USER MANUAL

Bluetooth® Wireless Stereo Headphones

with Headset Funconality

Model: AF36

PACKAGE CONTENTS

EN

Bluetooth® Wireless Stereo Headphones

with Headset Funconality

Wave Stereo
Bluetooth
Wireless
Headphones

Carrying
pouch

User
manual

Micro-USB
charging
cable

Stereo audio
cable for
wired use

1

PRODUCT OVERVIEW

Bluetooth® Wireless Stereo Headphones

with Headset Funconality

Left Earcup Right Earcup

A

B
C

D

E

F

EN

G

H

I

A

Status indicator light

B

Play/pause/multifunction button

C

Volume up button ( )

D

Previous track button ( )

E

Volume down button ( )

F

Audio jack for wired use

G

Charging connector

H

Next track button ( )

I

Built-in microphone

2

CHARGING

*** You must completely charge the headset before the first use ***

Connect the Micro-USB charging cable to any powered USB port and to the
charging jack of the Wave, which is located underneath a cover on the left
earcup. Make sure it is plugged in fully. Charge time is approximately 2 hours.
The red charging indicator light will stay lit while the headphones are charging
and turn off when they are ready for use.

When the battery is low, the status indicator light will be solid red and the
headset will say “battery low” every 60 seconds.

Apple® devices such as the iPhone®, iPad®, and iPod touch® will display an
on-screen headset battery indicator while the Wave is connected.

TURNING ON AND OFF

To turn on, press and hold the Multifunction button for about 2 seconds.
The headphone will say “power on” and the status indicator light will flash
blue.

To turn off, press and hold the Multifunction button for about 4 seconds.
The headphone will say “power off” and the status indicator light will flash red.

3

PAIRING WITH BLUETOOTH DEVICES

*** Your headset must be paired to a Bluetooth device before it can be used.

It is only necessary to pair your headset once with each device ***

Make sure the Wave is turned off and within 3 feet (1 meter) of your device.

1.
Press and hold the Multifunction button for about 5 seconds until you hear
the headphone say “Pairing”. The status indicator light will flash red and
blue in an alternating pattern while the Wave is in pairing mode.
(Note: The Wave will enter standby mode if not paired within 2 minutes)

Open the Bluetooth menu on the device you wish to pair (see Locating

2.
the Bluetooth menu section below for more details). Some devices
require you to select “search for devices” or “add new device” in order to
create a Bluetooth pairing.

Wait until you see “Air-Fi Wave” on your device screen.

3.

Select “Air-Fi Wave” on your device and follow any further prompts to pair.

4.
Use “0000” if a pin is required. Once connected, the status indicator light
will be solid blue.

LOCATING THE BLUETOOTH MENU:

iPhone, iPad, and iPod touch

a)

On your device, open the
Select

Bluetooth.

b)

The iPhone/iPad/iPod will automatically search for new devices.

Android™ Phones and Tablets

On your device, open the

a)

Select

Bluetooth

b)

the

Wireless & Networks

Select “Search for Devices” if your phone or tablet does not
automatically search for new devices.

Windows® Phone 8 devices

On your device, open the

a)

Select

Bluetooth. If Bluetooth is not on, turn it on.

b)

The Windows phone will automatically search for new devices.

Computers, Laptops, and Other Devices

Visit www.meelec.com/bluetooth for pairing, connecting, and setup
information.

If pairing fails after several tries, please refer to your device’s user manual for
further information. Visit www.MEEaudio.com/bluetooth for pairing videos,
troubleshooting, and additional information.

Settings

If Bluetooth is not on, turn it on.

(on older Android devices

menu.

Settings

menu.

menu). If Bluetooth is not on, turn it on.

Settings

Bluetooth

menu.

is found in

4

CONNECTING TO PAIRED DEVICES

Once the Wave is turned on, it will automatically connect with the last paired
Bluetooth device that is on and within range. If the Wave is not connected
automatically, tap the Multifunction button once to initiate connection with last
paired device. If the headset still does not connect, open the Bluetooth menu
on your device and select “Air-Fi Wave” from the Bluetooth device list.

Note: On some computers, the Bluetooth connection must be established
manually every time.

CONTROLS

The Wave can control media and phone calls from a smartphone or tablet.

Adjusting Volume

Function Operation Notes

Increase volume Short press the Volume up ( ) button

Decrease volume Short press the

Note: volume adjustments made while playing media will change the volume of the
headset independently of the connected device. Raise or lower device volume as
needed to further increase or decrease the overall volume. Some newer devices use
AVRCP 1.4 Bluetooth Profile, which will allow the Wave to control the device volume
directly at all times.

Volume down ( ) button

Headset will produce
a tone when volume
reaches the minimum
or maximum level.

Controlling Phone Calls

Status Function Operation

Incoming call

Call in progress End call Press the

Answer call Press the

Reject call

Multifunction button

Press and hold the
button for 2 seconds

Multifunction button

continue to next page

Multifunction

5

CONTROLS (Continued)

Controlling Phone Calls (Continued)

Status Function Operation

Call in progress,
phone handset
active*

Call in progress,
second incoming call

*

If you answer a call from your phone when a headset is connected, most phones will activate the phone
handset, not the headset. Press and hold the Multifunction button for 2 seconds to transfer the call to
the headset

Transfer call to headset

End call Press the

Hang up current call
and answer new call

Controlling Media Playback

Status Function Operation

No media playing*

(standby mode)

Play media Press the

Media playing Pause media playback Press the

Media playing or

paused

*

You may need to focus on the media player application by bringing it up on the screen for initial
playback to start.

**

Not all media players support this functionality.

Note: If you answer or make a call while listening to media, the media will be paused
until the call has ended.

Skip to next track** Press the Next track ( ) button

Restart the track/
previous track**

Additional Functionality

Status Function Operation

Media playing or

standby mode

*

Not all devices support this functionality. For more information, refer to the user manual for your device.

Redial last call* Double press the

Press and hold the
button for 2 seconds

Multifunction button

Press the

Multifunction button

Multifunction button

Multifunction button

Press the

Previous track ( ) button

Multifunction button

Multifunction

6

MULTIPOINT

Multipoint allows two Bluetooth devices to be connected to the Wave
simultaneously. Both devices will need to be paired before multipoint can be
used.

Multipoint Pairing

To use two Bluetooth devices with the Wave, first pair them by following the
pairing procedure described in the Pairing with Bluetooth devices section for
each device and then turn off the headset.

When turned on again, the Wave will automatically attempt to connect to the
2 most recently-paired devices, as long as they have Bluetooth enabled and
are within range. If a device that has already been paired does not connect
automatically, select “Air-Fi Wave” from the Bluetooth menu of the device.

If you no longer wish to connect to multiple devices, disable Bluetooth on the
device you do not want connected to the Wave or remove the “Air-Fi Wave”
pairing from the Bluetooth menu of the device.

Multipoint Functionality

Status Function Operation

Media playing

on one device

*It may take up to 10 seconds for audio to switch

Incoming calls will always take precedence over media. If media is playing
on one device and an incoming call is received on the other device, the Wave
will pause the media on the active device and activate the device with the
incoming call. Once the call is ended, the Wave will reactivate the original
device and resume playback (with most media applications).

For phone call controls, see the Controlling Phone Calls section.

Play media on other device

Pause audio playback on the active
device and start audio playback on the
other connected device*

7

USING AS A WIRED HEADPHONE

The Wave can be used as a wired headphone by plugging one end of the
included stereo audio cable into the jack on the left earcup and the other end
into any audio device with a standard 3.5mm headphone jack. This allows
use when the battery is depleted and with devices that do not have Bluetooth
(such in-flight entertainment systems) or aren’t paired.

The Wave can be used wired while also connected via Bluetooth to another
device; Bluetooth audio takes precedence over wired audio. Wired audio will
be partially muted whenever a signal is transmitted via Bluetooth and will
resume approximately 4 seconds after the Bluetooth transmission ends.

Note: The built-in microphone of the Wave will not work in wired mode.

SAFETY AND CARE

When not in use, power the headphones off and store in the included

a)

protective carrying pouch.
Clean with a soft cloth, damp with diluted soap water solution if

b)

necessary. Do not use chemical cleaners.
There are no user replaceable/reparable parts in the headphones.

c)

Disassembling the device will void your warranty.
Do not expose the headphones to liquids. If the device comes in

d)

contact with liquids, quickly wipe away. If submersed in water, do not
turn the device on until completely dried. Note: liquid submersion voids
the warranty.

Do not use around flammable gasses as fire or explosion may occur

e)

Battery performance will be severely decreased when stored in extreme

f)

temperatures: below -10°C/14°F or above 45°C/113°F including direct
sunlight.

Replacement parts and accessories are available online at

g)

www.MEEaudio.com

8

WARNING

Using headphones at high volumes for extended periods of time will result
in permanent hearing damage. It is advised you keep volume levels medium
to low at all times for your safety. Do not use while driving a car, cycling,
operating machinery, or performing other activities that require hearing
surrounding sounds.

It is advised to turn the volume on your device all the way down before
connecting your headphones, then gradually increase the volume until you
reach a comfortable listening level.

SPECIFICATIONS

See the Wave product page at www.MEEaudio.com for product
specifications.

TROUBLESHOOTING

Visit www.MEEaudio.com/bluetooth for additional Bluetooth information
and troubleshooting.

WARRANTY:

The Wave is covered by a 1-year manufacturer warranty.
For more information, visit www.MEEaudio.com/warranty.

MEE audio and its logo are registered trademarks of S2E, Inc. All rights reserved.

iPhone®, iPad®, iPod touch®, and Siri® are registered trademarks of Apple Inc.
Android™ is a registered trademark of Google Inc.
Windows® Phone is a registered trademark of Microsoft Corporation in the United States and other countries.
The Bluetooth® word mark and logos are registered trademarks owned by Bluetooth SIG, Inc.
and any use of such marks by MEE audio is under license. Other trademarks and trade names
are those of their respective owners.

9
