MEGAPOWER
1800 Lumens XGA LCD Projector
ML-180
High
Performance
Portable
Projector at
Affordable
Price
MEGAPOWER
INDUSTRIAL LIMITED
Suite 903, Park Tower
15 Austin Road
Tsimshatsui, Kowloon
Hong Kong
Phone: 852-6216-0140
Fax: 852-8147-1900
Email: [email protected]
Internet: www.mega-power.com
· Weighs only 6.8 lb (3.1 Kg)
· High Brightness– 1800 ANSI Lumens
· True XGA resolution
· Picture-in-Picture
· Digital Keystone Correction
The Model ML-180 is designed for high performance but at
budget price. The ML-180 projector gives you 1800 lumens of
XGA (1024x768) resolution. It projects vivid and rich video
images using either 4:3 or 16:9 aspect ratio. It offers digital
keystone correction to allow you to have a fully rectangular
image at all times.
Brightness, high-quality video, outstanding computer
resolutions, and great pricing are what make MEGAPOWER your
choice for projection.
Page 2
Specifications
Specifications True XGA, 1800 ANSI Lumens
Technology Three 0.63” diagonal Poly-silicon LCD
Native Resolution XGA (1024x768) ; 1280x1024 (Compressed)
Brightness 1800 ANSI Lumens
Image Size 40” ~ 300”
Throw Ratio 60” (Wide) ~ 48” (Tele) @ 2m
Zoom Ratio 1.23 : 1
Projection Distance 1.33m ~ 6.67m
Zoom Lens F# 1.7~2.1, f=26~32mm (Manual Zoom / Focus)
Uniformity 85%
Aspect Ratio 4:3 / 16:9 screen selectable
Contrast Ratio 400:1
Horizontal Frequency 15 ~ 80 kHz
Vertical Scan Rate 43 ~ 85 Hz
Audible Noise < 37 dB
Keystone Correction
Lamp 165 W, 2000 hrs Lamp life
Input Terminal RGB (D-Sub 15 pin) x 1, S-Video x 1, C-Video x 1,
Output Terminal Monitor Out x 1, Audio (Mini jack) x 1,
RS-232 x 1, 2 Watt speaker x 1
Video Compatibility HDTV / NTSC / PAL / SECAM
Body Material PC+ABS
Dimensions 297 x 233 x 93 mm (11.7”x 9.1”x 3.8”)
Weight 3.1 Kg (6.8 lbs)
Power Supply 90 to 240 VAC, 50 to 60 Hz
Power Consumption 230W
Functions
On-Screen Display
Languages
Safety Regulations CE. FCC. UL.
Accessories (Standard) AC Power Cord, VGA Cable, C-Video Cable,
Accessories (Optional) Ceiling Mount, Spare Lamp
MEGAPOWER INDUSTRIAL LIMITED
Suite 903, Park Tower, 15 Austin Road, Tsimshatsui, Hong Kong
Tel: 852-6216-0140 Fax: 852-8147-1900
Email: [email protected]
Digital Keystone, Digital Zoom, Picture-in-Picture,
Auto Sync, Freeze
English/French/German/Spanish/Italian/
Chinese(Traditional) /Chinese (Simplified)
S-Video Cable, Audio Cable (PC-PC) &
(RCA-PC), Batteries, User’s Guide,Remote Control,
Web site: www.mega-power.com
Vertical ±15º°
Audio (Mini jack) x 1
Carrying Bag
ML-180
