Page 1
MEGAPOWER
2400 Lumens XGA LCD Projector
ML-183
High
Performance
Portable
Projector at
Affordable
Price
MEGAPOWER
INDUSTRIAL LIMITED
Suite 903, Park Tower
15 Austin Road
Tsimshatsui, Kowloon
Hong Kong
Phone: 852-6216-0140
Fax: 852-8147-1900
Email: [email protected]
Internet: www.mega-power.com
· Weighs only 6.8 lb (3.1 Kg)
· High Brightness- 2400 ANSI Lumens
· True XGA resolution
· Supports HDTV
· DVI input
· Picture-in-Picture
· Digital Keystone Correction
The Model ML-183 is designed for high performance but at
budget price. The ML-183 projector gives you 2400 lumens of
XGA (1024x768) resolution. The ML-183 is HDTV ready. It
projects vivid and rich video images using either 4:3 or 16:9
aspect ratio. It offers digital keystone correction to allow you to
have a fully rectangular image at all times. Brightness, high-
quality video, outstanding computer resolutions, and great
pricing are what make MEGAPOWER your choice for projection.
Page 2
Specifications
Specifications True XGA, 2400 ANSI Lumens
Technology Three 0.79” diagonal Poly-silicon LCD
Native Resolution SVGA (800x600) ; 1024x768 (Compressed)
Brightness 2400 ANSI Lumens
Image Size 40” ~ 300”
Throw Ratio 64.2” (Wide) ~ 53.6” (Tele) @ 2m
Zoom Ratio 1.20 : 1
Projection Distance 1.25m ~ 9.35m
Zoom Lens F# 1.72~1.98, f=25~30mm (Manual Zoom / Focus)
Uniformity 85%
Aspect Ratio 4:3 / 16:9 screen selectable
Contrast Ratio 450:1
Horizontal Frequency 15 ~ 80 kHz
Vertical Scan Rate 43 ~ 85 Hz
Audible Noise < 35 dB
Keystone Correction Vertical ± 15°
Lamp 180 W, 2000 hrs (3000 hrs ECO Mode) Lamp life
Input Terminal RGB (D-Sub 15 pin) x 1, DVI In/Monitor Out x 1,
S-Video x 1, C-Video x 1, Audio (Mini jack) x 1
Output Terminal USB x1, RS-232 x 1, Audio (Mini jack) x 1
2 Watt speaker x 1
Video Compatibility HDTV / NTSC / PAL / SECAM
Body Material PC+ABS
Dimensions 315 x 245 x 100 mm (12.4”x 9.6”x 4”)
Weight 3.1 Kg (6.8 lbs)
Power Supply 90 to 240 VAC, 50 to 60 Hz
Power Consumption 230W
Functions Digital Keystone, Digital Zoom, Picture-in-Picture,
Auto Sync, Remote Mouse,
HDTV(480p/720p/1080i), Freeze
On-Screen Display
Languages
Safety Regulations CE. FCC. UL.
Accessories (Standard) AC Power Cord, VGA Cable, C-Video Cable,
Accessories (Optional) Ceiling Mount, Spare Lamp
MEGAPOWER INDUSTRIAL LIMITED
Suite 903, Park Tower, 15 Austin Road, Tsimshatsui, Hong Kong
Tel: 852-6216-0140 Fax: 852-8147-1900
Email: [email protected]
English/French/German/Spanish/Portuguese/Italian/
Sweden/Chinese (Tradition) /Chinese (Simplified)
S-Video Cable, USB Cable, Audio Cable (PC-PC) &
(RCA-PC), DVI to D-Sub Converter, Remote Control,
Batteries, User’s Guide, Carrying Bag
Web site: www.mega-power.com
ML-183
