The Mediatrix 3000 Series allow
enterprises to lower communications
costs over any IP link. They are multifunction devices combining VoIP IAD,
Gateway, IP Router, SIP aware
NAT/Firewall and QoS control in a secure
and powerful platform.
Mediatrix® 3000 Series
This platform, featuring analog FXS, ISDN
BRI, or T1/E1 PRI interfaces, provides an
ideal solution for enterprise voice
applications or for connecting to a service
provider’s broadband access.
The Mediatrix 3000 Series also allows
Carriers, Service Providers, and System
Integrators to initially deploy secure
systems and generate additional revenue
streams.
Key Benefits
Feature rich carrier grade product.
Analog FXS, ISDN BRI, or T1/E1 PRI interface
ports.
Deployable in SIP VoIP networks.
Up to 60 simultaneous calls.
User programmable call handling.
Networking features: complete VoIP-enabled IP
router.
Security features: NAPT/Firewall with proxybased SIP ALG, VPN, SNMPv3, SSH, HTTPS.
Hardware ready and capable to support SRTP
and SIP over TLS.
Proven voice algorithms implemented on
dedicated DSP engine for enhanced voice quality
on each interface card.
Fax over IP support, including T.38.
Multiple codec support.
Can support local VoIP network.
Remote management capabilities.
Product Overview
Designed specifically for enterprise applications,
the Mediatrix 3000 Series gateways make use of
existing broadband access equipment to connect
to any standards-based VoIP network.
The Mediatrix 3000 series gateways meet the
requirements of enterprises that want to connect
their Analog or ISDN equipment, such as PBXs,
through a FXS, BRI, or PRI interface to an IP
network or as a gateway to the PSTN.
The Mediatrix 3000 series is targeting:
Enterprises with branch offices and remote
offices, including SOHOs.
Enterprises seeking access to the benefits of
Voice over IP without discarding existing
legacy equipment.
Enterprises wishing to implement Voice over
IP through a gradual, transparent, and costeffective migration.
Multi-tenant / multi-dwelling units and
premises wishing to implement Voice over
IP while maintaining existing wiring and
handsets.
Enterprises looking to implement secure
RTP (SRTP) and Secure SIP (SIPS) in
2007.
The Mediatrix 3000 series platforms are available
with different packages including the Basic Digital
Gateway or the Secure Controller add-on.
SSaalleess DDeeppaarrttmmeenntt
AAmmeerriiccaass -- TTeell:: 11--887777--GGEETT--VVOOIIPP // ((887777)) 443388--88664477 FFaaxx:: ((881199)) 882299--55110000
EEuurrooppee,, MMiiddddllee EEaasstt,, AAffrriiccaa -- TTeell:: ++3399--0022--8844774422228811 FFaaxx:: ++3399--0022--8844774422221122
MMIIPP--GGEESS006600772277 33000000PPrroodduuccttBBrroocchhuurree
Applications
The Mediatrix 3000 VoIP gateways allow any office
to use an existing IP network for lower-cost voice
communications.
The Mediatrix units link any standard analog, ISDN
BRI, or T1/E1 PRI connection to the IP network and
deliver the clarity of toll quality voice for a
comprehensive VoIP solution.
T.38 FoIP, fax bypass, and modem bypass
capabilities ensure that the Mediatrix 3000 gateways
seamlessly transport voice and data services. The
Mediatrix 3000 gateways offer flexibility and
scalability for VoIP network integration and low
bandwidth voice.
With configurable FXS, NT/TE BRI/PRI ports, callswitching, and user-programmable call routing
(including caller/called ID), Mediatrix 3000 gateways
integrate smoothly into existing PBX and PSTN
networks.
Mediatrix 3000 Hardware Models
Mediatrix 3300 – FXS
7 FXS + 1 Bypass port per analog card
1 or 2 cards
Mediatrix 3400 – BRI
4 + 1 bypass ISDN BRI ports software
configurable as NT or TE per card
1 or 2 BRI cards
8 or 16 simultaneous calls
Configurable point-to-point, point-to-multipoint
and connector pinout
Cut-through relay for emergency operation
(bypass connection)
Optional power feeding module
Mediatrix 3530 – PRI T1
23 or 46 simultaneous calls
1 or 2 ISDN PRI ports
NT/TE software configurable
Mediatrix 3630 – PRI E1
30 or 60 simultaneous calls
1 or 2 ISDN PRI ports
NT/TE software configurable
Technical Specifications
Voice Processing
Vocoders: G.711 (A-law, µ-law), G.723.1,
G.726, G.729a/b
G.168 echo cancellation
DTMF detection and generation
Carrier tone detection and generation
Silence detection / suppression and Comfort
Noise Generation level software adjustable
Configurable dejitter buffer
Configurable transmit packet length
RTP/RTCP - RFC 1889, RFC 1890, RFC 2833,
RFC 3389
Fax and Modem Support
Fax over IP
T.38 Fax relay (9.6 k, 14.4 k)
G.711 Fax and Modem Bypass
Clear channel (G.711) or T.38
IP Telephony Protocol
SIP
Management
SNMPv3, HTTP, FTP, TFTP, HTTPS
Auto-provisioning for VoIP parameters
Automatic firmware download
User-friendly web Pages for VoIP Parameters
ISDN Signaling
Euro ISDN EDSS-1 / ETSI PRI/NET5
ETS 300 011 (ISDN PRI UNI)
ETS 300 012-1 (ITU-T I.430)
ETS 300 402-2 (ITU-T Q.921)
ETS 300 403-1/2 (ITU-T Q.931)
ETS 300 102-2 (ITU-T Q.931)
ISDN NI-2 (US T1 PRI)
ISDN DMS100 (US T1 PRI)
ISDN 5ESS (US T1 PRI)
ISDN speech, audio and data (Fax Gr 4, UDI 64,
RDI 64)
Voice Routing
Local switching
Interface hunt groups
Routing Criteria
•
Interface
•
Calling/called party number
•
Time of day, day of week, date
•
ISDN bearer capability
Number manipulation functions
•
Replace numbers
•
Add/remove digits
•
Multiple remote gateways
•
PLAR
QoS Marking
TOS/DiffServ
IEEE 802.1p/Q
WAN Connection
1 x 10/100 BaseT Ethernet RJ-45 connector
SSaalleess DDeeppaarrttmmeenntt
AAmmeerriiccaass -- TTeell:: 11--887777--GGEETT--VVOOIIPP // ((887777)) 443388--88664477 FFaaxx:: ((881199)) 882299--55110000
EEuurrooppee,, MMiiddddllee EEaasstt,, AAffrriiccaa -- TTeell:: ++3399--0022--8844774422228811 FFaaxx:: ++3399--0022--8844774422221122
MMIIPP--GGEESS006600772277 33000000PPrroodduuccttBBrroocchhuurree
Secure Controller Option
Specifications
IP Routing NAT and Firewall
SIP aware NAT/PAT/Firewall (SIP Proxy based)
with standard ALGs
Statefull inspection
RIPv1 and v2
Static routes
IP filtering and Port forwarding
DHCP Client
DHCP Server
PPPoE client
VLAN support
QoS / Traffic Control
Marking Incoming traffic, Locally generated traffic
or Both
Traffic shaping
Bandwidth guarantees and Limits
Classification by Port, Appl, Address, TOS byte
VPN
Encryption AES128, AES192, AES256, DES,
3DES
Authentication MD5 and SHA
Point-to point VPN or Roadwarrior configuration
Transport/Tunnel support
LAN Switch
4 Ethernet 10/100 Base-T Ethernet RJ-45 ports
enabled with the SC option.
Physical Specifications
Operating Environment
Operating temperature: 0oC to 40oC
Storage temperature: -20oC to +70oC
Humidity: up to 85 %, non-condensing
Power Supply
Internal 100-240 VAC power supply
Mechanical
Rack mount, Desk mount, Wall mount
2 interface card slots
Stackable units to increase port count
Dimensions
Height: 4.4 cm (1.73 in.) approx.
Width: 44.5 cm (17.5 in.) approx.
Width (mounting brackets): 48.5 cm (19 in.)
approx.
Depth: 20.5 cm (8 in.) approx.
Ordering Models
Analog BRI T1 PRI E1 PRI
Digital
Gateway
Secure
Controller
N/A Mediatrix
3400 DG
Mediatrix
3300 SC
Mediatrix
3400 SC
Mediatrix
3500 DG
Mediatrix
3500 SC
Mediatrix
3600 DG
Mediatrix
3600 SC
