Explanation of Symbols for
ICD and CRT-D devices

© Medtronic, Inc. 2015
M945734A001B
2015-06-16

Technical manuals:
www.medtronic.com/manuals

Caution: Federal law (USA) restricts this device
to sale by or on the order of a physician.

*M945734A001*

The following list of symbols applies to various products. Refer to the product package labels to see which symbols apply to this product.

Conformite Européenne
(European Conformity). This
symbol means that the device
fully complies with AIMD
Directive 90/385/EEC (NB 0123)
and R&TTE Directive 1999/5/EC.

This symbol means that the
device fully complies with the
Australian Communications and
Media Authority (ACMA) and the
New Zealand Ministry of
Economic Development Radio
Spectrum Management
standards for radio
communications products.

Radio compliance. This symbol
means that telecommunications
and radio communications
regulations in your country may
apply to this product. Please go
to www.medtronic.com/radio for
specific compliance information
related to telecommunications
and radio standards for this
product in your country.

Serial number

Use by

Reorder number

Authorized representative in the
European community

Sterilized using ethylene oxide

Temperature limitation

Do not reuse

Do not use if package is
damaged

Consult instructions for use

Open here

Open here

Package contents

Implantable device

Torque wrench

Pin plug

ICD (single chamber, RV)

ICD (dual chamber)

Cardiac resynchronization
therapy with defibrillation
(CRT-D)

Header shape

DF-1 connector

DF4 connector

IS-1 connector

IS4 connector

Adaptive

Upper tracking rate and lower
rate

Lower rate

Amplitude and pulse width: RA

Amplitude and pulse width: RV

Date of manufacture

Manufacturer

Product documentation

Dangerous voltage

Amplitude and pulse width: LV

Sensitivity: RA

Sensitivity: RV

Ramp+: RV

A-V interval (paced and sensed)

Sensed A-V interval

Pace polarity: LV

Detection: AF

Detection: AT, AF

Therapies: AT, AF

Intervention: AT, AF

Detection: VT, FVT, VF

Detection: VT, VF

Therapies (RV): VT, FVT

Therapies: VT

Ramp+: RV, LV

Ramp: RA, RV, LV

Burst: RV

Burst: RV, LV

Burst+: RA

50 Hz Burst

V pacing and V-V pace delay

SureScan symbol

MR Conditional
Note: Not all devices are MR
Conditional

Therapies: FVT

Therapies (delivered and
stored): VF

Active Can

Defibrillation

AV cardioversion

V cardioversion

Ramp: RA

Ramp: RV

Ramp: RA, RV

Ramp: RV, LV
