USER MANUAL
Table of Contents
Safety Information……………………………………………………………………………………………. 3
Specifications…………………………………………………………………………………………………….. 4
Main Power Connection…………………………………………………………………………………..5
DMX-512 Connection…………………………………………………………………...……………...... 5
DMX Profile......................................................................................................................... 6
Main Control Menu.......................................................................................................... 8
Rigging the Fixture………………………………………………………………………………………….10
Cleaning & Maintenance.............................................................................................10
Parts List............................................................................................................................10
Check that the unit has not been damaged during transport
Protection Against Fire
1. Maintain a minimum of 1 foot distance from any type of flame.
3. Replace fuse only with the specified type and rating.
4. Do Not install the unit to close to a heat source.
5. Make sure cable are properly secured
6. Maximum surface operating temperature 80º.
Protection Against Fire
1. Disconnect power before servicing.
2. For connection to main power supply proceed to page 5.
3. This unit must be earthed. (electronically grounded)
4. Do not expose unit to rain or moisture.
Protection Against Mechanical Hazards
1. Use safety chain when hanging unit.
2. Use quality clamps or bolts when positioning unit
3. Do not open unit while it is on, risk of electrical shock.
3
Technical Information
Part Numbers
Fixture
4085-N-E Color Target
Mechanical Specifications
DMX Connectors: 3 and 5 pin XLR connectors in/out
Power Connections: Power Conn in/out
Thermal: Maximum ambient temperature 40° C
Maximum surface temperature 60° C
Display: Digital
Fastening System: Mounting Yoke
Fixture Packaged for Shipping
Size: 11.80”L x4.5”W x 13.5”H
Weight: 12.7 lbs
Size: 16.5” x 7” x 14.5”
Weight: 14.7 lbs
Electrical Specifications
LED Quantity: 19 Quad Color
Red: 19
Green: 19
Blue: 19
White: 19
LED Watts each: 10
LED refresh rate: 4.7k HZ (flicker free)
LED Lifetime: 60,000 to 100,000 hours
LED Angle: 25°
Power Input Voltage: Universal 100 - 240V 50/60 Hz
Power Consumption: Watts: 139
Amps: 1.95
R 410 105 LUX
G 550 150 LUX
B 700 185 LUX
W 630 166 LUX
RGBW 2050 580 LUX
3
2
1
0
1
2
3
Control & Programming
Protocol: DMX 512
DMX Channels: 5 mode of operation
Mode A 3 Channel R, G, B
Mode P 4 Channel R, G, B, W
Mode H 8 Channel R, G, B, W, Strobe, CTO, Macro, Dimmer
Mode L 9 Channel R, G, B x 3
Mode F 12 Channel R, G, B,W x 3
Operating mode: Stand alone
11.80”
9.5”
10”
2 4.5
1.5 2.5
4.5”
13.5”
Distance (m)
Diameter (m)
4
Main Power Connection
Caution!
1. Do not connect fixture to a dimmer system.
2. This unit has Auto switching power supply. It will respond to 110V or 220V automatically
3. This unit must be earthed. (electronically grounded)
4. Replace fuse only with the specified type and rating.
The occupation of the connection-cable is as follows:
This fixture is equipped with an electronic power supply that will let the unit operate from 90V to 240V from 50Hz to 60Hz
Cable (USA) Cable (EU) Pin 110V
Black Brown
White
Green
Light Blue
Yellow/Green
110V
Connection
N
Connection
L
Neutral
Ground
220V
Live
L
N
L
220V
L
L
L
DMX-512 Connection
The fixture is equipped with 3 pin XLR Sockets for DMX input and output. The sockets are wired in parallel. Only use a shielded
twisted pair cable designed for RS-485 and 3 pin XLR plugs and connectors in order to connect the controller with the fixture or
the fixture with another.
DMX—input
1
2
3
1
2
3
Caution!
At the last fixture the DMX signal needs to be terminated with a terminator. Solder a 120
Ohm resistor between the (-) and the (+) signal into a 3 pin XLR plug and plug it in to the
last fixture on the signal run. Pre-manufactured terminator plugs are available for
purchase from your Mega-Lite dealer (HOS-DMXT).
DMX—output
1. Shield
2. Signal (-)
5
4
3. Signal (+)
2
1
3
5
4
5
1
2
3
DMX Profile
Target Mode A (3 Channel)
DMX Chanel Function Description Value
1 LED Color Red LED intensity 0-255
2 LED Color Green LED Intensity 0-255
3 LED Color Blue LED Intensity 0-255
Target Mode P (4 Channel)
DMX Chanel Function Description Value
1 LED Color Red LED intensity 0-255
2 LED Color Green LED Intensity 0-255
3 LED Color Blue LED Intensity 0-255
4 LED Color White LED Intensity 0-255
Target Mode H (8 Channel)
DMX Chanel Function Description Value
1 LED Color Red LED intensity 0-255
2 LED Color Green LED Intensity 0-255
3 LED Color Blue LED Intensity 0-255
4 LED Color White LED Intensity 0-255
5 Strobe
Strobe (slow to fast) 0-196
6 CTO
7000K 221-256
7 Macro
Macro Effect 7 250-255
8 Dimmer Dimmer Off to Full 0-255
Random Strobe (slow to fast) 197-255
3200K 0-36
3800K 37-73
4400K 74-110
5000K 111-147
5600K 147-183
6200K 184-220
No Function 0-1
Color fade All (slow to fast) 2-19
Color Snap All (slow to fast) 20-39
Random Full All (slow to fast) 40-59
Red Chase Each (slow to fast) 60-79
Green Chase Each (slow to fast) 80-99
Blue Chase Each (slow to fast) 100-119
White Chase Each (slow to fast) 120-139
Macro Effect 1 140-159
Macro Effect 2 160-179
Macro Effect 3 180-199
Macro Effect 4 200-219
Macro Effect 5 220-229
Macro Effect 6 230-249
6
Target Mode L (9 Channel)
DMX Chanel Function Description Value
1 LED Color Red LED intensity (Inner Circle) 0-255
2 LED Color Green LED Intensity (Inner Circle) 0-255
3 LED Color Blue LED Intensity (Inner Circle) 0-255
4 LED Color Red LED intensity (Middle Circle) 0-255
5 LED Color Green LED Intensity (Middle Circle) 0-255
6 LED Color Blue LED Intensity (Middle Circle) 0-255
7 LED Color Red LED intensity (Outer Circle) 0-255
8 LED Color Green LED Intensity (Outer Circle) 0-255
9 LED Color Blue LED Intensity (Outer Circle) 0-255
Target Mode F (12 Channel)
DMX Chanel Function Description Value
1 LED Color Red LED intensity (Inner Circle) 0-255
2 LED Color Green LED Intensity (Inner Circle) 0-255
3 LED Color Blue LED Intensity (Inner Circle) 0-255
4 LED Color White LED intensity (Inner Circle) 0-255
5 LED Color Red LED intensity (Middle Circle) 0-255
6 LED Color Green LED Intensity (Middle Circle) 0-255
7 LED Color Blue LED Intensity (Middle Circle) 0-255
8 LED Color White LED intensity (Middle Circle) 0-255
9 LED Color Red LED intensity (Outer Circle) 0-255
10 LED Color Green LED Intensity (Outer Circle) 0-255
11 LED Color Blue LED Intensity (Outer Circle) 0-255
12 LED Color White LED intensity (Outer Circle) 0-255
Main Control Menu
The control board on the fixture base is your interface to access and control
CONTROL BOARD
all the functions on the unit. Its digital display gives you a code view of the
options and functions. The following will explain each function and its options.
Menu Up Down Enter
DMX Address Red Dimmer
1-512 0-15 0-15 0 -15 0-15 0-15 0-15 0-15 0-15
Green Dimmer Blue Dimmer Flash Fade Scroll
White
0-15
Snap Scroll
Chase Effect
Chase Speed
Operating Mode
A
P
H
L
F
DMX Address
Press Enter to select the start address channel. The first display will let you know what operation mode you are in. Use the up/
down keys to select the desired start address. Press Enter to confirm.
Red Dimmer
This function allows you to dim the red LED’s on the whole module. Press Enter use the up/down keys to select desired dimmer
settings. Press Enter to confirm the settings. (15 Steps)
Green Dimmer
This function allows you to dim the green LED’s on the whole module. Press Enter use the up/down keys to select desired dim-
mer settings. Press Enter to confirm the settings. (15 Steps)
Blue Dimmer
This function allows you to dim the blue LED’s on the whole module. Press Enter use the up/down keys to select desired dimmer
settings. Press Enter to confirm the settings. (15 Steps)
White Dimmer
This function allows you to dim the White LED’s on the whole module. Press Enter use the up/down keys to select desired dim-
mer settings. Press Enter to confirm the settings. (15 Steps)
Flash
This function allows you to strobe the LED’s on the whole module in White color. Press Enter use the up/down keys to select
desired flash settings. Press Enter to confirm the settings.
Fade Scroll
This function allows you to fade the LED’s on the whole module from one color to another. Press Enter use the up/down keys to
select desired fade speed settings. Press Enter to confirm the settings. (15 Steps)
Flash Scroll
This function allows you to change the LED’s on the whole module from one color to another. Press Enter use the up/down keys
to select desired color change speed settings. Press Enter to confirm the settings. (15 Steps)
Chase Effect
This function allows you to select different chase patterns on the whole module. Press Enter use the up/down keys to select
desired chase settings. Press Enter to confirm the settings.
Chase Speed
This function allows you to select the speed of the chase that was selected on the Chase Effect . Press Enter use the up/down
keys to select desired chase speed settings. Press Enter to confirm the settings.
DMX Mode
Press Enter to select the desired operating mode. Use the up/
down keys to select. Press Enter to confirm.
Mode A (4 Channels) R,G,B
Mode P (4 Channels) R,G,B, W
Mode H (8 Channels) R,G,B,W, Strobe, CTO, Macro, Dimmer
Mode L (9 Channels) R,G,B, X 3
Mode F (12 Channels) R,G,B,W X 3
8
Rigging the fixture
Caution!
1. The installations must be carried out by an authorized dealer or trained professional.
2. Unit may cause severe injures if you have doubts concerning the safety do not install.
3. Unit is to be 24inches away from flammable materials (decoration material)
4. Use high quality installation equipment to hang unit.
When rigging a unit it is very important that you follow common safety procedures. Rigging requires extensive experience including but not limited to calculating working loads, material being used and periodic safety inspections. If you lack these qualifications, do not attempt the installation yourself, instead use a professional structural rigger.
When rigging the unit always be secured with a secondary safety attachment. The installation location of the projector has got to
be built in the way that it can hold 10 times the weight for 1 hour with out any harming. Installation should be checked at least
one time a year by a skilled person.
Cleaning and maintenance
Installation Maintenance: The operator has to make sure that the unit is operating safely and has the installations and electron-
ics checked by an expert every 2 years.
The following points have to be considered during the inspection:
1) All screws used for installing the device or part of the device have to be tightly connected and must not be corroded.
2) There must not be any deformations on the housing, fixation and installation spots (ceiling, suspension, trussing).
3) The electronic power supply cables must not show any damages, material fatigue (e.g. porous cables) or sediments. Further
instructions depending on the installation spot and usage have to be adhered by a skilled installer and any safety problems
have to be removed.
Note: There is no serviceable parts inside the device except for the LED’s. Maintenance and service operations are to be carried
out by authorized dealers.
Replacing the fuse: Only replace the fuse with the same type and rating.
Replacing the power cable: If the power cable of this device becomes damaged, it has to be replaced by authorized dealers or
trained professional only.
Should you have further questions , please contact your dealer.
Parts List
4085-FAN Replacement fan
4085-MPCB Main PCB card
4085-PS Power Supply
4085-DIS Display
4085-FG Front Glass
4085-LED LED Replacement
4070-KNOB Knob Set
9
Warranty Information
Limited Warranty
Unless otherwise stated, your product is covered by a one year parts and labor limited warranty. Dichroic filters and glass gobos are not guaranteed
against breakage or scratches to coating. It is the owner’s responsibility to furnish receipts or invoices for verification of purchase, date, and dealer
or distributor. If purchase date cannot be provided, date of manufacture will be used to determine warranty period.
Returning an Item Under Warranty for Repair
It is necessary to obtain a Return Material Authorization (RMA) number from your dealer or point of purchase BEFORE any units are returned for
repair. The manufacturer will make the final determination as to whether or not the unit is covered by warranty. Lamps are covered by the lamp
manufacturer’s warranty.
Any Product unit or parts returned to MEGA Systems Inc. must be packaged in a suitable manner to ensure the protection of such Product unit or
parts, and such package shall be clearly and prominently marked to indicate that the package contains returned Product units or parts and with an
RMA number. Accompany all returned Product units or parts with a written explanation of the alleged problem or malfunction. Ship returned Product units or parts to: 5711 Kenwick St. San Antonio TX 78254 USA.
Note: Freight Damage Claims are invalid for fixtures shipped in non-factory boxes and packing materials.
Freight
All shipping will be paid by the purchaser. Items under warranty shall have return shipping paid by the manufacturer only in the Continental United
States. Under no circumstances will freight collect shipments be accepted. Prepaid shipping does not include rush expediting such as air freight. Air
freight can be sent customer collect in the Continental United States.
REPAIR OR REPLACEMENT AS PROVIDED FOR UNDER THIS WARRANTY IS THE EXCLUSIVE REMEDY OF THE CONSUMER.
MEGA SYSTEMS INC. MAKES NO WARRANTIES, EXPRESS OR IMPLIED, WITH RESPECT TO ANY PRODUCT, AND MEGA SYSTEMS SPECIFICALLY DISCLAIMS ANY WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. MEGA
SYSTEMS SHALL NOT BE LIABLE FOR ANY INDIRECT, INCIDENTAL OR CONSEQUENTIAL DAMAGE, INCLUDING LOST PROFITS, SUSTAINED OR INCURRED IN CONNECTION WITH ANY PRODUCT OR CAUSED BY PRODUCT DEFECTS OR THE PARTIAL
OR TOTAL FAILURE OF ANY PRODUCT REGARDLESS OF THE FORM OF ACTION, WHETHER IN CONTRACT, TORT (INCLUDING
NEGLIGENCE), STRICT LIABILITY OR OTHERWISE, AND WHETHER OR NOT SUCH DAMAGE WAS FORESEEN OR UNFORESEEN.
Warranty is void if the product is misused, damaged, modified in any way, or for unauthorized repairs or parts. This warranty gives you specific
legal rights, and you may also have other rights which vary from state to state.
Ph 210-684-2600 Fax 210-855-6279
www.mega-lite.com / info@mega-lite.com
Mega-Lite
5718 Kenwick St
San Antonio, TX 78238
Loading...
