The Mediatrix 3600 Series allows
enterprises to lower communications
costs over any IP link.
It is a multi-function device combining
VoIP IAD & Gateway in a flexible and
powerful platform. It applies to SIP
Trunking, PBX IP Trunking, and PSTN
access for local VoIP equipments
solutions.
The Mediatrix 3600 Series also allows
Carriers, Service Providers, and System
Integrators to deploy secure systems and
generate additional revenue streams.
Key Benefits
Feature-rich carrier grade product.
1 or 2 ISDN E1 PRI interface ports.
30 or 60 simultaneous calls.
Deployable in SIP VoIP networks.
User-programmable call handling.
Security features: SNMPv3, SSH, HTTPS.
Hardware ready and capable to support SRTP and
SIP over TLS.
Proven voice algorithms implemented on dedicated
DSP engine for enhanced voice quality on each
interface card.
Fax over IP support, including T.38.
Multiple codec support.
Remote management capabilities.
Mediatrix® 3600 Series
Digital VoIP Gateway – E1 PRI
Product Overview
Designed specifically for enterprise applications, the
Mediatrix 3600 Series gateways make use of existing
broadband access equipment to connect to any
standards-based VoIP network.
The Mediatrix 3600 Series gateways meet the
requirements of enterprises that want to connect their
ISDN equipment, such as PBXs, through a E1 PRI
interface to an IP network or as a gateway to the PSTN.
The Mediatrix 3600 Series is targeting:
Enterprises with branch offices and remote offices,
including SOHOs.
Enterprises seeking access to the benefits of Voice
over IP without discarding existing legacy
equipment.
Enterprises wishing to implement Voice over IP
through a gradual, transparent, and cost-effective
migration.
Multi-tenant / multi-dwelling units and premises
wishing to implement Voice over IP while
maintaining existing wiring and handsets.
Enterprises looking to implement secure RTP
(SRTP) and Secure SIP (SIPS) in the future.
The Mediatrix 3600 Series is member of the 3000
family, which additionally offers IP Router, VPN, SIP
aware NAT/Firewall and QoS control services.
Americas - Tel: 1-877-GET-VOIP / (877) 438-8647 Tel: (819) 829-8749 Fax: (819) 829-5100
Europe, Middle East, Africa - Tel: 49 (0)30-3496-2085 / CALA - Tel: (954) 349-0394 Fax: (954) 349-8722
©© 22000077,, MMeeddiiaattrriixx TTeelleeccoomm,, aa DDiivviissiioonn ooff MMeeddiiaa55 CCoorrppoorraattiioonn
MMIIPP--GGEESS007700111155 33660000PPrroodduuccttBBrroocchhuurree
Applications
The Mediatrix 3600 VoIP gateways allow any office
to use an existing IP network for lower-cost voice
communications.
The Mediatrix units link any standard ISDN E1 PRI
connection to the IP network and deliver the clarity
of toll-quality voice for a comprehensive VoIP
solution.
T.38 FoIP, fax bypass, and modem bypass
capabilities ensure that the Mediatrix 3600 gateways
seamlessly transport voice and data services. The
Mediatrix 3600 gateways offer flexibility and
scalability for VoIP network integration and lowbandwidth voice.
With configurable NT/TE E1 PRI ports, callswitching, and user-programmable call routing
(including caller/called ID), Mediatrix 3600 gateways
integrate smoothly into existing PBX and PSTN
networks.
Mediatrix 3600 Hardware Models
Mediatrix 3631 – 1 x PRI E1 card
Up to 30 simultaneous calls
1 ISDN E1 PRI port software configurable
NT/TE software configurable
Mediatrix 3632 – 2 x PRI E1 cards
Up to 60 simultaneous calls
2 ISDN E1 PRI ports software configurable
NT/TE software configurable
Technical Specifications
Voice Processing
Vocoders: G.711 (A-law, µ-law), G.723.1,
G.726, G.729a/b
G.168 echo cancellation
DTMF detection and generation
Carrier tone detection and generation
Silence detection / suppression and Comfort
Noise Generation level software adjustable
Configurable dejitter buffer
Configurable transmit packet length
RTP/RTCP - RFC 1889, RFC 1890, RFC 2833,
RFC 3389
Fax and Modem Support
Fax over IP
T.38 Fax relay (9.6 k, 14.4 k)
G.711 Fax and Modem Bypass
Clear channel (G.711) or T.38
IP Telephony Protocol
SIP
Management
SNMPv3, HTTP, FTP, TFTP, HTTPS
Auto-provisioning for VoIP parameters
Automatic firmware download
User-friendly web Pages for VoIP Parameters
ISDN Signaling
ISDN NI-2 (US T1 PRI)
ISDN DMS100 (US T1 PRI)
ISDN 5ESS (US T1 PRI)
Euro ISDN EDSS-1 / ETSI PRI/NET5
ETS 300 011 (ISDN PRI UNI)
ETS 300 012-1 (ITU-T I.430)
ETS 300 402-2 (ITU-T Q.921)
ETS 300 403-1/2 (ITU-T Q.931)
ETS 300 102-2 (ITU-T Q.931)
ISDN speech, audio and data (Fax Gr 4, UDI 64)
Voice Routing
Local switching
Interface hunt groups
Routing Criteria
•
Interface
•
Calling/called party number
•
Time of day, day of week, date
•
ISDN bearer capability
Number manipulation functions
•
Replace numbers
•
Add/remove digits
•
Multiple remote gateways
•
PLAR
QoS Marking
TOS/DiffServ
IEEE 802.1p/Q
WAN Connection
1 x 10/100 BaseT Ethernet RJ-45 connector
Physical Specifications
Operating Environment
Operating temperature: 0oC to 40oC
Storage temperature: -20oC to +70oC
Humidity: up to 85 %, non-condensing
Power Supply
Internal 100-240 VAC power supply
Mechanical
Rack mount, Desk mount, Wall mount
2 interface card slots
Stackable units to increase port count
Dimensions
Height: 4.4 cm (1.73 in.) approx.
Width: 44.5 cm (17.5 in.) approx.
Width (mounting brackets): 48.5 cm (19 in.) approx.
Depth: 20.5 cm (8 in.) approx.
