Mega Lite outshine t54 User Manual

USER MANUAL
Table of Contents
Safety Information…………………………………………………………..…………………….3 Specifications……………………………………………………………………………………...4 Main Power Connection………………………………………………………………………….5 DMX-512 Connection…………………………………………………………………...………..5
Main Control Menu..............................................................................................................6
DMX Profile.........................................................................................................................8
Rigging the Fixture………………………………………………………………………………..9
Cleaning & Maintenance.....................................................................................................9
Check that the unit has not been damaged during transport
Protection Against Fire
1. Maintain a minimum of 1 foot distance from any type of flame.
3. Replace fuse only with the specified type and rating.
4. Do Not install the unit to close to a heat source.
5. Make sure cable are properly secured
6. Maximum surface operating temperature 140º.
Protection Against Electrical Shock
1. Disconnect power before servicing.
2. For connection to main power supply proceed to page 5.
3. This unit must be earthed. (electronically grounded)
4. This unit is IP 65 rated (do not submerge unit into water)
Protection Against Mechanical Hazards
1. Use safety chain when hanging unit.
2. Use quality clamps or bolts when positioning unit
3. Do not open unit while it is on, risk of electrical shock.
3
Technical Information
Part Numbers
7221– Outshine T54
Mechanical Specifications
DMX Connectors: Neutrik 3 pin XLR NC3FXX-HD-D and NC3MXX-HD-D IP 67 connectors in and out
Power connection: Nema 5-15
Thermal: Maximum ambient temperature 104°
Maximum surface temperature 140°
Fastening System: Dual Yoke
Display: Digital
Lens Angle: 16º
11.85”
10.25”
4.5”
8.25”
Fixture Packaging
Size: 10.25” x 11.85” x 5.75”
Weight: 7lb
Size: 13.5” x 11.25” x 7.5”
Weight: 8.75lb
Electrical Specifications
LED Quantity: 18 Tri Color LEDs Red, Green, Blue
LED Watts: 3W
LED Lifetime: 40 to 80 thousand hours average
Refresh Rate: 6000 Hz
Power Input Voltage: 110V-240 50/60 Hz
Ballast: Electronic auto switching
Power Consumption: Watts: 57
Amps: .75
Control & Programming
Protocol: DMX 512
DMX Modes: Mode 3 Channels R,G,B
Mode 4 Channels Dimmer, R,G,B Mode 6 Channels Dimmer, R,G,B, Strobe, Macro
Control Options: Display preset setting
5.75” w/ cable
4
Main Power Connection
Caution!
1. Do not connect fixture to a dimmer system.
2. This unit has Auto switching power supply. It will respond to 110V or 220V automatically
3. This unit must be earthed. (electronically grounded)
The occupation of the connection-cable is as follows:
This fixture is equipped with an electronic power supply that will let the unit operate from 100V to 240V from 50Hz to 60Hz
Cable (USA) Cable (EU) Pin 110V
Black Brown
White
Green
Light Blue
Yellow/Green
Live
Neutral
Ground
L
N
220V
L
L
L N
DMX-512 Connection
The fixture is equipped with Neutrik NC3FXX-HD and NC3MXX-HD IP 67 3 pin XLR Sockets for DMX input and output. The sockets are wired in parallel. Only use a shielded twisted pair cable designed for RS-485 and 3 pin XLR plugs and connectors in order to connect the controller with the fixture or the fixture with another.
DMX—input
1
2
3
Caution! At the last fixture the DMX signal needs to be terminated with a terminator. Solder a 120 Ohm re­sistor between the (-) and the (+) signal into a 3 pin XLR plug and plug it in to the last fixture on the signal run. Pre-manufactured terminator plugs are available for purchase from your Mega-Lite dealer (P-DMX-T).
1. Shield
2. Signal (-)
3. Signal (+)
5
DMX—output
2
1
3
Display Menu
CONTROL BOARD
DMX Ad- Red Dim-
1-512 0-255
3-Ch
4-Ch
6-Ch
Green Dim- Blue Dimmer
0-255
0-255
Fade
00-15
Fade DMX Mode
00-15
Dim Rate
0-3
Mode Up
Down
Enter
Press Mode to select the display options
DMX Address
Press Enter to select the DMX start channel use the up/down keys, display will be flashing once you have selected the desired start channel Press Enter to confirm display will stop flashing.
DMX Mode
This function allows you to select the mode in witch you want to control the Arc 90. Press Enter use the up/down keys to select desired DMX mode settings. Press Set Up to confirm the settings.
3 CH
Red, Green, Blue
4 CH
6 CH
Dimmer, Red, Green, Blue
Dimmer, Red, Green, Blue, Strobe, Macro
Red Dimmer
This function allows you to dim up or down the red LEDs . Press Enter use the up/down keys to select desired dimmer settings. Press Set Up to confirm the settings.
Green Dimmer
This function allows you to dim up or down the green LEDs . Press Enter use the up/down keys to select desired dim- mer settings. Press Set Up to confirm the settings.
Blue Dimmer
This function allows you to dim up or down the blue LEDs . Press Enter use the up/down keys to select desired dimmer settings. Press Set Up to confirm the settings.
6
Flash
This function allows you to strobe the LEDs. Press Enter use the up/down keys to select desired flash settings. Press Enter to confirm the settings.
Fade Scroll
This function allows you to fade the LEDs from one color to another. Press Enter use the up/down keys to select de- sired fade speed settings from 0 to 15. Press Enter to confirm the settings.
Dimming Speed
Press Enter to select the desired dimming speed. Use the up/down keys to select desired dimming fade speed settings from 0 to 3. Zero speed will be the fastest. Press Enter to confirm the settings.
7
Outshine T54 DMX Profile
3Ch
DMX Chanel Function Description Value
1 LED Color Red LED intensity 0-255 2 LED Color Green LED Intensity 0-255 3 LED Color Blue LED Intensity 0-255
4Ch
DMX Chanel Function Description Value
1 Dimmer Dimmer Off to Full 0-255 2 LED Color Red LED intensity 0-255 2 LED Color Green LED Intensity 0-255 3 LED Color Blue LED Intensity 0-255
6Ch
DMX Chanel Function Description Value
1 Dimmer Dimmer Off to Full 0-255 2 LED Color Red LED intensity 0-255
3 LED Color Green LED Intensity 0-255
4 LED Color Blue LED Intensity 0-255 5 Strobe
Random Strobe (slow to fast) 197-255
6 Macro
White LED Full 250-255
Strobe (slow to fast) 0-196
No Function 0-1
Color fade (slow to fast) 2-19
Color Snap (slow to fast) 20-39
Random (slow to fast) 40-59
Yellow 60-79 Purple 80-99
Aqua 100-119
Orange 120-139
Red Pulse 140-159
green Pulse 160-179
Blue Pulse 180-199
Yellow Pulse 200-219
Aqua Pulse 220-229
White Pulse 230-249
8
Rigging the fixture
Caution!
1. The installations must be carried out by an authorized dealer or trained professional.
2. Unit may cause severe injures if you have doubts concerning the safety do not install.
3. Unit is to be 24inches away from flammable materials (decoration material)
4. Use high quality installation equipment to hang unit.
When rigging a unit it is very important that you follow common safety procedures. Rigging requires extensive experi­ence including but not limited to calculating working loads, material being used and periodic safety inspections. If you lack these qualifications, do not attempt the installation yourself, instead use a professional structural rigger.
When rigging the unit always be secured with a secondary safety attachment. The installation location of the fixture has got to be built in the way that it can hold 10 times the weight for 1 hour with out any harming. Installation should be checked at least one time a year by a skilled person.
Cleaning and Maintenance
Installation Maintenance: The operator has to make sure th at the unit is operating safely and h as the in stalla-
tions and electronics checked by an expert every year.
The following points have to be considered during the inspection:
1) All screws used for installing the device or part of the device have to be tightly connected and must not be corroded.
2) There must not be any deformations on the housing, fixation and installation spots (ceiling, suspension, trussing).
3) The electronic power supply cables must not show any damages, material fatigue (e.g. porous cables) or sediments. Further instructions depending on the installation spot and usage have to be adhered by a skilled installer and any safety problems have to be removed.
Note: There is no s erviceable part s ins ide the device except fo r the LED s. Maintenance and service operations are to be carried out by authorized dealers.
Replacing the fuse: Only replace t he fuse w ith th e same type and rat ing.
Replacing the power cable: If the power cable of th is dev ice becomes damaged, it has to be r eplaced by author-
ized dealers or trained professional only.
Should you have further questions , please contact your dealer.
Parts List
7221-LED Replacement LED
7221-MPCB Main PCB card
7221-PS Power Supply
7221-DIS Display
7221-LEDMOD LED Module
7221-FG Frontal Glass
7220-KN Knob Set
9
Warranty Information
Warranty Conditions
-Unless otherwise stated in writing, your product is covered by a one year parts and labor limited warranty.
-LEDs are not guaranteed to match in color temperature or output.
-It is the owners responsibility to furnish receipts or invoices for verification of purchase, date, and reseller or distributor.
If purchase date cannot be provided, date of manufacture will be used to determine warranty period.
-Goods returned under warranty must follow the proper authorization procedure and must be accompanied by a copy of
the original invoice and Return Authorization Number given by MSI.
-Goods repaired under warranty will be returned to the owner with the freight prepaid by MSI via the most economical
means of shipment.
-Repair or replacement as provided for under this warranty is the exclusive remedy of the consumer. MEGA SYSTEMS
INC. makes no warranties, express or implied, with respect to any product, and Mega Systems specifically disclaims any warranty of merchantability or fitness for a particular purpose. Mega Systems shall not be liable for any indirect, inci­dental or consequential damage, including lost profit, sustained or incurred in connection with any product or caused by product defect or the partial or total failure of any product regardless of the form of action, weather in contract, tort (including negligence), strict liability or otherwise, and weather or not such damage was foreseen or unforeseen.
- Warranty is void if the product is misused, damaged, modified in any way, or for unauthorized repairs or parts. This
warranty gives you specific legal rights, and you may also have other rights which vary from state to state.
Ph 210-684-2600 Fax 210-855-6279
www.mega-lite.com / info@mega-lite.com
Mega-Lite
5718 Kenwick St
San Antonio, TX 78238
