mee audio AF32 User Manual

User
ManUal

STEREO BLUETOOTH
WIRELESS HEADPHONES

model: AF32

®

PACKAGE CONTENTS

1

Runaway AF32
Stereo Bluetooth
Wireless Headphones

Charging cable
(USB – 3.5mm)

Stereo audio cable
(3.5mm – 3.5mm)

Carrying pouch

User manual

PRODUCT OVERVIEW

Stereo Bluetooth
Wireless Headphones

RIGHT EAR CUP

LED indicator light

A

Multifunction button ( / )

B

Previous track button ( )

C

Next track button ( )

D

Volume down button ( )

E

Volume up button ( )

F

Headphone / charging jack

G

Microphone

H

-

+

2

CHARGING

*** You must completely charge the headphones before the first use ***

Connect the USB charging cable to any powered USB port and to the 3.5mm
jack on the right earcup. Make sure it is plugged in fully. Charge time is
typically 2-3 hours.

The red LED light will stay lit while the headphones are charging and will blink
or turn off completely when the headphones are ready for use. A blinking red
LED light indicates a trickle charge mode, whereby the battery is charged
almost fully and the headphones are maintaining their current charge level.

Note: the Runaway cannot be turned on or used while charging.

INDICATOR LIGHT STATE WHEN CHARGING CABLE IS PLUGGED IN:

LIGHT PATTERN STATUS NOTES

Solid red light Battery charging Allow to charge for 2-3 hours

Blinking red light Trickle charge Ready for use

All lights off Battery full Ready for use

When the battery is low, the headphones will say “Battery low” every
60 seconds and the red light will flash three times every three seconds.

Apple® devices such as the iPhone®, iPad®, and iPod® Touch will display a
headphone battery indicator when the Runaway is connected.

3

TURNING ON AND OFF

To turn on, press and hold the Multifunction button for approximately 3
seconds. The headphones will say “Power on” and the blue LED light will flash.

To turn off, press and hold the Multifunction button for approximately 4
seconds. The headphones will say “Power off” and the red LED light will flash.

PAIRING WITH BLUETOOTH DEVICES

*** Your headphones must be paired to a Bluetooth device before they can be

used. It is only necessary to pair your headphones once with each device. ***

1) Open the Bluetooth menu on the device you wish to pair (see Locating
the Bluetooth Menu on page 5 for more details). Some devices require

you to select “Search for Devices” or “Add New Device” in order to create a
Bluetooth pairing.

2) With the headphones turned off, press and hold the Multifunction button for
approximately 6 seconds until the headphones say “Pairing”. The red and
blue LED lights will flash in an alternating pattern while the Runaway is in
pairing mode. (Note: The Runaway will enter standby mode if not paired
within 90 seconds.)

3) Wait until you see “MEE audio Runaway” on your device screen.

4) Select “MEE audio Runaway” on your device and follow any further prompts
to pair. Use “0000” if a pin is required. Once pairing is complete and a
connection is established, the blue LED light will flash several times.

4

LOCATING THE BLUETOOTH MENU

iPhone, iPad, and iPod Touch

a) On your device, go to

b) Select

Bluetooth

The iPhone/iPad/iPod will automatically search for new devices

Android™ Phones and Tablets

a) On your device, go to the

b) Select

Bluetooth

in the

Wireless & Networks

Select “Search for Devices” if your phone or tablet does not automatically
search for new devices

Windows® Phone 8 Devices

a) On your device, open the

b) Select

Bluetooth

The Windows phone will automatically search for new devices

Computers, Laptops, and Other Devices

Visit the Bluetooth Support Page at www.MEEaudio.com
for pairing and setup information.

If pairing fails after several tries, please refer to your device’s user manual for
further information. Visit the Bluetooth Support Page at www.MEEaudio.com
for instructional pairing videos and troubleshooting information.

Settings

. If Bluetooth is not on, turn it on.

Settings

menu

(on older Android devices Bluetooth is found

menu). If Bluetooth is not on, turn it on.

Settings

menu

. If Bluetooth is not on, turn it on.

CONNECTING WITH PAIRED DEVICES

Once the Runaway is turned on, it will automatically connect with the last
paired Bluetooth device that is on and within range. If the Runaway is
not connected automatically, tap the multifunction button once to initiate con­nection with last paired device. If the headphones still do not connect, open
the Bluetooth menu on your device and select “MEE audio Runaway” from
the Bluetooth device list.

On some computers, Bluetooth audio must be enabled manually every time
you connect.

5

CONTROLS

The Runaway can control media and phone calls from a smartphone or tablet.

1. ADJUSTING THE VOLUME

FUNCTION OPERATION NOTES

Increase volume Press the Volume Up

Decrease volume Press the Volume

Note: Volume can be adjusted only while media is playing or during a phone call.
With most devices, volume adjustments will change the volume of the headphones
independently of the connected device while playing media. Adjust device volume
as needed to further increase or decrease the volume. During a phone call the
headphones will directly control device volume.

2. CONTROLLING PHONE CALLS

STATUS FUNCTION OPERATION

Incoming call Answer call Press the Multifunction button

Call in progress End call Press the Multifunction button

button

Down button

Reject call Double press the Multifunction button

Transfer call
between
headphones
and phone*

Mute /
unmute call

When the volume reaches
the minimum or maximum
level the Runaway will
produce a short tone.

Press and hold the Multifunction button
for 2 seconds until you hear a tone

Double press the Multifunction button
to mute; double press again to unmute

(continues on page 7)

6

CONTROLS (CONTINUED)

2. CONTROLLING PHONE CALLS (CONTINUED)

STATUS FUNCTION OPERATION

Call in
progress,
second
incoming call

One call active,
one on hold

*If you answer an incoming call from your phone instead of the headphones, most

phones will activate the phone speaker. Press and hold the Multifunction button for 2
seconds to transfer the call to the headphones.

Answer new
call and put
current call
on hold

Reject
incoming call

Switch
active calls

End current
call and
switch to call
on hold

Press the Multifunction button

Double press the Multifunction button

Press and hold the Multifunction button
for 2 seconds until you hear a tone

Press the Multifunction button

3. CONTROLLING MEDIA PLAYBACK

STATUS FUNCTION OPERATION

No media playing* Play media Press the Multifunction button

Media playing Pause media

Media playing
or paused

*You may need to focus on the media player application by bringing it up on the

screen for initial playback to start.

** Not all media players support this functionality.

Note: If you answer or make a call while listening to media, the media will be paused
until the call has ended.

playback

Skip to next track** Press the Next Track button

Restart track /
previous track**

Press the Multifunction button

Press the Previous Track button

(continues on page 8)

7

CONTROLS (CONTINUED)

4. ADDITIONAL FUNCTIONALITY

FUNCTIONALITY OPERATION NOTES

Redial last call* Double press the

Activate Siri ®/
voice command/
voice dialing*

Battery meter Press the volume

*Not all devices support this functionality. For more information, refer to the user

manual for your device.

Multifunction button
when no call is in
progress

Press and hold the
Multifunction button
for 2 seconds

up or volume down
button when the unit
is in standby mode
(no media playing/
no active phone
calls)

Headphones will say “Last
number redial”

Headphones will produce
a tone and media will be
paused. Press and hold
Multifunction button for 2
seconds again to cancel.

Headphones will provide
approximate battery state as
either “Battery high”, “Battery
medium”, or “Battery low”

8

MULTIPOINT

Multipoint allows two Bluetooth devices to be connected to the Runaway
simultaneously, providing additional flexibility for your multimedia experience.

1. MULTIPOINT PAIRING

To use two Bluetooth devices with the Runaway, first pair them by following
the pairing procedure described in the Pairing with Bluetooth Devices
section on Page 4 for each device and then turn off the headphones. Both
devices will need to be paired before multipoint can be used.

When turned on again, the Runaway will automatically attempt to connect to
the 2 most recently-paired devices, as long as they have Bluetooth enabled
and are within range. If a device that has already been paired does not
connect automatically, select “MEE audio Runaway” from the Bluetooth menu
of the device.

If you no longer wish to connect to multiple devices, disable Bluetooth on the
device you do not want connected to the Runaway or remove the “MEE audio
Runaway” pairing from the Bluetooth menu of the device.

(continues on page 10)

9

MULTIPOINT (CONTINUED)

2. MULTIPOINT FUNCTIONALITY

STATUS FUNCTION OPERATION

Media playing
on one device

Incoming call Answer call Short press the Multifunction button

Call in
progress,
second
incoming call

One call active,
one on hold

Note: Incoming calls will always take precedence over other audio. If two phones are
connected to the Runaway, an incoming call on either phone will trigger an alert and
media playback will be paused if the call is answered. Once the call is terminated, the
Runaway will reactivate the original device and resume playback (with most media
applications).

Play media on
other device

Reject call Double press the Multifunction button

Mute /
unmute call

Answer new
call and put
current call
on hold

Reject
incoming call

Switch
active calls

End current
call and
switch to call
on hold

Pause audio playback on the active
device and start audio playback on the
other connected device. It may take up
to 10 seconds for audio to switch

Double press the Multifunction button

Press the Multifunction button

Double press the Multifunction button

Press and hold the Multifunction button
for 2 seconds until you hear a tone

Press the Multifunction button

10

USE AS WIRED HEADPHONE

The Runaway can be used as a wired headphone by plugging one end of
the included stereo audio cable into the 3.5mm jack on the Runaway and the
other end into any audio device with a standard 3.5mm headphone jack.
Plugging the audio cable into the headphone will disable Bluetooth
functionality until the cable is unplugged.

Note: the built-in microphone of the Runaway will not work when the
headphones are used in wired mode.

SAFETY AND CARE

• When not in use, power the headphones off and store in a cool, dry place.
Battery performance will be severely decreased when stored in extreme
temperatures: below -10°C/14°F or above 45°C/113°F including direct
sunlight.

• Clean with a soft cloth, damp with diluted soap water solution if necessary.
Never use chemical cleaners.

• There are no user replaceable/reparable parts in the headphone.
Disassembling it will void your warranty.

• Do not expose the headphones to liquids. If the device comes in contact
with liquids, quickly wipe away. If submersed in water, do not turn the
device on until completely dried. Note: liquid submersion voids the
warranty.

• Do not use around flammable gasses as fire or explosion may occur

• Replacement parts and accessories are available online at

www.MEEaudio.com

WARNING:

Using headphones at high to moderate volumes for extended periods of
time will result in permanent hearing damage. It is advised you keep volume
levels moderate to low at all times for your safety. Do not use while driving a
car, cycling, operating machinery, or performing other activities that require
hearing surrounding sounds.

It is advised to turn the volume on your device all the way down before
connecting your headphones, then gradually increase the volume until you
reach a comfortable listening level.

11

SPECIFICATIONS

Bluetooth Version 4.0

Bluetooth Profiles Supported A2DP, HSP, HFP, AVRCP

Driver 40 mm dynamic driver

Frequency Response 20Hz to 20kHz

Operating Range 10 m (30 ft)

Music Playback Time 15 hrs

Talk Time 15 hrs

Standby Time 150 hrs

TROUBLESHOOTING

Visit the Bluetooth Support Page at www.MEEaudio.com
for troubleshooting procedures.

WARRANTY

The Runaway is covered by a 1 year manufacturer warranty.
For more information, visit www.MEEaudio.com

12

NOTES

Have a question?
Email [e-mail]

MEE audio and its logo are registered trademarks of S2E, Inc. All rights reserved.

iPhone®, iPad®, iPod®, iPod touch®, and Siri® are registered trademarks of Apple Inc.
Android™ is a registered trademark of Google Inc.

®

Phone is a registered trademark of Microsoft Corporation in the United States and other countries.

Windows

®

word mark and logos are registered trademarks owned by Bluetooth SIG, Inc.

The Bluetooth
and any use of such marks by MEE audio is under license. Other trademarks and trade names
are those of their respective owners.

13

www.MEEaudio.com

[e-mail]
