Page 1
14" Ultrabook™
MEDION® AKOYA S4216
Instruction Manual
N26968
MD 99081
Page 2
Open Notebook
1 - Webcam
1 2
3
2 - Webcam LED
3 - Microphone
4 - TFT Display
5 - Speaker
6 - Keyboard
7 - Touchpad
8 - Device Indicators
4
9 - Power ON/OFF
10 -
11 - Power Socket
12 - LAN Port (RJ-45)
13 - External monitor port VGA
9
5
14 - HDMI Connector
15 - USB Port 3.0 with charging
function for mobile phones*
C
M
Y
CM
MY
6
7
16 - Audio Out**/
Digital Audio Out*
17 - Microphone**
18 - USB Port 2.0
19 - Optical Drive
20 - Kensington
CMY
CY
K
8
Front View
* See the instruction manual for more information.
** Ports with dual function. Configuration is set with the included software.
10
Right SideLeft Side
11 12
13
14
15
16
Page 3
1 - Webcam
2 - Webcam LED
3 - Microphone
4 - TFT Display
5 - Speaker
6 - Keyboard
7 - Touchpad
8 - Device Indicators
9 - Power ON/OFF
10 -
Multimedia Card Reader
11 - Power Socket
12 - LAN Port (RJ-45)
13 - External monitor port VGA
14 - HDMI Connector
15 - USB Port 3.0 with charging
function for mobile phones*
16 - Audio Out**/
Digital Audio Out*
(S/P-DIF, optical)
17 - Microphone**
18 - USB Port 2.0
19 - Optical Drive
20 - Kensington®Lock
* See the instruction manual for more information.
** Ports with dual function. Configuration is set with the included software.
Right SideLeft Side
16
17
18 19 20
Page 4
Table of Contents
1. About these Instructions .................................................................................. 6
1.1. Symbols and Key words used in these Instructions ............................................... 6
1.2. Proper Use ............................................................................................................................. 7
1.3. Declaration of Conformity ............................................................................................... 7
2. Safety Instructions ............................................................................................ 8
2.1. Operational Safety ..............................................................................................................8
2.2. Never Carry Out Repairs Yourself .................................................................................9
2.3. Data Backup ........................................................................................................................10
2.4. Setup Location ...................................................................................................................10
2.5. Environmental Requirements ......................................................................................10
2.6. Ergonomics .........................................................................................................................11
2.7. Connecting ..........................................................................................................................12
2.8. Cabling ..................................................................................................................................12
2.9. Information about the Touchpad ................................................................................13
2.10. Battery Mode ......................................................................................................................13
3. Included with your Notebook ........................................................................ 14
4. Views ................................................................................................................ 15
4.1. Open Notebook .................................................................................................................15
4.2. Front View ............................................................................................................................16
4.3. Left Side ................................................................................................................................16
4.4. Right Side .............................................................................................................................17
4.5. Operating and Status LEDs ............................................................................................18
5. First Use ........................................................................................................... 19
6. Power Supply ................................................................................................... 20
6.1. On/Off Switch .....................................................................................................................20
6.2. Mains Power........................................................................................................................20
6.3. Battery Mode ......................................................................................................................22
6.4. Power Management (Power Options) .......................................................................25
7. Display ............................................................................................................. 25
7.1. Opening and Closing the Display ...............................................................................25
7.2. Screen Resolution .............................................................................................................25
7.3. Appearance and Customisation ..................................................................................26
7.4. Connecting an External Monitor .................................................................................27
8. Data Input ........................................................................................................ 28
8.1. The Keyboard .....................................................................................................................28
9. The Touchpad .................................................................................................. 30
10. The Hard Drive ................................................................................................. 32
10.1. Important Directories ......................................................................................................33
After Sales Support
Telephone: 1300 884 987
Internet: www.medion.com.au
1 of 80
Page 5
10.2. mSATA Hard Drive (optional) ........................................................................................34
11. The Optical Drive ............................................................................................. 35
11.1. Inserting a disc ...................................................................................................................35
11.2. Playing/Reading Discs .....................................................................................................36
11.3. Regional playback information for DVDs .................................................................36
11.4. Issues Relevant to the Burner .......................................................................................37
12. The Sound System ........................................................................................... 38
12.1. External Audio Connections .........................................................................................38
13. Network Operation ......................................................................................... 39
13.1. What is a Network? ..........................................................................................................39
13.2. Wireless LAN (Wireless Network) ................................................................................39
14. Bluetooth ......................................................................................................... 41
14.1. Flight Mode .........................................................................................................................41
15. The Multi-Card Reader .................................................................................... 42
15.1. Inserting a Memory Card ...............................................................................................42
15.2. Removing Memory Cards ..............................................................................................42
16. The Webcam .................................................................................................... 43
17. The Universal Serial Bus Port ........................................................................ 43
17.1. Charging function for Compatible Mobile Phones ..............................................44
18. Securing your Notebook ................................................................................ 45
18.1. Power-on Password ..........................................................................................................45
18.2. Kensington Security Lock ..............................................................................................45
19. Software ........................................................................................................... 46
®
19.1. Getting to know Windows
8 ........................................................................................46
19.2. Windows Activation .........................................................................................................46
19.3. Windows® 8 – What’s New .............................................................................................47
19.4. Overview ..............................................................................................................................49
19.5. Logging in to Windows ...................................................................................................50
19.6. Linking a User Account to a LiveID .............................................................................51
19.7. Windows® 8 Start Screen ................................................................................................52
19.8. Windows® 8 Desktop ........................................................................................................53
19.9. Using the Search Function ............................................................................................56
20. Control Panel ................................................................................................... 56
®
20.1. Windows
8 Power On/Off Functions ........................................................................58
20.2. Control Panel Settings .....................................................................................................59
20.3. Resetting the Notebook to its Factory Settings .....................................................60
20.4. BIOS Setup Program ........................................................................................................61
20.5. Kaspersky Internet Security ..........................................................................................62
20.6. Windows® 8 – Help and Support .................................................................................63
21. FAQ – Frequently Asked Questions ................................................................ 64
After Sales Support
2 of 80
Telephone: 1300 884 987
Internet: www.medion.com.au
Page 6
22. Customer Ser vice ............................................................................................ 65
22.1. What To Do In Case of Hardware Problems ............................................................65
22.2. Find The Cause ..................................................................................................................65
22.3. Do You Need More Help? ...............................................................................................67
22.4. Driver Support ...................................................................................................................67
22.5. Transport ..............................................................................................................................68
22.6. Maintenance .......................................................................................................................69
22.7. Care of the Display............................................................................................................69
23. Upgrading/Modifying and Repair ................................................................. 70
24. Recycling and Disposal ................................................................................... 71
25. European EN 9241-307 Class II Standard ...................................................... 72
25.1. Energy Star
® ................................................................................................................................................................................................................... 74
25.2. FCC Compliance Statement ..........................................................................................75
26. Index ................................................................................................................ 77
After Sales Support
Telephone: 1300 884 987
Internet: www.medion.com.au
3 of 80
Page 7
14“ Ultrabook™
S4216 (MD 99081)
Warranty Details
The product is guaranteed to be free from defects in workmanship and parts for a
period of 24 months from the date of purchase. Defects that occur within this
warranty period, under normal use and care, will be repaired, replaced or refunded
at our discretion. The benefits conferred by this warranty are in addition to all rights
and remedies in respect of the product that the consumer has under the
Competition and Consumer Act 2010 and similar state and territory laws.
Our goods come with guarantees that cannot be excluded under the Australian
Consumer Law. You are entitled to a replacement or refund for a major failure and
for compensation for any other reasonably foreseeable loss or damage. You are also
entitled to have the goods repaired or replaced if the goods fail to be of acceptable
quality and the failure does not amount to a major failure.
After Sales Support
4 of 80
Telephone: 1300 884 987
Internet: www.medion.com.au
Page 8
Personal Information
Please append the following to your proof of ownership:
Serial number ................................................
Date of purchase ................................................
Place of purchase ................................................
You will find the serial number on the underside of the Notebook. Where applicable,
also copy the number on your warranty documents.
Our Target Group
This operating manual is intended to be read by both first-time and experienced
users. Regardless of any possible professional use, this Notebook is designed for use
in a private household. The entire family will be able to enjoy the wide variety of
applications it offers.
The Quality
We select our components with a close eye to functionality, ease of use, safety and
reliability. Thanks to our ideally balanced hardware/software concept we are able to
offer you a state of the art Notebook that you will enjoy whether you are working or
at play. Thank you for purchasing our products. We are delighted to welcome you as
our new customer.
Copying this Manual
This document contains legally protected information. All rights reserved.
Mechanical, electronic and any other form of reproduction is prohibited without the
written permission of the manufacturer.
Copyright © 2012
®
All rights reserved. This manual is protected by copyright. MEDION
is the owner of
the copyright.
Trademarks: MS-DOS® and Windows®8 are registered trademarks of the Microsoft®
corporation. Intel, the Intel Logo, Intel Inside, Intel Core, Notebook, and Core Inside
are trademarks of Intel Corporation in the U.S. and/or other countries.
®
, the HDMI logo and the name High Definition Multimedia Interface are
registered trademarks of HDMI Licensing LLC.
Other trademarks are the property of their respective owners.
Subject to technical and optical changes as well as printing errors.
After Sales Support
Telephone: 1300 884 987
Internet: www.medion.com.au
5 of 80
Page 9
1. About these Instructions
Before using the device for the first time, please read these operating
instructions carefully, paying special attention to the safety notices.
This device should only be used as designated and as described in these
instructions.
Please keep these instructions in a safe place for future reference.
Always include these instructions if passing the device on.
1.1. Symbols and Key words used in these Instructions
DANGER!
Warning: immediate mortal danger!
Warning!
Warning: possible mortal danger and/or serious irreversible
injuries!
CAUTION!
Please follow the guidelines to avoid injuries and/or property damage.
ATTENTION!
Please follow the guidelines to avoid property damage.
PLEASE NOTE!
Additional information on using the device
PLEASE NOTE!
Please follow the guidelines in the operating instructions.
WARNING!
Warning: danger of electric shock!
• Bullet point/information on operating steps and results
Tasks to be performed
After Sales Support
6 of 80
Telephone: 1300 884 987
Internet: www.medion.com.au
Page 10
1.2. Proper Use
8
This device is designed for the use, management and editing of electronic
documents and multimedia content, as well as for digital communication. The
device is intended for private use only and not for industrial/commercial use.
Please note that we shall not be liable in cases of improper use:
• Do not modify the device without our consent and do not use any auxiliary
equipment which we have not approved or supplied.
• Use only spare parts and accessories which we have supplied or approved.
• Follow all the instructions in these operating instructions, especially the safety
information. Any other use is deemed improper and can cause personal injury or
damage to the product.
• Do not use the device in extreme environmental conditions.
1.3. Declaration of Conformity
This device is supplied with the following wireless features:
• Wireless LAN
• Bluetooth
Due to the output of the integrated wireless LAN solution, the device may only
be used inside buildings in France. There are currently no restrictions in any other
EU countries. When using the device in other countries, please find out about the
relevant legal regulations.
Medion AG hereby declares that this device conforms to the fundamental
requirements and the remaining relevant regulations of the 1999/5/EC R&TTE
Directive.
This product satisfies the basic requirements and relevant regulations of the
Ecodesign Directive 2009/125/EC.
Full declarations of conformity are available at http://www.medion.com/
conformity.
N2696
After Sales Support
Telephone: 1300 884 987
Internet: www.medion.com.au
7 of 80
Page 11
2. Safety Instructions
• Dangers for children and people with reduced ability to operate machinery.
• This device is not intended for use by people (including children) with reduced
physical, sensory or mental abilities or for those without experience and/or
knowledge, unless they are supervised by a person responsible for their safety or
they have been instructed in its use.
• Children should be supervised to ensure that they do not play with the device.
Children should not be allowed to use this device without supervision.
• Keep the device and its accessories out of the reach of children.
DANGER!
Keep plastic packaging out of the reach of children. There is a risk of
suffocation.
2.1. Operational Safety
Please read this section carefully and follow all instructions given. The instructions
will help you to operate the Notebook reliably and increase its service life.
• Never open the housing of the Notebook, battery or mains adapter! This could
result in an electric shock or even ignite a fire which will damage your Notebook.
• Optical drive (CD/CDRW/DVD) constitute class 1 laser equipment providing
these devices are contained in a sealed Notebook housing. Do not remove the
drive cover as invisible laser radiation may escape.
• Do not insert anything into the Notebook through the slots and openings. This
could result in an electric shock or even ignite a fire which will damage your
Notebook.
• The slots and openings on the Notebook are for ventilation purposes. Do not
cover these openings as this could cause the device to overheat.
• The Notebook is not intended for use by companies in the heavy industry sector.
• To avoid damage from lightning strikes, do not operate the Notebook during
thunderstorms.
After Sales Support
8 of 80
Telephone: 1300 884 987
Internet: www.medion.com.au
Page 12
• Do not place any objects on top of the Notebook and do not exert pressure on
the display. Otherwise, there is a risk that the display
may break.
• If the screen breaks, there is a danger of injury. If this happens, pick up the
shattered pieces wearing protective gloves and send them to your service centre
for professional disposal. Finally, wash your hands with soap, as the pieces may
have been contaminated with chemicals.
• Do not fold the display back by an angle of more than 120°. Exceeding this value
may damage the housing or the Notebook. Always hold the display firmly by the
middle when folding it back, adjusting the position and closing it. Failure to do
so may damage the display. Never use force to open the display.
• To avoid damaging the screen, do not touch it with fingers or sharp objects.
• Never lift the Notebook up by the display as this could break the hinges.
• Switch the Notebook off immediately/do not switch the Notebook on,
disconnect the mains plug and contact customer services if ...
− the mains adapter or the attached power cable or plug is burnt or damaged.
Replace faulty mains cables/mains adaptors only with original parts. These
parts should not be repaired under any circumstances.
− the Notebook housing is damaged or liquid has penetrated into the device.
Have the Notebook inspected by customer services. Otherwise, it may not be
possible to operate the Notebook safely. There may be a risk of electric shock
and/or harmful laser radiation!
2.2. Never Carry Out Repairs Yourself
WARNING!
Never try to open or repair the device yourself. There is a risk of
electric shock.
• If there is a fault, contact the MEDION Help Desk or other suitable specialist
workshop.
After Sales Support
Telephone: 1300 884 987
Internet: www.medion.com.au
9 of 80
Page 13
2.3. Data Backup
ATTENTION!
Back up your data on external storage media before each update. We do
not accept any liability for claims for compensation arising from loss of data
or any consequential loss or damage.
2.4. Setup Location
• Keep your Notebook and all connected devices away from moisture and avoid
dust, heat and direct sunlight. Non-compliance with these instructions can lead
to faults or damage to the Notebook.
• Do not use the Notebook outdoors because external elements, such as rain,
snow, etc., could damage it.
• Set up and operate all components on a stable, level and vibration-free surface
to prevent the Notebook from falling down.
• Do not operate the Notebook or power adaptor for long periods on your lap
or any other body part as the heat dissipation on the underside can result in
uncomfortable overheating.
• In the first few hours of use new devices can give off a typical, unavoidable but
totally harmless smell, which wears off with time. Ventilate the room regularly to
prevent odour build-up.
2.5. Environmental Requirements
• The Notebook is most reliably operated at an ambient temperature between
• 5° C (+41° F) and 30° C (+86° F) and at a relative humidity between 20% and 80%
(without condensation).
• When powered off, the Notebook can be stored at temperatures between
• 0° C and 60° C (+32° F and 140° F).
• During a thunderstorm, disconnect the mains plug and the antenna plug. For
extra safety, we recommend using an overvoltage protection device to prevent
the Notebook from sustaining damage as a result of power surges or lightning
strikes.
After Sales Support
10 of 80
Telephone: 1300 884 987
Internet: www.medion.com.au
Page 14
• After transporting the Notebook, wait until the device has reached room
temperature before switching it on. Large changes in temperature or
fluctuations in humidity can cause moisture build up within the Notebook due
to condensation. This can cause an electrical short circuit.
• Keep the original packaging in the event the device needs to be sent in the post.
2.6. Ergonomics
PLEASE NOTE!
Avoid dazzle, reflections and strong bright-dark contrast in order to protect
your eyes.
The Notebook should never be placed next to a window because this is the
brightest part of the room in daylight. This brightness can make it more difficult for
the eyes to adjust to the darker display. The Notebook should always be positioned
so that the direction of vision is parallel to the window front.
Setting up the Notebook with your back to the window is incorrect as reflections
from the bright window on the screen will then be unavoidable. A position looking
onto the window is also incorrect as the contrast between the dark screen and the
bright daylight can cause problems for the eyes to adjust and result in problems.
The parallel line of vision should also be maintained in relation to artificial lighting
equipment.
In other words, the same criteria and principles apply where the workspace is
illuminated with artificial light. Where space restrictions make it impossible to set up
the screen as described, then correct positioning (rotating, tilting) of the Notebook/
screen can prevent dazzling, reflections and excessive bright-dark contrast, etc. In
many cases, an improvement can also be achieved by using slats or vertical blinds
on the windows, partition walls or by changing the artificial lighting equipment.
After Sales Support
Telephone: 1300 884 987
Internet: www.medion.com.au
11 of 80
Page 15
2.7. Connecting
Follow the instructions below to connect your Notebook correctly and safely:
2.7.1. Power Supply
DANGER!
Do not open the housing of the mains adapter. There is a risk of
electric shock when the housing is open. It does not contain any parts
requiring maintenance.
The socket outlet must be close to the Notebook and easily accessible.
• To disconnect the power supply from your Notebook (via the mains adaptor),
pull the mains plug from the power outlet.
• Plug the Notebook’s mains adapter into AC 100–240 V~, 50/60 Hz earthed
sockets only. If you are not sure about the power supply at the set-up location,
please ask your power supplier.
• Use only the mains adapter and power cable supplied.
• For extra safety, we recommend using an overvoltage protection device to
prevent your Notebook from sustaining damage as a result of power surges or
lightning strikes.
• If you want to disconnect the adapter from the mains, pull the connector out
of the wall socket first and then out of the socket on the Notebook. The mains
adapter or the Notebook may be damaged if this process is carried out in the
reverse order. Always take hold of the plug when disconnecting the cable from
the socket. Never pull on the cable.
2.8. Cabling
• Position the cables so that they cannot be stepped on or tripped over.
• To avoid damaging the cables, do not place any objects on them.
• Do not connect peripheral devices – such as keyboards, mouse and monitor, etc.
– when the Notebook is switched on to avoid damage to the Notebook or the
devices. Some devices may also be connected while the computer is running.
This is generally the case for devices with a USB connection. In all cases, observe
the relevant operating instructions.
After Sales Support
12 of 80
Telephone: 1300 884 987
Internet: www.medion.com.au
Page 16
• Maintain a distance of at least one metre from sources of high-frequency and
magnetic interference (TV sets, loudspeakers, mobile phones, DECT telephones,
etc.) in order to avoid malfunctions and data loss.
• Please note that only shielded cables that are shorter than 3 metres may be
connected to the external interfaces of this Notebook. Please only use doubleshielded cables for printer cable connections.
• Do not exchange the supplied cable for another one. Use only the supplied
cable as this cable has been extensively tested in our laboratory.
• In addition, when connecting your peripherals only use the connecting cables
supplied with those devices.
• Ensure that all connection cables are connected to their corresponding
peripheral device to avoid any interference radiation. Disconnect any cables that
are not required.
• The only devices which may be connected to the Notebook are those that meet
the requirements set out in the EN60950 standard “Information Technology
Equipment – Safety” or devices that meet the EN60065 standard “Audio, video
and similar electronic apparatus – Safety requirements”.
2.9. Information about the Touchpad
• The touchpad is operated with the thumb or another finger and reacts to the
energy given out by the skin. Do not use pens or other objects as these can
damage your touchpad.
2.10. Battery Mode
To extend your battery’s performance and lifespan and ensure safe operation, you
should observe the guidelines below:
• Never expose the battery to direct sunlight or heat for extended periods.
• Do not throw batteries into a fire.
• Failure to comply with these guidelines can result in damage and possibly even
the battery exploding.
• Never open the battery; it does not contain any serviceable parts.
• Avoid dirt and contact with electrically conductive materials or chemical
substances and cleaning agents.
• Use only the supplied mains adaptor to charge the battery.
After Sales Support
Telephone: 1300 884 987
Internet: www.medion.com.au
13 of 80
Page 17
• Make sure (via the Notebook display or acoustic signal) that the battery is fully
discharged before charging it again.
• Please note: There is a risk of explosion if batteries are incorrectly replaced.
Only replace the battery with the same battery type or an equivalent type
recommended by the manufacturer.
• Always charge the battery until the battery charging light goes out. Please also
observe the information in “Charging the battery” on page 31 to assess the
charge status of your battery.
• Ensure the Notebook is switched off before replacing the battery.
• Batteries are special waste. Dispose of old batteries properly Your customer
service agent is the correct point of contact for this.
3. Included with your Notebook
Please check that the contents are complete and notify us within 7 days of purchase
if any of the following components are missing:
• 14” Notebook
• 4-cell Li-Ion Battery
• AC Adapter with Power Cord (Model: Delta ADP-65JH)
• Windows® 8 Recovery DVD
• Medion Application and Support DVD
• Instruction Manual
• Warranty Certificate
• Warranty Sticker
DANGER!
Keep packaging material such as plastic film away from children.
There is a risk of suffocation if used improperly.
After Sales Support
14 of 80
Telephone: 1300 884 987
Internet: www.medion.com.au
Page 18
4. Views
4.1. Open Notebook
1 2
9
3
4
5
6
8
1) Webcam
2) Webcam LED
3) Microphone
4) LCD Display
5) Stereo Speaker
6) Keyboard
7) Touchpad
8) Device Indicators
9) Power ON/OFF
After Sales Support
Telephone: 1300 884 987
Internet: www.medion.com.au
7
15 of 80
Page 19
4.2. Front View
10
10) Multimedia Card Reader
4.3. Left Side
11 12
13
14
15
11) Kensington® Lock
12) LAN Port (RJ-45)
13) External monitor port VGA
14) HDMI Connector
15) USB 3.0 Port with charging function for mobile phones
ATTENTION!
The charging function (“Symbols and Key words used in these Instructions“
is available in sleep mode and when the Notebook is switched off providing
it is activated beforehand in the BIOS.
After Sales Support
16 of 80
Telephone: 1300 884 987
Internet: www.medion.com.au
Page 20
4.4. Right Side
16
17
18 19 20
16) Audio Out* / Digital Audio Out (S/P-DIF, optical)
17) Microphone*
18) USB 2.0 Port
19) Optical Drive
20) Power Socket
*Ports with dual function. Configuration is set with the included software
After Sales Support
Telephone: 1300 884 987
Internet: www.medion.com.au
17 of 80
Page 21
4.5. Operating and Status LEDs
The system displays power supply status and operating modes via LEDs. The
operating lights also light up during Notebook activity.
1) Battery LED
This LED lights when the battery is charging.
2) Access Indicator
This LED lights or flashes when the Notebook is accessing the hard disk or
the optical drive.
3) WLAN / Bluetooth LED
This LED lights when the WLAN /Bluetooth function is activated.
The following combinations are possible:
Bluetooth on / WLAN on
Bluetooth off / WLAN on
Bluetooth on / WLAN off
Bluetooth off / WLAN off LED off
4) Capital Lock
This LED lights when CAPS-Lock has been activated. This sets the keyboard to
capital letters.
LED lights
After Sales Support
18 of 80
Telephone: 1300 884 987
Internet: www.medion.com.au
Page 22
5. First Use
To operate your Notebook safety and ensure a long service life, you should read the
“Operational safety” chapter at the beginning of this manual. All operating software
is already fully preinstalled on the Notebook so there is no need for you to install
any more drivers and you can get started right away.
Before starting, insert the battery by placing it into the compartment until it
clicks into place. Be sure to fasten the battery compartment to prevent the
battery falling out.
Connect the supplied mains adapter to the Notebook (11). Next, connect the
power cable to the adapter and then plug it into a mains socket.
Open up the display to the desired position using your thumb and forefinger.
The display should not be folded back by more than 120°. Always hold the
display firmly by the middle when folding it back, adjusting the position and
closing it. Failure to do so may damage the display. Never use force to open the
display.
PLEASE NOTE!
When first operating your Notebook please ensure that the battery is
inserted and the mains adapter is connected. This is required for Windows®
8 to correctly work out the Windows® 8 performance index.
Switch the Notebook on by pressing the on/off switch (9). The Notebook will
now start and run through various steps.
PLEASE NOTE!
There should be no bootable disk (e.g. the recovery disc) in the optical drive
as this will prevent the operating system from being loaded from the hard
drive.
The operating system will be loaded from the hard drive. The loading process takes
a little longer during the initial setup. Once all the necessary data has been entered,
the operating system will be set up. The operating system is fully loaded once the
Windows® 8 start-up screen appears.
PLEASE NOTE!
The initial installation may take a few minutes. Do not unplug the Notebook
from the mains or switch it off during the initial installation. This may
adversely affect the installation. Do not switch off the Notebook until after
the installation has been completed successfully and the startup screen
appears.
After Sales Support
Telephone: 1300 884 987
Internet: www.medion.com.au
19 of 80
Page 23
6. Power Supply
6.1. On/Off Switch
Open the Notebook and hold the on/off switch down briefly to switch the
Notebook on or off.
The operating light indicates the current operating mode. Regardless of the
operating system, the Notebook will switch off if the switch is held down for longer
than 4 seconds continuously.
ATTENTION!
Do not switch your Notebook off while the hard drive or optical drive is
being accessed. Otherwise data may be lost. To protect the hard drive, you
should always wait for 5 seconds after switching off the Notebook before
switching it back on again.
6.2. Mains Power
Your Notebook comes with a universal mains adapter for alternating current which
automatically adapts to the available power source. The following values are
supported: AC 100–240 V~/50–60Hz. Observe the safety information concerning
the power supply on pages 12 ff.
The adapter is connected to an AC outlet via a mains cable. The mains adapter DC
cable is connected to the left side of the Notebook (11).
The adapter supplies the Notebook with power and also charges the battery. The
operating lights on the Notebook provide information about the operating mode.
Your battery will also be charged while you work on your Notebook with the mains
adapter connected. The mains adapter also consumes power when the Notebook
is not connected to it. You should therefore always remove the mains adapter plug
from the socket when it is not connected to the Notebook.
ATTENTION!
Use only the mains adapter and power cable supplied.
After Sales Support
20 of 80
Telephone: 1300 884 987
Internet: www.medion.com.au
Page 24
6.2.1. Starting the Notebook
Open up the display as described above and press the on/off switch.
Follow the instructions on the screen. Step by step instructions will guide you
through the process to be followed.
The welcome procedure takes you through several screens and dialogues.
Select your desired language and then the corresponding country settings.
Licence Agreement
Please read through the licence agreement carefully. It provides important legal
information about the use of your software product. To view the text in full, you
must slide the scroll bar downwards using the mouse until you reach the end of
the document. You accept the licence agreement by checking the I accept the
agreement radio button. Only this entitles you to use the product in accordance
with the terms and conditions.
After entering a computer name you can connect your Notebook to the Internet
immediately on the “Wireless” page (if you already have an appropriate Internet
connection set up).
If you choose to skip this point, you can connect to the Internet later via the
®
Windows
8 interface.
If you have already set up an Internet connection, you can now log in to your
Notebook using a Microsoft account.
The Microsoft Store allows you to purchase new apps or update previously installed
apps.
If you log in on a local account, you can set up a Microsoft account later at any time.
The following animated windows simply contain information about using the new
Windows® 8 operating system.
No entries of any kind may be made during the animation.
The Windows® 8 interface appears after the login process.
PLEASE NOTE!
In the first few days following the initial installation, Windows® 8 may
update and configure data (e.g. with new updates) which can result in
delays in the Notebook shutting down and starting up. For this reason, do
not switch the Notebook off prematurely. This may adversely affect the
installation.
After Sales Support
Telephone: 1300 884 987
Internet: www.medion.com.au
21 of 80
Page 25
6.3. Battery Mode
PLEASE NOTE!
Please charge and discharge the new battery completely two or three times
consecutively to ensure that it reaches its optimum performance! Batteries
store electrical energy in their cells and then release it again as required.
The service life and performance of your battery depends on careful handling.
The battery should always be completely discharged before charging and then fully
charged again to optimise the service life and performance.
Please also take note of the safety instructions on “Safety Instructions“.
6.3.1. Inserting the Battery
Insert the battery by sliding it into the compartment until it clicks into place. Be
sure to fasten the battery compartment to prevent the battery falling out.
After Sales Support
22 of 80
Telephone: 1300 884 987
Internet: www.medion.com.au
Page 26
6.3.2. Removing the Battery
To remove the battery pack, slide the battery lock and to the ‘lock open’ position
and remove the battery pack from the compartment.
ATTENTION!
Do not remove the battery while the Notebook is switched on or data may
be lost.
Take care when storing the battery and when using the Notebook that the
contacts on the battery and the Notebook are not soiled or damaged. This
could cause malfunctions.
6.3.3. Charging the Battery
The battery is charged using the mains adapter. When the mains adapter is
connected and switched on, the battery charges automatically regardless of
whether or not the Notebook is switched on or not. A complete charge takes a few
hours with the Notebook switched off. With the Notebook switched on, the
charging process takes significantly longer.
PLEASE NOTE!
The charging process is interrupted if the battery voltage or temperature
gets too high.
After Sales Support
Telephone: 1300 884 987
Internet: www.medion.com.au
23 of 80
Page 27
6.3.4. Discharging the Battery
Operate the Notebook on battery power until it turns itself off due to low battery
charge.
PLEASE NOTE!
Be sure to save your open files promptly to prevent any data loss.
6.3.5. Battery Performance
The actual operating time varies depending on the configuration of the powersaving functions. You can configure these to suit your requirements in the
Control Panel under System and Security, Power Options. Note: your Notebook
consumes more power when running certain applications, e.g. when playing a DVD.
6.3.6. Checking the Battery Charge
To check the current battery charge status, move the cursor over the power icon in
the task bar.
In battery mode, the icon is displayed as a battery.
You can obtain more information about settings by double clicking the icon.
PLEASE NOTE!
If you ignore the low battery warning, your Notebook will shut down.
ATTENTION!
Never remove the battery while the Notebook is switched on or before the
Notebook has shut down completely as this can lead to data loss.
After Sales Support
24 of 80
Telephone: 1300 884 987
Internet: www.medion.com.au
Page 28
6.4. Power Management (Power Options)
Your Notebook offers automatic and customisable power-saving and energy
functions that can be used to optimise battery life and reduce the overall operating
costs.
6.4.1. Sleep
With this setting the content of your Notebook’s RAM is preserved while practically
all other components of your Notebook are disabled or their power consumption
reduced to a minimum. For example, if you flip the Notebook shut, it puts it into
sleep mode and it is automatically restarted upon opening.
PLEASE NOTE!
Changes can be made to the sleep settings at any time in the power options.
7. Display
7.1. Opening and Closing the Display
The special design of the display hinges keeps the display closed without the need
for an additional catch.
To open the Notebook, fold the display up to the desired position using your
thumb and forefinger.
ATTENTION!
Do not fold the display back by an angle of more than 120°. Always hold the
display firmly by the middle when folding it back, adjusting the position and
closing it. Failure to do so may damage the display. Never use force to open
the display.
Opening and closing the display can be assigned different functions in the power
options.
7.2. Screen Resolution
The integrated monitor can display up to 1366 x 768 pixels. If you change to a
display with different settings in the Windows® 8 Control Panel, Appearence and
Personalisation wizard, the display may not, in certain circumstances, fill the entire
screen area. Distortions can also occur, especially for fonts, when enlarging. You
can work with a higher resolution, however, if you connect an external monitor
with a higher resolution. The Windows® 8 Control Panel, Appearence and
Personalisation wizard allows you to adjust the display to the modes supported.
After Sales Support
Telephone: 1300 884 987
Internet: www.medion.com.au
25 of 80
Page 29
7.3. Appearance and Customisation
This program gives you the option of customising your desktop. This includes the
background image, the screensaver and other settings for your monitor and your
graphics card. The program can be started as follows:
• Right-click on the Windows desktop and left-click on Personalise
.
or
• Via Settings, Personalisation, Display by double clicking with the left mouse
button.
Move the mouse pointer into the top right or bottom corner of the display and
click Settings.
Then click Personalisation.
First select the Display option from the dialogue box.
The following settings options are available:
− Set resolution
− Set brightness
− Calibrate colour
− Change display settings
− Display on second monitor
− Customise ClearType text
After Sales Support
26 of 80
Telephone: 1300 884 987
Internet: www.medion.com.au
Page 30
7.4. Connecting an External Monitor
The Notebook has a VGA connection socket (13) as well as an HDMI port (14) for an
external monitor.
Shut down your Notebook correctly.
Plug the external monitor’s signal cable into the VGA socket on the Notebook
(13). Alternatively, you can use the digital HDMI connection (High Definition
Multimedia Interface) (14) to transmit picture and sound signals.
Connect the external monitor to the mains and switch it on.
Now switch your Notebook on.
Once the operating system has loaded, the external monitor will be detected. A
number of options are available. You can access these as follows:
Run the Desktop App.
Move the mouse pointer into the top right or bottom corner of the display and
click
Then click Personalisation.
In the dialogue box, first select the Display option and then Project to a second
screen.
Press the + P buttons at the same time to open this menu quicker.
Settings.
Under Project to a second screen choose from the following options:
− PC screen only
− Duplicate
− Extend
− Second screen only
After Sales Support
Telephone: 1300 884 987
Internet: www.medion.com.au
27 of 80
Page 31
7.4.1. Duplicate
This mode duplicates the Notebook display on the external monitor.
PLEASE NOTE!
In this mode the same screen resolution must be configured for both
devices.
7.4.2. Extend
In this mode, a blank desktop is displayed on the second (external) monitor.
Windows on the first screen can be moved onto the second screen and vice versa.
The screen resolution and colour quality can be configured individually for each of
the display devices under Settings, Personalisation, Display.
7.4.3. PC Screen Only
The desktop will only be shown on main monitor 1.
7.4.4. Second Screen Only
The desktop will only be shown on the second (external) monitor.
8. Data Input
8.1. The Keyboard
The double assignment of certain keys means that the range of functions available
to you is the same as on a conventional Windows keyboard. Some functions are
entered using the FN key (standard on most Notebooks).
After Sales Support
28 of 80
Telephone: 1300 884 987
Internet: www.medion.com.au
Page 32
8.1.1. Notebook-Specific Keyboard Shortcuts
Short
Cuts
Fn + F1
Fn + F4
Fn + F5
Fn + F6
Fn + F7
Fn + F8
Description
Sleep
To configure these keys to suit your requirements, please go to
Power Options
Smart Power
You will be able to select between two different Energy Saving
Modes with this key combination.
Darker
Reduces the brightness of the display.
Brighter
Increases the brightness of the display.
Background lighting
Turns off background lighting for the integrated display to save
power. The lighting is turned back on by pressing any key.
Display
Switches the screen display between LCD, external display and
duplicate display.
Fn + F9
Fn + F10
Fn + F11
Fn + F12
Fn +
Fn + Sc Lk
Touchpad
Switches the touchpad on and off.
Mute
Switches the sound on or off.
Quieter
Decreases the playback volume.
Louder
Increases the playback volume.
Flight mode
Opens the user interface for switching the WLAN and/or
Bluetooth function on or off.
Scroll
This key combination activates / deactivates the scroll function.
Many applications use this function to scroll the screen without
moving the cursor
After Sales Support
Telephone: 1300 884 987
Internet: www.medion.com.au
29 of 80
Page 33
9. The Touchpad
In normal mode, the cursor follows the direction specified by moving your fingers in
the corresponding direction on the touchpad.
ATTENTION!
Do not use pens or other objects as this can damage your touchpad.
The left and right mouse buttons are found in the lower section of the touchpad
and can be used in the same way as those on a conventional mouse.
You can also perform a click or a double click on the touchpad directly by tapping
the touchpad surface once or twice briefly.
In the Windows®8 control panel, under the Mouse item, you will find a number of
useful settings to simply your day to day tasks.
After Sales Support
30 of 80
Telephone: 1300 884 987
Internet: www.medion.com.au
Page 34
9.1.1. Two-Finger Touchpad Operation
Your touchpad supports two-finger operation which enables certain commands to
be executed in some applications.
You can perform the following commands using your touchpad:
Image Command Function
zoom out
Drag two fingers
together or apart
Place one finger in the
centre and trace a circle
with the second finger
Swipe from left to
right/from right to
left with two fingers
simultaneously
from an object/
zoom in on an object
Rotate an object anti-clockwise
Page forward/
page back
Swipe down or up
with two fingers
simultaneously
Swipe from top to
bottom on the touchpad
Swipe from the far right
across the touchpad
Swipe from the far left
across the touchpad
Scroll function This function is
used in most applications to scroll
up and down the screen without
having to move the cursor.
Opens the context menu on the
start screen and the top and
bottom tabs in Internet Explorer
Opens the menu bar
Scrolls through all open windows
After Sales Support
Telephone: 1300 884 987
Internet: www.medion.com.au
31 of 80
Page 35
10. The Hard Drive
The hard drive is your main memory medium and combines high storage capacity
with rapid data access. You Notebook is supplied with an OEM version1* of the
®
Microsoft Windows
performance features. We have configured your Notebook’s hard drive so that you
will be able to work with it optimally without having to install any additional drivers
yourself. The Windows®8 operating system requires part of the capacity to manage
the hard drive therefore the hard drive’s full capacity is not available. This explains
any differences between the BIOS display and the operating system display. The
Notebook’s operating system, other applications and security data are located on
the hard drive meaning that the full capacity is already reduced.
The first partition (C:\) contains the operating system, the applications and the
“Documents” folder for the configured user.
The second partition (D:\) is used for the data backup and also contains drivers
(D:\Drivers) and utilities (D:\Tools) for your Notebook.
ATTENTION!
The startup files for system restoration ““Symbols and Key words used in
these Instructions“ and the Windows® 8 installation files are located in nonrewritable partitions. These partitions cannot be deleted.
8 operating system which supports all of the Notebook’s
1*
Original equipment manufacturer/program versions purchased from the manufacturer which are usual-
ly sold in conjunction with end devices
After Sales Support
32 of 80
Telephone: 1300 884 987
Internet: www.medion.com.au
Page 36
10.1. Important Directories
We have listed the most important directories below and described their contents.
ATTENTION!
Do not delete or modify these directories or their content otherwise data
may be lost or system functionality may be impaired.
C:\
The C: drive root directory contains important files required for Windows® 8 startup.
On delivery these files are hidden for security reasons.
C:\Programs
As the name suggests, software programs install the files required for running the
application into this directory.
C:\Windows
The main Windows ®
8
directory. The operating system saves its files here.
D:\Drivers
You will find all the (preinstalled) drivers required for your Notebook in this folder.
D:\Tools
Here you will find the utility programs for your Notebook.
After Sales Support
Telephone: 1300 884 987
Internet: www.medion.com.au
33 of 80
Page 37
10.2. mSATA Hard Drive (optional)
Your Notebook is supplied with an mSATA hard drive installed.
This mSATA hard drive will speed up your entire system. It optimises access speed to
the standard hard drive.
This has the benefit of making your Notebook boot up and programs start more
quickly.
The Intel® Rapid Boot technology is also supported in mSATA hard drives bigger
than 32GB:
Put the Notebook into standby mode as usual.
After a predefined time in the BIOS, which you can change to suit your personal
preferences, the Notebook switches into hibernate mode automatically (Sleep
mode).
Switch the Notebook on as normal using the on/off switch and the boot
procedure is completed in just a few seconds
ATTENTION!
If you remove the mSATA hard drive, the Notebook is no longer able to
function properly.
PLEASE NOTE!
Installations and modifications to your device should only be carried out by
qualified specialists.
Make sure to use only replacement parts provided by the manufacturer. The
appliance may sustain damage if unsuitable replacement parts are used.
After Sales Support
34 of 80
Telephone: 1300 884 987
Internet: www.medion.com.au
Page 38
11. The Optical Drive
11.1. Inserting a disc
Unlike optical drives on a desktop PC, the Notebook uses a mount to hold the disc.
When inserting the disc ensure that it is pressed into the mount correctly and that
it clicks into position there.
PLEASE NOTE!
Do not stick protective film or other adhesive labels to the disc. To prevent
damage to your drive, do not use any deformed or damaged discs.
ATTENTION!
Do not use scratched, broken, dirty or poor quality discs. The high speeds
in the drive can cause these to break destroying your data and damaging
your device. Inspect discs carefully before inserting them. If damage or dirt
is visible, do not use the disc. Damage caused by faulty media is not covered
under warranty and repairs will be chargeable.
Incorrectly positioning the disc in the mount can cause it to be damaged
when closing the drive drawer.
With the device switched on, press the eject button on the optical drive to open
the drawer.
Carefully pull the drawer out fully.
Remove the disc from its case, where possible without touching the unprinted
side.
Insert the disc into the drawer with the label up and carefully press it down. The
disc now lies flat in the drawer and audibly clicks onto the disc mount.
Check that the disc can turn freely and then carefully slide the drawer back into
the optical drive until it clicks into place.
On delivery, your optical drive is assigned the drive letter “E”. You can easily
access the data on your discs using Windows Explorer (Computer). Run
Windows Explorer using the shortcut on the taskbar or by simultaneously
pressing the Windows key and the “E” key. When accessing DVD videos (or audio
and video files on conventional data CDs), the preinstalled media player is used
automatically.
If you wish to remove a disc, press the eject button.
ATTENTION!
Do not try to remove the disc from the drive while the Notebook is accessing
the optical drive.
After Sales Support
Telephone: 1300 884 987
Internet: www.medion.com.au
35 of 80
Page 39
11.1.1. Emergency Release of a Blocked Disc
In the event of the drawer no longer opening automatically, it can be opened
manually providing your device has an emergency eject hole.
®
Exit Windows
8 and switch off the Notebook.
Insert a long pointed object (e.g. straightened paperclip) into the emergency
release until you feel some resistance.
A slight push now opens the drawer.
Remove the disc and restart the Notebook.
11.2. Playing/Reading Discs
Your optical drive is capable of playing audio CDs, DVD films or data CDs/DVDs.
Once a disc has been loaded, a dialogue box opens containing various playback
options. Normally, there will be a number of different options available.
If the dialogue box does not open, there is always the option of accessing the
optical drive via Explorer.
11.3. Regional playback information for DVDs
Playback of DVD film titles includes decoding MPEG2 video, digital AC3 audio
data and decoding CSS-protected content. CSS (sometimes also referred to as
Copy Guard) is the name of a data protection program used by the film industry to
protect against illegal copying.
Among the many controls for CSS licensees, the most important of the playback
restrictions involve country specific content.
To make it easier to create geographically separate film releases, DVD titles are
coded for specific regions. Copyright laws required that each DVD film be limited to
a specific region (usually the region where it is sold).
DVD film versions can be published in multiple regions but CSS rules require that
each CSS decoder system may only be used for one region.
PLEASE NOTE!
The region setting can be changed up to five times via the viewing software
before the last setting becomes permanent. If you then wish to change the
region setting again, this must be carried out by the manufacturer. Any
shipping and configuration costs must be borne by the user.
After Sales Support
36 of 80
Telephone: 1300 884 987
Internet: www.medion.com.au
Page 40
11.4. Issues Relevant to the Burner
This section only concerns devices supplied with a CD-RW, a combination CD/DVD
read drive or a DVD-RW drive. First some information about blank discs
11.4.1. Blank CDs and DVDs
Normal CDs are pressed by a glass master and then sealed. With blank discs, digital
information is burned onto them using the drive’s laser. They are therefore more
sensitive then conventional discs.
Because of this, it is essential to avoid, particularly in the case of unused blanks:
• exposure to direct sunlight (UVA/UVB radiation)
• scratches and damage
• extreme temperatures
After Sales Support
Telephone: 1300 884 987
Internet: www.medion.com.au
37 of 80
Page 41
12. The Sound System
The Fn + 11 and Fn + 12 keyboard shortcut enables you to adjust the volume.
12.1. External Audio Connections
Your Notebook has an integrated stereo speaker so you can always reproduce
sound without additional devices. Using the external connections provides you
with an ideal opportunity to connect your Notebook to external devices.
WARNING!
Excessive volume when using headphones or earphones can damage
your hearing. Before pressing play, set the volume to the lowest
setting. Start playback and increase the volume to a comfortable
level. Changing the basic settings of the equaliser can also increase
the volume and thus cause permanent damage to your hearing.
Changing the drivers, software, equaliser, operating system, etc.,
can also lead to an increase in the volume and thus cause permanent
damage to your hearing.
Listening to a device at high volumes for an extended period via
headphones/earphones can damage your hearing.
Audio output/
digital
audio output
(S/PDIF)
(16)
Microphone socket
(17)
For sound output using an external
surround sound decoder via an optical
cable (available separately from
specialist retailers).
For sound playback via external stereo
devices such as (active) speakers or
headphones.
For recording via an external
microphone.
After Sales Support
38 of 80
Telephone: 1300 884 987
Internet: www.medion.com.au
Page 42
13. Network Operation
13.1. What is a Network?
We talk about a network when multiple computers are directly connected to one
another. This allows users to transfer information and data with one another and to
share their resources (printers and drives).
Here are a few concrete examples:
• In an office, messages are exchanged by email and appointments are managed
centrally.
• Users share one printer on the network and back up their data to a central
computer (server).
• Two or more computers are connected to one another to play network games or
exchange data.
13.1.1. Network Connection (RJ45)
Your Notebook comes with a GBit LAN connection.
Connect one end of a cable with a RJ45 connection (western jack) to your
Notebook’s network interface (12) and the other to a different computer or hub/
switch.
You can find more details about the network in the Windows® 8 help.
13.2. Wireless LAN (Wireless Network)
Wireless LAN is an optional feature. This function enables you to establish a network
connection to a corresponding remote station. Please read about the necessary
requirements.
The wireless LAN function is enabled and disabled via the Windows® 8 menu and is
activated by default.
Press the Fn + keyboard shortcut to open the menu.
ATTENTION!
Do not operate the WLAN function in locations (e.g.: hospitals, aeroplanes,
etc.) where there is sensitive equipment. Do not switch the device unless you
are sure it will cause no interference.
After Sales Support
Telephone: 1300 884 987
Internet: www.medion.com.au
39 of 80
Page 43
13.2.1. Requirements
A so called WLAN access point may be used as a remote station. A WLAN access
point is a radio transmitting device that communicates with your Notebook and
controls access to the connected network.
WLAN access points are frequently found in large offices, airports, train stations,
universities or Internet cafés. They provide access to particular services and
networks or to the Internet.
Access permissions are generally necessary and often result in usage charges.
Access points often have built-in DSL modems. These so called routers establish the
connection to the existing DSL Internet connection and the wireless LAN.
A connection can also be established to another end device with wireless LAN
functionality without an access point. Without a router, however, the network is
restricted to those devices directly connected to it.
2
The wireless network connection works in accordance with the IEEE 802.11n
standard and is compatible with the IEEE 802.11b/g standard.
If encryption is used for the transfer, the same procedure must be used for all
devices. Encryption is a procedure to protect the network from unauthorised
access.
The transfer speed can vary depending on the distance and the number of users
accessing the remote station.
2 To make use of the full performance, a WLAN router compatible with the 802.11n
standard is required.
After Sales Support
40 of 80
Telephone: 1300 884 987
Internet: www.medion.com.au
Page 44
14. Bluetooth
Bluetooth technology is used to wirelessly bridge short distances. Bluetooth devices
transfer data via radio so that computers, mobile phones, printers, keyboards, mice
and other devices can communicate with one another wirelessly. Bluetooth wireless
technology has numerous possible applications. A few of them are listed below:
• Creating a wireless Internet connection using a mobile phone.
• Transferring files between computers or between a computer and another
device.
• Printing using a Bluetooth printer.
• Using a Bluetooth keyboard and mouse.
• Connecting to a PAN (Personal Area Network).
• Synchronising a personal digital assistant (PDA) with a computer or other device
that uses Bluetooth.
The Bluetooth wireless technology data transfer speed can vary depending on
the device or environmental factors. Data can be transferred through walls, jacket
pockets and briefcases using a Bluetooth device. The transfer between Bluetooth
devices occurs at the high frequency of 2.4 Gigahertz (GHz). For Bluetooth high
speed data transfer, WLAN must be enabled and the partner station must also
support the high speed mode.
Press the Fn + keyboard shortcut to open the menu.
ATTENTION!
Do not operate the Bluetooth function in locations (e.g.: hospitals,
aeroplanes, etc.) where there is sensitive equipment. Do not switch the
device unless you are sure it will cause no interference.
14.1. Flight Mode
In flight mode, all wireless connections (e.g. WLAN, Bluetooth) are disabled. Flight
mode is disabled by default to ensure that all wireless connections are available.
Move the mouse pointer into the top right or bottom corner of the display and
click Settings.
Next, click Change PC settings.
Click Wireless.
Now enable or disable Flight mode here. Alternatively, use the Fn +
keyboard shortcut to open flight mode.
Once flight mode is enabled, a small aeroplane is displayed in the traditional
desktop task bar. You can also enable/disable flight mode by clicking this icon.
After Sales Support
Telephone: 1300 884 987
Internet: www.medion.com.au
41 of 80
Page 45
15. The Multi-Card Reader
Memory cards are media that are used, e.g. in the field of digital photography, and
are gradually replacing the diskette. The shape and capacity of a memory card can
vary depending on the manufacturer.
Your Notebook supports the following formats:
• MMC (MultiMediaCard)
• SD (Secure Digital), SDHC, SDXC
When inserting the memory cards, ensure that the contacts are pointing in the right
direction, as specified in the list below. Inserting a card incorrectly may damage the
card reader and/or the card.
Card type Connection contacts
SD (Secure Digital) pointing downwards
MMC (MultiMediaCard) pointing downwards
15.1. Inserting a Memory Card
PLEASE NOTE!
The memory cards can only be inserted in one direction. Please observe the
instructions in the section above.
Slide the card in as far as it will go.
15.2. Removing Memory Cards
To remove SD/MMC cards or memory sticks, first push these into the socket to
release the safety catch.
Now pull the card out of the slot and store it properly.
After Sales Support
42 of 80
Telephone: 1300 884 987
Internet: www.medion.com.au
Page 46
16. The Webcam
The integrated webcam enables the use of various communication services.
17. The Universal Serial Bus Port
The universal serial bus (USB 1.1 and USB 2.0) is a standard for connecting input
devices, scanners and other peripherals. Up to 127 devices can be connected to the
USB ports via a single cable.
The USB 3.0 ports are fully backwards compatible with USB 2.0 and 1.1.
Your Notebook has 1 USB 3.0 connection socket with charging function for mobile
phones (15) and 2 USB 2.0 connection sockets (18).
PLEASE NOTE!
Where possible, always connect your USB devices to the same port that they
were originally installed on. Otherwise they will be assigned a new ID and
the drivers will need to be reinstalled.
After Sales Support
Telephone: 1300 884 987
Internet: www.medion.com.au
43 of 80
Page 47
17.1. Charging function for Compatible Mobile Phones
You can use the USB 3.0 port on the left side of the Notebook (15) to charge a
compatible mobile phone (5 volts max. 1.5A)
The charging function is available in sleep mode and when the Notebook is
switched off.
This function is disabled by default and can be enabled in the BIOS under the
Advanced, USB3 Charger option.
Restart your Notebook and hold down the F2 key during the boot process until
the BIOS menu opens.
or
Move the mouse pointer into the top right or bottom corner of the display and
click
Then click Power.
Now hold down the Shift key and click on Restart.
Now open the Troubleshoot item and then open the Advanced options.
Open the UEFI Firmware menu and then click Restart.
Settings.
ATTENTION!
To save the Notebook’s battery we recommend only using the charge
function in mains power mode.
Disconnect external data media from this socket when you are not using the
Notebook.
The charging function is not available with less than 20% battery power.
After Sales Support
44 of 80
Telephone: 1300 884 987
Internet: www.medion.com.au
Page 48
18. Securing your Notebook
Your new Notebook has software and hardware solutions for preventing
unauthorised access.
18.1. Power-on Password
You can protect your Notebook against unauthorised use with a power-on
password. On switching on the Notebook, a password prompt will appear on the
screen. The password is set up in the BIOS .
ATTENTION!
Keep your password in a safe place. If you forget your password, you have
no way of deleting it. If this happens, contact your service centre.
You can also use the Windows® 8 security options to protect your data against
unauthorised access.
18.2. Kensington Security Lock
you can use a so called Kensington security lock to protect your Notebook against
theft. This security lock (complete with cable) is usually available as an accessory in
specialist retailers.
To attach the security lock, wind the cable around a stationery object, e.g. a table
leg. Plug the lock into the Kensington device and turn the key to lock it.
Keep the key in a safe place.
After Sales Support
Telephone: 1300 884 987
Internet: www.medion.com.au
45 of 80
Page 49
19. Software
This section deals with the subject of software. We distinguish here between the
operating system, the software (the applications), the Windows activation and
the BIOS.
19.1. Getting to know Windows® 8
Windows® 8, the new operating system from Microsoft, contains a series of
innovative functions and new technologies that your Notebook uses to work
quickly and reliably. At the same time, it is also designed to be easy to use.
19.2. Windows Activation
To protect against software piracy, Microsoft has introduced product activation. The
Windows® 8 version installed on your Notebook and supplied with the Notebook
must be activated to enable you to use of all Windows® 8 functions.
To do this, you require simply an Internet connection. The activation process is fully
automatic; no personal data will be transmitted.
If no Internet connection is available, select telephone activation as follows:
Move the mouse pointer into the top right or bottom corner of the display and
click Settings.
Next, click Change PC settings.
Select the Activate Windows item.
Now click cevkxcvg"d{"rjqpg.
Click Next after choosing your country.
Call one of the specified hotlines on the telephone and read out the column of
figures displayed when prompted to do so.
You will then be given a confirmation ID over the telephone.
Enter this in the empty field and click Cevkxcvg.
PLEASE NOTE!
If you have not activated Windows® 8, not all functions will be available to
you under PC settings. A watermark will also continue to be displayed at the
bottom right on the traditional desktop.
After Sales Support
46 of 80
Telephone: 1300 884 987
Internet: www.medion.com.au
Page 50
19.3. Windows® 8 – What’s New
Microsoft Account
A Microsoft account is an email address and password for logging in to Windows®
8. You can use any email address. We recommend using the address you use to
communicate with friends and log into your favourite web sites, however.
The Microsoft account also allows you to purchase or download apps from the Store
and install them on up to five devices.
Once you have logged on to your Notebook using a Microsoft account, you also
have access to the various services and programs provided by Microsoft.
• The contact information and status updates for your friends from services such
as Hotmail, Facebook, Twitter and LinkedIn will be updated automatically as
soon as you run these services using your Microsoft account.
• You can also access and share your photos, documents and other files via
SkyDrive, Facebook and Flickr.
• Your personal settings, including designs, language settings, Internet favourites
®
and apps will be synchronised with each PC running Windows
to.
8 that you log on
• You can obtain Apps from the Windows® 8 Store. You can use these on any PC
running Windows® 8 that you log on to.
If you wish to create a Microsoft account in Windows
®
8, proceed as follows:
Move the mouse pointer into the top right or bottom corner of the screen and
click
Settings.
Click Change PC settings. > Users > Switch to a Microsoft
account.
After Sales Support
Telephone: 1300 884 987
Internet: www.medion.com.au
47 of 80
Page 51
Taskbar (Desktop Mode)
You can start programs from the taskbar at the bottom of the screen and switch
between programs already running. In Windows® 8 you can place any program
onto the taskbar, so that you can always open it with a single click. You can also
rearrange the icons on the taskbar by simply clicking on them and dragging them
to the desired position. Move the mouse pointer over the icons and thumbnails of
each file or each open window and that program will be displayed. If you move the
mouse pointer over the thumbnail, a full screen preview of the window in question
appears. When you move the mouse pointer away from the thumbnail again, the
full screen preview closes.
Jump Lists
Jump lists offer a practical way of calling up recently opened files. To display the
recently used files, simply right-click on the application icon in the taskbar. Thus if
you right-click on the Word icon, the recently used Word documents are displayed.
You can also easily place other files you wish to have easily to hand in the jump list
so that they are always displayed. This allows you to access documents that you use
frequently in just a few mouse clicks.
The jump lists for certain programs such as Windows
populated in advance with frequently used commands. Thus, for example, you
will see options to play all music or to reopen the last playlist in the jump list for
Windows® 8 Media Player.
®
8 Media Player can be
The frequently visited and last visited websites are displayed in the jump list for
Internet Explorer. This therefore allows you to quickly access commands for certain
programs that could previously only be called up from the program itself, such as
the command to compose a new email message.
Improved Desktop
Windows® 8 simplifies working with windows on the desktop. You therefore have
more intuitive options for opening and closing, changing sizes and rearranging.
Windows
(snaps) makes it easier to compare two open windows, for example. You do not
need to manually adjust the size of the opened windows to make a comparison.
Simply drag the window to one of the screen margins using the mouse and it will fill
half of the screen.
Click the window’s title bar, “shake” it and all other opened windows are displayed
as icons on the task bar. “Shake” the window once more and the other windows are
displayed again.
®
8 makes completing everyday tasks even simpler. The locking function
After Sales Support
48 of 80
Telephone: 1300 884 987
Internet: www.medion.com.au
Page 52
Improved Device Management
Windows® 8 allows you to connect, manage and use all devices via the central
“Devices” function.
All devices are shown in a central location.
With the new “Device Stage” technology, however, Windows® 8 goes one step
further with device management. Device Stage helps you to use all compatible
devices that are connected to the computer. Thanks to Device Stage you can now
display the device status and perform frequently used commands within a single
window. Here you will even find images of the devices so you can easily see which
devices are connected. The device manufacturers can even adjust Device Stage. For
example, if your camera manufacturer releases an updated version of Device Stage,
you can see details such as the number of photos on the camera and get links to
useful information when you connect the camera to your Notebook.
HomeGroup
With home network groups, a Windows® 8 function, connecting home computers
becomes child’s play. A home network group is set up automatically when you
connect the first PC running Windows® 8 to the home network. Adding additional
PC’s running Windows® 8 to the home network group can be done very quickly.
You can specify precisely what should be shared on each PC with all other PCs in
the home network group. Sharing files on the various home PCs – and on many
other devices – is then as easy as if all the data were located on a single hard drive.
Thus, you can save digital photos on the computer in the study and then access
them easily on a Notebook in any other room. Similarly, the printer in the study is
automatically shared among all PCs in the house once they are part of the home
network group.
19.4. Overview
The greatest innovation with Windows® 8 is the Start screen.
This key element replaces the Start menu in Windows® 8.
Here you can run all the main programs and services.
As with previous versions, operation is by inputting commands using the mouse or
keyboard.
The Start screen can be opened at any time using the (Win) key. This key
also allows you to switch back and forth between the Start screen and an active
application. To switch to an application other than the last one opened, press the
Win+Tab keyboard shortcut.
A central feature of the Start screen are the tiles which each represent an
application or function. They are shown in blocks and you can define the number of
blocks and their columns yourself.
Drag & drop the tiles to the desired position using the mouse.
After Sales Support
Telephone: 1300 884 987
Internet: www.medion.com.au
49 of 80
Page 53
19.5. Logging in to Windows
To be able to work with Windows® 8, you must set up a Windows® 8 user account.
Move the mouse pointer into the top right or bottom corner of the display,
move the mouse down and click
Next, select Change PC settings.
Open the User category.
Select Add a user, to set up additional user accounts.
Windows® 8 allows you to log in using 3 different login procedures. Windows® 8
gives you the choice of standard login by password, a PIN or an image code. To set
up a PIN or image code, you must first have set up a password for Windows ® 8.
19.5.1. Setting up a Password for Windows
Move the mouse pointer into the top right or bottom corner of the display and
click Settings.
Next, click Change PC settings.
Select the User item.
Settings.
Click Change your Password
and follow the instructions.
19.5.2. Setting a PIN for Windows
Move the mouse pointer into the top right or bottom corner of the display and
click Settings.
Next, click Change PC settings.
Select the User item.
Click Create a PIN and follow the instructions.
19.5.3. Setting Up an ImageCode for Windows
Move the mouse pointer into the top right or bottom corner of the display and
click Settings.
Next, click Change PC settings.
Select the User item.
Click Create a Picture password and follow the instructions.
PLEASE NOTE!
The image code login has been specially designed for touch screen devices.
In devices without a touch screen, use the mouse instead of finger
movements or gestures.
PLEASE NOTE!
To be able to use all Microsoft services you need to log in using a Microsoft
account.
After Sales Support
50 of 80
Telephone: 1300 884 987
Internet: www.medion.com.au
Page 54
19.6. Linking a User Account to a LiveID
You can link your user account to a LiveID. This enables you to log in to any
computer or mobile device connected to the Internet using your LiveID.
Move the mouse pointer into the top right or bottom corner of the display,
move the mouse down and click
Next, select Change PC settings.
Open the User category.
Select Switch to a Microsoft account.
Now enter your Windows Live ID email address.
If you have not yet created a Windows Live ID account or added an email address
to your Windows Live ID account, you can create and edit your Windows Live ID
account at http://www.windowslive.com/.
Follow the instructions on the screen to complete the link.
Settings.
After Sales Support
Telephone: 1300 884 987
Internet: www.medion.com.au
51 of 80
Page 55
19.7. Windows® 8 Start Screen
Once the operating system is running, you will see the new Windows® 8 Start
screen.
Information such as the following may be displayed here, for example:
Windows® 8
Windows® 8 apps are executable programs.
App
The “Desktop” tile opens the traditional
Windows display.
The Internet Explorer tile launches Internet
Explorer
PLEASE NOTE!
Apps are applications that are displayed on a desktop with a program
thumbnail. The app thumbnails are bigger than the standard tiles.
(image similar)
After Sales Support
52 of 80
Telephone: 1300 884 987
Internet: www.medion.com.au
Page 56
19.8. Windows® 8 Desktop
This image shows a symbolic representation of additional programs.
Information such as the following may be displayed here, for example:
(image similar)
Classic
desktop
apps
Desktop apps are applications that are displayed on a
desktop with a program thumbnail. The app thumbnails
are bigger than the standard tiles.
The classic “Power Recovery” desktop app
launches the system recovery program.
The classic “Microsoft Office” desktop app launches the
Microsoft Office program.
Windows® 8 apps from third-party suppliers are displayed as follows.
Example:
Windows® 8
apps from
These Windows® 8 apps are executable
programs from third-party suppliers.
third-party
suppliers
This Windows® 8 app launches the “PowerDVD”
program.
This Windows® 8 app launches the “YouCam”
program.
After Sales Support
Telephone: 1300 884 987
Internet: www.medion.com.au
53 of 80
Page 57
19.8.1. Working with Windows® 8 and Cassic Apps
Menu Instructions
Opening an app Click the desired app with the left mouse
button.
Closing an app PLEASE NOTE!
Not all apps need to be closed!
Windows® 8 closes unused apps
automatically.
Press the Alt+F4 keyboard shortcut.
Click on the top edge of the running app and
drag the app down to the edge of the display.
Displaying all apps Right-click on the Start screen.
Click All Apps in the bottom right-hand
corner of the display.
Linking apps
to the Start screen
Right-click on the Start screen.
Click All Apps in the bottom right hand
corner of the display.
Right-click on the desired app to highlight it.
Click Pin to Start in the bottom left-hand
corner of the display.
Linking apps to the taskbar Right-click on the Start screen.
Click All Apps in the bottom right-hand
corner of the display.
Right-click on the desired app to highlight it.
Click Pin to Taskbar in the bottom left-hand
corner of the display.
Installing an app Run the Shop app.
Search for the desired app and
click Install. The app will now be
downloaded and installed in the background.
After Sales Support
54 of 80
Telephone: 1300 884 987
Internet: www.medion.com.au
Page 58
Uninstalling an app Right-click on the Start screen.
Click All Apps in the bottom right hand
corner of the display.
Right-click the desired app.
Click Deinstallieren at the bottom edge of the
display.
PLEASE NOTE!
Not all apps can be uninstalled. If the
Deinstallieren option is not displayed,
this app can not be uninstalled.
Running apps as administrator
(Only possible with desktop
apps)
Running an app in a new
window
(Only possible with desktop
Right-click the desired app.
Now click Run as administrator on the
bottom edge of the display.
Right-click the desired app.
Click Open new window
at the bottom edge
of the display.
apps)
Searching for apps Move the mouse pointer into the top right-
hand corner of the display, move the mouse
down and click
Search.
Enter the name of the app.
Arranging apps Click and hold the left mouse button down
on the desired app and drag it to the desired
position.
Selecting multiple
Right-click the desired apps.
apps
After Sales Support
Telephone: 1300 884 987
Internet: www.medion.com.au
55 of 80
Page 59
19.9. Using the Search Function
Use the search function to find individual tasks, settings or apps quickly.
Move the mouse pointer into the top right or bottom corner of the display and
click Search.
Enter the name of the app or file and select an entry from the results list on the
left-hand side of the display.
The search results are arranged by
Crru, Ugvvkpiu and Hkngu. Choose the category
(Crru, Ugvvkpiu or Hkngu) in which the desired file is located.
20. Control Panel
The Control Panel allows you to customise the Start interface.
PLEASE NOTE!
Windows® 8 must be activated for changes to be made.
Move the mouse pointer into the top right or bottom corner of the
display and click Settings.
Next, click Change PC settings.
Menu Instructions
Windows
aktivieren
Customise Set the background image for the
Activate Windows® 8 by telephone or over the Internet.
lock screen and the Start screen here.
Select a profile image here.
User Create and update user accounts here.
Set or modify the PIN or image code.
Notifications Set the various program instructions to On or Off here.
Search Define the settings for the
search function here.
Define the app the search function should work with
here.
Sharing Define the settings for the
share function here.
Define the apps to be shared
here.
After Sales Support
56 of 80
Telephone: 1300 884 987
Internet: www.medion.com.au
Page 60
General Configure the general settings for time zone, spell
checking, language and memory here.
Reinstall the operating system without losing personal
user data or key basic settings.
Restore your Notebook to its factory settings.
Perform a reboot with a CD inserted.
Data protection Configure the security settings for apps, accounts and
®
Windows
8 here.
Devices Install additional external connected devices here, e.g.
joystick or USB speaker.
Enable or disable Download over metered
connections. This function prevents drivers for newly
added devices being searched for and downloaded via
the Internet.
Wireless Enable or disable flight mode here.
Enable or disable the integrated WLAN function here.
Simplified
operation
Synchronise
settings
Customise the contrast, mouse pointer and tab bar to
your requirements here.
Configure synchronisation of your Notebook with the
connected network.
Configure here whether or not an online
synchronisation should also be performed with payable
networks.
Home network
group
Here you will see the home network group and the apps
and files shared within it.
Windows Update Allow Windows
necessary Windows® 8 updates.
®
8 to search the Internet for any
After Sales Support
Telephone: 1300 884 987
Internet: www.medion.com.au
57 of 80
Page 61
20.1. Windows® 8 Power On/Off Functions
The new Windows® 8 allows you to restart your Notebook, put it into sleep mode or
shut it down.
Changes can be made to the sleep settings at any time in the power options.
In sleep mode the content of your Notebook’s RAM is preserved while practically
all other components of your Notebook are disabled or their power consumption
reduced to a minimum. For example, if you flip the Notebook shut, it puts it into
sleep mode and it is automatically restarted upon opening.
Restarting Move the mouse pointer into the top right or bottom corner
of the display, move the mouse down and click Settings.
Now click Power and select Restart.
Your Notebook will now restart.
Sleep Move the mouse pointer into the top right or bottom corner
of the display, move the mouse down and click Settings.
Now click Power and select Sleep .
Your Notebook will now switch to sleep mode.
Shut down Move the mouse pointer into the top right or bottom corner
of the display, move the mouse down and click Settings.
Now click Power and select Shut down.
After Sales Support
58 of 80
Telephone: 1300 884 987
Internet: www.medion.com.au
Page 62
20.2. Control Panel Settings
You can change Windows® 8 settings using the control panel. These settings control
virtually everything about how Windows® 8 appears and functions and enable you
®
to customise Windows
When the control panel is run for the first time, some of the most frequently used
control panel elements are displayed grouped together by category.
If you require additional information about a control panel element in the category
view, you must hold the mouse pointer over the icon or category name and read
the text shown there.
To run one of these elements, click on the associated icon or category name.
A list with executable tasks and a selection of individual control panel elements
opens for some of these elements.
To launch the control panel, proceed as follows:
Move the mouse pointer into the top right or bottom corner of the display and
click Search.
Enter Control Panel in the search field.
Click on Control Panel.
8 to meet your requirements.
After Sales Support
Telephone: 1300 884 987
Internet: www.medion.com.au
59 of 80
Page 63
20.3. Resetting the Notebook to its Factory Settings
In the event of problems with the installation or other software problems which
make it necessary to reinstall the software, Windows® 8 offers three options for
®
reinstalling Windows
First ensure that you have backed up all important data
and programs.
20.3.1. Running System Restore
After restarting, press the F11 key or start up the Notebook with the F11 key
held down to launch PowerRecover.
Click the PowerRecover Windows® 8 desktop app to run the program from the
Windows® 8 desktop.
You will be offered 3 possible options:
− Dwtp"Ftkxgtu"cpf"Vqqnu"vq"cp"Qrvkecn"fkue
Create a support disc
− Tghtguj"{qwt"RE"ykvjqwv"chhgevkpi"{qwt"hkngu
Update your Notebook without deleting your data.
8 on your Notebook.
or
− Tguvqtg
Choose between two recovery options:
● Restore to HDD – no backup of user data
All data on the Notebook will be permanently deleted.
The factory settings will be restored.
● Restore to HDD – with backed up user data
The factory settings will be restored and all user data under C:\USER will
be backed up.
PLEASE NOTE!
Always perform any type of recovery using mains power.
ATTENTION!
The recovery process takes a long time when you select the option to back
up user data. Only the data located in the folder C:\USER will be backed up.
All other data will be deleted. It is therefore important to perform regular
data backups to external data media. We do not accept any liability for
claims for compensation arising from the loss of data or any consequential
damages incurred.
Click Next and follow the on screen instructions to restore the factory settings.
After Sales Support
60 of 80
Telephone: 1300 884 987
Internet: www.medion.com.au
Page 64
20.4. BIOS Setup Program
BIOS setup (the basic hardware configuration of your system) offers you numerous
configuration options for operating your Notebook. For example, you can modify
the operating mode for interfaces, security features or power supply management.
The Notebook has already been configured by the manufacturer to ensure
optimum operation.
ATTENTION!
Please only change settings where strictly necessary and if you are familiar
with the configuration options.
20.4.1. Running the BIOS Setup
You can only run the configuration program upon system startup. If the Notebook
has already started up, switch it off and restart it. Press the F2 function key to run
the BIOS SETUP.
After Sales Support
Telephone: 1300 884 987
Internet: www.medion.com.au
61 of 80
Page 65
20.5. Kaspersky Internet Security
Kaspersky Internet Security is a comprehensive tool to protect your data. The use
of it not only offers you full protection against viruses, but also against spam and
attacks against your network. Further components of the software will protect your
computer against threats and phishing attacks unknown up to now and allows the
access to the Internet to be restricted sensibly. Full protection will cover all areas of
data transfers and exchanges.
Kaspersky Internet Security is already installed, so that additional installation
will not be necessary. If you nevertheless have to carry out an installation (e.g.
after system restoration), you will find the software package on the Application &
Support disc supplied with the machine.
Kaspersky Internet Security consists of the following security components:
• File Anti-Virus
File Anti-Virus will protect the file system of the computer against infection.
The components will be started when the operating system is started. They
will be permanently located in the working memory of the computer and will
check all the files that are opened, saved or started on your computer and all
the connected hard drives. Kaspersky Internet Security will intercept any attack
on a file and will check the respective file for known viruses. A file will then only
be released for use if it is virus-free or has been successfully disinfected by the
program.
• Mail Anti-Virus
Mail Anti-Virus will check the incoming and outgoing emails on your computer.
An email will only be delivered to the respective recipient if it does not contain
any dangerous elements.
• Web Filter / Child Protection
The Web Filter will block visits to dangerous web pages and will create a safe
working environment during Internet surfing in this way. Child protection allows
access to Internet resources and programs to be restricted flexibly for different
users of the computer depending on age.
PLEASE NOTE!
Kaspersky Internet Security will be activated automatically if the Internet
connection is active. Manual activation will not be necessary. Kaspersky
Internet Security will be deactivated automatically after a test period.
We recommend the acquisition of a licence in good time, to ensure the
optimum protection of your computer, for this reason.
After Sales Support
62 of 80
Telephone: 1300 884 987
Internet: www.medion.com.au
Page 66
The Kaspersky Internet Security Package will be updated with the most up to date
virus information for a test period after the free registration. Read the activation
information about this on the internet at: http://www.Kaspersky.com.
PLEASE NOTE!
The operating system and anti-virus software are automatically updated
when the first online connection is made. These processes usually take a few
minutes, during which time the operating speed of the computer may be
affected although this is only noticeable on initial start-up.
20.6. Windows® 8 – Help and Support
Here you will find a comprehensive collection of instructions, help sections and
troubleshooting suggestions.
This help covers the entire spectrum of the Windows
It is recommended for both beginners and experts. The information is subdivided
into topics and can be printed out or bookmarked. Start as follows:
Move the mouse pointer into the top right or bottom corner of the display,
move the mouse down and click
Settings.
Now click on Help.
®
operating system.
Choose the topic you are interested in.
After Sales Support
Telephone: 1300 884 987
Internet: www.medion.com.au
63 of 80
Page 67
21. FAQ – Frequently Asked Questions
Do I need to install the discs supplied?
− No All programs are preinstalled. The discs are provided as backup copies
only.
Where can I find the necessary drivers for my Notebook?
− The drivers can be found in the second hard drive partition in the
Drivers and Tools folders.
What is
Windows® 8 activation?
− You will find a relevant section in these operating instructions containing
detailed information on this topic.
How do I activate Windows® 8?
− Windows®8 is activated automatically as soon as an Internet connection is
established.
How do I activate Windows® 8 without an Internet connection?
− Windows® 8 can also be activated over the telephone. Follow the instructions
in the section ““Windows Activation“to activate Windows® 8 by telephone.
When is restoring factory settings recommended?
− This method should only be selected as a last resort. Read about the
alternatives in the System recovery section.
How do I perform a data backup?
− Perform a backup or backup synchronisation of selected data onto external
media to familiarise yourself with the technology. A backup is of no use if
you are unable to recover the data or if the medium is faulty or is no longer
available.
Why do I need to reinstall my USB device even though I have already done it?
− If the device is not operated on the same USB port as the one it was installed
in, it automatically receives a new identifier. The operating system then treats
it like a new device and tries to reinstall it.
− Use the installed driver or connect the device to the port on which it was
originally installed.
After Sales Support
64 of 80
Telephone: 1300 884 987
Internet: www.medion.com.au
Page 68
22. Customer Service
22.1. What To Do In Case of Hardware Problems
Malfunctions can sometimes have quite trivial causes, but they may also be the
result of defective components. We have included a brief troubleshooting guide
below which may help to solve any problems.
If these tips don’t do the trick, then we’ll be more than pleased to help you out. Just
give us a call!
22.2. Find The Cause
Start by carefully checking all the cable connections. If the indicator lamps are not
on, ensure that the Notebook and all peripheral devices are connected to the power
supply.
• If you are in battery mode, connect the Notebook to the mains adapter and
check that the battery is charged.
• If you wish to operate the Notebook using the mains adapter, disconnect the
mains adapter from the socket and connect an electrical appliance such as a
lamp to the same socket to test it. If the lamp does not work either, seek the
advice of an electrician.
• Turn off the Notebook and check all cable connections. If the Notebook is
connected to peripheral devices, check all cable connections. Do not swap
around the cables for the various devices, even if they look alike. The pin
assignment within the cables may be different. Once you have ensured that the
device’s power supply is functioning and all connections are intact, then switch
the Notebook back on.
After Sales Support
Telephone: 1300 884 987
Internet: www.medion.com.au
65 of 80
Page 69
22.2.1. Faults and Possible Causes
The screen is black.
• This fault can have various causes:
− The operating light (on/off switch) does not light up and the Notebook is in
hibernation.
Solution:
Press the on/off switch.
− The sleep light is flashing. The Notebook is in sleep mode.
Solution:
Press the on/off switch.
− The background lighting has been disabled using the Fn+F7 keyboard
shortcut.
Solution:
Reactivate the background lighting by pressing any key.
The Notebook turns itself off during operation.
The battery may be flat. Plug the Notebook in using the mains adapter and
charge the battery.
The Notebook cannot be switched on.
If you are running the Notebook on batteries, check that they have been
inserted correctly and are fully charged.
Wrong time and date displayed.
Click the clock display in the taskbar. Select the
Datums- und Uhrzeiteinstellung ändern option and enter the correct values.
No data can be read by the optical drive.
Check whether the disc has been inserted correctly.
The WLAN/Bluetooth connections do not work.
Check that flight mode is disabled.
The touchpad is not working.
To activate the touchpad, press the Fn + F9 keyboard shortcut.
Apps (e.g. the weather app) cannot be displayed as live tiles.
Check the date, time zone and time.
After Sales Support
66 of 80
Telephone: 1300 884 987
Internet: www.medion.com.au
Page 70
22.3. Do You Need More Help?
You’ve checked through the suggestions in the previous section and you’re still
having problems with your device? Then call our hotline or contact us at www.
medion.de/service. We’ll be glad to help you.
Before contacting your technology centre, however, prepare the following
information:
• Have you made any upgrades or modifications to the initial configuration?
• What peripheral devices do you use?
• What messages, if any, appear?
• What software were you using when the problem occurred?
• What steps have you already taken to try and rectify the problem?
22.4. Driver Support
The system has been thoroughly and successfully tested with the installed drivers
in our test laboratory. It is normal in the computer sector, however, for the drivers
to need updating from time to time. This is because there may be compatibility
problems with other components (programs, devices) which have not yet been
tested. You can find current drivers on the Internet at the following address:
http://www.medion.com
Please use the service address for the country where the device was purchased.
After Sales Support
Telephone: 1300 884 987
Internet: www.medion.com.au
67 of 80
Page 71
22.5. Transport
Please note the following information if you wish to transport the Notebook:
• Switch the Notebook off. This ensures that the hard drive heads are
automatically moved to a safe area to avoid damage. Remove any inserted
DVDs/CDs.
• After transporting the Notebook, wait until the appliance has reached
room temperature before switching it on. Large changes in temperature or
fluctuations in humidity can cause moisture build-up within the Notebook due
to condensation. This can cause an electrical short circuit.
• Close the Notebook and check that the lid is firmly closed.
• Always use a Notebook carrying case to protect the Notebook from dirt,
moisture, vibrations and scratches.
• Always use the original cardboard packaging to ship your Notebook and obtain
advice on this from your carrier.
• Always charge your battery and any spare batteries fully before embarking on
longer trips and do not forget to take along your mains adapter.
• Find out about the power and communication options available in your
destination before travelling.
• Where necessary, purchase the required power or communication adapter (LAN
etc.) before departure.
• When shipping the Notebook, pack the battery separately in the cardboard
packaging.
• When going through the hand luggage check at the airport it is recommended
that you send the Notebook and all magnetic storage media (external hard
drives) through the x-ray facility (the device that scans your bags). Avoid the
magnetic sensor (the structure that you walk through) or the magnetic hand
scanner (the manual device used by security personnel) as this may destroy your
data, among other things.
•
After Sales Support
68 of 80
Telephone: 1300 884 987
Internet: www.medion.com.au
Page 72
22.6. Maintenance
ATTENTION!
None of the parts inside the Notebook housing require cleaning or
maintenance.
You can increase the lifespan of your Notebook with the following measures:
• Always unplug the device, disconnect all cables and remove the battery before
cleaning.
• Clean the Notebook with a damp, lint-free cloth.
• Do not use solvents, corrosive or aerosol-based detergents to clean the device.
• Do not use CD-ROM cleaning discs or similar products that clean the lens of the
laser to clean your optical drive.
• Dust or grease on the touchpad can affect its sensitivity. Remove the dust or
grease from the surface of the touch pad with a strip of adhesive tape.
• Over time, dust can collect inside the Notebook which then blocks the vents.
This can lead to an increase in the fan speed and, therefore, also increase
the operating volume of your Notebook. It can also lead to overheating and
malfunctions. Therefore, have the interior of the Notebook cleaned by your
service department or a specialist at regular intervals.
22.7. Care of the Display
• Close the Notebook when you are not working with it. Avoid scratching the
surface of the screen because it can be easily damaged.
• Make sure that no water droplets remain on the screen. Water can cause
permanent discolouration.
• Clean the screen with a soft, lint-free cloth.
• Do not place the screen in strong sunlight or near ultraviolet light.
• The Notebook and its packaging can be recycled.
PLEASE NOTE!
The surfaces of the device are covered in protective film to prevent
scratching during production and transport.
Remove the film once the device has been set up properly and before you
use it.
After Sales Support
Telephone: 1300 884 987
Internet: www.medion.com.au
69 of 80
Page 73
23. Upgrading/Modifying and Repair
• Upgrades and modifications to your Notebook should only be carried out by
qualified specialists. If you do not have the necessary qualifications, have the
work carried out by a qualified service technician. Please contact your customer
service department if you have technical problems with your Notebook.
• If a repair must be carried out, please contact only our authorised service
partners.
23.7.1. Notes for Service Technicians
• Only service technicians may open up the Notebook housing or upgrade or
modify your Notebook.
• Use only original replacement parts.
• Before opening the housing, disconnect all power and connecting cables and
remove the battery. If the Notebook is not disconnected from the power supply
before being opened, there is a risk that components could be damaged.
• Internal components of the Notebook may be damaged by electrostatic
discharge (ESD). Carry out repairs, as well as system enhancements or
modifications, at an ESD workplace. If such a workplace is not available, wear
an antistatic cuff or ensure you are touching an earthed, metallic object. We will
charge for any repairs to damage caused by incorrect handling.
23.7.2. Information on Laser Radiation
• The Notebook can contain laser equipment classified as laser class 1 to laser
class 3b. The equipment meets the requirements for laser class 1.
• By opening the housing of the optical drive, you will have access to laser
equipment classified up to laser class 3b.
The following should be observed when removing and/or opening this laser
equipment:
• The integrated optical drive contains no parts that require repair or
maintenance.
• Repairs to the optical drive should only be carried out by the manufacturer.
• Do not look directly into the laser beam, even when using optical instruments.
• Do not expose the laser beam. Avoid exposing your eyes or skin to the laser
beam – either directly or through scattered laser radiation.
After Sales Support
70 of 80
Telephone: 1300 884 987
Internet: www.medion.com.au
Page 74
24. Recycling and Disposal
Should you have any questions concerning the disposal please contact your dealer
or MEDION Customer Service.
Packaging
Your device has been packaged to protect it against transportation
damage. Packaging is raw material and can be re-used or added to the
recycling system.
Device
At the end of its life, the device should not be disposed of in household
rubbish. Enquire about the options for environmentally friendly and
appropriate disposal.
Batteries
Do not dispose of used or defective batteries in the household rubbish!
They should be taken to a collection point for used batteries.
After Sales Support
Telephone: 1300 884 987
Internet: www.medion.com.au
71 of 80
Page 75
25. European EN 9241-307 Class II Standard
For active matrix LCDs (TFT) with a resolution of 1366 x 768 pixels, each of which
consist of three sub-pixels (red, green, blue), there are a total of approx. 3.1 million
control transistors in use. Due to this very high number of transistors and the
associated extremely complex manufacturing processes used, occasionally one or
more pixels can fail or become incorrectly controlled.
In the past, there were a number of approaches for defining the permitted number
of pixel defects. However, these approaches were mostly very complicated and
varied from one manufacturer to the next. When handling warranty issues for all
of its display products, MEDION therefore adheres to the strict and transparent
requirements of the standard ISO 9241-307, Class II; which has been briefly
summarised below.
The EN 9241-307 standard defines, amongst other things, the generally applicable
guidelines relating to pixel defects. Pixel defects are categorised into four fault
classes and three defect types. Every individual pixel consists of three sub-pixels,
each of which is assigned a basic colour (red, green, blue).
Pixel structure
5 Pixel
5 Pixel
Sub-Pixel
Rows
Pixel
blue
green
red
After Sales Support
72 of 80
Telephone: 1300 884 987
Internet: www.medion.com.au
Page 76
Pixel defect types:
• Type 1:
permanently illuminated pixel (bright, white dot) even when not activated. A
white pixel occurs due to the illumination of all three sub-pixels.
• Type 2:
non-illuminated pixel (dark, black dot) even when activated.
• Type 3:
abnormal or faulty red, green or blue sub-pixel (e.g. permanently illuminated at
half brightness, one colour not illuminated, flashing or flickering but not type 1
or 2)
Supplement: Type 3 cluster (= failure of two or more sub-pixels within a 5 x 5 pixel
block). A cluster is a field of 5 x 5 pixels (15 x 5 sub-pixels).
EN 9241-307, error class II
Cluster
Cluster
Resolution Type 1 Type 2 Type 3
Type 1, type 2
Type 3
1024 x 768 2 2 4 0 2
1280 x 800 3 3 6 0 3
1280 x 854 3 3 6 0 3
1280 x 1024 3 3 7 0 3
1366 x 768 3 3 7 0 3
1400 x 1050 3 3 8 0 3
After Sales Support
Telephone: 1300 884 987
Internet: www.medion.com.au
73 of 80
Page 77
25.1. Energy Star
®
ENERGY STAR® is a joint program by the US American Environmental
Protection Agency and the U.S. Department of Energy which aims to
save costs and protect the environment through the provision of
efficient products and procedures.
MEDION® is delighted to be able to offer our customers products with an ENERGY
STAR®-compliant labelling.
®
The Medion
Akoya® S4216 (MD99081) has been designed and tested to meet the
requirements of the ENERGY STAR® 5.2 program for computers.
Using ENERGY STAR compliant products and your computer’s power-saving
functions will reduce your power consumption. Lower power consumption leads
to possible savings, a cleaner environment and a reduction in greenhouse gas
emissions.
You can find more information about ENERGY STAR at http://www.energystar.gov.
We would like to help make the efficient use of power a key component of your
everyday activities. To support these efforts, Medion has configured the following
power-saving functions which activate if your computer is inactive for a specific
period of time:
Battery operation Mains power
operation
Display shut-off 5 minutes 10 minutes
Standby-Modus
15 minutes 30 minutes
aktivieren
Festplatten
10 minutes 20 minutes
ausschalten
Ruhezustand
30 minutes 90 minutes
aktivieren
After Sales Support
74 of 80
Telephone: 1300 884 987
Internet: www.medion.com.au
Page 78
25.2. FCC Compliance Statement
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation.
This equipment generates, uses, and can radiate radio frequency energy and, if
not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined
by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which
the receiver is connected.
• Consult the dealer or an experienced technician for help.
Changes or modifications not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment. Shielded
interface cables, if any, must be used in order to comply with the emission limits
After Sales Support
Telephone: 1300 884 987
Internet: www.medion.com.au
75 of 80
Page 79
14“ Ultrabook™
S4216 (MD 99081)
Repair and Refurbished Goods
or Parts Notice
Unfortunately, from time to time, faulty products are manufactured which need to
be returned to the Supplier for repair.
Please be aware that if your product is capable of retaining user-generated data
(such as files stored on a computer hard drive, telephone numbers stored on a
mobile telephone, songs stored on a portable media player, games saved on a
games console or files stored on a USB memory stick) during the process of repair,
some or all of your stored data may be lost. We recommend you save this data
elsewhere prior to sending the product for repair.
You should also be aware that rather than repairing goods, we may replace them
with refurbished goods of the same type or use refurbished parts in the repair
process.
Please be assured though, refurbished parts or replacements are only used where
they meet ALDI’s stringent quality specifications.
If at any time you feel your repair is being handled unsatisfactorily, you may escalate
your complaint. Please telephone us on 1300 884 987 or write to us at:
MEDION Australia Pty Ltd
St. Leonards, NSW 2065
Australia
MEDION Help Desk 1300 884 987
(Operating Hours: Mon-Fri 8:30AM to 6:00PM EST)
Email: australia@medion.com
After Sales Support
76 of 80
Telephone: 1300 884 987
Internet: www.medion.com.au
Page 80
26. Index
B
Battery Mode .......................................................................................................................................22
Charging the Battery ....................................................................................................................23
Discharging the Battery .............................................................................................................. 24
Inserting the Battery ....................................................................................................................22
Removing the Battery ..................................................................................................................23
Battery Performance .........................................................................................................................24
BIOS .........................................................................................................................................................61
Blank CDs and DVDs ..........................................................................................................................37
Bluetooth ...............................................................................................................................................41
C
Cabling ...................................................................................................................................................12
Caring for the Display ....................................................................................................................... 68
Connecting an External Monitor ..................................................................................................27
Connections .........................................................................................................................................12
Control Panel................................................................................................................................. 56, 59
Customise .........................................................................................................................................56
Data protection ..............................................................................................................................57
Devices ..............................................................................................................................................57
General ..............................................................................................................................................57
Home network group .................................................................................................................. 57
Notifications ....................................................................................................................................56
Search ................................................................................................................................................56
Sharing ..............................................................................................................................................56
SimplifiedOperation .....................................................................................................................57
Synchronise settings .................................................................................................................... 57
User .....................................................................................................................................................56
WindowsActivate ...........................................................................................................................56
Windows Update ...........................................................................................................................57
Wireless .............................................................................................................................................57
Customer Service ...............................................................................................................................64
D
Data Backup .........................................................................................................................................10
Data Input .............................................................................................................................................28
Ultrabook-Specific Keyboard Shortcuts ................................................................................29
Declaration of Conformity .................................................................................................................7
Display ....................................................................................................................................................15
Driver Support ..................................................................................................................................... 66
E
After Sales Support
Telephone: 1300 884 987
Internet: www.medion.com.au
77 of 80
Page 81
Energy Star ............................................................................................................................................73
Ergonomics ...........................................................................................................................................11
European Standard ............................................................................................................................71
External Audio Connections ...........................................................................................................38
F
Factory Settings .................................................................................................................................. 60
FAQ .......................................................................................................................................................... 63
H
Help and Support ............................................................................................................................... 62
HomeGroup ..........................................................................................................................................49
I
Improved Desktop ............................................................................................................................. 48
Improved Device Management .................................................................................................... 49
J
Jump Lists .............................................................................................................................................48
K
Kensington Security Lock ................................................................................................................ 45
L
Logging in to Windows .................................................................................................................... 50
Setting a PIN for Windows .......................................................................................................... 50
Setting Up an Image Code for Windows ............................................................................... 50
Setting Up a Password for Windows .......................................................................................50
M
Maintenance ........................................................................................................................................68
Microphone Socket ...........................................................................................................................17
N
Network Operation ............................................................................................................................ 39
O
Operating Safety ....................................................................................................................................8
P
Power Supply .......................................................................................................................................12
R
Recycling and Disposal ....................................................................................................................70
Restarting .............................................................................................................................................. 58
S
Saving Energy ...................................................................................................................................... 58
Shut Down ............................................................................................................................................58
Sleep .......................................................................................................................................................58
Software .................................................................................................................................................45
Getting to know Windows® 8 .................................................................................................... 46
Windows® 8 – What’s New ..........................................................................................................47
After Sales Support
78 of 80
Telephone: 1300 884 987
Internet: www.medion.com.au
Page 82
Windows activation ...................................................................................................................... 46
T
Taskbar ................................................................................................................................................... 47
The Multi-Card Reader ......................................................................................................................42
Inserting a Memory Card ............................................................................................................42
MMC ...................................................................................................................................................42
Removing Memory Cards ........................................................................................................... 42
SD ........................................................................................................................................................42
The Optical Drive ................................................................................................................................ 35
Emergency Release of a Blocked Disc .................................................................................... 36
Inserting a Disc ............................................................................................................................... 35
Playing/Reading Discs .................................................................................................................36
Regional Playback Information for DVDs ..............................................................................36
The sound card ....................................................................................................................................38
The touchpad.......................................................................................................................................30
Two-Finger Touchpad Operation .............................................................................................31
The Webcam .........................................................................................................................................43
Transport ...............................................................................................................................................67
U
Upgrades/Modifications ..................................................................................................................69
Information on laser radiation .................................................................................................. 69
Notes for service technicians ....................................................................................................69
V
Views .......................................................................................................................................................15
W
Windows® 8 Desktop ......................................................................................................................... 52
Desktop apps .................................................................................................................................. 53
Windows® 8 Start Screen ................................................................................................................. 51
Windows® 8 app .............................................................................................................................52
Wireless LAN ......................................................................................................................................... 39
Flight Mode .....................................................................................................................................41
Requirements ..................................................................................................................................40
Working With Apps ............................................................................................................................ 54
After Sales Support
Telephone: 1300 884 987
Internet: www.medion.com.au
79 of 80
Page 83
After Sales Support
80 of 80
Telephone: 1300 884 987
Internet: www.medion.com.au
Page 84
MEDION Australia Pty Ltd
St Leonards, NSW 2065
Australia
Hotline: 1300 884 987
Opening hours: Mon - Fri 08:30AM to 06:00PM EST
Internet
www.medion.com.au
E-mail Support
australia@medion.com
11/12
MSN 4004 3137
Loading...
