GENOA
F25245RC/ F25745RC/ F26645RC/ F26745RC
Instruction Manual
TECHNICAL SPECIFCATION
Model Number
MM Code
Lamp Holder
Wattage
Voltage
Frequency
IP Rating
CA UTI ON S
Read the entire manual carefully before installation and operation.
•
•
It is reco mmended that the installat ion and maintenance be performed by a
licensed and qualified ele ctrician.
Switch off the power source before instal lation, replacement and cleaning.
•
•
Wearin g gloves d uring installation is sugg ested for keeping the module in the
best condition.
•
Before repl acement of luminaire or module, t urn off and allow them to cool
down. Heat-resistant gloves are mandator y when handling the luminaire or
module.
•
In case the external flexible power cord is damaged, the replacement should be
handled by a licensed and qual ified electrician for safety purpo se.
ATTENTION
•
Instant restart is allowed.
•
Designed for indoor applic ation and recessed ceiling installation only.
Installation
F25245RC F25745RC F26645RC F26745RC
MT7661 X MT76XX X MT7662 X MT76XXX
PHJ65d-2
Max. 30W
MEGAMAN TECOH CFx
220-240V~
50/60Hz
PHJ65d-2 PHJ65d-2 PHJ65d-2
Max. 20W
MEGAMAN TECOH CFx
Max. 30W Max. 20W
220-240V~
50/60Hz
IP20 IP20 IP20 IP20
MEGATRON
MEGAMAN TECOH CFx
220-240V~
50/60Hz
•
The minimum safety distance from the illuminated object is 0.1m.
•
Only the MEGAMAN TECOH CF x (Max.30W or Max.20W) can be us ed with
220-240V~
50/60Hz
luminaire. Using incandescent lamp, halogen or other kinds of light source will
be resulted in risk of fire or electric shock .
•
When this recessed luminaire is install ed into false ceiling, the exposed part of
the luminaire has a rated IP23, whereas the unexposed part has a rated IP20.
•
The manufacturer accepts no liability for any damage resulting from the misuse
of the luminaire or from when it is used with ina ppropriate equipment.
•
Consult your dealer if you have any enquiries.
When the recessed luminaire is installe d into ceiling areas, the exposed part of
•
the luminaire has a rated ingress protection of IP23, whereas the unexposed par t.
has a rated ingress protection of IP20.
Recommended working temp erature of luminaire is -30°C to + 40° C.
•
MEGAMAN TECOH CFx
0.1
---------
m
Max.
25mm
•
1
2
TYPE OF CONNECTION
Working with terminal block LA5111
Power Cord Preparation:
6mm
18-26mm
Press downwards to
secure connection wire
Model No.
F25245RC
F25745RC
F26645RC
F26745RC
Cut-Out Ø (mm)
140
140
160
160
1
• 1. Snap in the LED Module into the luminaire
and match with the slot of the luminaire.
There will be a sound "click" if the LED
module and luminaire is locked.
• 2. Push the reflector into the luminaire.
Single Type Connection
Input voltage
220-240V~
N
L
Ste p1
Safety Distance:
Model No.
F25245RC
F25745RC
F26645RC
F26745RC
W(mm)
H(mm)
110 170
110 170
110 170
110 170
1.
1
Unlock and remove the reflector
2.
fro m the luminaire.
Remove t he module by twisting it to
3.
the slot of the lamp holder, unlock
and remove the module form the
luminaire.
Working with terminal block LA5113
Stripping Preparation
Power Cord
Preparation:
11-12mm
18-23mm
0.75-2.5mm
For solid
conductors
0.75-2.5mm
For tinned
wire ends
max. 1.8mm
For wire ends
with ferrule
Press downwards to secure
2
connection wire
2
1mm
H
W W
Twist the reflector to the slot of the luminaire.
3
2
Ste p2
Single Type Connection
Input voltage
220-240V~
Parallel Type Connection
Input voltage
220-240V~
Correct Disposal of This Product
This marking indicates that this product should not be disposed with other household wastes
throughout the EU. To prevent possible harm to the environment or human health from
uncontrolled waste disposal, recycle it responsibly to promote the sustainable reuse of material
resources. To return your used device,please use the return and collection systems or contact
the retailer where the product was purchased. They can take this product for environmental safe
recycling.
IDV GmbH
Birkenweiherstr. 2
D-63505 Langenselbold
Germany
MEGATRON
LED
Expandable up to 230W max.
8010GRC38A
