MEE AF36 User Manual

Bluetooth® Wireless Stereo Headphones

with Headset Funconality

Model: AF36

USER
MANUAL

EN

PACKAGE CONTENTS

Wave Stereo
Bluetooth
Wireless
Headphones

Carrying
pouch

User
manual

Micro-USB
charging
cable

Stereo audio
cable for
wired use

1

Bluetooth® Wireless Stereo Headphones

with Headset Funconality

PRODUCT OVERVIEW

EN

Left Earcup Right Earcup

A
B
C
D
E

Bluetooth® Wireless Stereo Headphones

with Headset Funconality

A

B
C

D

E

F

G

H

I

2

F
G
H
I

Audio jack for wired use
Charging connector
Next track button ( )
Built-in microphone

Status indicator light
Play/pause/multifunction button
Volume up button ( )
Previous track button ( )
Volume down button ( )

CHARGING

*** You must completely charge the headset before the first use ***

Connect the Micro-USB charging cable to any powered USB port and to the
charging jack of the Wave, which is located underneath a cover on the left
earcup. Make sure it is plugged in fully. Charge time is approximately 2 hours.
The red charging indicator light will stay lit while the headphones are charging
and turn off when they are ready for use.

When the battery is low, the status indicator light will be solid red and the
headset will say “battery low” every 60 seconds.

Apple® devices such as the iPhone®, iPad®, and iPod touch® will display an
on-screen headset battery indicator while the Wave is connected.

TURNING ON AND OFF

To turn on, press and hold the Multifunction button for about 2 seconds.
The headphone will say “power on” and the status indicator light will flash
blue.

To turn off, press and hold the Multifunction button for about 4 seconds.
The headphone will say “power off” and the status indicator light will flash red.

3
