

Floor Lamp

Set Group

Timer

Reset Access Code

Delete

From here you can:

Rename a Lamp

Bulb 06d4

Bulb 06d4

Set Group

• Add current lamp into an existing group. More details
will be covered in “Create a group” chapter.

Timer

• Set a timer to switch on a lamp. More details will be
covered in “Timer” chapter.

Reset Access Code

• The access code is used for pairing a lamp with smart
device. Resetting the code will un-pair the lamp from
all linked smart devices.

Delete

• Tapping this button will un-pair the lamp from your
smart device, but not affect the pairing to other smart
devices. The lamp will be removed from the “All
Lamps” list and “Groups” list.

®

MEGAMAN

Create a Group

Tap “Groups” to go to the “Group List”, and tap the “+”
button to create a group.

This will open the “Add Group” page. Simply enter a
name to create a new group.

Group List

Groups SetupAll Lamps

Bedroom

100%

Living Room

100%

Select the lamps to be added into this group by tapping

next to the lamps.

The navigator button can be used to identify the
location of lamps. When you press the navigator button,
the lamp will fast fl ash for 2 seconds and reach 100%
brightness.

Bedroom Save

Cancel

Ceiling Lamp

Floor Lamp

Table Lamp

MEGAMAN

Add Group

Bedroom

Q W E R T Y U I O

A S D F G H

123

Cancel

Ceiling Lamp

Floor Lamp

Table Lamp

J K L

Z X C V B N M

space

Bedroom Save

return

P

Add Lamps into Existing Group

There are two ways to add a lamp into an existing group.

1. In “All Lamps” list, tap the setting icon next to the
lamp which you want to add.

Then, tap “Set Group” button and select the group.

All Lamps

Groups SetupAll Lamps

Ceiling Lamp

70%

Floor Lamp

60%

Table Lamp

60%

Floor Lamp Save

Cancel

Living Room

Bed Room

2. In “Group List”, tap the setting icon next to the
group and select lamps you want to add.

Group List

Groups SetupAll Lamps

Bedroom

50%

Living Room Save

Cancel

Ceiling Lamp

Floor Lamp

Table Lamp

MEGAMAN MEGAMAN

8 9 10 11 12 13

Living Room

Living Room

Timer

Lamps

Delete Group

Living Room

Living Room

Timer

Lamps

Delete Group

8010BT004A

Connect to a Group

Simply tap the Bluetooth icon in dark grey to
connect to a group. The icon will fl ash green during the
connection. It will become steady green when the
connection is completed.

Group List

Groups SetupAll Lamps

Bedroom

50%

Living Room

50%

A “!” mark will appear in front of the Bluetooth
icon when there is one or more lamps that cannot
be connected within the group. Possible reasons for a
failed connection include: lamp positioned, outside the
coverage area, the lamp is not powered, interference in a
crowded environment, etc.

Switching Control of Groups

To optimise the system operation, ONLY ONE group can
be connected and controlled at the same time. You can,
however, easily switch the connection from the existing
group to another group for control.

To switch the connection, simply tap the Bluetooth icon

of the group that you would like to switch to. The

system will automatically disconnect the existing group
and connect to the group intended to switch to. The
Bluetooth icon will fl ash with green and change to steady
when the new connection is completed.

Group List

Groups SetupAll Lamps

Bedroom

50%

Living Room

50%

GB

®

Bedroom

50%

Living Room

50%

Group List

Groups SetupAll Lamps

Switch Grouped Lamps On/Off

Press power icon to turn on or off all the

INGENIUM® BLU lamps within a group.

Dark Grey

The group of lamps is off. Press the button
to turn the lamp on.

Green

The group of lamps is on. Press the button
to turn the lamp off.

Living Room

100%

Dimming control

Slide the dimming bar to adjust the dimming level of the
group of lamps. The number beside the dimming bar is to
indicate the dimming percentage from 1% to 100%.

100%

Setting Option

You can edit the settings of your groups by tapping the
settings icon

Within the Group Settings menu you can:

• Change the name of the group

• Timer
Set a timer to switch on a group of lamps. More details

will be covered in “Timer setup” chapter.

• Lamps
Select lamps to be included in this group

• Delete
Remove this group, but the paired lamps will be still

existed in “All Lamp” list.

Bedroom

100%

Living Room

100%

Group List

Groups SetupAll Lamps

MEGAMAN

Living Room

Living Room

Timer

Lamps

Delete Group

®

Scene Setup

You can store up to 4 scenes for each group.

To set a scene, press the scene icon , followed by
the setting icon in the “Scenes” page.

Group List

Groups SetupAll Lamps

Bedroom

100%

Living Room

100%

In the “Scenes Setting” page, set your scenes by:

• Naming the scenes

• Selecting the lamp to be controlled by tapping
next to the lamp

• Adjusting the dimming level of the lamps

• Setting lamps to be turn ON or OFF

Scene Settings Save

Cancel

Movie

Ceiling Lamp

1%

Floor Lamp

70%

Floor Lamp

70%

MEGAMAN

Scenes

Living Room

Movie

Reading

Relax

Sleeping

®

Scene Operation

To play a scene, simply press the scene icon
under the “Group List”, and then press the play icon
in the “Scenes” page.

Bedroom

100%

Living Room

100%

Group List

Groups SetupAll Lamps

MEGAMAN

Scenes

Living Room

Movie

Reading

Relax

Sleeping

®

Timer Setup

Set a timer to switch on an individual lamp or a group
of lamps at a scheduled time, by following these few
simple steps.

To set the timer of an individual lamp, tap the setting

icon on the “All Lamps” page. You can also tap the

setting icon on the “Group List” page to set the timer

for a group of lamps.

Once you are on the ‘Timer’ page:

• Set the “Enable” option to “on”

• You can also disable the function by selecting ‘Off’

Off

here.

This is a wake up timer; so the selected lamps will light

up from 10% brightness (minimum) to full brightness

100% gradually, with 2 different speed options:

Fast

Fast

The lamps light up in 5 minutes

Slow

Slow

The lamps light up in 10 minutes

Note:

• The timer can be scheduled for one week, and you can
set a different time for each day.

• The time set on the “Schedule” is the time the lamps
will reach full brightness. Depending on the mode
selected, the time set cannot be set less than 5 or 10
minutes in the future.

• Each lamp can only record one schedule, the previous
setting will be over-written by the later setting.

• The setting is stored in the memory of lamp, therefore
the lamp will light up as scheduled even if no smart
device is connected at that time.

• Please note that the lamp will not light up as scheduled
if the lamp is switched off at the wall switch.

Timer

Settings

Speed Fast

Enable Off

Schedule

01/8 Friday 12:00 Off

02/8 Saturday 12:00 Off

03/8 Sunday 12:00 Off

MEGAMAN

On

Timer

Settings

Speed Slow

Enable

Schedule

01/8 Friday 12:00

02/8 Saturday 12:00

03/8 Sunday 12:00

®

On

On

On

On

Share Settings

You can share all your current settings from one smart
device to another following these simple steps.

1. Go to the “Setup” page, press “Share Settings”

2. Select “Export” from the export device.

3. Within 5 seconds, select “Import” from the import
device.

4. Both devices will automatically build up a connection
and transfer data

5. After the data transfer, the import device should be
closed and re-opened to fi nalise the setting sharing.

Setup

Groups SetupAll Lamps

Share Settings

Help

Version 1.01

Note:

1. Make sure the Bluetooth function is activated in both
devices.

2. Both devices need to be on the same platform. (iOS to
iOS, Android to Android)

3. Make sure both devices have suffi cient battery power
to avoid data corruption.

Help page
The help button will direct you to the FAQ page

www.ingenium.cc/support.

Fragen und Antworten

Die Hilfe-Schaltfläche (Help) wird Sie zu den häufig
gestellten Fragen (FAQ) weiterleiten.
Weitere Hinweise erhalten Sie im Internet unter:

www.ingenium.cc/support

MEGAMAN

Setup

Groups SetupAll Lamps

Share Settings

Import

Export

Share Settings

Cancel

Help

Version 1.01

®

14
